Used Cycle Control for sale (47,352)

Condition: used, Year of construction: 2009, Technical details: turning diameter: 800 mm turning length: 4500 mm control: 840-3 Circulation diameter via slide valve: 510 mm Shift of the planing slide: 410 mm bed width: 480 mm spindle head: DIN 55027 Gr. 11 spindle bore: 106 mm speeds:: 1-1800 1/min Klsdpfx Ajyb R Exjh Nel diameter of quill: 115 mm Inner cone of the quill: MK 6 quill stroke: 225 mm total power requirement: 37/30 kW dimensions of the machine ca.: 6500 x 2500 x 1950 mm weight of the machine ca.: 8000 kg

Condition: used, Year of construction: 2012, Technical details: turning diameter: 1800 mm turning length: 6000 mm control: 840 circulation diameter via slide valve: 1140 mm Shift of the planing slide: 680 mm bed width: 1350 mm spindle head: DIN 55027 Gr. 15 spindle diameter in front bearing: 240 mm spindle bore: 110 mm speeds:: 3,55-710 1/min Klodpfsyapp Hjx Ah Nel diameter of quill: 220 mm quill stroke: 350 mm Maximum torque at the spindle: ca. 21000 Nm feed power Z: 35000 N Feed force X: 25000 N Rapid traverse X: 4 m/min Rapid traverse Z: 4 m/min total power requirement: 55/70 kW dimensions of the machine ca.: ohne Verkleidung 13000x4200x2400 mm weight of the machine ca.: 34000 t

Year of construction: 2001, condition: used, turning diameter 420 mm Klodpfx Ash N D Uneh Njl turning length 1200 mm control Fanuc bore diameter 60 mm

Condition: used, CNC cycle controlled lathe HARRISON type Alpha 400 Plus Machine No. P30180/150 Year of construction 1998 center distance 1250 mm turning diameter over bed 400 mm center height 200 mm Swing diameter over cross slide 245 mm Swing diameter in the bend 585 mm bed width 313 mm face travel (X-axis) 250 mm Tailstock spindle diameter 73 mm Tailstock quill stroke 140 mm Tailstock quill mount MK 5 spindle bore 54 mm Klodoh Hvk Aopfx Ah Nsl spindle head size Camlock D1 size 6 Spindle speed 20-2500 rpm. Spindle speed range (stage 1) 15-275 rpm. Spindle speed range (stage 2) 35-795 rpm. Spindle speed range (level 3) 110-2500 rpm. Feed rate X and Z 0.03 - 0.6 mm/rev. Rapid traverse speed X axis max. 2000 mm/min. Rapid traverse speed Z-axis max. 4000 mm/min. Threading function Metric / Inch / Diametral / Module Spindle drive power 7.5 KW Mains connection 400 Volt, 50 Hz, 23,5 kVA - cycle control Harrison Alpha / GE FANUC - language in French (France) - automatic gear range shifting in 3 steps (15-275, 35-795, 110-2500 rpm.) - electronic handwheels with different transmission ratios (1/10/100) - 3-jaw face spiral lathe chuck FORKARDT Ø 250 mm type CSN, 1 set of soft top jaws - quick-change tool holder MULTIFIX size B with 2 inserts - 1 piece of centering point running with the tool - 1 piece quick-action drill chuck RÖHM, 3-16 mm - hinged lathe chuck guard - hinged working area protection doors - chip tray with coolant device under the machine bed - Switch cabinet fixed to the machine - Interface RS 232 Space requirement L x W x H 2600 x 1450 x 1550 mm weight 1950 kg good condition

Condition: excellent (used), Year of construction: 1996, turning diameter 380 mm turning length 750 mm Klsdpfox U Encex Ah Nol control HEIDENHAIN ManualPlus total power requirement 9 kW weight of the machine ca. 2 t dimensions of the machine ca. 2,4 x 1,7 x 1,7 m

Condition: used, Year of construction: 1988, turning diameter 570 mm Klsdpfx Ahsx U A Uts Nol turning length 2000 mm control ja weight of the machine ca. 3,5 t

Condition: used, Year of construction: 1998, turning length 2000 mm 980507 Kedpow Syb Dsfx Ah Nell x-axis 7000 mm z-axis 10000 mm 65 mm total power requirement 15 kW weight of the machine ca. 3,5 t

Condition: used, Year of construction: 1999, control Heidenhain centre distance 1400 mm weight of the machine ca. 3,6 t Kljdpfsw Syd Sox Ah Nel Handwheel defective

