Used Deep Hole Boring Machine for sale (66,077)

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: 286, workpiece weight (max.): 2,000 kg, spindle speed (max.): 3,000 rpm, travel distance milling slide X-axis: 650 mm, travel distance milling slide Y-axis: 300 mm, travel distance milling slide Z-axis: 600 mm, swivel angle A-axis (min.): -20 °, swivel angle A-axis (max.): 20 °, No reserve price - guaranteed sale at the highest bid! Submitting a bid obliges you to pick up the item on time by March 31, 2025! TECHNICAL DETAILS X-axis (transverse): 650 mm Y-axis (vertical): 300 mm Z-axis (drilling axis): 600 mm A-axis (swivel range of the drilling axis): ± 20° W-axis (table adjustment): 650 mm Control: Siemens Simatic OP17 Drilling capacity Maximum drilling depth: 900 mm Drilling diameter with twist drill: 16 mm Drilling diameter with single-lip drill: 4 – 20 mm Thread cutting: M 16 Drilling spindle Spindle mount: MK 2 Spindle speed: 0 – 3,000 rpm Spindle drive (60% E.D.): 6.0 kW Spindle drive (100% E.D.): 4.1 kW Workpiece table Dimensions: 1,100 x 650 mm Swivel range: ± 360 degrees Load capacity: 2,000 kg MACHINE DETAILS Ljdev Iay Ujpfx Ad Nerg Length: 2,620 mm Height: 1,637 mm Table height: 950 mm Width: 1,485 mm Weight: 1,600 kg X-axis (transverse): ball screw with servo motor Y-axis (vertical): ball screw with servo motor Z-axis (drilling axis): rack and pinion drive with servo motor W-axis (table adjustment): ball screw with gear motor

Condition: like new (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: 106882-11, total length: 4,400 mm, total width: 1,700 mm, total height: 2,700 mm, overall weight: 7,000 kg, The drilling process of the deep hole drilling machine utilizes the single-lip drilling method. Drilling Unit Information: - Drilling depth: 200 mm - Min./max. drilling diameter: 1–12 mm based on ST 60 - Number of spindles: 2 - Spindle distance: 200 mm - Spindle drive: 2 x 2.4/4.2 kW - Infinitely variable spindle speed: 1,000–20,000 rpm - Infinitely variable feed rate: 10–25,000 mm/min - Rapid traverse: 25,000 mm/min - Slide travel (nominal): 650 mm - Slide width: 460 mm - X-axis slide travel: 200 mm, rapid traverse: 25,000 mm/min - Y-axis slide travel: 200 mm, rapid traverse: 25,000 mm/min Fluid Information: - Coolant supply: deep hole drilling oil - Tank capacity: 500 liters - 1x automatic filter, filter performance: 50 l/min - 1x monitoring filter - 2x ELB drilling oil supply lines - 1x flow divider - 1x air cooler with recirculation pump - 1x electrostatic oil mist extraction unit - 1x scraper belt chip conveyor - 1x hydraulic unit and pneumatic unit/equipment - 1x sump pump - 3x submersible pumps - 1x radial piston pump with remote adjustment: Delivery rate: 1–38 l/min Pump drive: 7.5 kW Spindle Unit: - Motorized spindles with frequency-controlled, infinitely variable speed regulation - Spindle head with connection for tool holder - 2 x tool holders for collet sleeves according to VDI 3208 SE10x60, permanently bolted to the spindle head of the motorized spindle Drill Bushing Carrier: - The drill bushing carrier is positionable via the NC axis - Cast iron design, mounted on linear guideways - W-axis drive via AC servomotor and ball screw with indirect, absolute position measurement system Lrsdpfx Adewh Rp Eo Neg Workpiece Slide: - The workpiece slide is designed as a cross-slide for vertical and horizontal positioning of the workpiece, for mounting clamping plates or special fixtures - Base unit in cast iron design with linear roller guideways - X and Y axes driven by AC servomotors and ball screws - Direct, absolute position measurement systems. Table plate with clamping or alignment grooves Clamping Table with NC rotary indexing device for positioning: - With rotary and swivel axes - Hydraulic clamping in rotary and swivel axes Technical Data: - Swivel range: 270º - Rotary range: 360º - Center height: 25 ± 0.02 - Spindle distance: 200 ± 0.005 - Indexing accuracy: rotary axis ± 15" / swivel axis ± 30" Electrical Equipment Information: - 1x drilling process monitoring - 1x CNC control 840D (Solution Line) Connection Data: - Operating voltage: 3AC 400V ± 10% - Frequency: 50 Hz - Control voltage: 24 V DC - Total rated power: 25 kW Additional Machine Equipment: - 2 x holders for resilient drill bushing holders, arranged on the drill bushing carrier - For max. drilling Ø18 mm.

