Used Uv Machine for sale (65,318)

Condition: new, functionality: fully functional, Year of construction: 2025, control type: CNC control, laser type: fiber laser, laser power: 3,000 W, Equipment: CE marking, centralized greasing system, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, nozzle changer, safety light barrier, Type: Two chucks Groove function: Standard Power range: 3KW, 6KW Round tube processing range: 10mm~160mm Square tube processing range: 10mm~160mm Chuck maximum speed: 130r/min Machine weight: 3T Power specification: 380VAC, 50Hz Optional loading rack: G16pro-automatic loading, G16pro-semi-automatic loading Optional unloading rack: servo unloading rack, cylinder unloading rack Lasdpjwwz Dlofx Aftsd Standard: System 3000DE-DH, including nesting, supports servo, dustproof (Y axis), dustproof (X axis), dustproof (Z axis), rear card hollow dust removal, short tail material Optional: safety fence (light curtain), radiation-proof glass

Condition: good (used), Bizerba X Ray Machine With reject facility Fully stainless steel Tests carried out using certified test pieces, non-ferrous, stainless steel, ferrous metals Laodpfxsyivgqj Aftsd The unit comes with an option of a Gamma Monitor, Red Eye G20-10 In every day use

Condition: new, Year of construction: 2025, workpiece weight (max.): 12,000 kg, turntable diameter: 280 mm, overall weight: 120 kg, The Robotmover 20 is the ultimate solution for moving heavy loads such as industrial machinery, installations, or steel structures – 100% electric, so zero emissions and noise pollution. Work with unparalleled flexibility thanks to the wireless remote control and the ability to effortlessly change direction 360°. This compact electric mover excels at maneuvering through tight spaces, making it an indispensable tool in congested or confined environments. Thanks to the 48V-60Ah battery, the Robotmover ensures long-lasting operation, saving both time and labor. Whether you're moving equipment or heavy loads, this electric Robotmover is your reliable partner that streamlines your work and increases productivity. Flexible Operation: The wireless remote control provides infinitely variable drive with 360° direction changes. Strong Traction: The two powerful 1000W motors equipped with magnetic brakes produce a robust pulling force of 20 tons. High Load Capacity: The triple-bearing turntable effortlessly carries a maximum load of 12 tons. Long Battery Life: The 48V lithium-ion battery with a 60 Ah capacity provides 4-5 hours of use without frequent charging. Scope of supply: Robotmover 20, remote control, battery chargers Also available transport crate with garage, battery operated hydraulic jacks, fixed following rollers electric skates power skates machine mover robot mover jung lifting equipment hydraulic jacks Ljdjw I Rt Njpfx Aftead

Condition: excellent (used), XYZ 710 VMC Vertical Machining Centre, Table Size 800mm x 445mm (Vac Table not included) with Siemens Sinumerik CNC Control, 24 Tool ATC, BT40 Spindle Taper, 8000rpm Spindle Speed, Filtermist FX5002 Extractor. S/No. SMT00054 Laedexvpffopfx Aftjd Delivery available on request, at extra cost. 14 day return or repair.

Condition: new, functionality: fully functional, Year of construction: 2025, laser power: 6,000 W, travel distance X-axis: 3,030 mm, travel distance Y-axis: 1,520 mm, travel distance Z-axis: 310 mm, total length: 9,500 mm, total width: 4,500 mm, total height: 2,050 mm, Equipment: CE marking, centralized greasing system, cooling unit, dust extraction, emergency stop, fume extraction, nozzle changer, safety light barrier, VS-3015CE 6KW FIber Laser Sheet Cutting Machine Working area (mm) : 3000×1500 X axis travel distance (mm): 1520 Y axis travel distance (mm): 3030 Z axis travel distance (mm)： 310 X/Y axis positioning accuracy ： ≤0.03mm\m X/Y axis repeat positioning accuracy： ≤±0.02mm Max. synthetic positioning speed: 150m\min Max. acceleration: 2G Double-sided control panel, adaptive multi-angle placement, simple disassembly, and can fit into a standard 40HQ container. Industrial-grade special air conditioner, constant temperature and humidity for stable performance. Automatic grease and oil injection system, intelligent air pressure monitoring device, and anti-collision detection device provide intelligent protection. Lasdpfx Afjv Ngrastod

