Condition: used, 4 ink trays with 22-channel control from Microcolor I unit remotely (off-press controls) Hnjlev Nzrnjhcdw Hsk

Condition: good (used), IR dryer for 28” (50x70 cm) paper and cardboard processing, for example in the delivery of a 28” offset machine The lamp holder contains 18 lamps of 1kW; the frame in which everything is attached and soldered is liquid cooled, preferably with coolant, the warm air is treated by 2 blowers, one for supply of cool air and one for extraction of the warm air in case of paper stop or paper crash where the machine would stop with sheets in the delivery. The lamps are then switched off and hot air is forcibly extracted. Everything is clearly indicated in diagrams and that is all complete. Holhov Nzq Rscdw Hjnk

Condition: excellent (used), Iijima EFC-1600 die-cutting machine with break-out section and leading edge edging device for package delivery onto conveyor belt. Hnjlhsv Nzpgscdw Hsk

Condition: ready for operation (used), MAS VR4A radial drilling and milling machine Type: VR4A Height adjustment 750 mm Throat 1250 mm Spindle diameter: 80 mm Mounting MC5 Spindle stroke: 300 mm Speed: 2500 rpm Bed: 760 x 1400 mm Dimensions: 225 x 90 x 255 cm LxWxH Weight 3200 kg With separate coolant tank and pump Hslhev Nzcaecdw Henk

Condition: refurbished (used), Year of construction: 1986, Functionality: fully functional, machine/vehicle number: 86053, total width: 1,950 mm, total length: 4,000 mm, total height: 1,800 mm, overall weight: 7,500 kg, type of input current: three-phase, input voltage: 380 V, working range: 48 mm, power: 9.56 kW (13.00 HP), control voltage: 24 V, paper weight (min.): 80 g/m², paper weight (max.): 2,000 g/m², paper width (min.): 350 mm, paper width (max.): 910 mm, paper height (min.): 290 mm, paper height (max.): 670 mm, Equipment: documentation/manual, lighting, Refurbished high quality flatbed die cutting machine from Italy with Spiess insert with steel insert plate with lateral adjustment, a left and right pull attachment (Spiess), double sheet detection, moving upper platen (WUPA system or Kama) with central pressure adjustment as with KAMA, but with the conventional intermittent pull gripper bar system with closing upper grippers. In other words: the sheet moves almost in a straight path through the machine; that is why this machine is ideally suited for lighter paper and cardboard types and is definitely an excellent intermediate step between a Heidelberg SBD and a medium format 40" die-cutting machine from Bobst, for example. No break-out, sheets are laid out directly on the pallet output after die-cutting. The output contains forks to place small format pallets on. Guaranteed pressure force is 200 tons. Stroke of the moving upper platen is 48 mm. Hardened die-cutting plate and device plate. This machine has hardly been used and is in excellent condition, however we have made modifications to further increase the ergonomics and operational reliability. Can be tested at our company and can be delivered with installation and warranty. The asking price is based on this. For all information in various languages, please open the PDF containing the original folder with explanation and specifications. Some specs: Maximum paper-cardboard size 67 x 91 cm Minimum paper-cardboard size 29 x 35 cm Gripper margin 6 to 14 mm Minimum paper weight approx. 80 -100 grs Maximum cardboard thickness 3 mm or 1.5 mm solid cardboard Stroke of the upper platen 48 mm Hnslov Nwwaehcdw Hjk Maximum rotation speed 4500 per hour Minimum rotation speed 1500 per hour Pressure force 200 tons Total power consumption incl. 80 m3 air pump 10 kW (13Hp) Total weight 7,500 kg The die-cutting section is transported separately from the Spiess insert and must be assembled. The electrical switch cabinet is fully plugged in with the components.

