Used Vertical Panels for sale (19,038)

Condition: repair required (used), Year of construction: 2017, functionality: not functional, machine/vehicle number: 108113, Technical Characteristics: Work Area - Maximum clamping plate diameter: 160 mm - Maximum turning diameter: 160 mm - Maximum machining diameter: 100 mm - Maximum workpiece length: 150 mm - X-axis travel: 700 mm / Rapid traverse X: 60 m/min - Z-axis travel: 375 mm / Rapid traverse Z: 30 m/min - Standard automation with closed system (number of loading nests by workpiece diameter: 14/(80–200), 18/(30–160), 30/(30–85)) Main Spindle - Spindle interface per DIN 55026: Size A5 - Maximum spindle speed: 6000 rpm Hnedpfx Aexxip Ajgtjt - Power (100% / 40% duty cycle): 18.1 / 13.9 kW - Torque (100% / 40% duty cycle): 77 / 59 Nm Tool Holder with Driven Tools - Tool shank per DIN 69880: 12 – BMT65 - Number of stations: 12 - Maximum tool length including holder: 190 mm - Maximum speed: 6000 rpm - Maximum torque (10% duty cycle): 27 Nm; (100% duty cycle): 14 Nm Electrical Equipment - Operating voltage: 400–480 V, 80 A - Connected load: 27 kVA Dimensions - Total dimensions (L x W x H): 4350 mm (with chip conveyor) x 1600 mm x 2500 mm - Weight: 5500 kg Main Features and Capabilities: - Vertical Design: Optimized for chip removal and easy loading/unloading - CNC Controller: GE Fanuc FS 32i B - High precision: Positioning accuracy in X and Z axes ±0.001 mm with Heidenhain linear scales - Main spindle: High power and broad speed range - In-process control: Marposs T25 measuring probe - Automated loading/unloading: Integrated automation for feeding and removing parts - Live tools: Capability for drilling and milling operations - Tool life monitoring and sister tool management - Chip conveyor & Knoll coolant filtration unit with paper filter and 40 bar pumps (suitable for filtering two machines) - Fully enclosed work area, with work area lighting - Documentation: Electronic version available, printed booklet incomplete Machine Status: - NOT WORKING - LT motor defective, repairable - Operator panel, safety switch, and two buttons broken and need replacement

Condition: new, Year of construction: 2024, New Grundfos Pump - Vertical, multistage centrifugal pump with integrated frequency converter. inlet and outlet ports on same the level (inline). The pump head and base are in cast iron – all other wetted parts are in stainless steel. A cartridge shaft seal ensures high reliability, safe handling, and easy access and service. Power transmission is via a rigid split coupling. Pipe connection is via DIN flanges. The pump is fitted with a 3-phase, fan-cooled asynchronous motor. The motor includes a frequency converter and PI Hnsdoyug R Rspfx Agtst controller in the motor terminal box. This enables continuously variable control of the motor speed, which again enables adaptation of the performance to a given requirement. An operating panel on the motor terminal box enables setting of required setpoint as well as setting of pump to "Min." or "Max." operation or to "Stop". The operating panel has indicator lights for "Operation" and "Fault". Communication with the pump is possible by means of Grundfos GO Remote (accessory). The remote control enables further settings as well as reading out of a number of parameters such as "Actual value", "Speed", "Power input" and total "Power consumption". The terminal box holds terminals for these connections: • pump start/stop input (potential-free contact) • remote setpoint setting via analog signal, 0-10 V, 0(4)-20 mA • 10 V voltage supply for setpoint potentiometer, Imax = 5 mA • three analog sensor inputs, 0-10 V, 0(4)-20 mA • 24 V voltage supply for sensor, Imax = 40 mA • one analog output • three digital inputs • two Pt100 inputs • two potential-free fault signal relays with changeover contact, reporting "Fault", "Operation" or "Ready" • RS-485 GENIbus connection • interface for Grundfos CIM fieldbus module

Condition: used, Year of construction: 2001, Second-hand machine Year of manufacture: 2001 Condition: well-maintained Features and technical specifications: Hsdezk Nm Espfx Agtont Cutting length 4,300 mm Cutting height 2,200 mm Cutting depth 45 mm Motor: 3 kW Saw blade diameter 220 mm with SuperCut scoring device with automatic sliding grate Complete with length stop Includes strip stop Availability: at short notice Location: 63934 Röllbach

