Used Universal Turning Machine for sale (66,957)

Condition: good (used), Year of construction: 1998, Ref. -No.: 10548 Lrodexmd T Ejpfx Aiijn Manufacturer: MONFORTS Type: RNC 5 A17 Year of construction: 1998 Type of control: CNC-Steuerung Control: Monforts Storage location: Halberstadt Country of origin: Germany Machine-No.: 303XXXX Chuck diameter: 250 mm Centre Distance: 1080 mm Spindle Diameter In Front Bearing: 100 mm Spindle head according to DIN 55027 (size): Gr. 8 Circumferential diameter over radial slide: 290 mm Max swing diameter: 500 mm travel of the cross slide: 265 mm Tailstock outside diameter of the quill: 80 mm Tailstock maximum quill stroke: 160 mm Tailstock inner cone: MK 5 Type Material flow max.: 70 mm Turning Speed Range: 2 - 2800 rpm Further information: The machine can be viewed under power by arrangement.

Condition: ready for operation (used), Year of construction: 2004, operating hours: 61,297 h, functionality: fully functional, travel distance X-axis: 2,800 mm, travel distance Y-axis: 2,200 mm, travel distance Z-axis: 800 mm, controller model: HEIDENHAIN TNC 426, Equipment: chip conveyor, No minimum price – guaranteed sale to the highest bidder! In January 2025, a new spindle was installed by the manufacturer! The machine has been regularly maintained! Previous use: The machine was primarily used for precision machining. Roughing operations were only carried out to a limited extent. TECHNICAL DETAILS Travel range X-axis: 2,800 mm Travel range Y-axis: 2,200 mm Travel range Z-axis: 800 mm Feeds Rapid traverse: 35,000 mm/min Spindle speed S1 (continuous operation) Vertical: 10,000 rpm Spindle speed S1 (continuous operation) Universal swivel head 2-axis: 18,000 rpm Vertical milling head: TVS 10,000 Swivel milling head: TU 18,000 Tool holder: HSK 63 A Tool changer: 40 tool positions MACHINE DETAILS CNC control: HEIDENHAIN iTNC 530 Electrical data Supply voltage: 400 V (-15 %, +10 %) Frequency: 50 Hz Current consumption: 101.1 A Installed total power: 59.8 kW Lodpozb D Aqjfx Aiijrn Operating hours Power-on hours: 99,222 h Program run time: 61,297 h EQUIPMENT High-rigidity gantry design Precise linear guides and ball screws Generous working area with 2.8 m X-axis travel High feed rates for efficient machining Ideal for tool, mold, and machine construction Documentation and acceptance certificate according to ISO standards Tool changer Coolant system Chip conveyor Swiveling milling head with 4th/5th axis Maintenance and service documentation

Condition: ready for operation (used), Year of construction: 2014, operating hours: 15,662 h, functionality: fully functional, travel distance X-axis: 620 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 460 mm, controller model: Heidenhain TNC530i, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 620 mm Travel range, Y-axis: 520 mm Lrodpfx Aiezd Aitsien Travel range, Z-axis: 460 mm C-axis: 360° B-axis: -50° / +110° Rotary table diameter: 500 mm Spindle speed (max.): 12,000 rpm Spindle type: SK40 Number of spindles: 1 Number of tool positions in the tool magazine: 30 MACHINE DETAILS Control system: Heidenhain TNC530i Operating hours (see image) Control system operating hours: 38,569 h Machine operating hours: 37,263 h Spindle operating hours: 15,662 h EQUIPMENT Documentation/Manual Speed infinitely adjustable Chip conveyor Scraper-type chip conveyor Workpiece measuring probe Coolant system Compressed air via M-command Heidenhain handwheel Kinematic optimization cycle Note: The machine is sold without tools, vise, and clamping plate.

Condition: excellent (used), Year of construction: 2002, 5-axis CNC machining center 2006 Control: Heidenhain iTNC 530 Technical data: x-axis travel 880 mm y-axis travel 630 mm z-axis travel 630 mm Max. torque 130 Nm tool holder SK 40 (ISO 7388IIB) swiveling B: 103° Work table: Clamping surface 1,250 x 700 mm Rotary table diameter 700 mm rotatable C: 360 ° Max. table load approx. 500 kg T-slots 11x 14mm x 63mm Tool magazine: Number of tool places 32 (2x 16) pos. tool holder SK 40 (ISO 7388IIB) Max. tool diameter 80 / 130 mm Max. tool diameter with free neighbor box 160 mm Lrsdpewn A Slefx Aiisn Max. tool length 315 mm Max. tool weight 8.0 kg

