Used Painting Machine for sale (66,833)

Condition: ready for operation (used), Year of construction: 1996, functionality: fully functional, travel distance X-axis: 1,500 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 650 mm, spindle speed (max.): 6,000 rpm, Equipment: chip conveyor, TECHNICAL DETAILS Travel X-axis: 1,500 mm Travel Y-axis: 650 mm Travel Z-axis: 650 mm Pallet size: 1,740 x 650 mm Spindle taper: SK 50 Spindle speeds: 25 - 6,000 rpm Spindle overhang: 665 mm Distance spindle nose to table: 200 / 850 mm Spindle motor power: 18.5 kW Max. spindle torque: 758 Nm Rodpfx Ahjya E Ryjzobt Feed rate - longitudinal/cross/vertical max.: 8 mm/min Rapid traverse longitudinal and cross: 26 m/min Rapid traverse vertical: 20 m/min Drilling capacity (solid): 50 mm Tapping capacity: M 45 Tool changer positions: 60 Tool diameter: 125 mm Tool diameter with 2 empty stations: 260 mm Max. tool length: 400 mm Max. tool weight: 20 kg EQUIPMENT Chip conveyor Coolant device

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2005, operating hours: 11,000 h, controller model: Sinumerik 840D, laser power: 2,700 W, sheet thickness steel (max.): 6 mm, sheet thickness aluminum (max.): 4 mm, working length: 6,500 mm, TruLaser Tube 5000 with Special Equipment: Laser TruFlow 2700 & SeamLine Tube! TECHNICAL DETAILS Laser Power: 2,700 W Maximum Sheet Thickness (Steel): 6 mm Maximum Sheet Thickness (Aluminum): 4 mm Working Area: 6,500 mm MACHINE DETAILS Laser Type: TruFlow 2700 Control System: Sinumerik 840D Laser Operating Hours: 11,000 h EQUIPMENT - Documentation / Manual - Safety light curtain - Sturdy machine frame with integrated laser unit - CO2 laser TruFlow 2000, high-frequency excited, with cooling unit - Maintenance-free three-phase servo motors - NitroLine high-pressure cutting - SprintLine for rapid processing - Programmable cutting gas pressure control - Laser cutting head with 5 lenses - Quick-change device for the cutting head - Laser power control - Laser logbook function - Automatic shutdown - Workspace illumination - Multi-beam light curtains - Fully enclosed and ventilated beam guidance Rbedeyanr Tjpfx Ahzst - Compact dust extractor - Protective enclosure - PRS 3001 discharge station with brush table - Set of clamping jaws D 20–85 mm and D 85–150 mm - 1 set of V-shaped form shells and guide rollers for round tubes - 1 set of U-shaped form shells and guide rollers for a circumscribed diameter of 120 mm - SeamLine Tube

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2008, operating hours: 22,600 h, machine/vehicle number: A0230A2187, laser power: 7,000 W, sheet thickness steel (max.): 25 mm, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 116 mm, No minimum price – guaranteed sale to the highest bidder! TruLaser 5030 Laser Cutting Machine with Special Equipment TruFlow 7000! TECHNICAL DETAILS Laser power: 7,000 W Travel X-axis: 3,000 mm Travel Y-axis: 1,500 mm Travel Z-axis: 116 mm Max. sheet thickness (steel): 25 mm Max. sheet thickness (aluminum): 20 mm X-axis feed rate: 200 m/min Max. workpiece weight: 900 kg MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 11,100 x 4,600 x 2,600 mm Total weight: 12,000 kg Control system: SINUMERIK 840D Laser type: TruFlow 7000 Rbsdpfx Aoyanplehzot Laser hours: 22,600 h EQUIPMENT • Enclosed machine frame with integrated laser unit • Motion unit for ultra-precise machining • Gantry drive combined with linear direct drives • Enclosed beam guidance • Single cutting head strategy • TFT color monitor • Longitudinal conveyor belt for small parts and scrap • Automatic pallet changer • Work area lighting • Positioning laser diode • Oil spray device • Piercline • FocusLine • NitroLine • PlasmaLine • CO2 Laser TruFlow • Maintenance-free turbo radial blower • Lens cutting head with 250 mm lens • Universal quick-change device (UTI) with bus connection • LensLine with condition monitoring • ControlLine: height control and sheet edge detection • Auto shut-off • ConturLine • FastLine • FlyLine • Microweld • USB interface • RJ-45 network connection • CE marking • Light barriers • Multi-chamber extraction system • Compact dust extraction unit • Complete operating manuals • Lens cleaning kit • Transport locks • Crosshairs/ measuring bridge

