Condition: new, Year of construction: 2025, turning height: 2,800 mm, workpiece weight (max.): 30,000 kg, turning diameter: 3,300 mm, feed length Y-axis: 2,500 mm, feed length Z-axis: 1,500 mm, faceplate diameter: 3,000 mm, feed rate X-axis: 4 m/min, feed rate Y-axis: 4 m/min, feed rate Z-axis: 4 m/min, rotary table diameter: 3,000 mm, rapid traverse X-axis: 6 m/min, rapid traverse Y-axis: 6 m/min, rapid traverse Z-axis: 6 m/min, rotational speed (max.): 92 rpm, rotational speed (min.): 1 rpm, table load: 30,000 kg, table diameter: 3,000 mm, REM Vertical Turning Lathe TURNING DIAMETER SCR 33 MANUAL with DRO Special manufactured by REM for : CENTER AND EAST EUROPE MIDDLE EAST LATIN AMERICA DEVELOPING SHOPS , HIGHLIGHTS - UNBEATABLE PRICE - VERY EFFECTIVE MACHINE - GOOD FOR WORSHOPS IN SMALL AND MIDDLE RANGE OF PRODUCTION - NO GEARBOXES - NO CNC CONTROLL - NO EXPANSIVE TEHNOLOGIST AND WORKER - EASY MAINTENANCE AND - EASY OPERATE - EASY LEARN Technical Details: Faceplate Diameter (mm) 3000 Max. Turning Diameter (mm) + 300 Machining Height: 2800 mm Max. Work Piece Weight: 30 tons Conventional Control Kelev Ilg Hohccqnedk DIGITAL READ OUT for each axis

Condition: new, Year of construction: 2025, turning height: 2,400 mm, rotary table diameter: 2,500 mm, table load: 30,000 kg, table diameter: 2,500 mm, warranty duration: 12 months, table speed: 112 mm/min, machining diameter: 2,630 mm, REM Vertical Turning Lathe TURNING DIAMETER SCR SCR 27 MANUAL Special manufactured by REM for : CENTER AND EAST EUROPE MIDDLE EAST LATIN AMERICA DEVELOPING SHOPS, Kjlhjv Hngtsccqnedk HIGHLIGHTS - UNBEATABLE PRICE - VERY EFFECTIVE MACHINE - GOOD FOR WORSHOPS IN SMALL AND MIDDLE RANGE OF PRODUCTION - NO GEARBOXES - NO CNC CONTROLL - NO EXPENSIVE TEHNOLOGIST AND WORKER - EASY MAINTENANCE AND - EASY OPERATION - EASY LEARNING Technical Details: Faceplate Diameter (mm) 2500mm Max. Turning Diameter (mm) 2500+ up to300mm Machining Height: 2400mm Max. Work Piece Weight: 30 tons Control Conventional DIGITAL READOUT for each axis Plase note: This machine tool is made to order and can be customized to your specific needs.

