KADIGO Werkzeugmaschinen & Zubehör Handels GmbH

Condition: like new (used), Year of construction: 2021, Functionality: fully functional, Double spindle CNC lathe with 2 spindles, 3 turrets and 3 Y axes each turret with 15 stations, BMT 44 driven tool holder 2x C-axis 3x Y axis Fanuc 32i -TB control Bkk3N8Iqya Bar passage 65 mm Left spindle 15/11 KW, Hainbuch Spanntop mini Axle pull size 65 Right spindle 11/7.5 KW, Kitagawa three-jaw chuck Finished part gripper Conveyor belt Bar loader interface Coolant system, separate tank 200 l Cooling unit High pressure on turrets 1-3 via M function 15 bar/40 l/min 2x Brinkmann pump Renishaw tool measurement for all turrets Tool monitoring for spindle and AGW Spindle flushing through the counter spindle IKZ, Deublin Rotary distributor Hinged belt conveyor Transformer available immediately

Condition: new, Year of construction: 2024, Functionality: fully functional, FIVE STAR THM-460 Horizontal dual-head milling machine with indexing axis Ideal machine for milling and chamfering P-plates for toolmaking from 4 sides in one clamping. Basic technical equipment: Control system - FANUC 0i-MF - User-friendly touch screen, 10.4" color display - Dialog-supported data input Machining capacities - Workpiece length min./max.: 20 - 460 mm - Workpiece width min./max.: 20 - 460 mm - Workpiece height min./max.: 12 - 150 mm (opt. 180 mm) - Workpiece corner chamfer Cmax.: 10 mm Travel paths - X-axis (machine table): 620 mm - Y/Z-axis (infeed axis/headstock): 330 mm / 330 mm Drive power of the axes - X-axis motor: 2.5 kW - Y/Z-axis motor: 1.4 kW - B-axis motor: 1.4 kW Speeds - Rapid traverse X (machine table): 15 m/min - Rapid traverse Y (infeed axis): 10 m/min - Rapid traverse Z (headstock): 10 m/min - Manual feed: 0 - 1,500 mm/min - Automatic feed: 0 - 5,000 mm/min Main spindles - Two horizontally opposed milling spindles, designed for heavy-duty cutting - Drive type: Belt drive - Speed range: 100 to 1,000 min-1 each - Drive power: 11 kW each - Spindle interface: 2" / Ø50.8 mm each - Oil-cooled with separate spindle oil cooler (optional) Tools (standard) - Cutter head: Ø160 mm (opt. Ø200 mm) Note: Tools not included in the standard scope of delivery! Rotary axis (B-axis) - Indexing: (standard 5° pitch) Hqs3Nlflk - Indexing angle: 0°, 45°, 90°, 135° and 180° (for 2-sided machining) - Table size: Ø320 mm - Max. Max. load: 320 kg Workpiece alignment - 90° stop for easy positioning of the workpieces by the operator - Automatic measuring unit for detecting the workpiece position Guides - X-axis: Linear roller guide - Y-axis: Flat guide, TURCITE-B coated - Z-axis: Flat guide, TURCITE-B coated - 2 chip spirals (left and right) in the machine - Automatic spiral chip conveyor Miscellaneous - Central lubrication oil / air - Switch cabinet with heat exchanger - Machine sheet metal partial cladding - Support work table - Hand tool box - LED work light - 3-color warning light - CE declaration of conformity according to European directives Machine dimensions and weight - Machine size: 2,800 x 3,410 x 2,200 mm - Machine weight: approx. 7,500 kg Spindles - Power-Up spindle motor 15kW - Spindle interface 1-7/8" each, suitable for face cutter head Ø200 mm arbor diameter: Ø47.625 mm tools - Face cutter head Ø200 mm, MAROX-Tools Taiwan Type: SE545R/L0810, DC200 Rotary axis (B-axis) - Indexing axis, 5° increments, standard option Indexing angle: 0°, 45°, 90°, 135° Table size: Ø320 mm Max. Load capacity: 320 kg Compressed air, coolant and chip management - Chip compressed air nozzle, 1 piece each, external to the spindles, standard option (metal compressed air articulated tube) - Coolant system with separate cooling lubricant tank and low-pressure pump, as well as paper filter, tank capacity: 600 liters Filter capacity: 80 l/min. - Chip spirals (left and right) in the machine, standard option - Automatic hinged belt chip conveyor

