Used Workshop Lathe for sale (8,981)

Condition: used, Year of construction: 1999, turning diameter 450 mm turning length 380 mm control Seicos 40L Multi max. machining diameter 340 mm Bar feed 51 mm turning speed range - spindle 30 ~ 5.000 U/min drive capacity - spindle motor 11 / 7,5 kW spindle nose A2-6 spindle bore 59 mm bearing diameter 100 mm travel -x axis 215 mm travel -z axis 400 mm turret (x-stations) 16 feed 0,001 ~ 500 mm/min rapid traverse X/Z: 30 m/min Shank diameter 25 x 25 mm Drill shank diameter 40 mm Gjdpfx Aex S Rxuegbjil taper of center MK 5 tailstock adjustment 300 mm total power requirement 23 kVA weight of the machine ca. 4,6 t dimensions of the machine ca. 5,5 x 2,8 x 2,2 m CNC Lathe HITACHI SEIKI - HiTec-Turn HT 20 RIII

Condition: good (used), Year of construction: 2018, functionality: fully functional, Fanuc control, two turrets, Y-axis, counter spindle, short bar loader, accessories Gijdpfxsx S N Tqo Agbol

Condition: used, STAR SW 20 is a CNC automatic (Swiss-type) lathe offering high precision, strong accuracy and reliable performance. Capacities: 11 axes, 2 spindles, max machining Ø 20 mm, back spindle up to 10,000 t/min. Specs: spindle 3.7 kW, driven tools 1.2 kW (8,000 t/min), carriages with 7 and 5 positions, counter-operation 8 tools (6 driven), rapid traverse 35 m/min, 50 Hz 3x380 V, ~3400 kg, L2600×W1150×H1765 mm. Accessories: bar loader, lamp, 150 l coolant system, ELBARON oil-mist extractor, interface for bar loader. Achieves tight tolerances; typical uses: automotive, watchmaking, tooling, aerospace, medical. Gisdpox S N Sysfx Agbsl

Condition: excellent (used), Year of construction: 2007, turning length: 1,545 mm, turning diameter over cross slide: 660 mm, spindle bore: 65 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,545 mm, Make: MAZAK Type: INTEGREX 200-4 ST Control: MAZATROL MATRIX Year: 2007 Multi-Tasking Machining in a Single Machine Setup Sub spindle for overtaking with full C-Axis The INTEGREX IV series can finish all machining processes. High speed, advanced milling spindle that can tilt up to 240 degrees swiveling. Lower turret with rotary tool spindle so livew tooling Chip conveyor with coolant and 15 Bar iKZ Double chuck KNCS-N 210-53 SMW Autoblock MAZAK Flex -GL150F Gantry Loader Gripping range 200 x 120 length x 15 Kg Max. turning Ø: 660mm Gjdjx S Hm Iepfx Agbjil X-Axis: 580mm Y-Axis: 160mm Z-Axis: 1545mm B Axis: 270° Spindle bore: 65mm Speedrange: 5000Rpm Spindle power: 22kW Subspindle speeds:5000Rpm Subspindle bore: 65mm Subspindle power: 18.5kW ATC / revolver: 40 B-Axis Toolsystem:Capto C6 B-Axis Speedranges:12000Rpm Length: 5200mm Width: 2550mm Height: 2600mm Weight: 14000kg

Condition: used, Year of construction: 1998, Technical details: turning diameter over bed: 600 mm turning diameter over support: 400 mm turning length: 2000 mm center height over support: 300 mm centre distance: 1600 mm revolution per minute: 3 - 2.500 U/min tailstock taper MT: MK 5 Gisdpfxow Rkt Io Agbol spindle bore of work spindle: 62 mm quill stroke: 190 mm longitudinal feeds:: ca.0,001-10 einstellbar mm/U cross feed: ca. 0,001-5 einstellbar mm/U Rapid feed X axis: bis zu 5000 m/min. total power requirement: 40 KVA weight of the machine ca.: 5,6 t dimension machine xH: 4,0 x 2,0 x 1,9 m incl. accessories see picture *