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2007, machine/vehicle number: A0250A0472, laser power: 5,000 W, travel distance X-axis: 4,000 mm, travel distance Y-axis: 2,000 mm, TECHNICAL DETAILS Travel range, X-axis: 4,000 mm Travel range, Y-axis: 2,000 mm Laser power: 5,000 W Ledpfx Afszkr T Uetsad MACHINE DETAILS Mains voltage: 400 V / 50 Hz Connected load: 105 kVA Control voltage: 24 V DC Required fuse rating: 3 x 160 A Compressed air connection: 7 to 10 bar Nitrogen connection N₂: 30 bar Oxygen connection O₂: 20 bar

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: M704025, sheet thickness (max.): 100 mm, overall weight: 4,650 kg, passage width: 1,300 mm, TECHNICAL DETAILS Lsdozkr Rtjpfx Aftead Material thickness: 0.8 to 100 mm Passage width: max. 1,300 mm Workpiece dimensions: min. 180 x 100 mm Workpiece weight: max. 250 kg/m Feed rate: 0.2 to 6 m/min MACHINE DETAILS Dimensions & Weight Dimensions: 2,200 x 2,900 x 2,200 mm Machine weight: approx. 4,650 kg EQUIPMENT Processing: on both sides, dry

Condition: used, Year of construction: 2011, operating hours: 5,000 h, machine/vehicle number: M344Z16201031AHC, travel distance X-axis: 2,032 mm, travel distance Y-axis: 660 mm, travel distance Z-axis: 610 mm, table load: 2,700 kg, spindle speed (max.): 12,000 rpm, The following repairs were carried out: Defective inverter identified and replaced Bearings in the Y-axis replaced; bearing set VTXZ Y-axis (5 pieces, 35x72) Rotary table adjusted Orientation adjusted TECHNICAL DETAILS Travel range X-axis: 2,032 mm Travel range Y-axis: 660 mm Travel range Z-axis: 610 mm Spindle speed: 12,000 rpm Spindle cooling: Internal cooling Rapid traverse rate X/Y/Z: 35 m/min Power: 18 kW Tool holder: SK 40 Tool positions: 40 Tool diameter with full occupancy: 75 mm Maximum tool weight: 10 kg Maximum tool length: 300 mm Table load: 2,700 kg Table clamping area: 2,285 x 660 mm T-slots in the table according to DIN 650: 5 Slot width: 18 mm H8 Slot spacing: 125 mm Lajdpfxozka His Aftsd Positional accuracy X, Y, Z: 0.02 mm Repeatability X, Y, Z: 0.01 mm MACHINE DETAILS Footprint W x D x H, doors open / with control / chip conveyor: 6,950 x 5,150 x 3,700 mm Transport weight: 20,000 kg Machine weight: 18,000 kg Operating hours Machine hours: 11,417 hours Spindle hours: approx. 5,000 hours Further technical data can be found in the attached documents.

Condition: used, Year of construction: 2004, operating hours: 28,082 h, travel distance X-axis: 800 mm, travel distance Y-axis: 620 mm, travel distance Z-axis: 520 mm, controller model: Siemens 840 D, spindle speed (max.): 13,000 rpm, The control system (PCU 50) was replaced in March 2024! The machine spindle was replaced after approximately 5,500 operating hours! TECHNICAL DETAILS Travel range X-axis: 800 mm Travel range Y-axis: 620 mm Travel range Z-axis: 520 mm Spindle speed: 13,000 rpm Number of tool slots in the tool magazine: 30 MACHINE DETAILS Control system: Siemens 840 D Ljdpfjzka Akox Aftoad Operating hours Control system operating hours: 60,150 h Machine operating hours: 56,860 h Spindle operating hours: 28,082 h Spindle replacement at: 5,500 h EQUIPMENT Tools 4th axis Hofmann RW/NC160 Oil mist extraction system Strip filter system with internal cooling, 20 bar, with dual switching filter Documentation: Hedelius + Siemens Sinumerik Infrared probe: Renishaw

