Used Lathes Bed Plan for sale (11,935)

Condition: good (used), Platform trolley, transport trolley, heavy-duty trolley, table trolley, assembly trolley, industrial trailer, container dolly, double turntable steering, heavy-duty trailer -Heavy-duty transport wagon: Industrial trailer with 2-axle steering -Platform: 2500/1255/H490 mm -Load capacity: 11 t Rbsdpfxet Rbkcj Ahzst -Tires: Solid rubber -Quantity: 1x transport trolley available -Overall transport dimensions: 3350/1255/H490 mm -Weight: 780 kg

Condition: used, Platform trolleys, transport trolleys, heavy-duty trolleys, table trolleys, assembly trolleys, industrial trailers, container dolly, heavy-duty trailers -Handover: in current condition as seen -Note: Pay attention to the condition of the wheels -Platform: 11,000/3000/H1070 mm -Load capacity: 100 tons -Steering: double -Drawbar length: 1500 mm -Drawbar eye: Ø 50 mm -Wheels number: 32 pieces Rsdsrc Il Djpfx Ahzsbt -Wheel Size: 646/200-480 -Total dimensions: 12,300/3000/H1070 mm -Weight: 12200kg

Condition: good (used), Platform trolley, transport trolley, heavy-duty trolley, table trolley, assembly trolley, industrial trailer, container dolly, heavy-duty trailer -Platform: 11,000/3,000/H1,100 mm -Load capacity: 100 tons -Steering: possible on both sides -Drawbar length: 1500 mm -Drawbar eye: Ø 50 mm -Number of wheels: 32 pieces -Wheel size: 646/200-480 -Overall dimensions: 12,300/3,000/H1,100 mm -Weight: 12960 kg -Handover: in its current condition as inspected -Note: Check the condition of the wheels Rjdpfx Ajrd Aclohzebt

Condition: good (used), Colchester / Harrison / 600 Lathes TORNADO 300 CNC lathe TECHNICAL DATA Spindle power: 18 / 22 kW Spindle connection: A2-8 Spindle bore: 90.5 mm Chuck sizes (A type): 265 mm Drawtube diameter: 82 mm Front bearing (inner diameter): 130 mm Max. Spindle speed: 4000 rpm X-axis: 240 mm Travel over center of rotation: 213 mm Under turning center: 27 mm Working stroke Z-axis: 500 mm Feed speeds: Rapid traverse X-axis: 10 m/min Rapid traverse Z-axis: 20 m/min Min. feed step: 0.001 mm Tool carrier: Turret, number of tools: 12 Tool holder mounting: VDI 3425 / 40 Turning chisel, shank size: 25 x 25 mm Max. Drill rod diameter: 40 mm Tailstock quill diameter: 95 mm Quill inner cone: No. 5 MK Quill stroke: 125 mm Tailstock travel: 485 mm Max. Tailstock quill axial force: 7860 N Swing diameter: 530 mm Turning diameter over cross slide: 330 mm Max. Machining diameter: 300 mm Max. Turning length: 500 mm Rbsdpfx Ahsrnkhyszst Height of turning center above floor: 913 mm Bed width Z-direction: 750 mm Bed width X-direction: 393 mm Bed width tailstock guide: 255 mm Cross slide width: 256 mm Bed slide inclination: 600 mm Installation area: 3.26 m2 Weight: 3300 kg We assume no liability for the accuracy, completeness and up-to-dateness of the information provided

Condition: good (used), Year of construction: 2008, Colchester Harrison Alpha 1400U CNC lathe Footprint: 1.7 x 3.1 m Height: Approx. 1500 mm Weight: 3200 kg Equipment: Electrically interlocked chuck guard, full safety guard, coolant tank and pump 100 l, fully extendable chip tray, machine lighting Rjdpjrnkdysfx Ahzsbt Machining length: 1250 mm Turning diameter: 400 mm Center distance: 1250 mm Spindle bore: 54 mm Turret, number of tools: 8 Tool size: Standard: 20 x 20 mm Boring bar: 32 mm No responsibility is taken for the correctness, completeness and up-to-dateness of the information.