Condition: good (used), Year of construction: 2005, functionality: fully functional, Technical details swing over bed 730 mm centre distance 3000 mm control Heidenhain MANUALplus4110 weight of the machine ca. 6,5 t dimensions of the machine ca. 7400 x 2100 mm Additional information Very well-maintained cycle lathe with only 15652 operating hours. Working area: Center distance 3000 mm Swing diameter over bed 730 mm Swing diameter over cross slide 450 mm Bed width 480 mm Main spindle: Spindle mount according to DIN 55027 size 11 Spindle bore 130 mm Spindle diameter at front bearing 170 mm Spindle taper 1:20 Tap in center sleeve MT 6 Main drive: AC drive with 2-stage ZF gearbox (automatic shifting gearbox) Drive power (100/60% duty cycle) 22/28 kW Total speed range 1 - 2200 rpm Maximum spindle torque: approx. 2200 Nm X-axis (cross slide) performance data: Maximum travel: 400 mm Feed force: 14 kN Speed: 4 m/min Z-axis (bed slide) performance data: Feed force: 18 kN Speed: 7 m/min Max. workpiece weight: Between centers without steady rest: 2000 kg With one steady rest: 2200 kg With two steady rests: 2500 kg In the chuck: 750 kg Tailstock: Quad diameter: 115 mm Quad stroke: 225 mm Quad taper: MK 6 Equipment and accessories: Heidenhain MANUALplus 4110 CNC control SCHUNK ROTASplus 400-102 3-jaw manual chuck Gedpfx Agox S Ehdsbsil 2 steady rests PARAT tool holder Chip conveyor Coolant system Work area enclosure with two sliding doors. Machine length 5700 mm, with swarf converyor 7400 mm Machine width 2100 mm

Condition: new, Year of construction: 2025, Heating capacity / nominal heat output: 21 kW For rooms up to approx. 300 to 500 m³ (according to DIN 4108) Flue pipe outlet: rear side (standard) Flue pipe: Ø 180 mm Filling volume: 80 ltr Gjdpfx Ashvibzsgbeil Required chimney draft min. 12 Pa Mass of the filling opening (L x W) 300 x 340 mm Weight: 375 kg Efficiency 88,2 Energy efficiency class: A+ EWI-A 15G space heaters are type-tested according to DIN EN 13240, according to 15a B-VG (Austria) and LRV (Switzerland). They comply with the limit values of the 1st BImSchV. (Federal Immission Control Ordinance)

Condition: new, The V-Turn 410 PRO, a cutting-edge Conventional Horizontal Lathe from KNUTH, represents the latest in the Engine Lathes product group, designed for both efficiency and precision. This machine boasts improved ergonomics alongside enhanced safety features, making it user-friendly while maintaining top-tier performance. Equipped with a powerful 5.5 kW spindle motor and an innovative inverter, it reaches speeds of up to 3,000 revolutions per minute, allowing efficient machining of workpieces with varying diameters. Its constant cutting speed function automatically adjusts the spindle speed during face turning, achieving results comparable to CNC lathes. With a robust and rigid construction, including a heavily ribbed machine bed and pre-loaded spindle bearings, this lathe ensures exceptional stability and precision. The standard equipment includes a 3-axis position indicator, coolant system, and various tool holders, enhancing its functionality for diverse machining tasks. You can buy now to elevate your machining capabilities with the V-Turn 410 PRO, a remarkable addition to the Conventional Horizontal Lathes and Engine Lathes by KNUTH. Gedpfxoww T S Io Agbjil

Condition: good (used), COLCHESTER COMBI 4000 is a CNC turning lathe engineered for precision, high accuracy and reliability. Capacities: distance between centres 2000 mm, turning diameter over cross-slide 370 mm, swing over bed 554 mm, max turning length 2000 mm; Z travel 1920 mm, X travel 290 mm, spindle hole 104 mm, spindle nose D1-11, Camlock D1-6, tailstock Morse 6 CM, spindle stroke 178 mm Ø95 mm. Specs: 3-step speeds 16–1800 t/min, rapid traverse 10 m/min, spindle motor 11/7.5 kW, 50 Hz 3×380 V, weight ~4000 kg, overall L3300×W1800×H1700 mm. Equipment: 3‑jaw Ø400 mm and 4‑jaw Ø700 mm chucks, faceplate Ø680 mm, 90 l coolant, MULTIFIX toolholders, toolholder sets and reducing bushes, lamp, tailstock, steady, drill chuck, chuck protection. Delivers tight tolerances; ideal for automotive, aerospace, medical, watchmaking and machine tool sectors. Giodpfx Asx S N Hdjgbjl