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, working width: 450 mm, Equipment: safety light barrier, TECHNICAL DETAILS Working width: 450 mm (limited processing up to 520 mm possible) EQUIPMENT - Safety light barrier - Saw - Universal milling unit with roller cutter - Dovetail cutter - Finger joint cutter - Drilling units: 1x horizontal + 2x vertical - Slotting device - Marker on stop side - Automatic beam turning station - Wood length is now processed in the feed up to 16m - Control computer with EKP program included Rsdpeyfhi Nofx Ahzjbt

Condition: good (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 0179 (033), turning length: 125 mm, spindle speed (max.): 7,000 rpm, turning diameter: 32 mm, clamping diameter: 32 mm, workpiece length (max.): 150 mm, The machine is supplied with tool holders and spare parts. TECHNICAL DETAILS Swing diameter over bed: 32 mm Spindle bore: 32 mm Turning length: 125 mm Control: YASKAWA SIEMENS 840 DI V2 Spindle speeds: 7000 rpm Workpiece length: max. 150 mm Clamping diameter: 32 mm Feed rate: 0 - 2000 mm/min Rjdpfex U Tchex Ahzsbt MACHINE DETAILS Machine weight: approx. 5.7 t Space requirements: approx. 10.5 x 2 x 1.9 m Connection voltage: 200 V, 3 phases Frequency: 50 / 60 Hz Connected load: 8.0 kVA

Condition: ready for operation (used), Year of construction: 2020, functionality: fully functional, machine/vehicle number: 89N1160, cutting width (max.): 800 mm, insertion depth: 800 mm, overall weight: 900 kg, reverse speed: 70 mm/s, TECHNICAL DETAILS Cutting width: 800 mm Insertion depth: 800 mm Maximum operating height: 100 mm Pressing force: 180–2,700 daN Minimum cut without cover plate: 15 mm Minimum cut with cover plate: 50 mm Return speed: 70 mm/s Rbodpfjycr Ikjx Ahzot MACHINE DETAILS Power consumption: 4.0 kVA Power supply: 400 V, 50 Hz, 2.6 A Control: 18.5" touchscreen Program memory: 1,998 jobs Total cuts: 24,551 Weight: 900 kg Table: Stainless steel with air support EQUIPMENT 1× mounted POLAR 78 1× new POLAR 78 SKH-2, 960×110×11.7 mm Process visualization Hydraulic swinging angled cut LED cutting line indicator Air table Robust machine body Ultra-fast knife change with POLAR OptiKnife New spare knife

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, travel distance X-axis: 1,740 mm, travel distance Y-axis: 760 mm, travel distance Z-axis: 660 mm, controller model: Mazatrol 640M, rotational speed (max.): 12,000 rpm, TECHNICAL DETAILS X-axis: 1,740 mm Y-axis: 760 mm Z-axis: 660 mm Rapid traverse X-axis: 36 m/min Rsdpfx Aoya Dh Rohzobt Rapid traverse Y-axis: 36 m/min Rapid traverse Z-axis: 36 m/min Table size: 2,000 x 760 mm Table load capacity: 1,400 kg Distance from table surface to spindle nose: 160 mm - 840 mm Spindle speed: 12,000 rpm Main drive power (5 min): 18.5 kW Main drive power (30 min): 11 kW Tool Changer Number of tool stations: 30 Spindle taper: SK 40 Max. tool diameter: 80 mm Max. tool diameter with free adjacent stations: 110 mm Max. tool length: 350 mm Max. tool weight: 8 kg MACHINE DETAILS Control: Mazatrol 640M Interfaces: RS232, LAN, Floppy drive Dimensions & Weight Dimensions (L x W x H): 4,435 x 3,300 x 3,442 mm Machine weight: 11,500 kg Operating Hours as of 23.05.2025 Operating hours: 6,585 h Cutting hours: 8,300 h Auto cutting hours: 8,374 h EQUIPMENT Documentation/manual Chip conveyor Relocation detector Automatic tool length measurement system Preparation for partition wall for pendulum machining 4th axis Electronic handwheel EIA / ISO programming Synchronous tapping Through-spindle coolant, 5 bar

