Used Dowel Insertion for sale (2,214)

Condition: used, Year of construction: 2006, functionality: fully functional, Drilling, Milling, and Dowel Insertion Center – KOCH Model WINDOOR-L, Year of Manufacture 2006 Iiodjxgfd Sopfx Afish Working Length (Y): 150 – 800 mm / 50 – 1,350 mm (2,100 mm in 2 cycles) Material Thickness (Z): 14 – 60 mm Maximum material length: 2,100 mm. Material stops on the right and left are automatically lowered to allow processing of oversized workpieces. The machine is equipped with 2 working fields. 2 workpieces, each with a maximum width of 650 mm, can be placed independently. Wider workpieces are positioned separately. Working height: 900 mm Machine features: • 1 horizontal drilling station • Guide bush for drill bits • Glue injection and dowel insertion station Drilling unit: 2 kW Drill speed: 2,800 rpm, with air nozzles for cleaning the dowel holes 1 dowel drill bit, 8 mm dowel diameter Dowel length: 30 mm Dowel protrusion: 7–14 mm, set to 12 mm 2 Milling units, 3 kW each (12,000 rpm): One right-hand, one left-hand rotation with vertical spindle. Frequency inverter for stepless speed control from 6,000 – 12,000 rpm. Spindle diameter: 40 mm, collet length: 70 mm, profile diameter: 100 – 200 mm. 1 brake for the profiling motors, without acoustic enclosure. 1 Vibratory dowel feeder 1 glue pump 1:1 with central lubrication Electronic glue monitoring 1 material clamping system with 10 pneumatic cylinders • 1 material stop on the left and right • Mechanical digital readouts for adjustment Machine cycle is started by push buttons • Modem for remote diagnostics via telephone line KOCH Numeric positioning control PC Pentium CPU Screen area in local language OS (Windows XP Professional): English 15” touch panel VGA graphics + touch screen via LVDS connection USB interface to PC and touch panel Serial and parallel interface to PC 2.5” hard drive All machine functions, including motor control, entered via the touch panel Electrical supply: 400 V, 50 Hz, 3 phase Pneumatic connection: 1 x R 1/2" female thread, 7 bar Dust extraction airspeed: approx. 30 m/sec Ambient temperature at installation: min. 10°C (50°F), max. 40°C (100°F)

Condition: like new (used), functionality: fully functional, Dowel inserting machine with operating gun for simultaneous glue application and dowel insertion Standard dowels Ø8 mm Dowels lenght 25 - 80 mm Nominal capacity 1 dowel/second (includes glue application) Uses PVA adhesives (glue) in water dispersion viscosity 200-400mPa 1 pcs TANK FOR GLUE capacity 8 kg Iijdpfxjqu N U Ds Afish 1 pcs TANK FOR WATER capacity 8 kg Maximum pressure 5 bar

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, Machine for inserting vinyl glue and reins with gun - vibrating bowl for feeding the reins - glue tank 9 kg - water tank 9 liters - cleaning disposition - pneumatic pistol - for reins 8 mm, length 25 to 50 mm Iiedpexd Atljfx Afish

Condition: new, Year of construction: 2022, Exhibition machine Year of manufacture: 2022 Equipment and technical data: Base machine 7402 with Pin-Jet dowel insertion function Hand control device 2D barcode scanner UPS Isdpfx Afowt E Tvjijih Quattro-HSK package incl. 4-position tool changer XL drilling head Double drilling spindle in Y-axis Automatic central lubrication Location: Hochheim Availability: approx. week 32/2022

Condition: good (used), Year of construction: 2003, functionality: fully functional, Fully automatic electronic control with program selector switch RINSE-GLUE-GLUE/DRIVE - Dowel feed via electronic vibrating conveyor with potentiometer for stepless adjustment of the dowel feed rate - Closed glue system with 6 bar glue pressure via glue nozzle - GLUE/WATER selector switch for rinsing/cleaning the glue system with EasyClean function button (automatic cleaning program for glue hose and glue nozzle via spray funnel and dirty water collection container) - 1 stainless steel container for 7.5 kg glue, as well as 1 stainless steel container for 7.5 l water for rinsing/cleaning incl. 1 gun for dowels Ø 8 mm Dowel length 25 - 40 mm Iiodpjv Aubpsfx Afish Glue/dowel driving tool completely overhauled and no longer used

