Used machining centers (vertical) X-axis travel 1700mm for sale (164)

Condition: used, Year of construction: 2023, x-travel 3000 mm y-travel 820 mm z-travel 720 mm Control Mazatrol Smooth G spindle taper SK 40 spindle turning speed range 35 - 12.000 U/min spindle motor 15 kW distance spindle centre table top edge 140 - 860 mm table load 2500 Kg rapid travel x/y/z 50 m/min table width 3500 mm table length 820 mm table height over floor 870 mm T-slots 7 T-slot - width 18 mm T-slot - distance 100 mm tool change unit 48 Dcedpfx Akeyvvluevok tool changing time 4,7 sec wotkpiece diameter with 2 vacant positions 130 mm workpiece diameter at full load 80 mm max. tool weight 8 kg tool length - max. 350 mm air pressure - required 5 - 9 bar Air volume 260 l/min electrics - voltage/frequency 400 / 50 V/Hz coolant tank 500 l total power requirement 46,7 kW weight of the machine ca. 15,4 t dimensions of the machine ca. 5,3 x 3,6 x 3,3 m Standard machine including the following optional extras: - Provision for dual oil mist extraction - Air cooling via the rotating milling spindle - 48-tool magazine - Pulse handwheel - 3-colour LED signal light - Additional work area lighting - Air blow-off device on the milling spindle - High-pressure coolant supply through the spindle (15 bar) - Provision for MAZAK Monitoring - Chip conveyor with left-hand ejection (Crowther) - Manual grease gun - Grease cartridge - Mazak API - Drilling cycle with automatic chip breaking - Synchronous thread cutting - Rapid traverse with constant angle of inclination STANDARD ACCESSORIES Adaptation for the European market USB port (1 port) Mazak standard colour Work area lighting SAFETY FEATURES Operator door with interlock switch Work area cladding The splash guard enclosure encloses the work area from the side. Fully enclosed work area Protection against chips, coolant and access to the work area during automatic machining. Safety precautions in accordance with global standards COOLANT SUPPLY Coolant supply via spindle (pump pressure = 5 bar) Complete coolant system includes pumps, valves, pipework and nozzles for the efficient production of high-quality components. FACTORY AUTOMATION Automatic start/stop and warm-up function Automatic activation of a warm-up via digital timer MEASURING SYSTEM Tool length measurement and tool breakage detection NUMERICAL CONTROL Horizontally adjustable NC control panel Relocation Detector Mazatrol SmoothG control 19" colour LCD screen (touch screen) Mazak Tornado tapping/drilling cycle (Mazatrol) EIA/ISO input function Tool path verification in the background 3D coordinate conversion Shape compensation for rotating axes Mazacc-2D software (contour correction) Mazacc-3D software package MAZACC-3D high-speed software package (NO456) is additionally required. Control system with high smoothing Interface for LAN SD memory card interface Smooth Standard Software for M/C - NO443 B) MAZACC-2D software (workpiece shape compensation) - NO444 D) MAZACC-3D high-speed software package - NO445 B) Shape compensation for rotating axes - NO497 D) High-precision control for finishing - Seamless corner point control - Variable acceleration control - Ultra-high-speed machining mode - NO498 Rapid traverse paths, rounding function Absolute positioning system - All dimensions, weights and performance specifications are subject to change - - Used machine without warranty - - Subject to prior sale -

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 6,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 600 mm, workpiece weight (max.): 800 kg, controller model: HEIDENHAIN iTNC 530, No reserve price – guaranteed sale to the highest bidder! Dedpfxjyvudvs Akvsck TECHNICAL DETAILS Travel X-axis: 6,000 mm Travel Y-axis: 800 mm Travel Z-axis: 600 mm Spindle mount: SK 50 Spindle speed: 20 – 9,000 rpm Torque: max. 165 Nm Table load capacity: 3,000 kg Workpiece weight: max. 800 kg MACHINE DETAILS Control: HEIDENHAIN iTNC 530 Main drive: 60 kW Machine weight: approx. 24 t

