Condition: used, Year of construction: 2002, x-travel 800 mm y-travel 600 mm z-travel 500 mm CNC-control iTNC 530 HEIDENHAIN Table dimensions Ø 600 mm max. table load 300 kg spindle taper SK 40 spindle turning speed range 15000 U/min feed range 35.000 mm/min rapid traverse 35 m/min tool change unit 30 Pos. voltage 400 V total power requirement 31 kW Dedpfx Aex Edugjb Tola weight of the machine ca. 8,5 t dimensions of the machine ca. 2,65 x 3,45 x 2,75 m coolant tank 2,30 x 0,80 x 0,50 m - Serial-No.: 15197 - Machine ON: 82.298 h - Program Run: 55.650 h - control: iTNC 530 HEIDENHAIN - electronic hand wheel - 3D-Touch Probe M&H - coolant equipment

Condition: used, Year of construction: 2008, x-travel 1.035 mm y-travel 560 mm z-travel 510 mm control 810 D Powerline Siemens turning speed range - main spindle 20 - 8.000 min/-1 power capacity - main spindel 13 / 9 kW max. Torque 83 / 57 Nm tool taper SK 40 table surface area 1.200 x 560 mm max. table load 1.000 kg table height over floor 720 mm T-slots 4x H12 / 1x 14 H7 number of toolpositions 20 pos. max. tool diameter 80 mm max. tool-dia with free toolbox 130 mm Dedpfstzvy Tex Ab Tola max. tool length 300 mm max. tool weight 6,0 kg change time 1,6 sec change-time chip to chip 7,0 sec feed speeds 20.000 mm/min rapid traverse 25 m/min total power requirement 17 kVA weight of the machine ca. 4,1 t dimensions of the machine ca. 4,0 x 4,0 x 2,5 m CNC - Machining Center Vertical DMG MORI SEIKI - DMC 1035 V ecoline - only 3.800 spindle hours

Condition: used, Year of construction: 2017, operating hours: 7,150 h, functionality: fully functional, GENERAL SPECIFICATION 1.1. AXES SYSTEM - Travel : o X axis: 1300 mm o Y axis : 670 mm o Z axis : 625 mm - Spindle to table surface : 150~775 mm - Motor power : o X axis : 3.0 kW o Y axis : 3.0 kW o Z axis : 3.0 Kw 1.2. CAPACITY - Table size : 1500 x 670 mm - Table surface : T-slot 5–125 x 18H8 mm - Max. workpiece weight : 1300 kg - Max. workpiece height : 700 mm 1.3. SPINDLE HEAD - Motor power (Cont./30min.) : 15/18.5 kW - Max. spindle speed : 12.000 rpm (optional) - Max. torque (short term) : 117.8 N·m - Taper type : ISO # 40, 7/24 Taper 1.4. TOOL MAGAZINE - Tool storage capacity : 30 scule - Tool shank : MAS403 BT40 - Pull stud : PS806 (NIKKEN) - Maximum tool diameter : o Continuous : Ø80 mm o Adjacent pots empty: Ø125 mm - Max. tool lenght : 300 mm - Max. tool weight : 8 kg - Tool change time (Tool-to-tool) : 1,2 sec - Tool change time (Chip-to-chip) : 3,4 sec 1.5. RAPID TRAVERSE - Rapid traverse: o X, Y axis : 36 m/min o Z axis : 30 m/min - Max. Cutting feedrate :15.000 mm/min - Ballscrew (Diameter x Lead) : o X, Y axis : 40 x 12 mm o Z axis : 40 x 10 mm 1.6. ACCURACY - Positioning : ±0.005 mm Dledpfx Aex Ecybeb Tea - Repeatability : ± 0.002 mm 1.7. LUBRICATION UNIT - Tank capacity : 0,7l 1.8. COOLANT SYSTEM - Tank capacity : 325 l - Pump motor power : 0,4 kW - Max. flowrate: 40 l/min 1.9. DIMMENSION AND WEIGHT - Dimmensions (LxlxH) : 2597 x 3350 x 3120 mm - Weight : 8.500 kg 1.10. OTHER CHARACTERISTICS - Electrical power supply : 3Ph-AC220V/60Hz x 33,5kVA - Air power supply : 0,54 MPa x 250 Nl/min - CNC Control : Fanuc i-Series 1.11. Accessories: • TSC 20 bar • 12.000 rpm • Chip conveyor

