Used Face Lathe for sale (6,268)

Condition: good (used), Year of construction: 2013, Centre height: 330 mm Centre distance: 2000 mm Ihsdpfx Ahex Ux D Dj Njt Spindle bore diameter: 103 mm Max. turning diameter over bed: 660 mm Max. turning diameter over carriage: 420 mm Spindle speed range: 36 – 1600 rpm (12 steps) Spindle nose: ISO 702/II No. 8 Longitudinal feed range: 0.063 – 2.52 mm/rev (65 steps) Cross feed range: 0.027 – 1.07 mm/rev (65 steps) Metric threads: 1 – 14 mm (22 steps) Inch threads: 28 – 2 TPI (25 steps) Module threads: 0.5 – 7 mm (18 steps) Diametral pitch: 56 – 4 DP (24 steps) Motor power: 7.5 kW Weight: 3200 kg Dimensions: 3635 x 1050 x 1450 mm

Condition: used, Year of construction: 2017, functionality: fully functional, Equipment: rotational speed infinitely variable, Pinacho lathe Type SC 250 Year 2017 With digital readout Centre distance 1500 mm Complete Isdpfxox Ux Dwe Ah Njht

Condition: good (used), Year of construction: 2007, Manufacturer: Volz BMT Year of manufacture: 2007 Control: conventional with digital readout (DRO) Iodpfx Ajx Uw S Hjh Noht Country of origin: Taiwan Swing diameter: 660 mm Max. turning length: 2000 mm Spindle bore: 85 mm Spindle mount: D1-8 Spindle motor: 7.5 kW Spindle speed: 17–1200 rpm with steady rest with digital readout (DRO) with thread cutting function

Condition: good (used), Year of construction: 1992, functionality: fully functional, machine/vehicle number: 5088, spindle bore: 25 mm, spindle speed (max.): 3,000 rpm, spindle speed (min.): 60 rpm, total height: 1,300 mm, total length: 1,200 mm, total width: 800 mm, overall weight: 700 kg, WEILER PRIMUS GS Lead and Feed Screw Lathe - Operating voltage: 380 V - Control voltage: 220 V - Power connection: 2 kW - Rated current: 4.1 A - Frequency: 50 Hz - Distance between centers: 450 mm - Center height over bed: 130 mm - Swing over bed: 260 mm Ihsdpox Ekm Eefx Ah Net - Center height over cross slide: 70 mm - Swing over cross slide: 140 mm The machine is equipped with a tailstock, a Multifix quick-change tool post, and a three-jaw chuck by RÖHM, diameter 120 mm. Comes complete with a matching workshop cabinet and appropriate accessories. This item comes from a training workshop. FCA D-73235 Weilheim Teck, loaded onto truck.

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, Technical details Iedpfxjx Uw Dvs Ah Noht swing over bed 730 mm centre distance 3000 mm control Heidenhain MANUALplus4110 weight of the machine ca. 6,5 t dimensions of the machine ca. 7400 x 2100 mm Additional information Very well-maintained cycle lathe with only 15652 operating hours. Working area: Center distance 3000 mm Swing diameter over bed 730 mm Swing diameter over cross slide 450 mm Bed width 480 mm Main spindle: Spindle mount according to DIN 55027 size 11 Spindle bore 130 mm Spindle diameter at front bearing 170 mm Spindle taper 1:20 Tap in center sleeve MT 6 Main drive: AC drive with 2-stage ZF gearbox (automatic shifting gearbox) Drive power (100/60% duty cycle) 22/28 kW Total speed range 1 - 2200 rpm Maximum spindle torque: approx. 2200 Nm X-axis (cross slide) performance data: Maximum travel: 400 mm Feed force: 14 kN Speed: 4 m/min Z-axis (bed slide) performance data: Feed force: 18 kN Speed: 7 m/min Max. workpiece weight: Between centers without steady rest: 2000 kg With one steady rest: 2200 kg With two steady rests: 2500 kg In the chuck: 750 kg Tailstock: Quad diameter: 115 mm Quad stroke: 225 mm Quad taper: MK 6 Equipment and accessories: Heidenhain MANUALplus 4110 CNC control SCHUNK ROTASplus 400-102 3-jaw manual chuck 2 steady rests PARAT tool holder Chip conveyor Coolant system Work area enclosure with two sliding doors. Machine length 5700 mm, with swarf converyor 7400 mm Machine width 2100 mm

