Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: YS-2674, turning height: 1,250 mm, workpiece weight (max.): 5,000 kg, turning diameter: 1,600 mm, faceplate diameter: 1,250 mm, controller model: Fanuc 0i-TD, TECHNICAL DETAILS Faceplate diameter: 1,250 mm Max. torque on faceplate: 12,500 Nm Iijdpfx Ajzb Uy Tjquec Turning height: 1,250 mm Max. turning diameter: 1,600 mm Max. workpiece weight: 5,000 kg Table speed: 2 - 300 rpm Travel range X-axis: 1,475 mm Travel range Z-axis: 900 mm Rapid traverse: 10 m/min Spindle taper: ISO BT50 Number of tool positions: 12 MACHINE DETAILS Control system: Fanuc 0i-TD Total power: 75 kW Dimensions & Weight Footprint: approx. 4.7 x 5.8 x 5.5 m Machine weight: approx. 32 t EQUIPMENT Tool changer magazine for 12 turning tools with BT 50 shank Note: The €5,000 for dismantling and loading applies to the preparation for EU transport. Preparation for sea transport is possible; costs upon request.

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, turning diameter over cross slide: 75 mm, turning length: 325 mm, turning diameter: 180 mm, travel distance X-axis: 56 mm, travel distance Z-axis: 176 mm, TECHNICAL DETAILS Swinging diameter over bed: 180 mm Swinging diameter over cross slide: 75 mm Turning length: 325 mm Travel in X-axis: 56 mm Travel in Z-axis: 176 mm Spindle speed range: 20 - 6,300 rpm Iijdpezb Ekcjfx Aquec Spindle bearing diameter in the front bearing: 50 mm Feed force in Z-direction max.: 3,000 N Spindle bore: 30 mm MACHINE DETAILS Control: Fanuc 21T Main spindle power max.: 3.7 kW Voltage: 400 V Frequency: 50-60 Hz Dimensions & Weight Dimensions (L x W x H): 2,200 x 1,000 x 1,620 mm Machine weight approx.: 1 t EQUIPMENT Automatic chuck Various accessories Interface for bar feeder

Condition: ready for operation (used), Year of construction: 2001, operating hours: 42,400 h, functionality: fully functional, travel distance X-axis: 800 mm, spindle speed (max.): 5,000 rpm, turning length: 300 mm, spindle bore: 79 mm, controller model: Siemens 840D, TECHNICAL DETAILS Turning length: 300 mm Travel range X-axis: 800 mm Travel range Z-axis: 300 mm Speed range main drive: 20 - 5,000 rpm Speed range C-axis: 0 - 100 rpm Iijdpozb Efgjfx Aqusc Spindle bore: 79 mm Torque main drive: 200 Nm Torque at the spindle: 240 Nm Torque clamping device: 28 Nm Rapid traverse X-direction: 100 m/min Rapid traverse Z-axis: 45 m/min Tools and tool magazine Number of positions in the tool magazine: 12 Speed of powered tool max.: 6,000 rpm Tool holder: VDI 40 Clamping area in the work area (W x H): 340 x 430 mm Number of T-slots according to DIN 650: 7 MACHINE DETAILS Control model: Siemens 840D Power main spindle: 27 / 20 kW Total power consumption: 50 kVA Electrical version - voltage/frequency: 3~ / 400 V / 50 Hz Interface: yes Spindle operating hours: 42,400 h Power-on hours: 93,728 h Dimensions & Weight Machine dimensions (L x W x H): 3,200 x 3,950 x 2,800 mm Chip conveyor dimensions (L x W x H): 3,400 x 1,150 x 2,180 mm Machine weight: 8 t EQUIPMENT High-pressure coolant system (capacity: 500 l) Chip conveyor with oil mist separator / industrial filter IFM 1000CTV Workpiece loading and unloading device with 20 stations Power chuck (225 mm) Hydraulics 6x various turning tool holders 2x various tool holders (rotating)

