Used Wiring Diagrams for sale (3,213)

Condition: excellent (used), Type ER 9-0.8, Dsdpfoy Eyy Iox Akcecg wire range 0.5-0.8 mm as-new devices, several available.

Condition: refurbished (used), Year of construction: 1999, functionality: fully functional, drawing speed: 10,000 mm/s, inner diameter: 600 mm, load capacity: 3,000 kg, wire diameter (max.): 14 mm, Year of manufacture 1999 Maximum speed 10 m/s Total installed power 230 kW Key status Complete electrical modernization TEUREMA EHS-110 wire drawing line, a heavy-duty industrial machine equipped with a Tecno Impianti drawing bench and designed for reliable production performance. The line has undergone a complete electrical modernization, including a new main electrical cabinet, Siemens S7-1500 PLC, Siemens HMI 1200, 100% new wiring and new push-button stations, significantly improving reliability, maintenance and overall operation. Line configuration Pay-off stands 2 tilting pay-off units. Maximum coil weight per unit: 3,000 kg. Vertical pay-off tower 6-meter tower with lifting and lowering carriage operated by hoist. Descaler Mechanical descaler. Lubrication box 1.5 kW motor at 1,500 rpm. TECNO IMPIANTI drawing bench 2 passes. Double-ring capstan: Ø 610 mm and Ø 760 mm. 3-speed gearbox: 3.90 / 7.20 / 10.00 m/s. Power: 160 kW. Frequency: 50 Hz. Horizontal coiler Horizontal drive. Maximum coil weight: 3,000 kg. 2-speed gearbox: 7.3 / 10.0 m/s. Maximum coil diameter: Ø 1,200 mm. Core diameter: Ø 600 mm. Useful spool width: 900 mm. Power: 45 kW. Technical data • Incoming wire diameter: 5.5 to 14 mm • Outgoing wire diameter: 4 to 12 mm • Number of blocks: 1 vertical • Maximum line speed: 10 m/s • 2 x CL30 A 33 Eurolls cassettes • Rollers: Ø 150 x Ø 90 x 15/20 mm • Total machine power: 230 kW • Frequency: 50/60 Hz Electrical and automation upgrade • Completely new main electrical cabinet • Siemens S7-1500 PLC • Siemens HMI 1200 • 100% new wiring • New push-button stations This line combines the strength of a proven industrial machine with a complete upgrade of its electrical and control systems, making maintenance easier, improving reliability and simplifying integration into modern production environments. Available services • Installation • Assembly • Commissioning • Technical assistance Dcodpfxey Ex Eco Akcog TEUREMA EHS-110 wire drawing line, manufactured in 1999, equipped with a Tecno Impianti drawing bench and capable of operating at speeds of up to 10 m/s. The machine features a complete electrical modernization with a new main electrical cabinet, Siemens S7-1500 PLC, Siemens HMI 1200, completely new wiring and new push-button stations, offering a robust, reliable and production-ready industrial solution.

Condition: good (used), Feed unit Weinig EM 11 Dedpfx Akjyth S Hscscg

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: 07D1M931, travel distance X-axis: 400 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 220 mm, wire diameter (max.): 0.3 mm, wire diameter (min.): 0.1 mm, TECHNICAL DETAILS Travel X-axis: 400 mm Travel Y-axis: 300 mm Travel Z-axis: 220 mm Travel U/V-axis: 120 mm Cutting angle at 87 mm: ±30° Cutting angle at 200 mm: ±15° Wire diameter: 0.1-0.3 mm Max. workpiece dimensions: 810 mm x 700 mm x 200 mm MACHINE DETAILS Operating hours: 28,500 h Dcodpfx Aey Emxqekcsg Machine weight: 2,700 kg

Year of construction: 1997, condition: ready for operation (used), Several Wafios wire processing machines with two payoffs are available. 1) Wafios N90, year of manufacture: 2003. Including payoff Wafios AHL 41 D-M, year of manufacture: 2002. 2) Wafios DS 80. 3) Wafios N6. 4) Wafios N5. 5) Wafios N4. 6) Wafios N4. 7) Wafios payoff AHL 41 DR, year of manufacture: 1998. 8) Wafios payoff AHL 41 D, year of manufacture: 1997. All machines including payoff. An on-site inspection is possible. Individual sale possible. Dcjdoy Eg Dmjpfx Akceg