Condition: new, Year of construction: 2023, New machine Year of manufacture: 2023 Partnership Edition Technical Specifications: Cutting height: vertical: 0–2,150 mm, horizontal: 80–2,000 mm Cutting length: 5,300 mm Cutting depth: 80 mm (55 mm with clamps) Saw blade: Diameter 303 mm, bore 30 mm, Z=60 hollow flat-top tooth Blade speed: 5,000 rpm Required air pressure: 6 bar Measurement readout for horizontal cuts: - via scale from 0–2,070 mm - via strip cutting fence from 75–500 mm Measurement readout for vertical cuts: - via scale from 0–1,300 mm Extraction connection: 1 x 100 mm, 1 x 120 mm Features: - ADVANCE clamping system, consisting of 2 pneumatic clamping grippers, motorized on vertical axes via a ball screw, moving from top to bottom. The grippers handle panels weighing up to 150 kg. - Torsion-free, free-standing machine frame - Round bar guides, vertical and horizontal - Pneumatically retractable slat bed - Fine-adjustable flip stop with extension - Fine adjustment for horizontal cuts via handwheel - Strip cutting fence - Manual programming rail with 5 T-slot nuts - Pneumatic immersion of the saw unit - 25 material support rollers - 1 infeed and 1 outfeed roller - Pneumatic workpiece clamping device between the support rollers - 3 intermediate support elements, pneumatically extendable - Pneumatic saw head locking - Control panel with documentation holder - Switch unit on the saw unit: start button, stop button - Tool cabinet - Scale illumination for vertical cuts Partnership Edition Features: - Digital display for the flip stop - Digital display for the saw unit with incremental mode - Pneumatically tiltable saw unit - Scoring system with controlled counter-air nozzle, numerical display for scoring or grooving depth setting, and activation indicator - 5.5 kW motor including star-delta starter - Cutting line laser Hnjdpfew I U D Esx Agtst Availability: Short-term Location: Flörsheim

Condition: good (used), Year of construction: 1997, power: 5.5 kW (7.48 HP), Technical data: Manufacturer : Striebig Type : Standard TRK2 6220 year 3.97 Feed : manual Design : automatically deflecting aluminum slatted frame Saw carriage lock : manual Immersion saw unit : manual Engine power : 4,4/5,5kW cutting area : 5300 × 2200× 80mm Speed : 4750 rpm Saw blade diameter : 303 mm Space requirement : L × H × W 6400×3000×1400 Mounting : Freestanding or wall Location : Warehouse Price : 12200€ net Hedpfx Agjvgfuustjnt Delivery and assembly possible by arrangement

Condition: like new (used), CTS 2,500 L Vertical Vat / Mixer with Double Jacket and Agitator – Stainless Steel Industrial vat / vertical mixer CTS with a capacity of 2,500 liters, equipped with a double jacket for thermal treatment and an agitation system, designed for the preparation, mixing, heating, and homogenization of food products in industrial batch processes. The equipment combines a large-capacity vertical vessel with a motorized agitator and a double jacket, allowing mixing and thermal treatment operations to be performed on the product in a single unit. Its 2,500-liter capacity, stainless steel construction, and bottom discharge make it a particularly interesting solution for plants that process large volumes of product. MAIN FEATURES Hodpfx Aezbi Rmogtont -Manufacturer: CTS -Capacity: 2,500 liters -Type: Industrial vertical vat / pot / mixer -Vertical configuration -Double jacket for thermal treatment -Integrated agitation system -Agitator with motorized drive -Mixing and homogenization of product -Stainless steel construction -Large-capacity vessel -Curved bottom -Bottom product discharge -Discharge valve -Robust support structure -Integrated control panel -Designed for industrial batch processing -Integrable into food production lines PROCESS The 2,500 L CTS is designed to receive the ingredients and mix them using the internal agitation system. The double jacket allows for the thermal exchange necessary to heat or maintain the product temperature, depending on the conditions and services available in the installation. The agitator keeps the product moving during the process, promoting uniform distribution of the ingredients and temperature. Once the cycle is complete, the product can be discharged through the outlet located at the bottom. It can be used for the following operations: Mixing and homogenization Heating Cooking, depending on the process Temperature maintenance Formulation preparation Dissolution and incorporation of ingredients Preparation of sauces, creams, and purees APPLICATIONS Particularly suitable for canning industries, sauce manufacturers, prepared meal producers, vegetable product manufacturers, puree, cream, and filling manufacturers, and other food industries that require a large-capacity processing vessel with agitation and thermal treatment. The combination of 2,500 liters, double jacket, agitator, and stainless steel construction provides a versatile solution for industrial preparation and mixing processes. Machine available for inspection. Additional technical information, dimensions, additional photographs, or videos can be provided upon request.