Condition: ready for operation (used), Year of construction: 2023, functionality: fully functional, spindle speed (max.): 14,000 rpm, number of slots in tool magazine: 133, TECHNICAL DETAILS Spindle speed: 14,000 rpm Coolant supply through the spindle: 70 bar MACHINE DETAILS Year of manufacture: 2023 EQUIPMENT Direct tapping Tool magazine with 133 storage positions Pallet changer Two pallets with tapped hole grid Eight adjustable rinse nozzles at the spindle Flow monitor for coolant through the spindle Cooling system with chip conveyor BSW880 Interface for mist extraction Visual tool breakage monitoring BTS Rbsdpfoyarhrox Ahzst Toolholder HSK-A63 Coolant temperature control unit Direct measuring systems (glass scales) for X, Y, Z axes Three-axis workpiece probe (Marposs Mida T25G) Double-layer cooling system (BDW 880) Automatic central lubrication Programmable axis mirroring Tool offset storage with 400 memory slots 54 (6+48) freely selectable workpiece coordinate systems Three-color signal lamp

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, number of spindles: 2, spindle speed (max.): 6,500 rpm, travel distance X-axis: 840 mm, travel distance Z-axis: 425 mm, Auction of a production line with robot and two workpiece palletizers! Rbodpjyap Naofx Ahzet TECHNICAL DETAILS Travel distance X: max. 840 mm Travel distance Z: max. 425 mm Spindle speed: 6,500 rpm Workpiece palletizer capacity: 24 workpiece carriers Number of main spindles: 2 Number of tool turrets: 2 Number of tools per turret: 12 MACHINE DETAILS High-pressure pump: up to 120 bar per line Machine weight: 8,000 kg Cooling: Spindle and machine bed cooling EQUIPMENT Robot M6iB Workpiece shuttle system by Heilig Automation with 2 pick-up stations High-pressure pump up to 120 bar per line Chip crusher Workpiece palletizer with a capacity for 24 workpiece carriers

Condition: ready for operation (used), Year of construction: 2017, operating hours: 5,214 h, functionality: fully functional, travel distance X-axis: 730 mm, travel distance Y-axis: 730 mm, travel distance Z-axis: 880 mm, controller model: SINUMERIK 840 D sl/operate, spindle speed (max.): 20,000 rpm, TECHNICAL DETAILS Travel X-axis: 730 mm Travel Y-axis: 730 mm Travel Z-axis: 880 mm Max. main spindle speed: 20,000 rpm Max. torque: 250/104 Nm Tool holder: HSK-A63 Distance spindle center to table: 80 - 810 mm Distance spindle nose to table center: 70 - 950 mm Number of pallets: 2 Rodpfx Ahoyapvaezsbt Pallet size: 500 mm x 500 mm Max. workpiece weight: 500 kg Pallet change time: 9.0 s Max. workpiece diameter: 800 mm Max. workpiece height: 1,000 mm Number of tool stations: 40 Tool change time (tool to tool): 2.5 s Tool change time (chip to chip): 4.4 - 10.0 s Max. tool diameter: 70 mm Max. tool length: 550 mm Max. tool weight: 12 kg Rapid traverse speed: 60,000 mm/min MACHINE DETAILS Control: SINUMERIK 840 D sl/operate High-pressure coolant: 70 bar Dimensions & Weight Floor space required: 6,000 mm x 4,000 mm x 2,700 mm Machine weight: 12.0 t Operating hours: 5,214 h EQUIPMENT Pallet changer Coolant tank Tool breakage monitoring

Year of construction: 2000, condition: ready for operation (used), functionality: fully functional, overall weight: 130 kg, total length: 1,200 mm, total width: 780 mm, total height: 1,280 mm, Equipment: foot remote control, TECHNICAL DETAILS Grommet size: 4 mm Rbsdpfeyf A S Ejx Ahzst MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 1,200 x 780 x 1,280 mm Net weight: 130 kg EQUIPMENT on castors with foot switch Note: The machine is sold without a riveting head.

Condition: ready for operation (used), functionality: fully functional, Auction of a set of 4 Basler acA5472-5gc machine vision cameras! TECHNICAL DETAILS Resolution: 20 megapixels Sensor format: 1 inch Pixel size: 2.4 µm × 2.4 µm Frame rate: 5 frames per second Interface: GigE Ethernet, GigE Vision, PoE-capable Lens mount: C-mount Housing size: 29 mm × 29 mm Sensor: Sony IMX183 CMOS Focal length: 8.46 mm ±5% Aperture range: F2.4 – F16 Compatibility: Cameras up to 12 MP, sensor size up to 1.1 inch Minimum working distance: 100 mm Focus range: 0.1 m to infinity FEATURES Rbodpfxoyf A Efe Ahzet Housing: Metal, manual focus and aperture adjustment, locking screws for focus and aperture

