Llinás Y Cia, Sa

Condition: new, Year of construction: 2025, WOOD SHAVINGS MACHINE KÄLIN Hobeltechnik, mod. MPC-P • Quantity of fresh shavings by hour: 3.800 Kg/hour • Measures logs box: 2.800mm x 1100mm x 1.300mm • Max. log input length: 2.650mm • 2 removables symmetrical cutterheads. Lenght 1.140mm. Each one in 3 pieces of: - Diameter: 200mm - Length: 380mm Nelhccevk Saxeqtokw - Number of knifes: 8 - Sharpening full cutterheads, without removing knifes!! • 2 extra removables symmetrical cutterheads, for replacement during sharpening. Super fast cutterheads change patented system!! • Power of the cutting heads: 90 kW/120 HP • Feeding speed controlled by ELECTRONICAL INVERTER: 6 to 36 m/min • Automatic control of the forward-charge ratio of the machine • Power of the feed motor: 15 kW/20 HP • Control System of the material level inside the logs box, to avoid working without logs • Cabinet and control panel. Touch screem to control the machine • Motorized conveyor belt for the wood shavings. 800mm x 5.000mm • Weight: 11.000 Kg • CE

Condition: used, Functionality: unexamined, type of input current: three-phase, HEAVY BANDSAW GRIGGIO model SNAC RS4” WITH MOTORIZED FEEDER • Very heavy structure • Solid steering wheels with a diameter of 940 mm, with a rim width of 100 mm • Cutting capacity at height: up to 600 mm • Pneumatic system for tensioning the belt • Guide for the saw • Fully enclosed band • Table measuring 880 mm x 1.100 mm, with inclination • 22 kW / 30 HP electric motor • Feeder group: - Power 1.5 kW / 2 HP - Adjustable drag speed by motor-variator - Input / output by pneumatic piston Nelhcevk Rv Escqtokw - Large traction roller, machined for maximum drag. Diameter 200 mm x height 240 mm - Support-guide with vertical idle rollers. Adjustable by a small steering wheel. It has a metric - Safety system to prevent boards of a width greater than desired from passing through

Condition: good (used), Year of construction: 1999, Functionality: fully functional, IMA BIMA 410 V CNC WORKING CENTRE FOR ROUTING + BORING + EDGE BANDING • Industrial machine with heavy-duty structure • Working area: X:4000 mm Y:1200 mm Z: 100 mm • Travel speed: X:100 m/min Y:80 m/min Z: 25 m/min • 2 Working areas • 8 movable work tables to support the panels. SCHMALZ system • 23 SCHMALZ suction cups with vacuum system for the locking of the working piece • 4 loading device through pneumatic bars assembled on the work tables that lift the pieces • 1 SIEMENS vacuum pump ROUTING UNIT: • 10 HP. Refrigerated router head • Automatic change of the tool • Tool holders: HSK F-63 • C AXIS that allows to turn and 360° angle drive heads with rotation regulation in automatic by numerical control • 0 to 20.000 rpm • Tool magazine 12 positions MULTI-BORING UNIT: • 7 independent spindles for vertical boring in X direction • 5 independent spindles for vertical boring in Y direction • High revolution speed: 9.000 rpm Njlhccqot N Iw Tstskw EDGE BANDING UNIT: • Automatic device to apply the edge into straight profiles of shaped panels • Applicable banding material in coils: thin edge and PVC up to 3 mm • Independent unit to edge band shaped panels. It's installed on the main frame of the machine - hot-melt glue pot and premelter - spreading roller to regulate the quantity of apllied glue - edge pression roller • Lamp zone to pre-heat the side of the panel • Multiple magazine for edge coils with 2 positions, to automatically change the edge type • Top and bottom edge trimming head-unit • Top and bottom edge scraping head-unit CONTROL OF THE MACHINE: • IMATRONIC • Software IMAWOP • Command board installed on a separated electrical cabinet to control the machine PROTECTION ENCLOSURE OF THE WORKING UNITS PROTECTION FENCES SECURITY CARPETS SECURITY NORME CE MARK

Condition: as good as new (ex-display), Year of construction: 2021, operating hours: 50 h, Functionality: fully functional, machine/vehicle number: 000247, GLUE MACHINE FOR SINGLE-COMPONENT POLYURETHANE ADHESIVE. SPECIAL FOR GLUING LAMELLAS OF LAMINATED BEAMS • Maximum gluing width: 300 mm • Gluing head divided into 3 combs, each 100 mm and controlled by solenoid valve • Glue cord pitch: 10 mm • Tray with non-stick liquid that automatically closes the combs when the machine does not dose • Glue dosage: 100 to 200 gr/m2, as determined • Gear metering pump • Glue viscosity range: 10.000 to 30.000 mPas • Drag speed: 7 to 15 m/min • Support for 200 l barrel • PLC control, with touch screen. KINCO brand • Machine from the GLUESTREAM company • CE rules • Machine manufactured in 2021 and assembled in May 2022. Like new, it has worked less than 50 hours Nolhccqst Nfarstokw WE ALSO HAVE THE HYDRAULIC PRESS TO MAKE GLULAM BEAMS, ALMOST NEW MACHINE

Condition: excellent (used), Year of construction: 2005, Functionality: fully functional, AUTOMATIC HIGH PRODUCTION FINGER-JOINT LINE, WITH DOUBLE HEAD AND 6,000 mm PRESS. Brand YONGQIANG, model FJL150/8 Transfer with smooth conveyor belts, for the introduction of the pieces in the first finger-joint machine. 1st finger-jointing machine MHB3515B-A, complete with hydraulically driven sliding carriage and vertical and front pressers, belt for parts introduction, scoring unit, disc-crusher unit and shaper unit. 2nd finger-jointing machine MHB3515B-B, complete with sliding carriage with hydraulic movement and vertical and frontal clamps, belt for parts introduction, scoring unit, disc-shredder unit, shaper unit and gluing unit. Transfer with motorized rollers and piece-to-piece separation system RC 2x800, consisting of pneumatic transversal piston and motorized belt in vertical position. Transfer SC300, with drive system by means of two lateral chains, one of them adjustable in width and central presser along the whole length of the transfer, with vertical idle wheels. The function of this transfer is the guided instruction of the pieces one by one in the press. Neljt Ivpnehccqtokw Hydraulic finger press MHB15608-C, composed of grooved and motorized roller for the introduction of the pieces, cutting group, pre-pressing system and system of pressing and ejection of the pieces and support arms for the unloading of the strips. Used machine, year of manufacture 2005. Very good condition In the link it is possible to see a video of a line in operation exactly like the one offered.