Condition: excellent (used), Year of construction: 2006, turning diameter 330 mm turning length 750 mm control WEILER D3 dia. of quill 50 mm quill stroke 130 mm taper in tailstock-quill MK-3 spindle turning speed range 1-4500 U/min taper in main spindle MK-5 Giodpjx Szpwsfx Agbel weight of the machine ca. 1400 kg dimensions of the machine ca. 1900 x 1300 x 1800 mm This WEILER E30x750 is in very good condition and can be viewed by arrangement with the seller. - Lever quick-release chuck for pressure collets DIN 6343-48/173E and Rubber-Flex collets, clamping range 3-42 mm diameter, with mechanical and electrical locking, max. speed 4500 rpm. - 1 set of pressure collets DIN 6343-48 / 173E - Adjustable hollow spindle stop 38-48 mm for main spindle - Live steady with sliding jaws, passage 10-85 mm - Three-jaw chuck with wedge bar system, diameter 160 mm, bore 42 mm, with mounting according to DIN 55027 /5, with 1 set of basic jaws and hard reversible attachment jaws - Lever quick-action chuck for pressure collets DIN 6343-48/173E and Rubber-Flex collets, clamping range 3-42 mm diameter, with mechanical and electrical locking, max. speed 4500 rpm. - 1 set of pressure collets DIN 6343-48 / 173E - Adjustable hollow spindle stop 38-48 mm for main spindle Translated with (free version)

Condition: used, Year of construction: 1987, turning diameter max. 400 mm turning length 1.000 mm control EPL 2 greates pass round over bed 400 mm Swing dia. over traverse guideway 225 mm travel -x axis 260 mm travel -z axis 1.040 mm turning speed range - main spindle 20 - 4.000 min/-1 power capacity - main spindel 11 kW max. Torque 75 Nm spindle bore 72 mm chucking diameter 185 mm spindle head 140H5 spindle diameter in front bearing 100 mm number of toolpositions 12 pos. diameter of quill 80 mm quill stroke 100 mm taper of center MK 4 Giedex Sy Uropfx Agbsl pressure max. 800 daN rapid power traverse in X-and Z direction 10 m/min Feed speed x: 5 m/min. Feed speed z: 5 m/min. Feed force x: 500 daN Feed force z: 800 daN total power requirement 29 kW weight of the machine ca. 4,0 t dimensions of the machine ca. 4,6 x 2,1 x 2,0 m CNC - Lathe GILDEMEISTER - NEF CT 40

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, Technical details faceplate diameter 1800 mm swing diameter 2000 mm turning height 1270 / 1120 mm Control SIEMENS 840 D workpiece weight max. 5000 kg ram head dimension 250 x 250 mm table turning speeds 1 - 320 U/min cross rail - adjustment 400 mm ram head - cross travel (X) -2770 / +2275 mm ram head - vertical travel (Z) 1250 mm c-axis 360° (0,001°) deg milling drive 37 kW turning speed range - milling 10 - 3000 U/min power capacity - table 100 kW Torque 31784 Nm feed range (X/Z) 0,1 - 15000 mm/min weight of the machine ca. 55 t Additional information Used CNC vertical lathe for turning, drilling and milling First machine installation in the year 2011. Max. workpiece diameter: 2040 mm Max. workpiece height: 1270 mm Ram stroke: 1250 mm Max. workpiece weight: 5000 kg (per pallet/chuck) Table speed range: 1.0 - 320 rpm Table drive motor: 100 kW Drilling and milling spindle: 37 kW Crossbar travel: 2 steps of 200 mm each Total electrical connection value: 218 kVA CNC control: Siemens 840 D Number of NC axes: 4 (X, Z, C, crossbar adjustment) Giedpfjx S Efpox Agbjl Travels: X-axis: -1650 to + 2165 mm Z-axis: 1250 mm Rapid traverse X- Z-axis: 15 m/min Number of tool magazine spaces: 80 spaces in the chain magazine, of which 60 x HSK 100 and 20 x Capto C6 Disc magazine 12-pos. for rotary holders and attachment heads Coolant system with filter and circulation unit Chip conveyor Oil-mist-extractor 1 pallet with jaws, diameter 1800 mm 1 hydraulic chuck with base jaws, diameter 1800 mm Various drilling and milling heads 2 measuring probes Several turning tool holders Special feature: Pallet changer with two stations, equipped with a face plate Ø1800 mm and a six-jaw lever compensation chuck with mechanical centrifugal force compensation Ø1800 mm. Note: The machine is in a pit. Condition description: The cross roller bearing on the Carnaghi was replaced about half a year ago. The Siemens components in the control cabinet were also completely replaced at the end of 2023. The machine also has a measuring probe for tool measurement and an external Renishaw measuring probe for workpiece measurement. As a special feature, the machine also has a measuring probe installed on the Z-axis (Z1-axis). This brings an advantage in terms of accuracy and time, as the tool does not have to be put down for measuring. However, it is currently shut down and should be overhauled when it is put back into operation. The machine also has a Rotomors six-jaw lever compensating chuck with centrifugal force compensation, which was completely overhauled in 2020/21.