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, product height (max.): 60 mm, product height (min.): 12 mm, product length (max.): 3,200 mm, product length (min.): 240 mm, product width (max.): 800 mm, product width (min.): 140 mm, TECHNICAL DETAILS Components: ESSE2 cross-loader: automatic BIESSE FTT: with 4 heads, drilling and milling, automatic tool change Tilter: available BIESSE FTT: with 2 heads, drilling and milling, automatic tool change BIESSE FHT: horizontal drilling and dowel insertion ESSE2 cross-unloader: automatic Panel dimensions Panel length: 240 - 3,200 mm Single panel width: 140 - 1,550 mm Panel width: 140 - 800 mm Panel thickness: 12 - 60 mm Drilling units FTT 1 drilling heads: 4 FTT 2 drilling heads: 2 Vertical spindles (X-direction): 14 independent per head Vertical spindles (Y-direction): 18 independent per head Horizontal spindles (X-direction): 3 independent, with double output Horizontal spindles (Y-direction): 3 independent, with double output Tool change system Turret cartridges: 2 Positions per cartridge: 56 Application: Automatic tool change of the vertical spindle centers on 4 drilling units of the two machining centers A and B Milling spindles Electric spindle 1: 3.7 kW (5 HP), ISO 30, with inverter and 3-station tool change rack Electric spindle 2: 3.7 kW (5 HP), ISO 30, with inverter and 3-station tool change rack Lateral positioning units Workstations: 2 for parallel machining of identical or mirror-image panels Left positioning element: fixed to the lateral reference Iodswmcxispfx Afijih Right positioning element: movable in the X-direction, on lower supports, linearly guided Adjustment: automatic according to the X-dimension of the panel Drive: Brushless with digital control Function: Detection of the actual X-length in the machining center, automatic correction of the drilling positions Max. travel speed: 120 m/min Loading and unloading Infeed system: 1 belt conveyor with cross-feed, single drive Unloading system: 1 belt conveyor with cross-feed, single drive Additional features: Cleaning fan in the unloading area Safety features Standards: CE-compliant Safety equipment: Extensive protective enclosures

Year of construction: 1991, condition: used, machine/vehicle number: 9105/4452, Double end automatic operation, for straight, right-angled workpieces Stock dimensions Stock length 220 - 2500 mm Stock width 15 - 200 mm Stock thickness 15 - 50 mm Double-sided trim saw: The saws are cutting downwards through the clamped workpiece.Each side 1 sawing unit. Horizontal drilling station: each side 1 drilling unit with 1 drilling motor 2 kW Distribution of vertical drilling units: 3 units at the front of the overhead beam 2 units at the back of the overhead beam Workpiece centre support: With stop and back stop Iedpfx Afoit T H Seijih Edge drilling unit: Each Side 1 support with height adjustment Distance from edge max 250 mm.

Condition: used, In this offer you purchase a used accessory ‘Canon Document Insertion Unit N1’ Object of sale: 1 x Canon Document Insertion Unit N1 for various Canon models Iedpfx Aot Rfh Esfioih Condition: This offer is for a used device, which may show signs of use (minor scratches or yellowing). (minor scratches or yellowing). The device has been tested for function Packaging and dispatch: You are welcome to view the device during our business hours. Please make an appointment for this! Seaworthy packaging and worldwide shipping available on request! For further information you can of course also contact us personally.

Condition: excellent (used), Year of construction: 1982, with 2 drilling beams Used, good condition Make Scheer Type DB 3 Year of construction 1982 Machine no. 73021 Number of spindles: 25 Number of drill beams: 2 Spindle spacing/grid: 32 mm Drilling from above Hydraulic feed brakes: 2 Linear stop: 1 approx. 2500 mm Working width: approx. 800 mm (768 mm) Drilling depth: approx. 100 mm stroke Drill chuck: M 10 Pendulum stops: 3 Clamps: 3 Drill programs: 4 Space required: approx. 1400 mm x 1300 mm x 1800 mm Weight: approx. 1000 kg Location: Arrives at the end of April at warehouse 54634 Bitburg - free on freight - Handed over in the current condition, as seen, without overhaul, without warranty or guarantee Iiodpfjv Trlmsx Afieh

