Used Automatic Dowel Inserting for sale (21,115)

Condition: used, machine/vehicle number: 007870, Max. panel width: 3200 mm Podewimz Hopfx Amkopt Max. panel length: 800 mm No of Bottom Units: 2 No of injectors: 12

Condition: used, Year of construction: 2006, functionality: fully functional, TECHNICAL DETAILS Components ADVANTAGE C transverse loader: automatic ROTATING DEVICE (flipper): available BIESSE FTT: with 4 heads, drilling and milling, automatic tool change BIESSE FHT: 2 WORKING UNITS horizontal drilling and dowel insertion WANDRES: brush cleaning from top ADVANTAGE SC transverse unloader: automatic Plate dimensions Plate length: 240 - 3,200 mm Single panel width: 140 - 1,550 mm Pjdpfxjy Ui Rne Amkopt Plate width: 140 - 800 mm Plate thickness: 12 - 60 mm Drilling units Drill heads FTT 800: 2 machining centres with 4 boring units - 5 working tables Vertical spindles (X-direction): 14 independent per head Vertical spindles (Y-direction): 18 independent per head Horizontal spindles (X-direction): 3 independent, with double output Horizontal spindles (Y-direction): 3 independent, with double output Tool change system Revolver cartridges: 2 Positions per cassette: 56 Application: Automatic tool change of the vertical spindle centers on 4 drilling units of the two machining centers A and B. Milling spindles Electro spindle 1: 3.7 kW (5 HP), ISO 30, with inverter and 3-way tool change rack Electro spindle 2: 3.7 kW (5 HP), ISO 30, with inverter and 3-way tool change rack Lateral positioning units Workstations: 2 for parallel processing of identical or mirror-inverted panels left positioning element: fixed for lateral reference Right positioning element: movable in X-direction, on lower supports, linearly guided Adjustment: automatic according to the X-dimension of the panel Drive: Brushless with digital control Function: Detection of the actual X Length in the machining center, automatic correction of the drilling positions Max. travel speed: 120 m/min Loading and unloading Infeed system: 1 belt conveyor with cross feed, single drive Unloading system: 1 belt conveyor with cross feed, single drive Additional: Cleaning fan in the unloading area Drill heads FHT (horizontal): machining centres with 2 working units (1 LH unit / 1 RH unit) - 3 working tables. HORIZONTAL BORING UNITS with 24 independent spindles to be installed onto 2 operating units HORIZONTAL INSERTING UNITS WITH 5+5 GLUE INJECTORS AND 8 mm. DIAMETER DOWEL INSERTERS TOOL-HOLDER ADAPTOR for the quick change spindles of the boring units. GLUE INJECTION AND DOWEL INSERTING UNIT for 8 mm. dia. dowels to be added to the standard ones. The unit is prearranged for the insertion of 8 mm. diameter and 25-35 mm. long dowels.* The 8 mm. diam. dowel inserting units are required. NOTE: Dowel inserting unit was never used and not tested. Not possible to be tested ADVANTAGE C 3200 TRASV. 1 POS - loading ADVANTAGE SC 3200 TRASV. 1 POS - unloading Security features Standards: CE compliant Safety equipment: Extensive protective enclosures