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, drilling depth: 660 mm, travel distance X-axis: 700 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 1,000 mm, drill diameter: 30 mm, TECHNICAL DETAILS Drilling depth: 660 mm Drill diameter: 30 mm X-axis travel: 700 mm Y-axis travel: 500 mm Z-axis travel: 1,000 mm W-axis travel: 250 mm Spindle speed: 60 - 60,000 rpm Table length: 900 mm Table width: 500 mm Table load capacity: 2,000 kg MACHINE DETAILS Control system: Heidenhain iTNC530 Dimensions & Weight Dimensions (L x W x H): 3,706 x 3,960 x 2,650 mm Total weight: 8,000 kg Lrodpfx Ajya U U Ujd Nog EQUIPMENT CNC rotary table (4th axis) Chip conveyor Paper band filter Electronic handwheel Original documentation

Condition: used, Year of construction: 1993, Control Sinumerik 805 turning speeds 45 - 6000 U/min Solid drill diameter / 0 weight of the machine ca. 20 t Type of machine: deep hole drilling machine Model / Type: TB 2 15 30001KT Year of construction: 1993 Manufacturer: hole Machine number: 221-3000-2093 Machine weight: approx. 20,000 kg Machine footprint: Width = approx. 3800mm Length = approx. 13500mm Height = approx. 3100mm Drilling length: approx. 3500mm Drilling capacity: drill 45mm / drill out 80mm Spindle speed range: 45 - 6000 rpm Control: Siemens Sinumerik 805 Hamül – coordinate table Type: KT 8.5 – 10.10 Clamping surface: approx. 1100 mm x 980 mm Travel: Y - axis: approx. 800mm Traverse path X - axis: approx. 500mm 7 pieces clamping - T - grooves: 18 mm Ljdpevvx Hijfx Ad Nsrg Special equipment: 1 piece Fibroplan NC - rotary indexing table Type: NC 1.05 Permissible transport load in horizontal use 2500 kg With manual chuck Forkardt F 630 The NC rotary indexing table can be adjusted manually in the longitudinal and transverse directions relative to the clamping table and is clamped hydraulically. 1 piece chips - centrifuge Type: VZ5A from CEPA Drum capacity: 80 liters Loading weight max. 100 kg Drum - Ø: 600 mm Speed: 1000 rpm 1 additional pump for large drill Ø 1 piece Bosch radial piston pump no.: Suitable for lip drills (internal cooling, chips run outwards) Suitable for BTA drills with screw-on heads (internal cooling, chips run inwards)

Condition: used, Year of construction: 2006, Solid drill diameter / mm bore depth / mm number of spindles / Froriep CNC deep hole drilling machine – the prefabrication specialist Year of manufacture: 2006 Control system: Siemens Sinumerik 840D Max. drilling depth: 8,850 mm Ledpsxgu R Iefx Ad Norg Workpiece diameter: 150 – 900 mm Speed range: 1 – 300 rpm Feed rate: 0.5 – 4,500 mm/min Drive power: 129 kW Swing diameter over bed: 1,000 mm Clamping diameter faceplate: 900 mm Weight: approx. 47,000 kg Ideal for precise pre-drilling of deep holes – including faceplate, steering ring