Condition: used, Year of construction: 2018, 1 x CNC-CONTROLLED DRILLING, GLUING AND DOWEL INSERTING MACHINE GANNOMAT "INDEX 130 PRO" (with options as Index 180 Pro) 400V, 3Ph, 50Hz complete in standard design with: - Support with linear guide consisting of: 1 x single-spindle horizontal drilling unit, 1.1 kW motor, tool speed selectable via operator software (3000/5000/8000 rpm) 1 x blow-out, gluing and dowel inserting station in reinforced design for dowels Æ 8 mm, dowel length 30 mm - fully automatic, electronically controlled central lubrication - X-axis NC controlled, with working length 1300 mm, travel speed max. 78 m/min. - Z-axis, position via support table 5-40 mm programmable with NC-controlled Z-axis option - Dowel driving overhang of 7-20 mm, programmable with NC-controlled Y-axis option, drilling depth of 0-35 mm (with drill length GL 70 mm) is automatically set with driving overhang - Closed glue system with 6 bar glue pressure via glue nozzle, for glues with a viscosity of 150 to 350 mPas - Glue quantity continuously adjustable via operator software - GL/WATER selector switch for rinsing the glue system, 1 stainless steel container each for 5 kg glue and 5 l water - Control lamp for residual glue quantity display in the glue container - 1 side stop left, 1 side stop right and 1 center stop (all removable) - 4 start buttons for individual working with 1-4 workpieces - 4 pcs. Pneumatic inclined clamping cylinder 10° for workpiece thicknesses up to max. 80 mm, workpiece length (Y) min. 70 mm - 1 pc. suction funnel, connection Æ 80 mm - 1 pc. TCT control with: built-in industrial PC, incl. Soft PLC type Beckhoff TWINCAT, operating temperature range 0-50°C, TFT industrial display 15" resistive touchscreen, resolution 1024 x 768, CPU 2 GHz, 256 MB RAM, 2x network interface adapters, IDE hard disk, 4x USB rear, 1x USB front, operating system: WINDOWS 7 - programming via menu-driven user software, drilling distances freely programmable with ABSOLUTE, RELATIVE or GRID dimensioning, automatic workpiece mirroring and work step optimization, 4 work fields can be assigned with different programs, graphic workpiece display, parametric programming, 0-point shift, programmable work lists, error diagnosis with plain text OPTIONS: 1 electronic, optical glue monitoring system G.I.C. (Glue Insert Control) for 1 glue nozzle 4 vertical inclined clamping cylinders 10° with holder, additionally, (total 8 clamping cylinders) 1 surcharge for machine bed length 1800 mm with working length 1800 mm 1 surcharge for: 1 horizontal drilling unit, motor 1.5 kW, with multi-spindle drilling head with 3 individually controllable drilling spindles, pitch 32 mm arranged in X-axis, tool speed 3000 rpm. (The standard working length is not reduced) 1 Y-axis NC-controlled, with recirculating ball screw and dynamic traversing speed of 300 mm/sec. The dowel driving overhang 7-30 mm and the drill hole depth 0-42 mm can be programmed via software. (with drill length GL 77 mm) for vertical drilling unit drilling from TOP, Y-axis position 5-42 mm 1 surcharge Y-axis NC-controlled position 5-62 mm instead of 5-42 mm 1 surcharge for: 1 vertical drilling unit drilling from TOP, motor 1.5 kW, with multi-spindle drilling head with 3 individually accessible drilling spindles, 32 mm pitch arranged in X-axis, tool speed 3000 rpm. Y-axis position 5-42 mm, workpiece length (Y) min. 130 mm, (the standard working length is not reduced) 1 Z-axis NC-controlled, with K Iodpfxoxnlf Es Afieih

Condition: used, Year of construction: 1992, Number of spindles per row of holes: 16 Number of horizontal spindles: 5 Cup hinge drilling head: yes Drill pitch: 32 mm Hold-down device: yes / pneumatic Power consumption: 2.2 kW Drilling unit: swivelling Iisdpfxowv Nb Nj Afieh

Condition: used, Year of construction: 1995, Rolling curve 45° with a criminal Conveyor curves, drive Centre Make: Transnorm Type: TS 2712 Year of construction: 1995 Project A49993 POS. 665 Conveyor angle: 45° Width: 500 mm constant speed V = 0.78 m/sec Role: slide stored with conical plastic molding and metal rollers without posts Optional columns Shipping weight: 120 kg on euro pallet Transportmasze: L x B x H = 1800 x 700 x 400 mm Für eine individuelle, fachmännische Beratung setzten Sie sich einfach mit uns in Verbindung. Kontaktieren Sie uns einfach telefonisch oder per Mail. Wir helfen Ihnen gerne bei der Planung und Umsetzung Ihrer Projekte. Wir freuen uns darauf von Ihnen zu hören. Mit freundlichen Grüßen Isdpek Aa N Aofx Afijih Ihr Team der Dr. Sonntag GmbH & Co. KG Ihr Spezialist und Ansprechpartner für Intralogistik

