Used Elb for sale (48)

Condition: used, Year of construction: 1980, workpiece diameter 600 mm workpiece weight 400 kg Iiodpot Abrwefx Aa Eed workpiece height 300 mm total power requirement 35 kW weight of the machine ca. 4500 kg

Condition: good (used), Year of construction: 1989, CNC Surface Grinding Machine Machine type: Elb Schliff SWDE 012 NPC-K Year: 1989 SPECIFICATIONS max. grinding length: 1.500 mm max. grinding width: 900 mm max. Arbeitshöhe mit neuer Schleifscheibe: 800 mm max. Arbeitshöhe bei abgenutzter Scheibe: 880 mm Max. workpiece weight: 1.000 kg statisch kg Max. Table Load: 1.500 kg/m dynamisch kg Isdpfozi Antox Aa Ejid grinding wheel-Ø: 500 mm Grinding wheel width : 100 mm Table size: 1.500 x 740 mm Equipment paper band filter Nassschleifeinrichtung EL.-Geraden-Abrichtapp Querklemmung grinding spindle taper: Konus 75 magnetic plate: 1.500 x 900 kein Rundtisch

Condition: used, Year of construction: 2001, functionality: unexamined, grinding length: 800 mm, grinding width: 600 mm, grinding height: 400 mm, grinding wheel diameter: 400 mm, grinding wheel width: 100 mm, grinding spindle motor power: 20,000 W, Used surface grinding machine and profile grinding machine, year of manufacture 2001, partially overhauled in 2019, ELB-SCHLIFF model PERFEKT-FUTURE BD 8 -F- Schleicher-Unicon CNC Electro-magnetic clamping plate 500 x 300 x 4 mm, new pole pitch in 2019 Coolant system featuring combination of permanent magnet and paper band filter Iodpjywk Akefx Aa Eoid Adjustable coolant supply nozzle Grinding wheel flange

Condition: used, Year of construction: 1992, grinding length 0800 mm grinding width 500 mm workpiece height 400 mm table-size 800 x 400 mm table speeds 1 - 25 m/min Iijdpfx Aaswgnz Aj Eod cross feed autom. 0 - 60 mm/Hub grinding wheel size 400 x 100 x 127 mm grinding spindle speed 1400/2800 U/min total power requirement 10 kW voltage 380 V weight of the machine ca. 6 t Machine has cooling arrangement, auto. vert. feed, dressing arrangement and wheel flanges. Control doesn't work continuesly !!

Condition: used, Year of construction: 1982, grinding length 600 mm grinding width 350 mm table surface area 900 x 300 mm dimensions of grinding wheel 400 x 50 x 127 mm 600 x 300 mm Iijdpjzip H Ajfx Aa Eod grinding spindle speed 3000 U/min weight of the machine ca. 2,5 t dimensions of the machine ca. 3,0 x 2,0 x 2,2 m Surface grinding machine - Magnetic grinding wheel - Coolant system

Condition: used, Year of construction: 1976, grinding length: 350 mm, grinding width: 150 mm, total height: 2,150 mm, total length: 1,200 mm, total width: 1,100 mm, grinding wheel diameter: 175 mm, table length: 400 mm, table width: 150 mm, spindle speed (min.): 2,800 rpm, grinding spindle motor power: 750 W, power: 0.75 kW (1.02 HP), Surface grinding machine, SONY digital readout, manual and automatic feed, manual magnetic chuck 350x150 mm, grinding wheel dresser, coolant system Iisdpfxsxq Abij Aa Ejd

Condition: good (used), Grinding range 400x250x375mm Wheel diameter 300mm Iodpfx Ajfbx Dwsa Eeid Magnetic plate 400x250mm MARCELS MASCHINEN CH

Condition: good (used), Year of construction: 1972, functionality: fully functional, machine/vehicle number: 107240172, A well-maintained surface grinding machine, manufactured by ELB, type: SWD 15 VA 2, machine number: 107240172, year of manufacture: 1972. The control cabinet was refurbished by Stöckel. Magnetic chuck: 1500x600. Ijdpfx Aezh E Tpoa Eeid Max. grinding area: 1500x750 mm Max. grinding height: 475 mm Max. table load: 1000 kg Max. grinding wheel diameter: 500 mm