Condition: used, Year of construction: 2006, Solid drill diameter / mm bore depth / mm number of spindles / 2-machine package: Froriep deep hole drilling machine & Irle finishing machine Perfectly matched duo for deep hole drilling and precise finishing of large workpieces A specialised machine package is available for sale – two perfectly matched systems for the complete machining of long, heavy workpieces with the highest demands on precision and efficiency. MACHINE 1 Froriep CNC deep hole drilling machine – the prefabrication specialist Year of manufacture: 2006 Control system: Siemens Sinumerik 840D Max. drilling depth: 8,850 mm Workpiece diameter: 150 – 900 mm Speed range: 1 – 300 rpm Lrodouddimspfx Ad Nsg Feed rate: 0.5 – 4,500 mm/min Drive power: 129 kW Swing diameter over bed: 1,000 mm Clamping diameter faceplate: 900 mm Weight: approx. 47,000 kg Ideal for precise pre-drilling of deep holes – including faceplate, steering ring MACHINE 2 Irle machine – high-precision finishing Power: 129 kW Control: Siemens NC control Speed range: 2 – 300 rpm (stepless) Feed: 3 – 4,500 mm/min (in steps) Centre distance: 11,000 mm Swing diameter over bed: 1,250 mm Clamping range of steady rests: 150 – 1,100 mm Workpiece length: up to 11,000 mm Workpiece weight: up to 10 tonnes Max. outer diameter: 850 mm With up to 50,000 Nm torque, perfect for smooth drilling, honing and demanding finishing processes. Your advantages at a glance - Complete solution from a single source – from pre-drilling to finishing - Large workpieces up to 11 metres and 10 tonnes in weight - High process reliability thanks to perfect machine synchronisation - Ready for immediate use, well maintained and from ongoing operation - Ideal for mechanical engineering, energy, oil & gas, hydraulics and large parts manufacturing

Condition: used, Year of construction: 2004, Solid drill diameter 200 mm bore depth / mm number of spindles / Technical data Power: 129 kW Control: Siemens NC control Speed range (stepless): 2 - 300 rpm Feed range (in steps): 3 - 4500 mm/min Oil system capacity: 20,000 litres Maximum delivery rate: 1500 l/min Circular diameter in steady rest: 1100 mm Circular diameter over bed: 1250 mm Centre distance: 11000 mm Clamping diameter face plate: up to 1100 mm Max. workpiece weight with one tailstock: 10 t Clamping range of the two steady rests: 150 - 1100 mm Clamping range BOZA: 1 = 200 - 400 mm 2 = 400 - 800 mm Dimensions Min. outer diameter: 406 mm Max. outer diameter: 850 mm Wall thickness: 10–150 mm Max. workpiece length: 11,000 mm Max. workpiece weight: 10 t Max. strength: 800 N/mm² Specific cutting resistance (Ks): 2000–2100 N/mm² Machine data Machine length: 28,800 mm Centre height: 560 mm Swing diameter over bed: 1120 mm Full drilling diameter: 200 mm Core drilling diameter: 350 mm Reaming diameter without drilling: 350 mm Reaming diameter with drilling: 350 mm Headstock: Main drive motor: Siemens Type: 1 PH 7228 Performance data at 1,000 min: 113 kW / 1,079 Nm Lrjdpfx Adexgic Ej Neg Performance data at 1,150 min: 129 kW / 1,017 Nm Main gearbox: Z-F manual gearbox Type: 2 K210 Switchable gear ratios: i = 1:1 i = 1:4 Fixed gear ratio for spindle: i = 11.68 Max. torque: 50,000 Nm Speed range I: 2...300 min Speed range II: 2 ...75 min

Condition: used, Year of construction: 2007, 106 369-11 bore diameter 3 - 65 mm number of spindles 1 total power requirement 45 kW Lredpfx Ajwizn Uod Nog . Siemens control Simens Sinumerik . weight 45 t +++++ Please note: The machine is dismantled and ready for loading. It is not possible to show it under power or make a video. Our offer includes already the best pictures. So we don’t have and won’t send additional pictures. +++++