Condition: used, Year of construction: 1993, Used machine Year of manufacture: 1993 Equipment and technical data: Workpiece clamping height: up to approx. 250 mm Mortising unit with 2 program cams (lowerable) 2-jaw drill chuck for up to 20 mm shank diameter Pneumatic position adjustment on 2 levels 0-100 mm Maximum drilling depth: 150 mm Precision indexing rail: 12 mm Central locking and lateral adjustment 2 pneumatic safety clamping cylinders Motor: 1.5 kW Speed: 2800 rpm Space requirement with stop and working area: approx. 1200 × 1000 mm Dimensions (without stop): 1100 x 1100 x 1500 mm Weight: 310 kg All information is subject to change until the machine arrives at our warehouse. Availability: approx. end of October 2025 Ijdpfx Afjxiztueieih Location: Brandenburg

Condition: good (used), Year of construction: 2022, - Ideal for carpenters, interior fitters, and small-batch manufacturers - Robust and practical construction Isdpfx Aexlzcuofioih - Easy and trouble-free spindle head change - Certified, type-tested design - Pneumatic two-hand control for fast and safe operation - 6-spindle drilling head for hinge, mounting plate, and connector fittings drilling - Useful special accessories provide extended machining capabilities for furniture parts - Voltage: 230 V Price: Please submit your binding offer Availability: Immediately Delivery terms: ex works (EXW) Payment terms: Payment before collection Accessories without guarantee. Sold as seen. The prospective buyer must inspect the completeness of the item onsite.

Condition: new, Year of construction: 2025, CNC-controlled drilling, gluing, and dowel insertion machine Isdpfxow Sgm Ho Afisih Complete in standard configuration with: - Support with linear guide consisting of: 1 pc. single-spindle horizontal drilling unit, motor 0.65 kW, stroke 70 mm Tool speed selectable via operator software (3000/5000/8000 rpm) 1 pc. blow-out, gluing, and dowel insertion station for dowels Ø 8 mm, dowel length 25–50 mm - Fully automatic, electronically controlled central lubrication - X-axis NC controlled, with working length 700 mm, max. traversing speed 95 m/min - Z-axis manually adjustable via mechanical digital counter, position on support table 5–40 mm - Dowel insertion projection adjustable from 7–20 mm via mechanical digital counter, drilling depth 0–35 mm (with drill length TL 70 mm), automatically set with insertion projection - Closed glue system with 6 bar glue pressure via glue nozzle, for glues with viscosity from 150 to 350 mPas - Glue quantity steplessly adjustable via operator software - Selector switch GLUE/WATER to flush glue system, each with: 1 stainless steel container for 7.5 kg glue and 7.5 l water - Indicator lamp for residual glue level in glue container - 1 pc. left side stop, 1 pc. right side stop (all removable) - 2 pcs. start buttons for individual operation with 1–2 workpieces - 2 pcs. pneumatic angled clamping cylinders 10° for workpiece thickness up to max. 80 mm, workpiece length (Y) min. 70 mm - 1 pc. extraction funnel, connection Ø 80 mm - 1 pc. TCT controller with: Integrated industrial PC, incl. Beckhoff TwinCAT soft PLC, operating temperature range 0–50°C, 15" capacitive touchscreen TFT industrial display, operating system: WINDOWS 10 IoT LTSC (long term support channel) - Programming via menu-guided user software, drilling distances freely programmable with ABSOLUTE, RELATIVE, or GRID dimensioning, automatic workpiece mirroring and process optimization, 2 working fields assignable with different programs, graphical workpiece display, parametric programming, zero-point shift, programmable work lists, plain text error diagnosis - Integrated options: - Electronic optical glue monitoring system G.I.C. (Glue Insert Control) for 1 pc. glue nozzle, art. no. 0470-0810 - 1 EASY CLEAN system, for automatic test glue shots before starting the drilling/gluing/dowel insertion program. E.C.S. for 1 pc. glue nozzle, art. no. 0471-Z010 - 1 single-spindle vertical drilling unit from ABOVE, 0.65 kW, (3000/5000/8000 rpm), position (Y) manually adjusted via mechanical digital counter Adjustable from 5–40 mm, drilling depth (Z) max. 30 mm (with drill length TL 57 mm) Workpiece thickness (Z) max. 50 mm, workpiece length (Y) min. 130 mm (incl. drilling depth compensation, e.g., for Häfele Minifix) Art. No. 0471-0830 - 4 vertical angled clamping cylinders 10° with mount, additional, Art. no. 0470-0850 Available: short notice