Condition: reconditioned (used), Year of construction: 2006, operating hours: 3,422 h, functionality: fully functional, machine/vehicle number: 214, workpiece weight (max.): 400 kg, travel distance X-axis: 500 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 430 mm, wire diameter (max.): 0.3 mm, No minimum price – guaranteed sale to the highest bidder! The machine was overhauled in 2025! The corresponding invoice is included. TECHNICAL DETAILS Maximum workpiece weight: 400 kg Travel X-axis: 500 mm Travel Y-axis: 350 mm Travel Z-axis: 430 mm Maximum wire diameter: 0.3 mm Table load: 400 kg Maximum workpiece height: 420 mm Positioning accuracy: 0.001 mm MACHINE DETAILS Input voltage: 400 V Input frequency: 50 Hz Input current: 17 A Voltage: 3 x 400 V Power: 12.1 kVA Rated current: 17.5 A Short-circuit current: 10 kA Total weight: 2,650 kg Operating hours: 17,800 h EDM hours: 3,422 h EQUIPMENT Wire alignment device Dcsdoy Ed E Ijpfx Akcjg

Condition: good (used), Winch rope, crane rope, lifting rope, wire rope, clothesline, PVC wire rope Dcedpjpy Ryqsfx Akcog -Wire rope: PVC-coated steel cable -Type: 6x7 FC PVC transparent -Rope nominal diameter 4.0 / 5.0 mm -Length: 102 m -Quantity: 1 piece available -Price: per piece -Weight: 6.6 kg/pc.

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 331965, workpiece weight (max.): 500 kg, travel distance X-axis: 400 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 200 mm, wire diameter (max.): 0.25 mm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Dcodpfx Aoyz Rxajkcjg X-axis travel: 400 mm Y-axis travel: 250 mm Z-axis travel: 200 mm (U/V) axis travel: 400 x 250 mm Taper angle: +/- 30° at 200 mm height Workpiece weight: 500 kg Workpiece height (max): 200 mm Workpiece width (max): 500 mm Workpiece length (max): 850 mm MACHINE DETAILS Standard wire guides: 0.25 mm Dimensions & weight Dimensions (L x W x H): 1,800 x 1,600 x 2,180 mm Machine weight: 2,190 kg Injection pressure upper nozzle: 0 - 11.5 bar Injection pressure lower nozzle: 0 - 11.5 bar

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, machine/vehicle number: 350900, workpiece weight (max.): 1,000 kg, travel distance X-axis: 400 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 400 mm, wire diameter (max.): 0.25 mm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel X-axis: 400 mm Travel Y-axis: 250 mm Travel Z-axis: 400 mm Travel U-axis: 400 mm Travel V-axis: 250 mm Workpiece weight: 1,000 kg Workpiece height (max.): 400 mm Djdpfsyz Rvlox Akcecg Workpiece width (max.): 500 mm Workpiece length (max.): 850 mm Taper angle: +/- 30° at 400 mm height MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 1,800 x 1,600 x 2,230 mm Machine weight: 2,500 kg Standard wire guides: 0.25 mm EQUIPMENT Collision protection in X/Y/U/V/Z

Condition: new, Included in delivery: 01x Wire mesh, new Dcjdpfx Akeyz Ir Rjcsg Manufacturer: Garantell Material finish: sendzimir galvanized Design: placed on top Total depth: approx. 1,118 mm Inner depth: approx. 1,105 mm Upright depth: approx. 1,100 mm Beam support width: approx. 53 mm Clear supporting width: approx. 998 mm Width: approx. 1,340 mm Mesh size: approx. 110 x 95 mm Wire gauge: approx. 4.00 mm Weight per piece: approx. 6.75 kg Number of support bars: 05 pcs Support bar dimensions: approx. 998|50|1.25 mm Maximum load capacity: 500 kg Your contacts in our company: Mr. Andre Evering Mr. Mario Klöver Mr. Falk Deutsch General information about this item: This item is only offered for collection. If transport or shipping is required, it will incur additional costs, which can be individually requested from us depending on the place of delivery or the scope of delivery.