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, Technical details swing over bed 730 mm Kedpfox Uw Dvox Ah Noll centre distance 3000 mm control Heidenhain MANUALplus4110 weight of the machine ca. 6,5 t dimensions of the machine ca. 7400 x 2100 mm Additional information Very well-maintained cycle lathe with only 15652 operating hours. Working area: Center distance 3000 mm Swing diameter over bed 730 mm Swing diameter over cross slide 450 mm Bed width 480 mm Main spindle: Spindle mount according to DIN 55027 size 11 Spindle bore 130 mm Spindle diameter at front bearing 170 mm Spindle taper 1:20 Tap in center sleeve MT 6 Main drive: AC drive with 2-stage ZF gearbox (automatic shifting gearbox) Drive power (100/60% duty cycle) 22/28 kW Total speed range 1 - 2200 rpm Maximum spindle torque: approx. 2200 Nm X-axis (cross slide) performance data: Maximum travel: 400 mm Feed force: 14 kN Speed: 4 m/min Z-axis (bed slide) performance data: Feed force: 18 kN Speed: 7 m/min Max. workpiece weight: Between centers without steady rest: 2000 kg With one steady rest: 2200 kg With two steady rests: 2500 kg In the chuck: 750 kg Tailstock: Quad diameter: 115 mm Quad stroke: 225 mm Quad taper: MK 6 Equipment and accessories: Heidenhain MANUALplus 4110 CNC control SCHUNK ROTASplus 400-102 3-jaw manual chuck 2 steady rests PARAT tool holder Chip conveyor Coolant system Work area enclosure with two sliding doors. Machine length 5700 mm, with swarf converyor 7400 mm Machine width 2100 mm

Condition: reconditioned (used), Year of construction: 2002, Cycle-controlled lathe GILDEMEISTER NEF 320 With MANUAL PLUS 4110 control Year of manufacture: 2002 Spindle bore: 50.8 mm Distance between centers: 750 mm Swing diameter over bed: 320 mm Klsdpsxn Apbofx Ah Nsl Swing diameter over cross slide: 150 mm Center height: 160 mm Speed range: 10 – 4000 rpm, stepless With the following accessories: Sliding guard with internal lighting Multifix tool holder with 2 inserts 3-jaw chuck Schunk ROTA – S plus Ø 200 mm 2 sets of soft top jaws ICP contour programming Tailstock with extendable quill Chip tray Coolant system Chip rinse gun 6 machine feet Operating manual

Condition: reconditioned (used), Year of construction: 1995, CYCLE LATHE WEILER " E 35" With 2 axes Siemens Sinumerik 805 Year of construction: 1995 Ksdpfxsuzyw Do Ah Njll Spindle bore: 54 mm Center distance: 950 mm Rotation O over bed: 410 mm Speed range: 4 - 3000 rpm With the following accessories: PARAT tool holder with 8 pcs. inserts Chuck guard 3 Jaw chuck 0 200 mm 4 jaw chucks 0 200 mm Fixed lynette 12 - 150 mm Chip collection tray Chip guard with lighting Coolant device 4 pcs. Height-adjustable machine shoes Operating instructions