Condition: ready for operation (used), Year of construction: 2010, operating hours: 47,512 h, functionality: fully functional, travel distance X-axis: 2,230 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 850 mm, controller model: HEIDENHAIN iTNC 435, spindle speed (max.): 6,000 rpm, TECHNICAL DETAILS X-axis travel: 2,230 mm Y-axis travel: 1,400 mm Z-axis travel: 850 mm Table dimensions: 2,000 mm × 1,250 mm Maximum table load: 6,000 kg Spindle speed: 6,000 rpm Tool holder: SK50 Tool magazine capacity: 40 positions Rapid traverse in X / Y / Z directions: 12 m/min MACHINE DETAILS Control model: HEIDENHAIN iTNC 435 Spindle drive power: 38 kW Dimensions & Weight Dimensions (L × W × H): 6,135 mm × 4,338 mm × 4,150 mm Machine weight: 22,000 kg Operating hours (machine): 72,846 h Operating hours (program run): 48,891 h Operating hours (spindle running time): 47,512 h EQUIPMENT Coolant system Internal coolant supply (IKZ) Dsdpfsy Dgy Eex Akvsck Electronic handwheel Touch probe Automatic workpiece measurement Chip flushing Chip conveyor

Condition: excellent (used), Year of construction: 2008, operating hours: 40,255 h, functionality: fully functional, For sale is a DMG DECKEL MAHO DMF 220 linear, a 5-axis universal travelling-column machining center. The machine was built in 2008 and was modernized / totally retrofitted in 2022 with Siemens Sinumerik 840D Solution Line control. Equipped with 5-axis simultaneous machining license, Siemens Sinamics drive technology, Siemens OP15 Black Operator Panel, MCP control panel and electronic handwheel. Technical data: Manufacturer: DMG DECKEL MAHO Type: DMF 220 linear Machine type: 5-axis universal machining center / travelling-column machining center Year of manufacture: 2008 Control: Siemens Sinumerik 840D Solution Line Modernization / Total Retrofit: Siemens CNC / drive modernization in 2022 5-axis simultaneous operation: License available Serial number: 15115223244 Machine number: 2499093 Travel X: 2,200 mm Travel Y: 560 mm Travel Z: 720 mm Tool taper: SK 40 Table load: 2,500 kg Main spindle speed range: 20 - 14,000 rpm Connected load: 80 kVA Max. rated current: 115 A Fuse protection: 125 A Supply voltage: 400 V Frequency: 50 Hz AC control voltage: 230 V DC control voltage: 24 V Power-on hours: approx. 40,255 h Spindle / working hours: approx. 13,082 h CNC / drive technology: X-axis: Siemens Sinamics 160 A, 2 x SMC20 encoder module Y-axis: Siemens Sinamics 50 A, 2 x SMC20 encoder module Z-axis: Siemens Sinamics 80 A, 2 x SMC20 encoder module B-axis: Siemens Sinamics 25 A, 2 x SMC20 encoder module Dodpfxoyuzg Hs Akveck A-axis: Siemens Sinamics 25 A, 2 x SMC20 encoder module Spindle axis: Siemens Sinamics 26 kW, 2 x SMC20 encoder module Operator panel: Siemens OP15 Black Operator Panel MCP control panel: Siemens Electronic handwheel: Siemens Magazine technology: Magazine A: 400 W servo drive, 400 W servo motor, 10 m power cable, 10 m encoder cable Magazine B: 400 W servo drive, 400 W servo motor, 10 m power cable, 10 m encoder cable Magazine C: 400 W servo drive, 400 W servo motor, 10 m power cable, 10 m encoder cable Software / licenses: 5-axis simultaneous machining license Axis licenses Operator software license Equipment: Integrated swivelling table / trunnion-type table setup Paper band filter unit Coolant / filter unit Electrical cabinet Full enclosure Working area lighting Siemens control panel Condition: Machine in well-maintained condition Modernized Siemens control and drive technology 5-axis simultaneous machining available

Condition: used, Year of construction: 2008, x-travel 1800 mm y-travel 510 mm z-travel 480 mm weight of the machine ca. 5500 kg Dodpfsxuv Svox Akvjck