Condition: used, Year of construction: 2007, Second-hand machine Year of manufacture: 2007 Specifications and technical data Cutting length: 5,300 mm Cutting height: 2,200 mm (trimming height 2,110 mm) Cutting depth: max. 60 mm Extraction system: - Saw unit 120 mm - Frame width 100 mm Workpiece support: - Sturdy plastic support for optimum stability, even for narrow workpieces. - Chips are removed via slanted slots. Lift-roller transport system: Manual, for light and gentle transport of materials Clamping: Manual, vertical and horizontal Feed: Manual, vertical and horizontal Circular saw blade: carbide-tipped, 250 mm, hollow roof-tooth, Z48 Saw motor: 4 kW at 5,450 rpm, 400 V, 50 Hz Hnodpfxjzk N S Ie Agtet Tilting table: including workpiece support for narrow parts (5 positions) Includes strip stop with Supercut scoring device Extraction system in accordance with BG TRK guidelines (less than 2 mg of fine dust per m³ of air) Availability: at short notice Storage location: 63934 Röllbach

Condition: excellent (used), Year of construction: 1980, functionality: fully functional, machine/vehicle number: 80753, total height: 2,300 mm, total width: 1,750 mm, total length: 2,500 mm, overall weight: 4,700 kg, Equipment: documentation/manual, Offered for sale is a universal tool milling machine, MAHO Type MH 800 P, with digital display and linear control system HEIDENHAIN TNC 121. Year of manufacture: 1980 Travel distances X: 700 mm, Y: 450 mm, Z: 500 mm Table size: 1050 x 627 mm Spindle taper: ISO 40 Spindle speed: 40-2000 rpm, 18 steps Feed rate X, Z-axis: 10-500 mm/min, infinitely variable Feed rate Y-axis: 5-250 mm/min, infinitely variable Rapid traverse X, Z-axis: 1.4 m/min Rapid traverse Y-axis: 0.7 m/min Arbor displacement, vertical: 100 mm Arbor feed, vertical: 0.02 / 0.03 / 0.05 / 0.08 / 0.12 / 0.2 mm/rev Arbor displacement, horizontal: 100 mm Spindle drive: 5.5 kW Power connection: 380 volts, 50 Hz, 10 kW - Swiveling control panel - Central lubrication Hsdpfjztkbcsx Agtont - Operating manual Machine dimensions L x W x H: 2.5 x 1.75 x 2.3 m Weight: approx. 4,700 kg

Condition: used, Vertical Milling Machine Droop & Rein type FS130 Hodpfx Agozw D R Sstent Travel X: 2000 mm Travel Y: 1000 mm Travel Z: 1000 mm Spindle SA 50 Sensitive spindle exit: 200 mm Rotation: from 31,5 to 1600 RPM Table size: 2400 x 1070 mm Throat depth: 950 mm Tilt head Spindle motor: 22 kW Scale HEIDENHAIN 3 axes Year of construction: 1976 New electrical panel in 2006 Voltage : 380 V Width : 3500 mm Depth : 4700 mm Total height : 4500 mm Weight : 26 T

