Used Weiler Primus Vc for sale (209)

Condition: excellent (used), functionality: fully functional, Weiler Primus GS lead and feed screw lathe 3 axis digital readout Easson- ES8 from training workshop Super condition !!! Technical data: >> Year of construction approx. 1990 Machine no. 3768 >> Center height 120 mm >> Center width 430 mm >> Speed: 60 - 3000 rpm in 18 gear steps >> Spindle clearance 23 mm >> Short taper spindle head DIN 4 >> Tailstock MK 2 >> Feed rates from 0.03 to 0.15 mm /rev >> Possible threads metric, inch, module and diametral pitch Lrsdevkfhpopfx Af Eeu >> Metric thread pitches from 0.25 to 2.5 mm >> Weight approx. 360 kg >> Length 1.2 m, height 1.3 m, depth 0.65 m Accessories and equipment: >> 3-axis digital display from Easson ES8 >> collet chuck device from 1 to 20 mm collets 1 mm rising with holder and draw tube >> 1 three-jaw chuck with 2 sets of jaws >> 1 four-jaw chuck with 2 sets of jaws >> Mulifix size A with 3 steel holders >> Bed stop >> Turning device To the machine : We are offering a Weiler Primus lathe built around 1990 in excellent condition. The machine is of course fully functional. The slides all run very smoothly and evenly. The bed guides are in very good condition. The Weiler runs smoothly even at high speeds. The machine comes from a training workshop of a large company. This newer generation of Weiler lathes is very user-friendly and surfaces can be produced as if ground. Take the opportunity to inspect this machine on site under power and see for yourself its condition.

Condition: new, Intern VC plus The new dimension in the field of conventional precision lathes. High-quality, energy-efficient, precise and universally applicable in production, training and further education. It convinces through: future-oriented technology highest accuracy durability user-friendly ergonomics smallest footprint and extensive accessories. The consistent and innovative further development of the practice-proven Praktikant series is the economical and intelligent solution for your daily applications. Technical data: WORKING RANGE Center height 160 mm Swing over bed 320 mm Swing over cross slide 190 mm Center width 650 mm ROTATING SPINDLE spindle head DIN 55027/DIN ISO 702-3 size 5 spindle bore 43 mm Spindle diameter in front bearing 70 mm MAIN DRIVE drive power 60 %/100 % ED - / 8 kW speed range 25 - 5.000 min-1 Number of speeds stepless FEED RANGE Number stepless longitudinal 0.01 - 6 mm/rev plane 0.003 - 2 mm/rev THREAD CUTTING RANGE Metric thread 0.1 - 20 mm REITSTOCK quill diameter 40 mm quill stroke 85 mm Inner taper DIN 228 MK 3 ACCEPTANCE ACCURACY DIN 8605 Lredshw N Ntepfx Af Eju Equipped with WEILER WTS 15 VC plus screen display - Large, clear 15" touch screen, rotatable and tiltable, resolution 1366 x 768 - Change of operating screens via swiping movements - Operating functions can be called up via App Manager - Control panels can be freely configured,

