Condition: excellent (used), CNC vertical lathe Gildemeister CTV 250 Working area: Chuck diameter: 250mm X-axis: 800mm Z-axis: 300m Spindle head: 170 h5 Spindle diameter in the front bearing: 120mm Hodpfovuqm Sox Apdjw Spindle bore: 79mm C-axis Number of work stations: 12 Videos available!!

Condition: good (used), turning diameter over bed slide: 1,250 mm, turning length: 8,000 mm, workpiece weight (max.): 12,500 kg, DBC Turning Length: 8000mm Swing over bed Ø: 1280mm Swing over cross slide Ø:1000mm Length: 12500mm Width: 2100mm Height: 1800mm Weight: 35000kg Hsdpfx Apowwtcmjdew

Condition: new, Maximum turning height: 230 mm Maximum turning length: 1000 mm Turning diameter over bed: 460 mm Turning diameter without bridge: 690 mm Turning diameter over support: 285 mm Bore diameter: 58 mm Spindle mounting according to DIN 55029: 1 - 6" 12 speeds: 25 - 2000 rpm Travel – Top slide: 128 mm Travel – Cross slide: 285 mm Feed rates (longitudinal): 0.031 - 1.7 mm/rev Feed rates (transverse): 0.014 - 0.784 mm/rev Thread (metric): 0.25 – 3.5 mm Thread (inch): 2 - 112 TPI Thread (diametral): 8 - 144 D.P. Thread (module): 0.25 - 3.5 mm Motor power: 400 V / 50 Hz / 5.5 kW Tailstock: MK 4 Dimensions L x W x H: 2020 x 1080 x 1600 mm Weight: 1680 kg Accessories / Special features: • Heavy-duty lead screw and feed screw lathe with extensive standard equipment. Low vibration and smooth running. Includes a solid base and machine bed. • 3-axis digital display • 3-jaw chuck Ø 250 mm • 4-jaw chuck Ø 300 mm • Stationary and traveling steady rest • Multifix size B quick-change tool holder system, mounted, 5-piece • Strong and torsion-resistant construction of the machine base and bed, cast in one piece from vibration-absorbing gray cast iron. • Hardened and ground bed guide rails • Generously sized machine bed • All guides are equipped with adjustable wedge strips • Central lubrication in the bed slide • Right/left rotation switchable on the bed slide • Removable bed bridge for machining large workpieces • Adjustable tailstock for turning tapers • Guaranteed concentricity < 0.015 mm measured in the spindle nose • Enclosed feed gear, gears and shafts are hardened and ground • Clear control panel with solid selector levers for selecting speeds Hodpfx Aok Dn Nwopdow • Oil bath gear system with hardened and ground gear teeth • Handwheels with adjustable fine scale • Main spindle hardened and ground and running in an oil bath, as well as guided by tapered roller bearings • Longitudinal feed, switchable by means of 4 adjustable cam followers • Mechanical foot-operated spindle brake • Lead screw cover • Acceptance test report • Manufactured according to DIN 8606 toolmaker's accuracy • CE compliant Delivery time: immediate, subject to prior sale Year of manufacture: 2023 (unused showroom machine) Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: good (used), Spare parts suitable for a high-performance universal lead and feed screw lathe VOEST DA 210-2000 - Apron (clutch box) Hsdpfxew Sfigj Apdjw - Lead, feed, and shifting screw - End bearing block - Spindle support - Change gears - Rack bars Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: good (used), Centre height: 290 mm Centre distance: 3000 mm Swing diameter over bed: 580 mm Swing diameter over cross slide: approx. 400 mm Spindle bore: 63 mm Spindle mount DIN 55027: Size 8 Speed range: 25 – 1120 rpm Bed width: 365 mm Longitudinal feed: 0.03 – 1.3 mm/rev Cross feed: 0.008 – 0.33 mm/rev 80 metric threads: 0.25 – 76 mm 96 Whitworth threads: ½” – 152 tpi 52 module threads: 0.25 – 22 module 88 diametral pitch threads: 1 – 176 DP Tailstock taper: MK 4 Drive power: 5.5 kW Dimensions (L x W x H): 4450 x 1300 x 1350 mm Weight: 2800 kg Hjdpextu Ersfx Apdsw Accessories / Special Features: • Quick-change tool post, brand "Multifix", size B • Hardened bedways • Bed stop Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: good (used), Year of construction: 1990, Maximum height 250 mm Turning length 640 mm Maximum turning diameter over the bed cover 500 mm Maximum turning diameter over the compound slide 290 mm Spindle head according to DIN Size 140 h5 Spindle bore 72 mm Speed range 25 – 5000 rpm Feed rate range, longitudinal and transverse 0.5 – 5000 mm/min Rapid traverse, longitudinal 15 m/min ditto, transverse 10 m/min Main drive 22 kW Dimensions with chip conveyor L x W x H 4527 x 1940 x 1730 mm Hjdpfx Apjz I Ubmedow Weight with chip conveyor 5140 kg This machine does not have a tailstock! Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany

Condition: used, Year of construction: 1975, Technical details: turning diameter over bed: 400 mm turning diameter over support: 220 mm turning length: 1100 mm centre height: 180 mm spindle passage: Ø 45 mm range of revolution per miute: 31,5 - 1.400 / 12 step U/min range of feed in x - axis: längs: 0,08 - 1,10 m/min range of feed in y - axis: quer: 0,028 - 0,40 m/min tailstock quill taper MT: MK4 tailstock quill adjustment: 200 mm total power requirement: 4,0 kW weight of the machine ca.: 1,7 t dimension machine xH: 2,5 x 1,1 x 1,4 m Equipment: -Three-jaw chuck Ø 250mm manufacturer Forkardt with interchangeable jaws -Multifix steel holder -Cooling water device with pump Hjdpfeu Ix E Hox Apdsw -chuck guard -chip collecting tray -chip guard Accessories: -chuck spanner -tool holder -2 pieces gears *

Condition: used, Year of construction: 1951, Technical details: turning diameter over bed: 400 mm turning diameter over support: 240 mm turning length: 1100 mm centre height: im Bett gemessen: 190 mm spindle passage: 40 mm range of revolution per miute: 37,5 - 950 U/min total power requirement: 3,5 kW tailstock quill taper MT: MK 4 tailstock quill: 180 mm weight of the machine ca.: 1,6 t dimension machine xH: 2,6 x 1,4 x 1,3 m The lathe is equipped with threading device. It is rewired and a new control cabinet is made. Emergency stop switch and chuck protection 3-jaw chuck Ø 250mm Hsdpeu Ix Hdsfx Apdjw rotating tip Tool support quadruple steel holder tool support approx. 30° right/left swiveling 4 Stück Wechselräder Copying device (taper 15° right/left) *

Condition: used, Year of construction: 1986, Technical details: turning diameter over bed: 315 mm turning diameter over support: 200 mm turning length: 500 mm turning diameter over bed: 315 mm swing diameter over face slide: 200 mm center height measured in bed: 180 mm spindle passage: Ø 32 mm range of revolution per miute: 56...2.800 / nur only 6 step links-rechts U/min range of feed in x - axis: längs: 0,02..0,8 m/min range of feed in y - axis: plan: 0,01..0,4 m/min tailstock quill taper MT: MK 4 tailstock quill adjustment:: 140 mm total power requirement: 5,5 kW Hsdpfx Apsu Ix Hqedow weight of the machine ca.: 2,0 t dimension machine xH: 2,1x 1,1 x 1,4 m -Workpiece pick-up via collet chuck -travels longitudinal slide= 580mm and cross slide=170mm -incl. tooling device lathe support -incl. change gears -steady rest Ø 100mm -fourfold tool holder The machines functionality is limited ! 6 speeds are currently selectable! (224/1800 ; 280/2240; 355/2800 rpm.) i.D. *