Condition: good (used), Year of construction: 1984, functionality: fully functional, Swing diameter over bed 560 mm Swing diameter over cross slide 250 mm Ihsdpfx Ahjvn Rlze Njt Spindle bore 65.3 mm Power Max. 15 KW Speeds 11.2 - 2,240 rpm Centre width 1,000 mm Quill diameter 80 mm Quill mount MK 5 Incl. chip conveyor Incl. complete documentation

Condition: good (used), Year of construction: 2009, functionality: fully functional, Technical details faceplate diameter 1800 mm swing diameter 2000 mm turning height 1270 / 1120 mm Control SIEMENS 840 D workpiece weight max. 5000 kg ram head dimension 250 x 250 mm table turning speeds 1 - 320 U/min cross rail - adjustment 400 mm ram head - cross travel (X) -2770 / +2275 mm ram head - vertical travel (Z) 1250 mm c-axis 360° (0,001°) deg milling drive 37 kW turning speed range - milling 10 - 3000 U/min power capacity - table 100 kW Torque 31784 Nm feed range (X/Z) 0,1 - 15000 mm/min weight of the machine ca. 55 t Additional information Used CNC vertical lathe for turning, drilling and milling First machine installation in the year 2011. Max. workpiece diameter: 2040 mm Max. workpiece height: 1270 mm Ram stroke: 1250 mm Max. workpiece weight: 5000 kg (per pallet/chuck) Table speed range: 1.0 - 320 rpm Table drive motor: 100 kW Drilling and milling spindle: 37 kW Crossbar travel: 2 steps of 200 mm each Total electrical connection value: 218 kVA CNC control: Siemens 840 D Number of NC axes: 4 (X, Z, C, crossbar adjustment) Travels: X-axis: -1650 to + 2165 mm Z-axis: 1250 mm Rapid traverse X- Z-axis: 15 m/min Number of tool magazine spaces: 80 spaces in the chain magazine, of which 60 x HSK 100 and 20 x Capto C6 Disc magazine 12-pos. for rotary holders and attachment heads Coolant system with filter and circulation unit Chip conveyor Ijdpfx Ahjx Uwtqs Noht Oil-mist-extractor 1 pallet with jaws, diameter 1800 mm 1 hydraulic chuck with base jaws, diameter 1800 mm Various drilling and milling heads 2 measuring probes Several turning tool holders Special feature: Pallet changer with two stations, equipped with a face plate Ø1800 mm and a six-jaw lever compensation chuck with mechanical centrifugal force compensation Ø1800 mm. Note: The machine is in a pit. Condition description: The cross roller bearing on the Carnaghi was replaced about half a year ago. The Siemens components in the control cabinet were also completely replaced at the end of 2023. The machine also has a measuring probe for tool measurement and an external Renishaw measuring probe for workpiece measurement. As a special feature, the machine also has a measuring probe installed on the Z-axis (Z1-axis). This brings an advantage in terms of accuracy and time, as the tool does not have to be put down for measuring. However, it is currently shut down and should be overhauled when it is put back into operation. The machine also has a Rotomors six-jaw lever compensating chuck with centrifugal force compensation, which was completely overhauled in 2020/21.

Condition: excellent (used), Year of construction: 2022, For sale is a used Drechselmeister Twister ECO woodturning lathe. The machine is in good condition and has been refurbished and inspected by our qualified staff. (Fully functional) Technical specifications: - Center height: 200 mm Ihsdpfx Ahox Uwhus Njt - Swing over bed: 395 mm (larger diameter possible with optional outboard turning attachment) - Distance between centers: 720 mm (extendable) - Spindle thread: M33 x 3.5 with ASR (Euro) anti-release groove - Spindle and tailstock taper: MK2 - Speed range (2 belt stages): 60 - 1,350 and 180 - 3,750 rpm - Motor: forward and reverse operation - Tailstock quill travel: 100 mm - Motor power: 2 HP (230 V connection) with frequency inverter - Weight, floor version (incl. cast iron legs): 165 kg The machine is located in A-5431 Kuchl and can be inspected and collected at any time during our business hours. Subject to prior sale! Related terms: woodturning lathe, lathe, turning machine Reference: 5263

Condition: new, The V-Turn 410/1000, part of the Conventional Horizontal Lathes category and under the Engine Lathes group, is a precision lathe that excels in both precision and production applications. This bestselling machine features a robust inverter and a high-performance 5.5 kW motor that enables spindle speeds of up to 3,000 RPM, ensuring efficient processing of workpieces with small diameters. The constant cutting speed function automatically adapts to the turning diameter during face turning, delivering superior quality akin to that of CNC machines. Built on a heavy ribbed machine bed and a solid one-piece cast-iron frame, the V-Turn provides exceptional stability for heavier machining tasks. With its wide, hardened guideways and large spindle bearings, it guarantees excellent concentricity and longevity. The extensive standard equipment includes a 3-axis position indicator, coolant system, and a quick change tool holder, among others. Experience the precision of KNUTH's V-Turn 410/1000—request a quote today and enhance your machining capabilities in the Conventional Horizontal Lathe category and Engine Lathes group. Ihedpfx Ajp Aua Ujh Not