Condition: reconditioned (used), functionality: fully functional, center height: 160 mm, center width: 650 mm, rotational speed (max.): 4,000 rpm, Equipment: rotational speed infinitely variable, Dear Sir or Madam, For sale is a Weiler Primus VC / Praktikant VC lathe. This model series is particularly distinguished by its Siemens control panel and completely stepless speed control. As the name suggests, the VC can operate at a constant cutting speed. The machine has undergone a comprehensive partial overhaul in our workshop, so it is in excellent technical and visual condition. All guides are in working order, the gears run quietly, and the levers shift easily. You are welcome to visit us to see the condition for yourself. Availability: upon request Center height: 160 mm Center distance: 650 mm Spindle bore: Ø 40 mm Tailstock taper mount: MT3 Quill stroke: 85 mm Possible thread types: Metric, inch, module, diametrical pitch Metric thread pitches: 0.25 - 8 mm Spindle brake: switchable Voltage: 400 V Dimensions: approx. 1.60 x 1.00 x 1.50 m (L x H x W) Weight: approx. 750 kg Other equipment and accessories: Siemens control panel, coolant system, chuck guard, lead screw and feed screw covers, 2 emergency stops, operating instructions, CE declaration of conformity, and much more upon request... Our service promise to you: Ljdswhx I Njpfx Af Ejru - We are a certified master craftsman in the field of mechanical engineering - All machines undergo at least a workshop inspection - All lubricants and any worn parts will be replaced in advance. - Upon request, we can fully or partially overhaul the selected machine. - Upon request, we can repaint the selected machine in your desired color. - Upon request, you can order additional accessories such as tools, etc. directly. - Upon request, we can install additional accessories such as safety devices, etc. - We are happy to take care of shipping and/or delivery.

Condition: used, functionality: fully functional, Distance between centers: 450 mm Center height: 120 mm Spindle bore: 23 mm Speed: 30 – 3000 rpm Tailstock: MT 2 Drive power: 1.5 kW Lrsdpfx Aowcxf Djf Eeu Weight: 350 kg Dimensions: 1200 x 650 x 1330 mm Paint finish: Reseda green RAL 6011. Digital display: Available upon request for an additional charge. Accessories: Additional accessories available upon request! We are also happy to offer this machine completely overhauled!

Condition: excellent (used), functionality: fully functional, Weiler Primus guide and feed spindle table lathe in excellent condition! Technical specifications: >> Machine no. 2801 >> Center height 120 mm >> Center distance 430 mm >> Speed: 60 - 3000 rpm in 18 gear steps >> Spindle bore 23 mm >> Short-taper spindle head DIN 55027 >> Tailstock MT 2 >> Feed rates from 0.03 to 0.15 mm/rev >> Possible thread sizes: metric, inch, module, and diametrical pitch >> Metric thread pitches from 0.25 to 2.5 mm >> Length 1.2 m, height 1.3 m, depth 0.65 m Accessories and equipment: >> 1 x Röhm 125 mm three-jaw chuck with 4 sets of jaws >> Collet chuck with collets from 2 mm to 12 mm, increments of 1 mm Drawbar >> Multifix size A with 4 tool holders >> Change gears >> Fixed steady rest >> Faceplate >> Spindle cover Lrsdpfx Afev Tyzce Eju >> Clamping tool About the machine: Offered is a Weiler Primus table lathe with guide rail and drawbar in very good condition. The machine is fully functional. All slides run very smoothly and evenly. Even at high speeds, the Weiler runs quietly. The Primus comes from a state-owned company where it was used little. This newer generation of Weiler lathes is very user-friendly, and surfaces can be produced with a polished finish. Take advantage of the opportunity to view this machine on-site under power and see for yourself its condition. (The base cabinet is included; the machine is not bolted to the machine.) A digital display is available for an additional charge.

Condition: excellent (used), Year of construction: 2003, Weiler Praktikant VC precision lathe Year of manufacture: 2003 Technical details Turning diameter: 250 mm Turning length: 650 mm Center height: 160 mm Swing diameter over bed slide: 320 mm Max. swing diameter over cross slide: 190 mm Main spindle: Speed range – main spindle: 30 – 4,000 rpm Power output – main spindle: 10 / 6.0 kW Number of gear stages: 1 Spindle head: 5 / DIN 55027 Spindle diameter in front bearing: 70 mm Spindle bore: 40 mm Usable bar diameter: 40 mm Tool holder: System: MultiFix B Turning tool shank cross-section: 20 x 20 Tailstock: Quill travel: 85 mm Lrsdpfx Asw Ea H Ijf Esu Quill diameter: 40 mm Tailstock taper: MK 3 Feeds: Number of feeds: 24 Longitudinal feed: 0.02 – 0.63 mm/rev Cross feed: 0.006 – 0.2 mm/rev Thread cutting: Metric: 0.25 – 8 mm Inches: 80-2 1/” Module: 0.25 – 4 mm Travel distances: Cross slide travel: 150 mm Top slide travel: 110 mm Swivel movement: 180 ° Total power requirement: 15 kVA Machine weight: approx. 1.0 t Space requirements: approx. 2.5 x 2.0 x 2.0 m Accessories/options: - Documentations - 3-jaw chuck diameter 160mm, with jaws - 4-jaw chuck diameter 160mm, with jaws - 4-jaw chuck diameter 200mm, with jaws - Collet type chuck with collets - Tailstock - Multifix tool holder, with holders - Steady - Change gears - Different kind of tooling - Lista cabinet - etc... Under power in our warehouse.