Year of construction: 2006, condition: used, functionality: fully functional, We present an Automatic drawer slide insertion line of 3 machines and robot (currently in production): BLA - B41, manufactured 2006/2007 (Sweden) BLA - B28, manufactured 2006 (Sweden) Screwdriver 3RL, manufactured 2018 (Lithuania) Robot TECHNICAL SPECIFICATIONS Inserting of Drawer Slides Fitting machine BLA-B41 – pos. 1 Fitting machine in pass-through outfit, equipped with positioning stop, designed for automatic screwing of drawer slides. The fitting machine is designed for following sizes of material: Deep: 300–600 mm, servocontrolled adjustment Height: 400–1500 mm, servocontrolled adjustment Thickness: 16 mm Dimensions Machine length: 4100 mm Pass-through height: 900 mm Screwdriver equipment Screwdriver beams, 2 units, each equipped with 2 screwdrivers and corresponding screw feeders for Ø6.3x13 screws. A suiting screw is the type 84 FSX Magazine units 2 magazine units designed for left drawer slide 2 magazine units designed for right drawer slide · Each magazine contains approximately 40 drawer slides. · The length of the slides are 450 mm and the width 21.5 mm. Buffer conveyor TPB – pos. 2 Driven roller conveyor Total length: 2150 mm Other specifications are the same as for pos. 3 above. Buffer conveyor TPB – pos. 3 Driven roller conveyor Total length: 2450 mm Roll length: 600 mm (620 mm inside conveyor frame) Roll pitch: 150 mm Roll type: Ø50 mm steel, coated with thermoplastic rubber Speed: 0.78 m/sec. at 50 Hz (frequency controlled) Height: 900 mm Returning Conveyor System TPT-US – pos. 4 Sideway section with four belts Speed: 0.5 m/sec. at 50 Hz (frequency controlled) Driven roller conveyor Total length: 8900 mm Roll length: 600 mm (620 mm inside conveyor frame) Roll pitch: 150 mm Roll type: Ø50 mm steel, coated with thermoplastic rubber Speed: 0.50 m/sec. at 50 Hz Height: 900 mm Additional specifications Podpfx Aoy T Nfijmkopt Sound pressure level Lower than 70 dB(A) Connection facts electrical With reference to the electrical drawings Connection facts pneumatic 0.63 MPa (6.3 bar), ½”

Condition: used, machine/vehicle number: 005448, Max. panel width: 3000 mm Max. panel length: 1350 mm Pedpfowcydzox Amkjpt No of injectors: 24

Year of construction: 2013, condition: used, We are offering this used TE Connectivity Insertion Machine P 300 pin inserter, year of manufacture 2013. Operating condition: "System functionality is no longer fully ensured. Functional limitation: After switching on, automatic initialization/homing does not work." If you are interested, we are certainly open to negotiating a price. Machine type: Insertion Machine P 300 Serial number/part number: 1-1372900-4 Manufacture date: 01/2013 Supply voltage: 230 V Phases: 1P~ Frequency range: 50/60 Hz Rated current: 2.5 A Max. current: 10 A Short-circuit current: 50 kA Ppodpfsy R I Uwsx Amkst Required air pressure: 6 bar Weight: 1600 kg If you have any questions or need further information, please feel free to send us a message or call us.