Condition: used, Year of construction: 2004, Technical details: turning diameter over bed: 610 mm turning dia. over face-slide: 350 mm swing diameter over bed: 610 mm centre distance: 1390 mm control: Fanuc 0i-Mate TC x-axis: plan: ca. 305 mm z-axis: längs: ca. 1350 mm revolution per minute: 22 - 2200 U/min feed:: X + Z-Achse: 5 / 10 m/min. spindle bore: Ø 70 mm tool turret - number of stations: 6 tailstock quill taper MT: MK5 tailstock quill stroke: 150 mm Weight approx.: 2,7 t total power requirement: 15 kW dimension machine xH: 3,7 x 1,7 x 1,7 m dimensions of hydaulic: 630 x 460 x 900 mm other features: -hydr. chuck TONFAU Ø 300mm -hydraulics -Coolant system Hsdpfx Aeu Ix I Uepdjw -control panel -double foot switch accessories: -div. mold jaws -div. soft jaws -6 footrests *

Condition: used, Year of construction: 1987, Technical details: turning diameter over bed: 180 mm turning length: 490 mm swing diameter: 450 mm cross travel: Z-Weg: 168 mm control: Traub TX8D revolution per minute: 20 - 4000 U/min Hedpfx Apeu Ix N Sedew spindle passage: Ø 60 mm operating hours - idle run: 23.495 h tool turret: 12 tools total power requirement: 38 kW Weight approx.: 4,2 t dimension machine xH: 3,6 x 2,5 x 2,2 m Tool holder straight shank DIN 69880 (VDI 3425) Ø 40x63 Röhm lathe chuck Ø 200mm hydraulic clamping Operation via double foot switch and control panel/operating panel. Coolant device The Traub carries an integrated chip conveyor with an ejection height of 1,100mm (currently without function). Accessories: multiple small parts 8 x machine feet without tailstock i.D. *

Condition: used, Technical details: spindle passage: 60 mm turning length: 45 mm turning diameter: max. 56 mm drill depth: max. 70 mm revolution per minute: 48 - 1500 (spindle) U/min threading: Drehzahl: 24 - 750 U/min tool turret - number of stations: 8 Hjdpfxou Iwyie Apdjw total power requirement: 5,5 kW weight of the machine ca.: 2,4 t space requirement of the machine approx.: L:2,1x1,0x1,8 m Cam-controlled automatic lathe according to template. Workpiece is clamped via clamping cartridge. Turret head: disk turret Hahn&Tessky Esslingen, tool path 80mm, adjustment 36mm, distance collet/turret head min./max.: 72/188mm 2 pieces turning support, working stroke 45mm 2 piece cutting off support, working path approx. 40mm Cooling water system Machine is not connected. Sale at a low selling price. *

Condition: used, Technical details: turning diameter over bed: 320 mm turning length: 800 mm centre distance: 800 mm centre height: 150 mm spindle bore of work spindle: 30 mm range of revolution per miute: 35 - 1500 / 16 step U/min range of feed in x - axis: 0,04 - 2,4 / 30 step m/min tailstock quill adjustment:: 125 mm tailstock taper MT: MK2 dimension machine xH: 1,7 x 0,8 x 1,5 m Equipment and other features: Hodpfeu Ixy Dex Apdsw -3-jaw chuck Röhm 160mm -chuck guard -protection system WxH: 510x400mm -Multifix tool clamp (4 pieces) -Tip in tailstock -Upper slide swivels +/- 45°, maximum travel = 100mm -Cross slide travel = 300mm feed Pump for coolant device (without feed) *

Condition: used, Year of construction: 1987, Technical details: turning diameter over bed: 500 mm turning diameter over support: 280 mm turning length: 1500 mm centre distance: 1500 mm turning dia. in gap: 730 mm spindle bore of work spindle: 65 mm range of revolution per miute: 25-1250 / 32-1600 / 36-1800 - 18 step U/min feed:: 0,05 - 8,5 mm rapid motion - x-axis: 4 m/min Hsdpfx Apju Ixznedsw rapid motion - y-axis: 1,26 m/min tailstock quill taper MT: 5 tailstock quill adjustment:: 200 mm total power requirement: ca. 8,2 kW weight of the machine ca.: 2,5 t dimension machine xH: 3,2 x 1,3 x 1,5 m Thread cutting possible Cross slide travel 300 mm, feed 0.015 - 2.8 mm (clutch end position switching not functional, manual switch-off necessary) Top slide with 4-fold tool holder Steel plate Ø 705mm with offset threaded holes *