Condition: ready for operation (used), Year of construction: 1989, operating hours: 3,500 h, Functionality: fully functional, machine/vehicle number: 20216035, color channels: 2 kleuren met keertrommel ook 1/1, paper weight (min.): 30 g/m², paper weight (max.): 350 g/m², paper width (min.): 148 mm, paper width (max.): 520 mm, paper height (min.): 102 mm, paper height (max.): 360 mm, total length: 2,800 mm, total width: 1,250 mm, total height: 1,690 mm, space requirement length: 2,800 mm, space requirement width: 1,250 mm, space requirement height: 1,690 mm, counter reading (black): 11,500,000, type of input current: three-phase, input current: 16 A, input voltage: 200 V, Equipment: documentation/manual, In exceptionally good and original condition, only 11.5 million prints (!) High-quality "heavy duty" B3 (35x50cm) 2-colour offset machine for high-quality streak-free printing due to typical constructive qualities; The turning device is in excellent condition. Cast-on dense molecular cast iron axles with affinity for oil (pressure lubrication) run in RG12 cast bronze 12 bearings, very durable and very good sliding properties. As a result, these machines print beautiful surfaces and halftones without the notorious shock stripe. We have had a lot of experience with this brand and this machine type in particular since 1991 and can deliver all parts from stock to our customers. For the complete specification see the PDF files at the bottom of this advertisement page. If desired, this machine can be completed with an impression, numbering and perforating unit installed by us (foldable) for an additional charge of € 1500,-- (optional) Some specs: Maximum production speed 11,000 sheets/hour with clean and weather printing 9,000 sheets/hour Paper size: minimum 148x105mm, maximum 520 x 360mm Hnslov Nwgnshcdw Hek Maximum printing surface 500 x350mm Plate size 510 x 410 to 420 mm Paper thickness 0.04 to 0.4 mm 4 ink plate rollers and 2 damp plate rollers (molton dampening) Staffing insert Height of the stack in the insert 900 mm Height of the stack in the delivery 450 mm Chain delivery with 3 gripper bars with hardened gripper tips and carbide coated gripper seats (also with pressure cylinder) Power consumption 4.75 kW Built-in circulation pump and water tank for damp work Dimensions L x W x H = 2800 x 1250 x 1690 mm Net weight 3,560 kg Machine is supplied with oil drip plate Input voltage is 3 x 200/220/230 VAC or via the supplied transformer 3 x 380/400/415 VAC

Condition: used, Functionality: fully functional, color channels: 2 kleuren rechtdoor, paper weight (min.): 30 g/m², paper weight (max.): 350 g/m², paper width (min.): 148 mm, paper width (max.): 520 mm, paper height (min.): 100 mm, paper height (max.): 365 mm, total length: 2,765 mm, total width: 1,523 mm, total height: 1,560 mm, space requirement length: 2,765 mm, space requirement width: 1,523 mm, space requirement height: 1,560 mm, type of input current: three-phase, input current: 20 A, input voltage: 200 V, Equipment: documentation/manual, 2-colour offset press in high-quality construction with hardened and ground gears, cylinders run in class P5 pre-stressed conical roller bearings (sets of 2) and lubricated in oil bath and pressure lubrication. B3 format (35x50 cm) in conventional standard design (no autoplate and/or cocking) but alcohol film dampening with large rollers according to SM52 construction, prints very nicely Originating from 1st owner who did not maintain the machine properly (visually); an extensive maintenance history has been carried out by the importer. The last counter reading in the history is 11.6 Mln from 2003. Due to illness and outsourcing, the previous owner, a printing broker, has hardly used the machine since then. We will check the machine on the current counter reading and ensure correct and proper operation. C)2 dry ice cleaning is still being considered as well as overhauling the entire machine, because the mechanical condition is exceptionally good. This is however cost increasing so the machine is now offered for the cheapest option, that is "as it is", EXW our warehouse in Son, NL. Any type of inspection is of course allowed. We guarantee the machine as free from breakage, cylinder damage and/or repair and damage free to gears. The rubber rollers are vitrified and need to be replaced. The Royce ECO circulation and cooling installation for the dampening work shows signs of corrosion. Some specs, for all specs open the PDF at the bottom of this page. Maximum printing speed 12,000 sheets per hour Maximum paper size 365 x 520 mm Minimum paper size 100 x 148 mm or 148 x 100 mm Maximum printing surface 350 x 510 mm Rubber cloth size 500 x 520 x 1.9 mm Plate size 400 - 410 x 510 mm Dampening rollers in this case of film dampening is 1 (62mm) Number of ink feed rollers 4 pieces of 46, 48, 52 and 54 mm Inlay stack height maximum 850 mm Explanation stack height max 360 mm Electrical connection 3 phases 200 VAC 50HZ (primary) but there is a transformer for conversion from 3 x 415/400/380/230 VAC to 200VAC Power consumption in total 7kW Primary fuse in any case 20A Dimensions LxWxH = 2765 x 1523 x 1560 mm Net weight 4000 kg Hnolhov Nv Tajcdw Hjk