Condition: used, Year of construction: 2008, Working area Circulation dia. above bed slide way cover: 680mm Circulation dia. above cross guide cover: 565 mm Facing traverse: 324 mm Longitudinal path: 600 mm Main spindle Spindle nose dia: 170 h5 / 220 h5 mm Bar dia. Max: 65 / 90 mm Spindle nose dia. in front bearing: 120 / 150 mm Spindle boring: 79 / 110 mm Chuck dia: 200 / 250 / 315 mm Drive rating S1 100% duty cycle: 25 / 33 kW Kledpfx Ajya Iirjh Nel Rotational speed range: 5000 / 4000 r.p.m Max. torque S1 100% duty cycle: 270 / 375 Nm Salient rotational speed: 900 / 850 r.p.m C axis (main spindle) Rotational speed: 250 r.p.m Stopping torque: 200 Nm Division accuracy: 0,025 deg. Compound slide X/Z/Y Facing traverse X: 260 / 1852 mm Longitudinal path Z: 635 / 6202 mm Ball spindle Z (dxh): 40x15 mm Vertical path Y: ±40 mm Ball spindle Y (dxh): 40x5 mm Rapid traverse speed X/Y/Z: 60/15/45 m/min Feed force X/Y/Z: 3,5/7/7 kN Tool holder Number of tool stations: 12 Tool mounting cylinder shaft (DIN 69880): 40 mm Tool disk, axial tool holder pitch circle dia: 370 mm Number of driven tools: 12 Drive rating max. 100% duty cycle: 4,9 kW Torque 100% duty cycle: 10,5 Nm Rotational speed range: 4500 r.p.m Tailstock Tailstock traverse path: 580 mm Tailstock force: 8 kN Tailstock mounting: MT 5 Rapid traverse speed Z2: 6 m/min Part accuracy for positioning: =/< 10 mm Hydraulic Contents: 40 l Pump capacity: 2,2 kW Max. pressure: 80 bar Pressure for clamping unit, tailstock: 10-60 bar Coolant unit Contents: 210 l Pump capacity: 1,7 kW Feed rate at 6 bar: 20 l/min Electrical energy requirement Connected rating: 50 kVA Operating voltage: 400 V Frequency: 50 Hz Fuses (slow blow/VDE 0100) perm: 80 A Voltage fluctuations at 400 V: 6% - 10% Machine dimensions Dimensions (LxWxH) with chip conveyor: 4350/2460/2080 mm Weight without chip conveyor/chip bath: ca. 6.000 kg Workplace based constant noise pressure level: - (DIN 45635 part 1-04.85 (ISO 3740-1980), measured as a chip removing cycle as per DIN 45635 part 1601-07.78): 77 db (A) - in idle running as per DIN 45635 part 1601-07.78: 78 db (A)

Condition: ready for operation (used), Year of construction: 1996, Immediately available ex location: VDF Boehringer Cycle Lathe Type DUS 800 Year of manufacture: 1996 Control: Sinumerik 805 Swing over bed: 820 mm Swing over cross slide: 520 mm Turning length: 6000 mm Spindle bore: 128 mm Drive: 46 kW Tailstock: MK 6 Quill diameter: 125 mm Quill stroke: 280 mm Spindle speeds: 8 – 1600 rpm Feed X-axis: 20 – 5000 mm/min Feed Z-axis: up to 10,000 mm/min Parat tool holder Klodpsyayf Eefx Ah Nsl Chuck: 400 mm Face plate: 600 mm Steadies: 250 – 500 mm Chip conveyor Weight: 12 t Price: EUR 26,500.— plus VAT, ex location

Condition: new, Year of construction: 2025, functionality: fully functional, machine/vehicle number: 2311151630, turning diameter over cross slide: 650 mm, spindle bore: 153 mm, turning length: 3,150 mm, turning diameter: 650 mm, turning diameter over bed slide: 650 mm, turning diameter over top slide: 410 mm, quill stroke: 150 mm, quill diameter: 100 mm, rapid traverse X-axis: 13 m/min, rapid traverse Z-axis: 13 m/min, spindle speed (min.): 30 rpm, spindle speed (max.): 1,600 rpm, center height over cross slide: 410 mm, feed length X-axis: 330 mm, feed length Z-axis: 3,150 mm, feed rate X-axis: 2 m/min, feed rate Z-axis: 13 m/min, total length: 6,261 mm, total width: 3,588 mm, total height: 2,375 mm, type of input current: three-phase, spindle motor power: 18,000 W, overall weight: 5,200 kg, rotational speed (min.): 30 rpm, rotational speed (max.): 1,600 rpm, torque: 1,050 Nm, controller manufacturer: Milltronics, controller model: 9000 DGI, input voltage: 230 V, drill spindle diameter: 153 mm, nominal power (apparent): 21 kVA, number of spindles: 1, spindle nose: A2-11, tailstock quill diameter: 100 mm, tailstock quill mount: MK 5, tailstock quill stroke: 150 mm, number of slots in tool magazine: 8, Equipment: rotational speed infinitely variable, LIST PRICE of the machine: EUR 149,500.00!!!!! The machine is new and immediately available. Subject to prior sale. Including hinged belt chip conveyor. Delivery of the machine in export packaging ex our warehouse. (Shipping costs to be borne by the buyer) Operating fluids to be supplied by the buyer. Commissioning and training by Milltronics possible. Leasing available (subject to credit approval) Machine details: • CNC control Milltronics 9000-DGI • 15" LCD color touchscreen • Ethernet interface • USB interface • Productivity software, DSA, MSV, bidirectional turning cycle, 9000-DGI Desktop • Connection for external keyboard • Electronic handwheels for manual operation, teaching, or automated processes • Custom macros available • Override potentiometer for axes and spindle • Spindle load monitoring • Key switch to lock the EDIT function • Indicator lights for operating status • Additional "M" function with CNC dwell channel • Constant cutting speed • Rigid tapping • Spindle speed 30 - 1600 rpm • Spindle motor 18 / 11 kW, 2-speed electronic gearbox • Spindle nose type A1-11 • Tool turret with 8 stations, 25 mm Kledpfxex Akm Rj Ah Njl • One axial tool holder for standard tools 25 mm x 25 mm • One boring bar holder 38 mm • Automatic lubrication system • Full enclosure with sliding doors • Coolant system with pump • CE certification • Instruction manual, spare parts list, and wiring diagrams in digital format • Operation and maintenance manuals in digital format • Transformer for standard industrial power, 400 volts, 3-phase • Lifting brackets for craning the machine Optional accessories: Manual 3-jaw chuck 300 mm Hydraulic tailstock quill (only in conjunction with hydraulic chuck) Hydraulic 3-jaw chuck with hydraulic power unit (diameter 300 mm – bore 70 mm) Fixed steady rest with rollers, range 20 – 200 mm Fixed steady rest with rollers, range 180 – 410 mm Follow steady rest with brass supports, range 20 mm – 200 mm 38 mm boring bar holder for turret 25 mm axial tool holder Hinged belt chip conveyor instead of drawers Programming manual in paper format Machine manual in paper format Floor mat with Milltronics logo