Condition: used, Technical details: turning diameter over bed: 230 mm turning diameter over support: 135 mm Hodpfx Aezvnq Topdow centre distance: 2000 mm spindle bore: 60 mm tailstock quill taper MT: MK 5 tailstock quill adjustment:: 300 mm total power requirement: 5,5 kW weight of the machine ca.: 2,5 t dimension machine approx.LxWxH: 3,7 x 1,20 x 1,30 m • 4 change gears installed • No taper turning attachment • 3-jaw chuck: Ø 350 mm • 4-jaw chuck: Ø 315 mm • Coolant system available *

Condition: used, Year of construction: 2008, Technical details: turning diameter over bed: 600 mm turning dia. over face-slide: 540 mm turning length: 550 mm longitudinal traverse (z-axis): 800 mm facing movement (x-axis): 260 mm control: Fanuc 18i-TB spindle bore: Ø 73 mm bar material dia.: Ø 65 mm revolution per minute: 0 ... 5000 steples U/min max. torque on the spindle: max. 250 Nm rapid traverse in x-y-z axis: X/Z: 30 m/min. / Y: 12 m/min. rapid traverse c-axis: 1000 U/min. tool turret - number of stations: 12 (Sauter) operating pressure: 6,0 bar electrics - voltage/frequency: 3 x 400 / 50-60 V/Hz operating pressure: 6 bar total power requirement: 40 kVA Weight approx.: 5,7 t dimension machine xH: 2,2 x 3,4 x 2,4 m dimension swarf conveyor LxWxH: ca. 2,9 x 0,6 x 0,55 (0,38 to) m dimensions LxWxH: Spänewanne: ca. 1,6 x 1,3 x 0,25 (0,2 to) m transport measurements machine: ca. 3,3 x 1,9 x 2,2 m The machine has a C-axis, E-axis, Y-axis, and W-axis. Powered tools can be used in all positions. Distance between spindle and counter spindle = 1050 mm. Counter spindle: A2-6, travel distance 800 mm, spindle diameter 105 mm, torque 250 Nm. Control cabinet equipped with Rittal cooler With hinged chip conveyor Chip tray Compressed air gun Hjdpfxovvtpxj Apdjw The machine has NO lathe chucks on sale as is! *

Condition: used, Year of construction: 2007, Technical details: turning diameter over bed: 762 mm turning length: 850 mm facing movement (x-axis): 287 mm longitudinal traverse (z-axis): 864 mm control: CNC Haas spindle passage: 76 mm revolution per minute: max. 3400 steples U/min tailstock taper ISO: Ø 290 tailstock quill stroke: ja mm tool turret - number of stations: 12 electrics - voltage/frequency: 360/ 400 V - 50-60 Hz V/Hz Weight approx.: 6,3 t transport measurements machine: ca. 3,4 x 2,1 x 2,4 m Equipment: 3-jaw power chuck KITAKAWA Ø 250 mm (without jaws) 4200 rpm. Operable via 2-position foot switch. Tool turret with powered tools available. Electric coolant system provided. Tool measuring system available. I.D. * Hodpfjvvt Emex Apdow

Condition: used, Year of construction: 1999, Technical details: turning diameter over bed: 665 mm turning dia. over face-slide: 530 mm turning length: 750 mm max. turning diameter: 395 mm longitudinal traverse (z-axis): 500 mm facing movement (x-axis): 600 mm control: TX8H spindle passage: 80 mm revolution per minute: 60 -12.000 U/min tool turret - number of stations: 24+1 operating hours - idle run: 26466 h operating pressure: 6 bar diameter of quill: 85 mm quill stroke: 140 mm tool taper: ISO 40 total power requirement: 36 kW Weight approx.: 6,6 t dimension machine approx.LxWxH: 4,8 x 3,5 x 2,8 m The TRAUB TNA 400 is a high-performance CNC turning machine designed for the precise complete machining of turned parts. Equipped with the proven TRAUB TX8H control system, the machine is suitable for both single-part and series production. It features a hydraulic chuck, tailstock, and a fully enclosed working area with a coolant system. Its robust design ensures high precision and reliable process stability in continuous industrial operation. Hedpfx Apsz Ndq Tedjw Equipment: ·TX8H CNC control ·Swivel table ·Central lubrication system ·Coolant system ·Spindle cooling ·Spindle air blow function ·Working area lighting ·Chip flushing nozzles ·Electronic handwheel ·Leveling elements ·Signal tower light ·Manual wash gun ·Macro programming ·NAVI-MILL workshop programming ·Programming cycles ·Program runtime calculation ·Parts counter ·Intelligent handwheel ·Tool magazine with 24 + 1 tool positions *