Condition: like new (used), Year of construction: 2006, functionality: fully functional, Deckel Maho DMU 50 evo Linear with TNC 530 control from Heidenhain, in TOP condition Technical data: >> Year of manufacture 2006 >> Manufacturer: Heidenhain, type iTNC 530 >> Travels X500/Y450/Z400 >> C-axis 360 degrees >> B-axis 0 degrees to 161.955 degrees >> Tool holder HSK A63 >> Max. spindle speed up to 18000 rpm >> Feed rate continuously programmable up to X, Y, Z 20000 mm/min >> C-B axis continuously programmable up to rapid traverse speed >> Rapid traverse Y- and Z-axis 50 m/min >> X-axis 80 m/min (linear drive) >> B-axis 40 rpm >> C-axis 50 rpm >> Tool magazine: Double gripper, 60 magazine slots >> Table clamping surface Ø 500 x 380 mm >> T-slot spacing 63/14H7 >> Table load 200 kg >> Dimensions and weight: approx. >> Machine without control and attachments >> Depth 3.0 meters, width 2.4 meters, height 2.6 meters >> Weight approx. 7000 kg >> Operating voltage 400 V >> Electric handwheel Heidenhain HR 410 >> Power connection 17 kVA >> Chip conveyor >> Active spindle cooling >> Mist extractor >> IKZ 40 Bar >> Coolant cleaning system (fleece filter system) >> Spray gun >> Visiport >> Compressed air supply to the measuring system >> Preparation for robot loading >> 3D probe Heidenhain TS640 >> 3D Quick Set >> Kinematics >> Blum laser for tool measurement and breakage detection >> Complete documentation The following work has been carried out: >> Main spindle overhauled >> Complete maintenance: All coolant hoses and pneumatic hoses renewed, filters new, fluids and belts renewed. Scrapers, etc. Complete cleaning. Lrjdpfszg Dnvex Aiion >> Geometrically measured (acceptance report) About the machine: Offered is a Deckel Maho DMU 50 evo Linear machining center with a TNC 530 3D path control from Heidenhain. The machine is in very good condition. The main spindle has been overhauled (replacement spindle) on the DMU, completely serviced, and an acceptance report has been created. Invoices for the overhaul of 42,000 Euros (net) are available. Take the opportunity to inspect and test the machine on site while it is powered up.

Condition: good (used), Year of construction: 1990, Ref. -No.: 10542 Lrodpfjxmd Txox Aiien Manufacturer: GILDEMEISTER Type: AS - 16 Year of construction: 1990 Max. Rod diameter: 16 mm Number of spindles: 6 Pcs Guide rod length: 3,3 m Further information: The machine can be viewed under power by arrangement.

Condition: used, Year of construction: 2005, machine/vehicle number: 564, RETROFIT of the machine in 2010, CNC control FANUC Series 18i TB, total weight 5,500 kg, filtration system W & W FILTERSYSTEME, chip conveyor SEREMETO, cooling unit EMAG HTD 720 Lsdpoy Sqiasfx Aiijrn

Condition: used, machine/vehicle number: 2055, up to 2000 rpm, T-slot table size 1000 mm x 400 mm, with 3-axis digital readout HEIDENHAIN Lrjdjy Sqi Hspfx Aiion

Condition: used, Year of construction: 1993, x-travel 0500 mm y-travel 400 mm z-travel 420 mm Ledpfx Aioyy A Dxjiorn table-size 800 x 400 mm feed range 1- 3000 mm/min rapid traverse 0,083- 5 m/min Tool bore ISO 40 turning speed range 20- 4000 U/min main drive DC 5 kW CNC control 355 HH total power requirement 10,9 KW weight of the machine ca. 2300 kg dimensions of the machine ca. 2,5 x 2,5 x 2,0 m CNC milling machine with Heidenhain TNC 355 Control and housing arround working area.

Condition: used, Year of construction: 2008, x-travel 1250 mm y-travel 1000 mm z-travel 1000 mm control Matrix Ledpfx Aieywntmjisrn max. workpiece diameter 1060 mm workpiece length - max. 1000 mm chucking diameter 800 mm type of pallet-changer 2 St. milling head speed 10000 U/min table turning speeds 500 U/min numbers of tools in magazin 120 tool taper 50 ISO table drive 37 kW milling drive 37 kW total power requirement 110 kW weight of the machine ca. 37 t dimensions of the machine ca. 5 x 4 x 3 m Milling and turning machine with 5 axes. Control: Mazatrol Matrix. Machine has coolant through spindle with mist exhaust and is prepared for Renishaw OMP.