Condition: good (used), Year of construction: 2004, functionality: fully functional, grinding length: 500 mm, grinding width: 300 mm, feed length X-axis: 600 mm, feed length Y-axis: 475 mm, feed length Z-axis: 275 mm, table length: 500 mm, overall weight: 3,700 kg, - control SPS NK - electro magnet - coolant device - 3 grinding wheels, some flanges Technische Daten / technical details: Schleiflänge / grinding length 500 mm Schleifbreite / grinding width 300 mm Schleifhöhe / grinding height 475 mm Elektromagnetabmessungen / electro magnet dimensions 500x300 mm Längsachse X / table travel X 600 mm Querachse Z / cross travel Z 270 mm Vertikalachse Y / vertical travel Y 475 mm Drehzahl Schleifscheibe / speed of grinding wheel 1440/2900 UpM / rpm Schleifscheibe / grinding wheel 300x50x76,2 mm Antriebsleistung Schleifspindel / drive capacity grinding spindle 5,7 kW Gewicht der Maschine ca. / weight ca. 3700 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Iiedpswrmcpefx Aa Esd Technical data, accessories and description of the machine are not binding.

Condition: used, Type Amb 6/4 VAI-Z In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Iisdpfxexzuyre Aa Esd Subject to changes and errors in the technical data and specifications, as well as prior sale!

Condition: good (used), Year of construction: 1991, functionality: fully functional, ELB OPTIMAL Surface Grinder – Magnetic Chuck – Year of Manufacture 1991 Technical Data Manufacturer: ELB-Schliff Model Series: OPTIMAL Year of Manufacture: 1991 Grinding Area approx. 600 × 375 mm Magnetic Chuck approx. 600 × 350 mm Max. Workpiece Height approx. 375 mm Iijdjzhgxyopfx Aa Esd Hydraulic Table Drive Electric Vertical Feed Coolant System Electromagnetic Chuck 400 V Description Well-maintained ELB precision surface grinder made in Germany. The machine features a magnetic chuck, hydraulic table feed, and an integrated coolant system. It is ideally suited for toolmaking, mold making, and machine building, as well as for training and maintenance workshops. Visually in good condition. Inspection possible by appointment.

Condition: used, Horizontal surface grinding machine Type/Model: ELB Star 2 Condition: Used Technical data: Grinding length max. 630 mm Grinding width max. 250 mm Workpiece height max. 300 mm, installation height above table Magnetic table standard 600 x 250 mm Total power requirement approx. 8.5 kW Weight approx. 3200 kg Iodpfjzdrgnsx Aa Esid Note: Automatic workpiece feed system is defective.

Condition: used, Year of construction: 1986, HK Orion surface grinding machine Condition: Used Year of manufacture: 1986 Technical data: Magnetic clamping table: 500 x 1,000 mm Automatic alignment system Automatic feed function Electronic handwheel Machine light Iedpfozdq Nbsx Aa Eoid

Year of construction: 1989, condition: ready for operation (used), travel distance X-axis: 1,500 mm, number of axes: 3, This 3-axis ELB Surface Grinder was manufactured in 1989. It features a working area of 1,500 mm x 500 mm, ensuring ample space for various grinding tasks. If you are looking to get high-quality surface grinding capabilities, consider the ELB Surface Grinder we have for sale. Contact us for further details. Iijdpfx Ajzb Et Doa Eed - Manufacturer: ELB- Working Area: 1,500 mm x 500 mm- Year of Manufacture: 1989- Condition: Very good / Fully functional

Condition: used, functionality: fully functional, grinding length: 450 mm, grinding width: 175 mm, For sale is a reliable surface grinding machine from the renowned manufacturer ELB-Schliff, type SW4/6HA. The machine is in used but functional condition. "Includes the original, external dust extraction system for effective reduction of grinding dust and sparks directly at the workpiece." Technical details: Manufacturer: ELB-Schliff Type: SW4/6HA Machine no.: 29770462 Dimensions of magnetic table: 450 x 175 mm Iiodpezbr R Njfx Aa Ejd Upon request, transport and loading can be arranged throughout Europe for an additional charge. Prices plus VAT. Inspection possible by appointment. Contact us, and our team will be happy to assist you. Trade-in or exchange possible! Machine purchase/sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MORE. Do you need a high-quality, yet affordable, metalworking machine for your production? Or do you want to sell yours? For more information or contact options, please visit our website.