Condition: like new (used), Year of construction: 2019, functionality: fully functional, Weiler Praktikant VCD Precision Lead and Feed Screw Lathe with 3-axis Digital Readout, Infinitely Variable Speed, As-new Condition, Year of Manufacture 2019 Technical Data: >> Year of manufacture: 2019 Machine no. OD08 >> Centre height: 160 mm >> Swing over bed: 320 mm >> Swing over cross slide: 190 mm >> Distance between centres: 650 mm >> Spindle speeds: 30 to 4000 rpm (infinitely variable) >> Spindle bore: 43 mm >> Short taper spindle nose DIN 55027 size 5 with bayonet lock >> Tailstock: MK 3 >> Number of feeds: 24 >> Longitudinal feed: 0.02 to 0.63 mm/rev >> Cross feed: 0.006 to 0.2 mm/rev >> Thread cutting: Metric, Inch, Module, and Diametral Pitch >> Metric thread pitches: 0.25 to 8 mm >> Weight: approx. 1150 kg >> Spindle brake >> Dimensions (LxHxD): approx. 1.72 m x 1.7 m x 0.89 m Accessories and Equipment: >> Weiler digital readout >> New collet chuck system; new collets from 3 to 26 mm >> 160 mm 3-jaw chuck with 1 set of jaws >> Multifix size B with 3 tool holders >> 1 bed stop >> Splash guard >> Coolant system >> Machine lamp >> Operating manual, spare parts plan Safety Features: >> Lockable main switch >> Emergency stop button >> Electrically monitored chuck guard >> Automatic disengagement of the relevant handwheel when feed is engaged VCplus Digital Readout: >> 8-inch color screen >> 3 axes for bed, cross slide and compound slide >> 99 tool memory locations >> Oriented spindle stop Lodpow Swkvsfx Af Eeru >> Input for constant speed or cutting speed >> Feed rate and thread settings displayed >> Thread cutting with electronic stop About the machine: Offered here is a Weiler Praktikant VCD Precision Lead and Feed Screw Lathe with 3-axis digital readout. Year of manufacture 2019, in as-new condition with original paint. The machine is, of course, fully functional and equipped with new collets and chuck. You are welcome to inspect the machine under power on site and see its condition for yourself.