Condition: good (used), Clamping table, clamping angle, T-slot table, rotary table, milling machine table -Table surface: 210 x 570 mm -T slots: 3 - rotatable and swiveling Dledjb A Iccjpfx Ab Tea -Fits Deckel Mikron WMW and other milling machines -Weight: 95 kg

Condition: reconditioned (used), functionality: fully functional, LVD 4000 x 200T Press Brake Type PPBL 200/40 Capacity 4000 x 200T Maximum stroke 150 mm Weight 13.5T Dledpfx Abewtmi Ej Tea With mobile blade rack

Condition: used, Year of construction: 2006, Technical details: turning diameter: 490 mm turning length: 2000 mm total power requirement: 15/20 kW weight of the machine ca.: 3,6 t dimensions of the machine ca.: 2,8 x1,85 x 1,9 m In like new condition Heidenhain cycle control Torsion-resistant bed, made of high-quality cast iron with hardened, precision-ground guideways and a glass scale on the X-axis Safety clutch on the Z and X axes Sealing air with carbon filter in direct position measuring system High accuracy and rigidity of the lathe spindle thanks to precision spindle bearings, spindle bore Ø 93 mm standard, optional Ø up to 130 mm Dledpfewmcx Asx Ab Tsa Solid tailstock, quill Ø 90 mm with internal taper MK5 Large overhang above the facing slide for easy accessibility during shaft machining. The machine has Teach-in CNC Programms. Control: MC420. Tool holder: SAUTER. *

Condition: good (used), Year of construction: 2014, operating hours: 25,208 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, torque: 300 Nm, controller manufacturer: Siemens, controller model: 840D SL, rotational speed (max.): 12,500 rpm, spindle speed (max.): 12,500 rpm, spindle motor power: 40,000 W, number of spindles: 1, Operating hours: 23145 Year of construction: 2014 Control unit: Siemens 840 D SL Spindle: EEC 100 Einheit 12500 1/min, 40 kW, 300 Nm Tool clamping system: HSK 100 Tool magazine / places: Chain / 100 Rotary table: 360.000° X 0,001° Coolant unit: KNOLL, KF 400, IKZ 50 bar, (work area flushing) Positioning range XYZ (mm): 800 / 800 / 800 Pallet size (mm): 500 X 630 Workpiece clamping: 60 bar Dlodpfx Aox Ecpieb Toa Additonal options, Specifics: Control of 4th line in the work area for hydraulic switching function; Interface for exhaust system; Screen blow-off device for operator door; Fast drill fracture sensing (SBBK); Integrated process monitoring and collision monitoring; standard operator-panel for tool-magazin;

Year of construction: 1997, condition: used, Saw blade diameter vertical and horizontal: 500 mm Max. profile height: 280 mm Max. notch width: 300 mm Max. latch height: 185 mm Max. latch depth: 185 mm Pivoting material stop with locking points and digital display Motorized latch height adjustable with digital display Motorized adjustment of the angles with digital display Dsdpfox Ecg Uox Ab Tjla Hydropneumatic material feed via 2-hand operation Pneumatic material clamps coolant lubrication