Condition: new, Year of construction: 2025, Functionality: fully functional, turning height: 1,200 mm, workpiece weight (max.): 8,000 kg, turning diameter over cross slide: 1,700 mm, turning diameter: 1,700 mm, feed length X-axis: 1,100 mm, feed length Z-axis: 760 mm, faceplate diameter: 1,500 mm, total height: 4,600 mm, total width: 4,500 mm, total length: 4,700 mm, rotary table diameter: 1,500 mm, type of input current: three-phase, rotational speed (max.): 200 rpm, rotational speed (min.): 2 rpm, table diameter: 1,500 mm, warranty duration: 24 months, overall weight: 21,000 kg, Equipment: documentation/manual, REM Vertical Turning Lathe SC 17 CC Name of the machine is DOUBLE COLUMNS VERTICAL BORING MACHINE type SC17CC, where: SC = Double Columns Vertical Lathe; 17 = Max. swing diameter (dm); CC = Conventional type (standard equipment) Special manufactured by REM for : - CENTER AND EAST EUROPE - MIDDLE EAST - LATIN AMERICA - DEVELOPING SHOPS , HIGHLIGHTS - Unbeatable pricing for the base machine wth the option to add more features. - very effective machine for machinning small series parts. - good for worshops in small and middle range of production. - no gearboxes - less maintenance costs. - no cnc controll - a DRO can be fitted for the rapid and feed rates. - no expensive tehnology and operator training. - easy maintenance operation. - easy learning curve. Technical Details: Faceplate Diameter (mm) 1500mm Kdjlhcovu Dz Nocqnok Max. Turning Diameter (mm) + 300 Machining Height: 1500 - 2000 - 3000 mm Max. Work Piece Weight: 8 tons Control Conventional DIGITAL READ OUT for each axis The bed - is a single column with table bed. Faceplate - made of high-strength cast iron with 4 dies for centring and fixing the workpiece for the machining. Piece clamping is done with mechanical device with manual clamping. The movable cross rail - is one of the main parts of the lathe, with the role of guiding the vertical working heads and shifting the tool in horizontal direction. The cross rail is the quality cast iron mono block construction heavily ribbed provided with guide ways heat treated and grinding that overtake the efforts without deformations. Feed drive - Is performed on each axis through a feed box; the kinematics chain is made up of gears and electromagnetic clutches. The feed box gear wheels are made of alloy steel, heat-treated, with a ground tooting. Lubrication equipment - The lathe it is provided with continuous lubrication units as well as with intermittent lubrication (oil pulse lubrication) units operating in automatic regime. The continuous lubrication is used to ensure the lubrication of the gear box, the feed boxes and the main spindle.

Condition: new, Year of construction: 2025, Functionality: fully functional, turning height: 3,000 mm, workpiece weight (max.): 50,000 kg, turning diameter: 5,000 mm, feed length X-axis: 3,000 mm, feed length Z-axis: 1,800 mm, faceplate diameter: 4,500 mm, total height: 8,000 mm, total width: 7,000 mm, total length: 12,000 mm, rotary table diameter: 4,500 mm, table load: 50,000 kg, warranty duration: 12 months, Vertical Turning Lathe, model SCR 50 New - In the process of Building - 2025 model year. Can be fitted with: Milling options, Various colors, Coolant trough spindle, Fanuc CNC (or similar). Kelounrxljhccqnjdk Table Diameter - 4,500 mm Max. Machining Diameter - 5,000 mm Swing Diameter - 5,000 mm Max. Machining Height (Max. Distance between Table Top and Standard Turning Tool Holder with Tool) - 3,000 mm Max. Workpiece Weight - 50,000 kg No. of clamping jaws (standard) - 8 Linear Travels X - Axis (Ram Carriage along the cross rail) (-200/+2,950 mm) + ATC travel Z - Axis (Ram vertical displacement) 1,800 mm Cross Rail travel 2,600 mm Table diameter 4,500 mm Standard table with T-slots Belt transmission Spindle speed range (continuously variable) 0 to 1,500 rpm Feed Motor power 5.5 kW Max. Thrust force 60,000 N

Condition: excellent (used), Year of construction: 2016, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 800 mm, table load: 25,000 kg, spindle diameter: 132 mm, spindle speed (max.): 2,500 rpm, total height: 50 mm, total length: 80 mm, total width: 50 mm, table length: 2,000 mm, table width: 1,750 mm, feed length W-axis: 10,000 mm, feed rate X-axis: 10 m/min, feed rate Y-axis: 10 m/min, feed rate Z-axis: 10 m/min, rotational speed (max.): 2 rpm, travel distance W-axis: 800 mm, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 10 m/min, workpiece weight (max.): 25,000 kg, power: 37 kW (50.31 HP), Machine full under power . Need new X axis telescopic covers Mfg by REM 2016 revised 2022 Control -- Fanuc 31 I A TECHNICAL FEATURES Milling and Boring Head Boring spindle diameter 132 mm Boring spindle tapered bore ISO 50 Speed ranges No 2 Spindle speed 0+2500RPM Tool clamping automatic Main motor power (regime S1) 37 KW (spindle motor) Rotary Table Dimensions 1750x2000 mm Table indexing 360.000x0.001 Indexing accuracy 6 seconds Kjlhccorwx U Isqnsdk Maximum hydrostatic 25.000 kg Axes Travel X cross slide 2500 mm Z spindle 800 mm Y headstock 1600 mm W column back forth 1100 mm Feeds Feed axes selection automatic Work feed range on X, Y, Z 2 ÷ 10.000 mm/min Work feed range on W 2 ÷ 6.000 mm/min Work feed range on B 0.025-3 rpm Lead screws type on X, Y, Z ,W ball-screw Overall Dimensions length 7600 mm width 6000 mm height 5100 mm Weight (approx.) 44 tons Accessories - standard • Foundation leveling blocks • Technical documentation – operator, maintenance and programming Accessories - optional • Angle plates ( vincle)