Condition: used, Year of construction: 2014, Used machine Year of manufacture: 2014 Equipment and technical specifications: Complete in standard configuration with: - Support with linear guide consisting of: 1 pc. single-spindle horizontal drilling unit, 0.65 kW motor, stroke 70 mm Tool speed selectable via operator software (3,000/5,000/8,000 rpm) 1 pc. blow-out, glue application, and dowel insertion station for dowels Ø 8 mm, dowel length 25-50 mm - Fully automatic, electronically controlled central lubrication - X-axis NC-controlled, with working length 1,300 mm, feed speed max. 105 m/min - Z-axis adjustable manually via mechanical digital counter, position via support table 5-40 mm - Dowel insertion projection adjustable 7-20 mm via mechanical digital counter, drilling depth 0-35 mm (with drill length GL 70 mm) is automatically set in conjunction with insertion projection - Closed glue system with 6 bar glue pressure via glue nozzle, for adhesives with viscosity 150 to 350 mPas - Glue quantity infinitely adjustable via operator software - Selector switch GLUE/WATER for flushing the glue system, each with: 1 stainless steel container for 7.5 kg glue and 7.5 l water - Control lamp for glue level indication in the glue container - 1 pc. left side fence, 1 pc. right side fence, and 1 pc. center fence (all removable) - 4 pcs. start buttons for individual operation with 1-4 workpieces - 4 pcs. pneumatic angled clamping cylinders 10° for workpiece thickness up to max. 80 mm, workpiece length (Y) min. 70 mm - 1 pc. extraction funnel, connection Ø 80 mm 1 pc. TCT control with: Integrated industrial PC, incl. Soft PLC type Beckhoff TWINCAT, operating temperature range 0-50°C, 15" capacitive TFT industrial touchscreen display, operating system: WINDOWS 7 - Programming via menu-guided user software, drilling distances freely programmable with ABSOLUTE, RELATIVE, or GRID dimensioning, automatic workpiece mirroring and process optimization, 4 work areas can be assigned with different programs, graphical workpiece representation, parametric programming, zero-point offset, programmable work lists, error diagnosis with plain text Pedpfx Aoy Ih Sksmkopt Options: 1 Electronic, optical glue monitoring system G.I.C. (Glue Insert Control) for 1 pc. glue nozzle 1 Z-axis with NC-controlled dynamic positioning for height adjustment of the drilling and dowel insertion station (programmable from 5-40 mm) travel speed max. 30 mm/sec 1 Single-spindle vertical drilling unit from above, 0.65 kW, (3,000/5,000/8,000 rpm), position (Y) manually adjustable via mechanical digital counter from 5-40 mm, drilling depth (Z) max. 30 mm (with drill length GL 57 mm), workpiece thickness (Z) max. 50 mm, workpiece length (Y) min. 130 mm (incl. drilling depth compensation, e.g., for Häfele Minifix) 4 Vertical-angled clamping cylinders 10° with holders, additional 1 Keyboard with holder Availability: by arrangement; currently being overhauled at Ganner factory Location: Austria

Condition: used, machine/vehicle number: 007400, Max. panel width: 800 mm Max. panel length: 1250 mm No of injectors: 1 Psdpfxjt Hmt Is Amkopt Positioning of Units by NC: yes Lateral horizontal groups: yes

Condition: new, Year of construction: 2025, Advantages of Pre-glued Dowels • No additional glue required when inserting dowels • No cleaning required for the water supply system Advantages of the DübelJet • Recoil-free gun • Simple handling • Mobile handheld device • Universal application range Technical Data of the DübelJet Dowel system and water supply system designed for pre-glued dowels Pedpewu Dnnofx Amkspt • Dowel diameter: 8 mm • Dowel length: 35 mm (default setting, adjustable from 30 to 40 mm) • Dowel projection: 12 mm (default setting, adjustable from 7 to 20 mm) Universal application • Insertion of pre-glued dowels (with water), especially in furniture manufacturing • Insertion of positioning dowels (without water) made of wood or plastic, e.g., in frame construction or in combination with screws or cabinet connectors

Condition: used, Year of construction: 2013, Bore diameter , mm Number of heads horizontal , St. Number of heads vertical , St. 2 pcs. Götzinger drilling and milling centers ----- For sale on behalf of a customer! 2 identical machines: Ppsdev N N Spspfx Amkjt One machine for "left" parts and one for "right" parts. The machines can also be used individually. The machines were controlled via window manufacturing software, but can also be operated via the machine software. Both machines are equipped identically: - Left and right drilling units for front-end drilling. - 3 units for drilling and milling for longitudinal machining. - Parts are loaded once, and the unit carrier then moves for the various machining operations. Installation length per machine approx. 6 m. Individual sale possible: Price per machine 10,000 Euro See the enclosed PDFs for more information.

Condition: new, Year of construction: 2022, Demonstration machine Year of manufacture: 2022 Equipment and technical data: Base machine 7402 with Pin-Jet dowel insertion function Handheld control device Ppsdpowt E Tvefx Amket 2D barcode scanner Uninterruptible power supply (UPS) Quattro-HSK package incl. 4-position tool changer XL drilling head Double drill spindle in Y-axis Automatic central lubrication Availability: short notice Location: Flörsheim