Year of construction: 2018, condition: refurbished (used), functionality: fully functional, workpiece weight (max.): 15 kg, inner dimension height: 95 mm, inner dimension length: 260 mm, negative pressure: 10,000 Pa, No minimum price – guaranteed sale to the highest bidder! Cleaning machine as a single-chamber flood system operating under full vacuum. The machine will undergo a complete overhaul in 2026 with an estimated value of €16,800 and is in very good condition. The original new price of the machine was €104,000. TECHNICAL DETAILS Cleaning medium: halogen-free hydrocarbon or modified alcohol Cleaning basket dimensions: 260 x 160 x 95 mm Batch weight max.: 15 kg MACHINE DETAILS Overall length: 1,260 mm Overall width: 1,110 mm Overall height: 2,600 mm Total weight: 1,600 kg EQUIPMENT CE marking in roll-on/roll-off standard version Complies with the 31st German Federal Immission Control Ordinance (BImSchV) (as of August 21, 2011) Complies with the Swiss Air Pollution Control Ordinance (as of March 1, 1998) Complies with the Austrian VAV Ordinance (as of July 26, 2022) Complies with the EU VOC Directive 199/13 Laedpfxozh Eiqo Aftjd

Condition: ready for operation (used), Year of construction: 2005, operating hours: 44,673 h, functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 900 mm, controller model: OSP-E100M, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 320, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range X-axis: 1,000 mm Travel range Y-axis: 900 mm Travel range Z-axis: 900 mm Spindle speed: 12,000 rpm Tool holder: BT50 Tool positions: 320 Tool positions for 600-mm tools: 80 Part accuracy: 0.001° MACHINE DETAILS Control system: OSP-E100M Number of axes: 4 Coolant pressure: 30 bar Dimensions & Weight Machine: 4800 x 2980 x 3150 – 21.5 t Tool magazine: 4500 x 2800 x 3150 - 6–7 t Chip conveyor: 4500 x 1600 x 2400 – 2 t, including high-pressure pump Repo: 3000 x 1200 x 1500 mm, 0–0.5 t Operating hours NC cycle time: 71,235 h Spindle running time: 56,241 h Machining time: 44,673 h EQUIPMENT ATC with 320 positions 80 positions for 600-mm tools 2 pallets Balluff read/write system NC table Absolute scales in X, Y, and Z Renishaw MP10 measuring probe Tool breakage detection MOP tool monitoring Laodpfx Afszlg U Aotjd 30-bar coolant system Mayfran Consep 2000 chip conveyor

Condition: ready for operation (used), Year of construction: 1999, machine/vehicle number: 6624, total width: 1,000 mm, total length: 3,200 mm, total height: 1,800 mm, input voltage: 400 V, table length: 1,300 mm, power: 13.5 kW (18.35 HP), No minimum price – guaranteed sale to the highest bidder! The machine has been cleaned, repainted, and tested for functionality. TECHNICAL DETAILS Length of magnetic grinding table: 1,300 mm Drive: 13.5 kW Ledpfxozlfm Ds Aftead Magnetic table: swiveling MACHINE DETAILS Dimensions (L x W x H): 3,200 x 1,000 x 1,800 mm EQUIPMENT Water cleaning with filter cloth Guide rail Separate control cabinet Separate control panel

Condition: ready for operation (used), Year of construction: 2023, functionality: fully functional, machine/vehicle number: PR721523001, travel distance X-axis: 1,300 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain TNC-460, spindle speed (max.): 15,000 rpm, The new price of the machine was approximately €140,000 in 2023! No tools or a vise are included. However, these can be purchased separately upon request. TECHNICAL DETAILS Travel range X-axis: 1,300 mm Travel range Y-axis: 650 mm Travel range Z-axis: 600 mm Spindle speed: 15,000 rpm Main spindle servo motor Siemens: 20/53 kW Main spindle servo motor Fanuc: 15/30 kW Spindle taper: SK 40 Work table Table dimensions: 1,500 × 650 mm Table load: max. 1,200 kg T-slots: 18 × 5 × 100 mm Distance spindle to table surface: 150–750 mm Distance spindle center to Z-axis cover: 697 mm Rapid traverse X/Y axis: 36 m/min Rapid traverse Z axis: 36 m/min Working feed rate: max. 1–12,000 mm/min Feed motors X/Y/Z: 3.2/3.2/4.3 kW Torques of the feed motors X/Y/Z: 20/20/27 Nm Tool positions: 28 Tool length: max. 300 mm Tool diameter: max. 75 mm Tool diameter with free auxiliary positions: max. 125 mm Tool weight: max. 8 kg Tool change time: 1.6 s MACHINE DETAILS Control system: Heidenhain TNC-460 Accuracy without linear glass scales Positioning accuracy over the entire travel range: 0.012 mm Repeatability accuracy over the entire travel range: 0.008 mm Accuracy with linear glass scales Positioning accuracy over the entire travel range: 0.008 mm Repeatability accuracy over the entire travel range: 0.006 mm Cooling and power supply Coolant tank volume: 250 l Coolant flow rate: 40 l/min Mains voltage: 400 V ± 10 % Number of phases: 3 Mains frequency: 50 Hz Connected power: 85 kVA Dimensions and weight Dimensions (L × W × H): 4,025 × 3,090 × 3,185 mm Weight: 8,000 kg EQUIPMENT Direct drive Double-arm tool changer O-BLUM tool measuring system Lasercontrol NT O-BLUM workpiece measuring system TC50 Electronic handwheel (MPG) Thread drilling without compensation chuck USB interface CF card interface Ethernet interface HIWIN linear guides with roller guides in all axes HIWIN ball screws Directly driven main spindle NSK/FAG main spindle bearings Separate oil-air spindle cooling unit Fully enclosed tool changer for protection against chips Pneumatic intermediate tank for the tool changer as a backup in case of pressure drop Fully enclosed splash guard Separate air conditioning system for heat dissipation from the control cabinet Siemens electrical components Automatic, path- or time-controlled central lubrication system Kyarow telescopic covers in all axes Coolant system with adjustable nozzles as a coolant ring around the spindle Chip flushing system in the interior for optimal chip collection Ljdpfxezlh S Ae Aftoad Spiral chip conveyor working in the Y-direction for removing chips from the machining area Rear chain chip conveyor