Condition: good (used), Year of construction: 2008, Nakamura Super NTJ -B Y-axis +/- 45 mm and B -axis +/-91 ° turret top. fully servo-controlled 0.001° with additional 1° serration and disk brake Milling drive top and bottom Bar passage D 65 mm spindle left, 51 mm spindle right Drive power 18.5 / 15 KW left/ 15711 KW right Fanuc 18 iTB control system Spiral interpolation Ciqqadxou Air outlet left 10.4 "" screen 12-position turret for driven tools 24-position turret for turning tools (double holder technology) IRCO interface Collision check NT Nurse NC - Kit Speed correction switch for both spindles Work area light Automatic central lubrication for all axes mobile coolant tank door interlock transformer CE chip conveyor Coolant and air discharge through the right spindle 5 pairs of free M functions Finished part gripper G L = 150 mm D 65 mm Parts collecting tray A for material remnants Polygon function intilligent hand wheel Clamping top GR 65 Modular A6 3 jaw chucks right available immediately Automatic hours 29187 h

Condition: excellent (used), Year of construction: 2020, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,300 mm, controller manufacturer: Heidenhain, controller model: TNC 640, WORKSPACE CLADDING The work area is completely enclosed. - Opening width of the doors for UniSpeed 3000: 2900 mm DESIGN VIEWING WINDOW SAFETY GLASS ELECTRIC DOOR DRIVE Platform MAIN DRIVE Driven by a frequency-controlled liquid-cooled AC motor. The power is transmitted directly to the milling head without an intermediate gearbox. gearbox. - 32 kW drive power at 100% ED - 44 kW drive power at 40 % ED Torque depending on the selected speed variant. - Speed from 10 to a maximum of 6,000 rpm Dqm39J - Torque 637 Nm at 100% ED - Torque 875 Nm at 40 % ED TOOL HOLDER SK 50 BIG-PLUS AUTOMATIC UNIVERSAL MILLING HEAD IN ORTHOGONAL DESIGN (C-AXIS 1 ° ) - Liquid-cooled milling head - Cast construction made of GGG 60 - Axes swivel automatically - Swivel range of the milling head holder (C-axis) ± 180° in degrees - Swivel range of the milling head (A-axis) in degrees± 180° - Indexing of the axes via face gearing with Partial accuracy ±3 sec - 64,800 full degree positions can be programmed via the CNC control can be programmed - Milling head with maintenance-friendly half-shell technology - Low interfering contour due to compact design and completely internal media channels - Tool holder according to selected variant - The milling spindle is equipped with a hydromechanical tool tool clamping system HEIDENHAIN KINEMATICS OPT - Internal coolant supply - External coolant supply via nozzle ring - Drive via frequency-controlled, liquid-cooled main drive motor - Speed range depending on the selected speed option of the main drive Clamping surfaces for the work area: CNC ROTARY TABLE with generously dimensioned bearings - Clamping surface: 1,600 mm - Table load (centric): 8,000 - Maximum swing diameter of the workpiece: 2,400 mm Tool changer ToolTower AUTOMATIC TOOL CHANGER - Number of tools in the ToolTower: 102 places - Maximum tool diameter with full magazine: 125 mm - Maximum tool diameter with free neighboring slots: 250 mm - Maximum tool length: 500 mm - Maximum tool weight: 30 kg - Maximum tool load torque: 440 Nm - Pure tool change time: Approx. 7 sec. - Spindle position for tool change: vertical - Fixed position coding Coolant system 950 l Frequency-controlled high-pressure pump with infinitely variable pressure control via the control unit. Pump capacity: 32 I/min at max. 40 bar Coolant tank: 950 l Filter accuracy:

Condition: excellent (used), Year of construction: 2015, Functionality: fully functional, turning height: 1,700 mm, workpiece weight (max.): 10,000 kg, turning diameter over cross slide: 2,040 mm, turning diameter: 2,000 mm, feed length X-axis: 2,000 mm, feed length Z-axis: 1,661 mm, faceplate diameter: 1,600 mm, feed rate Z-axis: 3 m/min, total height: 6,177 mm, total width: 5,638 mm, total length: 3,937 mm, rapid traverse X-axis: 12 m/min, rapid traverse Z-axis: 12 m/min, type of input current: AC, rotational speed (max.): 258 rpm, rotational speed (min.): 1 rpm, torque: 16,070 Nm, table load: 10,000 kg, table diameter: 1,600 mm, year of last overhaul: 2024, Equipment: rotational speed infinitely variable, - CNC unit (FANUC 32i-A) - Automatic tool exchange unit (ATC) Use Pot quantities (18 Pot) For the linear cutting Standard tool holder Tool holder for the linear cutting - Chuck - Cutting oil Tank - Air Gun unit - Tool & Bed washing unit - Splash guard (Splash guard) - Hydraulic unit - Axis Slide Cover - Working lamp Hu3Nnh0 - warning lamp - Ladder and Hand Rail - Tool box for the standard maintenance - Manual MPG - Chip Conveyer

Condition: like new (used), Year of construction: 2022, Functionality: fully functional, 5-axis machine, gantry design, swivel rotary table A/C Pallet changing system: HS flex, 18 pallets, 6/3-fold storage Heidenhain TNC 640 124 WZG HSK 63 Travels : 650x650x500 mm Spindle speed 18.000 rpm Spindle power: 25/42 KW Blum tool breakage: LC 50 Heidenhain measuring probe Cun7Ys2Rty auto.door High pressure coolant system 80 bar scraper belt chip conveyor and much more. can be inspected under power available immediately.

Condition: new, Year of construction: 2023, Functionality: fully functional, with 8 pallets Fanuc M-Pro1 (0i-MF Plus) control system Travel X/Y/Z: 800/800/860 mm Rapid traverse X/Y/Z: 74/74/74 m/min Pallet size 500 x 500 mm Load capacity: 550 kg per pallet Workpiece size: Ø800 x H1,000 mm Tool holder: BBT 40 Number of magazine positions: 220 Max. Tool diameter: Ø95 mm Max. Tool diameter with free neighboring pockets: Ø185 mm Max. Wkz. length: 400 mm Max. Tool weight: 8 kg Spindle cone: BBT40 Big Plus™ Speed: 15,000 rpm Chip spirals on the right and left in the machine Coolant through the spindle Dual chip conveyor Fully-fledged 4th axis from PARKSON 50 kvA transformer Chc0Tqecz0

Condition: good (used), Year of construction: 2016, turning length: 558 mm, turning diameter: 175 mm, spindle speed (max.): 5,000 rpm, spindle bore: 42 mm, travel distance X-axis: 175 mm, travel distance Y-axis: 62 mm, 2 spindles 2 turrets with 12 stations each 2 Y-axes Control: Fanuc 31iA Main spindle: Spindle power 11 / 7.5 kW Spindle nose A2-5 Chcbo07Pbm Counter spindle: Spindle power 11 / 7.5 kW Spindle nose A2-5 Chip conveyor Bar feeder LNS Alpha 552 Parts catcher

