Used Surface Grinder for sale (7,996)

Condition: like new (used), Year of construction: 2017, operating hours: 59 h, functionality: fully functional, grinding length: 400 mm, grinding width: 200 mm, feed length X-axis: 510 mm, feed length Z-axis: 220 mm, feed rate X-axis: 20 m/min, grinding wheel diameter: 205 mm, distance table to spindle center: 357 mm, table load: 120 kg, type of input current: three-phase, grinding wheel width: 16 mm, spindle speed (max.): 3,600 rpm, spindle speed (min.): 1,000 rpm, overall weight: 2,100 kg, grinding spindle motor power: 2,200 W, grinding wheel speed: 3,600 rpm, input voltage: 400 V, Equipment: documentation/manual, TECHNICAL CHARACTERISTICS: Year of manufacturing: 2017 Colour touchscreen: Yes Maximum grinding lenght x width: 400 x 200 [mm] Stroke X axis (table movement): 510 [mm] Min. Stroke speed X axis: 100 [mm/min] Max. Stroke speed X axis: 20000 [mm/min] Z axis travel (transverse movement): 220 [mm] Min. distance spindle nose / table: 22.5 [mm] Max. distance spindle nose / table: 357.5 [mm] Max. load on table: 120 [Kg] Grinding wheel min. speed: 1000 [rpm] Grinding wheel max. speed: 3600 [rpm] Grinding spindle motor power: 2.2 [kW] Max. diameter grinding wheel: 205 [mm] Max. grinding wheel width: 16 [mm] Min. grinding wheel width: 6 [mm] Grinding wheel bore: 31.75 [mm] Number of running hours: 59 [h] Supply voltage: 400 [V] Total power required: 11 [kVA] Weight : 2100 [Kg] INCLUDED EQUIPMENT: x1 150 [L] coolant tank FB1/R with papertape filtration unit FB1 x1 BRAILLON electro-permanent magnetic chuck type EPEFINE 2 x1 BRAILLON magnetic chuck remote control, microprocessor-based, type T10 x5 grinding wheel flanges x1 oil chiller x1 transformer x2 service keys x1 balancing shaft x1 set of axis-brackets for transport STANDARD CONVERSATIONAL PROGRAMMING MODE: Straight and angular dressing (standard) Surface grinding, multiple plunge grinding, and face grinding (standard) INCLUDED ISO PROFILING: Wheel profiling Contour machining of workpiece Full functionality for V-shape and freeform programming on the grinding wheel, and ISO contouring on the workpiece. Precise positioning integrated: +/- 1 [μm] Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Similar machine to brands like Jones & Shipman, Jung, Favretto, Blohm, Studer. Also see cylindrical grinder, lathe, machining center, milling machine. Bjdpow Hf Hisfx Abbelc

Condition: used, Guideway and surface grinding machine WMW FRITZ HECKERT Aschersleben type SZ 1000 x 1250 x 3000 / 344 make no. 13.2236.2 year of construction 1989 nominal grinding area 3000 x 1250 mm table clamping area 3240 x 1000 mm grinding length max. 3300 mm Machining width 1250 mm Bljdpfshv A A Dex Abbjc Machining height 1250 mm grinding wheel diameter (surface grinding support) max. 600 mm grinding wheel width (flat grinding support) max. 100 mm grinding wheel diameter (swivel support) max. 450 mm Mains connection 400 Volt, 50 Hz - grinding support swiveling, drive power 16,5 kW, infinitely variable speed - grinding support for surface grinding, drive power 15 kW, infinitely variable speed - new electrical control, based on SIEMENS S7 from year 2001 - new electric control cabinet beside, year of construction 2001 - infinitely variable grinding wheel speed at both grinding supports - swiveling wheelhead for guideway and profile grinding - swivel-mounted and height-adjustable control panel - coolant system adjacent - Hydraulic system adjacent - oil circulation lubrication adjacent - Various grinding wheels and holders space requirement complete L x W x H 11900 x 7700 x 4600 mm weight 45 ton. very good condition

Condition: refurbished (used), grinding length: 600 mm, grinding width: 200 mm, grinding length 600 mm Bljdpoxal Hyjfx Abboc grinding width 200 mm electromagnetic chuck 450×175 mm X-travel 660 mm Z-travel 225 mm grinding wheel size 250x25x51 mm Control Jung TouchScreen weight approx. 3000 kg