Condition: excellent (used), Year of construction: 2012, machine/vehicle number: MIKA Seilzüge, 1x Demag DR wire rope hoist crane Due to numerous inquiries - Price is per unit! 5 units available, see listing below: Dodpoy D D S Ssfx Akcecg 1x Demag wire rope hoist EKDR-Pro3 NL1600Kg/1.6t, serial number 96656002, 4M, hook path/lift 12m! – double reeved, year 2015 1x Demag wire rope hoist EKDR-3 NL1600Kg/1.6t, serial number 96656701, 2M, hook path/lift 12m! – double reeved, year 2015 1x Demag wire rope hoist EKDR-3 NL1000Kg/1.0t, serial number 96305549, 4M, hook path/lift 12m! – double reeved, year 2012 1x Demag wire rope hoist EKDR-3 NL1000Kg/1.0t, serial number 96305548, 4M, hook path/lift 12m! – double reeved, year 2012 1x Demag wire rope hoist EKDR-3 NL1600Kg/1.6t, serial number 96305550, 4M, hook path/lift 12m! – double reeved, year 2012 Each with 2 lifting speeds, lifting height 12m, trolley gauge adjustable Each hoist supplied with pendant control and power supply plug Total weight approx. 300 kg, connection to 400V 50Hz Very good condition, see photos Item location: 75053 Gondelsheim Shipping available, please inquire with your postal code

Condition: good (used), Technical data for the shelf panel: Shelving system: SSI Schäfer Type: R 3000 Included in the scope of delivery: 01x shelf panel, used Material finish: Sendzimir galvanized For upright depth: approx. 600 mm Overall width: approx. 1,600 mm Overall depth: approx. 590 mm Overall height: approx. 30 mm Frame profile: approx. 25 x 25 mm Mesh size: approx. 68 x 50 mm Weight per piece: approx. 6.90 kg Note: Water-permeable (up to 70%), suitable for sprinkler systems and thus optimized fire protection. Dcsdpfx Ajyzpiqekcog Air-permeable – allows for good air circulation, e.g. in deep-freeze warehouses. Light-permeable – ensures a bright working environment in the warehouse. Your contacts in our company: Mr. Andre Evering Mr. Mario Klöver Mr. Falk Deutsch General information about the item: This item is offered for collection only. Any transportation or dispatch beyond collection is subject to additional costs, which can be requested from us separately depending on the delivery location and scope.

Condition: used, Year of construction: 2006, Wire erosion / EDM Travel distance X: 300 mm Travel distance Y :200 mm Travel distance Z: 200 mm max. workpiece size X: 500 mm max. workpiece size Y: 300 mm Djdsyznabopfx Akcocg max. workpiece size Z: 200 mm max. workpiece weight: 300 kg table size X: 536 mm table size Y: 337 mm with AWF ( Automatic Wire Feeding ) U / V axis: +-80 generator: 60 Ampere submerged cooling unit Linear motor drive (no ball screw wear) High positioning accuracy with glass scales Automatic wire threading Submerged machining capability CNC control system (Sodick LN series) Taper cutting up to ±20° Integrated cooling system Filtration system with ion exchange resin Ideal for complex contours and precision machining

Condition: ready for operation (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: 02DC2563, workpiece weight (max.): 1,500 kg, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 310 mm, wire diameter (max.): 0.3 mm, The machine will remain in operation until 08/04/2026! TECHNICAL DETAILS X-axis travel: 600 mm Y-axis travel: 400 mm Z-axis travel: 310 mm U/V-axis travel: 150 mm Max. workpiece weight: 1,500 kg Maximum workpiece dimensions: 1,050 x 820 x 305 mm Taper angle (workpiece height): 15 mm / 260 mm or 30 mm / 110 mm Table dimensions: 840 x 560 mm Possible wire diameters: 0.10 - 0.30 mm Wire spool capacity: 10 kg Dcjdpfx Akeyzh Dascjg MACHINE DETAILS Dimensions & Weight Machine dimensions: 2,687 x 3,030 x 2,150 mm Machine weight: 3,500 kg EQUIPMENT Hardened 3-sided table