Condition: ready for operation (used), Year of construction: 1990, operating hours: 4,000 h, Functionality: fully functional, machine/vehicle number: 0651044, color channels: 1 kleur, paper weight (min.): 30 g/m², paper weight (max.): 350 g/m², paper width (min.): 148 mm, paper width (max.): 520 mm, paper height (min.): 105 mm, paper height (max.): 360 mm, space requirement length: 1,800 mm, space requirement width: 1,290 mm, space requirement height: 1,650 mm, counter reading (black): 13,084,844, type of input current: three-phase, input current: 16 A, input voltage: 220 V, Equipment: documentation/manual, In exceptionally good and original condition, only 13 million prints (!) High-quality "heavy duty" B3 (35x50cm) 1-colour offset machine for high-quality streak-free printing due to typical constructive qualities; Helhcev Nv Svodw Henk Cast-on dense molecular cast iron axles with affinity for oil (pressure lubrication) run in RG12 cast bronze 12 bearings, very durable and very good sliding properties. As a result, these machines print beautiful surfaces and halftones without the notorious shock stripe. We have had a lot of experience with this brand and this machine type in particular since 1991 and can deliver all parts from stock to our customers. For the complete specification see the PDF files at the bottom of this advertisement page. If desired, this machine can be completed with an impression, numbering and perforating unit installed by us (foldable) for an additional charge of € 1500,-- (optional) Some specs: Maximum production speed 11,000 sheets/hour Paper size: minimum 148x105mm, maximum 520 x 360mm Maximum printing surface 500 x350mm Plate size 510 x 410 to 420 mm Paper thickness 0.04 to 0.4 mm 4 ink plate rollers and 2 damp plate rollers (molton dampening) Staffing insert Height of the stack in the insert 900 mm Height of the stack in the delivery 450 mm Chain delivery with 3 gripper bars with hardened gripper tips and carbide coated gripper seats (also with pressure cylinder) Power consumption 3.2kW Built-in circulation pump and water tank for the damp work Dimensions L x W x H = 1800 x 1290 x 1650 mm Net weight 1,960 kg Machine is supplied with oil drip plate Input voltage is 3 x 200/220 VAC, no transformer included

Year of construction: 1997, Condition: excellent (used), Functionality: fully functional, machine/vehicle number: 052302303, Bobst Easypress 142, for the format 102x142cm to carry out models, test punching, preparation work for the production machine. excellent condition, year of construction 1997 Hnjlhcdwouk I Nxj Hjk

Condition: excellent (used), Year of construction: 1978, Functionality: fully functional, machine/vehicle number: 6F070, total length: 1,800 mm, total width: 1,150 mm, total height: 1,600 mm, type of input current: three-phase, input voltage: 200 V, power: 3 kW (4.08 HP), overall weight: 1,400 kg, Equipment: documentation/manual, 1978 very original in excellent condition one color offset machine from the Japanese Sakurai with never used Number Perforating and Impression unit (sprayed in tectyl and deliberately not cleaned by us) is really for that time, compared to other makes incl Heideleberg's GTO46 a top class machine. Very nice and solid machine. Hjlhcdwouga U Ds Henk Paper size 32 x 49 cm working with the same size plates as at that time the Rotaprint broadened models as well as Romayor and Fuji 50. The condition is so fine that it would almost be allowed in the reception room of the manufacturer. All documentation is included, electrical schematics are complete with legend and parts book belongs to this machine.

