Eccentric press ter Hart

Condition: excellent (used), consisting of: 2 pcs. Art. No. 47155: Makro Grip 125 Centering Vise, clamping range 155 mm Ltsdpfx Aexauacoffoa 1 pc. Art. No. 41350: Extended Stamping Unit 1 pc. Art. No. 41010: Center Marking Device for Stamping Unit 16 pcs. Art. No. 45570: Mounting Bolts, diameter 20 mm 1 pc. Art. No. 47520: Double Mounting Body 1 pc. Art. No. 47355: Makro Grip 125 Centering Vise, clamping range 355 mm 1 pair Art. No. 44251: Avanti Base Jaws 4 pcs. Art. No. 44258.76: Top Jaw 77x126mm for Avanti 125 4 sets Art. No. 45570.10: Spacer Mounting Bolts, diameter 20 mm 2 pcs. Art. No. 47255: Makro Grip 125 Centering Vise, clamping range 255 mm 3 pcs. Art. No. 45742: Plate L384xW384xH27 mm, 4-position grid plate 96 (photo attached) 1 set Art. No. 47355-TG27: Twin-Grip Conversion Kit for Makro Grip 125 No. 47355 1 pc. Art. No. 47520: Double Mounting Body 1 pc. Trolley for Stamping Unit

Condition: used, TECHNICAL DETAILS - Number of axes : 5 MILLING SPINDLE - Tool holder type : BT40 - Spindle power : 24/32 [kW] - Spindle speeds : 12000 [rpm] - Number of spindle hours : 9122 [h] LINEAR AXES - Travels on X/Y/Z axes : 650/765/520 [mm] - Rapid traverses rates (X/Y/Z) : 40/40/36 [m/min] - Cutting feed rates (X/Y/Z) : 18/18/18 [m/min] A ROTARY AXIS - Travel : 150 [°] (+/-) - Rapid traverse rate : 20 [rpm] - Cutting feed rate : 7200 [mm/min] B ROTARY AXIS - Travel : 360 [°] (+/-) - Indexing precision : 0.001 [°] - Rapid traverse rate : 30 [rpm] - Cutting feed rate : 7200 [mm/min] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur Lsdpfeuhbz Uox Affota - Tool magazine capacity : 120 - Tool exchange time : 1 [sec] TABLE - Table dimensions : 500 X 500 [mm] - Maximum weight upon table : 500 [kg] - Distance table / spindle nose (min./max.) : 160/680 [mm] PALLET CHANGER - Pallet size : 500 x 500 [mm] - Pallets number : 2 - Pallet exchange time : 30 [sec] POWER SUPPLY - Total installed power : 54 [kW] MACHINE HOURS - Number of hours under power : 24226 [h] - Number of working hours : 9122 [h] EQUIPMENT - CNC : Heidenhain TNC530 - Interface : RS232 / USB / PCMCIA - Electronic handwheel - 3 colors status lamp - Coolant tank * with high-pressure pump : 20 [bars] - Coolant through spindle - Chips conveyor - Spindle cooling unit - Tool probe : Renishaw - Electric transformer

Condition: as good as new (ex-display), functionality: fully functional, travel distance X-axis: 304 mm, travel distance Y-axis: 304 mm, table length: 1,054 mm, table width: 1,004 mm, warranty duration: 24 months, pump pressure: 2.068 bar, power: 3.7 kW (5.03 HP), 𝗢𝗠𝗔𝗫 𝗣𝗿𝗼𝘁𝗼𝗠𝗔𝗫 - 𝗱𝗶𝗲 𝗸𝗹𝗲𝗶𝗻𝘀𝘁𝗲 𝗪𝗮𝘀𝘀𝗲𝗿𝘀𝘁𝗿𝗮𝗵𝗹𝘀𝗰𝗵𝗻𝗲𝗶𝗱𝗮𝗻𝗹𝗮𝗴𝗲 𝗱𝗲𝗿 𝗪𝗲𝗹𝘁 The compactness in combination with the comprehensive versatility makes the ProtoMAX® waterjet cutting system a perfect system for e.g. the production of small series and prototypes as well as teaching applications. In addition, the ProtoMAX® can also be used as a supplement to larger waterjet cutting systems. Thanks to its small footprint, the ProtoMAX® waterjet cutting system is perfect for smaller spaces. Mounting the system on castors also makes it easy and uncomplicated to relocate. Ljdet A A A Dspfx Affeta ✔ 5 hp pump with over 2000 bar ✔ Up to 25 mm cutting thickness for a wide range of materials ✔ Efficient and reliable direct drive pump technology ✔ incl. laptop with pre-installed control software ✔ Quiet and clean underwater cutting (approx. 76 dB) ✔ Automatic switch-off of the pump in cutting mode as soon as the protective cover is opened ✔ Clamps to secure the material during cutting operation Prompt delivery can be arranged with INNOMAX AG. This is a demonstration machine.