Condition: used, Year of construction: 2024, Dowel Hole Drilling Machine GANNOMAT "DB 21400V, 3Ph, 50Hz / 1.5 kW" complete in standard configuration, equipped with: - Fully automatic electronic control with pulse operation via foot pedal for clamp-drill-release sequence, including electrical skip operation. - Automatic return of the drilling unit after reaching the preset drilling depth. - Automatic drilling depth extension for end-face drilling. This saves the need to adjust the drilling depth when switching from flat-face to end-face drilling (+10 mm, e.g., with dowel length 35 mm, flat-face drilling depth 14 mm, end-face drilling depth 24 mm). - 1 drilling beam with 21 spindles, 32 mm pitch, 1.5 kW motor (drilling feed 0-70 mm). Includes 21 quick-change chucks (Ganner system) for easy drill bit changeover. - Easy pivoting of the drilling unit from 0° to 90°, assisted by gas cylinders. - 1 clamping beam movable on Y-axis with 3 pneumatic clamping cylinders, for workpieces up to max. 80 mm height. Ideal fence system consisting of: - 1 stop ruler, 1800 mm, for shelf drilling (aluminum profile 40x40 mm) with 3 drop-in stops. - Quick-change system, easily switchable from right to left stop for mirrored drilling of shelves in carcass construction; also suitable for line boring in system 32. - Side stops and position adjustments, as well as drilling height position, via mechanical digital counters on the support table. - Side stops can be easily folded away for fastest set-up change from carcass to frame or line drilling. - Clamping arms for the clamping beam enable line boring positions up to max. 300 mm. - Optimized three-stage tool system. Includes 1 set of dowel drill bits: - 5 carbide dowel bits, Ø 8x77 mm, right - 4 carbide dowel bits, Ø 8x77 mm, left Basic machine Dowel Hole Drilling Machine GANNOMAT "DB 21400V, 3Ph, 50Hz / 1.5 kW" complete in standard version, equipped with: Iodsxnlflepfx Afioih - Fully automatic electronic control with pulse operation via foot pedal for clamp-drill-release, electrical skip operation. - Automatic return of the drilling unit after reaching the preset drilling depth. - Automatic extension of drilling depth for end drilling saves the need to adjust depth when switching from flat to end drilling (+10 mm, e.g. for dowel length 35 mm, flat-side depth 14 mm and end-side depth 24 mm). - 1 drilling beam with 21 spindles, 32 mm pitch, 1.5 kW motor (drilling feed 0-70 mm). Includes 21 quick-change chucks (Ganner system) for easy drill changeover. - Easy pivoting of the drilling unit from 0° to 90°, gas spring assisted. - 1 clamping beam, Y-axis adjustable, with 3 pneumatic clamps for workpieces up to max. 80 mm high. - Ideal stop system comprising: - 1 stop ruler, 1800 mm, for shelf drilling (aluminum profile 40x40 mm) with 3 drop-in stops, quick-change system, easily switched from right to left for mirrored shelf drilling in carcass constructions, also usable for line boring in system 32. - Side stops and adjustable positions, as well as drill height position, via mechanical digital counters on the support table. - Side stops can be folded away easily for shortest retool time from carcass to frame and line boring operations. - Clamping arms for the clamp beam suitable for line-boring positions up to max. 300 mm. - Three-stage optimized tool system. Extraction funnel, dust tested, Ø 120 mm 1 set for line boring in system.

Condition: excellent (used), functionality: fully functional, overall weight: 71 kg, AYEN Magnum Dowel Inserter 25.09.8212 Net price: 5,900 PLN Dowel diameter range: 8–20 / 11–26 mm Simultaneous dowel insertion with integrated glue dispensing Cycle time: 1.2 s Stepless dowel diameter adjustment Adjustable glue dispensing volume Operating pressure: 6 bar Maximum glue working pressure: 6 bar Continuous air consumption: 200 l/min Glue tank capacity: 1.4 l (sufficient for approx. 10,000 dowels) Dowel hopper capacity: 4 l Installation dimensions: - Width: 480 mm - Depth: 480 mm - Height: 900 mm Total machine weight: 71 kg Single gun weight: 2.2 kg Mobile and portable device, easy to use Compact design Requires only compressed air for operation Accurate centering thanks to the protruding glue nozzle Glue always applied directly into the hole via the protruding nozzle Iiedpoxlr Smjfx Afijh Glue volume and injection time precisely adjustable via the valve control block Quick gun switching: "Glue + dowel" or "Glue only" Integrated water flushing option Standard high-pressure gluing system suitable for D4 glue Operates in any position, even upside down