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, HOLZ-HER EVOLUTION 7405 (2021) – Like New! Only 202 Working Hours HOLZ-HER EVOLUTION 7405 vertical CNC machining center for sale. Excellent condition, barely used, fully operational under power. Quick Specs: - Year of manufacture: 2021 Hnsdpfx Agozutd Nstot - Active milling hours (Vorschub aktiv): ONLY 202 hours! - Total machine uptime: 1,860 hours - Serial No: 1195/2-109 - Made in Austria (CE) Features & Software: - HOLZ-HER CAMPUS / HOPS active / Betternest - Vacuum-free automatic panel clamping system - Complete 4-side routing, drilling, and grooving - Compact vertical design (under 5 m² footprint)

Condition: used, Year of construction: 1996, Cutting length: 5300 mm Cutting height: 2100 mm Cutting depth: 60 mm Scoring saw: no Feed: manual Horizontal cut display: scale Vertical cut display: scale Saw blade diameter: 300 mm Swing-away material support: yes Saw blade speed: approx. 4000 rpm Motor power: 3 kW Hodpfjuix Eyjx Agtjnt Machine length: 6500 mm Machine depth: 1500 mm Machine height: 3000 mm Weight: 800 kg

Condition: used, Year of construction: 1999, Cutting length: 5300 mm Cutting height: 2100 mm Cutting depth: 80 mm Scoring unit: no Feed: manual Horizontal cut display: scale Vertical cut display: scale Saw blade diameter: 300 mm Swiveling material support: yes Saw blade speed: approx. 4000 rpm Motor power: 4 kW Machine length: 6500 mm Hnodpfxev R U I Sj Agtjt Machine depth: 1500 mm Machine height: 2800 mm Weight: 800 kg

Condition: like new (used), functionality: fully functional, Year of construction: 2017, operating hours: 48 h, VERTICAL HYDRAULIC BALER MG 50 TVE Vertical hydraulic baler, model MG 50 T.V.E. 1200x1100x3500h, for compacting and baling soft material scraps such as fiberglass mats or similar. The MG 50 T.V.E. model features a fully enclosed compaction chamber, with both the material loading door and bale extraction door capable of opening. The control panel is mounted on the side of the unit with integrated controls, and is equipped with a 10-meter extension cable to allow for placement away from the baler. The pressing plate is operated by a single cylinder with a 2700 mm stroke and is guided by four lateral sliding rails. Material is loaded from the front. The compaction cycle (press descent and ascent) is automatically activated via push button. - For transportation, the machine is manufactured in three parts: one section is 2000 mm high, one approximately 2300 mm high, and the cylinder, which will be assembled on-site. - Bale tying is preset; it is done manually with the doors open. Via slots in the rear of the chamber, tying can be completed with standard pre-cut wire or strapping. - Bale extraction is carried out by forklift, with special channels at the base for the insertion of fork tines. - The bale extraction door is closed via a handwheel, ensuring safe operation even with elastic materials. A safety microswitch ensures the door is securely closed before pressing. The top loading door features a hydraulic lever closure with machine-mounted controls. Hedpfxeyzr Nmo Agtent - The baler can be placed flush against a wall; only front space is required for material loading and bale removal. - The hydraulic circuit is equipped with an anti-fall safety blocking valve for the press plate. - The machine must be anchored to the floor and is placed above a wash liquid collection tray. • Brand / Model: MG 50 T.V.E. 1200X1100X3500H • Pressing force: 50 tons • Pressing pressure on material: 3.8 kg/cm² • Operating pressure: 220 bar • Bale size: mm 1250 x 1150, variable height (min 800 mm, max 1700 mm) • Bale weight: 400–1000 kg, depending on material • Press chamber: mm 1200 x 1100 x 3500 h • Loading opening: mm 1200 x 1800 h • Compactor stroke: 2700 mm, single cylinder • Operation: Automatic by push button • Cycle time (automatic): 130 seconds • Manual ties: No. 5 • Bale ejection: Removal by forklift • Hydraulic power unit: Integrated into press • Motor power: 10 HP – 7.5 kW • Power supply: 380 Volt – 50 Hz • Overall dimensions: mm 2000 x 3500 x 7150 h • Noise level: 78 dB • Press weight: approx. 5000 kg • Certification: CE Condition: • Used hydraulic baler in excellent condition, sold as seen and approved.