Condition: ready for operation (used), Year of construction: 2010, operating hours: 17,250 h, functionality: fully functional, travel distance X-axis: 710 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 520 mm, controller model: Heidenhain Mill Plus, spindle speed (max.): 18,000 rpm, In 2015, a new spindle was installed! TECHNICAL DETAILS Travel range X-axis: 710 mm Travel range Y-axis: 520 mm Travel range Z-axis: 520 mm Maximum spindle speed: 18,000 RPM Number of tool magazine slots: 30 Tool holder: SK40 Distance between T-slots: 63 mm Rotational speed of the 4th axis max.: 40 RPM Rotational speed of the 5th axis max.: 40 RPM 4th axis swivel range: 360 x 0.001 degrees 5th axis swivel range: 0 ± 102 x 0.001 degrees MACHINE DETAILS Control system model: Heidenhain - Mill Plus Operating hours: currently 36,500 hours Spindle hours: currently 17,250 hours EQUIPMENT Programmable coolant nozzles Coolant gun Chip conveyor 40 bar internal coolant system with 600 l paper filter system Measuring probe 3D Quickset Laser tool measurement Visiport Handwheel Ljdezldqnepfx Aftsad Signal light Operating mode 4

Condition: used, Year of construction: 2003, machine/vehicle number: 95240126, travel distance X-axis: 4,870 mm, travel distance Y-axis: 1,840 mm, travel distance Z-axis: 250 mm, working width: 1,300 mm, working length: 4,200 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Number of axes: 4 Travel range X-axis: 4,870 mm Travel range Y-axis: 1,840 mm Travel range Z-axis: 250 mm Travel range C-axis: 360° Maximum axis speed X: 85 m/min Maximum axis speed Y: 85 m/min Maximum axis speed Z: 25 m/min Working area: 4,200 x 1,300 mm Spindle power: 9 kW (12 hp) Maximum spindle rotation speed: 18,000 rpm Spindle interface: HSK63F Number of tool changer positions on the head: 8 Number of tool changer positions on the Y-axis: 15 MACHINE DETAILS Power of the independent swivel spindle: 3 kW (4 hp) Power of the independent horizontal motor: 5.6 kW (7.6 hp) Maximum speed of the horizontal motor: 18,000 rpm Drilling unit motor power: 3 kW (4 hp) Suction capacity of the vacuum pump: 100 m³/h Dimensions & Weight Dimensions of the installed machine (L x W x H): 7,500 x 3,800 x 2,350 mm Overall dimensions for transport (L x W x H): 13,500 x 2,400 x 2,400 mm Ledpfszi A E Eex Aftoad Total weight: 5,000 kg EQUIPMENT 6 suction bars, each with 3 suction cups 4 panel lifting bars 6+2 reference stops 6 lockable clamping devices Dot laser HSK63F tool holder (2 pieces) TPA Albatros CNC control system (updated in 2018) with remote control Automatic central lubrication Front safety mats + perimeter guardrails User manuals + electrical diagram + CE certificate