Condition: used, Year of construction: 2012, TGW curves roller conveyors 45° left Iedpfxsk Aa Nqs Afieih Order no. 150072 Item 03.0721 year of manufacture: 2012- working width: 345 mm plastic rollers working width: 400 mm metal rollers total width: 480 mm inner radius: 1050 mm speed: 0.45 m / sec lateral guide on both sides Rollers: conical plastic molded rollers: Metal Optional: 3 supports Shipping dimensions: Lxwxh 2200 x 800 x 400 mm: 90 kg Für eine individuelle, fachmännische Beratung setzten Sie sich einfach mit uns in Verbindung. Kontaktieren Sie uns einfach telefonisch oder per Mail. Wir helfen Ihnen gerne bei der Planung und Umsetzung Ihrer Projekte. Wir freuen uns darauf von Ihnen zu hören. Mit freundlichen Grüßen Ihr Team der Dr. Sonntag GmbH & Co. KG Ihr Spezialist und Ansprechpartner für Intralogistik

Condition: new, Year of construction: 2025, functionality: fully functional, Gannomat Selekta dowel driving device Year of manufacture 2025 Dowel driving machine with gun for simultaneous gluing and dowel driving. For professional and efficient processing of dowels in furniture and frame construction. • Constant dowel driving protrusion • Always constant and correct amount of glue • Due to the correct amount of glue, no subsequent cleaning of the workpieces is necessary Ijdpfx Afevxgm Neioih • Easy cleaning of the glue system via EasyClean, the automatic cleaning program • Automatic ejection of dowels with the wrong diameter and length thanks to Auto-DL-Selekt • Dowels are not driven into the bottom, the dowel driving protrusion is set independently of the drill hole depth • Recoil-free, extra-light and comfortable glue-dowel-driving gun • Great time saving compared to glue bottle and hammer

Condition: new, Bore diameter variabel mm Number of heads horizontal 3 St. Number of heads vertical 4 St. Dimensions (L/W/H) 6100x1500x2300 mm Weight 950 kg 1 NEW drilling and milling center Götzinger Power Drill 300 With the Götzinger PowerDrill you can, depending on the type and design: - Drill on the front and on the long side - Dowels of front doors, pegs, fighters - The drilling patterns are freely programmable - You can drill: handle slides and corner bearings, with quick-change multiple spindle - You can: Milling lock case, pusher and PZ as well as 3D belts and drill - The machine has a horizontal and a vertical milling unit - A simple control lets you create drilling and milling programs, save and call again Base frame in sturdy design, covered with sheet metal Table top 1800 x 200 mm Processing unit: X-axis - 500 mm working travel Y-axis - 0-120 mm Z-axis - 0-105 mm (above table) Horizontal aggregates: 1 horizontal drilling unit (dowel drilling unit left) ----- Drilling motor 220 V, 1.1 kW Collet holder ER 25 4,000 - 11,000 rpm adjustable 1 milling unit horizontal for lock case ----- Milling motor 2.2 kW Speed ??controllable 3,000 - 16,000 rpm Collet holder ER 25 1 horizontal drilling unit (dowel drilling unit right) ----- Drilling motor 1100 W, infinitely variable 4,000 - 11,000 rpm, with collet holder ER 25 Vertical aggregates: 1 drilling unit vertical ----- Drilling motor 1100 W, infinitely variable 4,000 - 11,000 rpm, with collet holder ER 25 1 boring unit vertical - with quick-change boring head ----- Drilling motor 1,1 KW, 3,000 rpm Included: 1 boring head BKF 2/3, for corner bearing incl. Drill set, quick-change ----- On loose item, drill assembly to customer fitting Iedpsif Az Ujfx Afijih 1 boring head BKF 3, for olive incl. Drill set, quick-change ----- On loose item, drill 1 cubo d = 25, 2 x dowel d = 10 1 milling unit vertical for lock case ----- Milling motor 2.2 kW Speed ??controllable 3,000 - 16,000 rpm Collet holder ER 25 1 piece length stop right and left, usable length 2.7 m, NC controlled Control: electro-pneumatic with three-axis NC positioning controller and integrated machine function Input via TFT display, 10 "color Machine complete, CE-compliant, with 1 set of drilling tools, DÜBO each 1 x d = 6,8,10,12 + 2 roughing cutters d = 16, ready for connection Loading dimensions: Machine L x W x H = 2.50 x 1.50 x 2.30 m, weight 850 kg Length stop L x W x H = 6.00 x 0.30 x 0.30 m, weight 100 kg ----- Total price in above mentioned version, ex works: on request Plus freight and installation / instruction (Technical information according to the manufacturer - without guarantee!)