Condition: used, Year of construction: 2008, weight of the machine ca. 8,8 t dimensions of the machine ca. 4500x1990x2300 mm Number of controlled spindles (C axes): 2 Number of controlled axes: 8 Number of channels: 3 Max. bar diameter: 65 mm Bore in tie rod: 75 mm Chuck diameter: 175 mm Spindle nose: 140 mm Max. speed: 5,000 rpm Nominal torque: 191 Nm Nominal power: 20 kW Kodeyat Hvspfx Ah Njll DATA FOR THE W2 AXIS OF THE COUNTER SPINDLE Stroke: 690 mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 2,400 N X1 AXIS DATA Stroke: 165 mm Rapid traverse: 40 m/min Max. acceleration: 10 m/s² Nominal force: 2,400 N Z1 AXIS DATA Stroke: 678 mm Rapid traverse: 30 mm Max. acceleration: 5 m/s² Nominal force: 5,000 N Y1 AXIS DATA Stroke: 80(+50/-30) mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 5,000 N X2 AXIS DATA Stroke: 165 mm Rapid traverse: 30 m/min Max. acceleration: 5 m/s² Nominal force: 5,000 N Number of tool stations: 12 Tool holder diameter: 30 mm Driven stations: 12 mm Max. speed of driven tools: 4,000 rpm Translated with (free version)

Condition: good (used), Year of construction: 1996, functionality: fully functional, turning diameter over cross slide: 200 mm, spindle bore: 54 mm, turning diameter: 410 mm, center width: 950 mm, center height: 200 mm, spindle speed (max.): 3,000 rpm, overall weight: 2,100 kg, Equipment: documentation/manual, Dear Sir or Madam, We offer for sale a WEILER E35 CNC cycle lathe. The Siemens 805 cycle control and electronic handwheels make operation very simple and extremely convenient. The machine has been thoroughly inspected in our workshop, is in fully functional condition, and is available for a power-on test at any time. We look forward to your inquiry! Our service promise to you: - We are a certified master workshop specializing in mechanical engineering - All machines are thoroughly checked Kodpfx Asyaluljh Nell - All lubricants and, where necessary, worn components are replaced in advance - On request, we can completely or partially overhaul the selected machine for you - You can freely choose the paint color of your selected machine - Additional accessories such as tools can be ordered directly if required - On request, we can install further accessories such as safety devices - We are happy to take care of shipping and/or installation for you