Condition: good (used), Year of construction: 2009, operating hours: 21,955 h, functionality: fully functional, HEIDENHAIN iTNC530 controller Table dimensions 5300 x 750 mm Maximum table load 4500 kgs X-axis travel 4500 mm (pendulum operation) Y-axis travel 800 mm Z-axis travel 620 mm Spindle nose to table surface 325 - 925 mm Spindle speed 12000 rpm (Kessler Celox motor spindle) Torque 183 Nm Spindle taper HSK63 ATC 56-position magazine Middle wall in working area - pendulum operation possible Rapid traverse X/Y/Z = 30/40/40 m/min Power consumption 25 kVA Weight 21000 kgs Space requirement L x W x H = 10.4 x 4.2 x 3.2 m Equipment, accessories - Large chip conveyor - Large inclined water system 1800 l Internal coolant system and flushing pump - 2x special-design extraction systems – without piping - Machine hood with automatic roller blind - Machine doors with automatic drive and Rotoclear window - Water system 3 x 2 m, position to the left of or behind the machine - Hydraulic clamping unit for machine interior - Blum RMP measuring probe - Separation wall – pendulum operation possible - Hedelius service complete - Pipes for machine cooling, flushing, and pneumatics replaced in 07/2024 - Vises and fixtures on machine table are not delivered with the machine. Dcedpfxoyugups Akvjk The machine is no longer in production (it has been professionally stored) and was dismantled in fully functional condition.

Condition: ready for operation (used), Year of construction: 2010, travel distance X-axis: 4,200 mm, travel distance Y-axis: 485 mm, travel distance Z-axis: 340 mm, total height: 2,000 mm, total width: 1,600 mm, overall weight: 5,500 kg, spindle speed (max.): 6,000 rpm, spindle motor power: 6,000 W, product length (max.): 7,500 mm, number of axes: 3, This 3-axis Elumatec SBZ 131 was manufactured in 2010. It features an impressive X-axis travel of 4200 mm, Y-axis travel of 485 mm, and Z-axis travel of 340 mm. The machine includes an 8-position rotating tool head and a maximum spindle speed of 6000 rpm. If you are looking to get high-quality profile machining capabilities, consider the Elumatec SBZ 131 CNC profile machining centre we have for sale. Contact us for further details. • Control: Industrial PC with eluCam software; 15" colour monitor • Turret/tooling: 8-position rotating turret head with 8-position tool changer Dedpfxoyt Ifye Akvsck • Rapid traverse: X 60 m/min; Y 30 m/min; Z 30 m/min • Tool interface: BT30 • Collet systems: ER25 / ER32 • Saw blade diameter: approx. 300–420 mm Technical Specification Taper Size BT 30

Condition: good (used), Year of construction: 2016, Table size 3000 x 1700mm, Traverses X Y Z 3200 x 2100 x 920mm, Table load 11,000kgs, spindle nose to table 164 – 1084 mm, spindle bored Din 50, spindle speed 6000 rpm, 40 station ATC, Dcjdpfxewu Dlae Akvsk Hurco Winmax 5 control. swarf conveyor

Condition: ready for operation (used), Year of construction: 2007, travel distance X-axis: 4,200 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 300 mm, overall weight: 9,000 kg, spindle speed (max.): 6,000 rpm, spindle motor power: 5,500 W, number of axes: 3, This 3-axis Elumatec SBZ 130 was manufactured in 2007. It features a maximum machining length of approximately 4200 mm and a robust Y-axis travel of 400 mm. The high-speed milling spindle operates at a maximum speed of 6000 rpm, supported by an 8-position turret head tool changer. If you are looking to get high-quality profile machining capabilities, consider the Elumatec SBZ 130 CNC profile machining centre we have for sale. Contact us for further details. • Control system: Ferrocontrol CNC • Max. machining length: approx. 4200 mm • Machining length with end machining: approx. 4080 mm • Spindle: Dcedpfoyt Hg Njx Akvok • Type: High-speed milling spindle • Tool system: • Tool changer: Turret head • Tool positions: 8