Condition: as good as new (ex-display), Year of construction: 2012, operating hours: 1,000 h, Very little running time Technical data: Spindle diameter - 130mm Spindle Type - ISO 7:24 No50 Spindle Speed - 3000 RPM W axis - 800mm Y axis - 2000mm Z axis - 1600mm Kelhspa N Uheccqnjdk X axis - 4000mm Table size - 1800x2200mm Table loading capacity - 10.000kg General dimensions - 6800x6300x4600mm Machine Weight - 35000kg

Condition: excellent (used), Year of construction: 2021, operating hours: 3,000 h, travel distance X-axis: 6,100 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 950 mm, Machine manufactured basically in 1990 and retrofitted by REM in 2021 CNC - Heidenhain TNC 320 Kdjlsn D N H Tjhccqnjk Z axial slide travel mm 950 Y head vertical travel mm 2.000 X transversal travel mm 6.000 2-spindle head Spindle taper ISO50 with device for automatic locking and unlocking Head rotation 360°, 1000/4000rpm Head dimensions mm 290x290 Motor power of the spindles c.c. kw. 15 Approx. net weight machine ton. 32 Table surface mm 7.000x1.000 Vincles 3 pcs 1500X500X750

Condition: used, Year of construction: 2004, First MCV 2000 - Vertical Machining Center with Fanuc 0i control. Kolem E Ttxjhccqnsdk Specifications: Table dimensions: 2200 x 1000 mm X axis travel: 2050 mm Y axis travel: 1150 mm Z axis travel: 760 mm Spindle speeds: 12.000 rpm Work feed: 8.000 mm/min Rapid speed Z-axis: 15 m/min Rapid speed X - Y axis: 20 m/min Machine in stock, fast delivery

Condition: used, Horizontal Machining Center Kitamura HX500G Main Technical specifications: Kdjlhcom E Ttbjcqnjk Spindle Max. Speed: 12000 RPM Max. diameter of tools: 125mm Max. weight of tools: 20 kg Table work area: 630x630mm Max. work size: 1000x1000mm Table load capacity: 1200kg X-axis: 1050 mm Y-axis: 850 mm Z axis: 900 mm Spindle nose to table distance: 130 - 1030 mm Available. Fast delivery

Year of construction: 2016, operating hours: 7,000 h, Condition: as good as new (ex-display), machine/vehicle number: 0012, Technical data: 1. Capacities - Maximum turning diameter with either Vertical Head 3300 mm - Maximum machining height under Cross Rail, at least 2000 mm - Maximum weight of the workpiece 20 tons 2. Table - Table diameter 3000 mm - Speed (inf. Variable) 1- 110 RPM - Main motor drive (AC) 100 KW - 4 jaw chuck with reversible jaws 3. Vertical Heads - Straight Ram vertical travel (250X250 mm cross section) 1300 mm - Horizontal and Vertical travel by means of 10 mm pitch ball screws 4. Cross Rail - Vertical Travel 2000 mm - Cross Rail elevating motor 7.5 KW AC 5. Feeds - Feed ranges 0.1 – 5 mm/rev - Rapid traverse feed 8000 mm/min 6. Overall Sizes Kdelodpdfzehccqnok - Dimensions (approx.) L x W x H 6600 x 5.300 x 5.400 mm - Weight (approximate) 60 tons GEOMETRICAL TESTS (ISO 3655, ISO 230-1; VDI 3441 and ISO 230-2) Positioning accuracy -X and Z axes mm +/-0,015/1000 Positioning repeatability -X and Z axes mm 0,010 CNC Fanuc