Condition: as good as new (ex-display), Year of construction: 2025, Machine is in the exhibition and was only used for demonstration purposes. Optiturn L44 CNC Premium CNC lathe direct from the manufacturer. L44 CNC - The OPTIMUM Premium CNC milling machine with Siemens SINUMERIK 828D control is characterized by performance, speed, precision and long service life. Dimensions and weights Width/depth max. 2300 mm Length approx. 2530 mm Width/depth approx. 1595 mm Height approx. 1795 mm Weight approx. 2600 kg Working areas Lathe chuck diameter 150 mm Lathe chuck Hydraulic control of the clamping movement Center height 223 mm Center width 850 mm Swing diameter over machine bed 446 mm Swing diameter in the bed bridge 520 mm Swing diameter over cross slide 240 mm Bed width 300 mm Motor torque X-axis 6 Nm Z-axis 8.5 Nm Speed range Number of speed ranges 1 Speed range 10 - 3000 min¯¹ Electrical data Drive motor power 7 kW Supply voltage 400 V Mains frequency 50 Hz Electrical connection Total connected load 23 kVA Accuracy Repeat accuracy ± 0.005 mm Positioning accuracy ± 0.005 mm Hydraulic system Motor output 0.75 kW Tank capacity 50 l Coolant system Coolant pump output 270 W Tank capacity 90 l Machine data Chuck opening diameter 40 mm Motor(s) Torque drive motor 33 Nm Tailstock Mounting MK 4 Quill stroke 165 mm Quill diameter 52 mm Spindle Spindle holder DIN ISO 702-1 No. 5 Spindle bore/bar passage diameter 52 mm Control system Type Sinumerik 828D PPU 240 System software SW 24 CNC memory 3 MB Look Ahead 50 Block change time 3 ms Number of tools 128 Travel distance X-axis 250 mm Z-axis 760 mm Vertical spindle Power drive motor continuous operation S1 7 kW Power drive motor S6-30 % operation 16 kW Drive motor torque 33 Nm Drive motor S6-30 % operation 80 Nm Feed rate Speed X-axis 15000 mm/min Z-axis 15000 mm/min Feed force Feed force X-axis 7.5 kN Feed force Z-axis 5.3 kN Ksdpfx Ahew Ea Tus Nsll Tool changer Hydraulic type; VDI 30 Number of tool positions 8 pcs Mounting height, width square max. 20 x 20 mm Boring bar mounting diameter max. 25 mm SIEMENS SAFETY INTEGRATED Equipment Main spindle - Solid design Machine bed - Heavily ribbed - High rigidity and durability Guideways - Stable flat bed guide Recirculating ball screw - For high rapid traverse speeds in all axes - Less wear and tear - For high positioning and repeat accuracy Cast body - Hardened HRC48-52 and heat-treated Machine feet - Six pieces - Optimum alignment of the machine Heat exchanger - Closed switch cabinet with intelligent cooling management - Optimum temperature even at high outside temperatures Tool changing system - Eight tool stations - Hydraulic VDI30 tool changer - Pick-up height max. 20 mm Hydraulic unit - Motor power 750 W - Tank capacity 50 liters - Clamping pressure / operating pressure 2,500 - 2,942 kPa Three-jaw chuck - Hydraulic three-jaw lathe chuck Ø 150 mm - Hydraulic loosening and clamping via foot switch - Simple clamping of workpieces - Hard and soft block jaws Central lubrication system - Automatic supply at intervals - Reduces wear on bearings, ledges and ball screws - With float switch. An acoustic signal sounds if the oil level is too low

Condition: used, Year of construction: 1998, Technical details: turning diameter over bed: 600 mm turning diameter over support: 400 mm turning length: 2000 mm center height over support: 300 mm centre distance: 1600 mm revolution per minute: 3 - 2.500 U/min tailstock taper MT: MK 5 spindle bore of work spindle: 62 mm quill stroke: 190 mm longitudinal feeds:: ca.0,001-10 einstellbar mm/U cross feed: ca. 0,001-5 einstellbar mm/U Rapid feed X axis: bis zu 5000 m/min. total power requirement: 40 KVA weight of the machine ca.: 5,6 t dimension machine xH: 4,0 x 2,0 x 1,9 m incl. accessories see picture * Klsdjw Rkt Ijpfx Ah Njl