Condition: ready for operation (used), Year of construction: 2015, operating hours: 43,196 h, functionality: fully functional, travel distance X-axis: 165 mm, travel distance Y-axis: 80 mm, controller model: Fanuc 310 is, spindle speed (max.): 5,000 rpm, counter spindle speed (max.): 5,000 rpm, No minimum price – guaranteed sale to the highest bidder! CNC turning center with comprehensive accessories! A wide range of like-new spare parts is also available! TECHNICAL DETAILS Travel X1 axis: 165 mm Travel X2 axis: 165 mm Isdpfx Asza Alhjqusic Travel Y1 axis: 80 (+50 / -30) mm Travel Z1 axis: 678 mm Travel Z2 axis: 640 mm Travel W2 axis: 690 mm Rapid traverse X/Y/Z/W axis: 30 m/min Acceleration X/Y/Z/W axis: 5 m/s² Main and counter spindle Power main spindle: 20 / 25 kW Power counter spindle: 17 kW Speed main spindle max.: 5,000 rpm Speed counter spindle max.: 5,000 rpm Bar diameter main spindle max.: 65 mm Bar diameter counter spindle max.: 45 mm Number of turrets: 2 Number of rotating tools per station: 12 driven positions Tool system: VDI 30 Speed driven tools: max. 4,000 rpm MACHINE DETAILS Control: Fanuc 310 is Coolant tank capacity: approx. 650 l Coolant pump capacity per turret: max. 20 l/min Pump pressure: 7 bar Connected power: 91 kVA Dimensions & Weight Machine dimensions (L x W x H): 4,500 x 1,990 x 2,300 mm Machine weight: approx. 9,500 kg Operating hours Power-on hours: 64,274 h Operating hours: 43,196 h EQUIPMENT IEMCA MASTER 865 MP 43 L bar loader Drive for slides 1 and 2, all 12 positions C-axis for main and counter spindle Y-axis for slide 1 Chip conveyor, belt type Counter spindle collet cleaning with coolant Workpiece discharge including belt Mechanical preparation for oil mist filter Electrical and software interface for bar loader Angular synchronization between main and counter spindle Automatic machine shutdown 2 additional inputs/outputs, 4 M-functions Thread drilling without compensation chuck Piece and time counter Software for polygonal turning for slides 1 and 2 Constant cutting speed Helical interpolation for slide 1 Spindle speed monitoring Four-color warning light Cooling unit for control cabinet Collet chuck type MPF 65/140 without axial feed for main spindle, max. diameter 65 mm Manual collet changer type SACO MPT65/140 and MPF65/140 Differential pressure for counter spindle with the possibility of setting two different clamping pressures 1 set of soft jaws for collet chuck type SMW 175-BBD Collet chuck type SMW 175-BBD for counter spindle including adapter for spindle adjustment Tool wear monitoring system for CNC FANUC Sister tool selection system for Tool Monitor CNC FANUC External flushing of jaws and collets with coolant on main and counter spindle

Year of construction: 2003, condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 250 mm, quill diameter: 60 mm, quill travel distance: 140 mm, spindle bore: 64 mm, spindle speed (max.): 4,000 rpm, machine/vehicle number: 2818.02, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Swinging diameter over bed: 400 mm Swinging diameter over cross slide: 230 mm Travel range X-axis: 250 mm Spindle head according to DIN 55027: A6 Spindle bore diameter: 64 mm Spindle diameter in the front bearing: 100 mm Speed range: 1–4,000 rpm Feed range, facing: 0.001–1,000 mm/rev Feed range, longitudinal and thread pitches: 0.001–2,000 mm/rev Rapid traverse, facing: 5 m/min Rapid traverse, longitudinal: 10 m/min Feed force, facing: 5,000 N Feed force, longitudinal: 7,000 N Tailstock Arbor diameter: 60 mm Arbor travel: 140 mm Taper: MK 4 MACHINE DETAILS Main spindle drive Power, digital AC motor at 40% duty cycle: 16 kW Isdpszb Hf Usfx Aqueic Power, digital AC motor at 60% duty cycle: 15 kW Power, digital AC motor at 100% duty cycle: 12 kW Gear stages: 2 Standard chuck size 1: 200 mm Standard chuck size 2: 250 mm Three-phase voltage: 400 V Frequency: 50 Hz Operating hours (according to meter): 4,521 h