Condition: used, Year of construction: 2019, x-travel 2.000 mm y-travel 820 mm z-travel 720 mm Control Mazatrol Smooth G spindle taper SK 40 spindle turning speed range 35 - 12.000 U/min spindle motor 22 kW distance spindle centre table top edge 140 - 860 mm table load 1700 Kg rapid travel x/y/z 50 m/min table width 820 mm table length 2500 mm table height over floor 870 mm T-slots 7 T-slot - width 18 mm T-slot - distance 100 mm tool change unit 48 tool changing time 4,7 sec wotkpiece diameter with 2 vacant positions 130 mm workpiece diameter at full load 80 mm max. tool weight 8 kg tool length - max. 350 mm air pressure - required 5 - 9 bar Air volume 260 l/min electrics - voltage/frequency 400 / 50 V/Hz coolant tank 450 l high-performance coolant system 25 bar total power requirement 46,7 kW weight of the machine ca. 14,8 t dimensions of the machine ca. 4,3 x 3,6 x 3,1 m STANDARD ACCESSORIES Transformer for the European market USB port (1 port) Mazak standard colour Spindle speed 12,000 min-1 (steep taper 40) Work area lighting SAFETY DEVICES Operator door with locking switch Work area panelling The splash guard encloses the working area from the side. Fully enclosed work area Protection against chips, coolant and access to the work area during automatic machining. Safety precautions in accordance with global standards COOLANT SUPPLY Coolant supply through spindle (pressure at the pump = 5 bar) Complete coolant system includes pumps, valves, pipework and nozzles for the efficient production of quality components. FACTORY AUTOMATION Automatic switch on/off and warm-up function Automatic switch-on of a warm-up cycle via digital timer MEASUREMENT SYSTEM Tool length measurement and tool breakage detection CHIP DISPOSAL Factory preparation for chip conveyor (left) NUMERICAL CONTROL Fixed control/operating unit Relocation Detector Mazatrol SmoothG control unit 19" LCD colour screen (touch screen) Mazak tapping/drilling cycle Tornado (Mazatrol) By drilling and tapping in helical machining mode, a wide range of diameters a wide range of diameters can be machined at high speed with a wide range of diameters can be machined at high speed with just one tool. This function minimises programming and machining times. EIA/ISO input function Tool path check in the background The tool path of a programme can be checked even if another programme number is programme number is called up and processed in automatic mode. 3D coordinate conversion Shape compensation for rotating axes Mazacc 2D software (contour correction) Accuracy is maintained at high feed rates. Dcsdpfx Aketuggcsvjk Mazacc-3D software package for high-speed machining High-speed and high-accuracy machining for contours defined in the finest programme contours defined in the finest programme increments. MAZACC-3D high-speed software package (NO456) is additionally required. Control with high smoothing Interface for LAN SD Memory Card I/F Smooth standard software for M/C - NO443 B) MAZACC-2D software (workpiece shape compensation) - NO444 D) MAZACC-3D high-speed software package - NO445 B) Shape compensation for rotating axes - NO497 D) High accuracy control for finishing operations - Seamless corner point control - Variable acceleration control - Ultra high speed machining mode - NO498 Rapid traverse paths Rounding function Absolute positioning system Machine incl. the f...

Condition: ready for operation (used), Year of construction: 2017, Main Drive Spindle Speed 7500 RPM Spindle motor power 22.4 kW Dcedpfx Akjx Imrpovjk Movement X-Axis Movement 2134 mm Z-Axis Movement 762 mm Y-Axis Movement 813 mm This 3-axis HAAS VF 7/50 was manufactured in 2017, featuring extensive axis travels with X-Axis at 2,134 mm, Y-Axis at 813 mm, and Z-Axis at 762 mm. It supports a maximum workpiece weight of 1,814 kg and includes a spindle speed up to 7,500 rpm. Ideal for robust machining tasks, consider the opportunity to buy this HAAS VF 7/50 vertical machining centre. Contact us for more information about this machine. Application Types Milling