Condition: reconditioned (used), Year of construction: 2002, Cycle-controlled lathe GILDEMEISTER NEF 320 With MANUAL PLUS 4110 control Year of manufacture: 2002 Spindle bore: 50.8 mm Distance between centers: 750 mm Swing diameter over bed: 320 mm Swing diameter over cross slide: 150 mm Center height: 160 mm Speed range: 10 – 4000 rpm, stepless With the following accessories: Sliding guard with internal lighting Multifix tool holder with 2 inserts 3-jaw chuck Schunk ROTA – S plus Ø 200 mm 2 sets of soft top jaws ICP contour programming Tailstock with extendable quill Chip tray Coolant system Chip rinse gun 6 machine feet Ihjdpfoxn Apbjx Ah Net Operating manual

Condition: reconditioned (used), Year of construction: 2003, Universal Lathe GILDEMEISTER NEF 320 K With Siemens SINUMERIK 810 DE control (SIMATIC PANEL TOUCH SCREEN) Year of manufacture: 2003 Spindle bore: 52 mm Isdpfoxn Ar Aox Ah Njht Distance between centers: 750 mm Swing diameter over bed: 320 mm Swing diameter over cross slide: 150 mm Cross slide travel: 185 mm Infinitely variable speed range: 14 – 3550 rpm Including the following accessories: Sliding guard with internal lighting Multifix tool holder with 2 inserts 3-jaw chuck SCHUNK ROTA plus Ø 200 mm 2 sets of soft top jaws Coolant system Chip blow gun 6 machine feet Operating manual The machine is in very good condition!

Year of construction: 2012, condition: reconditioned (used), Conventional Precision Lathe WEILER “CONDOR VC” With Siemens 3-axis digital readout Ihedpfx Aoxykz Aeh Nst Year of manufacture: 2012 Spindle bore: 56 mm Centre distance: 800 mm Swing over bed: 205 mm Speed range: 30 – 3500 rpm Supplied with the following accessories: Multifix tool holder Chip guard with internal lighting Coolant system 3-jaw chuck Ø 200 mm Chuck guard Follow rest Ø approx. 150 mm Tailstock with retractable quill Operating manual

Condition: reconditioned (used), Year of construction: 2006, CNC Lathe GILDEMEISTER CTX 420 linear Equipped with Siemens 840 D powerline control Year of manufacture: 2006 Max. turning diameter: 324 mm Max. turning length: 600 mm Max. swing diameter: 680 mm Spindle bore: 79 mm Max. spindle speed: 4,500 rpm Including the following accessories: Sliding guard with interior lighting 12-position turret with 12 driven stations Y-axis, C-axis Tool measuring device Ihedoxzt Dcspfx Ah Net Parts catcher 3-jaw hydraulic chuck 210 mm with foot switch Hainbuch hydraulic collet chuck IRCO Breuning RBK 10012 bar feeder Signal lamp Tailstock with quill Chip conveyor Oil mist extraction Coolant system with high-pressure coolant (IKZ) and belt filter unit Operating manuals

Condition: reconditioned (used), Year of construction: 1956, Lead and Feed Screw Lathe WEIPERT Year of manufacture: 1956 Spindle bore: 90 mm Centre distance: 3000 mm Swing over bed: 800 mm Swing over cross slide: 610 mm Ihodpjw Ew D Dofx Ah Not Swing in gap: 1120 mm Speed range: 7.5 – 475 rpm Comes with the following accessories: Multifix toolholder with 11 inserts Coolant system 3-jaw chuck 315 mm 3-jaw chuck 400 mm 3-jaw chuck 500 mm Faceplate 400 mm Faceplate 800 mm Faceplate 1000 mm Travelling steady Various turning tools (30 insert tools) 2 revolving centres 1 drill chuck Operating manual

Condition: reconditioned (used), Year of construction: 1995, CYCLE LATHE WEILER " E 35" With 2 axes Siemens Sinumerik 805 Year of construction: 1995 Spindle bore: 54 mm Center distance: 950 mm Rotation O over bed: 410 mm Speed range: 4 - 3000 rpm With the following accessories: PARAT tool holder with 8 pcs. inserts Chuck guard 3 Jaw chuck 0 200 mm Iodpfjuzyw Djx Ah Neht 4 jaw chucks 0 200 mm Fixed lynette 12 - 150 mm Chip collection tray Chip guard with lighting Coolant device 4 pcs. Height-adjustable machine shoes Operating instructions