Condition: used, Year of construction: 1976, Technical details: turning diameter over bed: 340 mm turning diameter over support: 190 mm turning length: 800 mm turning length: plan =140 / quer =120 mm Hsdpfx Apeva Ertjdew center height over bed: 170 mm spindle bore of work spindle: Ø 40 mm range of revolution per miute: 25 - 2000 / 20 step U/min feeds:: längs: 0,028 - 1,0 / quer: 0,012 - 0,44 mm tailstock quill taper MT: MK3 tailstock quill adjustment:: 120 mm total power requirement: 3,0 kW weight of the machine ca.: 1,1 t dimension machine xH: 2,0 x 0,8 x 1,4 m Threading possible: Metric, Withwort and modular thread Equipment: - 2-way measuring device VISUCONT - 3-jaw chuck Ø 205mm with internal clamping jaws - quick-change steel holder Multifix - foot brake - cooling water pump (exclusive supply) *

Condition: used, Year of construction: 1979, Technical details: turning diameter over bed: 540 mm turning length: 630 mm centre distance: 900 mm center height over bed: 270 mm center height: über Hinterschlitten: 138 mm Turning diameter: über Hinterschlitten: 250 mm longitudinal feed: 700 mm facing movement : 80 / 75 mm revolution per minute: 1,8 - 450 bei 8x steples U/min clamping diameter: 26 mm range of feed in x - axis: 12 step / 0,063 - 0,63 mm/U range of feed in y - axis: 36 step / 0,070 - 1,11 mm/U tailstock quill: MK5 mm tailstock quill stroke: 250 mm Total power requirement: 7,0 kW machine weight approx.: 3,76 t dimension machine xH: 3,2 x 1,2 x 1,8 m Hjdpfxjvbhv Re Apdew Application: Mainly for relief turning and relief grinding of cutting tools (especially hobs with and without thread pitch). Back turning and relief grinding is possible from the front, the rear and in the axial direction of the machine. Main drive via 8-stage manual gearbox. Feed gearbox is designed as a 12-stage manual gearbox. Swivel range of the rear slide = 360deg. Swivel range of cross slide = 360deg. Lathe chuck is cone disc Ø 200mm with MK5 Equipment: turning mandrel Ø 49,5 x 400mm Measuring system ARBAH-L 3+1 Inverter FRENIC 5000G11 i.D. *

Condition: used, Technical details: turning diameter over bed: 350 mm turning diameter over support: 200 mm turning length: 560 mm centre height: 170 mm spindle bore: Ø 32 mm range of revolution per miute: 36...1.800 / 8 step U/min range of feed in x - axis: längs: 0,02..0,8 m/min range of feed in y - axis: plan: 0,01..0,4 m/min tailstock quill taper MT: MK 4 tailstock quill adjustment:: 140 mm total power requirement: 5,5 kW weight of the machine ca.: 2,0 t dimension machine xH: 2,1x 1,1 x 1,4 m Hedpfjvadd Ijx Apdsw -Working stroke longitudinal support=580mm; plan support=170mm; top support 130mm; -Workpiece support via 3-jaw chuck Niles Ø 160mm, speed 2,800 rpm. -Tool holder quick change steel holder Multifix. Equipment: Cooling water pump 4 pieces machine feet Copying device *