Condition: good (used), functionality: fully functional, table dimensions: 830mm x 200mm magnet dimensions: 600mm x 200mm grinding wheel dimensions: 250mm stroke x:720mm y:250mm z:320mm automatic feeds on x and y axes z-axis height electrically adjustable height:1600mm x length:1800mm x depth 1500mm weight: 1700kg Financial information VAT/margin: Margin: The displayed price includes VAT (VAT not deductible for businesses) Bodpfsxg Td Tjx Abbolc

Condition: used, Surface grinding machine BLOHM type HFS 6 make no.: 10493 year of construction 1973 Electro magnetic clamping plate 600 x 300 mm grinding length 600 mm grinding width 400 mm table longitudinal movement max. 650 mm transversal movement 350 mm distance spindle center - table surface max. 600 mm distance spindle center - magnetic plate max. 517 mm Clamping surface table 1020 x 300 mm grinding wheel diameter 300 mm grinding wheel width 50 mm grinding wheel bore 76 mm table longitudinal feed 2-30 m/min infinitely variable table cross feed 2-65 mm stepless electric cross feed 3 m/min vertical feed 0,001 - 0,020 mm per infeed pulse vertical feed 0,250 m/min grinding wheel speed 1400 / 2800 rpm. Motor power hydraulic pump 2,2 kW Motor power grinding spindle 5 / 6 kW Mains connection 380 Volt, 50 Hz. Total power 11 kW - automatic depth adjustment Bledjd Hbafepfx Abbjc - hydraulic longitudinal table movement - grinding wheel dresser on the headstock - electromagnetic plate height 83 mm - coolant system adjacent, with magnetic filter in filter housing - grinding spindle circulating lubrication - adjacent control cabinet (800 x 500 mm) - swiveling control panel - operating instructions and spare parts manual space requirement L x W x H 3000 x 2200 x 2100 mm weight surface grinding machine 3000 kg weight switch cabinet 200 kg good condition

Condition: good (used), Year of construction: 1998, feed length X-axis: 1,180 mm, feed length Y-axis: 644 mm, feed length Z-axis: 480 mm, table length: 1,000 mm, table load: 1,000 kg, table width: 595 mm, power: 15 kW (20.39 HP), X - Travel: 1180mm Y - Travel: 644mm Z - Travel: 480mm Table Length: 1000mm Table Width: 595mm Table load: 1000 KG Feed rate X-Axis:30000mm/min. Feed rate Z-Axis:30000mm/min. Power: 15kW Bsdpfx Abowrx Scebolc Length: 4800mm Width: 2500mm Height: 2700mm Weight: 8000kg

Condition: used, Surface grinder ABAWERK FF635 Bledpexbt Hdofx Abboc

Condition: used, SURFACE GRINDER MAGNETIC Blsdpfe Dv Nuex Abbjc Down table size: 1100x400mm

Condition: excellent (used), Year of construction: 1969, functionality: fully functional, For sale: excellent UMC tool grinder Bodpfjwum Sijx Abbslc The machine is fully operational and in very good condition.

Condition: excellent (used), Year of construction: 1988, Magnet table 1.800 x 450mm, cross travel 580mm. New CNC Fagor 8037M 2018. Paper filter with magnet separator Blodpfxetqt Ids Abbec

Condition: as good as new (ex-display), functionality: fully functional, Surface grinder. New condition Taiwanese machine. The machine run a few hours, just it was tested. Standard accessories: Grinding wheel Wheel flange Flange extractor Wheel balancing arbor Wheel balancing base Wheel dresser with diamond Leveling screw & plates Tool box & tools Manual Optional accessories: 3 HP Spindle motor (siemen brand) instead of 2 HP Longitudinal by sensor & solenoid valve Electro magnetic chuck, 150 x 450 mm (Fine pole) Coolant system (Capacity 52L, 1/8 HP) Auto crossing stroke adjustment Crisscross grinding Power rapid up/down system (AC motor, 1/5 HP) Bedjm Tv U Tjpfx Abbslc Wheel flange (extra) Back water splash shield Led lamp instead of halogen lamp Spindle motor inverter 3 HP (Taiwan made) Digital readout (lu, cross: 300 mm + vertical: 450 mm; 2 axes monitor) Auto. demagnetizer for chuck 5A If you are interested, please contact me! More machines for sale: Berco, Comec, Sunnen, Carmec, Kwik-Way, Serdi, PEG Valve grinder, head and block resurfacer, valve seat milling, pressure tester, parts washer machines