Condition: good (used), Year of construction: 2017, functionality: fully functional, Technical details core drilling diameter max. 3 - 28 mm bore depth 1000 mm control Heidenhain TNC 640 x-axis 1000 mm y-axis 800 mm z-axis 800 mm spindle head - swivable (W) +15°/-30° deg B-axis (table) 360.000° deg table surface area 1000 x 1000 mm table load 5,0 t tool taper SK 40 spindle turning speed range 60 - 6000 U/min spindle motor 12 kW total power requirement 58 kW weight of the machine ca. 14 t dimensions of the machine ca. 6,35 x 4,75 x 3,80 m Additional information 5 axes Deep Drilling-Milling-Machine A current geometry measurement report is available. Equipped with: HEIDENHAIN TNC 640 control 5 CNC AXES X – Y – Z – W – B NC rotary table 360.000 deg. Milling performance 150 cm3/min. Direct linear position measuring system Digital AC drives Table design with Hirschmann zero-point clamping system Ledjx Ux Dkepfx Ad Nerg NC-controlled tilting of the deep hole drilling/milling unit (W) +15/-30 deg. Automatic tool changer for 24 tools Internal coolant supply High-pressure coolant system 1200 liters for deep hole drilling oil up to 140 bar Paper belt filter system SIEMENS extinguishing system Fire protection system Spindle cooling Oil temperature control 3D HEXAGON probe RENISHAW tool measurement Electronic handwheel OPT kinematics Chip conveyor Coolant pressure and flow control Collision and vibration monitoring Feed control Coolant gun MONTRONIX machine airbag Oil mist extraction 2 clamping plates Walk-in full enclosure with roof and opening for crane loading Included in delivery: Operating manual Documentation Machine parameters on USB stick

Condition: used, Year of construction: 2007, functionality: fully functional, 3 axe machine Siemens Sinumerik 840 D 1000 rpm Table 3300 x 950 mm X axe 950 mm Z axe 1750 mm Table loading 4000 kg Lrjdpfex Uqp Ssx Ad Nog

Year of construction: 1986, condition: used, Technical details: Lredpow Dz Tasfx Ad Nsg core drilling diameter max.: 16-65 mm bore depth: 600 mm total power requirement: 73 kW weight of the machine ca.: 6 t

Condition: ready for operation (used), Year of construction: 1983, operating hours: 6,348 h, functionality: fully functional, drilling depth: 1,500 mm, travel distance X-axis: 1,250 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 900 mm, drill diameter: 50 mm, The machine was overhauled in 2009! TECHNICAL DETAILS Drilling depth: 1,500 mm Drill diameter: 5 - 50 mm Travel X-axis: 1,250 mm Travel Y-axis: 900 mm Travel Z-axis: 900 mm Table length: 1,000 mm Table width: 1,000 mm Max. table load: 3,000 kg Spindle speed: 100 - 6,000 rpm Spindle taper: SK 40 MACHINE DETAILS Control: Siemens 802 D Dimensions & Weight Dimensions (L x W x H): 5,000 x 2,600 x 2,000 mm Weight: 6,000 kg Operating hours: 6,348 h Lodpfox Ngxrex Ad Nsrg

Condition: like new (used), Year of construction: 2019, operating hours: 454 h, functionality: fully functional, machine/vehicle number: 7438, drilling depth: 3,000 mm, total length: 11,515 mm, total width: 5,415 mm, total height: 2,350 mm, overall weight: 14,450 kg, spindle speed (min.): 13 rpm, spindle speed (max.): 1,800 rpm, rapid traverse Z-axis: 6,000 m/min, type of input current: AC, input voltage: 400 V, Deep drilling machine, in excellent conditions due to very limited usage - 454 hours. Tooling of different diameters available and included in the price. Selling because of business change. Lrodpfx Adsxzq Rye Njg

Condition: like new (used), Ryazan Model PT295106 Deep Hole Borer x 4000mm Manufacturer Ryazan Model PT295106 Year 1985 Condition Used Stock Number 2850 Centre Height 550mm Solid Boring Capacity 200mm Max Boring Length 4000mm Headstock Hollow spindle 500mm Headstock Spindle speeds 16-250 rpm Headstock drive 50/75kw Lrsdpsxzp Rlofx Ad Nog Max boring length in front of headstock 3500mm Max boring length if using the 500mm hollow spindle 4000mm