Condition: not inspected (used), JAFO FYN 50 NB – CNC Vertical Milling Machine For sale is a CNC vertical milling machine from JAFO, model FYN 50 NB, year of manufacture 1988. The machine is fully operational and ideal for precise milling operations on workpieces up to 700 kg including clamping device. ⸻ Technical Data • Travel (X/Y/Z): 800 × 500 × 500 mm • Table working area: 500 × 1,400 mm • Number of T-slots: 7 • Slot width: 18 mm • Slot pitch: 63 mm • Max. longitudinal table travel: 800 mm • Max. vertical knee travel: 500 mm • Max. transverse spindle head travel: 500 mm • Feed rate: stepless 0–4,000 mm/min • Spindle taper: ISO 50 • Head swivel angle: ±45° • Distance spindle axis to vertical guides: max. 590/90 mm • Spindle speed: 56–1,800 rpm • Rapid traverse: 4,000 mm/min • Spindle drive motor power: 5.5 kW • Operating voltage: 380 V, control voltage 24 V • Total power consumption: 10 kW • Dimensions (L×W×H): 2,080 × 1,700 × 2,260 mm • Total weight incl. hydraulic unit: 4.5 t ⸻ Equipment & Features • Vertical, swivelling milling spindle on a transversely adjustable ram • Hydromechanical tool clamping system • Separate feed drives with DC motors and permanent magnets • Power transmission via toothed belt to preloaded ball screws • Automatic lubrication system for spindle drive and guideways • Hydraulic counterweight for the knee • Manual adjustment via electronic handwheel • Heidenhain control at the swivelling control panel, control cabinet mounted on the machine base • Documentation and operating manual included • Additional images and videos available upon request ⸻ The machine is immediately ready for operation. • Inspection possible at any time • Europe-wide transport available ⸻ Contact Maschinenhandel Nord Gerstenstraße 2 17034 Neubrandenburg 📞 All prices net plus VAT. Subject to modifications and errors. Hodsxk Tzgspfx Agtsnt

Year of construction: 2003, condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 09103, COMANDULLI Model EDILUX 7+4 DX • Belt running direction: RIGHT to LEFT, year of manufacture 2003 #09103 • 7 end-face grinding supports, 130 & 150 mm, with vertical oscillation • 2 pneumatic lower supports / 2 upper supports • Water groove milling support, manual height and side adjustment • Coating support, manual height adjustment • Separate control panel on a swivel arm • Table extension console • Water trough • Machine footprint approx.: 440 x 180 cm • Infeed area approx.: 190 x 60 cm • Outfeed area approx.: 150 x 60 cm Hjdpfx Ajzz Nfcsgtsnt Price: • EXW at the machine location, plus VAT, subject to prior sale, no tools included, attachments & accessories in the pictures are not included with the machine/scope of supply. Payment terms • 50% down payment upon order confirmation, 50% payment upon notification of shipping readiness Warranty • Machine sold “as is”, excluding any warranty claims Inspection possibility • at the operating site near Cottbus Availability • after delivery of the new machine in December 2026 / January 2027

Condition: good (used), functionality: fully functional, Technical specifications: Manufacturer: Striebig Type: Standard II Plus 6220A Year of manufacture: 5.92 Feed: manual Design: automatically adjustable aluminum slatted frame Saw carriage lock: manual Saw unit plunge-cut: manual Swivel adjustment from 0 to 90°: manual Hnsdpfowdig Iox Agtst Motor power: 4.4 kW Cutting area: 5600 × 2200 × 80 mm Speed: 4750 rpm Saw blade diameter: 300 mm Space required: L × H × W 6400 × 2900 × 1600 Condition: good (all ball bearings new, red plastic strips new) Location: Warehouse Installation: Wall-mounted, freestanding A forklift is available for loading. Installation and delivery available upon request.