Condition: new, Year of construction: 2025, turning diameter over cross slide: 250 mm, turning length: 730 mm, turning diameter: 500 mm, spindle speed (max.): 1,800 rpm, CNC lathe machine CK 6150 with flat bed We offer a new CNC lathe machine model CK6150. We use this machine in our production and you can see it in operation before ordering. The CK 6150 lathe has a flat bed and hardening guides, which ensures a long period of operation of the equipment. The machine is equipped with a CNC system, the GSK CNC system is installed as standard. Optionally, the machine can be equipped with a Fanuc or Siemens CNC system. The machine can have a tool holder for 4-6 or 8 tools, depending on the customer's wishes. It is possible to install a hydraulic chuck on the machine, which will greatly simplify the process of installing parts on it and a hydraulic tailstock. The CK 6150 lathe can be equipped with additional supporting frame for more accurate manufacturing of long parts. Technical specifications: Model CK 6150 x 1000 Maximum workpiece diameter over bed 500 mm Maximum workpiece diameter over support 250 mm Maximum workpiece length 1000 mm Maximum turning length 730 mm Spindle bore diameter 82 mm Spindle speed 150-1800 rpm Engine power 7.5 kW Mechanical chuck (hydraulic optional) Chuck size 250 mm. 4-position tool holder (6 or 8 optional) Maximum tool size for tool holder 25x25 mm Machine weight 2700 kg Machine dimensions 2650×1700×1820 mm We can also supply lathes CK 6140, CK 6150 and CK 6160 with other dimensions of the working part: CK 6140 dimensions of the working part 550/750 mm Rbodpjxdmgvefx Ahzst CK 6150 dimensions of the working part 1000/1500/2000 mm CK 6160 dimensions of the working part 1000/1500/2000 mm CK 6152E dimensions of the working part 1000/1500/2000/3000 mm CK 6165E dimensions of the working part 1000/1500/2000/3000 mm CK 6165E dimensions of the working part 1000/1500/2000/3000 mm CK 6185E dimensions of the working part 1000/1500/2000/3000/4000 mm CK 61100E dimensions of the working part 1000/1500/2000/3000 mm CK 61125E dimensions of the working part 1000/1500/2000/3000 mm

Condition: excellent (used), functionality: fully functional, Year of construction: 2010, PLAN 10-4c heavy-duty trailer / transport trailer Payload: 25t - 25,000kg Rbsdsxmuz Hopfx Ahzet Unladen weight approx. 2,240kg Turntable steering with oscillating axles, year of manufacture 2010 Loading area dimensions: 500x200cm, loading height 76cm Very good condition, see photos Forklift available for loading Collection by appointment only in 75053 Gondelsheim Shipping by freight forwarder possible, please inquire with postcode

Condition: good (used), Year of construction: 1990, Offer 25210 Technical data: - Load capacity: 8,000 kg - Both axles steerable / all-wheel steering (knuckle steering) Rbodpfxswwi R He Ahzst - Tow bar usable at both front and rear sides - Solid rubber tyres: 425 / 150 - 305 - Platform length approx.: 2,500 mm - Platform width approx.: 1,250 mm - Platform height approx.: 500 mm - Total length without tow bar: 3,300 mm - Total length with tow bar approx.: 4,400 mm - Weight approx.: 700 kg