Condition: ready for operation (used), Year of construction: 2012, operating hours: 50,106 h, travel distance X-axis: 3,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, spindle speed (max.): 9,000 rpm, spindle motor power: 16,000 W, number of axes: 5, This 5-axis Matec 30 HV vertical machining centre was manufactured in 2012. It features a generous X-axis travel of 3000 mm, Y-axis travel of 800 mm, and Z-axis travel of 800 mm (horizontal). The machine is equipped with a powerful motor spindle, capable of speeds up to 9000 rpm, and a maximum table load of approximately 2500 kg. If you are looking to get high-quality machining capabilities, consider the Matec 30 HV machine we have for sale. Contact us for further details. • Travel Z: 800 mm (horizontal) • Travel Z: 700 mm (vertical) • Tilting swivel head with 1° indexing (Hirth coupling) • Swivel radius: 250 mm • Spindle power: 16 kW (40% duty cycle) • Spindle power: 11 kW (100% duty cycle) • Torque: 100 Nm (40% duty cycle) • Voltage: 400 V • Installed power: 55 kW • Central lubrication system Dcsdjyrqvlspfx Akvok • Machine status: fully functional • Operating hours: 50,106 h • Control: Rexroth IndraMotion MTX Additional equipment • NC rotary table Ø800 mm (horizontal), maximum table load approx. 2500 kg • Internal coolant supply through spindle (20 bar) • Paper band filter coolant system with approx. 450 l tank • Electronic handwheel • 3D measuring probe (Renishaw) • Work area lightingPlease note: the vice and zero-point clamping system shown are not included in the scope of delivery. Technical Specification Taper Size SK 40

Condition: ready for operation (used), Year of construction: 2004, travel distance X-axis: 3,425 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 18,000 rpm, number of axes: 4, This 4-axis MECAL MC 305 vertical machining centre was manufactured in 2004. It features a powerful 5.5 kW electric spindle, air-cooled, with a maximum speed of 18,000 RPM and an ISO30 tool holder. The tool magazine is centrally located, protected, and supports various tools. It has a standard workpiece length up to 4000 mm and an extended range up to 8000 mm. Contact us for more information about this machine. • A (rotation): ±125° • Spindle Type: Electric, air-cooled • Tool magazine: • Located in the middle of the machine base in a protected area • Accommodates various tools: milling cutters, taps, end mills, angle heads • Construction: • Welded steel structure for maximum rigidity Dsdex D I Hkopfx Akvock • Linear guides with ball screws • Automatic central lubrication of guides and screws • Cooling: Centralized minimum lubrication system (MQL) • Working range: • Standard workpiece length: up to 4000 mm • Extended range (differential cycle): up to 8000 mm

Condition: ready for operation (used), Year of construction: 2008, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,800 mm, travel distance Z-axis: 850 mm, spindle speed (max.): 22,000 rpm, number of axes: 5, This 5-axis OMV Active Five 3000 was manufactured in 2008. It features a fixed table with a tilting head, Heidenhain TNC-530 control, and a travel range of 3000 x 1800 x 850 mm. The spindle operates at 22,000 rpm with a HSK63A taper and a 30-position tool changer. If you are looking to get high-quality milling capabilities, consider the OMV Active Five 3000 machine we have for sale. Contact us for more information. Djdpex D H Dujfx Akvsck • Head rotation: B 360° / A ±105° • Tool changer: 30 positions • Table size: 3100 x 1100 mm • Optical scales: Yes • Options/Features: • Torque motor head • Laser tool presetting • Laser measuring system

Condition: ready for operation (used), Year of construction: 2016, operating hours: 16,595 h, travel distance X-axis: 2,120 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 800 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, overall weight: 18,000 kg, number of axes: 3, This 3 axes Wele RB - 212 was manufactured in 2016. It features an impressive X-Axis travel of 2120 mm, Y-Axis travel of 1200 mm, and Z-Axis travel of 800 mm. The machine is equipped with a Heidenhain iTNC 530 CNC system and can support a maximum weight of 3500 kg on its 2000 mm x 1100 mm table. Consider the opportunity to buy this Wele RB - 212 vertical machining center. Contact us for further details. • Table size: 2000 x 1100 mm • Spindle taper: ISO 50 Dcedpfjyidxxjx Akvsk • Spindle speed: 10000 rpm • Spindle hours: 16595 h • Number of tools: 60 • Distance between columns: 1300 mm • Distance spindle to table: 150–950 mm Additional equipment • Blum laser tool measurer • Blum TC50 probe • External coolant 40/80 bar • Air conditioning

Condition: ready for operation (used), Year of construction: 2003, travel distance X-axis: 2,000 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 550 mm, controller manufacturer: SIEMENS, controller model: Sinumerik, table width: 550 mm, table length: 2,600 mm, spindle speed (max.): 12,000 rpm, number of axes: 4, This CHIRON MILL 2000 Vertical Machining Center was manufactured in the year 2003. It is equipped with a Siemens Sinumerik control unit. The machine has a spindle speed of 12000 rpm. Additional equipment • Chip conveyor Machine Benefits Dsdpfx Aksyi Eh Dovjck Technical Machine Benefits • Rapid feed 40 m/min • Tool magazine with capacity for 24 tools