Condition: repair required (used), Year of construction: 1998, functionality: limited functionality, 2 drilling spindles, individually selectable 1 glue gun (note: glue pump missing) Dowel insertion tool for 8 x 40 mm dowels The following issues were identified during testing: - Glue specification missing Ppjdpfxsytq R Eo Amket - Center stop rule missing - On the left working field, the front stops do not engage; instead, they lower when drilling on the right field - SPS module Beckhoff repeatedly fails. Machine must then be restarted. - Rubber pads under the hold-downs are missing. When inserting the dowels, the parts deform because the surface is too smooth

Condition: like new (used), functionality: fully functional, Dowel inserting machine with operating gun for simultaneous glue application and dowel insertion Standard dowels Ø8 mm Dowels lenght 25 - 80 mm Nominal capacity 1 dowel/second (includes glue application) Uses PVA adhesives (glue) in water dispersion viscosity 200-400mPa 1 pcs TANK FOR GLUE capacity 8 kg Ppedpfx Amsqu N U Doket 1 pcs TANK FOR WATER capacity 8 kg Maximum pressure 5 bar

Condition: used, machine/vehicle number: 008406, Max. panel width: 1000 mm Max. panel length: 2500 mm Psdpfxoyl Ihxo Amkjpt No of injectors: 12

Condition: excellent (used), CNC Flexible Automatic through-feed ROUTERING, DRILLING and DOWELS INSERTING LINE Min/Max workpieces (panels) width (X axis) with FTT: mm 240 / 3100 Min/Max workpieces (panels) thickness (Z axis) with FTT: mm 12 / 60 Min/Max workpieces (panels) length-depth (Y axis) with FTT: mm 140 /1550 (or 800+800) A) Motorized Roller table "RBO" with 90° conveyoring belts B) Gantry (Portal) CNC (Routering and Drilling) machine "BIESSE" FTT 800 slot A: No. 2 vertical Electro-spindles ISO 30 (Kw 4.5 each) with 2 tool-holder stores 3 places each (tot. 6) slot B: No. 2 predispositions for the installation of other 2 electro-spindles No. 4 upper drilling units (4x32 = total 128 vertical spindles + 4x4= tot. 16 horizontal spindles in Y-axis) No. 2 drilling spindles stores/magazines (revolver) with 60 positions each (total 120) C) Connection system, with up-side-down turning machine (180°) "RBO" Mod. Ribaltatore D) Gantry (Portal) CNC (Routering and Drilling) machine "BIESSE" Mod. FTT 800 R8 Ppjdpjyhqa Aofx Amkot No.2 horizontal units (1 left+1 right) with 4x BH18 heads with 18 spindles each (36 right + 36 left) total 72 slot A: No. 2 vertical Electro-spindles ISO 30 (Kw 4.5 each) with 2 tool-holder stores 3 places each (tot. 6) slot B: No. 2 predispositions for the installation of other 2 electro-spindles No. 4 upper drilling units (4x32 = total 128 vertical spindles + 4x4= tot. 16 horizontal spindles in Y-axis) No. 2 drilling spindles stores/magazines (revolver) with 60 positions each (total 120) E) "BIESSE" RD dowels insertion machine No.2 horizontal units (1 right+1 left) with 5 insertion nozzles each (5 left + 5 right), total 10 nozzles F) Brush-cleaning machine "WANDRES"

Condition: used, machine/vehicle number: 006158, Max. panel width: 1000 mm Max. panel length: 2500 mm Ppsdpfxsiwptuj Amkst No of injectors: 14 Positioning of Units by NC: yes

Condition: used, machine/vehicle number: 008342, Max. panel width: 70 mm Podpfx Amex A Tc Uskspt Max. panel length: 2100 mm No of injectors: 4 Lateral horizontal groups: yes

Condition: used, machine/vehicle number: 008014, Max. panel length: 1250 mm Lateral horizontal groups: yes Podpfx Amewuz S Djkept

Condition: good (used), Year of construction: 2009, functionality: fully functional, Dowel Insertion Machine Ganner Selekta 252 Ppedpjycf Ikjfx Amkst Year of manufacture: 2009

