Used Turning for sale (7,606)

Condition: ready for operation (used), Year of construction: 2006, operating hours: 13,006 h, functionality: fully functional, machine/vehicle number: 190433, turning length: 1,050 mm, turning diameter: 660 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 150 mm, travel distance Z-axis: 1,050 mm, controller model: Mazatrol Matrix, The technical data is based on manufacturer specifications. The seller cannot guarantee its accuracy! Operating times according to control system: Total: 5,025 h Automatic machining: 1,866 h Pure machining RV1: 1,037 h Pure machining RV2: 298 h Operating time: 13,006 h Tool type: Capto C6 Hedpfx Asy Slqfsg Ujn Tool changer: 72 positions Turret: 9 positions TECHNICAL DETAILS Max. turning diameter: 660 mm Diameter over bed: 760 mm Turning length: 1,050 mm X-axis: 580 mm Y-axis: 150 mm Z-axis: 1,050 mm Main spindle speed: 5,000 rpm Counter spindle speed: 5,000 rpm Milling spindle: 12,000 rpm MACHINE DETAILS Control system: Mazatrol Matrix Main circuit: 3AC Main circuit voltage: 400 V Frequency: 50/60 Hz Control circuit AC: 100 V Control circuit DC: 24 V Main motor current draw: max. 84 A Main motor voltage: 400 V Rated power: 91.8 kVA Weight: 11,800 kg

Condition: ready for operation (used), Year of construction: 1999, operating hours: 12,500 h, functionality: fully functional, controller model: OSP 7000M, Equipment: chip conveyor, TECHNICAL DETAILS Tool changer: 24 BT40 MACHINE DETAILS Control system: OSP 7000M HS: Big Bore GS: Standard Bore Coolant pump: 8 bar Spindle hours: 12,500 h Hsdoy S Sw Eopfx Ag Ujn EQUIPMENT Chip conveyor

Condition: ready for operation (used), Year of construction: 2008, operating hours: 10,500 h, functionality: fully functional, turning diameter: 630 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 935 mm, controller model: Okuma OSP P200L, TECHNICAL DETAILS Diameter over slide: 630 mm Machining diameter: 630 mm Distance between centers: 900 mm Travel range X-axis: 580 mm Travel range Y-axis: 160 mm Travel range Z-axis: 935 mm Travel range W-axis: 1,000 mm Travel range C-axis: 360° Travel range B-axis: -30° to 195° Main spindle: 3,800 rpm Counter spindle: 5,000 rpm Milling spindle: 6,000 rpm Rapid traverse X-axis: 40,000 mm/min Rapid traverse Z-axis: 40,000 mm/min Rapid traverse Y-axis: 26,000 mm/min Rapid traverse W-axis: 20,000 mm/min Rapid traverse C-axis: 200 rpm Rapid traverse B-axis: 30 rpm Tool diameter max.: 90 mm Tool diameter without adjacent tools max.: 130 mm Tool length max.: 300 mm Tool weight max.: 10 kg Hodpoy S Swxofx Ag Uen MACHINE DETAILS Number of axes: 6 Control system: Okuma OSP P200L Dimensions & Weight Footprint: 4,340 × 2,050 mm Height: 2,600 mm Weight: 10,300 kg Spindle hours: 10,500 h EQUIPMENT Documentation/Manual Speed infinitely adjustable Marpos tool sensor Chip conveyor & coolant system with small band filter system ATC 60 system HSKA-63 (60 tools)

