Sanding drum (rubber air drum) Original product from KED, (Kurt Ehemann)
-Type: G 20 x 50
-consisting of:
-Base body, rubber hose, air valve, 2 clamping caps for rubber hose
-Dimensions:
-Diameter: 200 mm
-Grinding length: 450 mm
-Length of the body: 500 mm
-Location hole: 40 mm
-Number: 1x available
-Price: per piece
Available on request in other sizes:
e.g. diameter 40mm, 60mm, 75mm, 100mm, 125mm, 150mm, 175mm, 200mm, 250mm, 300mm
e.g. grinding length 100mm, 150mm, 200mm, 250...
7
Code: 0160
Brand: SCM MINIMAX
Bzmxpqptvz
Model: LS 2500 - CE Standard
Belt sanding machine with double goose neck for sanding wood, aluminium, steel, various materials - CE Standard
Technical data:
Worktable length mm 2500
Worktable width mm 1100
Table vertical stroke mm 580
Sanding belt width mm 150
1-speed belt motor with reversing Hp 4
Automatic table lifting - Motor Hp 0,5
Pulleys diameter mm 250
Overall dimensions: mm 3650 x 1700 x 1500 h
Weight kg 460
4
Joinery long belt sanding machine make BÜTFERING type C 55
machine. # 6397
Lmgkjhxb
Technical data:
Sanding table size 2500 x 850 mm
roller center distance 2900 mm
grinding belt size 6630 x 150 mm
Belt speed:
Dry grinding (with main switch on "2") 20 m/sec.
Wet grinding and polishing (main switch on "1") 10 m/sec.
Size of the pressure plate 150 x 110 mm
1 roller has a lateral grinding surface dia. 225 mm
height support table to lower belt max. 500 mm
drive motor 4 PS
outer dimensions approx. 350...
1
CASADEI Libra 35 - Wide belt sanding machines in double belt design
Technical data
sanding width 1100 mm
Min. / max. working height 4 /170 mm
Sanding belt width 1115 mm
Sanding belt length 1900 mm
feed speed 4,5 / 9 m/min
Feed motor 0,33/0,55 kW
Motor power table adjustment 0,25 kW
Power drive motor 11 kW
Electrical voltage 400 V
Phase(s) 3 Ph
Mains frequency 50 Hz
Length 1650 mm
Width/depth 1820 mm
Height 1960 mm
Illustration with optional equipment
Wide belt sander as double belt version up t...
6
Technische Daten: - max. Arbeitsbreite 630 mm
- min. / max. Durchlasshöhe 3 / 160 mm
- min. Werkstücklänge 500 mm
- Schleifbandabmessungen 650 x 2100 mm
- Vorschubgeschwindigkeit 5 - 27m/min. 1. Schleifaggregat:
- gerillte Stahlwalze Durchmesser 200 mm
- Motor 11 kW / 400 V
- Schleifbandgeschwindigkeit 19 m/s 2. Schleifaggregat
- Kombiaggregat Walze 70 sh / Schuh
- Durchmesser 200 mm
- Motor 7,5 kW / 400 V
- gummierte und gerillte Kontaktwalze
- Schleifbandgeschwindigkeit 16 m/s 3. Entst...
1
diameter 300 mm
width (einspannen) 265 mm
Effective width 250 mm
Korn 180
Bn0qncmxvt
internal diameter 35 mm
48 Bürsten
11
Type Cindy 400
Width 425 mm
Height 200 mm
Electric starting system
Composition 1 belt-1 shoe
Bzlf8krpds
Year 2008
Thickness adjustment Automatic
Digital display Yes
Table extension Yes
Pneumatic oscillation
4kw motor
Voltage 380V
Encombrement 135cm/100cm/H235cm
Weight +- 600 kg
3
Frame grinding machine Löwer RSM 280
Year of manufacture 80s
engine 5,5 kw
grinding width 160 mm
Ehft87n
feed speed 6/11/16 m/min
belt 1600 x 200 mm
height indication
space requirement 1400 x 1000 x 1600 mm
approx. 650 KG
5
Used machine
Year of manufacture 1988
technical data:
length of the working tables: 1440 mm
Total width of the two work tables: 710 mm
inclination adjustment of the working tables: 0 30 degrees
Working pressure: 6 bar
Length of sanding belt: 2170 mm
Dyiyci
Width of the sanding belt: 150 mm
Speed of the sanding belt: 10 20 m/sec
Vertical adjustment of the oscillation unit: 125 mm
weight: 450 kg
Air consumption: 25 NL/min
Electricity: 380 V / 2,9 kW
Availability: short term
Location: Röllbach
1
Grinding unit via a lever up to 45 ° swivelling
The machine frame made of welded steel guarantees high torsion stiffness and vibration-free operation.