Condition: new, Year of construction: 2022, operating hours: 3 h, functionality: fully functional, Commodor 230 VCD Lathe, NEW CONDITION The Commodor series has been the benchmark for long-term precision for decades. These field-proven, high-quality, and powerful production lathes are designed for universal use in industry, toolmaking, skilled trades, and education. Features: Center distance 1000 mm Center height 230 mm Automatic handwheel release Lead and feed screw covers Holding brake Toolmaking precision according to DIN 8605 Frequency converter and speed potentiometer for continuous speed control High drive power on the main spindle Large thread cutting range Digital speed display Convenient operation LED machine light WORKING AREA Center height 230 mm Swing over bed 475 mm Swing over cross slide 270 mm Center distance 1000 mm TURNING SPINDLE Spindle head DIN 55027/DIN ISO 702-3 Gr. 6 Spindle bore 56 mm Spindle diameter in front bearing 90 mm MAIN DRIVE Drive power 60%/100% duty cycle – / 11 kW Speed range 25 – 2,000 rpm Number of speeds: continuously variable FEED RANGE Number 320 Longitudinal 0.026 – 7.4 mm/rev Cross 0.013 – 3.7 mm/rev THREADING RANGE Metric threads 0.3 – 80 mm Ledpfx Afev Tv R Ho Eoru TAILSTOCK Quill diameter 70 mm Quill stroke 150 mm Internal taper DIN 228 MK 4 ACCEPTANCE ACCURACY DIN 8605 The WEILER screen display for the VCD series with constant cutting speed (V-constant) 3-axis display for Bed, cross, and top slides Direct speed input and display Constant cutting speed Freely selectable speed limit (lockable via key switch) Oriented spindle stop Tool technology memory for 99 tools Power display in percent (graphic) and kW Axis display deactivation via key switch (for training purposes) Accessories RÖHM three-jaw chuck 250mm RÖHM three-jaw lathe chuck DURO-M, DIN 55027 Fixed steady rests 5 x Multifix size B Movable chip guards Numerical position indicators About the machine: Offered is a Weiler Commodor 230 VCD lathe in new condition. The Weiler has 3 spindle hours. The machine is CE-compliant. Take advantage of the opportunity to view and try out this machine on-site under power.

Condition: ready for operation (used), operating hours: 33,600 h, functionality: fully functional, spindle bore: 83 mm, center width: 2,000 mm, turning diameter over bed slide: 570 mm, spindle speed (max.): 2,500 rpm, controller model: Siemens 810D, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Swing diameter over bed: 570 mm Swing diameter over carriage: 340 mm Centre distance: 2,000 mm Speed range, stage 1: 1–625 rpm Speed range, stage 2: 4–2,500 rpm Spindle bore: 83 mm Spindle nose: Size 8 DIN 55027 Feed range longitudinal/cross: 0–20 mm/rev Metric threads: 0.1–400 mm Inch threads: 1/4–56 TPI Tailstock quill diameter: 80 mm Taper: MK 5 MACHINE DETAILS Lrjdpfx Afoxqpgfs Eeu Control: Siemens 810D Electrical data Main drive: 20/17 kW Connected load: 30 kW Dimensions (L x W x H): 4,000 x 2,300 x 1,800 mm Operating hours: 33,600 hours EQUIPMENT Rapid traverse longitudinal/cross 8-position Sauter tool turret incl. holders Mayfran chip conveyor with coolant system Movable chip guard cover 3-jaw chuck Schunk Rota S 250 Manuals Note: The viewing windows and feed selection levers have been replaced. In addition, an oil change has been performed and the oil filter replaced.

Condition: ready for operation (used), turning length 500 mm turning diameter over bed 297 mm turning diameter over slide rest 160 mm spindle bore 36.0 mm tool adaptor DIN 55022 Gr. 5 quill: 3 MK quill travel 90.0 mm turning speeds 30 - 3550 U/min motor speeds: 1410 / 2830 U/min total power requirement 3.3 kW voltage 380 V weight of the machine ca. 620 kg. range L-W-H 1420 x 700 x 1200 mm from a vocational school - in very good condition (!!) particularly suitable for medium-precision turned parts Features: - Robust lead/feed screw lathe - RÖHM three-jaw chuck Ø 160 mm - Foldable lathe chuck guard - Chuck key - MULTIFIX steel holder A, with 3x new inserts - Movable tailstock - Swiveling machine light - Control panel, front left - Automatic feeds for face and upper support Lrsdpfx Afsxq Hh Hs Eeu - Machine base, with cabinet door (storage space) - Chip splash guard rear panel - 1x empty tool cabinet - Emergency stop button - Operating instructions

Condition: used, Technical data : Center width approx. 500 mm Center height above bed 125 mm 16 speeds from 125 - 2800 rpm Space requirement, length x width 1.2 x 0.6 m Estimated weight approx. 450 kg . Scope of delivery : Hand lever quick clamping device Electrical monitoring of whether the part clamping lever is in the open or clamped position Lodjxq E Dmepfx Af Esru 1 set of collets from 3.0 - 25.0 mm, increasing by 1 mm Cross support with two tool holders Turret with 6 tool holders .