Condition: used, Platform transport trailer, heavy-duty trailer Industrial trailer with 2-axle turntable steering Manufacturer: PLAN, type 11 Chassis no.: 31361-1 = year of construction 03/2015 Chassis no.: 31361-2 = year of construction 03/2015 Payload 20000 kg Unladen weight approx. 3760 kg Gross vehicle weight 23760 kg Platform height 850 mm Platform length 5000 mm (between the tarpaulin frame) Platform width: 2500 mm Overall length: 6100 mm (without drawbar) Overall width 2500 mm Tires Ø 559 x 300 mm (solid rubber tires 559/305-406.4) - 4 wheels with 2-axle turntable steering - track-running - Reversible drawbar, drawbar can be bolted to the front or rear - Drawbar with drawbar eye size 40 mm diameter - Small turning radius - Very stable outer frame made of U-beam Height 280 mm, width 95 mm - Very stable steel floor made of 10 mm checker plate - Tarpaulin body with steel base frame, can be loaded from the side Max. transport height 2300 mm under tarpaulin Length for transportation 610 cm (with drawbar folded up) Width for transportation 250 cm Height for transport 330 cm (with tarpaulin body) Weight per trailer approx. 3760 kg Good condition Rbedpsiiumrofx Ahzjt 2 pieces available Price per trailer

Condition: used, TECHNICAL DETAILS - Plate diameter : 348 [mm] - Part dimensions (rings) : approx. 70 [mm] Rbjdpfx Aoug U Dmohzet - Part dimensions (full) : approx. 40 [mm] - Remaining work thickness : approx. 5 [mm] EQUIPMENT - Same as on photos

Condition: used, TECHNICAL DETAILS - Plate diameter : 348 [mm] - Part dimensions (rings) : approx. 70 [mm] - Part dimensions (full) : approx. 40 [mm] Rbsdpfeug U Dgex Ahzet - Remaining work thickness : approx. 5 [mm] EQUIPMENT - same as on photos

Condition: ready for operation (used), Year of construction: 2007, operating hours: 32,000 h, functionality: fully functional, spindle speed (max.): 8,000 rpm, travel distance Z-axis: 140 mm, counter spindle speed (max.): 8,000 rpm, number of axes: 5, Equipment: bar feeder, TECHNICAL DETAILS Number of axes: 5 Number of spindles: 2 Main spindle Max. bar diameter: 16 mm Z-axis travel: 140 mm Spindle speed: 8,000 rpm Spindle drive power: 2.2 kW Number of tool positions: 13 Sub-spindle Max. bar diameter: 12 mm Spindle speed: 8,000 rpm Number of tool positions: 4 MACHINE DETAILS Control: FANUC 18i-T Rsdpfsycp Nlox Ahzebt Operating hours: 32,000 h EQUIPMENT FMB Minimag bar loading magazine Note: Dismantling and loading can be carried out by the seller for €1,500.

Condition: ready for operation (used), Year of construction: 2000, operating hours: 47,000 h, functionality: fully functional, spindle speed (max.): 8,000 rpm, travel distance Z-axis: 140 mm, counter spindle speed (max.): 8,000 rpm, number of axes: 5, Equipment: bar feeder, TECHNICAL DETAILS Number of axes: 5 Number of spindles: 2 MAIN SPINDLE Max. bar diameter: 12 mm Z-axis travel: 140 mm Rbsdpfjycp Ihex Ahzjt Spindle speed: 8,000 rpm Spindle drive power: 2.2 kW Number of tool positions: 13 SUB SPINDLE Max. bar diameter: 10 mm Spindle speed: 8,000 rpm Number of tool positions: 4 MACHINE DETAILS Operating hours: 47,000 EQUIPMENT FMB Minimag bar feeder Note: Dismantling and loading can be handled by the seller for €1,500.