Condition: used, Year of construction: 2017, operating hours: 2,612 h, functionality: fully functional, GENERAL SPECIFICATION PUMA GT 2100M 1.1. CAPACITY : - Swing over bed (interference with front cover) / : 600 mm - Swing over saddle: 390 mm - Recomended turning diameter : 210 mm - Max. turning diameter : 300 mm - Max. work length : 513 mm - Bar working diameter : 65 mm - Max. permissible mass (including chuck) : o Chuck work : 150 kg o Shaft work : 300 kg - Base structure o Bed slant angle:30 deg. o Guideway type: Box guide 1.2. MAIN SPINDLE : - Drive mechanism : Belt-drive - Chuck size : 210 mm - Motor power (15 min / cont.) : 18,5 / 15 Kw Dodpex Ecwasfx Ab Tela - Spindle speed : 4.500 rpm 1.3. CARRIAGE : - Travel : o X axis : 230 mm o Z axis : 580 mm o C axis : 360 grade (in 0.001) - Rapid traverse rate : o X axis : 24 m/min o Z axis : 30 m/min o C axis : 200 rot/min - Continuous thrust force : o X axis : 6207 N o Z axis : 11305 N - Intermittent thrust force : o X axis : 9931 N o Z axis : 16958 N - Ballscrew (diameter x lead) : o X axis : 32 x 10 mm o Z axis : 32 x 10 mm - Servo motor: o X axis : 1,8 kW o Z axis : 3,0 kW 1.4. ACCURACY : - Positioning : o X axis : 0,01 mm o Z axis : 0,02 mm o C axis : 0,0167 degrees

Year of construction: 1991, condition: good (used), Underfloor circular saw, crosscut saw, pull saw, chop saw, sliding table saw, table saw, circular saw, panel saw -Manufacturer: Altendorf, sliding table saw type TKR 45 -Main motor: Bauknecht 5.5 kW with brake -Scorer motor: Emod 0.75 kW -Speed: 3000/4000/5000 rpm Dedpfx Absmydmbo Tsla -Saw blade: Ø 300 mm / max. Ø 350 mm -Max. Cutting height: 90° 95 mm / 45° 70 mm -Miter cut: up to 45° -Cutting width: 2250 mm -Table length: 1400 mm -Dimension total 3480/1530/H1370mm -Weight: 1104 kg

Year of construction: 2003, condition: used, Max. sawing length: 6,000 mm Smallest cutting length: 335 mm Max. saw blade diameter: 550 mm Automatic length positioning via E 500 control Swivel inside and outside 22.5° - 90° - 140° Tilt angles between 45 and 90 degrees Dlodpfx Abex Ecgne Tea Digital angle displays Moving roller conveyor Minimum quantity spray device label printers

Condition: good (used), Container rotating device, welding rotating device, welding rotating device, welding device, welding rotary table, welding rotary and tilting table, welding rotating device -Table: is tiltable -Maximum load: 75 kg -Clamping diameter: 300 mm -Hollow shaft: Ø 42.5 mm -Drive: 0.1 kW -Speed: RPM -Quantity: 1x welding rotator available -Price: per piece -Dimensions: 830/450/H920 mm Dsdpjdwpduofx Ab Tela -Weight: 174 kg

Condition: good (used), Bending tool, die, lower knife, lower tool, lower jaw -Tool: for swivel bending machine -Widthen: for lower cheek -Dimensions: 59 x 19 mm -Length: 1452 mm Dledpecn Shuofx Ab Toa -Weight: 10 kg

Condition: good (used), Dividing head, spiral milling device, dividing head, tool holder for grinding, drill grinding machine, milling cutter grinding machine, drill grinding holder -Manufacturer: Stankoimport, holder for tool grinding machine -Type: 36642.M7 -swivelling: up to 105° -Mounting: Ø 35 mm / M16 see photos -Dimensions: 150/140/H85 mm Dlodpfx Aboxfh N Uo Tja -Weight: 3.9 kg

Year of construction: 1992, condition: good (used), Container turning device, welding turning device, welding turning device, welding device, welding turntable, welding turntable and tilting table, welding turning device, welding turntable tilting table -Manufacturer: Commercy Soudure, welding rotating device swiveling -Type: PM 250 -Load capacity: see photo nameplate Dlsdpfx Aeq Ei A Teb Tsa -Control: with foot pedal -Three-jaw chuck: Ø 314 mm, bore Ø 100 mm, base plate Ø 600 mm -Speed: max. 3 rpm right/left rotation -tiltable: via crank -Transport dimensions: 1190/720/H900 mm -Total weight: 267 kg