Condition: good (used), Year of construction: 2006, FOR SALE Mitsubishi FA20S Wire EDM Machine Technical Data: - Model: FA20S (High Performance Series) - Travel (X x Y x Z): 500 x 350 x 300 mm - U/V Axis Travel: ±32 mm - Maximum workpiece dimensions: 1050 x 800 x 295 mm - Maximum workpiece weight: 1,500 kg - Maximum taper angle: ±15° (over 100 mm height) Year: 2006 Included Equipment and Options: - Filtration system: TFA20SM dielectric fluid tank - Automatic wire threading (AT) for efficient unmonitored machining - Mitsubishi CNC with user-friendly interface - Generator featuring anti-electrolysis technology for improved surface integrity Key Advantages: This machine offers excellent thermal stability and high reliability. Furthermore, spare parts and consumables (guides, filters) are readily available on the market. Condition: Used machine in good overall condition. Please do not hesitate to contact me for further information or to discuss the price. BT MACHINES PURCHASE AND SALE ALL TYPES OF INDUSTRIAL EQUIPMENT ALL TYPES OF MACHINE TOOLS Djdpsyzct Aofx Akcjcg

Condition: new, Year of construction: 2026, functionality: fully functional, workpiece weight (max.): 400 kg, travel distance X-axis: 440 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 400 mm, total height: 1,700 mm, total length: 1,650 mm, total width: 1,150 mm, wire diameter (max.): 0.25 mm, workpiece height (max.): 400 mm, table width: 380 mm, overall weight: 1,150 kg, table length: 650 mm, empty load weight: 1,150 kg, warranty duration: 12 months, input voltage: 400 V, The EDM32 wire electrical discharge machine is a precision device designed for electro-erosion machining of electrically conductive materials. It is ideal for the production of tools, molds, and components requiring high accuracy and surface quality. The machine enables efficient cutting of complex shapes in both single-piece and serial production. Thanks to its stable construction and well-optimized operating parameters, the EDM32 ensures high productivity and repeatability of the machining process. The device allows cutting at angles up to ±6°, increasing its technological versatility. The use of wire with a diameter of 0.12 to 0.25 mm enables precise machining of even highly demanding components. The machine provides good surface finish quality at the level of 1.6–2.5 Ra, reducing the need for additional processing. High cutting efficiency and stable wire speed ensure optimal performance. The robust construction and maximum table load of up to 400 kg allow machining of heavier workpieces without loss of accuracy. Technical data Table travel: 440 × 350 mm Table size: 380 × 650 mm Max cutting height: 400 mm Wire diameter: 0.12 – 0.25 mm Taper cutting: ±6° Max cutting efficiency: 120 – 150 mm²/min Surface roughness: 1.6 – 2.5 Ra Machining power: 2 kW Wire speed: 11 m/s Max table load: 400 kg Weight: 1150 kg Machine dimensions: 1650 × 1150 × 1700 mm Applications Dcedsy A N Ezopfx Akcog Mold and die production Toolmaking industry Precision metal machining Production of complex geometry parts

Condition: excellent (used), Year of construction: 2026, Wire reel, pasture wire reel, barbed wire winder, wire winder, wire winding machine, pasture fence winder, winding device -Drum diameter: 800 mm Dcedpfxexvh Hue Akcsg -Drum width: 990 mm -Drive: hydraulic -The device could be used with a corresponding front loader or three-point hitch -without front loader mount and hydraulic connections -Dimensions: 1020/1450/H830 mm -Weight: 318 kg

Condition: good (used), Year of construction: 2001, Travel X / Y / Z: 220 x 150 x 150 mm Z-axis device: standard equipment (= 5th axis) Max. taper angle: 15° (for workpiece 100 mm thick) Dcjdjg Icdyepfx Akcsg Taper machining unit: standard equipment (= 3rd and 4th axis) Wire diameter: 0.03 - 0.25 mm dimensions L x W x H 1900 x 2345 x 2060 mm Weight 3500 kg Siegfried Volz Machine Tools Rüschebrinkstr. 151-153 44143 Dortmund - Wambel