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, turning length: 385 mm, turning diameter: 350 mm, overall weight: 4,200 kg, controller model: Fanuc Series 01-TB, The machine's hydraulics have been renewed! TECHNICAL DETAILS Max. turning diameter: 350 mm Max. turning length: 385 mm Rbodpfxoyf Afls Ahzjt Turret tool changer: 12-position EWS MACHINE DETAILS Control system: Fanuc Series 01-TB Dimensions & Weight Dimensions (L x W x H): 2,700 x 1,800 x 1,700 mm Machine weight: 4,200 kg

Condition: ready for operation (used), functionality: fully functional, turning diameter: 1,700 mm, center height: 630 mm, center width: 4,000 mm, spindle speed (max.): 400 rpm, empty load weight: 4,000 kg, TECHNICAL DETAILS Rsdpoydv N Uofx Ahzjbt Centre height: 630 mm Swing diameter over bed: 1,300 mm Swing diameter over carriage: 1,000 mm Swing diameter over removable bed section: 1,700 mm Centre distance: 4,000 mm Bed width: 700 mm Spindle bore: 120 mm Spindle speed: 2.8 - 400 rpm MACHINE DETAILS Control: Conventional Dimensions & Weight Dimensions (L x W x H): 6,800 x 2,200 x 2,000 mm Unladen weight: 11,000 kg Transport packages: 2 EQUIPMENT Documentation Three-jaw chuck Four-jaw chuck Removable bed section Quick-change tool holder Fixed steady rest Travelling steady rest

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 102, turning height: 1,250 mm, workpiece weight (max.): 8,000 kg, turning diameter: 1,550 mm, faceplate diameter: 1,250 mm, spindle speed (max.): 3,000 rpm, TECHNICAL DETAILS Turning height: 1,250 mm Rodpfx Ahjybbi Iezsbt Workpiece weight: 8,000 kg Turning diameter: 1,550 mm Faceplate diameter: 1,250 mm Faceplate speed: 200 rpm Spindle speed: 3,000 rpm Tool changer: 15 positions MACHINE DETAILS Control: Siemens 840 D Type of supply current: Alternating current (AC) Year of last overhaul: 2000 EQUIPMENT C-axis Infinitely variable speed 3-jaw hydraulic-mechanical chuck Coolant system Belt filter unit Internal coolant supply

Condition: ready for operation (used), Year of construction: 1997, operating hours: 38,000 h, functionality: fully functional, machine/vehicle number: 325202, turning length: 305 mm, turning diameter: 210 mm, rotational speed (max.): 5,000 rpm, bar passage: 42 mm, controller model: Heidenhain Elektro Pilot 1190, TECHNICAL DETAILS Swing diameter over bed: 440 mm Swing diameter over cross slide: 210 mm Rsdpfx Ajyfgttjhzsbt Turning length: 305 mm Bar capacity: 42 mm Spindle speed: 5,000 rpm Turret: 12 stations Tool holder: VDI 20 MACHINE DETAILS Control: Heidenhain Elektro Pilot 1190 Dimensions & Weight Dimensions (L x W x H): 2,800 x 1,651 x 1,771 mm Machine weight: approx. 3,000 kg Power-on hours: approx. 38,000 h EQUIPMENT Coolant system Tailstock Documentation

Condition: ready for operation (used), Year of construction: 2005, operating hours: 20,634 h, functionality: fully functional, machine/vehicle number: 051116206, turning length: 1,000 mm, rotational speed (max.): 4,000 rpm, bar passage: 52 mm, controller model: Fagor 8040 TC, TECHNICAL DETAILS Swing diameter over bed: 450 mm Swing diameter over cross slide: 215 mm Rodpfxsycu Igs Ahzsbt Turning length: 1,000 mm Bar capacity: 52 mm Spindle speed: 4,000 rpm MACHINE DETAILS Control unit: Fagor 8040 TC Dimensions & Weight Machine dimensions (L x W x H): 3,000 x 1,995 x 2,001 mm Machine weight: approx. 2,400 kg Operating hours: 20,634 h EQUIPMENT 4-position tool holder Tailstock Documentation