Condition: ready for operation (used), Year of construction: 2007, operating hours: 5,426 h, functionality: fully functional, machine/vehicle number: 101098, travel distance X-axis: 400 mm, travel distance Z-axis: 200 mm, workpiece length (max.): 130 mm, TECHNICAL DETAILS Travel range, X-axis: 400 mm Working stroke, X-axis: 150 mm Travel range, Z-axis: 200 mm Chuck diameter: 160 mm Turning diameter: max. 200 mm Machining diameter: max. 130 mm Part length: max. 110 mm Main spindle Spindle flange according to DIN 55026: Size 5 Spindle bearing, diameter front: 80 mm Speed, hybrid bearing: max. 6,000/7,500 rpm Main drive AC asynchronous motor: 1MB200E Indramat Low-voltage technology: Fanuc Power at 100/40 % duty cycle: 16/24 kW Torque at 100/40 % duty cycle: 102/153 Nm Rated speed: 1,500 rpm Feed drive Rapid traverse speed X: 60 m/min Rapid traverse speed Z: 30 m/min Feed force X and Z: 5 kN Ball screw diameter X and Z: 40 mm Acceleration X/Z: 5/5 m/s² Tool holder Cylindrical shank tool holder according to DIN 69880: 12-fold Shank diameter: 40 mm Tool length incl. holder: max. 190 mm Pitch circle diameter: max. 740 mm Pitch circle diameter Lifetool: max. 620 mm Tool holder with driven tools Cylindrical shank tool holder according to DIN 69880: 12-fold Shank diameter: 40 mm Speed: max. 6,000 rpm Rated speed: 3,000 rpm Torque at 10 % duty cycle: max. 37 Nm Torque at 25 % duty cycle: max. 26 Nm Torque at 100 % duty cycle: max. 14 Nm MACHINE DETAILS Closed standard automation Number of carrier bars with workpiece diameter 27 mm: 85 Number of carrier bars with workpiece diameter 18 mm: 130 Permissible total load: max. 120 kg Pick-up stroke depressed: 1 mm Pick-up stroke over-depressed EMERGENCY STOP: 5 mm Pick-up spring travel: max. 30 mm Chain length: 162 inches Chain pitch: 25.4 mm Chain tension with 27 carrier bars: 400 N Chain sprocket: Z = 30 Gear ratio: i = 100 Hedpfx Agey T Iupj Usn Motor revolution/band revolution: 540 Loading time: 2–4 s Electrical equipment Operating voltage: 400–480 V Control voltage DC: 24 V Control voltage AC: 230 V Frequency: 50/60 Hz Connected load: 31 kW Supply line fuse: 50 A Design of the electrical system: VDE 0113 Operating hours: 5,426 h

Condition: ready for operation (used), Year of construction: 2006, operating hours: 91,318 h, functionality: fully functional, machine/vehicle number: 040033, rotational speed (max.): 5,000 rpm, working width: 120 mm, working height: 260 mm, working length: 360 mm, TECHNICAL DETAILS Work area X-axis: 360 mm Work area Y-axis: 120 mm Work area Z-axis: 260 mm Handling area X/Z: 490/260 mm Maximum spindle speed: 5,000 rpm Spindle bore: 65 mm Spindle diameter at front bearing: 110 mm Spindle nose, cylindrical: ∅ 140 mm Feed force X/Y: approx. 8,000/10,000 N Feed force Z: 10,000 N Rapid traverse rate X/Z/Y: approx. 80/40/7.5 m/min Acceleration X/Z/Y: 7 m/s² MACHINE DETAILS Hsdpfx Ajy T Itrsg Uon Control system: SIEMENS Sinumerik Power at 100% duty cycle ED main spindle: 20 kW Torque at 100% duty cycle ED: 105 Nm Power at 40% duty cycle ED: 27 kW Torque at 40% duty cycle ED: 145 Nm Dimensions & Weight Machine dimensions (L x W x H): 2,430 x 2,000 x 2,850 mm Machine weight: approx. 7,500 kg Rated power: 20 kW Apparent power: 25 kVA Rated current: 36 A Voltage: 400 V Frequency: 50/60 Hz Operating hours: 91,318 h EQUIPMENT Sliding door: Sheet thickness 5 mm Note: The machine is sold including a small set of accessories!

Condition: ready for operation (used), Year of construction: 2005, operating hours: 91,318 h, functionality: fully functional, machine/vehicle number: 040018, rotational speed (max.): 5,000 rpm, controller model: SIEMENS Sinumerik, working width: 120 mm, working height: 260 mm, working length: 360 mm, TECHNICAL DETAILS Hedpfjy T Im Eex Ag Uen Working area, X-axis: 360 mm Working area, Y-axis: 120 mm Working area, Z-axis: 260 mm Handling area, X/Z: 490/260 mm Maximum spindle speed: 5,000 rpm Spindle through-hole diameter: 65 mm Spindle diameter at the front bearing: 110 mm Spindle nose, cylindrical: ∅ 140 mm Feed force, X/Y: approx. 8,000/10,000 N Feed force, Z: 10,000 N Rapid traverse rate, X/Z/Y: approx. 80/40/7.5 m/min Acceleration, X/Z/Y: 7 m/s² MACHINE DETAILS Control system: SIEMENS Sinumerik Power at 100% duty cycle, main spindle: 20 kW Torque at 100% duty cycle: 105 Nm Power at 40% duty cycle: 27 kW Torque at 40% duty cycle: 145 Nm Dimensions & Weight Machine dimensions (L x W x H): 2,430 x 2,000 x 2,850 mm Machine weight: approx. 7,500 kg Rated power: 20 kW Apparent power: 25 kVA Rated current: 36 A Voltage: 400 V Frequency: 50/60 Hz Operating hours: 91,318 h EQUIPMENT Sliding door: Sheet thickness 5 mm Note: The machine is sold including a small set of accessories!