Condition: good (used), functionality: fully functional, Keyence VHX 700F Measurement Microscope in fully functional condition. - Base unit VHX 700F - Stand VHX-J20 - Objective lens VH-Z20R - Reference object (calibrated glass scale) - User manual Camera Scanning method: Progressive Image sensor: 1/1.8-inch, 2.11 megapixel CCD sensor Total pixels: 1688 (H) x 1248 (V) Effective pixels: 1628 (H) x 1236 (V) Usable pixels: 1600 (H) x 1200 (V) Frame rate: Selectable 15 fps and 28 fps Resolution: 2 megapixels, 1600 (H) x 1200 (V), approx. 1000 TV lines Gain: AUTO, NORMAL, PRESET Hnedpsw Ah Axofx Agtjt Electronic shutter: AUTO, MANUAL, OFF, 1/15, 1/30, 1/60, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/5000, 1/9000, 1/19000 Supercharge shutter: 0.2 seconds to 17 seconds adjustable in 0.1 second increments White balance: Auto, Manual, One-touch setting, Preset (2700 K, 3200 K, 5600 K, 9000 K) Back focus adjustment: Not required LCD Monitor: 17-inch color LCD (TFT)*1 Panel size: 365.76 (H) x 228.6 (W) mm*1 Pixel pitch: 0.1905 (H) x 0.1905 (W) mm*1 Number of pixels: 1920 (H) x 1200 (W) (WUXGA)*1 Display colors: Approx. 16,770,000 colors *2*1 Brightness: 270 cd/m² (typical)*1 Contrast ratio: 450:1 (typical)*1 Viewing angle: ±80° (typical, horizontal), ±70° (typical, vertical)*1 Hard Drive 500 GB (including 80 GB reserve capacity) Approx. 2.1 million images (with compression of a 2-megapixel image) or approx. 70,000 images (if 2-megapixel images are uncompressed) Image format JPEG/HD Photo (compressed), TIFF (uncompressed) Viewable image size: 1600 pixels (H) x 1200 pixels (V) Light source: Lamp 12 V, 100 W, halogen lamp Video output: Output format DVI-I, 1920 x 1200 pixels Output Scan frequency

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, input voltage: 400 V, input current: 44 A, input frequency: 50 Hz, number of slots in tool magazine: 23, total length: 10,000 mm, total width: 4,100 mm, Equipment: CE marking, documentation/manual, HOMAG BMG 311 Venture 316 XXL – 5-Axis CNC Machining Centre Lightly used and maintained in excellent condition, this HOMAG BMG 311 Venture 316 XXL is almost like new. The machine is equipped with a powerful 5-axis machining unit, 23-position tool changer, multiple vertical and horizontal drilling heads, grooving saw blade, and extensive routing and drilling capabilities. It is suitable for complex furniture, cabinet, door, panel, and solid-wood machining applications. Thanks to its versatile configuration, the machine can perform routing, drilling, sawing, grooving, and angled machining operations in a single setup. Hnedpfxezp Ih Eo Agtet A highly capable and well-equipped CNC machining centre with very low operating hours, ready for immediate production.

Condition: used, Year of construction: 1992, Second-hand machine Year of manufacture: 1992 Features and technical specifications: Hedpfxjzk Nnve Agtsnt - Saw blade diameter 300 mm - Saw blade speed 4,750 rpm - Motor power 4.5 kW - Motor speed 2880 rpm - Max. cutting width: 5,300 mm - max. cutting height: 2100 mm - max. panel height: 2200 mm - max. machining thickness: 80 mm - with small-parts support - Dimensions: approx. 6,500 x 1,300 x 2,880 mm - Weight: approx. 900 kg Availability: at short notice Location: 63934 Röllbach

Condition: excellent (used), C.N.C. WORKING CENTER 3 axes (X-Y-Z) Hnodpfjzza Sgsx Agtjt Vertical position of the panel (workpiece) Movable panel (workpiece), movable working head Numerical Control/Software MAESTRO Safety cabin (enclosure) of the working head No. 2 Workpieces fixing clamps (for the panels introduction in the working area Minimum workpieces dimensions (X - Y - Z) mm 200 x 50 x 8 Maximum workpieces dimensions (X - Y - Z) mm 3050 x 1300 x 95 WORKING GROUPS: No. 1 Drilling head (5-sided with Ro.Ax. roto-axial technology) F31LTC with spindles: - No. 24 Independent vertical boring spindles - No. 11 Independent horizontal boring spindles (6 in X + 4 in Y) No. 1 Circular Grooving Saw (on X axis) dia. (mm) 125 No. 1 Vertical electro-spindle (HKS63) power Kw 6,6 Automatic Tools Changing System - Tools storage plate (No. 6 folds-positions) OPTIONAL: Panel loading robot + Robot for unloading machined panels