Condition: used, This Weiler Condor lathe is being auctioned online in our industrial/machinery insolvency auction – SK Hydroautomation GmbH – CNC machines – workshop equipment – material. Lrjdpjxqyp Defx Af Eju

Condition: used, Year of construction: 2000, Technical details: turning length: 750 mm turning diameter over bed: 330 mm turning diameter over slide: 160 mm spindle bore: 42 mm Ledpfx Aexp I E Dsf Eoru turning speed range: 1 bis 4500 U/min drive capacity - spindle motor: 10 kW diameter of quill: 50 mm quill stroke: 130 mm control: Weiler Zyklensteuerung D2 rapid travel - longitudinal/face: 8 m/min weight of the machine ca.: 2100 kg Teach-in lathe, PARAT toolholder basicsystem prepaired for collets 3.chaw-chuck SCHUNK Rota S plus D = 200 mm Yuear of teh Machine 2000, complet retrofitted in 2018 for € 53.000.- Original Invoice exists Control-Update new D2 - V2.07 Machine in very good condition Machine under power *

Year of construction: 2006, condition: ready for operation (used), This Weiler DZ65 was manufactured in 2006. A horizontal turning machine featuring a chip conveyor, counter spindle, extraction system, interface bar feeder, and an in-machine puller for 1m bars. It also boasts an enlarged coolant tank. Consider the opportunity to buy this Weiler DZ65 horizontal turning machine. Contact us for more information. Lodpfsxp Sp Hox Af Eeru Application Types Turning

Condition: used, Technical details: turning diameter over bed: 570 mm turning diameter over support: 340 mm turning length: 1000 mm switched on hours: 37917 h centre distance: 1000 mm swing diameter over bed: 570 mm swing diameter over face slide: 340 mm centre height: 280 mm spindle bore: Ø 66 mm revolution per minute: 1 - 625 steples U/min max. torque on the spindle: 1600 Nm longitudinal feeds:: 0 - 20 mm/U cross feed: 0 - 20 mm/U tailstock quill adjustment:: 160 mm tailstock quill: MK 5 mm Lrodpexg Nhnsfx Af Eju total power requirement: 20 kW weight of the machine ca.: 3,2 t dimension machine xH: 2,9 x 2,28 x 1,8 m Machine has been overhauled/refurbished: Ball screw Z overhauled, X-axis end position overhauled, new paint job. Conventional design with integrated automatic cycle control. Metric thread cutting, inch threads, DP threads. Chip conveyor not available. 4-jaw chuck with steady rest available. 3-jaw chuck mounted. *

Condition: ready for operation (used), turning length 500 mm turning diameter over bed 297 mm turning diameter over slide rest 160 mm spindle bore 36.0 mm tool adaptor DIN 55022 Gr. 5 quill: 3 MK quill travel 90.0 mm turning speeds 30 - 3550 U/min motor speeds: 1410 / 2830 U/min total power requirement 3.3 kW voltage 380 V weight of the machine ca. 620 kg. range L-W-H 1420 x 700 x 1200 mm from a vocational school - in very good condition (!!) particularly suitable for medium-precision turned parts Features: - Robust lead/feed screw lathe - RÖHM three-jaw chuck Ø 160 mm - Foldable lathe chuck guard - Chuck key - MULTIFIX steel holder A, with 3x new inserts - Movable tailstock - Swiveling machine light - Control panel, front left - Automatic feeds for face and upper support Lrodpfx Aexq Hhyjf Eeu - Machine base, with cabinet door (storage space) - Chip splash guard rear panel - 1x empty tool cabinet - Emergency stop button - Operating instructions