Condition: excellent (used), Year of construction: 1988, Functionality: limited functionality, machine/vehicle number: 25.05.004, total length: 9,500 mm, total width: 2,250 mm, total height: 2,300 mm, input voltage: 380 V, power: 50 kW (67.98 HP), overall weight: 21,000 kg, compressed air connection: 7 bar, net weight: 18,000 kg, Equipment: documentation/manual, Paper size 730 x 1060 mm and printing area 710 x 1040 mm Hnslsuf Sy Ashcdw Hsk Paper thickness 0.05 mm - 0.5 mm Set maximum speed (i.v.m. mimicking road time fast printing presses) is 4000 per hour, but machine can run much faster for commercial work. Four-fold central backpressure cylinder that unwinds all 4 printings in 1 gripper closure. 1988 FAG speedproof with control cabinet for ink trays and cylinder adjustment for highly accurate register printing.Attached is an original factory brochure.Fully dry ice cleaned and cylinders are in very good condition. Machone is offered only on the basis of ïn the condition it is in, as is. The largest width is 225 cm, the largest height is 230 cm; shipping in High Cube container is possible. Price is definitely a fixed price and based on taking away parts we can sell separately such as the Mabeg with vacuum belt insert and the 4-fold Baldwin stainless steel unit with for each color a separate bath, a mixer and an adjustable temperature, so all four baths can have different temperature and different alcohol percentage set. We dry ice cleaned the machine and it was intended to play a prominent role in electronics paper printing, but due to too many run-up losses, project was discontinued. The machine has been with us for 3 years now and due to its size I want it sold as soon as possible. Therefore this very low price. It is an uisteful machine. Should the machine still need to be set up for testing and trials, then that is possible, at an additional cost of € 10,000, of which € 5,000 must be paid in advance as a down payment under conditions. All relevant information can be found in the original FAG leaflet of the machine, to be found via this advertisement as PDF

Year of construction: 1966, Condition: used, Functionality: fully functional, machine/vehicle number: 562-66280, Hydraulic bridge punching cq cutting machine with forward and backward moving upper platen. Working area 600 x 2000 mm. Max oil pressure per cylinder 400 bar with a diameter of 185mm = 107 tons per hydraulic cylinder Guaranteed pressure force regardless of load location 100 tons Dimensions of the machine 320 x 170 x 190 cm Weight 4,500 kg Machine is without oil; which has been drained upon removal All electrical documentation is complete; even warranty certificates for the Sick photocells from 1970 ! Hjloud Rhvjhcdw Henk

Condition: excellent (used), Year of construction: 1984, operating hours: 1,000 h, machine/vehicle number: 51510274, in exceptional good condition a mid 80's Dominant 515 NP wi Hnelhcdwst Etitj Hjk

Condition: excellent (used), Year of construction: 1976, full-hydraulic - driven by tasting unit - wiith single operated unit - has a range of lxwxh 400 x 350 x 250 mm. ISO 40, fourth shaft/axle to copy drum curves Hjlhcjt Ab Ufjdw Hjnk

Year of construction: 1968, operating hours: 35,000 h, Condition: good (used), Functionality: fully functional, machine/vehicle number: 7723238, 72x102cm two revolution die cutter for thin paper and light carton up to 600 grs/m2. excellent stable and very silent fast cylinder press. Locking to the floor is not necessary. Price is for each machine, NOT for the package. Package is 15% discount. Two identical machines available from the same shop, both with the same specs and the same state of maintenance. As a kind of specialist in these type of machines, I have delivered machines to this company which already had one, so at certain moment they produced with 4 machines and 6 or 7 Heidelberg Cylinder presses at half the size. maintenance always carried out by my company, so both machines have a known history, which is good. As a result of shrinking industry in The Netherlands and different types of shivering/perforating/scoring on offset presses with the cutting plates, the company went to a smaller building and only kept one Condor. In my opinion the best, fastest and strongest letterpress ever, built in this size, for sure! With less parts than a Heidelberg SBD and running much smoother. As a result of my cooperation with the KBA factory and particular Mr. Hans Bernhard Bolza-Schünemann who is the engineer responsible of the several new innovative constructions in the Condor, a small sized Condor (65x95cm) in very good original condition as a complete printing press, with some ""patina"" was donated to the Leipzig -er Museum für Printkunst (June 2002), because of its importance for the development of the printing industry in the 60's. Holotyy Sfohcdw Honk