Condition: ready for operation (used), Year of construction: 2004, operating hours: 63,778 h, functionality: fully functional, machine/vehicle number: 06800002061, rotational speed (max.): 6,000 rpm, spindle bore: 56 mm, spindle diameter: 90 mm, empty load weight: 6,000 kg, TECHNICAL DETAILS X-axis travel: 800 mm Z-axis travel: 300 mm Rapid traverse rate X: 100 m/min Rapid traverse rate Z: 45 m/min Chuck diameter: 200 mm Spindle head, flat flange: F140 h5 Spindle diameter in the front bearing: 90 mm Spindle bore: 56 mm C-axis Speed range: 0–100 rpm Hodpfxjy T Ikko Ag Usn Torque, holding torque brake: 240 Nm Accuracy in point positioning: < 0.02 degrees Number of tool stations: 12 Cylindrical shank diameter: 40 mm Drive power, 40% duty cycle: 10.8 kW Torque: 28 Nm Speed: max. 6,000 rpm MACHINE DETAILS Power of the three-phase main drive: 25 kW Torque, 100% duty cycle: 160 Nm Speed range: 20–7,000 rpm Electrical data Power: 25/35 kW Voltage: 400 V / 50 Hz Control voltage: 24 V DC Hydraulics Total capacity: approx. 25 l Pressure: 80 bar Pressure for clamping device: max. 700 bar Coolant system Capacity: approx. 190 l Pump output: 1.7 kW Flow rate at 6 bar: 20 l/min Weight: approx. 6,000 kg Operating hours: 63,778 h Note: The machine is sold including a small set of accessories!

Condition: ready for operation (used), Year of construction: 2002, operating hours: 74,523 h, functionality: fully functional, machine/vehicle number: 06800001121, rotational speed (max.): 6,000 rpm, spindle bore: 56 mm, spindle diameter: 90 mm, empty load weight: 6,000 kg, TECHNICAL DETAILS Travel, X-axis: 800 mm Travel, Z-axis: 300 mm Rapid traverse rate, X: 100 m/min Rapid traverse rate, Z: 45 m/min Chuck diameter: 200 mm Spindle head, flat flange: F140 h5 Spindle diameter at front bearing: 90 mm Spindle bore: 56 mm C-axis Speed range: 0–100 rpm Torque, holding torque brake: 240 Nm Accuracy in point positioning: < 0.02 degrees Number of tool stations: 12 Hsdpey T Id Defx Ag Uon Cylindrical shank diameter: 40 mm Drive power, 40% duty cycle: 10.8 kW Torque: 28 Nm Speed: max. 6,000 rpm MACHINE DETAILS Power of the three-phase main drive: 25 kW Torque, 100% duty cycle: 160 Nm Speed range: 20–7,000 rpm Electrical data Power: 25/35 kW Voltage: 400 V / 50 Hz Control voltage: 24 V DC Hydraulics Total capacity: approx. 25 l Pressure: 80 bar Pressure for clamping device: max. 700 bar Coolant system Capacity: approx. 190 l Pump power: 1.7 kW Flow rate at 6 bar: 20 l/min Weight: approx. 6,000 kg Operating hours: 74,523 h Note: The machine is sold including a small set of accessories!