Condition: excellent (used), For sale: metal lathe from the English manufacturer Harrison, model m300, as shown in the photos. The machine is in very good condition. It is equipped with a new 160 mm chuck from Fuerda. Sino brand optical scales have been installed. During test turning over 20 cm, a diameter variation of 0.04 mm was measured. Ihjdpfx Aox Ur Amjh Njt Price is non-negotiable. Net price +23% VAT. Chuck: 160 mm Turning length: 600 mm Swing over cross slide: 220 mm Swing over bed: 320 mm Tailstock taper: MK3 Spindle bore: 38 mm

Condition: new, Year of construction: 2025, 0554 mm 370 mm 2000 mm 280 mm 104 mm Ihedpfx Ahox Urtro Not 11 kW

Condition: excellent (used), functionality: fully functional, Triade TI-40 Automatic Lathe Turning length: 400 mm Template-following copying tools Ihjdpfex Uq Rvsx Ah Net 1 profile tool Automatic material loading

Condition: used, L + Z Lathe WEILER Type Condor 81 A Mach. No. 36553 Year of manufacture approx. 1985 Centre distance 750 mm Swing over bed 330 mm Centre height over bed 165 mm Swing over cross slide 180 mm Centre height over cross slide 90 mm Spindle bore 40 mm Chuck mounting: Short taper DIN 55027 size 5 Tailstock quill taper MK 3 Quill travel 110 mm Spindle speed 45 - 2800 rpm, 16 steps Drive power 3 kW Power supply 400 Volt, 50 Hz - Spindle speed through 16 gear steps - 3-jaw chuck Ø 160 mm RÖHM with hard and soft jaws - Multifix quick-change tool post size B with 3 holders - Automatic longitudinal and cross feed - Electro-mechanical spindle brake - Emergency stop - Coolant tank with pump integrated in the machine base, without feed hose to working area - Hinged chuck guard - Splash guard - 1 live center Iodpfx Aek S Ht Ajh Neht - Electric diagram and operating manual Space requirements L x W x H 1850 x 950 x 1400 mm Weight 1100 kg Good condition

Condition: used, L + Z Lathe TONGIL- SAEILO Type TIPL-4SP Machine No. 00570319 Year of manufacture: 1985 Centre distance: 1000 mm Swing over bed: 400 mm Swing over cross slide: 210 mm Centre height over bed: 200 mm Centre height over cross slide: 105 mm Spindle bore: 58 mm Spindle speed: 55 - 1600 rpm, 16 steps Ijdsx Urbvepfx Ah Nsht Feed: Longitudinal and cross Tailstock taper: MT4 Chuck flange: Camlock, taper size 6 Motor power: 4 / 6 kW Electrical connection: 380 Volt, 50 Hz - Spindle speed via 2 motor speeds and 8 gear stages - 3-jaw scroll chuck RÖHM Ø 200 mm with stepped jaws - Multifix quick-change tool post size B with 2 exchangeable tool holders - Spindle brake via mechanical foot pedal - Coolant system - Emergency stop - Machine lamp Space required (L x W x H): 2250 x 1050 x 1220 mm Weight: 1500 kg

Condition: excellent (used), Year of construction: 2009, CNC controller: M720BM Capacity X-axis travel mm: 260 Y-axis travel mm: ±50 (100) Z-axis travel mm: 795 Turning length mm: 705 Max. turning diameter mm: ø 356 Swing over bed mm: ø 923,8 Swing over cross-slide mm: 755 Bar work capacity mm: 80 C-axis degree: 0,001° Ihjdpfxjxcqz Io Ah Nst Upper turret Number of tool slots St .: 12 Speed ​​driven tools RPM: 6.000 Drive power driven tools kW: 5,5/3,7 (3 min/cont) Indexing time s: 0,25 Main spindle Speed ​​spindle rpm: 4.000 Drive power spindle kW: 18,5/15 (25% ED/cont) Spindle bore mm: ø91 Tailstock Tailstock travel mm: 734 Holder: MT5 Equipment Chip conveyor Tool measuring arm

Condition: excellent (used), functionality: fully functional, Triade TI-30 automatic lathe Turning length 300 mm Copying tools by template 1 profile tool Ihsdpfx Ahjx Uqtdj Not Automatic material loading