Condition: excellent (used), Year of construction: 2010, operating hours: 9,416 h, functionality: fully functional, feed length X-axis: 535 mm, feed rate Z-axis: 3,845 m/min, turning diameter over cross slide: 630 mm, turning diameter: 950 mm, turning diameter over top slide: 630 mm, spindle bore: 254 mm, spindle speed (max.): 630 rpm, total height: 1,850 mm, total width: 2,105 mm, Hankook Protec 9NC Hollow Spindle Oil Country Lathe Model: Protec 9NC Control: Fanuc 21i-TB Year: 2010 Spindle Bore: 254mm Capacity: 950 x 4000mm Hedjz S Nc Uspfx Apdow Swing Over Cross Slide: 630mm Spindle Speeds: To 630 RPM (2 Ranges) Main Motor: 37 KW Machine With: Double 4 Jaw Manual Chucks (front or rear) Duplomatic 8 Station Turret 2 x Fixed Steadies

Condition: used, Year of construction: 2004, turning diameter 820 mm turning length 3000 mm control Siemens 840 D workpiece weight 2,5 t Hjdpfoz S Nx Ajx Apdsw drive of main spindle 77 kW spindle nose A15 spindle bore 160 mm Workpiece head (C-axis) 0,005 grad max. torque on the working spindle 2500 Nm main spindle speeds: 0-2.430 U/min feeds z-axis 0,1-18.000 mm/min rapid traverse Z-axis 18 m/min feeds x-axis 0,1-30.000 mm/min rapid traverse X-axis 30 m/min steady 50-350 Spannbereich tailstock - quill dia 180 mm tailstock - travel of quill 170 mm y-axis -100/+150 mm rapid traverse y-axis 12.000 mm/min b-axis -105/+95 Grad milling spindle - taper HSK100 milling spindle motor 43 kW milling head speed 1-5.500 U/min max. torque on the milling spindle 336 Nm tool changer 96 Plätze weight of tools max. 15 kg total power requirement 166 KVA weight of the machine ca. 40 t dimensions of the machine ca. 112x4,4x3,85 m

Condition: ready for operation (used), Year of construction: 2009, travel distance X-axis: 300 mm, travel distance Z-axis: 900 mm, total height: 5,800 mm, total width: 5,500 mm, overall weight: 26,000 kg, controller manufacturer: FANUC, controller model: 0i-TC, product length (max.): 7,200 mm, number of axes: 2, Vertical turning machine manufactured in 2009. This SMTCL QTC 20090 features a maximum turning diameter of 2,000 mm and a turning height of 1,600 mm. It includes a manual 4-jaw chuck with a diameter of 1,600 mm and a 12-position tool changer magazine. If you are looking to get high-quality turning capabilities, consider the SMTCL QTC 20090 machine we have for sale. Contact us for further details regarding this machine. • CNC control: FANUC 0i-TC with 10.4" screen • Mobile vertical crossbar with 5 indexing positions • CE safety equipment • Manual 4-jaw chuck diameter: 1,600 mm • Maximum turning diameter: 2,000 mm • Maximum turning height: 1,600 mm • Chuck speed: 1–254 rpm (2 ranges) • Motor power: 55 kW (30-minute rating) • RAM cross-section: 220 × 220 mm • 12-position tool changer magazine • Electrical supply: 380 V ±10% Additional equipment • Direct measurement system: HEIDENHAIN • RENISHAW tool presetting system • Turning tool holder • Chip extractor • Work light • Access cover and stairs Hodpfoz Sy Tkjx Apdsw Technical Specification Driven Tools No

Condition: excellent (used), Year of construction: 2001, spindle bore: 150 mm, spindle motor power: 95,000 W, total height: 3,800 mm, total length: 16,000 mm, total width: 5,000 mm, overall weight: 80,000 kg, Swing over bed Ø: 2000mm Swing over cross slide Ø:1550mm DBC Turning Length: 8000mm Spindle bore: 150mm Spindle power: 95kW Bed width: 1400mm Tailstock spindle Ø: 260Ø Stroke pinole: 200mm Spindle taper: Metric 80Mk Workpiece weight: 25000 Power: 95A Speeds / ranges: 360Rpm Feed rate X-Axis: 0 - 6000mm/min. Hjdpfxjz Sy Two Apdow Feed rate Z-Axis: 0 - 6000mm/min. Length: 16000mm Width: 5000mm Height: 3800mm Weight: 80000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
