C-METALS nv

Condition: good (used), Year of construction: 1988, Hydraulic guillotine shear TS 3012 Capacity St45 : 12mm Capacity stainless : 8mm Cutting length : 3000mm electric powered back gauge Nslhcev S D N Uocqtekw YOM 1988 Strokes/min: 7 > 17 str/min Adjustable cuttingedge: 0,5 > 3°

Condition: excellent (used), FICEP PUNCHING MACHINE HYDRAULIC MODEL : 801 Year: 2006 Serial number: 29598 Stock number: 100410046 Pressure: 80 Ton Nelhccjv S D Absqtjkw Adjustable travel: 0-40 mm Free passage in the recess: 510 mm Ø maximum punch: 32 thickness 20 mm Engine power: 7,5 kW Weight: 1900 Kg Worktop height: 950 mm Overall dimensions: 759 x 1600 x 1730 mm

Condition: ready for operation (used), hydraulic guillotine shear Nslsv Skhdjhccqtekw

Condition: like new (used), IRONWORKER GEKA HYDRACROP 80 SD Nkslhccqjv Skg Tjtow

Condition: ready for operation (used), hydraulic press brake Nkjlhccsv Skgysqtjw

Condition: good (used), Year of construction: 1989, Functionality: fully functional, Hydraulic press brake AMADA STPC 160/30 Yom 1989 CNC Controller DNC 7000 Max Cap : 1600kN Working length : 3000mm tooling included Nslhccev Rcc Reqtokw

Condition: excellent (used), Year of construction: 2012, pressing force: 2,200 t, total width: 2,100 mm, total length: 6,415 mm, throat depth: 400 mm, overall weight: 20,000 kg, distance between stands: 3,150 mm, table width: 120 mm, bending length: 4,000 mm, type of input current: AC, distance between side stands: 3,150 mm, working length: 4,000 mm, input voltage: 400 V, Hydraulic press brake LVD PPEB-EFL 220/40 Year of construction 2012 Serial number 34547 Technical specifications Force 2200 kN Working length 4000 mm Distance between uprights 3150 mm Stroke 300 mm Distance table – ram 500 mm Gap 400 mm Table width 120 mm Turbo model PP5400 Approach speed 120 mm/s Working speed 21mm/s Return speed 200 mm/s weight 15700 kg motor 37 kW oil 350 l COMMAND CONTROL TOUCH-B 15” – 6 axis • Table PP8170 V-axe • EFL 130 PP8303 EASY FORM LASER • hydraulic clamping toptool PP3100 – PP3090 WILA • Back gauge X R PP8099 Nkjljv Hqn Hjhccqtsw • Stroke X-axe: 600mm • 4 on fingers on back gauge • CE : PP3520 – lasersafe • 2 front support PP1115 • Turbo version PP5400

Condition: excellent (used), Year of construction: 2003, Functionality: fully functional, throat depth: 750 mm, punching force: 55 t, GEKA PUMA 55 / 750E punching machine with options included 1. Mutli- stop table 2. 100mm punch / table equipment yom 2003 Nkslhjvt Akmeccqtew

Condition: excellent (used), Year of construction: 2006, total height: 3,700 mm, pressing force: 2,200 t, total width: 2,100 mm, total length: 6,415 mm, throat depth: 400 mm, overall weight: 20,000 kg, distance between stands: 3,150 mm, table width: 120 mm, table height: 970 mm, bending length: 4,000 mm, type of input current: AC, distance between side stands: 3,150 mm, working length: 4,000 mm, stroke distance: 450 mm, input voltage: 400 V, ram stroke: 405 mm, cylinder stroke: 405 mm, working range: 4,000 mm, Hydraulic press brake LVD PPEB-EFL 220/40 cadman cnc Year of construction 2006 Serial number 30266 Technical specifications Force 2200kN Working length 4000mm Distance between uprights 3150mm Stroke 450mm Distance table – ram 685mm Gap 450mm Table width 120mm Turbo model PP5400 Approach speed 120mm/s Working speed 21mm/s Return speed 200mm/s weight 19000 kg motor 37kW COMMAND CONTROL CADMAN CNC 9 • EFL EASY FORM – W axis • PP3295 Hardened table • Table PP8170 V-axe • top tool clamping PP3090 – Wila • hydraulic top tool clamping PP3100 • hydraulic bottom tool clamping PP3160 • Back gauge X X’ R Z1 Z2 • Stroke X-axe: 600mm • 2 fingers on back gauge • 2 front supports • 2 pneumatic sheetfollowers • Security; CE PP3580 – lasersafe PP5320 Nolovtz T Hshccqtokw

Condition: refurbished (used), Full retrofitted Hydraulic press brake LVD PPEB-6 80/20 S840W Year of retroift : 2024 Year of construction :1999 Serial number : 25886 Technical specifications Force 800kN Working length 2000mm Distance between uprights 1550mm Nkjlhjuvgk Ssccqtjw Stroke 200mm Distance table – ram 400mm Gap 400mm Approach speed 130mm/s Working speed 11mm/s Return speed 115mm/s weight 6000 kg motor 7.5kW NEW TOUCH SCREEN Controller 15" - 3D Graphic • Back gauge X R Z1 Z2 PP8005 • Security; CE PP3520 – lasersafe