Condition: excellent (used), Year of construction: 2012, Data: Ibarmia gantry-type machining center (3 axes) Dcodpfx Aksywz H Hovok XYZ travel: 3050 x 600 x 900 mm Spindle speed: 12,000 rpm Tool magazine: 60 positions, HSK 63 High-pressure coolant: 60 bar Tool measurement: Renishaw Touch probe: Renishaw Coolant system / band filter Chip conveyor

Condition: repair required (used), Year of construction: 2001, functionality: limited functionality, travel distance X-axis: 2,000 mm, travel distance Y-axis: 450 mm, nominal power (apparent): 37 kVA, controller manufacturer: Sinumerik 840 D, overall weight: 7,000 kg, spindle speed (min.): 10,000 rpm, Equipment: chip conveyor, - SK 40 tool holder - The machine is currently idle. - The buffer battery is empty, which has caused the connection to the PLC to be interrupted. Dcodeywpa Iepfx Akvsk The machine can be inspected under power at any time.

Condition: excellent (used), Year of construction: 2008, operating hours: 50,236 h, functionality: fully functional, travel distance X-axis: 2,360 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 800 mm, spindle speed (max.): 9,000 rpm, For sale is a 6-axis machining center from AXA, model VHC 2-2360-XTS / 50. The machine is in good condition and fully functional, has only been used for light machining such as aluminium. Dsdpoyi Er Asfx Akvjck Of particular note: Each of the two NC tables allows clamping of workpieces up to Ø1,100 mm – see drawing. A fixed milling table can also be mounted. A high-speed spindle insert SK50 is available for this machine. Technical data: Year of manufacture: 2008 Controller: Heidenhain iTNC 530 Machine on: 50,236 hours Spindle hours: 16,319 X-axis: 2,360 mm Y-axis: 600 mm Z-axis: 800 mm Spindle taper: SK 50 Spindle power: 56 kW Torque: 355 Nm Tool changer: 52 positions on 2 chains NC rotary tables (2 pieces) Type: SKH-NC 7/T Table plate: Ø 630 mm Max. load: 750 kg Clamping: Hydraulic Dimensions: 5,650 mm x 3,700 mm x 3,200 mm Weight: approx. 22,000 kg Equipment: IC coolant system with 50 bar high-pressure pump, belt filter, Heidenhain RCN 729 measuring system, 3D probe Renishaw OMP 60, electronic handwheel, 2x Visiport (inspection windows), chip conveyor. Tool holders are not included in the offer, but can be supplied at additional cost. Transport and loading can be organized throughout Europe on request for an additional fee. Prices are subject to VAT. Inspection possible by appointment. Please contact us – our team is happy to assist you. Trade-in or exchange possible! Machinery purchase and sales – BUYING / SELLING OF PRODUCTION & METALWORKING MACHINES AND MORE. Are you looking for a high-quality yet affordable metalworking machine for your production? Or do you want to sell your machine? For further information or to contact us, please visit our website.

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: 026694, travel distance X-axis: 3,200 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain iTNC 530i, rotational speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel X-axis: 3,200 mm Travel Y-axis: 800 mm Travel Z-axis: 600 mm Spindle mount: SK40 Speed: 50 – 12,000 rpm Dcjdsyg D Evopfx Akvek Number of tools in magazine: 30 pcs Table clamping surface: 3,900 x 750 mm Rapid traverse x/y/z: 12/12/12 m/min MACHINE DETAILS Control: Heidenhain iTNC 530i Total power requirement: 29 kW Dimensions & weight Space required: approx. 7,200 x 3,500 x 3,100 mm Machine weight: approx. 15,000 kg EQUIPMENT Chip conveyor 30-position tool changer High-pressure belt filter system Through-spindle coolant (IKZ) 15 bar SK40 tool holders Operating manual