Condition: used, Year of construction: 1997, functionality: fully functional, Brand: LARENN - France Hnsdpfxoydpx As Agtst Model: 250BEL Manual vertical panel saw for cutting wood panels, plywood, furniture, composite materials. Technical features: - Extremely stable motor column - Compact, vibration-free saw group - Integrated strip stop for repetitive cuts - Easy blade unit rotation - Support for small panels - Reference stops Technical data: - Cutting dimensions: 5,300 x 2,200 mm - Cutting depth: 60 mm - Blade speed: 5,400 rpm - Motor power: 3 kW (4 HP) - Suction diameter: 100 mm - Overall assembled machine dimensions: 6,400 x 2,950 mm - Weight: 895 kg Also available: SAMCO circular saw with scorer and tilting blade up to 45° Cutting length on carriage: 1,600 mm Cutting height: 100 mm PRICE: 1,800 euros

Condition: used, Year of construction: 1991, Used Machine Year of Manufacture: 1991 Features and Technical Specifications: - Fully automatic, floor-standing Hnjdpjzk Nx Ijfx Agtet - Cutting area: 5,300 x 2,200 mm - Saw blade diameter: 300 mm - Control system for vertical and horizontal cuts - With aluminum folding stops and aluminum center support - With SUPER-CUT scoring device - Motor: 3 kW - 400 V Availability: available shortly Location: 63934 Röllbach

Condition: used, Year of construction: 1994, Cutting length 5300 mm, cutting height 2200 mm, cutting height 80 mm, manual feed, measuring system: scale, free-standing supports, rated current 21 A. Storage location: Nattheim. Hjdjytrhrspfx Agtsnt

Condition: not inspected (used), Year of construction: 1998, machine/vehicle number: 13189, functionality: limited functionality, VERTICAL PANEL SAW WITH ELECTRIC MOVEMENTS & DIGITAL DISPLAYS FOR CUTS Brand: GMC MACCHINE SRL Model Type: KGS 660S Serial No.: 13189 Year: 1998 (Photos taken prior to any potential refurbishment, machine offered as-is) MACHINING CAPACITIES: - Max. horizontal cutting length: 5300 mm - Max. horizontal cutting height: 2100 mm - Max. vertical cutting height: 2200 mm - Max. cutting depth: 80 mm OTHER FEATURES: - Power supply: 380V Three-phase+T - Installed power: 7.5 kW - Main motor power: 4.4 kW (6 hp) - Saw blade speed: 5,200 rpm Pneumatic blade feed - Carbide-tipped saw blade: Ø 300 mm, bore Ø 30 mm - Welded steel frame, PVC slat frame with automatic retraction via pneumatic cylinders - Fully lengthwise pneumatic retractable intermediate support with 2 adjustable and retractable stops - Retractable rollers for panel handling - Pneumatic locking of the saw carriage - 8 bar pneumatic feed - Digital display for cuts - Complete extraction system DPS Back cover spans the entire rear of the machine Lower longitudinal channel for sawdust collection Multiple extraction points in the lower section Extraction port: Ø100 mm Hodpfx Agou R Ulhstsnt - Support for floor-mounted installation - CE Marked Total space required when mounted on supports: 6300 x 1600 x 3040 mm (includes operator and maintenance area) Transport dimensions, 2 packages: . 1 frame 6300 x 860 x h.2620 mm . 1 pallet 3150 x 1000 x 1000 mm Total weight: 1250 kg Please contact us for supply of consumables, accessories, and/or extraction systems. Offered as a lot, without refurbishment or warranty. Ex works price, excluding VAT. Transport and services on request.