Condition: good (used), functionality: fully functional, grinding length: 500 mm, grinding width: 350 mm, total height: 2,350 mm, total length: 2,400 mm, total width: 1,900 mm, table length: 900 mm, table width: 300 mm, For sale is an ELB surface grinding machine, model SW 5 VA 1, manufactured in 1972 (machine no. 112630972). It is equipped with a robust hydraulic table drive and, despite its age, is in remarkably well-maintained and immediately operational condition. Technical data: Grinding length (X-axis): 500 mm Grinding width (Y-axis): 350 mm Workpiece height (Z-axis): 300 mm Table clamping area: 900 x 300 mm Magnetic plate: 500 x 250 mm or 400 x 200 mm Table speed: 2 – 25 m/min Grinding wheel dimensions: Ø 300 x 50 x 76 mm Spindle speed: 2,800 rpm Spindle drive power: 4.5 – 5.5 kW Dimensions & Weight: Footprint (L x W x H): approx. 2,400 x 1,900 x 2,350 mm Machine weight: approx. 2,500 – 2,700 kg Iodpfxjzbryks Aa Ejid Hydraulics: Stepless longitudinal movement of the table for optimal grinding results. Transverse feed: Automatically and manually adjustable. Vertical feed: Manual handwheel feed (fine feed). Documentation: Original operating manual available. Upon request, transport and loading can be arranged for an additional fee, throughout Europe. Prices are exclusive of VAT. Inspection is possible by appointment. Contact us, our team will be happy to assist you. Trade-in or exchange is possible! Machine buying/selling PURCHASE/SALE OF PRODUCTION & METALWORKING MACHINES, ETC. Do you need a high-quality but affordable metalworking machine for your production? Or do you want to sell yours? For more information or to contact us, please visit our website.

Condition: used, grinding length:650 mm grinding width:450 mm workpiece height:425 (ohne Magnetplatte) mm max. workpiece weight:600 kg weight of the machine ca.:3,8 t total power requirement:15 kW machine dimensions approx. WxHxD:3,0 x 2,4 x 2,3 m Used/reconditioned surface grinding machine, make GER, type RSA-650. Automatic infeed in all 3 axes. Machine geometrically overhauled, repainted (RAL6011, green), all functions tested, accuracy checked. OVERHAUL SCOPE: Machine completely disassembled, all components thoroughly cleaned and tested for complete functionality. Main spindle newly mounted, concentricity 3 µ. All guideways newly scraped in new machine geometry. Wear parts replaced, defective components repaired or replaced. Reassembly, complete functional test and internal acceptance. Machine repainted. Machine in perfect condition, ready for production. MEASURED GEOMETRIC ACCURACIES: Actual geometric accuracy after overhaul, measurement with dial gauge. Geometry of machine axes X and Z X = longitudinal axis 650 mm Z = transverse axis 450 mm Measurement magnet traversed with dial gauge. X axis = Max. Deviation 0,008 mm Z axis = Max. Deviation 0,005 mm INCL. THE FOLLOWING ACCESSORIES: -Electro-magnetic clamping plate, with fine longitudinal pole pitch. dimensions 600 x 400mm -demagnetizing device -Complete coolant device with paper band filter - Digital display of the vertical axis (Y-axis), make Sony -Technical documentation in English language -1 pieces grinding wheel holders -1 piece grinding wheel dresser, mounted above the grinding wheel with manual infeed Iiodpfefkg H Tex Aa Eed and automatic (hydraulically operated) transverse movement - 1 set of setting elements You can find more information in the attachment. Payment: 100% before loading the machine Warranty: 6 months on the geometry and the new parts demonstrably installed. No general legal warranty.

Condition: good (used), Year of construction: 1982, 1 used surface and guideway grinding machine Manufacturer: ELB Model: SWDE 30 U CNC Year of manufacture: 1982 / 1999 Control type: CNC Control: Mitsubishi 520 Location: NRW Country of origin: Germany Delivery time: short notice Delivery terms: ex stock Iiodpfx Aeynglboa Esd TECHNICAL DATA Grinding length: 3000 mm Grinding width: 900 mm Workpiece height: 600 mm Electromagnetic chuck: 3000 x 900 mm Pole pitch: 18 mm Grinding wheel dimensions: Ø 500 x 100 mm Control: Mitsubishi 520 Total power requirement: 18.5 / 5.5 kW Machine weight approx. 19 t Space requirement approx. 9 x 4.5 x 3.5 m Shipping dimensions approx. 13 x 2.5 x 3.5 m

Condition: ready for operation (used), Year of construction: 1971, functionality: fully functional, grinding length: 400 mm, grinding width: 250 mm, grinding height: 275 mm, grinding wheel diameter: 250 mm, grinding wheel width: 30 mm, ELB - Surface grinding machine, Model: SW 4 VA I, year of manufacture: 1971, grinding area: 450 x 250 x 275 mm, grinding wheel: 250 x 30 x 51 mm Isdpfx Aasyzfale Eeid ACCESSORIES: Coolant tank with pump, electro-magnetic chuck 450 x 250 mm, leveling feet