Condition: used, Wire Stitching Machine Polygraph 703/1T Drahtheftmaschine / Wire Stitching Machine Polygraph 703/1T 1-head wire stitcher for block- and saddle stapling. Year - Serial-No. 21/4 Online-Video-Inspection by WhatsApp - MS Zoom - Telegram Djdpfxsyywzxo Akcocg On Stock Emskirchen/Nürnberg - Available Immediately - Can be test

Condition: good (used), Year of construction: 2002, functionality: fully functional, Gamma 333 fully functional. Dcsdpfxoy Ah R Ns Akcog

Condition: used, Year of construction: 2005, operating hours: 18,950 h, travel distance X-axis: 350 mm, travel distance Y-axis: 220 mm, travel distance Z-axis: 220 mm, Wire Diameter 0,1-0,3 mm Automatik Threading Working Hours 18950 Std Verfahrwege X 350 mm Y 220 mm Z 220 mm U 350 mm Dodpowzyvhjfx Akcocg V 220 mm Year 2005

Condition: refurbished (used), Year of construction: 2001, functionality: fully functional, AGIECUT Excellence 3 Year of manufacture: 2001 Travel paths: X= 500 mm, Y= 350 mm, Z= 256 mm U/V-axis travel: +/- 70 mm Maximum taper: 30° at 100 mm height Maximum workpiece dimensions: 1050 x 650 x 250 mm Maximum workpiece weight: 400/800 kg Achievable surface finish: Ra: 0.10 µm Available wire diameters: 0.10 – 0.33 mm Submerged machine with automatic wire threading With automatically lowering tank (accessible from 2 sides) Including AGIEJOGGER handbox for convenient setup Including AGIESETUP 3D AGIEVISION control unit AGIE IPG generator Dimensions (L x W x H): 2800 x 2400 x 2220 mm Net weight: 4500 kg The machine will be cleaned, overhauled, and thoroughly tested by us upon receipt of order. Includes user training at Techma on your overhauled machine Dcsdpfxjyx D I As Akcjg Optional: Transport, commissioning, chiller

Condition: good (used), Year of construction: 2001, Agiecut Challenge 3 Year 2001 XYZ - 500x350x256 UV axis - +-70mm Maximum coveted 30° at 100 mm height Maximum pieces 1050x650x250 Maximum weight 400/800 kg Dodpfxouanm Ij Akcecg Machine dimensions 2800x2400x2220mm Machine weight 4t500kg

Condition: used, Year of construction: 2005, AGIECUT Challenge 2 eCut Year of construction 2005 TECHNICAL DETAILS X-axis travel: 350 mm Y-axis travel: 250 mm Z-axis travel: 256 mm U/V axis: ±70 mm Cone angle: 30°/100 mm Dodsua Uzfepfx Akcocg Cutting rate: > 300 mm²/min Quality: Ra 0.1 µm Thread height: 250 mm Tapping die: 1/2 mm Wire diameter: 0.1 - 0.33 mm Workpiece height: 250 mm Workpiece width: 550 mm Workpiece length : 750 mm Workpiece weight with/without bath: 200 / 450 kg MACHINE DETAILS Bath size : 700 l Dimensions : 2215 x 2215 x 2220 mm Net weight : 3600 kg

Condition: good (used), Year of construction: 2011, functionality: fully functional, section length (min.): 100 mm, section length (max.): 3,500 mm, type of input current: three-phase, For sale: Used WAFIOS RS4 wire straightening machine in good condition. Technical data: • Model: RS4 • Manufacturer: WAFIOS • Straightening range: 3 to 6 mm • Equipment: includes blades, straightening stones, feed roller in various sizes, decoiler Dcsdpfow U Eubsx Akcog • Year of manufacture: 2011 Condition: • Fully operational, regularly serviced Location: 74931 Lobbach Price: €6,000 net