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 020033, spindle speed (max.): 5,000 rpm, spindle diameter: 110 mm, controller model: Siemens SINUMERIK, empty load weight: 11,000 kg, counter spindle speed (max.): 5,000 rpm, The machine is expected to be available for approximately €4,000, including loading onto a truck (FOB). TECHNICAL DETAILS Working area X1-axis: 1,190 mm Working area Y1-axis: 120 mm Working area Z1-axis: 260 mm Working area X3-axis: 540 mm Working area Y3-axis: 120 mm Working area Z3-axis: 260 mm Handling space X1-axis: 490 mm Axes and Feed Feed force X1/Z1/Y1: approx. 8/10/10 kN Feed force X3/Z3/Y3: approx. 8/10/10 kN Rapid traverse speed X1/Z1/Y1: approx. 80/40/7.5 m/min Rapid traverse speed X3/Z3/Y3: approx. 40/40/7.5 m/min Acceleration X1/Z1/Y1: 7/7/7 m/s² Acceleration X3/Z3/Y3: 7/7/7 m/s² Spindle Speed at main and counter spindle: 5,000 RPM Power at 100% duty cycle, main spindle: 20 kW Torque at 100% duty cycle: 105 Nm Power at 40% duty cycle: 27 kW Torque at 40% duty cycle: 145 Nm Spindle bore: 65 mm Spindle diameter at front bearing: 110 mm Spindle nose diameter (cylindrical): 140 mm Hydraulic full-stroke cylinder OVS80 - Main spindle Piston stroke: 32 mm Piston area: 34.36 cm² Clamping pressure: 8 to 80 bar Tensile or compressive force at 80 bar: max. 27.2 kN Leakage oil volume at operating pressure 80 bar: max. 2.2 l/min Hydraulic full-stroke cylinder OVS65 - Counter spindle Piston stroke: 32 mm Piston area: 26.1 cm² Clamping pressure: 8 to 100 bar Tensile or compressive force at 100 bar: max. 26.1 kN Leakage oil volume at operating pressure 100 bar: max. 3 l/min Y-axis Slide travel: 120 mm Feed force: 10 kN Rapid traverse: 7.5 m/min Resolution: 0.05 mm Speed of driven tools: 6,000 RPM MACHINE DETAILS Control system: Siemens SINUMERIK Unloading device Swivel angle: 90 degrees Swivel time: 2 s Iiodpezdqdfofx Aqusc Slide travel: 100 mm Rapid traverse speed: 6 m/min Workpiece weight: approx. 10 kg Workpiece diameter: 200 mm Electrical data Rated power: 45 kW Apparent power: 53 kVA Rated current: 76 A Voltage: 400 V Frequency: 50/60 Hz Dimensions and weight Dimensions with chip conveyor (L x W x H): 2,770 x 4,435 x 2,750 mm Weight: approx. 11,000 kg EQUIPMENT Two tool holders with 12 tool positions each, VDI 30 Note: Further technical data can be found in the attached data sheet. The machine is not equipped with a B-axis.

Condition: ready for operation (used), Year of construction: 2019, operating hours: 2,808 h, functionality: fully functional, machine/vehicle number: NL257181158, turning length: 705 mm, travel distance X-axis: 260 mm, travel distance Y-axis: 50 mm, travel distance Z-axis: 795 mm, swing diameter over cross slide: 742 mm, swing diameter over bed slide: 920 mm, New auction due to buyer's payment default! TECHNICAL DETAILS Working Area Swinging diameter over bed max.: 920 mm Swinging diameter over cross slide max.: 742 mm Turning length max.: 705 mm Bar capacity: 80 mm X-axis travel: 260 mm Y-axis travel: 50 mm Z-axis travel: 795 mm Main Spindle Power: 18.5/15 kW Speed max.: 4,000 rpm Chuck size: 10 inches Spindle bore: 91 mm Front bearing diameter: 140 mm Counter Spindle Ijdpfozck Txox Aqueic Power: 11/7.5 kW Speed max.: 4,000 rpm Chuck size: 6 inches Spindle bore: 45 mm Front bearing diameter: 85 mm Turret and Axes Tool stations: 12 Arbor cross-section: 25 mm Speed of driven tools max.: 10,000 rpm Rapid traverse X-axis: 30,000 mm/min Rapid traverse Y-axis: 10,000 mm/min Rapid traverse Z-axis: 30,000 mm/min Rapid traverse B-axis: 30,000 mm/min MACHINE DETAILS Control: M730UM with CELOS Dimensions & Weight Machine height: 2,000 mm Footprint: 3,347 x 2,106 mm Weight: 5,820 kg Operating hours: 2,808 h Power-on hours: 11,311 h EQUIPMENT Y-axis Counter spindle Main spindle with 10-inch chuck Counter spindle with 6-inch chuck Chip conveyor High-pressure coolant system Tool measuring device Parts catcher Workpiece ejector Interface for bar loader