Condition: like new (used), Year of construction: 2025, GANNOMAT "JUNIOR 323" FRAME DOWEL AND SLOT MORTISING MACHINE Complete in standard configuration as per price list 01/22/D with: - Precision collet chuck for ER 40 collets Ø 3–26 mm, including collets Ø 10 / 13 / 16 / 20 - Motor 1.5 kW, 2800 rpm - Positioning via digital counter - Pneumatic 2-level positioning adjustment (0–100 mm) - Max. drilling depth: 150 mm - Precision indexing rail with 12 mm pitch, featuring: - Center detent and lateral adjustment 320 mm - 2 pneumatic safety clamping cylinders - Complete fence system consisting of: • 1 center stop and 1 stop for oversized frames • 1 round stop bar approx. 850 mm long (can be mirrored from left to right) • 2 flip stops - Tiltable slot mortising device with 2 program cams (400V, 3Ph, 50Hz, 1.5kW) - Extraction hood Ø 80 mm, dust-tested - Central mitre stop 45° - Pair of auxiliary workpiece supports, pivotable (left and right) - Drill head holder - 3-spindle drilling head, 32 mm pitch (can be rotated 90°) - Chassis with 4 wheels for easy machine movement Availability: Short-term – immediately – Iiedpoxdttisfx Afioh

Condition: new, Bore diameter variabel mm Number of heads horizontal 1 St. Number of heads vertical 0 St. 1 Götzinger dowel gluing and insertion machine BLE With the BLE, the workpieces are glued and dowelled on the front. Optional the BLE can be upgraded with a drilling unit, counter milling unit and longitudinal stop will. A 10" touch panel allows easy operation for manual or online operation. Base frame: in a compact design, covered with sheet metal Table support approx. 800 x 200 mm position 1 ----- 1 glue station full jet valve Glue quantity precisely adjustable Glue gun for counter hole gluing position 2 ----- 1 stainless steel glue pump, high-pressure pump and glue hose item 3 ----- 1 press-in station with dowel separation and press-in cylinder item 4 ----- 1 oscillating conveyor for dowels d 8 x 50 mm with feed hose into the injection unit item 5 ----- 1 processing unit with cross table, linear guide and 3NC axis motors X = 200 mm processing width Y = 120 mm processing height Z = 50 mm offset item 6 ----- 1 positioning controller Iijdpfxju Uu Uzs Afijh Touch panel 10" color 500 drilling patterns can be created and saved, which can be easily accessed when needed (1 drilling pattern can have up to 16 dowel positions) Software prepared for ONLINE connection With online control, the data for the control must be provided by the software be prepared. Our machine can then read and process this data. ----- Total price in this version Pos. 1 to Pos. 6: on request! Options with additional prices: ----- item 7 ----- 1 horizontal drilling unit, 1,000 W drilling motor Speed ??4,000 - 8,000 rpm, collet holder Pneumatic drill feed Surcharge: EUR 4,305.00 Additional accessories such as a larger touch screen, additional dowel station for additional dowel sizes or scanner for Program selection on request! Prices net plus statutory VAT, without packaging/shipping and without Installation. (technical data according to the manufacturer - without guarantee!)

Condition: excellent (used), Year of construction: 2017, SCM STARTECH 27 Dowel Drilling Machine with 27 Spindles Year of Manufacture: 2017 Top Condition Fast set-up thanks to spindles with quick-release system Pneumatic adjustment of the drilling head at 0° - 45° - 90° Iiedpfx Afjw Trp Njieh Fold-away side stops and stop extension up to 3 m Touch probe for mirror-image drilling Turret stop with 5 positions for precise depth adjustment Chip extraction system Technical Data Drilling spindles: 27 Drill spindle spacing: 32 mm Drill spindle speed: 3000 rpm Maximum stroke of drilling unit: 63 mm Maximum workpiece width under drilling unit: 1025 mm Panel thickness: 10 - 60 mm Motor power: 1.5 kW Location: ex stock 54634 Bitburg - Immediately available -