Oscillating abrasive belt with a separate geared motor for better grinding results
Oscillation can be activated optionally
Grinding sole with graphite coating for a longer life of the sanding belt
2rfzji
Height-adjustable grinding table to take advantage of the total width of the sanding belt
Height-adjustable auxiliary table with fume control sys...
1
Double-sided sander for boxes
2 side tables
2 sanding units
Fq7jpsj
Oscillation
Each motor on a separate switch
Sanding belt height approx. 200mm
2
-new-
Zum sanding from nahezu allen work piece-
formen about Bürstwerkzeuge or Lufttrommel
(gerade, runde, gebogene Profile etc.)
- Massivholzschliff
- intermediate lacquer sanding
- Bürsten
- polishing
- different Schleifmittel einsetzbar durch
30 mm tool receiver
- Optional with variabler rev adjustment
Technische Daten:
motor performance: 2,2 kW
rpm: 1000/1500 or 1500/3000 rpm
shaft diameter: 30 mm
Max. abrasive product: 350 mm
Schleifkörperlänge: 275 mm
weight: ca. 180 kg
Art.-No. 1090-90...
6
Technische Daten: - Arbeitsbreite Bürstaggregat 300 mm
- doppelseitig
- Motorleistung 1,5 kW
- Drehzahl stufenlos regelbar
Bhhijty0wo
- Spannung 400 V / 50 Hz
- Abmessung Schleiflamelle 300 x 60 mm
- Abmessungen L=1320,B=660, H= 850 mm
- Gewicht 170 kg OPTION: - Schleiflamelle 300 x 60 mm P180 EUR 1,90 / Stück
- Schleiflamelle 300 x 60 mm P240 EUR 1,90 / Stück
- Schleiflamelle 300 x 60 mm P320 EUR 1,90 / Stück
4
CONSTANT TABLE MACHINE / autom. head adjustment
-heavy duty wide belt calibrating fine grinding machine
-1. unit comb. contact roller and electronically controlled sanding shoe unit CPS
-2. unit combined contact roller and electronically controlled sanding shoe unit CPS
Gxz9xc
-automatic grain compensation for sanding belt
-3. unit cleaning - brush unit
-stable table for a large surface support
-working width 1350 mm
-feed speed infinitely variable 2,5 - 13 m/min.
LACKSCHLIFFPAKET:-stepless belt...
6
Exhibition machine
Year of manufacture: 2021
Equipment and technical data:
BASE MACHINE:
- Usable WORKING WIDTH mm 1350
- GRINDING BELT LENGTH mm 1370 X 2150
- MAX. WORKING THICKNESS mm 160
- Steel CALIBRATING ROLLER mm 180
- RUBBERED GRINDING ROLLER mm 180
- GRINDING SHOE WIDTH mm 50
- BELT MOTOR POWER PS 20
- BELT SPEED m/s 18/16
- FEED MOTOR POWER PS 0,75
- Adjustment gear Feed carpet with infinitely variable speed m/min 4/20
- HEIGHT ADJUSTMENT MOTOR PS 0,33
- Mechanical BANDOSCILLATION ECO...
9
Master - "out of the Box
The Master gets to the heart of grinding. It contains the essence of our 75 years of experience in the field of grinding technology. This means that it combines ex works, i.e. "out of the box", all the properties that are essential for the fast, reliable production of perfect surfaces. No more, no less. The core model Kündig Master is equipped with a calibrating roller as well as a sanding pad unit and has the proven design that guarantees decades of high sanding precisi...