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, center width: 1,500 mm, center height: 250 mm, swing diameter over bed slide: 500 mm, spindle speed (max.): 2,800 rpm, controller model: Monforts Control System MTC K, The machine was overhauled in 2017! The corresponding invoices are available upon request. TECHNICAL DETAILS Iijdpfxozdfzaj Aquoc Swinging diameter over bed: 500 mm Swinging diameter over slide: 290 mm Distance between centers: 1,500 mm Spindle bore: 70 mm Center height: 250 mm Spindle speed: 2 - 2,800 rpm MACHINE DETAILS Control system: Monforts Control System MTC K Control method: Teach-in Dimensions & Weight Dimensions (L x W x H): 3,350 x 1,550 x 1,800 mm Net weight: 3,300 kg Transport packages: 1 EQUIPMENT Fixed steady rest 3-jaw chuck Documentation CE marking

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, spindle speed (max.): 3,500 rpm, travel distance X-axis: 271 mm, travel distance Y-axis: 600 mm, center width: 600 mm, Equipment: bar feeder, chip conveyor, TECHNICAL DETAILS Turning diameter over bed: 350 mm Distance between centers: 600 mm Bed width: 210 mm Travel in X-axis: 271 mm Travel in Y-axis: 600 mm Spindle bore: 62 mm Maximum spindle speed: 3,500 rpm MACHINE DETAILS Control system manufacturer: Siemens Power: 30.0 kW Dimensions & Weight Dimensions (L x W x H): 4,300 x 2,100 x 2,100 mm Net weight: 5,000 kg EQUIPMENT Iiodpozdd Npsfx Aqusc Chip conveyor Three-jaw chuck Bar feeder Driven tools C-axis Note: The parameters are stored, but are lost if the power supply is interrupted. As long as the power supply is maintained, this is not a problem.

Condition: ready for operation (used), Year of construction: 2005, operating hours: 60,683 h, functionality: fully functional, turning length: 1,524 mm, turning diameter: 820 mm, spindle speed (max.): 3,300 rpm, rapid traverse X-axis: 40 m/min, milling spindle speed (max.): 10,000 rpm, The following work was carried out on the machine: Repair/overhaul of the gearbox of the B-axis (2025) Complete maintenance (2025) Motor magazine renewed (2025) Replacement of the linear guides of the X and Y axes (2024) Renewal of the ball screws of the X and Y axes (2024) Repair of the milling spindle (2024) Including approximately 120 tools, SK 50 TECHNICAL DETAILS Turning length: 1,524 mm Turning diameter: 820 mm Travel range, X-axis: 870 mm Travel range, Y-axis: 500 mm Travel range, Z-axis: 1,598 mm Main spindle Spindle speed (max.): 3,300 rpm Drive power of main spindle: 30 kW / 22 kW Max. torque of main spindle: 588 Nm Spindle nose of main spindle: A2-11" Spindle bore: 104 mm Indexing: 0.0001 Counter spindle Spindle speed (max.): 3,300 rpm Drive power of counter spindle: 30 kW / 22 kW Max. torque of counter spindle: 588 Nm Spindle nose of counter spindle: A2-11" Indexing: 0.0001 Milling spindle Drive power of milling spindle: 37 kW Max. torque of milling spindle: 260 Nm Milling spindle speed range: 0-10,000 rpm Rapid traverse, X-axis: 40 m/min Rapid traverse, Y-axis: 40 m/min Rapid traverse, Z-axis: 40 m/min MACHINE DETAILS Iisdszcwyljpfx Aquec Control system: Mazatrol 640M PRO Tool holder: SK50 Number of tool positions: 120 Operating voltage: 400 V / 50 Hz Connected load: 104 kVA Required installation area (L x W): 7 x 3.5 m Operating hours: 60,683 h EQUIPMENT Approx. 120 tools, SK 50 Variable speed adjustment Tool magazine, 120 positions High-pressure coolant, 70 bar Renishaw probe (new in 2025) Laser measuring system for rotating tools Interface set Air/water cooling through the spindle Overload monitoring system Chip conveyor, Mayfran Consep 2000 Quick-change tool holder, SMW