Condition: used, Year of construction: 2005, machine/vehicle number: 107.32.99.158, travel distance X-axis: 530 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 12,000 rpm, Re-auction due to buyer’s payment default! The machine spindle was replaced in July 2025! TECHNICAL DETAILS Travel range X-axis: 530 mm Travel range Y-axis: 450 mm Travel range Z-axis: 450 mm Rotary table Table diameter: 400 mm Table load capacity: 200 kg Swivel range: degrees Swivel speed: 20 rpm Rotational speed: 30 rpm Tool holder: SK40 Maximum speed: 12,000 rpm Ljdpsziz Ncjfx Aftjad Recommended maximum working feed rate: 15 m/min Rapid traverse speed: 22 m/min Feed force X and Y/Z: 5,000 N Magazine capacity: 30 Maximum tool diameter: 90 mm Maximum tool length: 250 mm (manual 350 mm) Maximum tool weight: 6 kg MACHINE DETAILS Control system: Heidenhain iTNC 530 with digital control Positional tolerance according to DIN/ISO 230-2/97: 0.008 mm Machine weight: 6,500 kg EQUIPMENT RENISHAW MP 12 measuring probe Blum tool monitoring system

Condition: excellent (used), functionality: fully functional, Year of construction: 2014, laser power: 2,000 W, sheet thickness (max.): 16 mm, sheet thickness steel (max.): 16 mm, sheet thickness stainless steel (max.): 8 mm, sheet thickness aluminum (max.): 6 mm, The machine is in very good condition and has been regularly serviced by qualified service technicians! Lajdpfx Aozlc Sqoftsd TECHNICAL DETAILS Laser power: 2,000 W Sheet metal thickness max: 16 mm Sheet metal thickness, steel max: 16 mm Sheet metal thickness, stainless steel max: 8 mm Sheet metal thickness, aluminum max: 6 mm Table length: 3,000 mm Table width: 1,500 mm EQUIPMENT Cooling unit Emergency stop switch Fume extraction Safety light curtain Dust extraction Note: The operating hours can be found in the last image.

Condition: ready for operation (used), Year of construction: 1959, functionality: fully functional, machine/vehicle number: 80, total height: 1,900 mm, total width: 2,200 mm, total length: 1,500 mm, power: 5 kW (6.80 HP), empty load weight: 2,500 kg, No minimum price – guaranteed sale to the highest bidder! MACHINE DETAILS Drive system: Conventional Power: 5.0 kW Dimensions & Weight Dimensions (L x W x H): 1,500 x 2,200 x 1,900 mm Weight: 2,500 kg Transport packages: 3 EQUIPMENT Documentation Laedpfx Afszk Dzqeted

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, working width: 550 mm, power: 32 kW (43.51 HP), empty load weight: 3,000 kg, Equipment: CE marking, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Maximum working width: 550 mm MACHINE DETAILS Power: 32 kW Dimensions & Weight Lasdpfx Afjzk Dyyjtod Dimensions (L x W x H): 1,700 x 2,700 x 2,900 mm Empty weight: 3,000 kg Control: Conventional Wet/Dry: Dry EQUIPMENT Station type 1: Belt sander CE marking

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 550 mm, table length: 2,600 mm, spindle speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 2,000 mm Travel range, Y-axis: 500 mm Travel range, Z-axis: 550 mm C-axis rotation: 360° Table length: 2,600 mm Table width: 550 mm Tool holder: ISO40 Main spindle power: 22 kW Spindle speed: 20 - 12,000 rpm Ljdpfx Ajzk Dv Ujftead Positioning accuracy: 0.01 mm Travel speed: 667 mm/s Number of axes: 4 MACHINE DETAILS Control system manufacturer: Siemens Power consumption: 24 kW Dimensions & Weight Dimensions (L x W x H): 7,500 x 3,700 x 2,500 mm Net weight: 9,600 kg Shipping packages: 2 EQUIPMENT Tool magazine External cooling Chip conveyor CE marking

