Condition: good (used), Production capacity of up to 4000 b/h (depending on the format) For formats between 0,25lts up to 3lts Composed by: Helhjwcggvscdw Honk • Oven for heating the preforms composed of 6 heating modules with 8 infrared lamps each • Preform transfer Wheel • Two-stage compressed air blowing body, low pressure pre-blowing and subsequent high pressure blowing. • Bottle transfer Wheel • Delivered with pallet turner. DOCUMENTATION AVAILABLE

Condition: excellent (used), Compressor type: Dry air Hnslhcjwcgc Redw Hek Revolutions per minute 750 Outlet pressure: 42 bar Volume spawned: Number of cylinder lines 2/4 stages Supplied air: 7.73m³ / min; 464m³ / h Motor power: 90kW

Condition: good (used), Composed of: 2 hydraulic presses of 1000bar/max de capacity Hjlhcdwewcf Rtj Hjnk Hydraulic control unit with individual regulation of each equipment

Condition: used, For basquets Ø 500 mm. Power 10 Kw Hjlhcdwjwcf Npe Hsnk

Condition: good (used), Year of construction: 2000, Equipment: documentation/manual, PLS2500 2D laser with 2 x cutting table with usable area: 3140 x 1640 x h100mm, Axis stroke 3000x1500x150mm (XYZ), Maximum speed linear axes 40m/min (XY) and 20m/min (Z), Neck LGL France type NLEX 35, Sideros Engineering dust extraction system 3000W CO2 laser source Hnjlhjwcf Dgscdw Hjk DOCUMENTATION AVAILABLE

Condition: like new (used), Year of construction: 2015, operating hours: 10,740 h, Functionality: fully functional, Composed of: OPTIMO machine + CNC control panel P30L S/N 15/40 - 0083-01, CV4000 laser Working hours: 10740. Linear axis strokes: 4500x2500x1020mm (XYZ) Rotary axis strokes: A axis +- 360º continuous, B axis +- 135º. Adaptive axis stroke (with part position sensor) C axis +- 10 mm Maximum speed of the linear axes (XYZ) 50 m/min Max. combined speed of linear axes 85 m/min Maximum speed of rotary axes A,B 540º/sec Acceleration of rotary axes A,B 60 rad/sec2 Power supply 400V, three-phase, 50hz Prima Power wired remote control S/N 14/06 00489 4000W CO2 laser source Hyfra Sigma 52-S collar, installed power 53kw/58kva. Hslhcdswcfzfew Hsnk Aspiration and dust treatment system Donaldson DFPRO12, installed power 15kw/18kva. Donaldson MD2 Micro Dosing System

Year of construction: 2004, Condition: good (used), Composed of: Hslhcdwewcfq Hs Hsnk • Weigher/divider/tedder. For all types of masses. Automatic greasing system. Adjustable weight 60 to 600 gr • Weigher/divider/heiner. For all types of masses. Automatic greasing system. Adjustable weight from 60 to 600 grams. Speed variator. • 40 Kg Hopper for dough, made of stainless Steel and non-stick material • Flour sifter • Digital piece counting • Resting chamber with 400 baskets • Bread loaf former, tape width 600 mm.

Condition: good (used), For 1 cart Max. temperature 400ºC Gas operation. FLAXMER burner Cart dimensions: 600 x 800 mm. Height 1800 mm (15 trays) Hnjlhcswcfqajdw Hsk Included 3 carts

Year of construction: 2009, Condition: like new (used), Vertical type abrasive peeler. Suitable for fresh or blanched products, using abrasives in a drum. It has a loading buffer with level detectors and a gate valve. It is possible to regulate the peeling time and the opening time of the gate by means of regulators located inside the electrical panel. Loading height: 1820mm Load capacity: 25kg Hnjlhswcfn Sjcdw Hjk Power: 1.1kW Voltage: 220/380V III 50Hz Overall dimensions 1000 x 1200 x h1800mm

Condition: good (used), Made of stainless steel. for marinating meat products of 2m³ Helhswcfnxecdw Hsnk With vacuum system and heating jacket Includes ROCASA type B500 lift / turner manufactured in 2011 for loading, access platform with ladder and upper flag for hoist. Mixer drum dimensions: Ø1300 x 1300mm

Year of construction: 2003, Condition: used, For packaging meat products and derivatives. Holhcdwewcfnfs Hjnk Compact machine made up of a thermoforming module, loading area, upper film applicator, welding area and cross section. Bottom film width: 520mm Upper film width: 515mm Mold 4 x 2 trays dimensions: 150 x 120mm With ink injector IMAGE mod. 9040

Condition: excellent (used), Continuous horizontal press, to compact and pack materials such as cardboard, paper, plastics and others. IMABE IBERICA brand, pressure 125TN, loading mouth 1800 * 1000mm, with blades on the top of the compaction carriage that allows cutting the excess material above the compaction tunnel. Folding compaction tunnel, both at the top and on the sides, for greater retention of the material, outlet for bullets of dimensions 1050 * 1100mm and adjustable length. Automatic tying system, lateral, by 5 wires, for high production 30-35ton / hour. Hnjlhcov U R Agedw Hjk Fully rebuilt and revised in 2019