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: 7402-09-03006-03, spindle bore: 90 mm, rotational speed (max.): 2,000 rpm, center width: 3,000 mm, center height: 325 mm, controller model: SIEMENS SINUMERIK 810D, TECHNICAL DETAILS Swinging diameter over bed: 630 mm Swinging diameter over carriage: 380 mm Center height: 325 mm Distance between centers: 3,000 mm Carriage overhang on bed: 700 mm Bed width: 520 mm Longitudinal travel X-axis: 355 mm Longitudinal travel Z-axis: 3,000 mm Tailstock spindle diameter: 100 mm Tailstock spindle travel: 180 mm Maximum workpiece weight between centers: 3,000 kg Maximum workpiece weight in cantilever mode: 500 kg Spindle bore: 90 mm Spindle mounting: DIN 55027/8 Spindle taper: 120 mm Front spindle bearing: 130 mm Main drive power 100% ED / 40% ED: 12 / 18.5 kW Maximum torque: 2,400 Nm Speed: 2–2000 rpm Speed ranges: 3 Range 1: 2–220 rpm Range 2: 50–660 rpm Range 3: 100–2000 rpm Speed control: 50–120 % MACHINE DETAILS Control system: SIEMENS SINUMERIK 810D Load display on screen: 0–140 % Iijdpfx Aqszc Hmnjuec Main drive: 10 kW Power supply: 3 × 400 V / 50 Hz Dimensions & Weight Dimensions (L (with chip conveyor) x W x H): 5,600 x 1,950 x 1,850 mm Machine weight: approx. 5,500 kg

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, turning length: 500 mm, turning diameter: 300 mm, spindle bore: 75 mm, spindle speed (max.): 3,800 rpm, controller model: OSP 5000L-G CNC-System, No minimum price – guaranteed sale to the highest bidder! Turning machine with integrated Okuma robot! TECHNICAL DETAILS Turning diameter over cross slide: 450 mm Turning length: 500 mm Turning diameter: 300 mm Spindle bore: 75 mm Spindle speed: 70 - 3,800 rpm Spindle power: 11 kW (30 min) / 7.5 kW continuous operation Travel X-axis: 400 mm Travel Z-axis: 500 mm Rapid traverse X-axis: 12 m/min Rapid traverse Z-axis: 12 m/min Feed rate XZ: 12,000 mm/min Iedpfx Aszc E Dfsquoic Data transmission: RS232 Tool turret: 12 positions MACHINE DETAILS Control system: OSP 5000L-G CNC system Data transmission: RS232 Tool turret: 12 positions Power supply: 3 × 400 V Rated machine power: 21 kVA Maximum load current: 36 A Dimensions & Weight Dimensions (L (with chip conveyor) x W x H): 3,900 x 1,800 x 1,800 mm Machine weight: approx. 4,500 kg EQUIPMENT Integrated Okuma robot Automatic parts feeding Ideal for series and automated turning operations Stable and durable design

Condition: used, Year of construction: 1980, Wickman 1" SN: 17069 Ijdpfjzfa U Nox Aqusic Mfd. 1980 6 Spindles 1" Capacity Motor and Controls Stock Stand and Reel Chip Conveyor Universal Threading Pickoff and back finish Recently Reconditioned

Condition: used, Year of construction: 2017, TORNOS MultiSwiss 8x26 CNC Multi-Spindle Swiss-Type Screw Machine Mfd. 2017 SN: 14295 3 Y-Axes Fanuc 30i-B Control 8 Main Spindles 26 mm Capacity Iisdozdvrzspfx Aquec Counter Spindle Integrated Bar Loader High-Pressure Coolant System Chip Conveyor Oil Mist Collector Approx. 11,450 Hours Assorted tooling included. Available under power for inspection. Detailed specification sheet available upon request.