6
Edge grinder Stefani MVT 200
2 sanding units
Aggregates with oscillation
Aggregates with tracer
1 unit for polishing
Each unit has an individual engine
Material transport system caterpillar
CE
Customized machine
Bzjndzkvm3
2
used, top condition,
cleaned, function checked
test run,
K7yngglt
manufactured by Arminius
for three-side-sanding
number of aggregates 3
1 x top belt 200 mm
1 x right hand - air drum
1 x left hand - air drum
combined aggregate
belt oscillation lateral drums ca. 80 mm
feeder belt 60 mm
located in 97447 Gerolzhofen
sale in current condition
6
Technische Daten: - Arbeitsbreite Bürstaggregat 300 mm
- Arbeitsbreite Schleifaggragat 220 mm
- doppelseitig
- Motorleistung 1,5 kW
- Drehzahl stufenlos regelbar
Bhhij7kakp
- Spannung 400 V / 50 Hz
- Abmessung Schleiflamelle 300 x 60 mm
- Abmessungen L=1250,B=880, H= 850 mm
- Gewicht 180 kg
OPTION: - Schleiflamelle 300 x 60 mm P180 EUR 1,90 / Stück
- Schleiflamelle 300 x 60 mm P240 EUR 1,90 / Stück
- Schleiflamelle 300 x 60 mm P320 EUR 1,90 / Stück
- Schleifband 1350 x 220 mm P180 EUR 7,00 / St...
4
heavy wide belt calibrating fine grinding machine.
1. contact roller - calibration with auto. Adjustment via control
2. combined contact roller-shoe unit with auto. Adjustment via control
working width 1100 mm
further special accessories
auto. Workpiece dimensions
Bzigadaiju
total power approx. 27 kW
year of construction 2004
machine cleaned and functional
ex location joinery
1
wheel diameter 300 mm
Jcanfmzn3
turning speeds 1400 U/min
total power requirement 2,2 kW
voltage 380 V
weight of the machine ca. 100 kg
dimensions of the machine ca. 1,25 x 0,30 x 0,40 m
- Serial-No.: 87461
1
Quick belt tension via lever
Upper belt support with graphite coating
250 mm large balanced belt rollers ensure optimum drive.
With electrical height adjustment
With suction and noise protection devices
With noise protection certificate
With two speeds
Adapts to surfaces due to swivel-mounted grinding shoe
Angled surfaces
Clockwise and anti-clockwise rotation as standard
The quick belt tensioning system allows quick and easy changing of the abrasive belts.
delivery is carried out partly assemble...
5
Demonstration machine
Year of manufacture: 2021
Equipment and technical data:
1-belt machine with combi unit roller/shoe for solid wood, veneer and intermediate lacquer sanding.
- Usable WORKING WIDTH mm 1100
- SANDING BELT LENGTH mm 1120 X 2150
- MAX. WORKING THICKNESS mm 160
- RUBBER CALIBRATION ROLLER mm 150
- GRINDING SHOE WIDTH mm 50
- BELT MOTOR POWER PS 15
- BELT SPEED m/s 18/16
- FEED MOTOR POWER PS 0,75
- Adjustment gear Feed carpet with infinitely variable speed m/min 4/20
- HEIGHT A...
2
cleaned, function checked, test run
second hand
Make Luger
Type Luco 250
Roller 200 mm
In need of repair
Bearing and sanding roller
Storage location 97447 Gerolzhofen
K7mzik8m
Delivery in the current condition as seen
- free on truck
6
Technische Daten: - Arbeitshöhe Bürstaggregat 150 mm - Durchmesser Bürstaggragat 280 mm - doppelseitig - Bürstaggregat mit je 20 Stück Schleif/Bürsten Streifen bestückt - Motorleistung 3,0 kW - Drehzahl stufenlos regelbar 0 - 1400 UpM - Spannung 400 V / 50 Hz - Abmessung Schleiflamelle 150 x 60 mm - Abmessungen L=1700,B=660, H= 850 mm - Gewicht 180 kg OPTION: - Schleiflamelle 150 x 60 mm P180 EUR 1,00 / Stück - Schleiflamelle 150 x 60 mm P240 EUR 1,00 / Stück - Schleiflamelle 150 x 60 mm P320 EU...
13
Dear customers, here we offer you a used disc or disk grinding machine of the brand BMT for sale. Here are a few technical data:
grinding wheel: Ø900 mm
table dimensions: 450 x 1.200 mm
table extension: 300 mm
grinding wheel inclination: +/- 30
motor power: 4.0 kW
Speed: 600 min-1
Right and left rotation with optical display
voltage: 3 x 400 V, 50 Hz
07e38utr
with table extension
suction nozzle: Ø150 mm
Weight: 460 kg
Price plus VAT, which will be shown separately on the invoice.