Condition: used, Year of construction: 1973, Technical details: grinding length: 400 mm grinding width: 200 mm workpiece height: 300 mm dimensions of grinding wheel: 275 - 315 mm magnetic plate size: 400 x 200 mm max. table load: 200 kg Iisdpjxu Dv Aefx Aa Eod weight of the machine ca.: 1,6 t dimension machine xH: 1,55 x 1,45 x 2,20 m

Condition: used, Year of construction: 1987, Technical details: grinding length: 600 mm grinding width: 350 mm workpiece height: 600 mm feed: 1 - 30 m/min magnetic plate size: 610 x 255 mm distance table - spindle center: min./max. 150 / 420 mm grinding spindle speed: 3000 U/min stroke of the table: min./max.: 200 / 650 mm total power requirement: ca. 4,0 kW weight of the machine ca.: 2,5 t dimension machine xH: 1,5 x 1,9 x 2,0 m dimension coolant device LxWxH: 0,63 x 0,40 x 0,65 m Headstock: -vertical travel Y = 0.002 - 0.06 mm -adjustment = 0,001 - 2mm Cross slide: -transverse travel Z = 360mm -feed adjustment = 1 - 60mm/stroke -rapid traverse = 1.2 m/min. Iijdpfx Aou Ngicoa Eod Dressing manual Cooling water unit with capacity 140Liter Equipment: -3x support feet -machine lighting accessories: -alignment device for grinding wheel holder *

Condition: used, Technical details: grinding length: 630 mm grinding width: 250 mm workpiece height: 300 mm Table dimensions: 2050 x 340 mm magnetic plate size: 600 x 250 (110V) mm feed range: Tisch: 0,005 - 0,045 mm/Hub feed of spindle: 0,001 - 0,045 mm/Hub dimensions of grinding wheel: Ø 220 x 46 mm total power requirement: 8,5 kW dimension machine xH: 2,1 x 1,8 x 1,9 m Isdpfx Aasu Ngkme Ejid dimension coolant device LxWxH: 0,8 x 0,31 x 0,5 m -Longitudinal table stroke = 700mm -transverse travel of table = 800mm Coolant pump *

Condition: excellent (used), Year of construction: 1986, grinding length 800 mm grinding width 375 mm workpiece height 375 mm magnetic clamping plate, electical 900 x 300 mm spindle turning speed range 1500 - 3000 U/min Iijdpfx Aaeunt Iuj Esd table surface area 1550 x 370 mm table longitudinal travel 100 - 1000 mm max. workpiece weight 350 kg dimensions of grinding wheel 300 x 50 mm total power requirement 9 kW weight of the machine ca. 4,6 t dimensions of the machine ca. 4,0 x 2,3 x 2,6 m

Condition: good (used), Year of construction: 1991, CNC surface grinding machine, make ELB, type: BRILLANT B8 UNICON with CNC dresser for profile grinding. Grinding mass: lengthwise 800 mm, width 500 mm, height 400 mm Iijdevk Elzjpfx Aa Ejd Magnet: 800 mm x 450 mm with paper belt filter and extraction. Complete machine documentation.

Condition: used, Surface grinding machine ELB type SW 3 HA Juwel Machine no. No. 51810465 Year of construction 1965 Sanding area 300 x 150 mm Clamping surface 300 x 150 mm Electromagnet 300 x 150 mm Distance spindle center - magnet approx. 350 mm Grinding wheel diameter 175 mm Grinding wheel width max. 25 mm Grinding wheel speed 2800 rpm Grinding spindle drive 0.75 kW Mains connection 380 Volt, 50 Hz. - Manual and automatic table cross adjustment (0.02 mm per graduation mark) - Manual cross adjustment via handwheel, travel per handwheel rotation, Y-axis 2 mm - Manual depth adjustment via handwheel, travel per handwheel rotation, Z-axis 0.2 mm - Longitudinal table movement via electric motor with 2 speeds - Grinding wheel extractor - Electromagnet type SD 15/30 Height = 78 mm - Lubrication pump for the table guide in the machine base - Wet grinding unit with pump opposite - Electric box Electromagnet for wall mounting - Operating instructions - Machine light Space requirement L x W x H 1250 x 1100 x 1950 mm Weight approx. 920 kg Isdpfxettc T De Aa Esid good condition