Condition: new, Year of construction: 2016, functionality: fully functional, total height: 830 mm, total width: 800 mm, total length: 1,820 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Drive pinion: 10 teeth Chain sprocket: 10 teeth Carrier width: 30 mm Chain link length: 130 mm Redpjyf Aypsfx Ahzsbt MACHINE DETAILS Dimensions (L x W x H): 1,820 x 800 x 830 mm EQUIPMENT 2 pcs drive unit 1,600 x 360 x 520 mm 5 pcs spare chains (4 pcs packed)

Condition: ready for operation (used), Year of construction: 1977, functionality: fully functional, grinding length: 700 mm, grinding width: 550 mm, travel distance X-axis: 500 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 475 mm, TECHNICAL DETAILS Rbsdpfx Ahjyf Ahmszet X-axis travel: 500 mm Y-axis travel: 300 mm Z-axis travel: 475 mm Manual grinding area Length: 700 mm Width: 550 mm Height: 400 mm Automatic grinding area Length: 700 mm Width: 470 mm Height: 400 mm Table size: 1,100 x 500 mm Maximum workpiece height: 400 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 3,000 x 1,960 x 2,550 mm Machine weight: 3,300 kg EQUIPMENT Operating manual

Condition: repair required (used), Year of construction: 1994, functionality: limited functionality, travel distance X-axis: 650 mm, travel distance Y-axis: 400 mm, rotational speed (max.): 4,000 rpm, table load: 400 kg, controller model: Heidenhain TNC 407, TECHNICAL DETAILS Travel range X-axis: 650 mm Travel range Y-axis: 400 mm Clamping surface: 900 x 468 mm Maximum table load: 400 kg Tool holder: SK40 Spindle speed range: 20 – 4,000 rpm Drive power: 5.9 kW Tool changer: 32 positions (HTC 32) MACHINE DETAILS Rbodpoyf Agcefx Ahzet Control: Heidenhain TNC 407 Dimensions & weight Dimensions (L x W x H): 2,000 x 2,500 x 2,100 mm Machine weight: approx. 3,500 kg Note: The machine's Simodrive is defective.

Condition: defective spare-parts repository (used), Year of construction: 1991, functionality: not functional, travel distance X-axis: 700 mm, travel distance Y-axis: 350 mm, table width: 380 mm, table length: 925 mm, spindle speed (max.): 6,000 rpm, TECHNICAL DETAILS Travel X-axis: 700 mm Travel Y-axis: 350 mm Redpfsyf Ac Dsx Ahzsbt Table size: 925 mm x 380 mm Spindle taper: SK 40 Spindle speed: up to 6,000 rpm Drive power: 11 kW Tool changer capacity: 20 MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 2,600 x 2,100 x 3,000 mm Machine weight: approx. 3,600 kg Note: The machine no longer starts. It is being sold for spare parts.

Condition: ready for operation (used), Year of construction: 2009, operating hours: 1,572 h, functionality: fully functional, travel distance X-axis: 3,230 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 750 mm, table width: 1,650 mm, table length: 3,000 mm, TECHNICAL DETAILS Rbjdpfx Ahsyd Acbezst X-axis travel: 3,230 mm Y-axis travel: 2,100 mm Z-axis travel: 750 mm Table length: 3,000 mm Table width: 1,650 mm Max. spindle speed: 3,500 rpm Tool holder: ISO50 Tool magazine: 30 pcs Positioning accuracy: 0.005 mm Traverse speed: 250 mm/s MACHINE DETAILS Control: CNC Number of axes: 4 Power: 22 kW Main spindle power: 22 kW Tool magazine: 30 pcs Control operating hours: 5,269 h Spindle hours: 1,572 h EQUIPMENT External cooling Tool magazine Touch probe Tool measuring system Spindle cooling Chip conveyor