Condition: ready for operation (used), Year of construction: 2002, operating hours: 22,347 h, functionality: fully functional, machine/vehicle number: 190347, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 1,500 mm, table load: 10,000 kg, controller model: Heidenhain TNC 430 B, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS 6 axes (X, Y, Z, table C, swivel head A, B) Travel range X-axis: 3,000 mm Travel range Y-axis: 1,600 mm Travel range Z-axis: 1,500 mm Table size (2x): 2,000 x 2,000 mm Table load: 10 t Spindle speeds: 60 - 3,600 rpm Spindle mounting: ISO 50 MACHINE DETAILS Control system: Heidenhain TNC 430 B digital Number of controlled axes: 6 Milling drive: 28 kW Total power consumption: 48 kW Dimensions & Weight Space requirement: approx. 6.5 x 3 x 3 m Machine weight: approx. 47 t Program runtime: 22,347 h EQUIPMENT Integrated coolant supply (ICS) 40-position automatic tool changer Chip conveyor High-speed spindle (30,000 rpm) Lsdjzku Sgopfx Aftjad 2 pallets

Condition: ready for operation (used), Year of construction: 2000, operating hours: 25,616 h, functionality: fully functional, machine/vehicle number: 184640, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 1,500 mm, table load: 10,000 kg, controller model: Heidenhain TNC 430 B, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel in X-axis: 3,000 mm Lajdpfxezku R As Aftjd Travel in Y-axis: 1,400 mm Travel in Z-axis: 1,500 mm Table size: 3,200 x 1,100 mm Table load: 10 t Spindle speeds: 60 - 4,000 rpm Spindle mounting: ISO 50 MACHINE DETAILS Control system: Heidenhain TNC 430 B digital Milling drive: 22 kW Total power consumption: 50 kW Dimensions & Weight Space requirement: approx. 6.5 x 3 x 3 m Machine weight: approx. 22 t Program run time: 25,616 h Machine operating hours: 53,291 h Control system operating hours: 55,029 h EQUIPMENT 20-position automatic tool changer Milling head automatically swivels and rotates in 1.5° increments Chip conveyor Adaptable high-speed spindle (30,000 rpm) Mist coolant system

Condition: ready for operation (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 3,000 mm, workpiece height (max.): 30 mm, TECHNICAL DETAILS Axis: 920 mm X-axis: 3,000 mm A-axis: 360° Material thickness Z: 12 mm - 30 mm Feed rate: 20 m/min Minimum dimensions (plate): X: 300 mm Y: 120 mm Z: 12 mm Maximum/minimum hole diameter: 3 mm - 35 mm Maximum cutting depth with saw blade: 10 mm MACHINE DETAILS Lodpezkt A Rofx Aftsad Motor power: 0.75 HP Voltage: 400 V Required extraction capacity: 2,300 m³/h EQUIPMENT 4-position drill chuck Saw blade in the X direction

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 750 mm, travel distance Y-axis: 750 mm, travel distance Z-axis: 725 mm, controller model: SIEMENS Sinumerik 840D, spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Travel range X-axis: 750 mm Travel range Y-axis: 750 mm Travel range Z-axis: 725 mm B-axis: 360° Spindle mounting: HSK 63A Spindle speed: 50-10,000 rpm Spindle drive power 40/100% duty cycle: 37/24 kW Tool positions: 320 Feed rate: 60,000 mm/min Rapid traverse: 60 m/min Laodpfozi Edkex Aftjd MACHINE DETAILS Control system: SIEMENS Sinumerik 840D Machine length with chip conveyor: 6,100 mm Width (with control and additional magazine): 4,500 mm Installation dimensions internal cooling: 2,450 x 1,700 mm Installation dimensions spindle cooler: 800 x 900 mm Machine weight: approx. 15,000 kg EQUIPMENT NC rotary table with B-axis Magazine for 320 tools Pallet changer, 2 pallets 500mm x 500mm Internal coolant supply (80 bar) Chip conveyor Coolant system

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 650 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 680 mm, controller model: SIEMENS Sinumerik 840D, spindle speed (max.): 24,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 650 mm Travel range, Y-axis: 650 mm Travel range, Z-axis: 680 mm B-axis: 360° Spindle speed (max.): 24,000 rpm Spindle taper: HSK 63A Tool positions: 80 MACHINE DETAILS Control system: Sinumerik 840D Machine weight: approx. 13,000 kg Laedpfx Aozi Ealjfted EQUIPMENT NC rotary table with B-axis Magazine for 80 tools Pallet changing system, 2 pallets 400 mm x 400 mm Internal coolant supply (ICS) Chip conveyor Coolant system