If you have an...
10
grinding diameter 300 mm
grinding length 550 mm
max. module 26
Bwhhjuwsgw
min. module 1
centre distance 700 mm
turning speeds 1750/2160/2860 U/min
clamping slot pitch angle max. 0 - 45 °
grinding wheel diameter 150 / 200 / 250 mm
grinding spindle head - swivable 15 °
total power requirement 13 kW
weight of the machine ca. 4,1 t
dimensions of the machine ca. 2,9 x 2,0 x 2,3 m
1
Quick belt tension via lever
Upper belt support with graphite coating
250 mm large balanced belt rollers ensure optimum drive.
With electrical height adjustment
With suction and noise protection devices
With noise protection certificate
With two speeds
Adapts to surfaces due to swivel-mounted grinding shoe
Angled surfaces
Clockwise and anti-clockwise rotation as standard
The quick belt tensioning system allows quick and easy changing of the abrasive belts.
delivery is carried out partly assemble...
- Producer Venjakob
- Type VEN CLEAN
- Year of construction 2001
- Working width 1300 mm
- Max. part height ca. 120 mm
Cwk0scxcq
- Voltage / HZ 400 / 50
1
tool carrier for abrasive product
8 piece base elements
used
manufactured by Arminius
radius ca. 20 mm
located in 97447 Gerolzhofen
sale in current condition as seen
Ok7kl
- free on truck -
6
Technische Daten: - Arbeitsbreite Bürstaggregat 300 mm - Arbeitsbreite Schleifaggragat 220 mm - doppelseitig - Motorleistung 1,5 kW - Drehzahl stufenlos regelbar - Spannung 400 V / 50 Hz - Abmessung Schleiflamelle 300 x 60 mm - Abmessungen L=1250,B=880, H= 850 mm - Gewicht 180 kg OPTION: - Schleiflamelle 300 x 60 mm P180 EUR 1,90 / Stück - Schleiflamelle 300 x 60 mm P240 EUR 1,90 / Stück - Schleiflamelle 300 x 60 mm P320 EUR 1,90 / Stück - Schleifband 1350 x 220 mm P180 EUR 7,00 / Stück
Bhhikg2f...
11
Dear customers, here we offer you a used disc or disk grinding machine for sale. It is a Swiss precision machines.
They are designed for the processing of wood, plastic,
Jxfu8q
metal, etc. and are used by model makers, designers, schools
(handicraft lessons), engineering schools as well as by metal- and
and plastic processing companies for a variety of tasks.
used. Here are a few technical data:
Grinding wheel: Ø600 mm
table dimensions: 320 x 830 mm
table extension: 170 mm
grinding wheel inclina...
10
Working width: 1100 mm
Byn0wmlvx9
Through height: 3 - 160 mm
2 AGGREGATES
1 aggregate shaft
2 combi aggregate shaft and carcass
Brush on exit
Engine power 12 kW
Length 1900 mm
Width 1500 mm
Height. 1900 mm
Weight 2500 kg
1
Robust design also allows the machining of longer workpieces
Sanding unit swivels, therefore also usable as edge sanding machine
225 mm large balanced belt rollers ensure low-vibration drive.
Easy adjustment of the grinding belt
High belt speed of 17 m/s
Right-left rotation
Upper grinding sole with graphite coating
grinding shoe 4-fold spring mounted
With movable grinding shoe for bevelled surfaces
Smooth-running grinding table even with high loads from heavy workpieces
Optimal price-performance...