Year of construction: 1973, condition: excellent (used), turning length 125 mm Lodpfxexpxqws Af Esru weight of the machine ca. 0,4 t

Condition: used, Year of construction: 1997, - Drive system: Teach-in - Centre height [mm]: 210 - Swing over bed [mm]: 420 - Distance between centres [mm]: 900 - Spindle bore [mm]: 55 - Min. spindle speed [rpm]: 4 - Max. spindle speed [rpm]: 3000 - Options: Digital readout - Type of digital readout: Weiler - Year: 1997 - Documentation available: Yes Lrodpfx Aewnh I Sef Eeu - CE marking present: Yes - Serial number: 270 - Control: CNC Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Year of construction: 1977, condition: ready for operation (used), A Weiler precision lathe, overhauled by Mammut in 2004, is available. Center height: 125mm, max. swing over bed/cross slide: 260mm/140mm, distance between centers: 500mm, spindle bore: 28mm, clamping range: 1mm-26mm, drilling diameter: 22mm, cutting edge height: 22mm, tailstock quill diameter: 80mm, tailstock quill travel: 80mm, tailstock offset: 450mm. Documentation available. An on-site inspection is possible. Lrjdpfxexqqmte Af Eeu

Condition: excellent (used), Year of construction: 1992, Weiler Condor 81 Weiler Condor 81 lathe with Heidenhain digital display, year of manufacture 1992, in very good original condition. The machine comes from the training workshop of a renowned German mechanical engineering company. Technical data: Year of manufacture: 2003 Engine lathe WEILER type Condor 81 Lredpew T U Sgsfx Af Esu Distance between centers: 750 mm Swing over bed: 330 mm Center height over bed: 165 mm Swing over cross slide: 180 mm Center height over cross slide: 90 mm Spindle bore: 40 mm Chuck fitting: short taper DIN 55027 size 5 Tailstock quill taper: MK 3 Quill travel: 110 mm Spindle speed: 45 – 2800 rpm, 16 steps Drive power: 3 kW Power supply: 400 Volt, 50 Hz Spindle speeds via 16-speed gearbox Required space (L x W x H): 1850 x 950 x 1400 mm Weight: 1,100 kg Accessories and equipment: Röhm 3-jaw chuck Multifix quick-change toolpost Coolant installation Heidenhain digital readout About the machine: We offer a Weiler Condor 81 lathe with Heidenhain digital display, year 1992, in very good condition. The machine is, of course, fully functional. All slides move very smoothly and evenly. Even at high speeds, the Weiler runs very quietly. This newer generation of lathes is very user-friendly and can achieve ground-like finishes. Take the opportunity to inspect this machine under power at our location and see its condition for yourself. You can find more lathes from renowned manufacturers on our website.

Condition: used, Year of construction: 1999, Technical details: turning diameter over bed: 570 mm turning diameter over support: 340 mm turning length: 1.000 mm swing diameter over bed: 570 mm centre height: 280 mm centre distance: 1000 mm switched on hours: 26668 h spindle bore: Ø 66 mm revolution per minute: 1 - 2.500 U/min max. torque on the spindle: 1.200 Nm longitudinal feeds:: 0-20 mm/U cross feed: 0-20 mm/U diameter of quill: MK5 Taper tailstock quill adjustment:: 200 mm total power requirement: 30 kW weight of the machine ca.: 3,2 t dimension machine xH: 2,85x2,29x1,9 m Cycle controlle lathe Lrjdpfx Aswtc T Tef Eju equipment: -revolving tip (quill) -chip conveyor -cooling water unit manufactor Mayfran *