Condition: excellent (used), Year of construction: 2022, control OSP P 300LA spindle turning speed range 5000 U/min turret (x-stations) 12 turning diameter over bed 580 mm turning diameter over slide rest 470 mm turning diameter 340 mm turning length 800 mm x-axis 260 mm Isdpfx Ajzfql Eequsic z-axis 1.010 mm y-axis 120 mm spindle nose ASA 6" spindle bore 90 mm w-axis 895 mm total power requirement 22 kW weight of the machine ca. 6,8 t dimensions of the machine ca. LBH 3,5 x 2,1 x2,5 m • Turret: 12-position radial, motorized; turret motor 6,000 rpm, 7.1 kW • Pedals: Separate for spindle and tailstock • High-pressure coolant pump: 0.8 kW; 6 bar; 20 l/min • Tool presetter: Manual • Programming: IGF conversational programming incl. Chip Conveyor incl. Tools

Condition: used, Year of construction: 1972, turning diameter over bed 1650 mm turning diameter over slide rest 1350 mm turning length 10000 mm turning speeds 1,4 - 280 U/min greates pass round over bed 1580 mm center height over square guideway 825 mm bed length 13.350 mm bed width 1.120 mm spindle diameter in front bearing 260 mm spindle bore 82 mm upper head travel 500mm tailstock quill diameter 200 mm max. workpiece weight between centres 10.000 kg weight of the machine ca. 25,5 t Power 45 KW The machine is a first-hand purchase, is free from defects and is in very good condition. In 2023, the headstock was overhauled; this included replacing the main spindle bearings, chrome plating and reworking the main spindle and bottom wheel (bearing seat). The guideways are also in very good condition, considering their age. Iisdpfx Aqsy S Duvsuoc Accessories - Feed guard Equipment - 3-axis digital display - 1 x faceplate - 1 x roller stand - Chip conveyor (Kabel Schlepp 300/100)

Condition: used, Year of construction: 2013, turning diameter 360 mm turning length 1000 mm swing diameter over bed slide 215 mm reus 30 - 3000 U/min spindle bore 38 mm feed längs 0,043 - 0,653 m/min total power requirement 3,5 kW Iedpfx Aezfqi Roquoic weight of the machine ca. 1500 kg dimensions of the machine ca. 1900 x 900 x 1300 mm

Condition: used, Year of construction: 2022, turning diameter 420 mm turning length 1350 mm spindle passage 101 mm control Siemens SL 828D ShopTurn number of controlled axis 4 turning speed range 3000 U/min power requirement 22/18,5 kW rapid speed 30 m/min number of tapers in turret head 12/24 BMT 65 number of driven tools in turret 12 BMT 65 Spindel speed of driven tools 5000 U/min Spindelpower on driven tool 7,5/5,5 kW y-axis +/- 65 mm tail stock MT-5 weight 8,0 t dimensions 5,7 x 2,3 x 2,32 m Heavy CNC- lathe with driven tools and Y- Axis in very good condition. First instalation: 03/2023 Appr. 5400 h Power on. - 2x 3-jaw chuck Ø 325 + 400 mm - some fixed tool holders - Tool pre- setter - chip conveyor - 4x driven tool holders - 2 + 2 driven toolholders with Capto C4 - oildust collector - band filter system with appr. 1000 ltr. - hydr. steady moveable wit turret SMW Autoblock SLU-X3.1 (Ø 20- 165 mm) Iisdpfjzfqf Sex Aqujc - 3 colour signal lamp - coolant gun - some jaws - external programming system MCS40501/2 - build in spindle