Condition: ready for operation (used), Year of construction: 2002, operating hours: 77,119 h, functionality: fully functional, machine/vehicle number: 06810000041, rotational speed (max.): 6,000 rpm, spindle bore: 56 mm, spindle diameter: 90 mm, empty load weight: 6,000 kg, TECHNICAL DETAILS Travel X-axis: 800 mm Travel Z-axis: 300 mm Rapid traverse rate X: 100 m/min Rapid traverse rate Z: 45 m/min Chuck diameter: 200 mm Spindle head, flat flange: F140 h5 Spindle diameter at front bearing: 90 mm Spindle bore: 56 mm Hodjy T Iddepfx Ag Uon C-axis Speed range: 0–100 rpm Torque, holding torque brake: 240 Nm Accuracy at point positioning: < 0.02 degrees Number of tool stations: 12 Cylindrical shank diameter: 40 mm Drive power, 40% duty cycle: 10.8 kW Torque: 28 Nm Speed: max. 6,000 rpm MACHINE DETAILS Power of the three-phase main drive: 25 kW Torque, 100% duty cycle: 160 Nm Speed range: 20–7,000 rpm Electrical data Power: 25/35 kW Voltage: 400 V / 50 Hz Control voltage: 24 V DC Hydraulics Total capacity: approx. 25 l Pressure: 80 bar Pressure for clamping device: max. 700 bar Coolant system Capacity: approx. 190 l Pump power: 1.7 kW Flow rate at 6 bar: 20 l/min Weight: approx. 6,000 kg Operating hours: 77,119 h Note: The machine is sold including a small set of accessories!

Condition: ready for operation (used), Year of construction: 2020, operating hours: 8,977 h, functionality: fully functional, machine/vehicle number: MM0008-000192, turning length: 1,020 mm, turning diameter: 540 mm, travel distance X-axis: 565 mm, travel distance Y-axis: 170 mm, travel distance Z-axis: 1,050 mm, controller model: FANUC Series 31i-MODEL B, TECHNICAL DETAILS Turning length: 1,020 mm Turning diameter: 540 mm Swinging diameter over the machine bed: 750 mm Swinging diameter over the top slide: 540 mm Swinging diameter over the cross slide: 270 mm Travel range X-axis: 565 mm Travel range Y-axis: 170 mm Travel range Z-axis: 1,050 mm Rapid traverse rate X-axis: 36 m/min Rapid traverse rate Y-axis: 26 m/min Rapid traverse rate Z-axis: 36 m/min Power of the spindle motor: 22 W Spindle speed main spindle (max.): 5,000 rpm Spindle bore: 76 mm Spindle speed milling spindle (max.): 12,000 rpm Hsdoy Tw Uljpfx Ag Uen Bar passage: 76 mm Bar diameter (max.): 65 mm Spindle nose: A2#6 Spindle diameter: 110 mm MACHINE DETAILS Control system: FANUC Series 31i-MODEL B Chuck outer diameter: 210 mm Type of input current: Three-phase Dimensions & Weight Dimensions (L x W x H): 4,850 x 2,525 x 2,805 mm Total weight: 12,000 kg Operating hours: 8,977 h EQUIPMENT Documentation/Manual

Condition: excellent (used), Year of construction: 2013, operating hours: 5,785 h, Okuma Genos L300e-MY turning center Year: 2013 Technical details: Control OSP P300L-R Turning diameter 340 mm Turning length 1020 mm Spindle bore diameter 65 mm Spindle Speed 25 - 3000 1/min Spindle motor 15/11 kW Movement X-axis 235 mm Movement Y-axis +50 / -50 mm Movement Z-axis 1074 mm Minimum indexing C-Axis main Spindle 0,001 ° Number of tools on turret 12 Spindle speed driven tools 45 - 4500 1/min Number of driven tools 12 position Tool Taper VDI40 Spindle motor driven tools 7/3,3 kW Bar feeder SPACESAVER 2210 ( 1500 mm bar lenght, up to 67 mm diameter ) Machine dimensions 4370x2540x2490 mm Weight 7500 kg Accessories/options: - SPACESAVER 2210 barfeeder - swarf conveyor - parts cather - Renishaw tool measuring arm Hedpszat Tvjfx Ag Uen - Driven tool holders - Static tool holders - Hydraulic chuck - Jaws for chuck - Documentations - Dust extractor