Condition: good (used), Underfloor circular saw, crosscut saw, pull saw, chop saw, sliding table saw, table saw, circular saw, precision circular saw -Manufacturer: Rapid, table saw saw unit: 45° pivotable -Type: Pk 100 -Motor power: 2.5 kW / 2850 rpm -Saw blade: Ø 250 mm, (max. Ø 300 mm) Djdpfxsm Sk Hys Ab Tsla -Cutting height: 70 mm (max. ca. 100 mm) -Cutting width: 345 mm -Miter cut: up to 45° -Chip extraction: with gate valve for connection to a central extraction system -Dimensions 1020/850/H1300 mm -Weight: 188 kg

Condition: good (used), Bending tool, die, upper blade, upper tool, upper jaw -Bending tool: from Lotze HDZ swivel bending machine -Length 2678 mm -Hole spacing: 100 mm / M10 Dledpfoip Eqrjx Ab Toa -Dimensions: see drawing in the photos -Dimensions: 2678/15/H57 mm -Total weight: 15.7 kg

Condition: good (used), Bending tool, die, lower knife, lower tool, lower jaw -Bending tool: from Lotze HDZK swivel bending machine -Widthen: for lower cheek -Dimensions: 2487 x 100 x 15 mm / 190 x 100 x 15 mm Dsdpfx Absip Eqko Tela -Hole spacing: 100 x 18 mm -Transport dimensions: 2487/100/H30 mm -Total weight: 29.4 kg

Condition: good (used), Year of construction: 1989, Bending machine, folding machine, swivel bending machine, die bending machine Djdpfemiqm Isx Ab Tjla -Manufacturer: zts, folding machine type XONM.2000/2A-4 -Drive: hydraulic -Max. working width: 2000 mm -Max. sheet thickness: 2 mm -Connected load: 2.2 kW -Dimensions: Bending machine 2850/1100/H1400 mm / Unit 720/540/H760 mm -Total weight: 2160 kg

Condition: good (used), Computer monitor, operating unit, operating unit, keyboard, screen, control, industrial monitor Dlsdpfefu I N Usx Ab Tsa -Manufacturer: Cybernet -Accessories: swivel arm, multiple adjustable -Dimensions: 600/200/H365 mm -Weight: 10 kg

Condition: good (used), Cup grinding machine, swivel arm grinding machine, carbide chip breaker groove grinding machine, tool grinding machine, grinding machine, angle grinding machine, turning tool grinding machine -Clamping table: 440 x 300 mm Dodpfxecvnaie Ab Tola -Max. intermediate dimension: 130 mm -Grinding disc diameter: 125 mm -Dimensions: 1200/840/H1680 mm -Weight: 380 kg

Condition: good (used), LED high bay light, light fixture, high bay light, industrial lighting, industrial lamp, linear light, LED spotlight, high bay low beam light -Manufacturer: lichtline, LED high bay light with swivel arm -Power: 150 watts 5000K -Swivel arm: Length 3860 mm Dlodpfoh N Tifsx Ab Tja -Dimensions: 3860/340/H210 mm -Weight: 56 kg

Condition: good (used), Commission trolley, tray trolley, paint drying trolley, specialist transport trolley, transport trolley, window profile trolley -Total length: 2000 mm -Total depth: 1160 mm Dlsdpfjb Uvttox Ab Tea -Total height: 2160 mm -Arm length: 225 mm -Support height: 200 mm -Quantity: 1x car available -Price: per piece -Weight: 58 kg/piece

Condition: good (used), Profile turning head, boring head, spindle head, drilling head, grooving drilling head, grooving head, spindle drilling head, boring head, universal drilling head, profile turning head -Manufacturer: MFB Maschinen, ARMAG, profile turning machine -Recording: MK4 -Accessories: including extensive accessories see photos -Box dimensions: 450/350/H195 mm Dedpfx Abswylh Ts Tsla -Total weight: 5.4 kg

Condition: good (used), Four-jaw chuck, four-jaw lathe chuck, 4 jaw chuck Dledpfx Abotxklys Tja -Manufacturer: Röhm, four-jaw chuck Ø 200 mm -Passage: Ø 55 mm -Bolt circle: Ø 133 mm -Mounting: Short taper 6 / cone 103 - 105 mm short taper flange with Camlock fastening -Accessories: incl. 2 sets of interchangeable jaws and clamping tool -Dimensions: Ø200 x 185 mm -Weight: 24 kg