Condition: ready for operation (used), Year of construction: 1998, operating hours: 17,000 h, functionality: fully functional, turning length: 305 mm, spindle speed (max.): 5,000 rpm, swing diameter over bed slide: 440 mm, bar passage: 42 mm, controller model: Heidenhain Elektro Pilot 3190, TECHNICAL DETAILS Swing diameter over bed: 440 mm Swing diameter over carriage: 210 mm Turning length: 305 mm Bar capacity: 42 mm Spindle speed: 5,000 rpm Turret: 12 stations Driven stations: 6 stations Tool holder: VDI 20 MACHINE DETAILS Control: Heidenhain Elektro Pilot 3190 Dimensions & Weight Machine dimensions (L x W x H): 2,800 x 1,651 x 1,771 mm Machine weight: approx. 3,000 kg Power-on hours: approx. 17,000 h EQUIPMENT Chip conveyor C-axis Driven tools Parts catcher Tailstock Documentation Rbedpfxoycu A Ro Ahzjt

Condition: ready for operation (used), Year of construction: 2002, operating hours: 19,300 h, functionality: fully functional, turning length: 750 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 185 mm, travel distance Z-axis: 750 mm, swing diameter over bed slide: 320 mm, TECHNICAL DETAILS Swing diameter over bed: 320 mm Swing diameter over cross slide: 150 mm Turning length: 750 mm Travel X-axis: 185 mm Travel Z-axis: 750 mm Redpfeycuvkox Ahzjbt Bar capacity: 52 mm Spindle speeds: 4,000 rpm Spindle nose: 55027/A6 DIN Spindle drive: 9 kW Rapid traverse X-axis: 10 m/min Rapid traverse Z-axis: 8 m/min Tailstock quill diameter: 70 mm Tailstock quill stroke: 120 mm Tailstock taper: MT 5 MACHINE DETAILS Control: Heidenhain Manuel Plus Dimensions & Weight Machine dimensions: 2,450 x 1,668 x 1,825 mm Machine weight: approx. 2.0 t Operating hours: approx. 19,300 h EQUIPMENT 3-jaw chuck Tailstock Multifix size B Documentation

Condition: ready for operation (used), operating hours: 28,339 h, functionality: fully functional, turning length: 450 mm, turning diameter: 300 mm, spindle speed (max.): 5,000 rpm, travel distance X-axis: 160 mm, controller model: Siemens 840D ShopTurn, TECHNICAL DETAILS Turning diameter: 300 mm Turning length: 450 mm X-axis travel: 160 mm Main spindle speed range: 5,000 rpm Counter spindle speed range: 5,000 rpm Bar capacity: 65 mm Tool holder: VDI 30 Driven tool stations: 12 Driven tool speed: 5,000 rpm Rapid traverse X-axis: 60 m/min Rapid traverse Z-axis: 45 m/min MACHINE DETAILS Control: Siemens 840D ShopTurn Dimensions & Weight Required space with chip conveyor: 6,895 x 2,284 x 1,885 mm Machine weight: approx. 4.3 t Operating hours Power-on hours: 59,643 h Spindle hours: 28,339 h Redpfjycupqox Ahzjbt EQUIPMENT Chip conveyor Sub spindle Hainbuch collet chuck 65 mm Hainbuch collet chuck 42 mm Parts catcher Conveyor belt C-axis Driven tools Documentation

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, spindle bore: 65 mm, spindle speed (max.): 5,000 rpm, bar passage: 60 mm, controller model: Siemens 840D Powerline, counter spindle speed (max.): 5,000 rpm, TECHNICAL DETAILS Spindle bore: 65 mm Bar capacity: 60 mm Main spindle max. speed: 5,000 rpm Rbjdsya Ecvspfx Ahzot Counter spindle speed: 5,000 rpm MACHINE DETAILS Control: Siemens 840D Powerline Machine weight: 3,500 kg EQUIPMENT C-axis IEMCA bar feeder Master 880/33 HF (bar length up to 3,200 mm) KSS coolant supply / cooling unit Hinged belt chip conveyor