Condition: used, Year of construction: 2023, controller manufacturer: Mazak, controller model: Mazatrol SmoothAi, _____ Description: Year of manuf. : 2023 Control : Mazak Mazatrol SmoothAi Turning diam. : 600 mm Turning length : 850 mm In General: Year of manufacture:2023 Control system:Mazak Mazatrol SmoothAi Max. machining diameter:600 mm Max. machining length:850 mm Main spindle: Technology:Motor spindle Speed:6,000 rpm Power:11 kW Max. torque:184 Nm Bar capacity:51 mm C-axis:0.0001° Chuck:3-jaw chuck Clamping cylinder:Hollow clamping cylinder Sub spindle: Technology:Motor spindle Speed:6,000 rpm Power:11 kW Max. torque:184 Nm Bar capacity:51 mm C-axis:0.0001° Tailstock function:Yes Tool carrier (X/Y/ZB): Technology:Travelling column with milling spindle X-axis:535 mm Y-axis:210 mm Z-axis:900 mm B-axis:-30° / +210° Milling spindle speed:20,000 rpm Power:24 kW Tool taper: HSK 63 Tool magazin: Technology:Shelf magazine Number of stations:250 Tool changer:Double gripper Equipment: Chip disposal:Chip conveyor Coolant supply:Internal coolant system, 15 bar Workpiece measurement:Renishaw RMP 60 Tool measurement:Renishaw tool setter Bar loader:IRCO ILS-MUK 7012 Finished part removal:Parts catcher Software option I:5-axis simultaneous machining Hjdpfx Aeyrvzmjg Usn Software option II:Synchronous thread cutting Software option III:Cylinder interpolation Software option IV:Tool radius compensation Software option V:Tool length compensation Emulsion mist separator:Mechanical Setup mode:Electronical handwheel

Condition: ready for operation (used), Year of construction: 2013, spindle motor power: 38,000 W, spindle speed (max.): 3,000 rpm, travel distance X-axis: 515 mm, travel distance Y-axis: 210 mm, travel distance Z-axis: 1,280 mm, total height: 2,574 mm, total width: 2,274 mm, overall weight: 9,000 kg, product length (max.): 5,890 mm, number of axes: 5, This 5-axis Biglia Smart Turn B1200S was manufactured in 2013. It features a maximum turning diameter of 500 mm and a turning length of 1,280 mm. The machine is equipped with a main spindle that reaches speeds of up to 3,000 rpm and a sub-spindle with a maximum speed of 4,000 rpm. If you are looking to get high-quality turning capabilities, consider the Biglia Smart Turn B1200S turn-mill centre we have for sale. Contact us for further details. • Maximum rotation diameter: 750 mm • Maximum turning diameter: 500 mm • Maximum turning length: 1,280 mm • Main spindle nose: DIN 55026 8" • Main spindle bar capacity: 95 mm • Main spindle motor power: 30 / 38 kW • Main spindle maximum torque: 1,014 Nm • Main spindle chuck: SMW Autoblok 250 BB (250 mm diameter) • Sub-spindle maximum speed: 4,000 rpm • Sub-spindle nose: ASA 6" • Sub-spindle motor power: 30 / 40 kW • Sub-spindle maximum torque: 286 Nm • Sub-spindle W-axis travel: 1,130 mm • Sub-spindle chuck: 250 mm diameter • B-axis milling unit rotation range: 210° (±105°) • B-axis angular positioning accuracy: 0.001° • Milling spindle taper: HSK-A63 • Milling spindle maximum speed: 50–8,000 rpm • Tool magazine capacity: 40 stations • Footprint dimensions: 5,890 × 2,274 × 2,574 mm (H), including chip conveyor Additional equipment • Chip conveyor • Parts unloader arm with front conveyor belt Hedpfx Aszar Ixeg Ujn • Tool setter probe Technical Specification Counter Spindle Yes Driven Tools Yes

Condition: used, MAKE CHIRON MODEL MILL 800 5 axis 5 axis machininng center (milling/turning from bar) Under power in our warehouse in Gussago BS Italy Mimu Machine tools CNC Fanuc 18iMBS (5 simoultaneous axis 1*) X, Y, Z (mm) 800 – 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs 90fjsieew Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min/max 5/65 mm L= 600-1200 mm Highspeed (2) 60m/min. Spindle ... Hjdpfx Agogqg Sge Ujn

Condition: used, MAKE CHIRON MODEL MILL 800 5 axis 5 axis machininng center (milling/turning from bar) Under power in our warehouse in Gussago BS Italy Mimu Machine tools CNC Fanuc 18iMBS (5 simoultaneous axis 1*) X, Y, Z (mm) 800 – 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs 90fjsieew Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min/max 5/65 mm L= 600-1200 mm Highspeed (2) 60m/min. Spindle ... Hjdegmi Unspfx Ag Ujn