Condition: excellent (used), Type 1026 Max. longitudinal movement 700 mm Max. transverse movement 310 mm Table size 600 x 250 mm Blsdpfjvzk Hfsx Abbsc Max. grinding capacity 650 x 300 mm Main motor power 5.5 HP

Condition: new, IG 280 SD Specifications Motors Grinding Spindle Motor 20HP, 200 - 2330RPM Rotary Table Motor 1HP, 5 - 70RPM Servo Column Motor 2KW Coolant Pump 3/4HP, 45GPM Table Diameter 24" Table Features Thru-spindle vacuum/pressure feed Variable strength 3/4" fine pole electromagnetic chuck Custom Table Options 18" diameter T-slot or drilled for customer fixtures Contact a DCM Technical Specialist for other custom table & fixturing options Capacity Max Swing Diameter 27" Max Part Height 11" with a segmented wheel 12" with a 2A2T wheel Grinding Wheel Options Segmented Wheel Hub Kits 12" or 15" diameter 2A2T Ring Wheel Hub 12" diameter 6A2 Wheel Hub 8" diameter Cortland Chuck 12" or 15" diameter Ask a DCM Technical Specialist about our wide variety of available abrasives Feed System Servo driven Z-axis with precision ballscrew and encoder Feedrate variable from 0.0006 IPM to 0.1000 IPM AC motor driven Y-axis Electrical Requirements Blodpfx Abeubbp Soboc 230V, 50/60Hz, 3 phase Consult DCM Technical Specialist regarding operation on other voltages Dimensions 80" wide, 68" deep, 90" high Weight Machine & Swarf System: 5,480LBS. Electrical Box: 960LBS. IG 280 SD Features • 24" variable strength electromagnetic chuck with auto demag cycle • 20HP variable speed grinding spindle motor • Thru-spindle vacuum/pressure feed • Integral air mist collection and coolant flow systems for clean and consistent grinding • Programmable touch screen HMI controls • Manual pulse generator for precise Z-axis positioning • Internal memory for saving grind process recipes to aid in quick changeover • Password protection and operator lock-out features • Automatic routine maintenance reminders • 76" x 64" Footprint

Condition: used, TECHNICAL DETAILS - Magnetic table : 400 x 150 [mm] Bodpfjvq Sf Ijx Abbslc - Automatic plunge - Power : ~5 [KW] EQUIPMENT - Hydraulical unit - Coolant system with paper filter

Condition: excellent (used), functionality: fully functional, machine/vehicle number: 1761-1700, 457 x 152mm capacity. Equipped with magnetic chuck, power rise and fall to wheel head, table guard, coolant system, and dust extraction. SPECIFICATION Jones & Shipman Model 540P Working Surface of table 457 x 152mm Longitudinal traverse of table, hand and hydraulic 483mm Total cross traverse of table, hand and hydraulic 168mm Floor to table height 1035mm Table traverse speed range per min 1.5 – 18m Cross feed range per stroke at each reversal 0.178 – 1.78mm Micrometer cross feed graduated in Vertical feed adjustment in increments of 0.002mm Blodpjnxi Uuefx Abboc Vertical movement of wheelhead (max) 280mm Wheel spindle center to table (min) 50mm Size of grinding wheel 180 x 13 x 31.75mm bore Speed of wheel 2880rpm Wheelhead motor 1.5kW Hydraulic pump motor 0.55kW Machine in Imperial execution MACHINE EQUIPPED WITH Magnetic chuck Power rise and fall to wheel head Table guard Wheel guard Coolant System Dust extraction