Year of construction: 1966, operating hours: 10,000 h, Condition: excellent (used), Functionality: fully functional, outer diameter: 420 mm, machine/vehicle number: 58256, Nebiolo Saturnia in very good condition. From first owner, at first used as a letterpress in the upcoming market with offset in the 70's. The company always produced with it's offset to maxima 50/70 size. Situated as a local printer in a village, the Nebiolo was sometimes used for rilling, slitting, scoring some offset jobs. very good machine, low noise, excellent condition of al mechanical parts. Airpump for feeder and delivery is for a later make = Becker dry-pump 100m3 with low noise. All parts necessary for the machine come with the machine, even as the original operational book and spare-parts book. The cylinder has a 6 cm larger diameter than a KBA Condor and it weights 800kgs, only 200 kgs less of that of a heidelberg SBB/SBD. Hnslhcdjtyyvwow Hjk The delivery is different and for carton better that that of its competitors: a triple drum delivery, turning the front side up again on the belts which transport it to the pile. Best is to replace the individual belts for one large belt and make some extra attention for laying the sheets down when coming from the belt with better air facilities. Of course we can arrange that for you either. Then you have a faster, very easy to operate and maintain with better productivity and at least the same durability (with lower noise-level due to less moving parts) than an heidelberg SBD with approx the same size for more than double the money. Really a nice product from Nebiolo even as it big brother Urania. They have pull-lays but can easily turn over to push side lays. Some specs: Max paper size 650 x 950 mm Min paper size 300 x 420 mm Speed 1500 - 4000 imp/hour Feeder pile height 550 mm Delivery pile height 650 mm Impression force approx. 35000 N (not adjustable in lighter or heavier, only one value) Bearer height 24,85 mm; machines needs "normal - Bobst standard" 23,80 diecut forms/lines with a hardened steel plate under the form so that small compensations could be made with thin band and paper under this hardened plate. This is the only and best method. A 45 to 47 HRC plate will be delivered with the machine, even as a new cylinder jacket. Feeder and delivery use an additional extern pump, Becker, 100m3, 2kW Size of the machine (approx, with steps) L x W x H = 330 x 220 x 190 cm Weight net 4,800 kgs

Year of construction: 1963, Condition: used, Functionality: limited functionality, machine/vehicle number: 512804, 1963 Bobst SP900E with double action stripper in reasonable/good condition. Well-maintained.. in recent years for example sprocket wheels, main gripper chains, counterplate under cuttingplate, cardan joints to the feeding head, have been renewed (original Bobst parts) Gripperbars have not been renewed recently, they are still in quite a good condition. The knee joints have almost no signs of wear. they were probably at some point and the machine has not been used much since then. There is hardly any screech on them. Hnelhetyqizjcdw Hsk Machine is dismantled in our storage in the South of The Netherlands, dismantled and not under power. For seriously interested potential buyers we will further upgrade the machine and assemble it and give the possibility to test it inevery way they want. In that case price will be 22,000 euros, loaded on to your transport, EX SITE

Condition: good (used), Year of construction: 1989, 2-color "straight" offset machine with low-stack explanation; 48x66cm, last modified type of this model (= best) Helhjtyqhqscdw Hjnk

Condition: good (used), Year of construction: 2013, 4-color "straight" offset machine with layer stack explanation, autoplate, cocking and CIP3 ink bin and remote control Helhcdwotyqhke Henk

Condition: refurbished (used), machine/vehicle number: 62562, Fully rebuilt nebiolo Urania (80x112cm) two revolution cylinder diecutter is cutting 80grs silk with pages of a road map with on different positions finger tabs. Later cut by guillotine on 1 side to seperate them all. Mechanically rebuilt and modified Electrical completely modified with PLC and inverters for main drive, feeder pile up and down and in steps upwards, delivery pile up and down and in steps down with capacitive sensor in combination with timing function in Siemens PLC and inverterdrive. Siemens PLC, programm and electrical diagrams available and delivered with the machine. Low impressions since 2012; only used for thin and very thin paper qualities with less register tolerance in good register; client had several Bobst diecutters in production. Photos available on request. Max paper size 80 x112cm Min paper size 30 x 42 cm Max size inside form frame 78,5 x 108,5 cm, between bearers 78,5 x 112 cm Max height feeder pile 108 cm Max height delivery pile 118 cm Main motor 7,5kW with 9kW Altivar inverter and power resistance Neet weight of the machine ca 9 metric tons Size of the machine including steps 557 x 252 x 180 cm Hnslhcetyqgyodw Hsk Machine needs 7 bar pneumatic airsupply for several electro-mechanical functions, no compressor included An air pump 2kW with 100m3/min airflow is included
