welding current: V
welding current - continuous: 500A / 60% und 390A / 100% A
total power requirement: 21,5 kVA
weight of the machine ca.: 0,15 t
dimensions L x W x H: 1,0 x 0,73 x 1,4 m
- WIG: 10 A/10V - 500A / 40V
- MIG: 40 A/12V - 500A/ 40V
- cooling method water-cooled
- protection class IP 23
- insulation class B
- idle power: 150W
- wire feeder FU 20
- water circulation unit WU 10
- hose package: 10m more
Commission wagon, Horde wagon, Paint dry wagon, Special transport wagon, Transport wagon, Window profile wagon
- total length 870 mm
-Total depth 840 mm
-Total height 1810 mm
-collapsible to 250 mm
-Arm length 710 mm
-Support height 200 mm
-Price per piece
-Number of 9
-Weight 40 kg / St.
-1x car available
-Weight 58 kg / piece more
Maximum length: 4500 mm
Saw blade diameter: 500 mm
Program control E 500
Automatic positioning of the length
Tilt both heads between 45° and 90°
Weight: approx. 1500 kg
Machine packed on wood (see last photo) more
5- axis control profile machining center Elumatec SBZ 151/7,30 m/ date of construction 2011, in good condition
- Designed for flexible and efficient machining of aluminium and thin-walled steel profiles.
- All operations, such as routing, drilling, tapping, thread milling, notching and sawing, are performed while the profile bar is stationary to protect the profile surfaces.
- Fast positioning of the machining unit with up to 66 m/min thanks to dynamic servo drives.
- New generation of compute... more
power consumption: 40-450 A
welding current: 450 V
total power requirement: 0,215 kw
weight of the machine approx.: 255 kg
dimensions of machine: 1,0x0,53x1,5 m
welding device with feed FU 30
- control via switch 2/4 beat 64 welding steps
- water and air cooled (switchable)
- without hose package
- with intermediate hose package 13,5m
- without burner head
Welding device is functional. more
4-axis machining centre with saw and conveyor belt
Machining length: 8500 mm
Profile height: min. 15 mm, max. 250 mm
Profile width: min 15 mm, max 300 mm
Max. Saw blade diameter: 750 mm
Tool changer with up to 12 tools
Automatic clamp displacement
A-axis can be turned from 0°-180
Saw arm rotatable
The machine has been serviced annually by BDM and will be dismantled at the customer's site at the end of 2020. Until then the plant can still be inspected in operation.
Dismantling and loading ... more
5 - axis power for universal use, type ELUMATEC SBZ 150/ 7,30 m
in very good running condition (about 3.400 spindle hour)
- Processing in aluminium: Drilling, routing, taping, cutting and notching
- Processing in steel: Drilling, routing, taping
- Electronic 5- axis industrial PC- control
- Six- side processing (from the bottom with angle head)
- Max. processing length 7.000mm
- Automatic tool changer with eight standard tools and three spezial tools
(spezial tools: sawblade, angle head and s... more
Length: - mm
height: - mm
welding current - continuous: 40 - 450 A
protection class: IP23
total power requirement: 21,2 kVA kw
weight of the machine approx.: 255 kg
dimensions of machine: 1,0x0,6x1,6 m
- welding procedure: MIG/MAG
- 32 welding levels
- water cooled and air cooled switchable
- without pressure reducer
- with burner package
- intermediate hose package 8 meter
- welding feed ( for wire 0,9 - 1,0mm)
Machine has been tested!
Side cover for wire feed is miss... more
Throughfeed centre for complete machining of aluminium profiles
The profile is placed on the front of the machine, then it is automatically transported into the machining centre. Afterwards the milling and drilling is carried out, followed by the cutting, which can be done 90° or 45° in both directions.
Finally, the profile is transported to the removal point.
Machining length: 600 mm min., max. 7,500 mm
Profile cross section:
height: 15 mm min, 300 mm max
width: 5 min,... more
pressure: 80 t
distance between columns: 880 mm
dayligth: 200 mm
Table dimensions: 880x300 mm
height over floor: 1000 mm
distance between columns: 800 mm
total power requirement: ca. 12 kW
machine weight ab.: 2855 kg
space requirements of the machine approx.: T:1,4xB:1,65xH:1,9 m
Embossing - Hot Embossing
- for example: for foils, plastics, paper, hardboard materials etc.
- stamp plate size: 600x310mm
- hydr. tank
- Mounting plate ... more
Corner crimping press with powerful hydraulics and pneumatics. High contact pressure. It is possible to order tools for the machine as shown on the film Adjustable without tools 700euro. With tool 1100euro
4 axis control profile machining center Elumatec SBZ 140/ 4,20 m, in excellent condition, software eluCad (dongle) included, with few operation hour/ spindle hour
With this 4-axis profile machining centre efficient aluminium and steel profile processing can be carried out in first-rate quality.
For profile surface protection all work cycles such as milling, drilling, or tapping are carried out while the profile bar remains stationary.
The axis-controlled cutter head is able to work the profile... more
Length Stop WOLFF PC-TOUCH 3000
• Max Length: 3.000mm
• Mounting side: right or left, please specify with your order
• Linear axis with servomotor and planetary gear
• Covered tooth belt, protected from chips
• Stopper is hinged up
• Roller conveyor L=3.000mm W=300mm with plastic rollers Ø 50mm,
with cover plate
• PC-touch control with motion control, servo controller, emergency stop,
• Fully assembled and tested from the factory Lemgo
Other versions, length, width,... more
throat min.: 2600 mm
throat max.: 4200 mm
Support arm position: 360 schwenkbar °
weight of the machine ca.: ca. 1,75 t
dimensions L x W x H: L:5,0xB:1,6xH:2,8 m
space requirements of the machine approx.: 6,61x1,4x2,8 m
WELDING STATIVE for positioning a welding torch/welding source on large wide workpieces.
- The device for adjusting the gas cylinder is integrated in the frame.
- Dm of the base frame = 1480mm
- All adjustments are made manually.
- With welding device Make: KOLBE; Type: SC ... more