Condition: good (used), Year of construction: 1997, functionality: fully functional, turning height: 2,250 mm, workpiece weight (max.): 20,000 kg, turning diameter over cross slide: 2,500 mm, turning diameter: 2,600 mm, Basic Information Designation: Mario Carnaghi TG 20/2500 Machine type: Vertical Turret Lathe (Vertical Turning Machine) Manufacturer: Mario Carnaghi Year of manufacture: 1997 Machine number: 1092/96 Installation dimensions / Required space Length: 4.5 m Width: 6.0 m Height: 6.0 m Footprint: 27 m² Working Range / Capacities Max. turning length: 1960 / 2250 mm Max. swing diameter over bed: 2500 mm Max. swing diameter over cross slide: 2500 mm Max. workpiece weight: 20,000 kg Work Spindle / Faceplate Faceplate diameter: 2000 mm Redpfeyf Um Isx Ahzobt (additional spindle specifications such as spindle bore, internal taper, torque etc. are not provided) Slide / Tool Data Tool system: Mario Carnaghi Tool shank section: 40 × 40 mm Number of cross slides: 1 Longitudinal travel: 1145 mm (face travel/number of face slides not specified) Feeds / Rapid Traverse Longitudinal slide feed min./max.: 0 – 10 mm/rev Cross slide feed min./max.: 0 – 10 mm/rev Rapid traverse longitudinal: approx. 5 m/min Rapid traverse cross: approx. 5 m/min Spindle Speeds (Gear Stages) Stage I: 17 – 38 rpm Stage II: 38 – 64 rpm Stage III: 64 – 140 rpm Stage IV: 140 – 200 rpm

Condition: like new (used), Year of construction: 2004, Retrofitted: 2026 Numerical control: HEIDENHAIN TNC-i530 Rbsdpfx Ahjyf Rryozjt Technical features Dimensions Table dimensions: 2000 x 900 mmNumber of T slots: 5T slots dimensions: 22 mm Traverses of axis X axis traverse: 2000 mmY axis traverse: 1000 mmZ axis traverse: 1000 mm Milling head Head type: Manual milling head (U22)Tool clamping system: HydraulicTaper nose: ISO 50 (DIN 69871) / Pull stud: DIN 69872Speed range: 3000 r.p.m.Spindle power: 22 kW Feedrates Working feedrate: 12000 mm/minRapid feedrate (X-Y-Z): 20000 mm/min Weight and dimensions Maximum weight on table: 3500 kgMachine weight approx.: 14000 kgMachine dimensions approx : 6637 x 5070 x 2803 mm Accesories External coolantElectronic handwheel: HR-410New foot clamping tool pedalGuarding and new perimetral safety fence installation Sales conditions Warranty: 6 months mechanical partsSale conditions and price: On request View all technical features

Condition: like new (used), Year of construction: 1992, Retrofitted: 2023 Numerical control: SELCA 4045D Rbjdpjyf Rtkjfx Ahzot Technical features Dimensions Table dimensions: 4500 x 1100 mmNumber of T slots: 8T slots dimensions: 22 mm Traverses of axis X axis traverse: 4000 mmY axis traverse: 1200 mmZ axis traverse: 1250 mm Milling head Head type: Universal manualTool clamping system: HydraulicTaper nose: ISO 50 (DIN 2080)  /  Pull stud: DIN 69872Speed range: 20 - 2000 rpmSpindle power: 22 kW Feedrates Feedrate: 2 - 5000 mm/minRapid feedrate (X / Y,Z): 15000   /   10000 mm/min Weight and dimensions Maximum weight on table: 8000 kgMachine weight approx.: 23500 kgMachine dimensions approx.: 11100 x 5392 x 3400 mm Accesories  Electronic handwheel: Joystick SELBOX S2External coolantGuarding Sales conditions Warranty: 6 months mechanical partsSale price (Ex Work): On request View all technical features