Condition: ready for operation (used), Year of construction: 1992, spindle speed (max.): 36,000 rpm, bar diameter (max.): 60 mm, total width: 2,000 mm, total height: 1,900 mm, travel distance X-axis: 510 mm, travel distance Y-axis: 180 mm, overall weight: 4,300 kg, controller manufacturer: MAZATROL, controller model: T32-2, product length (max.): 2,700 mm, number of axes: 2, Multi-spindle turning machine manufactured in 1992. This Mazak Quick Turn 18 NSP features a maximum turning diameter of 260 mm and a turning length of 500 mm. It includes a tool turret with 8-fold / 16 positions and a spindle speed range of 36 - 3,600 rpm. If you are looking to get high-quality turning capabilities, consider the Mazak Quick Turn 18 NSP machine we have for sale. Contact us for further details regarding this machine. - Control: MAZATROL T32-2- Max. Turning Diameter: 260 mm- Max. Turning Length: 500 mm- Speed Range Main Spindle: 36 - 3,600 rpm- Speed Range Sub-Spindle: 36 - 3,600 rpm- Travel Z-Axis: 510 mm- Travel X-Axis: 180 mm- Spindle Bore: Ø 70 mm- Bar Loader Length: 3,000 mm- Collet Chuck Holder: For 185 E collets- Collet Chuck Range (Main Spindle): Ø 4 - 60 mm- Sub-Spindle: 3-jaw chuck, Ø 125 mm to Ø 70 mm- Tool Turret: 8-fold / 16 positions- Tool Eye: Measuring probe for tool measurement in working area- Main Spindle Chuck: KITAGAWA 3-jaw chuck Ø 254 mm- Coolant System: Complete coolant equipment- Foot Switch: 2 double foot switches for opening/closing both chucks- Machine Weight: 4,300 kg- Machine Dimensions (L x W x H): 2.7 x 2.0 x 1.9 m Optional - Drip pan (2500 x 2700 mm), IRCO 3000 mm bar loader Technical Specification Hsdpfx Agezarf Ro Ujn Counter Spindle Yes

Condition: good (used), Year of construction: 2023, CNC multi-axis turning center Manufacturer: Hyundai WIA Type: LM1800TTSY Control: Siemens 840D Shopturn with 3D simulation Year of construction: 2023 Technical data: Incline bed design with box guide in X/Y axis, Z-axis with linear guide Counter spindle and twin turret system Travel distances: X/X1: 165 / 195 mm Z1/Z2: 700 / 720 mm ZB: 668 mm Y: 100 mm Rapid traverse rates: X/Y/Z: 20 / 7.5 / 40 m/min Max. turning diameter: 230 mm Max. turning length: 673 mm Spindle nose: A2-6 Spindle bore / bar capacity: 76 / 65 mm Spindle speed: 5,000 rpm (both spindles) Drive power: 2x 22 / 11 kW Turret & milling unit: 2 turrets each with 12 stations (optional 24) System: BMT55P Milling drive: Speed: 5,000 rpm Power: 5.5 / 1.1 kW Equipment: Automatic measuring arm Coolant tank 270 liters Direct path measuring system (X1/X2, Z1/Z2, Y) Temperature compensation for coolant (with air conditioning unit) High-pressure cooling 20 bar Chip conveyor (belt conveyor) Siemens network extension Bar loader interface Extensions & accessories Software & electrical: ShopTurn with 3D simulation Machine transformer Measuring & automation technology: Automatic Q-Setter Renishaw Linear positioning sensor (for main and counter spindle) Workpiece handling: Part catcher for main spindle Part catcher for counter spindle with belt discharge Workpiece ejector Clamping technology: Spanntop mini from Hainbuch Main spindle (AX puller size 65) Counter spindle (AX fixed size 65) Peripherals: Bar loader magazine Sprint 565 S2 from LNS For bars up to 3,000 mm length Diameter: 5 – 65 mm Reduction sleeve set (various diameters) Extraction system Purchase price in 2023: 330,000 Euros Hjdsy Hfrljpfx Ag Usn The machine has been little used and is in very good condition.