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2012, operating hours: 18,000 h, machine/vehicle number: A0215A0232, laser power: 2,500 W, sheet thickness (max.): 15 mm, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, positioning accuracy: 0.1 mm, overall weight: 8,900 kg, TECHNICAL DETAILS X-axis travel: 3,000 mm Y-axis travel: 1,500 mm Laser power: 2,500 W Maximum sheet thickness (mild steel): 15 mm Maximum sheet thickness (stainless steel): 6 mm Maximum sheet thickness (aluminum): 5 mm Axis speed: max. 60 m/min Positioning accuracy: ±0.1 mm MACHINE DETAILS Dimensions & Weight Dimensions (L × W × H): approx. 7,400 × 3,300 × 2,300 mm Machine weight: 8,900 kg Mains connection: 400 V / 50 Hz Connected load: 65 kVA Control voltage: 24 V Required fuse protection: 3 × 100 A Compressed air connection: 7–14 bar Nitrogen connection (N₂): 29 bar Oxygen connection (O₂): 14 bar Rsdpfx Aheyb Rzyjzjbt Operating hours: approx. 18,000 h EQUIPMENT Automatic pallet changer FocusLine laser technology NitroLine laser technology Maintenance-free AC servo drives

Condition: ready for operation (used), functionality: fully functional, cutting length (max.): 3,550 mm, cutting width (max.): 530 mm, overall weight: 9,000 kg, stroke length: 100 mm, TECHNICAL DETAILS Usable cutting length (as double guillotine): 3,200 mm Usable cutting length (as single plate shear): 3,550 mm Press stroke: 100 mm Press width: 550 mm Min. cutting width: 18 mm Max. cutting width: 530 mm Scrap setting range: 0/50 mm Operating pressure: 6/7 bar MACHINE DETAILS Rbedpfoyf Eucjx Ahzet Installed total power: 13.9 kW Dimensions & Weight Dimensions (L x W x H): 5,200 x 1,700 x 1,800 mm Weight: 9,000 kg EQUIPMENT Robust steel construction Blade beam made of cast iron Self-lubricating prismatic guides Adjustable rear support Press for holding the veneer package during cutting Photoelectric cells Electronic programming device Perimeter safety guards

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 60 mm, workpiece length (max.): 3,000 mm, overall weight: 2,700 kg, TECHNICAL DETAILS Working area X-axis: 3,000 mm Working area Y-axis: 1,000 mm Working area Z-axis: 60 mm Maximum workpiece length: 3,000 mm Minimum workpiece length: 90 mm Maximum workpiece width: 1,000 mm Minimum workpiece width: 70 mm Rsdpfx Aheyf Elzszjbt Maximum workpiece height: 60 mm Minimum workpiece height: 8 mm Vertical electrospindle power: 4.8 HP Circular saw unit diameter: 150 mm Circular saw unit power: 2.3 HP Vertical drilling spindles: 29 Horizontal drilling spindles (X-axis): 8 Horizontal drilling spindles (Y-axis): 2 MACHINE DETAILS Compressed air: 7/8 bar Total installed power: 20 kW Machine weight: 2,700 kg EQUIPMENT Numerical control with Biesseworks software Infeed table with motorized belts (left) 2 panel clamps Outfeed table with motorized belts (right) Protection for machining head with emergency stop front mats Transfer system for panel loading and unloading with aluminium profiles Belt-driven table for panel transfer/lifting bar BiesseWorks machining programming system

Condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 3,085 mm, travel distance Y-axis: 1,385 mm, travel distance Z-axis: 180 mm, controller model: Xylog, milling spindle speed (max.): 18,000 rpm, TECHNICAL DETAILS X-axis working area: 3,085 mm Y-axis working area: 1,385 mm Z-axis working area: 180 mm Programmable X-axis speed: 50 m/min Programmable Y-axis speed: 45 m/min Programmable Z-axis speed: 22.5 m/min Drilling unit Vertical spindles: 10 Horizontal spindles X-axis: 2 Horizontal spindles Y-axis: 2 Motor power: 2.2 kW Speed: 4,000 rpm Milling unit Electrospindle: 10 HP Speed: 18,000 rpm Engraving unit Motor power: 2.2 kW Speed: 6,000 rpm Worktable Number of worktables: 6 Vacuum suction cups: 18 Loading supports: 4 Vacuum pump Flow rate: 100 m³/h MACHINE DETAILS Control system: Xylog Rsdpfxsyf Ekks Ahzobt Installed power: 17/20 kW Compressed air: 6/7 bar Weight: 3,000 kg EQUIPMENT Automatic lubrication