Condition: used, Year of construction: 1996, charge load 135 liter 1220 mm tank diameter / tank height 1.220 / 1035 mm 304 mm motor capacity 0,75 kW Ltjdswcg Eropfx Affoa motor speeds: 1500 U/min voltage 400 V weight of the machine ca. 600 kg dimensions of the machine ca. 1,38 x 1,28 x 1,04 m Dryer - Serial-No.: 15772 / 96-08 - Machine ON: 44.854 h - Heat unit

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, travel distance X-axis: 2,400 mm, travel distance Y-axis: 2,850 mm, travel distance Z-axis: 1,000 mm, feed length X-axis: 20,000 mm, feed length Y-axis: 30,000 mm, feed length Z-axis: 20,000 mm, Droop & Rein Modimill built in 2001 Fidia C20 Ljdpovk Ubxsfx Affota

Condition: new, High performance threading machine with lead screw and optimal safety device against tool breakage. Program for single or continuous cycle. Electronically controlled motor braking for single cycle. Easy lead screw change by quick coupling. Technical data UNIMAX 3T GL: Threading capacity: M 4 - M20 Thread per hour: 800 Normal drilling capacity: 28 mm spindle: MK 3 thread depth: 90 mm drilling depth: 120 mm throat: 260 mm spindle / table: 220 - 600 mm table surface: 420 x 390 mm T-slot width: 14 mm column diameter: 110 mm total height: 1.300 mm weight: 250 kg special motor: 0,9 kW Mains connection: 400 V / 50 Hz 9 spindle speeds: 95 / 160 / 200 / 350 / 420 / 450 / 750 / 900 / 1,650 rpm Standard packing: C - 160x75x125 cm Lodpfegv I Unox Affeta Other accessories / options: Lead screw, tap holder, outfeed switch, forced-ventilated motor, die holder, flange quill, foot pulse button, two-hand start, LED machine light, minimum quantity lubrication system, base cabinet.

Condition: excellent (used), Year of construction: 2006, Technical Specifications: Press Brake: Model: AMADA HDS 1030 NT Working Length: 3100 mm Folding Width: 2700 mm Press Force: 100 t CNC Control: AMADA AMNC PC 3D-graphic 15-inch TFT Color Screen Controlled Axes: 7 Drive: Servo-Hydraulic Installation Height: 500 mm Motorized Adjustable Backgauge: 600 mm Thrust: 415 mm Stroke: 200 mm Working Height: 960 mm Motor Power: 9 kW Dimensions (Length x Width x Height): approx. 4300 x 2300 x 2950 mm Weight: approx. 8 tons Loading and Unloading Robot: Model: ASTRO-MP 20 Max. Capacity: 20 kg Number of Controlled Axes: 6 CNC control: AMADA AMNC II Drive: AC servo motor Bending robot: Model: ASTRO-100 NT CNC control: AMADA AMNC II Max. capacity: 20 kg Number of controlled axes: 5 Length of linear axis: 3080 mm Max. cutting size for sheet metal: 800 x 1000 mm Max. cutting size for profiles: 300 x 1800 mm Drive: AC servo motor Ltsdpfx Afewmw Acefsa The seller is not liable for typing or data transmission errors. The machine's appearance, technology, and wear are consistent with its age; used machines are sold without any warranty.