Condition: excellent (used), Year of construction: 2008, Functionality: fully functional, Mori Seiki NL 2500 SMC/700 with counter spindle C-axis and driven WZG ran under oil. (Kraft and Bauer extinguishing system) Year of construction 2008 Control system: MSX-850III Short loading magazine from LNS Quick Load Servo II Turret with 12 stations, all driven C-axis on both spindles. Main spindle: Hainbuch clamping system BZI 65 Sub-spindle: Schunk 165 mm three-jaw chuck Integrated main spindle motor 18.5 KW. Integrated motor for the counter spindle head 11 KW. Direct motor for driven tools 5.5 kW. Starting torque of the motor 640 N/M. Motors without belts or steps. Main spindle size A2-8. Counter spindle size A2-6. Main spindle passage 80 mm. Rdclxlas Main spindle speed 4,000 rpm. Speed of motorized tools 6,000 rpm. Turning diameter 755 mm. Machinable diameter 365 mm. Machinable length 750 mm. Oil cooler for both Daikin spindles. Rapid traverse speed 30 m/min in X- and Z-axis. Indexing time for turret change 0.2 seconds. Two arms for automatic measurement of Renishaw tools. Interfaces via USB, PCMCIA card and RS 232. Interface for bar loader Automatic parts gripper Foot pedal for independent opening and closing of main and counter spindle chucks. Knoll filter system with high-pressure pump Transformer. Documentation Weight approx. 6,500 kg Machine can still be inspected under power available at short notice

Condition: new, Year of construction: 2022, Immediately available stock machine "NEW" (year of manufacture 10/2022), CNC Mini CNC lathe from PO LY GIM (Taiwan) A combination of main spindle, linear tool slide and additional 8-station SERVO tool turret Main features: Collet chuck, Model 25 Collet Chuck (161E) Foot switch for collet chuck OPEN / CLOSE Linear tool slide with 3 boring bar holders 8-station SERVO tool turret Compact parts catcher and conveyor belt Automatic belt chip conveyor, incl. chip cart FANUC control 0i-TF PLUS, 10.4" control screen Coolant system Bike7Nauyno Handwheel Central lubrication unit Work area lighting

Condition: new, Working area round 360 mm Working area quadrant 360 x 360 mm Working area bundle W x H 180 - 280 x 50 - 160 mm Cutting speed 20 - 100 m/min (infinitely variable) Saw blade dimensions 4,420 mm x 34 mm x 1.1 mm Hydraulic saw blade tensioning Multiple feed 500 mm Drive power 3.7 kW Machine size LxW 2,500 x 2,200 mm Machine weight 2,300 kg Standard equipment - Hydraulically controlled full-stroke double clamping system. - Driven by IE3 motor with inverter (PMSM, Euate IE4) - User-friendly NC touchscreen control with high-end system (NCIII CONTROL) - Feed rate display on the HMI (10" HMI screen) - Automatic chip conveyor - Automatic shuttle feed - IC board control for all electrical and hydraulic functions - Floating pendulum vice - Two-piece front vice - Stepless speed control by inverter Gmf8Bg - Hydraulic blade clamping - Roller bearings with hydraulically controlled carbide blade guide system - Automatic working height control through quick start sensor - Preset cutting counter with cut-off function - Nesting device for bundle cutting (hold-down device) - Power-operated blade cleaning brush - Saw blade monitoring with regard to standstill and blade breakage - Flushing hose for machine cleaning - Work light - Roller table with 2 m length - One M42 bi-metal saw blade - One set of tools and one toolbox

Year of construction: 2020, Condition: like new (used), Bar feeder for bar diameters from 5-65 mm previous use on a Mori Seiki machine as new condition , immediately free Steady rest 2Igfxpkv bar length 3 m many accessories Location : Switzerland

