Gang Drilling Machine

WEBO BKR

Condition: ready for operation (used), Year of construction: 2008, spindle speed (max.): 3,500 rpm, travel distance X-axis: 245 mm, travel distance Y-axis: 102 mm, travel distance Z-axis: 1,270 mm, overall weight: 6,300 kg, controller manufacturer: FANUC, controller model: 18i-TB, This 3-axis DOOSAN Puma 2500XLY horizontal turning machine was manufactured in 2008. It offers robust performance for precision turning operations. If you are looking to get high-quality turning capabilities, consider the DOOSAN Puma 2500XLY machine we have for sale. Contact us for more information. Additional equipment • Documentation/manual Machine Benefits Technical Machine Benefits Guedpfx Aajx D H Aqo Eed • Turning length: 1270 mm • Turning diameter over cross slide: 334 mm • Turning diameter: 334 mm • Spindle bore: 86 mm • Tool holder: 55 mm • Speed infinitely adjustable Extra Information Machine still under powerClamping range 30–150 mmMaximum opening 170 mmMeasuring arm for tool measurement

Condition: good (used), Year of construction: 2015, Ref. -No.: 10647 Manufacturer: DMG MORI Type: DMF 360-11 Year of construction: 2015 Type of control: CNC Control: Heidenhain iTNC 530 Storage location: Halberstadt Country of origin: Germany Serial no.: 2903XXXX Machine-No.: 591XX X-Travel: 3600 mm Y-Travel: 1100 mm Z-Travel: 900 mm Max. Workpiece Weight: 8000 kg Max. Tool Weight: 5 kg Max. Tool Length: ab Spindelnase 300 mm Workpiece Diameter With 2 Vacant Positions: 130 mm Tool Taper: HSK 63 Numbers Of Tools In Magazin: 120 Tool changer: 60 Gsdpfjzc D Hfjx Aa Eeud Spindle Speed: 20000 RPM Max. Torque: 288 / 187 Nm Rapid Travel X/Y/Z: 80 x 60 x 60 mm / min Main Drive: 35 / 25 kW Internal cooling: 40 bar coolant reservoir: 600 L. Further information: - Fixed table, often with an integrated NC rotary table (FD version) - Spindle: Standard speed is typically 10,000 rpm; more powerful variants are available as an option - Traveling column design: Ideal for pendulum machining and long workpieces - Stability: The mineral cast machine bed ensures high damping and precision - 5-axis: Usually equipped with an NC swivel milling head (B-axis) The machine can be viewed while powered on by appointment.

Condition: good (used), Year of construction: 1998, machine/vehicle number: 3815-130-3235, Offer 25380 Technical Data: - Drilling capacity in steel ST 60: 40 mm - Maximum drilling capacity in steel ST 60: 50 mm - Tapping capacity in steel ST 60: up to M 42 - Spindle taper: MK 4 - Spindle stroke: 200 mm - Spindle speeds steplessly adjustable: 40 – 1100 rpm - Right and left-hand rotation - 3 automatic feeds: 0.1; 0.16; 0.25 mm/rev - Throat depth: 350 mm - Max. distance spindle – table / baseplate: 790 / 1210 mm - Table with 2 T-slots: 630 x 540 mm - Table height adjustable via rack with hand crank - Drive: 400 V / 1.6 / 2.9 kW - Required floor space approx.: W 600 x H 2050 x D 980 mm - Weight approx.: 650 kg - Includes: - Tapping device - Quick-action drill chuck 1–13 mm - Emergency stop button - Work light Gjdpfx Aasxr Ayho Esud - Coolant device

Condition: used, number of spindles 4 bore capacity in steel (diameter) 23 mm bore stroke 150 mm total power requirement kW weight of the machine ca. t Gujdpfx Aajt Hw U No Eod dimensions of the machine ca. m

Condition: good (used), Year of construction: 2010, Machine have live tools option and Y axis. Cutting tools not come. Parts shown by hand not come. Gjdpfx Asxpw Nloa Eeud Technical details shown on pictures.