Condition: used, Year of construction: 2012, x-travel 0760 mm y-travel 845 mm z-travel 760 mm control 840DI Siemens table-size 500 x 500 mm feed 0- 60 m/min Lrodpfx Aieywntgoijn workpiece weight max. 350 kg type of pallet-changer 4 St. milling head speed 12000 U/min numbers of tools in magazin 320 tool taper 63 HSK A- axe (swivel) 30- 120 ° B- axe (turning) 360 ° total power requirement 83 kW weight of the machine ca. 15 t dimensions of the machine ca. 6 x 4 x 2,5 m 5 axes machining center with swivable and turnable table. Coontrol Siemens 840 DI. Machine will be supplied with many spare parts. Machine has cooling through spindle, dust exhaust and a 4 pallet exchange storage. We will deliver a measuring tracer along with the machine.

Condition: used, Year of construction: 2006, x-travel 1250 mm y-travel 1000 mm z-travel 1000 mm control 640MPlus max. workpiece diameter 1060 mm workpiece length - max. 1000 mm chucking diameter 800 mm type of pallet-changer 2 St. milling head speed 10000 U/min table turning speeds 500 U/min numbers of tools in magazin 80 tool taper 50 ISO table drive 37 kW milling drive 37 kW total power requirement 110 kW weight of the machine ca. 36 t dimensions of the machine ca. 5 x 4 x 3 m Milling and turning machine with 5 axes. Control: Mazatrol 640 MPlus. Machine Lrodpsywntasfx Aiien has coolant through spindle with mist exhaust and is prepared for Renishaw OMP.

Condition: used, Year of construction: 2007, turning diameter 600 mm swing diameter 680 mm turning height 600 mm z-axis 500 mm x-axis 560 mm drive of main spindle 65/80 kW main spindle speeds: 2800 workpiece tool changer 12 Plätze feeds z-axis 0,01-30.000 mm/min Ljdpfxsv Rrq Dj Aiiorn feeds x-axis 0,01-45.000 mm/min chuck Rota NCR 630 mm voltage 400 V frequency 50 Hz control Siemens 840 D pl total power requirement 140 A weight of the machine ca. 18 t dimensions of the machine ca. 6,5 x 3,8 x 4,20 m

Condition: excellent (used), Haida Type: HD-B604-S Sensor: TECSIS load cell Max. capacity: 2T / 20 kN Unit: G, kg, N, LB (adjustable) Resolution: 1/250,000 Accuracy: ± 0.5% Max. stroke: 700 mm (without fixture) Test speed: 0.1-500 mm/min (adjustable) Voltage: 220V AC ± 10%, 50/60Hz Chuck range: 0-7 mm Weight: approx. 175 kg Dimensions (W x D x H): 88 x 50.5 x 150 cm Condition: used Lrjdpfjzgr Eiox Aiijn Scope of delivery: (See image) (Changes and errors in the technical data are subject to change!) We will gladly answer any further questions you may have over the phone.

Condition: used, Year of construction: 2003, CNC machining center, universal Manufacturer: AXA Type: VPC 40 U Year of manufacture: 2003 CNC control: Heidenhain TNC 430 Travel ranges: X/Y/Z = 2,300 x 1,200 x 600 mm NC rotary table dimensions: 1,100 x 1,100 mm Fixed table dimensions: 1,100 x 1,100 mm Tool interface: SK40 Tool magazine: 60 positions Spindle speed: 10,000 rpm Weight: approx. 20 tons. 23626 Lrodpfx Aiewwt Nmsisn

Condition: used, Year of construction: 1978, x-travel 1.000 mm y-travel 340 mm z-travel 450 mm table: 1.300 x 400 mm spindle taper ISO 40 SK turning speeds 32 - 1.400 U/min Lrodszf Nrdopfx Aiijn spindle stroke 80 mm total power requirement 7,5 kW Features: - Universal console milling machine with HEIDENHAIN digital display - Mechanical tool clamping - Cooling system - Various SK 40 tool holders - Machine documentation in German

Condition: excellent (used), Year of construction: 2021, Maximum turning diameter 2800 mm Maximum swing diameter 3000 mm diameter of spindle flange 1100 mm control Siemens 840 D sl Table rpm 230 1/min Maximum speed of driven tools 6000 1/min x-travel 2700 mm z-travel 1000 mm Feed - X 24 m/min feed capacity - x 22 kN tool taper CAPTO C8 total power requirement 200 kVA dimensions of the machine ca. 10,4 x 6.3 x 5,7 m weight of the machine ca. 120 t Equipment/Accessories: - 2 tool changers one with 25 positions and one with 41 positions - 2 x chip conveyors - Coolant system, 6 bar - High-pressure cooling, 70 bar - Knoll paper belt filter - 12-jaw balancing chuck, RÖHM - internal coolant supply - Hydraulic unit Lrjdpfozf Np Njx Aiien - Automatic door - Electric handwheel - Technical documentation

Year of construction: 2003, condition: excellent (used), Working travels 6000x1000x1200mm B-Axis milling head +/-90° Table size 6400x1000mm Spindle taper HSK-100 Spindle speeds -9000 rpm Tool changer 80 pos. Control SIEMENS 840D Coolant through spindle Tool measuring device Zero point clamping system 3R Lrodpod Rz Uvefx Aiion MARCELS MASCHINEN CH