Year of construction: 2003, Condition: excellent (used), Matsuura MAM72-3VS, 5-axis vertical Machining center Year of construction 2003 Commissioning 2004 Fanuc 16iMB control X/Y/Z axis travel: 680 / 400 / 625mm B-axis travel: +65ºto -110ºC C-axis travel: 360º Distance pallet-spindle nose: -86 - 540mm (B axis is in position 0º) Pallet center to spindle nose distance: 60 - 685mm (B axis is in position -90º) Distance pallet center column guide: -25 - 375mm distance spindle center - column guide: 227mm distance OK floor-pallet surface: 1165mm Working surface diameter: 130mm Max. Pallet load: 60kg Spindle speed: 40 - 15.000 rpm Spindle taper: 7/24 steep taper #40, Big PLUS Spindle diameter: 80mm Max. Spindle Torque: 135Nm / 850 rpm (15/7.5kW) rapid traverse X/Y/Z: 30m/min B-axis: 10 rpm Cxm73Uzy C-axis: 13,5 rpm feed X/Y/Z: 1 - 15m/min B axis: 1 - 2160º/min C axis: 1 - 3600º/min Number of tools: 240 Max. tool Ø: 80mm with free neighbor stations: 150mm Max. Tool length: 260mm Max. Tool weight: 8kg Pallet changer with 40 pallets Max. Workpiece dimensions: 360mm Ø x 250mm height Machine height: 3210mm Machine weight: 11700kg floor space, approx.: 4945 x 3655mm Encoder for B- and C-axes, direct measuring system (Heidenhain) for X-, Y-, and Z-axis 30l/min / 20bar internal cooling Scraper belt chip conveyor timer power on / power off Measuring probe RENISHAW MP 10 Easy Probe Laser Renishaw NC 1 2MB memory 8 additional M-functions Number of tool offsets 999 Increase of workpiece coordinate systems from 6 to 54 Coordinate system rotation G68/G69 Automatic zero point tracking Program restart For further information on the machine, please refer to the enclosed brochure.

Year of construction: 2012, Condition: good (used), IEMCA Vip 80 E II Bar feeder Year of manufacture 2012 Dimensions round material: Ø Min. 5 mm (3/16") Ø Max. 80 mm (2") Dimensions hexagonal material (tap socket): Min. 5 mm (3/16") Max. 65 mm (2" 3/16) Side length square material Min. 5 mm (3/16") Max. 55 mm (2" 3/4) Minimum workpiece length 210 mm (3.3 ft) Maximum length workpieces 1615 mm (6.2 ft) Material capacity magazine (useful width) 650 mm (No. 65 workpieces with Ø 10 mm) Feed speed (adjustable): 0-1200 mm/sec Cj997Rp0Jz Return speed 1200 mm /sec Installed power 1 kW Air pressure 6 bar Weight of loading magazine 550 kg