Condition: new, Year of construction: 2025, Heat output / nominal heat output: 17.8 kW For rooms up to approx. 300 - 400 m³ (according to DIN 4108) Filling volume: 78 ltr Gijdpfx Agjdlmnnsbjl Mass of the filling opening: Ø 215 mm Flue outlet: rear side (standard) Flue pipe Ø 180 mm Required chimney draught min. 13 Pa Weight: 250 kg Efficiency: 79,02 Energy efficiency class: A The room heaters GRA-N are type-tested according to DIN EN 13240, according to 15a B-VG (Austria) and LRV (Switzerland). They comply with the 1st BImSchV (Federal Immission Control Ordinance) stage 2.

Condition: used, Year of construction: 2011, turning diameter 0700 mm turning length 800 mm control 840D Siemens turret head 12 swing over bed 380 mm spindle turning speed - stepless 10- 5000 rpm spindle bore 67 mm feed - longitudinal/cross 20000 mm/min rapid travel - longitudinal/face 30 m/min dimensions 5000 x 2800 x 2000 mm total power requirement 65 KVA Gisdpfx Agjx Sy U Esbsl weight of the machine ca. 7,5 t Machine has 6 live tooling positions

Condition: used, TORNOS Micro 8 is a CNC automatic lathe engineered for high-precision machining with strong accuracy and reliability. Working capacities: 5 axes, workpiece length max 20 mm, max bar diameter 10 mm; collet tapers W15 (spindle) and F13 (back spindle). Key specs: stepless spindle 0–12000 t/min; rapid traverse X 20 m/min, Y 40 m/min, Z 20 m/min; spindle/back-spindle motors 2.2/3.7 kW; 3x400 V 50 Hz; total power 8 kVA; weight ~1600 kg; dimensions 1670×870×1650 mm. Equipment: LNS TRYTON 112 bar feeder, lamp, coolant system, oil mist extractor, RS232 interface, status light. Delivers tight tolerances; suited to automotive, watchmaking, machine tools, aerospace and medical sectors. Gedpfex S Nwcsx Agbsil

Condition: used, L + Z Lathe ZMM - SLIVEN (Bulmak - Bulgaria) Type CU 325 Machine No.: 8169 Year of manufacture: 2002 Centre distance: 1000 mm Swing over bed: 320 mm Centre height over bed: 160 mm Swing over cross slide: 190 mm Centre height over cross slide: 95 mm Spindle bore: 32 mm Spindle speeds (forward): 85 - 2000 rpm, 12 steps Spindle speeds (reverse): 130 - 1300 rpm, 6 steps Feeds: longitudinal and cross Chuck flange: short taper DIN 55027 size 5 Tailstock quill taper: MT 3 Drive power: 2.2 kW Power supply: 400 Volt, 50 Hz - 3-axis digital readout RSF, type Z 730 - Spindle speed adjustable in machining direction via 12 gearbox steps - Spindle speed adjustable in counter direction via 6 gearbox steps - 3-jaw chuck BISON Ø 160 mm with 1 set of stepped jaws - 4-way universal tool post - Coolant tank with pump integrated in machine base - Spindle brake operated via direction lever - Emergency stop via foot pedal and emergency switch - Foldable chuck guard - Machine lamp - Splash guard - Travelling steady rest - Quick-change drill chuck with MT 3 taper - Multiple change gears - Operating manual with electrical diagram Installation dimensions (L x W x H): 2100 x 800 x 1600 mm Weight: 750 kg Good condition Gisdpfx Asvt U Tmsgbsl