Condition: new, Year of construction: 2024, Technical specs CNC – 1100 Control Syntec 21MA-E Lrodpsu Nyxwefx Ad Nsg Drive system YASKAWA servo drive Main motor 7,5/11 Kw Spindle speed till 7000 Rpm Max drilling dept 1000 mm Drilling diameter 3 till 30 mm X stroke 1000 mm Y stroke 800 mm Z stroke 1000 mm cutting feed 0-300 mm/min inner hole accuracy 0.005mm Surface roughness of the hole Ra 3.2um spindle speed 7000 Rpm X servo motor 2.3Kw Y servo motor 3.0 Kw Z servo motor 2.3 Kw oil pump motor 5,5 Kw oil pressure 21 bar Filtration precision 20 um table loade 7000 kg machine weight 10 ton machine power 34 Kw. Capacity of cutting oil tank 800L Machine size 4,8 x 3,8 x 2.6 meter installation on request. price free on truck Rotterdam.

Condition: excellent (used), Heidenrich & Harbeck B3 SB Deep Hole Borer Lrjdpfx Adjw U Uhko Nsg 10,000mm Capacity, 4 off Steady Rests 2 off Boring Bar Dampers Swarf Tray & Baskets Tooling, Counter Rotation

Condition: used, Year of construction: 1965, core drilling diameter max. 50 mm bore depth 2000 mm swing diameter mm drilling capacity diameter max. 110 mm total power requirement 30 kW weight of the machine ca. 10 t Drilling Ø, approx. 2 - 50 mm Boring Ø, approx. 100 mm Drilling depth, max. (see stroke / mounting length) 1,600 - 2,000 mm Stroke of drilling slide, approx. 4,000 mm Distance between the two spindle heads 5,000 mm Height of centres above guideways 350 / 450 mm Drilling feed of drilling slide, infinitely variable 20 - 200 mm/min Quick feed of drilling slide 2,500 mm/min Spindle speeds via belt disks 260 - 650 / 650 - 1,625 rpm Lrodpfxot Hwuco Ad Njg Workspindle drive 24 kW Drive of coolant pumps 1 x 7.5/15 kW and 1 x 15/28 kW Total electrical load, approx. 60 kW - 380 V - 50 Hz Total length of machine / guideways 7,500 / 5,000 mm Weight, approx. 10,000 kg Accessories / Special Features * Machine consists of the following elements: Main spindle on the left-hand side, followed by the coolant oil supply device. Table group, driven by ball screw spindle. Coolant oil supply device with elevated height of centres. At the end is a headstock, Type B 16, with drive motor approx. 7.5 kW, n = 900/2400 and 2400/6000. Large coolant device with filter unit. Large selection of accessories and drilling tools with Ø up to 100 mm. * Machine is suitable for working with a rotating workpiece together with a fixed drilling tool (ELB and BTA Process), as well as for a fixed workpiece and a rotating drilling tool. It can work with internal oil feed (Elb) or with external oil feed (BTA). * Complete oil coolant unit with tank and filter and two SIG high pressure pumps. Number of litres can be set: 17 / 40 / 120 or 220 / 500 litres per minute. Capacity approx. 2,500 l. * Feed of main slide is via ball screw spindle and infinitely variable DC motor. Mounted on the main slide is at present a table, approx. 800 x 800 mm, cross-adjustable approx. 500 mm, and suitable for holding cubic and cylindrical workpieces. Electric control via cam rail, approx. 2,500 mm long. End switch for quick feed, feed and return. * 2 closed 3-point steady rests. * FORKHARDT 3-Jaw Chuck, manually operated, Ø approx. 315 mm. * Modernized control panel with speed display, feed setting and display, display for kW, switch for feed, quick feed, right/left, etc. * 2 separate switch cabinets, separate coolant oil display device, bushes, reducers, clamping helps and lots of other accessories. This is a very valuable machine because of all the accessories!