Condition: new, AVEREX HS-540i GTS 2-APC, new machine Horizontal machining center with the possibility of adapting an optional round pallet storage (6-APC or 8-APC) Basic equipment - AVEREX MPro1 (FANUC 0i-MF Plus) - LCD color screen with 15" diagonal, MANUAL GUIDE i, QWERT* keyboard - iHMI - Intelligent Human Machine Interface - Program memory with 2 MB (MegaByte) and up to 1.000 programs, - 4-axis simultaneous operation (X,Y,Z,B) - AICC II Control with 200 blocks Look Ahead read ahead function - HRV3+ Servo Drives (digital servo current control) - JERK Control (jerk control) - Fine Surface Technology (High-Speed High Quality) - Extended workpiece coordinate system G54.1 P1 - P300 - Workpiece coordinate system G52 - G59 - Memory card (PCMCIA flash card) and USB slot - Network interface RJ45, Embedded Ethernet - Improved Embedded Ethernet function - Weekly timer: Auto. Power On/Off of the machine - High-speed skip function - Tool Offset Memory C - 400 pairs of tool offsets - 1.000 registerable programs - Programmable data input (G10) - Programmable spindle load monitoring M37/M38 - Tool Life Management - Extended macro variables (#100 - #199, #500 - #999) - Program Restart - Helical Interpolation - Cylindrical shell interpolation (G07) - Fixed cycles for drilling - Synchronous tapping (G84/G74) - Rigid tapping with bell-shaped acceleration/deceleration - Programmable mirroring, -scaling - Polar coordinates programming (G15/G16) - Chamfer or round corners (,C / ,R) - optional blanking blocks, up to 9 blocks - Custom macro programming Travels - travels X/Y/Z: 800/800/860 mm Speeds - rapid traverse X/Y/Z: 74/74/74 m/min - Feed rate during milling: 0 - 40,000 mm/min - Rapid traverse B: 66.6 min-1 - 1G+ Acceleration Pallet changer - lathe changer - Number of pallets 2-APC: 2 (machine / setup station) - pallet size 500 x 500 mm - hole grid: 5x 5 M16 x 25mm/deep, distance 100 mm - Payload: 550 kg per pallet - workpiece size 2-APC: Ø800 x H1.000 mm - workpiece size 6-APC/8-APC: Ø800 x H900 mm - Mechanical locking of the pallet clamp - Pallet clamping force: 9.8 kN x 4 cones (39.2 kN) - pallet height from floor: 1.100 mm - standard preparation for retrofit of a 4-fold pallet accumulator (HS-540) pallet storage (HS-540i GTS 2-APC ==> 6-APC, 2 + 4 pallets) High-speed tool changer - Tool holder: BBT-40 (opt. SK-40 DIN69871 or HSK-A63) - Number of magazine positions: 80 - Max. Tool diameter: Ø95 mm - Max. Max. tool diameter with free adjacent places: Ø185 mm - Max. Wkz.length: 400 mm - Max. Tool weight: 8 kg - Type: fixed station/chaotic table Ceb8Gwmmw8 - Speed: 16 sec. for 80 tools - Tool change time: 0,9 sec./2,1 sec. (heavy tool) - Chip to chip time: 3.0 sec./3.5 sec. (Heavy tool) Spindle Rotary axis - Manufacturer: PARKSON™ - Axis: full 4th axis - max. rotation: 66.6 rpm - indexing: 0.001° - Clamping torque: 5.000 Nm - Holding torque: 1.973 Nm Linear guides - Manufacturer: THK™ - Width: 45 mm - Guide shoes X/Y/Z: 190 x 120 / 120 x 70 / 154 x 86 mm Ball screw Coolant, chip and compressed air management