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 3,200 mm, travel distance Y-axis: 720 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain TNC, workpiece weight (max.): 3,000 kg, TECHNICAL DETAILS X travel: 3,200 mm Y travel: 720 mm Z travel: 600 mm Table height: 900 mm Number of T-slots: 5 T-slot width: 18 mm T-slot spacing: 125 mm Dcedpfx Ajxn Nd Sekvsk Distance spindle nose to table: 140 - 740 mm Max. workpiece weight: 3,000 kg Clamping surface: 3,900 x 650 mm Tool holder: DIN 69871 AD 40 Spindle speed: 30 - 8,000 rpm Max. torque: 102 x 240 Nm Number of tools: 30 pcs Max. tool length: 330 mm Tool clamping: disc spring Max. milling capacity: 400 x 600 Max. thread size: M20 x M30 mm Boring diameter: 28 x 44 mm Feed rates X/Y/Z axis: 30,000 mm/min Rapid traverse X/Y/Z: 30 / 30 / 30 mm/min Max. feed force: 9,000 / 9,000 / 9,000 kN MACHINE DETAILS Control: Heidenhain TNC Space requirement (L x W x H): 7,200 x 3,400 x 3,100 mm Coolant: 250 bar Total power requirement: 50 kW EQUIPMENT Special accessory Trautomatic (L = 7.50 m) Special accessory full enclosure for work area (H = 3.60 m)

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, travel distance X-axis: 2,100 mm, travel distance Y-axis: 1,020 mm, travel distance Z-axis: 762 mm, controller model: Fanuc MXP-200FP, spindle speed (max.): 6,000 rpm, TECHNICAL DETAILS Travel Axes X-axis travel: 2,100 mm Y-axis travel: 1,020 mm Z-axis travel: 762 mm Spindle Spindle speed: 6,000 rpm Spindle power: approx. 22 kW Spindle torque: approx. 550 Nm Spindle taper: SK 50 Max. tool diameter: 120/240 mm Max. tool length: 350 mm Table Table clamping surface: 2,300 x 1,020 mm Table load capacity: max. 3,000 kg Number of T-slots: 6 x 22 mm T-slot spacing: 150 mm Dcodsw Nv I Ispfx Akvsk MACHINE DETAILS Control: Fanuc MXP-200FP EQUIPMENT Tool changer with chain magazine, 40 stations Coolant unit with through-spindle coolant pump and filter Emulsion mist extraction Electronic handwheel 2 pcs. magnetic clamping plates 800 x 400 mm Various SK50 tool holders Chip conveyor Note: Oversized load transportation is required for this machine.

Condition: used, Year of construction: 1996, x-travel 3000 mm y-travel 1500 mm Dcsdpfx Aeud Ixljkvek z-travel 400 mm Serial number 7872 chip conveyor MAYFRAN 40.6GS-HR/SP20 control SIEMENS SINUMERIK 820 table surface area 3000 X 1500 mm table load 1000 kg / m2 Tool changer 52 stck. weight of the machine ca. 15000 kg UNISIGN - Uniport 4 - Machining centre - Vertical Technical details will be added shortly 40820 operating hours including chip conveyor from the manufacturer MAYFRAN with TYPE 40.6GS-HR/SP20 Total weight: 15,000 kg

Condition: used, Year of construction: 2001, x-travel 2050 mm y-travel 1100 mm z-travel 800 mm Control Fanuc 18iM Super Cap II turning speeds 60-6000 U/min tool magazin: 60 Dsdorw Dknjpfx Akvock tool taper BT50 total power requirement 26 kW weight of the machine ca. 23,6 t required space 6,3 x 3,3 x 3,8 m

Condition: ready for operation (used), Year of construction: 2005, operating hours: 11,148 h, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 620 mm, travel distance Z-axis: 520 mm, table length: 2,500 mm, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS X-axis travel: 2,000 mm Y-axis travel: 620 mm Z-axis travel: 520 mm Number of axes: 3 Table length: 2,500 mm Table width: 600 mm Tool holder: SK40 Main spindle power: 20 kW Max. spindle speed: 12,000 rpm Tool magazine: 30 MACHINE DETAILS Dimensions (L x W x H): 5,000 x 2,500 x 3,000 mm Net weight: 10,500 kg Power: 20 kW Operating hours: 11,148 h EQUIPMENT Dedpex Hzn Asfx Akvock - Tool magazine - Chip conveyor - External cooling - without machine vices.