Condition: good (used), Year of construction: 2007, 1 used, very well-maintained high-performance cycle turning machine with FAGOR 8055, 8-position tool turret VDI 40, constant cutting speed, and chip conveyor Manufacturer: MICROTURN, Origin Taiwan Model: Challenger BNC 26160X Year of manufacture: 2007 Technical data: Center height 325 mm Distance between centers 4000 mm Swinging diameter over bed 650 mm Swinging diameter over cross slide 410 mm Swinging diameter in the gap 870 mm Spindle speeds 0 – 2400 rpm Spindle bore 82 mm Spindle motor 15 / 22 kW Machine dimensions L x W x H 6190 x 2096 x 2050 mm Machine weight 6,800 kg Accessories / Special features: • Cycle control FAGOR 8055 with alphanumeric keyboard o LCD color monitor o Graphical simulation of the cycles Iodozfqdnspfx Aqusic o 2 electronic handwheels • 3-jaw chuck • 8-position tool turret VDI 40 • Chip conveyor • 2 fixed steady rests • Automatic lubrication of the headstock • Automatic lubrication of the longitudinal and cross slides • Tailstock with hydraulically actuated quill • Coolant system • Chip conveyor • CE compliant Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany

Condition: good (used), Lathe support stop, longitudinal stop, lathe, support stop, stop, depth stop, length stop for lathe -Groove opening: 22 mm -Number: 1x keystrokes available -Price: per piece Iiodpfx Aqod Efz Tjusc -Dimensions: 130/110/H50 mm -Weight: 2.4 kg

Condition: refurbished (used), Year of construction: 2009, functionality: fully functional, Control system: SIEMENS 840D Turning diameter: 2,800 mm Turning height: 1,000 mm Load capacity: 16,000 kg Max. swing diameter, approx.: 2,800 mm Turning diameter - external, max.: 2,800 mm Spindle speed: 63 rpm Cross slide travel: 620 mm Ram stroke - max.: 690 mm Tool interface: CAPTO 6 Included: Chip conveyor 2 supports 4-position tool turret Hydraulic chuck Iodpfxjzfn Hys Aqusic

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, Control system: SIEMENS 840D Machining diameter: 4,000 mm Machining height: 1,400 mm Travel of the rotary table: 850 mm Iiedpjzfn Evsfx Aqujc Max. swing diameter, approx.: 4,200 mm Turning diameter – external, max.: 4,000 mm Travel of the cross slide: 850 mm Ram stroke – max.: 950 mm Tool holder: CAPTO 6 Included: Chip conveyor 2 tailstocks 4-position tool turret Hydraulic chuck, 2,800 mm

Condition: used, Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Iijdpfx Aezfni Ijquoc Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: refurbished (used), Year of construction: 2022, functionality: fully functional, turning diameter over bed: 540 mm turning length: 1.500 mm turning diameter in the recess: 580 Working travel of the lower slide max. approx.: 415 mm adjustment of upper support, max. approx.: 140 mm turning speed range: 0 - 1.800 U/min diam. of main spinde: 135 mm spindle bore: 68 mm internal taper diameter: 73 mm bed width: 403 mm Equipped with: Three jaw chucks FORKARDT 250 Isdpfx Aezfnd Ssquoic Digital read out 3 axis fixed steady rest feed safety chip tray tool holders, 6 chisel holders, 1 holder for clamping sleeve

Condition: used, Year of construction: 2006, Turning diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Center distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 Turning diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Center distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 mm Swing diameter over face slide: 260 mm Face slide travel: 380 mm Main drive Drive power AC motor - 40/60/100% duty cycle: 33/27/22 kW Spindle box Spindle bore diameter: 106 mm Spindle diameter in front bearing: 140 mm Speed range (V constant): 1 - 2,000 rpm Cross slide Feed range, face: 0.001 - 1,000 mm/rev Feed range, face, optional up to: 5,000 mm/rev Feed range, longitudinal and thread pitch: 0.001 - 2,000 mm/rev Feed range longitudinal and thread pitch, optional up to: 13,000 mm/rev Feed force flat: 9,000 N Feed force longitudinal: 12,000 N Automatic tool turret Number of tool stations: 12 With tool drive for 6 stations Tool holder system (DIN69880) VDI40 Iiedpfx Aqjzfmu Nsujc Equipment SIMENS SINUMERIK 840D sl (Shop Turn with manual functions) COMBI control station C-axis with drilling, milling, and engraving cycles Residual material detection and machining – during roughing and contour pockets MULTIFIX C forne setup Three-jaw chuck SMW AUTOBLOK: HI-GRIP HGF260-81-3 Oil emulsion mist filter for work area extraction: MAHLE LTA600