Condition: good (used), Year of construction: 2006, turning length: 1,000 mm, Technical Data – QTN-250M (Turning Length 1000 mm) Chuck size: 10 inches Maximum swing diameter: 677.5 mm Standard turning diameter: 430 mm Maximum machining diameter: 633 mm Maximum machining area: 677 mm Maximum turning length (Z-axis): 1000 mm Bar capacity: 77 mm Spindle nose: A2-8 Main spindle speed: 30–4000 rpm Main spindle motor power (30-minute rating): 25 kW (36 hp) Maximum torque of main spindle: 355 Nm (36.0 kgf·m) Tailstock: • Quill type: Morse taper No. 5 • Maximum travel of tailstock: 1050 mm • Maximum thrust: 12 kN (1200 kgf) Tool turret: • 12 tool stations • Tool sizes: • External turning tool: Ø40 mm • Internal turning tool: Ø20 mm • Milling cutter/drill: Ø20 mm • Milling/threading tool: M12 Milling spindle: • Speed: 25–4500 rpm (optional 6000 rpm) • Motor power: 5.5 kW (7.5 hp) • Maximum torque: 35 Nm (3.6 kgf·m) Coolant capacity: 160 liters Machine dimensions: • Width: 1780 mm • Overall height: 2533 mm • Footprint: approx. 4.51 m² Hedpfx Ajwfynfog Uen • Machine weight: approx. 5200 kg

Condition: used, Year of construction: 2012, turning diameter 350 mm turning length 650 mm control 840 D SL ShopTurn Siemens greates pass round over bed 385 mm Swing dia. over traverse guideway 350 mm turning speed range - main spindle 0 - 4.500 min/-1 power capacity - main spindel 11,5 / 8 kW max. Torque 340 Nm spindle diameter in front bearing 130 mm spindle bore 87 mm bar material dia. max. 65 mm max. chucking diameter 250 mm spindle head 170 h5 number of toolpositions 12 pos. Shank diameter DIN 69880: 30 mm Number of driven toolspositions 6 pos. Spindle speed - driven tool stations max. 4.500 min -1 power capacity driven tool-stations 5,5 kW x-axis 255 mm z-axis 800 mm tailstock 680 mm taper of center MK 4 clamping capacity 6,8 kN feed speeds 0 - 30.000 mm/min rapid traverse ( X / Y / Z ) 30 / - / 30 m/min Feed force ( X / Y / Z ) 4,5 / - / 6,2 kN total power requirement 28 kW weight of the machine ca. 3,3 t dimensions of the machine ca. 5,0 x 2,5 x 2,3 m CNC Universal Lathe GILDEMEISTER - NEF 400 V3 - C-Axis - Tool-Drive Hsdpfx Agsy E Tvvo Uon - only ca. 8093h Spindle hours - incl. 1x workbench - incl. 1x tool cabinet - incl. 1x cabinet for VDI tool holders - incl. 8x tool holders - incl. 4x driven tools (2 radial, 2 axial)

Condition: good (used), Year of construction: 2001, Control: SIEMENS 840D Hedpfxezacfno Ag Usn Max. machining diameter: 2,800 mm Machining height: 1,000 mm Tool holder: CAPTO 6 Including chip conveyor and 2 supports

Condition: good (used), Year of construction: 2001, Control: SIEMENS 840D Hodpfozacfbox Ag Usn Machining diameter: 4,000 mm Machining height: 1,400 mm Cross slide travel: 850 mm Including chip conveyor and 2 supports

Condition: used, Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Hodszacc Tepfx Ag Uon Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, table diameter: 4.000 mm swing diameter: 4.500 mm turning height: 1.600 mm Cross-section of tool slide: 250 x 250 mm power capacity: 1 x 100 kW max. rotational speed: 140 min/1 max. table load: 50 t 2 pieces of tool changers Hjdpfxjzacbco Ag Uen 40 slots per tool changer