Condition: excellent (used), functionality: fully functional, Year of construction: 2012, operating hours: 55,771 h, laser hours: 35,157 h, laser power: 3,200 W, sheet thickness (max.): 20 mm, sheet thickness steel (max.): 20 mm, sheet thickness aluminum (max.): 8 mm, table length: 3,000 mm, table width: 1,500 mm, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 150 mm, positioning speed: 140 m/min, positioning accuracy: 0.02 mm, year of last overhaul: 2024, feed length X-axis: 3,000 mm, feed length Y-axis: 1,500 mm, feed length Z-axis: 150 mm, Equipment: cooling unit, documentation/manual, safety light barrier, The laser is in operation, can be inspected and tested. Regularly serviced in good technical condition. Mirrors completely replaced in 2024. Gusdpfxsv Hxbbo Aa Eed

Condition: good (used), Year of construction: 1975, Meuser horizontal boring and milling machine model M 76 BF 5.5 kw Drilling depth 76 mm Spindle holder MK 5 Guodpet T Rkdsfx Aa Eod Table 1000 x 1000

Condition: used, TECHNICAL DETAILS - Number of axes : 10 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 32 [mm] - Travel : 240 [mm] - Spindle speeds : 8000 [rpm] - Spindle power : 7.5 [kW] - C axis indexing precision : 0.1 [°] COUNTER-SPINDLE - Max. bar diameter : 32 [mm] - Spindle speeds : 6000 [rpm] GUIDE BUSH HOLDER 1 - Number of positions : 5 GUIDE BUSH HOLDER 2 - Number of positions : 5 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] END ATTACHMENT Guedpfx Aeuhax Eea Eod - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] SECONDARY OPERATION - Number of positions : 7 - Number of motorized positions : 3 - Live tools speed : 6000 [rpm] POWER SUPPLY - Supply voltage : 400 [V] MACHINE HOURS - Number of working hours : 56.433 [h] EQUIPMENT - CNC : Fanuc - Rotating tool motor on : S2,S3,S5 V+H - Rotating guide bush - Parts catcher - Ejection of workpiece - Chips conveyor - Coolant tank * with high-pressure pump - Number of turning tool holders : 3 - Number of fixed tool holders : 7

Condition: used, TECHNICAL DETAILS - Number of axes : 10 - Number of spindles : 2 MAIN SPINDLE - Max. bar diameter : 25.4 [mm] - Max. machining length : 200 [mm] - Spindle speeds : 10000 [rpm] - C axis indexing precision : 0.1 [°] COUNTER-SPINDLE - Max. bar diameter : 20 [mm] - Spindle speeds : 10000 [rpm] - Spindle power : 3.7 [kW] - C axis indexing precision : 0.1 [°] - Number of guide bush holders : 2 GUIDE BUSH HOLDER 1 - Number of positions : 5 GUIDE BUSH HOLDER 2 - Number of positions : 5 - Number of motorized positions : 4 - Live tools speed : 8000 [rpm] END ATTACHMENT - Number of positions : 4 - Number of motorized positions : 4 - Live tools speed : 6000 [rpm] SECONDARY OPERATION - Number of positions : 7 - Number of motorized positions : 3 - Live tools speed : 8000 [rpm] POWER SUPPLY Guedeuha Ugopfx Aa Eed - Supply voltage : 400 [V] - Total installed power : 14 [kW] WEIGHT & DIMENSIONS - Machine floor space : 2270 x 1650 [mm] - Machine height : 2200 [mm] - Machine weight : 3500 [kg] MACHINE HOURS - Number of working hours : 80490 [h] EQUIPMENT - CNC : Fanuc - Rotating tool motor on : S2,S3,S5,S6 - Rotating guide bush - Parts catcher - Ejection of workpiece - Chips conveyor - Coolant tank * with high-pressure pump - Bar loader : ROBOBAR SBF 532 - Oil mist extractor - Cooling unit

Year of construction: 2000, condition: good (used), Pressing force 28 t X-axis 2000 mm Y-axis 1000 mm Machine weight approx. 11000 kg Guedji Eld Uepfx Aa Eed