Condition: used, Year of construction: 1985, core drilling diameter max. 18 mm bore depth 320 mm swing diameter mm total power requirement 33 kW weight of the machine ca. 6 t Lrodpet Hwvaofx Ad Nsg dimensions of the machine ca. m

Condition: used, Year of construction: 1996, core drilling diameter max. 25 mm bore depth 1000 mm swing diameter mm total power requirement 25 kW weight of the machine ca. 12,5 t dimensions of the machine ca. m T B T (Germany) CNC-Controlled Horizontal Deep Hole Drilling " Centre " Model BWP 250 Year 1996, but reconditioned mechanically and electrically in 2006 _____ Working range: X Axis, machine column cross 2,000 mm Z Axis, drilling slide horizontal 1,200 mm Drilling depth 1.000 mm Y Axis, drilling slide vertical 1,100 mm Table clamping area 1,200 x 2,000 mm Drilling capacity in solid material, approx. 4 - 25 mm Tool holder taper HSK 50 Spindle speeds 1.260 - 15,000 rpm Feed rates / quickfeed, XYZ, infinitely variable 100 - 10,000/15.000 mm/min. Force rate of feed motors 27 Nm / 1.000 daN Lodpjt Hw Aysfx Ad Nsrg Spindle drive steplessly adjustable 7 kW Total electrical load, approx. 30 kW - 400 V - 50 Hz Weight, approx. 10,000 kg Accessories / Special Features: " Ideal machine for the complete processing of large workpieces like tool a. dies (cooling holes) mould- and dieplates, hydraulicparts etc. by means of deep hole drilling up to 25 x 1.000 mm, face milling up to Ø 60 mm, spiral twist drilling, counterboring and threading up to M 24 x 3 mm. " SIEMENS Continuous Path Control in 4 axes Model 840 D, with process monitoring for coolant pressure, operation data control function, toollife, feed force,Error diagnostics and easy dialogueprogramming directly on the panel, etc. " High Frequency Spindle Make GAMFIOR with stepless speeds " Hydraulically movable drill bush carrier, swivels 90° for holding gun drills (ELB) or picking up regular tools from the tool changer like twist drills, milling tools, taps, etc. " With automatic tool changer made by MIKSCH, Model CTM 40, using a 12-position tool changer, which is mounted on the r.h.side of machine housing, in fixed position, only moving forward and backward for tool changing operation. " Built-on indexing table as B-Axis made by FIBRO Model RTN 400 = 420 x 420 mm, " Extra Rotary Table made by FIBRO with Ø 1.000mm, for indexing 3-144 positions " Built-in coolant device with chip conveyor and various filters. " 2 steady rests. " Completely covered working area with access at the front and at the side. Condition : Very good condition. This is a rare and valuable machine. Under Power Delivery : immediately ex our Stock Payment : Net, after conclusion of contract.

Condition: used, Year of construction: 1990, core drilling diameter max. 6 mm bore depth 350 mm Lrsdpfxjt Hw A Tj Ad Neg swing diameter mm total power requirement 15 kW weight of the machine ca. 3500 kg dimensions of the machine ca. 5000 x 1200 x 2200 mm

Condition: new, Year of construction: 2025, heavy-duty construction with cast iron table Ljdsycg U Eopfx Ad Njrg smooth movements using hand lever and handwheel eccentric clamping device dowel drilling unit with 16-22-25-32 mm grid 2 spindle speeds: 1500/3000 rpm WESCOTT drill chuck 1 - 16 mm CE compliant Work table dimensions: 287 x 550 mm Longitudinal travel: 200 mm Vertical travel: 160 mm Cross travel: 125 mm Three-phase motor power: 1.8 kW, 400 V, 50 Hz

Condition: used, Year of construction: 1980, Number of drill spindles: 23 Pitch: 32 mm Drill bit holder: Screw-in thread Operation: Foot pedal Drilling direction: From above and from the front Swivel: Pneumatic Maximum throughput width: 720 mm Number of material clamps: 2 Type of material clamping: Pneumatic Design: Mobile Stop system: For hole line and construction line Dimensions: 1300 x 1200 x 1700 mm Approx. weight: 365 kg Motor power: 2.2 kW Storage location: Nattheim Ljdpfewkir Djx Ad Norg