Condition: excellent (used), Gantry (Portal) machine Movable panel (workpiece), movable working head (Horizontal position of the panel/workpiece) Numerical Control Power Control, Software WoodWOP Safety cabin (enclosure) of the working head and integral safety cabin (enclosure) of the machine In-feeding working table (panel support). Out-feeding working table (panel support) Pjdpfsgwbbqjx Amkept Panels (workpieces) feeding by No. 3 motorized belts - Feeding speed (m/min) max 130 ca. Minimum workpieces dimensions (X - Y - Z) mm 250 x 100 x 15 Maximum workpieces dimensions (X - Y - Z) mm 2500 x 1050 x 60 Motorized carpet to evacuate chips and wastes. Separate electric and command cabinet Total installed power: Kw 99 N° 2 WORKING GROUPS (TOP) - (SERVO-MOTOR X-Y-Z ): N° 4 Drilling heads (4 x Kw 2.3) with No. 10 vertical spindles each (total top spindles No. 40) N° 3 WORKING GROUPS (BOTTOM) - (SERVO-MOTOR X-Y-Z ) : N° 6 Drilling heads (6 x Kw 2.3) with No. 40 vertical spindles each (total bottom spindles No 240) N° 2 WORKING GROUPS (HORIZONTAL) N° 2 Drilling heads with horizontal spindles N° 21 Horizontal drilling spindles (Right Side) + N° 21 Horizontal drilling spindles (Left Side) N° 8 Dowel Inserting nozzle & glue injectors(Right side) + N° 8 Dowel Inserting nozzle (Left Side) N° 2 Storage tanks for automatic feeding of the dowels OPTIONAL: WIRELESS BAR CODE SCANNER

Condition: excellent (used), CNC Flexible Automatic through-feed ROUTERING, DRILLING and DOWELS INSERTING LINE Min/Max workpieces (panels) width (X axis) with FTT: mm 240 / 3100 Min/Max workpieces (panels) thickness (Z axis) with FTT: mm 12 / 60 Ppedpfx Amogvdkgokjt Min/Max workpieces (panels) length-depth (Y axis) with FTT: mm 140 /1550 (or 800+800) A) Loader (Bridge Frame) "RBO" Double Station, Mod. Advantage C B) Motorized Roller table "RBO" with turning device 90° (length to crosswise) C) Gantry (Portal) CNC (Routering and Drilling) machine "BIESSE" FTT 800 Centre A: No. 2 Electro-spindles ISO 30 (Kw 3,7 each) with tool-holder magazine with 3 places each. Centre B: No. 2 predispositions for the installation of other 2 electro-spindles No. 2 tool-holder magazines (revolver) with 56 positions each. No. 4 upper drilling units (total 128 vertical spindles + 36 horizontal spindles) D) Connection transfer, with upsidedown turning machine (180°) "RBO" Mod. Ribaltatore E) Gantry (Portal) CNC (Routering and Drilling) machine "BIESSE" Mod. FTT 800 R8 No.2 horizontal units(1 left+1 right)with 4 BH18 heads with 18 spindles(36 right + 36 left),total 72 Centre A: No. 2 Electro-spindles ISO 30 (Kw 4,5 each) with 3 tool-holder magazine each. Centre B: No. 2 predispositions to install another 2 electro-spindles No. 2 tool-holder magazines (chain) with 60 positions each. No. 4 upper drilling units (total 128 vertical spindles + 36 horizontal spindles) F) "BIESSE" RD dowel insertion unit No.2 horizontal units(1 right+1 left)with 5 insertion nozzles each (5 left + 5 right), tot. 10 nozzles G) Stacker (Bridge Frame) "RBO" Double Station, Mod. Advantage SC

Condition: excellent (used), Double-sided machine, which can be placed in line after a through-feed Multi Borer for the automatic processing cycle of boring and dowels inserting Pjdpfx Amow Ug A Hekept - Electronic Programmer "CNI" NC 400 - Built-in command and electric cabinet - Max. distance between the horizontal heads mm 3200 approx - Movable and adjustable right side of the machine (according to the width of the panels) - No. 2 motorized conveyoring belts (HP 0.25 x 2 motors) - No. 1+1 dowels storage tanks for the automatic feeding to the nozzles - No. 6+6 horizonal inseritng nozzles (Glue injectors and dowel drivers) - High-pressure Glue-feeding system - Total installed power KW 5 ca.