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 300 mm, travel distance Z-axis: 700 mm, turning diameter: 140 mm, turning height: 380 mm, turning diameter over bed slide: 250 mm, TECHNICAL DETAILS Turning diameter: 140 mm Swing diameter: 250 mm Turning height: 380 mm Travel paths Travel - X axis: 300 mm Travel - Z axis: 700 mm Spindle Spindle speeds: 1 - 6,000 rpm Drive power 40% duty cycle: 38.00 kW Spindle nose: DIN 55026 - size 6 Spindle bore diameter at front bearing: 110 mm Feed & Rapid Traverse X-axis feed rate: 1 - 30,000 mm/min X-axis rapid traverse: 30.00 m/min X-axis feed force: 9,000 N Z-axis feed rate: 1 - 40,000 mm/min Z-axis rapid traverse: 40.00 m/min Z-axis feed force: 10,000 N Gedpfx Agowyvg Tebeil Tools Number of tools in turret 1: 11 Number of tools in turret 2: 11 Toolholder: VDI 40 MACHINE DETAILS Control: SINUMERIK 840D Total power requirement: 70.00 kW Machine weight: approx. 22.00 t Space requirements: approx. 5.80 x 8.60 x H3.80 m EQUIPMENT Chip conveyor Extraction unit Infeed and outfeed Reversing gripper

Condition: good (used), Code: 0242 Brand: MVM - ITALY Model: T 1500 - CE Standard Professional wood turning lathe with copying device for wood, plaster, composite materials and various - CE Standard Technical data: Single-phase motor 220 Volt - Kw 2,5 Gisdexykwkepfx Agbjl Copying device: the copying device is a unit mounted on the rear bench. It can reproduce weather with wooden samples or with metallic templates thanks to its modern view. It is a practical and manageable tool, it permits large time saving, in batch production or mass production, too. The feed is given by a confortable wheel rotation, the wheel is mounted on the machine fore side Distance between centres mm 1500 Height of centre mm 220 Tool support Spindle revolutions 4 speeds Spindle cone n° 2 Counter centre n° 3 Overall dimensions mm 2350 x 650 x 1200 h Weight kg 325

Condition: new, Year of construction: 2025, Heat output / nominal heat output: 16.5 kW For rooms up to approx. 300 to 400 m³ (according to DIN 4108) Flue pipe outlet: rear side (standard) Giodpfx Aedlmn Hogbel Flue pipe: Ø 180 mm Filling chamber volume: 80 ltr Required chimney draught min. 12 Pa Dimensions of the filling opening (L x W) 300 x 340 mm Weight: 370 kg Efficiency 85,88 Energy efficiency class: A+ The EWI-A 15 space heaters are type-tested according to DIN EN 13240, according to 15a B-VG (Austria) and LRV (Switzerland). They comply with the 1st BImSchV (Federal Immission Control Ordinance) stage 2.

Condition: used, Year of construction: 1998, turning diameter over bed 0400 mm turning diameter over slide rest 260 mm turning length 1000 mm centre height 200 mm centre distance 1000 mm spindle bore 50,8 mm speeds 20- 3150 U/min feeds longitudinal slide 0,01 - 3,24 mm/U Gedsxp Rzbopfx Agbeil feeds cross slide 0,005- 1,62 mm/U weight of the machine ca. 1,8 t dimensions of the machine ca. 2,85 x 1,4 x 1,9 m voltage 400 V connected load 7,7 kVA With chuck, Multifix toolholder and digital readout.