Condition: excellent (used), Year of construction: 1984, functionality: fully functional, machine/vehicle number: BO 94392, A familair machine in any toolroom, this Jones and Shipman 540P is equipped with a 6″ x 18″ magnetic chuck, power rise and fall, coolant system and dust extraction. A toolroom institution: USED Jones & Shipman Model 540P Horizontal Spindle Surface Grinding Machine Specification Working Surface of the table 457 x 152mm Longitudinal traverse of table, hand and hydraulic 483mm Total cross traverse of table, hand and hydraulic 168mm Floor-to-table height 1035mm Table traverse speed range per min 1.5 – 18m Cross-feed range per stroke at each reversal 0.178 – 1.78mm Micrometer cross feed graduated in Vertical feed adjustment in increments of 0.002mm Vertical movement of wheelhead (max) 280mm Wheel spindle centre to table (min) 50mm Size of grinding wheel 180 x 13 x 31.75mm bore Speed of wheel 3000rpm Wheelhead motor 1.5kW Hydraulic pump motor 0.55kW Bledpfxjnxi R Uo Abbec Machine in Imperial execution Machine equipped with Magnetic chuck Power rise and fall to wheel head Table guard Wheel guard Coolant System Dust extraction Lighting

Condition: used, Surface grinder LGB 10040 Bjdpfx Aou Hacwebbelc

Condition: ready for operation (used), OMN RV500 bowl grinder Blsdpfxourm Ucj Abboc Transport dimensions: 100x70x185 cm (LxWxH) Table dimensions: 160x300 mm Location: Hamont-Achel, Belgium The seller is not liable for typographical or data transmission errors. The machine is in accordance with its age in terms of appearance, technology and wear; used machines are sold without warranty. The price shown does not include VAT OMN RV500 cup grinder Transport dimensions: 100x70x185 cm (LxWxH) Table dimensions: 160x300 mm Location: Hamont-Achel, Belgium The seller is not liable for typing or data transmission errors. The machine is in appearance, technology and wear in accordance with its age; used machines are sold without warranty. The price shown is exclusive of VAT OMN RV500 Schüsselmühle Transport dimensions: 100x70x185 cm (LxWxH) Tischabmessungen: 160x300 mm Standort: Hamont-Achel, Belgium Der Verkäufer haftet nicht für Tipp- oder Datenübertragungsfehler. Die Maschine ist optisch, technisch und gebrauchstechnisch ihrem Alter entsprechend; Gebrauchtmaschinen werden ohne Gewährleistung verkauft. Der angezeigte Preis versteht sich exklusive Mehrwertsteuer

Condition: new, Perfectly built to optimise grinding and accuracy efficiency. Auto cross with hydraulic longitudinal. Manual vertical axis. Table longitudinal travel by sensor and solenoid valve - continuous lubrication. Specification Perfect D4080AH Saddle type surface grinder Table size 400 x 800mm Max. Grinding surface 400 x 800mm Max. distance centre of spindle to table 500mm (Option: 650mm) Table speed 5 ~ 25m/min Table guideway V & Flat way Auto. Cross feed increment approx. 0.5mm ~ 20mm Rapid power cross feed approx. 1100mm/min (60Hz) 900mm/min (50Hz) Cross feed on hand wheel 1 rev 5mm 1 gra 0.02mm Rapid power head elevation 550mm/min (60Hz) 450mm/min (50Hz) Vertical feed with MPG 1 rev 2mm 1 gra 0.01mm Auto down feed (Option) 0.001mm ~ 0.999mm/time Wheel speed 60Hz/50Hz 1750rpm (60Hz) 1450rpm (50Hz) Bsdpfxsnzh Uio Abbslc Wheel dimensions 406 x 50 x 127mm Spindle motor 5HP Hydraulic pump motor 2HP Auto. Cross feed motor 1/5HP Standard Equipment Grinding wheel and wheel flange Flange extractor Wheel balancing arbor and base Wheel dresser with diamond Levelling screws and plates Tool box and tools Working light Manual AD5 Automatic downfeed control Magnetic chuck and demagnetiser Coolant system with paper filter

Condition: new, functionality: fully functional, NEW Perfect DT Series of machines with the touch screen display and easy to use interface. Automatic NC controlled downfeed operation with spark out. Plunge grinding, criss-cross grinding and surface grinding. 300 x 600mm grinding capacity 500mm spindle centre to table 355 x 38 x 127mm grinding wheel Fine pole mag chuck + demagnetiser Coolant system with paper filter and magnetic seperator NC Auto downfeed control system LCD touch screen control panel with easy to use graphical interface Criss-cross grinding function Auto criss stroke adjustment via the touch screen control Bledponzh T Nofx Abbjc Ballscrew and microfeed for the cross feed Stepless variable hydraulic system Quantitive lubrication system Back water splash shield