Condition: new, High performance threading machine with lead screw device. Safety device against tool breakage. Programs for single and continuous cycle, programmable thread depth, piece counter, LED light and electronically controlled motor brake for the single cycle. Easy change of lead screw by quick coupling. Normal drilling capacity 15 mm Thread cutting capacity M 3 - M 10 Threads per hour 1.000 Spindle MK 2 Thread depth 60 mm Drilling depth 100 mm Throat 250 mm distance spindle/table 185 to 541 mm Table surface 340 x 445 mm T-slot width 12 mm Column diameter 90 mm Total height 1,050 mm Weight 120 kg Special motor 0,55 kW Power supply 400 V/50 Hz BT 18 GL M00033 4 spindle speeds 320 min-1 560 min-1 1,000 min-1 1,600 min-1 Ljdpfsfrlndjx Affsta Also available as pillar drilling machine BS 18 GL (M00034)! Digital display for speed as standard. 200 mm longer column 14154

Condition: used, grinding diameter 350 mm grinding length 1000 mm centre height 175 mm dimensions of the machine ca. 3,6/3,5 m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the service for your is: Kellenberger Kel-Varia Baureihe mit Kelco 90 Steuerung. Mechanische Überholung: -komplette Maschine nach Kellenberger Messprotokoll überholt Ljdpfxouwv H Te Affsta -Neue servicefreundliche Kabine -Neulackierung Elektrische Überholung: -Neue moderne CNC-RUNDSCHLEIFMASCHINEN-Steuerung -Neu aufgebauter Schaltschrank -Neue Antriebstechnik -Austausch sämtlicher elektrischer Leitungen Berus Druckschalter etc. -Neue Absolut-Glasmaßstäbe in x- und z -Neuer Absolut Drehgeber (Bei-B-Achse) Standardausstattung: -WSS mit Konus MK5, optional mit Adapter MK5/Kurzkegel -RST mit MK4 Konus. Optional mit Feinverstellung -Schleifspindelstock T1/T2/T3 -T1 Schleifscheibendurchmesser 400mm -T2 Schleifscheibendurchmesser 300mm -T3 Innenschleifeinrichtung riemengetrieben. -Schleifspindelmotor 4,4kW -B-Achse hochauflösend -Marposs Messsystem zur Schleifscheibenvermessung. -Längspositionierung Marposs -GAP Control (Sensor am Schleifspindelstock) Optionen gegen Aufpreis: -HF Innenschleifspindel -Hochgenauer, höchst kippsteifer Werkstückspindelstock -Messteuerung Die Werkzeugmaschine entspricht zum derzeitigen Zeitpunkt nicht den grundlegenden Sicherheits- und Schutzanforderungen wie in der BetrSichV 2015 genannt. Eine Anhebung des erforderlichen Mindest-Schutzzieles ist mittels einer Gefährdungsbeurteilung nach BetrSichV zu ermitteln.

Condition: used, TECHNICAL DETAILS - distance between centers : 600 [mm] - center's height : 175 [mm] - table orientation : 11 [°] UNIVERSAL GRINDING WHEEL HOLDER HEADSTOCK - left grinding wheel dimension : 400 x 50 x 127 [mm] - right grinding wheel dimension : 225 x 20 x 76,2 [mm] - motor power : 3 [kW] - spindle speed : 1500 / 1700 / 2200 Ledpfx Aeuhbywjffsta - grinding-wheel holder headstock orientation : 270 [°] PART HOLDER HEADSTOCK - part-holder headstock orientation : 360 [°] - spindle speeds : 20 - 400 [Rpm] - internal taper : Morse 5 - motor power : 0,9 [kW] TAIL STOCK - internal taper : CM4 - quill stroke : 30 [mm] DIMENSIONS - floor surface : 2580 x 1680 [mm] - height : 1670 [mm] - weight : 2200 [kg] EQUIPMENT - broche intérieure FISCHER : 14.000 [tr/min]