Condition: good (used), Year of construction: 1991, Functionality: fully functional, sheet thickness steel (max.): 16 mm, cutting length (max.): 6,000 mm, HYDRAULIC SHEAR LVD MVSB 62/16 Serial number 18478 Yom 06/1991 TECHNICAL SPECIFICATIONS Max. sheet thickness St45 16 mm Cutting length 6200mm Distance between uprights 6400mm Gap 60mm Njlsumhm Ashccqtekw Range back gauge 1000mm Min. cutting angle 0.5 ° Max. cutting angle 2.5° Min. number of strokes/min. 6 Max. number of strokes/min 25 Min. blade clearance 0.05 mm Max. blade clearance 1.6mm Motor power 30kW Approx weight 35000 Kg LxWxH 7100x2400x3000mm Accessories included; ELGO P85 “GO-TO” for back gauge Electrical adjustment of back gauge 1000mm 1 x Front support 2mtr, one with 90° square arm front support L2000mm Foot pedal Ball bearings on table Inclinable back gauge with manual hydraulic pump

Condition: reconditioned (used), Year of construction: 1997, Functionality: fully functional, sheet thickness steel (max.): 16 mm, cutting length (max.): 4,000 mm, HYDRAULIC SHEAR LVD MVSB 40/16 Nkslhsuipu Esccqtew Serial number 24159 Yom 1997 TECHNICAL SPECIFICATIONS Max. sheet thickness St45 16 mm Cutting length 4050 mm Distance between uprights 4250 mm Range back gauge 1000mm Min. cutting angle 0.5 ° Max. cutting angle 2.0 ° Min. number of strokes/min. 7 Max. number of strokes/min 26 Min. blade clearance 0.5 mm Max. blade clearance 1.6 mm Motor power 22 kW Approx weight 20500 Kg LxWxH 4800x2170x2750mm Accessories included; Electrical adjustment of back gauge 1000mm with Go-to controller blade clearance and cutting angle adjustable. 1 x Front support 1500mm, one with 90° square arm front support 1 x Front support of 1500mm Foot pedal

Condition: new, Year of construction: 2022, AVAILABLE FROM STOCK : Geka plasma cutting machine GCS P-4020 table size 4000 x 2000mm incl. plasma source Hypertherm 125A incl. PRONEST HYPETHERM NESTING SOFTWARE - GEKA CNC cutting table - Hypertherm Powermax 125A - cutting capacity: steel 25mm, stainless steel 20mm, aluminium 12mm - CNC control with GproCUT 2D CAD cutting software - Nesting included. - Country of manufacture Spain incl. CE conformity. - Heavy duty base for increased support and rigidity. - CNC Tex computer control with touch screen. - Linear guides on all axes for high repeatability. - Safety cutting head to prevent damage to the cutting head. - Rack and pinion gearbox with 70kg/cm servo motors. - Fully enclosed cable drag to protect cables from damage. - Movement speed 40 meters/min. - Resolution 0.01mm. - Optional automatic lubrication on all axes. - Optional, separate suction chambers in the machine bed. - Z-axis with integrated THC (Torch Height Control) to ensure automatic cutting distance between torch and material during the entire cutting process. - Torch anti-collision system (machine stops before any collision). - Laser pointer to check X and Y axes for zero reference. Njljgypclshccqtskw - The effective cutting area for P-4020 is 4000 x 2000mm. - Portal height Z = 100 mm. - Table with compartements for aspiration

Year of construction: 2018, Condition: new, TECHNICAL CHARACTERISTICS • Punching capacity: 500KN / 50Tn • Punching: Ø31x12mm • Strokes per minute (15mm travel): 34 • Throat deep: 177mm • Stroke: 50mm • L angle at 90⁰: 80x80x8mm • Flat bars: 350x10mm • Round bars: Ø35mm • Square bars: 30mm Nkjlhcedx Rd Uscqtow • Triangular notching: 90x42x10mm • Bending station: 100x10mm • Motor: 3KW • Net weight: 950Kg

Year of construction: 2018, Condition: new, TECHNICAL CHARACTERISTICS • Punching capacity: 600KN / 60Tn • Punching: Ø40x11mm • Strokes per minute (15mm travel): 32 • Throat deep: 500mm • L angle at 90⁰: 120x120x10mm • Flat bars: 350x15mm • Round bars: Ø45mm • Square bars: 40mm • Triangular notching: 100x42x10mm • Bending station: 150x10mm • Motor: 5.5KW Nkslsdx Rd Sohccqtow • Net weight: 2012Kg

Year of construction: 2018, Condition: new, TECHNICAL FEATURES • Punching capacity: 550KN // 55Tn • Motor: 5KW • Throat depth: “S” 250mm // “SD” 500mm • Punching capacity: Ø40x10mm o Ø20x20mm • Strokes per minute (20mm travel): 37 Nkelhjdx Rdisccqtew • Flats cutting up to: 300x15mm o 200x20mm • Angle cutting at 90⁰: 120x120x10mm • Angle cutting at 45⁰: 70x70x7mm • Round & square bar cutting: Ø y ÿ: 40mm • Notching station: 90x42mm (espesor 12mm)

Year of construction: 2018, Condition: new, TECHNICAL FEATURES • Punching capacity: 1100KN / 110Tn • Motor: 9KW • Throat depth: 510mm (SD version) • Punching capacity: Ø40x30mm or Ø34x34mm • Strokes per minute (20mm travel): 28 • Flats cutting station up to: 600x15mm or 400x20mm • Angle cutting at 90⁰: 152x152x13mm • Angle cutting at 45⁰: 70x70x7mm • Round & square bar cutting: Ø y ¨ 50mm • Notching station: 90x52mm (thickness13mm) Nkjlhccedx Rdceqtjw