3
zum Aufhängen von Schleifbändern
- Wagenbreite: 1500 mm
- Wagenhöhe: 1900 mm
- Wagentiefe: 1000 mm
- Nutztiefe Rohr: 1400 mm
- Räder: 4 St. Polyamidlenkrollen, Durchmesser 150 mm
( 2 St. davon mit Festesteller)
- Rohrdurchmesser ca. 152 mm
- Farbton: Lichtgrau RAL 7035
Bzirl9l7tz
Baujahr: 2020
Lieferzeit ca. 3 Wochen
1
abrasive product ca. 130 piece
Buv0jqr8bx
used
manufactured by Arminius
radius ca. 11 mm
grit K 120
located in 97447 Gerolzhofen
sale in current condition as seen
- free on truck -
6
Technische Daten: - Arbeitshöhe Bürstaggregat 150 mm
- Durchmesser Bürstaggragat 280 mm
- Bürstaggregat mit 20 Stück Schleif/Bürsten Streifen bestückt
- Motorleistung 1,5 kW
- Drehzahl stufenlos regelbar 0 - 1400 UpM
- Spannung 400 V / 50 Hz
- Abmessung Schleiflamelle 150 x 60 mm
- Abmessungen L=800,B=860, H= 850 mm
- Gewicht 140 kg
OPTION: - Schleiflamelle 150 x 60 mm P180 EUR 1,00 / Stück
Nuzsr
- Schleiflamelle 150 x 60 mm P240 EUR 1,00 / Stück
- Schleiflamelle 150 x 60 mm P320 EUR 1,00 / Stü...
3
Long belt sander, Mod. Ligmet PBK 2501
Daoi38l
year of manufacture 1999
weight 490 kg
very good condition
incl. sanding belts
few operating hours
5
Drum motor belt sander belt sander
-Spare part for: a grinding machine
-Drum: Ø 150 mm
-Drum length: 250 mm
-Speed: 2830 rpm
-Power: 1.80 kW
Clyicukw
-Shaft mount: Ø 22 mm
-Total length: 385 mm
-Also other sizes in stock: available
-Weight: 16 kg
1
Grinding unit via a lever up to 45 ° swivelling
The machine frame made of welded steel guarantees high torsion stiffness and vibration-free operation.
Oscillating abrasive belt with a separate geared motor for better grinding results
Oscillation can be activated optionally
Grinding sole with graphite coating for a longer life of the sanding belt
Height-adjustable grinding table to take advantage of the total width of the sanding belt
Height-adjustable auxiliary table with fume control system for...
5
Motor output:4 kW
Nkq9h
Table dimensions:2000x1000 mm
Weight:560 kg
:200 mm
:3200 mm
:200 mm
2
used
manufactured by Johannsen
type T 88 K pneuma
Masch.-No. 11877
motor 5,2 / 7,5 kW
sanding length ca. 2600 mm
sanding width ca. 1200 mm
belt length ca. 7800 mm
table size ca. 2600 x 1400 mm
exhaust fan 180 mm
right angle bend right hand ca. 1000 mm
upper belt cover
upper sanding rest
table illumination
pneumatic sanding pad contact pressure
2 belt speeds
right hand-left hand rotation
band blow-out
sanding pad 650 / 300 mm
exhaust connection D 180 mm
required space ca. l x w x h mm
4200 x 1700...
6
Technische Daten: - Arbeitshöhe Bürstaggregat 150 mm - Bürstaggregat mit Schleif/Bürsten Streifen bestückt - Motorleistung 1,5 kW - Drehzahl stufenlos regelbar 0 - 1400 UpM - Spannung 400 V / 50 Hz - Abmessung Schleiflamelle 150 x 60 mm - Abmessungen L=1700,B=860, H= 850 mm - Gewicht 190 kg OPTION: - Schleiflamelle 150 x 60 mm P180 EUR 1,00 / Stück - Schleiflamelle 150 x 60 mm P240 EUR 1,00 / Stück - Schleiflamelle 150 x 60 mm P320 EUR 1,00 / Stück
M8gf0t
4
- Producer Giardina
- Working width 1300 mm
- Max. part height ca. 120 mm
- With rotation air nozzles, clock-controlled 8 Stk.
- Zur Montage auf einen Transport oder Schleifmaschine
- With integrated switch control pneumatisch/pneuamtic
- Length 280 mm
- Width 1.470 mm
- Height 400 mm
Vuu0ji
- Connecting piece 100 mm
- Voltage / HZ 400 / 50
- Spannungsschwankungen max. +/- 5 %
3
Bürkle long belt sanding machines BSN
2500 x 800
Bvkcj933
1
Heavy machine base guarantees high torsional rigidity and vibration-free operation
Better sanding results due to sanding belt oscillation via separate gear motor
Oscillation optionally switchable
Veneer edge sanding device with fine adjustment as standard
Grooved infeed ruler for sanding veneer overhangs
Quick changeover from veneer to solid wood sanding
Height-adjustable sanding table for utilization of the entire sanding belt width
Height adjustment of the sanding table and sanding unit swivel...