Condition: like new (used), Year of construction: 2012, operating hours: 4,541 h, functionality: fully functional, machine/vehicle number: SN:79004, travel distance X-axis: 1,035 mm, travel distance Y-axis: 540 mm, travel distance Z-axis: 620 mm, feed rate X-axis: 35 m/min, feed rate Y-axis: 35 m/min, feed rate Z-axis: 35 m/min, nominal power (apparent): 14 kVA, torque: 96 Nm, controller manufacturer: Heidenhain, controller model: TNC 620, workpiece weight (max.): 1,000 kg, total height: 2,850 mm, total length: 2,500 mm, total width: 2,910 mm, table width: 540 mm, table length: 1,200 mm, table load: 1,000 kg, rotational speed (min.): 10 rpm, rotational speed (max.): 10,000 rpm, overall weight: 5,100 kg, spindle speed (min.): 10 rpm, spindle speed (max.): 10,000 rpm, operating hours of spindle: 4,541 h, coolant supply: 3 bar, distance table to spindle center: 150 mm, spindle motor power: 1,400 W, number of spindles: 1, number of slots in tool magazine: 24, input voltage: 400 V, type of input current: AC, Equipment: documentation/manual, rotational speed infinitely variable, The machine is in excellent condition and is almost like new. It has been used almost exclusively for aluminum prototype construction. Disassembly upon request. Here are all the details from the technical description. SN: 79004, Year: 2012 Commissioned: February 2014 UVA 1035 PLUS Heidenhain Vertical machining center with HEIDENHAIN TNC 620 control, new price, after discount, net 79,900.00 Standard equipment of the UVA 1035 PLUS as ex works: - Computer-optimized, vibration-damping machine base made of gray cast iron - Large linear guides with 45 mm width in all axes Description Overall price - CNC control Heidenhain TNC 620 - Ergonomically arranged control panel with electronic handwheel - Digital Heidenhain drives in all axes - Ball screws (supported on both sides and preloaded) diameter 40 mm Hnjdpfxszzrmpe Agtot - Pitch 12 mm in all axes - Rapid traverse rate 35 m/min in all axes - Guide covers (telescopic) in all axes - Spindle taper SK 40 DIN 69871 A - Tool pull stud DIN 69872 - Main drive with 13 kW, 96 Nm - Main spindle speed range 10 - 10,000 1/min - Preparation for internal cooling 20 bar - Tool changer (dual-arm gripper) with 24 storage locations - Work area full protection with large viewing doors and 2 work area lights - Large coolant tank with 380 l capacity - 2 chip drawers for easy and quick manual chip disposal - Flood coolant 3 bar / 60 l/min - Chip flushing in the work area - Spray gun for cleaning the inside of the machine - Signal light 2-color - Festo pneumatic system - Automatic central lubrication in all axes - All axes: Positioning accuracy +/- 0.005 mm - Repeat accuracy +/- 0.003 mm (ISO 230-3) - Painting in light gray (RAL 7035) and blue gray (RAL 7031) - Documentation - UVA Unverzagt machining centers comply with the CE standard UVA 1035 PLUS Heidenhain Technical details of the machine Travel ranges Travel X-axis [mm] 1,035 Travel Y-axis [mm] 540 Travel Z-axis [mm] 620 Distance spindle bottom edge to table [mm] 150 - 770 Work table Table length [mm] 1,200 Table width [mm] 540 Number of T-slots 5 Slot width [mm] 18 Table load max. [kg] 1,000 Feed Rapid traverse X and Y axis [m/min] 35 Rapid traverse Z axis [m/min] 35 Diameter ball screw X and Y axis [mm] 40 Diameter ball screw Z axis [mm] 40 Main spindle Main spindle speed max. [1/min] 10,000 Main spindle power [S6-40% ED kW] 14 Main spindle torque max. [Nm] [S6-25%] 96 Tool holder SK 40 Tool magazine Number of tool magazine positions 24 Tool change time [sec] 2.8 max. tool diameter [mm] 80 max. tool length [mm] 300 max. tool weight [kg] 7 Coolant system Volume coolant tank [l] 380 Through coolant pressure [bar] 3 Through coolant [l/min] 60 Internal coolant supply pressure [bar] 20 (optional) Air blow external yes Basic machine data Installation area width [mm] 2,910 Installation area depth [mm] 2,500 Machine height [mm] 2,850 Weight of the basic machine [kg] 5,100 Electrical connection power [kVA] 30 Required pneumatic connection [bar] 6 Required compressed air [l/min] 260 Control Manufacturer Heidenhain Control type TNC 620