Condition: good (used), Year of construction: 2006, functionality: fully functional, Technical details turning diameter 660/275 mm turning length 1498 mm control Fanuc/Mori Seiki MSX 701 total power requirement 90 kVA weight of the machine ca. 26,6 t dimensions of the machine ca. 5301 x 2997 x 2788 mm Additional information 9-axis CNC turning and milling centre * Fanuc MSX-701 CNC control * Milling spindle at top (B axis), as full 4th axis, positioning 0.0001 deg. * 40-position tool magazine * 10-position turret at bottom, all positions driven * 2 x 3-jaw quick-change chuck KNCS-N 315/91 * KNOLL high-pressure coolant system, pressure setting 12/25/35/45/55/62 and 72 bar, with maintenance-free rotary filter system * Chip conveyor * Drain system for main spindle chuck (controlled via M function) * Drain system for tool cutting edge (controlled via M function) * Coolant gun incl. accessories * Oil mist extraction * Direct measuring system X1, X2, Y-axis * Bar loader interface * Double foot switch for both spindles * Islands and pocket programming for MAPPS * High-speed fixed cycle for MAPPS * Programm memory extension to 8 MB * Programm restart * 3-stage signal lamp * 512 MB memory card (CF card) Swing diameter over cross slide (tool spindle 1): 750 mm Swing diameter over cross slide (turret 2): 400 mm Max. turning diameter (tool spindle 1): 660 mm Max. turning diameter (turret 2): 275 mm Max. machined workpiece length: 1498 mm Max. bar material: 90 mm Travels: X1 axis (tool spindle): 750 mm Y axis (tool spindle): 420 (+/- 210) mm Z1 axis (tool spindle): 1635 + 100 mm for tool change B axis (tool spindle): +/- 120 deg., full B-axis 1 deg. indexed and 0.0001 deg. braked X2 axis (turret): 195 mm Z2 axis (turret): 1525 mm SZ axis (subspindle): 1610 mm Rapid traverse: (X1,Z1) 50 m/min. / (Y,X2,Z2,SZ) 30 m/min. Main and subspindle: Spindle speeds infinitely variable (spindle 1 + 2): 30-3000 rpm. C axis (spindle 1 + 2): 0.001 deg. Main spindle motor: 22/18.5 kW Subspindle motor: 22/18.5 kW Torque (spindle 1 + 2): 1000 Nm Disc turret: Number of tool positions: 10 Speed of driven tools: 6000 rpm. Drive power: 5.5/3.7 kW Milling spindle head: Tool holder: HSK A63 Max. speed: 12,000 rpm Drive power: 18.5/11 kW Torque: 120/44 Nm Tool changer: 40-stations Tool diameter 70/140 mm Tool length 400 mm Hedpfx Ajzabltog Usn Tool weight 8/10 kg Total power requirement 90 kVA Main dimensions Length x width x height 5301 x 2997 x 2788 mm Machine weight 26.6 t Accessories: Measuring arm (picture) tool measurement in machine Tool holder + box, reduction sleeves, driven tools Clamping jaws package Collets package

Condition: used, Year of construction: 2005, Technical details: turning diameter: 275 mm turning length: 900 mm spindle passage: 65 mm power capacity at 100 % load: 25/20 kW spindle turning speed range: 1 - 5000 U/min spindle diameter in front bearing: 110 mm c-axis: 1 - 500 U/min. number of workpiece supports: 4 Hodpfxjwp D Nbj Ag Ujn tool turret: 1 x-axis: 290 mm y-axis: 165 mm z-axis: 360 mm b-axis: 360 ° rapid speed: 18/30 m/min number of tools: 2x2 + 2x2 number of driven tools: 2x2 + 2x2 mm toolpiece turning speed range: 8000 / 2000 U/min power capacity: 25% ED 5,8 kW tool taper: TRAUB 60 tool turret: 2/3/4 x-axis: 170 mm z-axis: 600/950 mm y-axis: +/- 60 mm rapid speed: 18/15/30 m/min number of driven tools: 10 mm toolpiece turning speed range: 1 - 6000 U/min power capacity: 25% ED 5,8 kW tool taper: DIN 69880 40 x 63 total power requirement: 95 kW weight of the machine ca.: 16 t dimensions of the machine ca.: 10,0 x 3,5 x 3,0 m with CNC TRAUB TX 8i, Barloader TRAUB Stamag DNH61 / 3000, Main and Sub spindle with C-axis 1 support with B-axis 3 turret supports dust exhauster, coolant attachment with coalescence-seperator and chip conveyor 2 pc. 3-jaw chuck SMW KNCS-N 170-43 2 pc. HAINBUCH Spanntop chuck 40 pc. various tool holder non-driven 6 pc various tool holder driven Spare parts package *