Year of construction: 2003, condition: good (used), Sub-spindle, Y-axis, B-axis SIEMENS 840D Powerline Turning diameter max 200mm Turning length -635mm Swing Diameter -250mm Ledpfxoglf A He Aiiern Spindle speeds main & sub-spindle 20-7000 rpm Turret head 1+2: 12 driven positions B-Axis, upper turret head +135/-45° Misc. accessories MARCELS MASCHINEN CH

Condition: excellent (used), HEIDENHAIN TNC430 with B + C axis Working travels 800 x 600 x 500 mm Table size Ø 280 mm Lrsdpfok Dz Ngox Aiien Table swivelling +/-110° Table rotating 360° Spindle taper HSK63 Spindle speeds -15'000 rpm tool changer 30 pos. Coolant through spindle 3D tracer Renishaw MARCELS MASCHINEN CH

Condition: excellent (used), Year of construction: 1997, Heidenhain Mill-Plus control system Travel ranges X/Y/Z: 500 x 380 x 380 mm Ledpezfx Ubofx Aiisrn Clamping surface: 500 x 400 mm Tool magazine for 24 tools, SK 40 Spindle speed: 8,000 rpm NC rotary and tilting table Chip conveyor

Condition: good (used), Year of construction: 1982, x-travel 300 mm y-travel 160 mm z-travel 340 mm tool taper SK40 Speed 40-2000 U/min. control Aktiv HEIDENHAIN table-size 600 x 210 mm total power requirement 2 kW weight of the machine ca. 0,73 t dimensions of the machine ca. TBH 1,20x1,10x1,60 m Comes from a vocational school - Powered feed in X, Y, and Z axes Lrjdpszfql Sofx Aiion - Coolant system - Machine vice - Work light

Condition: used, Year of construction: 2013, grinding diameter 300 mm grinding depth 300 mm Travel distance - Z1 470 mm Travel distance - X1 200 mm Tilt angle - B2 1/1000 ° power capacity 3,5 kW Travel distance - Z2 470 mm Travel distance - X2 325 mm Drive power – External grinding spindles 16,5 kW 120 mm grinding diameter - cylindrical 400 mm sanding belt length 400 mm Lredpfx Aszfqiwoiien grinding wheel size Ø 500 x 50 x Ø 127 mm Travel distance - U 470 mm Tilt angle – B1 with longitudinal adjustment -1/+12 ° Tilt angle - B1 with workpiece spindle unit -20/+30 ° Manual longitudinal adjustment of the workpiece sp 470 mm Drive power – workpiece spindle 3,8 kW turning speeds 1-895 U/min Load capacity - Spindle head 200 kg Centre height above the swing bridge 200 mm total power requirement 47 kW weight of the machine ca. 10 t dimensions of the machine ca. 3,54 x 2,83 x 2,3 m Accessories / Equipment: - Pneumatic dressing wheel that extends into the working area (mounted behind the workpiece spindle) - Coolant system with paper belt filter - Central lubrication - Spindle cooling - Documentation

Condition: good (used), functionality: fully functional, Internal article number: 26065 Lsdszfh Idepfx Aiiorn Universal milling machine Deckel FP1 Machine no.: 2101-0315 + 2-axis digital display + Stepped feed The machine comes from an educational institution and is in good condition. You are welcome to inspect the machine while it is powered on, in our heated warehouse with over 500 m² of space.

Condition: reconditioned (used), Year of construction: 2014, Immediately Available: Traveling Column Machine FS 2100 • Total travel in X axis: 21,000 mm – ideal for flexible large-part machining • Travel distances: X = 21,000 mm, Y = 1,500 mm, Z = 3,500 mm • iTNC 530 control with wireless HR 550 FS handwheel, operator cabin on the traveling column • 2-axis NC universal drilling/milling head, fully simultaneous and positioning mode per traveling column • Spindle HSK-A 100, 10,000 rpm, 220 Nm spindle torque • ICS air up to 6 bar • Dust protection packages for the safeguarding of guideways and drives • BA 4 per traveling column • Wireless probe RMP 60 by Renishaw • Work area monitoring with network camera and monitor located on the rear of the system • Process monitoring with ToolScope basic system • Additional control panel on the rear of the system • Partial enclosure of the working area and sheet metal door, rear side equipped with a safety fence for unobstructed view into the work area • Including fixators • Cooling aggregates • Including internal tool cooling (closed-loop system) with cooling unit • Short delivery time, immediately available – subject to prior sale – Inspection possible by appointment Spindle hours: approx. 9,079 Ljdpfxezfg S Us Aiisrn SPECIAL PRICE!