Condition: excellent (used), Year of construction: 2012, CNC lathe 2 axes DMC Korea DL22 Fanuc OiTD with Manual Guide and USB port Ihsdpjxyaulsfx Ah Net year of manufacture 2012 8-inch chuck Spindle bore 65mm Turning length 400mm 12-position tool turret Tailstock Coolant tank with pump

Condition: used, Year of construction: 2019, Technical details: bar material dia.: 38 mm turning length: 350 mm turning speeds: 7.000 / 7.000 U/min number of tools: 30 (3 x 10) driven tools: ja / yes control: FANUC 31i-B5 rapid traverse: 30 m/min Ihsdpfsmu Rtuex Ah Net total power requirement: 10,5 kVA weight of the machine ca.: 6,5 t dimensions of the machine ca.: 2,50 x 1,45 x 1,75 plus Lademagazin m work piece power: 4 kW toolpiece turning speed range: 5.700 1/min Accerories main spindle power 11 kW sub spindle power 7,5 kW CNC sliding headstock machine STAR ST 38, 3 turrets, 12 CNC Axis (X1/Z1/Y1/C1/X2/Z2/Y2/YA2/C2/X3/Z3/Y3, Fireextinguisher KRAFT und BAUER FB 703, partscatcher and conveyor belt (for long parts), LTA oilmist suction, chiller for oil, machining with oil as coolant, reading hours: approx. 14.500 hours "machine on", approx. 4.100 hours "machining" *

Condition: refurbished (used), Year of construction: 2002, operating hours: 2,500 h, functionality: fully functional, machine/vehicle number: 350523, Equipment: CE marking, Voltage: 380V Net weight: 1400 kg Customs tariff number: 8458.1120 Dimensions: 180x128x172 cm TECHNICAL SPECIFICATIONS CAPACITIES Maximum turning diameter: 270 mm Maximum diameter above cross slide: 115 mm Height of center above cross slide: 60 mm Turning length B32: 265 mm Center height above floor: 1,162 mm SPINDLE A2-4 / Camlock D1-3’’ Spindle for Schaublin collets: Hainbuch / F38 / B32 Spindle speed: 50–5,000 rpm AC motor drive: continuous/intermittent power: 5.5 / 7.5 kW AC motor drive: continuous/intermittent torque: 42 / 58 Nm Spindle bore (without clamping key): 39 mm Maximum bar capacity with collet: 32 mm Maximum bar capacity with automatic chuck: 32 mm PNEUMATIC CLAMPING Adjustable axial clamping force, force at 5 bars: 1,150 daN CROSS SLIDE Cross travel, X-axis: 190 mm Resolution, X-axis (radius): 0.0005 mm AC motor drive: continuous/intermittent torque: 4 / 14 Nm Ball screw, diameter x pitch: Ø 20 x 5 mm Longitudinal travel, Z-axis: 390 mm Resolution, Z-axis: 0.001 mm AC motor drive: continuous/intermittent torque: 4 / 14 Nm Ball screw, diameter x pitch: Ø 32 x 5 mm FEED RATES Working feed rates, X and Z axes, stepless: 0–5 m/min Rapid traverse, X and Z axes: 8 m/min TURRET TOOL SYSTEM Standardized toolholder mounting: VDI 20 Number of fixed/tool stations: 8 / - Maximum tool section: 16x16 mm Integrated coolant and bi-directional indexing: yes COOLANT SYSTEM Tank capacity: 55 L Pump flow rate: 10 L/min Pump pressure: 1.7 bar PNEUMATIC TAILSTOCK Quill taper: MT3 Outside diameter of quill: 45 mm Quill stroke: 70 mm Adjustable tailstock pressure: 25–260 daN Subject to errors or omissions, all technical details are provided without commitment. Completely overhauled: Mechanics, geometry, hydraulics, and electrical parts checked and/or replaced Headstock Disassembly, parts cleaning, replacement of worn and defective parts, replacement of bearings, replacement of belts, spindle disassembly, replacement of seals and O-rings, adjustment. New paint. Turret Disassembly, cleaning, replacement of worn/defective parts. New paint and face resurfacing. Tailstock Disassembled, inspected, and serviced. New paint. Hydraulic and pneumatic circuits Disassembled, motor inspected, hoses, defective and worn parts replaced. X-Axis Ihodpfxox Upuge Ah Net Disassembly, replacement of worn parts such as O-rings, seals, rings. New ball screw and new sliding block. Z-Axis Disassembly, replacement of worn parts such as O-rings, seals, rings. New ball screw and new sliding block. Electrical cabinet Complete inspection, various relays replaced. Paintwork Colors: White RAL 9003 and grey RAL 7011 Geometry according to manufacturer's protocol. Various accessories checked and cleaned Year: 2002