Condition: new, Year of construction: 2021, Functionality: fully functional, Stock machine "NEW" - available at short notice! (subject to prior sale) Control: Fanuc 0i-MF Plus, 10.4" with Manual Guide i & 2 MB NC memory LOOK-AHEAD function, 400 blocks Machine table: Table size: 950 x 550 mm Load capacity: 800 kg Width of T-slots: 18 mm Number of T-slots: 3 Distance between the T-slots: 150 mm Travel ranges: Travel X/Y/Z: 860/550/550 mm Spindle nose to table surface: 150 - 700 mm Linear guides & speeds: Ball guides in X/Y axis Roller guides in Z-axis Rapid traverse X/Y/Z: 40/40/30 m/min Feed rate for milling: 0 - 10,000 mm/min Smallest increment: 0.001 mm Tool magazine (CAM type) / changer: Number of magazine positions: 24 (optional 30, 40) System: chaotic Max. Tool diameter: Ø 75 mm Max. Max. tool diameter with free neighboring spaces: Ø150 mm (40 tools: Ø130 mm) Max. Wkz. length: 300 mm Max. Tool weight: 7 kg Spindle: Spindle taper: BBT-40 Big Plus® (optional DIN 69871 SK-40, SK-40 Big Plus®) Drive power (30min/cont.): 18.5/ 11 kW 15,000 rpm direct spindle drive Spindle oil cooler Coolant, chip and compressed air management: Coolant system incl. 300 liter tank and pumps External coolant around the spindle Chip spirals on the right and left in the machine bed Compressed air nozzle on the spindle (M32/M33) Compressed air through the spindle (M38/M39) Compressed air and coolant gun Miscellaneous: Swivel control panel Electronic handwheel (wired) Central lubrication oil / air Full enclosure Working light Heat exchanger on control cabinet Auto-Power OFF function Hand tool set Signal light Transformer 400 VAC, 50 Hz CE declaration of conformity in accordance with European directives Electrical and pneumatic requirements: Electrical connection: 36 kVA required. Pneumatic input pressure: 6 bar Dimensions: Machine size: B2,260 x D2,900 x H2,775 mm Required floor space: W3,160 x D3,000 x H3,000 mm (incl. chip conveyor ejection to the left) Machine weight: approx. 5,400 kg (net) Available special equipment: Spindle: - Direct drive spindle SK-40, 15,000 min-1 - Drive power (30min/cont.): 18.5 / 15 kW, (FANUC motor) Tool magazine / changer: - Tool drum magazine with 30 pockets, DIN69871, SK-40 Rotary or additional axes: - Preparation for 4th axis (FANUC controls), incl. cabling and Harting plug without axis driver Coolant, chip and compressed air management: - Bed flushing - IKZ cooling lubricant pump with 20 bar pressure, for directly driven spindles spindles - incl. cartridge filter - Belt chip conveyor incl. chip cart (chip conveyor at the front to the left side of the machine) Air extraction: - Extraction system AR Filter ARNO 2VF "Plus" series w. EPA filter, - motor protection switch, filter status indicator Motor protection switch, filter status indicator Accessory kit for AR filter with Ø150 mm connection Measuring and monitoring systems: Ceb7Jgh9X2 - BLUM TC50 touch probe with infrared transmission system for workpiece measurement, incl. probe holder, repeat accuracy: 1μm - Blum Z-Nano tool length measurement and Tool breakage monitoring in the machine, incl. holder - Auto-Door - Pneumatic interface workpiece clamping available immediately.

Year of construction: 1995, Condition: used, 3-axis machine Jfflacp Dialog 12 control Table size 800x400mm working range: x-axis movement 500 MM y-axis movement 400 MM z-axis movement 400 MM spindle speed up to 5,000 rpm Electr. handwheel

Condition: new, Year of construction: 2025, Fanuc 0i-TF PLUS Workpiece size: - Swing diameter over bed: Ø750 mm - Swing diameter over slide: Ø540 mm - Max. turning diameter: Ø400 mm B2Wumimkjc - Standard turning diameter: Ø221 mm - Max. turning length: 560 mm Travel ranges (flat-guided axes): - X-axis: 240 mm - Y-axis: 120 mm (± 60 mm), option - Z-axis: 700 mm Speeds: - Rapid traverse X/Y/Z: 30 / 10 / 30 m/min Main spindle: - Speed: 3,500 rpm - Drive power (30 min./const.): 18.5 / 15 kW - Torque (15 min. 25% / const.): 410 / 249.4 Nm - Spindle bearing inside: Ø140 mm - spindle nose: A2-8 - max. bar capacity: Ø81 mm - spindle bore: Ø91 mm - standard chuck size: Ø254 mm (10") Turret - driven tools with 5,000 rpm (5.5 / 3.7 kW) - tool holder: BMT-65 - drive power: 5.5 / 3.7 kW (15 min / const.) - torque: 52.5 / 26.6 Nm (15 min / const.) - max. speed: 5,000 rpm - max. drilling / thread diameter: Ø20 mm / M16 - smallest angle increment: 0.0001° coolant and chip management: - coolant system with 140 liter tank tailstock: - programmable, hydraulic movable - max. travel: 700 mm - quill diameter: Ø65 mm - Morse taper: MK-5 Y-axis with 120 mm travel - NC-controlled axis with a travel of ±60 mm Available at short notice