Condition: excellent (used), Flexible N.C. line for drilling, routing and "hardware" insertion. Numerical Control "TPA" Albatros. Composed by: 1) Hedgehog loader, with 12 positions (for 12 panels), vertical panel introduction. 2) CNC Drilling and routering machine Mod. Over 25.13 with inserter (for bushes, shelf support and base). - N. 1 operating head (estimated KW 5,5) with tool storing revolver (10 positions) - N. 1 boring head with 24 independent spindles (X axis) - N. 1 boring head with 2 independent spindles (Y axis) - N. 1 boring head with 5 independent spindles (Z axis) - N. 1 insertion unit (bushing screwing) - N. 1 insertion unit (shelf support pressure) - N. 1 storage and feeding tank Ppsdpjhvagkjfx Amkjt 3) Unloader (90° side-deplacement), with motorized conveyor for vertical outfeed of the panel. 4) Unloader - tilting (0°-90) moves the panel from vertical to horizontal, with motorized conveyor

Condition: excellent (used), Flexible N.C. automatic line for drilling, routing and inserting (hardware). Numerical control with Albatros software. Consisting of: KZ2046) Infeeder with hedgehog (buffer) store (18 positions) KZ2047) Transfer with motorised conveyoring belt KZ2048) CNC Mod. Vector GLR-X 30-13 KZ2049) Transfer with motorised conveyoring belt KZ2050) CNC Mod. Vektor XK 40-13 KZ2051) Transfer with motorised conveyoring belt Ppsdpfx Amoidmkrokjt KZ2052) CNC Mod. Idrak 3 KZ2053) Transfer with motorised carpet with 90° inclination on a rollers table KZ2054) Rollers conveyor with also motorised belts (to move panels at 180° to the assembly lines)

Year of construction: 2012, condition: excellent (used), Machine equipment with 2 working fields. 2 workpieces can be inserted independently of each other. Pjdjmrqrijpfx Amkspt Workpiece dimensions - length 110 - 800 mm - width 20 - 1700 mm - height 14 - 60 mm - Working height 900 mm Machine structure - 1 x horizontal drilling station 0,9 kW. Drill speed 7.200 rpm - drilling depth max. 30 mm - Drill depth 10 mm - total drill length 85 mm - 2 x glue application and dowel insertion station - 2 x dowels, dowel projection 15-20 mm - dowel center distance 96 mm - 2 x oscillating conveyor dowel - 1 x glue pump 18:1 - 2 x electronic glue control ELC - workpiece support table 1700 mm - 8 x workpiece clamping cylinders - Center stop for 4 working fields - Central lubrication with hand pump for grease lubrication - NC positioning of the height adjustment of the drilling and doweling station (Z-axis) - axis with position control, travel speed 12 m/min KOCH Numeric positioning control with 1 NC axis (X)

Condition: new, Year of construction: 2025, functionality: fully functional, Gannomat Selekta dowel driving device Ppedpfx Amovxgm Nskjt Year of manufacture 2025 Dowel driving machine with gun for simultaneous gluing and dowel driving. For professional and efficient processing of dowels in furniture and frame construction. • Constant dowel driving protrusion • Always constant and correct amount of glue • Due to the correct amount of glue, no subsequent cleaning of the workpieces is necessary • Easy cleaning of the glue system via EasyClean, the automatic cleaning program • Automatic ejection of dowels with the wrong diameter and length thanks to Auto-DL-Selekt • Dowels are not driven into the bottom, the dowel driving protrusion is set independently of the drill hole depth • Recoil-free, extra-light and comfortable glue-dowel-driving gun • Great time saving compared to glue bottle and hammer