Condition: used, TECHNICAL DETAILS - Useful table area: 2100 x 460 [mm] - Table travel: 2300 [mm] - Max. grinding height: 600 [mm] - Grinding wheel diameter: 510 [mm] - Drive power: 36.8 [kW] EQUIPMENT - Coolant tank : 750 [l] - Magnetic tray Blsdsu Hafropfx Abbec

Condition: new, Year of construction: 2025, Grinding area 1000 x 450 mm, rotary table diameter 1000 mm, grinding wheel 400 x 100 x 127 mm, spindle power 11 KW, magnetic clamping plate diameter 1000 mm, coolant system with paper belt filter, user-friendly operation with Mitsubishi PLC control, alternatively SIEMENS 828 CNC control, new machine, delivery time approx. 30 weeks. Financing / leasing, no problem, we would be happy to make you an offer! Bjdpfxoh I Tz Se Abbolc

Condition: refurbished (used), Year of construction: 2009, functionality: fully functional, grinding length: 1,000 mm, grinding width: 550 mm, overall weight: 2,500 kg, Equipment: documentation/manual, rotational speed infinitely variable, Hydraulic surface grinding machine Renato Scarpini model RS 1000x550, used, fully overhauled, variable wheel speed, variable table speed, total weight approx. 2500 kg, equipped with magnetic chuck, complete with manual. Bedowu Rwvopfx Abbolc

Condition: new, functionality: fully functional, IG 482 SD Specifications Motors Grinding Spindle Motor 50HP, 200 - 1180RPM Rotary Table Motor 3HP, 5 - 70RPM Servo Column Motor 5KW Coolant Pump 3/4HP, 45GPM Table Diameter 48" Table Features Thru-spindle vacuum/pressure feed Variable strength 3/4" fine pole electromagnetic chuck Contact a DCM Technical Specialist for custom table & fixturing options Capacity Max Swing Diameter 52" Max Part Height 12" with grinding segments retracted 10-1/2" with a 2A2T wheel Grinding Wheel Options 2A2T Suberabrasive or Conventional Segments 26" diameter Cortland Style Hub & Segment 26" diameter Ask a DCM Technical Specialist about our wide variety of available abrasives Feed System Servo driven Z-axis with precision ballscrew and encoder Feedrate variable from 0.0006 IPM to 0.1000 IPM Servo drive X-axis for precision positioning Electrical Requirements 460V, 50/60Hz, 3 phase Consult DCM Technical Specialist regarding operation on other voltages Dimensions 137" wide, 82" deep, 88" high Weight Machine & Swarf System: 14,500lbs. (estimated) Electrical Box: 1,500lbs. (estimated) IG 482 SD FEATURES • 48” variable speed electromagnetic chuck with auto demag cycle • 50HP grinding spindle motor • Integral coolant filtration & mist collection systems Bedpfx Aboubbqiebolc • Easy to operate touchscreen controls • Mitsubishi FX5U PLC • 3 Grinding Modes - Conventional, Incremental and Grind to Height • Regrind feature allows re-running previous grind sequence without reprogramming • Continuous grind – the machine can automatically cycle through grind 1, 2 & 3 • Servo-driven precision control of both Z and X-axis with absolute home positioning • The cross slide X-axis moves with manual pulse generator • Backlash compensation on both axes • Password protection & operator lockout features • SECS/GEM Interfaced to work with 3rd party Scada type software • Password protection and operator lock-out features • Automatic routine maintenance reminders • 120" x 82" Footprint

Condition: excellent (used), For sale: professional cutter and drill bit sharpener, model PP U3. Condition: very good, complete unit ready for operation. Included in the set: • Set of grinding wheels • Adjustable angular tool holder • Workshop lamp with flexible arm • Keys and clamping elements Specifications: Bsdpfx Aboxdh Hqobslc • For sharpening cylindrical and spiral end mills • For sharpening step and cylindrical drills • Wheel linear speed up to 35 meters per second • Maximum noise level: 66 dB • Machine weight: 41 kg Solid, stable construction—ideal for precise tool machining. A reliable solution for tool rooms, CNC workshops, and machine shops.