Condition: used, CITIZEN CINCOM R 07 VI is a high-precision CNC automatic lathe (Swiss-type) delivering strong accuracy and reliability. Capacities: 6 axes, 2 spindles; max turning Ø 7 mm, max length 40 mm, spindle bore 12 mm; threading up to Ø4 M, max tapping length 40 mm. Specs: spindle 0–16,000 rpm, 1.1 kW; back spindle up to 10,000 rpm, 0.5 kW; C-axis resolution 1°; supply 3x400 V 50 Hz, total power 4 kVA; weight ~950 kg; footprint 1465×560×1410 mm. Accessories: parts catcher, lamp, bar feeder LNS TRYTON 107, central lubrication, status light. Built to achieve tight tolerances; typical applications include automotive, watchmaking, medical, aerospace, and machine-tool components Gedox S I Dhspfx Agbsil

Condition: excellent (used), Year of construction: 2020, functionality: fully functional, CNC Swiss-type automatic lathe Manufacturer: STAR Model: SX-38 A Year of manufacture: 2020 featuring: FANUC 31i Model B5 control, Synchronous spindle, Driven tools, Y2-axis, Y3-axis, 2x C-axis, X2-axis, X3-axis, B-axis (programmable on linear carrier), Independent backworking (8 stations), Turret, Chip conveyor and chip bin, Parts conveyor belt, Fire extinguishing system, Gedpfx Agsx Sx T Tobeil Oil mist extraction, JBS guide bushing unit, Usable as both long- and short-part turning, High-pressure pump, Bar loader magazine FMB TURBO 5-65

Condition: ready for operation (used), Year of construction: 2015, operating hours: 15,050 h, functionality: fully functional, travel distance X-axis: 660 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 200 mm, spindle speed (max.): 7,500 rpm, turning diameter: 220 mm, turning height: 175 mm, TECHNICAL DETAILS Turning diameter: 220 mm Swing diameter: 270 mm Giedowynigspfx Agbel Turning height: 175 mm Control & axis travel Control: SIEMENS 840 D SL X-axis: 660 mm Y-axis: 300 mm Z-axis: 200 mm Spindle & tool change Max. speed: 7,500 rpm Tool changer: 12-station MACHINE DETAILS Total power requirement: 24 kW Machine weight: approx. 5.2 t Space requirement: approx. 2.5 x 1.6 x 2.3 m

Condition: used, Year of construction: 1999, Technical details: number of spindles: 6 spindle passage: 20 mm Article: cam-controlled multi-spindle automatic lathe Manufacturer: Schütte Type: SF20 S Dnt Yob: 1999 Six-spindle automatic lathe with 6 main spindles max. nominal diameter: D=20mm Spindle drum hirth coupled, CNC cross slide in positions 4, CNC cross slide in positions 5, pick up in position 6, sorting chute, 1x independent feed, thread cutting couplings, workpiece belt, Coolant tank with hinged belt chip conveyor Ruez, Oil/steel operation, PLC Siemens S7, Siemens CNC control, Siemens Simodrive 611, The scope of delivery regarding the tooling equipment could be different like pictures. Interface for: IEMCA PRA bar loading magazine (optional: IEMCA PRA40/31/ built in 1997 rear loader) Giedpfxox Sx Nhs Agbel *

Condition: excellent (used), Year of construction: 2019, CNC Lathe TAKAMAZ XY120PLUS Japan Year of manufacture: 2019 - Control system: Fanuc Oi-TD - Machining hours: 3,600 hours - Functionality: fully operational Axes: - X1 axis (150 mm) - Z1 axis (330 mm) - Y1 axis (+/- 35 mm) - Main turret: 24-tool stations with driven tools - C1 axis Sub-spindle: - X2 axis (150 mm) Gjdpfxjx Sxl Ao Agbsil - Z2 axis (440 mm) - C2 axis - Small turret with 12-tool stations Machining capacity: - Max. turning diameter: Main 170 mm / sub 135 mm - Max. turning length: 330 mm - Bar capacity: Main Ø52 mm / sub Ø20 mm - Spindle speed: up to 5,000 rpm - Sub-spindle speed: up to 5,000 rpm - Automatic parts catcher with parts conveyor belt - Chip conveyor (tube type) - Machine documentation - Driven tool holders: 6 pcs (3/3) - Interface for bar feeder - Dimensions (L x W x H): 2,630 x 1,950 x 1,730 mm - Machine weight: 4,500 kg