Condition: excellent (used), Year of construction: 2005,  Linear double head labeller, prepared for the placement of self-adhesive labels on multiform containers (Cylindrical, square, rectangular, oval, conical, etc...) Up to two labels per container, for partial or wrap-around labels, fast format change (without tools) With motorized top belt, side maintenance belt, motorized spacer worm gear and electronic speed variators. Maximum container dimensions: -. Cylindrical: Ø110mm -. Oval: 150 x 110mm -. Rectangular (similar): 110 x 85mm Maximum label dimensions: 250 x 10mm Maximum production: 4000b/h 220; 800W 50Hz AVAILABLE DOCUMENTATION Hnelhcdov I A Iusw Hok

Condition: excellent (used), Year of construction: 2016, Automatic blister machine for forming or molding blisters in PVC, PVDC, Polyethylene, Aluminum, etc. Sealing, for joining the formed and loaded line with the product to the upper line of Aluminum, Cardboard, Polyethylene, etc. Thermoforming and heat-sealing area: 400 x 200 mm Hsljv I Ay Rehcdw Honk Includes a trimming unit for individual platelets, film unwinder/feeder, and winder for waste collection. Supplied with a reel handling cart, reel loading cart, and format changeover cart. 21 kW; 380 V III+N Overall dimensions: 7400 x 963 x h1900 mm

Condition: excellent (used), Year of construction: 2011, Forming, filling and sealing of "berlingots" machine (with or without spout) of flat PVC or EVA film or any film that can be sealed by radiofrequency. Radiofrequency welding system that allows a very good quality of longitudinal sealing and sealing/transverse cutting. Fully PLC controlled and all operating parameters can be adjusted from the touch screen. Thanks to its specific dispenser, any type of aggressive product can be packed in this machine. All parts in contact with the product are made of stainless steel. Helhjv I Avxscdw Henk Production output 1800 to 3000 Bags/H Bag volume from 50 to 500 ml Bag length: 70 to 265 mm Maxi outer diameter of the coil: 400 mm Inner diameter: 76mm Includes product exit tape AVAILABLE WIRING DIAGRAMS

Condition: excellent (used), Year of construction: 2012, Complete dosing, packaging, capping and labeling line ccomposed: MIPSA tank, with agitator, made of fiberglass, on legs, with a conical bottom, lower outlet and upper mouth. Capacity: 2.5m³ PCM MM18C12S-FOOD screw pump , suitable for food and cosmetics (Year 2020. )With progressive cavity and short screw to avoid product loss in the final phase of racking. Max capacity: 40 m³/h at 498rpm, 3bar Hnslhsv Iz Uyecdw Hjk 4.8m³ APV tank made of stainless steel, on legs, with a conical tank bottom. Lower outlet, inlet and upper mouth. GRONINGER DFV-6000volumetric filler model , manufactured in 1991 and completely rebuilt in 2012. With 6 nozzles, dosage from 40 to 1000 cc, includes a centrifugal pump to fill the lung. ROBERT BOSCH GmbH manual pneumatic closer of 10Nm of torque and 1050rpm Linear labeling machine with 1 head, with adaptation to cylindrical container. height max. label 200mm. Includes EURO CODIC model M30 thermal transfer marker.

Year of construction: 2007, Condition: good (used), Composed: • MAYPER Shredder. Power 4 Kw • Product elevator. Width 350 mm. Length 4.000 mm • GUIDETTI SINCRO 315 Compact granulator. Capacity 130 Kg/h. 6,1 Kw. 400 V 50 Hz Hnjlev Iykmohcdw Hok • FORNUMAC Conveyor belt. Width 250 mm. Length 1500 mm

Condition: good (used), Year of construction: 2018, Functionality: fully functional, Con tres piedras de granito de Ø1200, Ø1250 y Ø1300mm respectivamente, diseñado para la molienda artesanal de la aceituna. Fondo construido en granito rosa y tanque en acero inox. Holhcdev Ivftow Hsnk

Year of construction: 2018, Condition: excellent (used), Functionality: fully functional, With input of olives with residues, output of leaves, output of soil and small residues from sieves. Composed: Roller screen, self-cleaning by means of a calibrated platen and high-resistance 3mm thick rollers. Air turbine, operating system based on an air current that falls on the product curtain. The air is adjustable in direction and flow to ensure optimal separation. Double reel, first reel located near the vibrating tray to retain large branches and create a good curtain of olives for cleaning. Second windlass installed on the roller screen to help all those branches that due to their weight cannot dislodge the air turbine. Hnjlhcdwsv Ivfao Hjk Roller guide, easily accessible chain traction system and protected by highly wear-resistant polyamide that soundproofs the entire machine. Leaf outlet regulator, for regulation of leaf and product separation depending on the variety of olives.

Year of construction: 2009, Condition: good (used), Functionality: fully functional, Production of 2000 kg/day (6h) Composed of: URBASA Q908.010b slicer MARRODAN PR32318 B/T elevator to load scalder. With PVC/Polyurethane 3C 500 band with studs. overall length: 3000mm. useful width: 500mm. Power 0,37 Kw MARRODAN PR32217 Linear mesh scalder, for vegetable products. The regulation of the scalding/hydrating system is carried out by means of a temperature controller connected to a PT100 probe. The forward speed is regulated by a frequency variator. Basic construction in AISI 304 STAINLESS STEEL Polypropylene mesh type A-1061mm Total installed power: 4.7kW Group of 2 pulping machines and 250-litre heated tanks for mixing and cooking INOXPA HYGINOX SE centrifugal pump of STAINLESS STEEL, driving the product to exchanger. UNICUS type HRS dynamic heat exchanger with scraper device to increase the heat transmission coefficient Hslov Ivcxshcdw Honk AVAILABLE DOCUMENTATION