Condition: used, Year of construction: 2000, Table size: 580 x 280 mm Drill table height: 800 mm Drilling depth: 150 mm Drilling length: 225 mm Height adjustment: 180 mm Swivel range: 2x 45° Drill speed: 2800 rpm. Wescute drill chuck: 0-20 mm dia. Extraction port: 80 mm dia. Motor power: 2.2 kW / 3 HP Space required: 850 x 1000 x 1050 mm Weight: approx. 240 kg Storage location: Nattheim Ledpfx Asxya H Isd Njrg

Condition: used, Year of construction: 1999, functionality: fully functional, Table length 630 mm Ledpfsybbaaex Ad Njrg Table width 285 mm Table height 800 mm Maximum drilling depth 180 mm Maximum height adjustment 200 mm Drill chuck 0 - 20 mm Motor power 2.2 kW Tiltable drilling unit Removable center stop With cam turret for drilling in various grids (Cam is missing)

Condition: used, x-axis / mm y-axis / mm z-axis / mm The boring mill is sold without clamping plates – the price refers exclusively to the boring mill. Technical data Horizontal milling and drilling machine with support sleeve Working range Vertical adjustment of the headstock from the clamping surface: 0 - 3000 mm Horizontal adjustment of the column: 7000 mm Lrjdpfoxdnraox Ad Neg Maximum drilling depth with drill spindle alone: 1200 mm Maximum drilling depth with drill spindle and support sleeve together: 1300 mm Drill spindle diameter: 150 mm Milling spindle diameter: 240 mm Support sleeve diameter: 390 mm Support sleeve extension: 700 mm Drill spindle tool holder: ISO 50 Maximum workpiece weight: 70,000 kg When placed in 4 prisms: 95,000 kg Main drive Total speed range, adjustable from 2 - 795 rpm Series 1 2 - 50.4 rpm Series 2 50.4 - 126 rpm Series 3 126 - 314 rpm Series 4 314 - 795 rpm Maximum drive power at rated speed 17.5 80 kW Quick adjustment speed of spindle box and column 1800 mm/min Rapid adjustment speed of drill spindle and support sleeve 1400 mm/min Fine adjustment speed of spindle box and column medium 75 mm/min Fine 3 mm/min Fine adjustment speed of drill spindle and support sleeve Medium 57.7 mm/min Fine 2.5 mm/min Feed of headstock and column for milling Row 1 3 - 75 mm/min Row 2 72 - 1800 mm/min Feed of drill spindle for drilling Row 1 0.19 - 4.7 mm/min Row 2 2.2 - 56 mm/min Row 3 56 - 1400 mm/min Special equipment Numerical length measuring device in horizontal and vertical directions Accuracy 0.01 mm Rotatable and movable clamping table, Collet & Engelhard, Offenbach Model Tdvmf 1.6 (for technical data, see ‘Clamping table’) Rotatable and movable clamping table from Scharmann, Rheydt Model DAV 1600 Rotatable and movable clamping table from Froriep, Rheydt Swivel crane for tool change, maximum load capacity 500 kg Special tools Carbide core drill bits for extracting core samples Universal facing and boring head from Wohlhaupter, Frickenhausen Model UPA7, with the following specifications: 1 division of the fine adjustment 0.01 mm in diameter 1 revolution of the fine adjustment 0.5 mm in diameter Facing and boring range 0 - 1250 mm Maximum slide adjustment 210 mm Automatic slide feed in mm/rev during facing 0.05 - 0.10 - 0.15 - 0.20 - 0.25 - 0.30 - 0.35 - 0.40 - 0.45 - 0.50 - 0.55 - Quick adjustment per revolution of the quick adjustment spindle 6 mm in diameter Largest diameter of the slide at zero position corresponds to the smallest drilling diameter of 323 mm Head height without shaft 260 mm