Condition: used, turning diameter 210 mm turning length 1000 mm swing diameter over bed slide 435 mm centre height 210 mm greates pass round over bed 435 mm spindle head DIN 55027 / DIN ISO 702-3 Ledpfx Asxqrdysf Eeru spindle bore 52 mm turning speeds 44 - 2.000 U/min transmission ratio 12 feed per revolution 0,036 - 2 U/mm diameter of quill 65 mm quill stroke 120 mm taper bore DIN 228 MK4 total power requirement 5,5 kW -Lead screw and feed screw cover -Brake for main spindle -Toolmaker precision according to DIN 8605 -High drive power and high torque on the main spindle -Large thread cutting range -Convenient operation -Digital position display (HEIDENHAIN ND 7013) 3-axis display for bed, cross slide, and top slide Tool memory for 16 tools Tool memory with one reference point per axis Sum button for Z and Zo Inch/metric switchable Plane path X as radius or diameter display Display resolution up to 1 µ Taper calculator -LED machine light -Coolant device

Condition: good (used), Year of construction: 1998,

Condition: like new (used), Year of construction: 1992, Lathe WEILER Precision center lathe in ergonomic design The Weiler Ergodor is the first German ergonomically designed lathe. It creates a more humane workplace and prevents health problems. The key feature is that the employee can operate this lathe while standing or sitting. Technical data Center width 470 mm Turning length 430 mm Center height 145 mm Rotation Ø over cross slide 160 mm Rotation Ø over bed 300 mm Spindle head, short taper flange Bayonet mounting DIN 55022 size 5 or Camlock clamping D 1-ASA-4 Spindle bore 36 mm DIN 55022 size 5 Spindle inner taper Spindle speeds Speeds 30 - 3550 rpm S Speeds 15 - 3550 rpm Brake motor 3 kW Brake motor 1.5/3 kW Face slide travel 150 mm Travel of the top slide 100 mm Feed rates and thread pitches on the gearbox switchable steps 30 Section 2 1.5/3 kW 38 Gear ratio in headstock 3 20 Long feeds 150 mm via change gears 100 mm via toothed belt Face feeds = 1/2 Longitudinal feed values Lsdsvgqu Hspfx Af Esru Metric pitches 0.2 - 12 mm Module pitches 0.1 - 4 Dimensions 1450 x 640 x 1500 mm Dimensions 1450 x 640 x 1500 mm Net weight 1000 kg Acceptance according to toolmaker's accuracy DIN 8605 20 Built according to the rules of occupational safety, official test no. A. EM 11 1545/80. Encombrement 1450 x 640 x 1500 mm

Condition: good (used), Year of construction: 1991, Machine type Lathe - cycle-controlled Manufacturer WEILER Type E30 year of construction 1991 Control Weiler Country of origin Germany Additional information Cycle-controlled lathe WEILER - E30 Technical details Turning diameter max. 330 mm Turning length 750 mm Weiler control Center height 165 mm Swing diameter over bed 330 mm Lodor Dvqzspfx Af Ejru Max. turning diameter over facing slide 160 mm Face slide travel 180 mm Longitudinal bed slide travel 395 mm Main spindle: Speed range - main spindle 1 - 4,500 min/-1 Drive power - main spindle 9 / 11 kW Max. Torque 165 Nm Spindle head DIN 55027 / 5 Spindle diameter in front bearing 70 mm Spindle bore 40 mm Usable bar diameter ( - ) mm Tool holder: Type MultiFix Turning tool shank cross-section 20 x 20 mm Tailstock: Quill stroke 110 mm Quill diameter 50 mm Tailstock holder MK 3 Feed rates: Rapid traverse max. 10 m/min Feed force 6 / 3 kN Feed range 0 - 20 mm/-1 Thread cutting: metric 0.1 - 400 mm Inch 1/4 - 56 G/1" Module 0.125 - 28 mm.II DP 1 - 224 G/".II Number of threads max. 50 Total power requirement 10 kVA Machine weight approx. 1.5 t Space requirement approx. 2.8 x 2.0 x 2.0 m