Condition: new, Bore diameter variabel mm Number of heads horizontal 3 St. Number of heads vertical 4 St. Götzinger Power Drill in special version with dübelleim and press-in station With the Götzinger PowerDrill, you can choose: - Drill the front and long sides - Doweling of doors, seatings, fighters - The drilling patterns are freely programmable - You can: Grip handle and corner bearing, with quick-change Multi-spindle drilling heads - You can: lock casings, pusher and PZ as well as 3D tapes and drill - The machine has a horizontal and a vertical milling unit - A simple control lets you create drilling and milling programs, Save and recall POWER DRILL - drilling and milling machine Universal drilling machine for drilling olives, corner bearings, dowel work On the front and the front, milling, lock boxes, tapes, etc. Base in stable design, covered with sheet metal Table top 1800 x 200 mm Processing unit: X-axis - 500 mm working travel Y-axis - 100 mm Z axis - 105 mm 1 drilling unit horizontal (dowel drilling unit left) Drilling motor 380 V, 1,100 W Clamping chuck d = 8/10 4,000 - 11,000 rpm can be adjusted 1 drilling unit vertically from above - fixed Drilling motor 1.1 KW, 3,000 rpm Quick change of the drill head 1 drill head BKF 2/3, quick-changeable, (corner bearing) On the loose part, hardware according to customer requirements including drill replacement Control: electro-pneumatic with three axes NC positioning controller and integrated machine function Input via TFT display, 10 "color Machine complete, CE compliant, with 1 set of drilling tools Dübo je 1xd = 6,8,10,14 + 2 Roughing cutter d = 16, 1 milling cutter d = 20, ready for connection 1 drill head BKF 3, fast exchangeable for olives including drill bit Fitting according to customer requirements 2 drilling units 1 x horizontal for drilling from above (for tapes) 1 x vertical for dowel work, right Drilling motor 1.100 Watt, infinitely variable 4,000 - 11,000 rpm with collet chuck ER 20 2 Milling units for lock boxes 1 x horizontal for tapes, lock boxes 1 x vertically from above for PZ, pushers, tapes Milling motor 2.2 KW Speed ??adjustable 3,000 - 16,000 rpm Clamping tool holder ER 25 1 length stop right and left, working length 2.8 m NC-controlled When the length stop is used, the fixed stops are removed. Dimension: Iijdpfx Aed Ih Hyefieh LxBxH = 2.50 x 1.50 x 2.20 m - Weight machine 850 kg PowerDrill LxBxH = 0,30 x 0,30 x 6,00 m - Weight length stop 100 kg 1 Dübelleim- and press-in station consisting of: - Swing conveyor for dowels with feed -Dübeleinpressstation -High pressure glue pump made of stainless steel with glue container - Full jet valve for precise glue application Exhaust nozzle Price for 1 dowel diameter The basic machine will be about 300 mm longer (Technical data according to manufacturer - without guarantee!)

Condition: new, Bore diameter variabel mm Number of heads horizontal 3 St. Number of heads vertical 4 St. weight 1500 kg Dimensions (L/W/H) 4800x1600x2400 mm Width mit Auflage 2300 mm Götzinger Power Drill Type BF 297 With the Götzinger PowerDrill you can, depending on the type and design: Griffoliven drill on the loose frame part or for finished wings, with multi-spindle drilling head, quick-change, also for milling of the lock case for WK 2 or intermediate gear Ecklager drill on loose frame part, with Mehrspindelbohrkopf, Iodpfxsd Ih Hqo Afisih quick-change, corner-oriented over stop or custom made (tilt window) Drill vertically from above for fitting, pre-drill for clip on loose frame part Milling vertically from above for pushers, profile cylinders, 3-D hinges Horizontal drilling with 2 drilling units, different drilling diameters, Dowel drill front and long side, plywood / fighter, sprouts, Corner connection, front door etc. Milling horizontally for lock case / fitting etc. machine description Base frame in stable welded construction, linear guide for the X-axis Table top 3,000 x 200 mm 6 clamping cylinder pneumatic with auto. Ausweichhub 2 side stops for machining on the front side, manually swiveling in and out 2 longitudinal stops can be manually swiveled in and out Travel: X-axis - 3,000 mm working length Y-axis - 120 mm Z-axis - 105 mm Aggregate: 1 drilling unit (unit 1) vertically from above, drill motor 1,1 KW Speed ??1,500 - 12,000 rpm, 1 spindle, collet holder ER 20 1 Bohraggreagt (unit 2) vertically from above, drill motor 1,1 KW Speed ??3,000 rpm, with drill head quick change device 1 boring head BKF 3, olives, quick-change 1 boring head BKF 3/2 corner bearing, quick-change 1 milling unit (Agg.3) vertically from above, milling motor 2 KW, 1,500 - 16,000 rpm, collet holder ER 25 2 horizontal drilling units (Agg.4 and 5) 1.0 KW, 1.500 - 12.000 U / min, Collet holder ER 20 1 milling unit horizontal (Agg.3) 2.0 KW, 1.500 - 16.000U / min, Collet holder ER 20 Electro-pneumatic control with 3-axis control X, Y, Z NC positioning controller make B + R input via TFT display 10 " Machine complete with 1 set of drilling tools dm 6, 8, 10 and 12, 2 roughing carbide cutters HM dm 16, CE compliant, ready for connection Suction connection: 1 x dm 120 Power connection: 1 x 400 V, 16 amps Air connection: 1 x LW 9 mm OPTION: Longitudinal stops right / left with NC axis high / low programmatically, thus dimension input by folding / light measure possible, Dimension: LxWxH = 4.80 x 1.60 x 2.40 m - weight machine 1,500 kg (technical data according to manufacturer - without guarantee!)