Condition: ready for operation (used), functionality: fully functional, overall weight: 5,000 kg, working width: 1,300 mm, workpiece height (max.): 130 mm, TECHNICAL DETAILS Working width: 1,300 mm Maximum working thickness: 130 mm Minimum working thickness: 1 mm Conveyor belt feed speed: 5/25 m/min MACHINE DETAILS Installed power: 32 kW Rbjdpfxsyf Eh Nj Ahzet Compressed air: 7 atm Dimensions & Weight Dimensions (L x W x H): 4,400 x 2,500 x 1,600 mm Weight: 5,000 kg EQUIPMENT Cross belt - Motor: 15 Hp - Electronic speed controller with display Transversal belt - Motor: 15 Hp - Electronic speed controller with display Transversal sanding belt size: 1,350 x 150 mm Chevron belt size: 5,510 x 140 mm Belt blower Fixed table and moving head for inline processing Rotary blower for panel cleaning Vacuum table Belt cleaning brush Infeed roller conveyor Extraction ports: No. 2 diameter 200 mm – No. 2 diameter 150 mm – No. 2 diameter 100 mm

Condition: ready for operation (used), Year of construction: 2001, operating hours: 85,355 h, functionality: fully functional, machine/vehicle number: 71.405627, travel distance X-axis: 600 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain Millplus, table width: 630 mm, table length: 500 mm, TECHNICAL DETAILS Travel X-axis: 600 mm Travel Y-axis: 700 mm Travel Z-axis: 600 mm Number of pallets: 2 pcs Pallet clamping surface: 500 x 630 mm Max. load pallet changer (one-sided): 600 kg Max. load pallet changer (double-sided): 1,200 kg Max. table plate rotation: 13.6 rpm Feed rate: max. 15,000 mm/min Rapid traverse speed: max. 40 m/min Set-up operation: 2,000 mm/min Magazine positions: 60 slots Max. tool weight: 10 kg Max. tool diameter: 100 mm Max. tool length: 350 mm Measuring System Resolution: 0.001 mm Input increment: 0.001 mm Positioning tolerance: 0.010 mm Rbsdpfx Asyfhahjhzot MACHINE DETAILS Control: Heidenhain Millplus Dimensions & Weight Machine without tool magazine: 8,400 kg Weight of tool magazine (60 tool positions): 600 kg Floor dimensions: 4.50 m × 2.72 m × 2.63 m Electrical Data Rated power: 44 kVA Current consumption, maximum: 64 A Current draw: 80 A Supply voltage: 400 V Frequency: 50 Hz Control voltage: 24 V Operating Hours Power-on hours: 96,878 h Spindle hours: 85,355 h

Condition: ready for operation (used), Year of construction: 1983, operating hours: 6,348 h, functionality: fully functional, drilling depth: 1,500 mm, travel distance X-axis: 1,250 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 900 mm, drill diameter: 50 mm, The machine was overhauled in 2009! TECHNICAL DETAILS Drilling depth: 1,500 mm Drill diameter: 5 - 50 mm Travel X-axis: 1,250 mm Travel Y-axis: 900 mm Travel Z-axis: 900 mm Table length: 1,000 mm Table width: 1,000 mm Max. table load: 3,000 kg Spindle speed: 100 - 6,000 rpm Spindle taper: SK 40 MACHINE DETAILS Control: Siemens 802 D Dimensions & Weight Dimensions (L x W x H): 5,000 x 2,600 x 2,000 mm Weight: 6,000 kg Operating hours: 6,348 h Rbedpjyfhcijfx Ahzst

Condition: ready for operation (used), Year of construction: 2016, operating hours: 400 h, functionality: fully functional, travel distance X-axis: 1,050 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 500 mm, controller model: Siemens 828D, spindle speed (max.): 12,000 rpm, The machine spindle was replaced in 2022! Rbedpsyf E Szefx Ahzet TECHNICAL DETAILS Travel X-axis: 1,050 mm Travel Y-axis: 550 mm Travel Z-axis: 500 mm Milling spindle (BT40): 12,000 rpm MACHINE DETAILS Control unit: Siemens 828D Operating hours: Power-on hours: 26,247 h Spindle hours: approx. 400 h (total 4,727 h) EQUIPMENT - Active electrical cabinet air/air cooler - Network connection - USB interface - Spindle chiller - Side windows left and right for large components - Safety cabin with armoured glass - Coolant pump at spindle - Pump for chip flush device - Air at the spindle via M-code function - Operating status light - Oil separator - Electronic handwheel - ICS system (internal coolant supply) - Pump for ICS - 24-position tool changer - Hinge-type chip conveyor, rear discharge - Glass scales including purge air by Siemens - Wireless workpiece measuring system Renishaw OMP60 - Tool measuring system Renishaw NC4 - Automatic machine door Note: The Halter automation system as well as vices including zero-point clamping system are not included in the scope of delivery.