Condition: excellent (used), Year of construction: 2006, turning diameter 330 mm turning length 750 mm control WEILER D3 dia. of quill 50 mm Kodpox Szpwofx Ah Noll quill stroke 130 mm taper in tailstock-quill MK-3 spindle turning speed range 1-4500 U/min taper in main spindle MK-5 weight of the machine ca. 1400 kg dimensions of the machine ca. 1900 x 1300 x 1800 mm This WEILER E30x750 is in very good condition and can be viewed by arrangement with the seller. - Lever quick-release chuck for pressure collets DIN 6343-48/173E and Rubber-Flex collets, clamping range 3-42 mm diameter, with mechanical and electrical locking, max. speed 4500 rpm. - 1 set of pressure collets DIN 6343-48 / 173E - Adjustable hollow spindle stop 38-48 mm for main spindle - Live steady with sliding jaws, passage 10-85 mm - Three-jaw chuck with wedge bar system, diameter 160 mm, bore 42 mm, with mounting according to DIN 55027 /5, with 1 set of basic jaws and hard reversible attachment jaws - Lever quick-action chuck for pressure collets DIN 6343-48/173E and Rubber-Flex collets, clamping range 3-42 mm diameter, with mechanical and electrical locking, max. speed 4500 rpm. - 1 set of pressure collets DIN 6343-48 / 173E - Adjustable hollow spindle stop 38-48 mm for main spindle Translated with (free version)

Condition: good (used), Year of construction: 1999, Ref. -No.: 10365 Manufacturer: MONFORTS Type: KNC 8 S - 3000 Year of construction: 1999 Type of control: CNC Control: MTC K Storage location: Halberstadt Country of origin: Deutschland Machine-No.: 178.05 X stroke: 455 mm Z - stroke: 2850 mm Chuck diameter: 315/400/500 mm Centre Distance: 3000 mm Feed Capacity - Z: 23,9 kN Feed Capacity - X: 11,3 kN Rapid Travel Speed X-Axis: 6,8 m / min Rapid Travel Speed Z-Axis: 4 m / min Circumferential diameter over radial slide: 540 mm Max swing diameter: 830 mm travel of the cross slide: 450 mm Spindle head max. passage for violent material: 88 mm Spindle head max. passage for bare material: 90 mm Tailstock outside diameter of the quill: 125 mm Tailstock maximum quill stroke: 200 mm Tailstock inner cone: MK6 Type hydraulic tank: 15 L. coolant reservoir: 220 L. Coolant tank at chip conveyor: 160 L. Kodpfox Sw Dwox Ah Njll Machine length: 5200 mm Machine width: 2110 mm Machine Height: 1995 mm Weight Of The Machine Ca.: 6,850 (Ohne Späneförderer und Kühlmittelbehäter) t Headstock Spindle Head: DIN 55027 - 11x290 Further information: Additional lubricating oil tank approx. 6l incl. tools Machine is under power and can be inspected by arrangement.

Condition: used, Year of construction: 2010, Technical details: turning diameter: 1000 / 700 mm turning length: 3000 mm face slide travel: 600 mm turning diameter over slide: 700 mm turning speeds: 1-1.800 1/min transmission ratio: 2 spindle: 46 (60%) kW spindle bore: 132 mm quill stroke: 280 mm workpiece weight max.: 2.560 kg Klodpfx Ahsr U Skhj Nel total power requirement: 38 kW weight of the machine ca.: 6 t dimensions of the machine ca.: 5 x 2,6 x 1,9 m teach in lathe, PARAT tooling system, SCHUNK ROTA NC 500-160 power chuck, tailstock, chipconveyor *

Condition: used, Year of construction: 2007, operating hours: 41,000 h, spindle bore: 165 mm, turning length: 3,000 mm, turning diameter: 830 mm, turning diameter over bed slide: 1,200 mm, quill stroke: 400 mm, quill diameter: 140 mm, torque: 8,000 Nm, Technical Specifications ----- Max. turning length: 3,000 mm Turning diameter: 830 mm Max. turning diameter over bed: 1,200 mm Bed width: 600 mm Spindle bore: 165 mm Spindle head DIN 55027 Gr 15 Chuck: Forkardt 3KS 800 mm Speed range: 1 - 280 / 4 - 900 rpm Gear ratios: 2 Torque: 8,000 Nm Number of turrets: 1 Sauter 4-station head turret for 140 mm chucks Tailstock Quill diameter: 140 mm Quill stroke: 400 Features ----- Electronic handwheel Forkardt 3KS 800 mm hydraulic power chuck Ksdpfxsv Nhxzj Ah Njll Chip conveyor

Condition: used, Year of construction: 2008, turning diameter 560 mm turning length 2000 mm Klodeviyh Uspfx Ah Nsl control FANUC Series oi-TC CNC spindle turning speed range 2200 U/min spindle bore 82 mm tailstock quill taper MT 5 quill stroke 150 mm total power requirement 7,5 kW weight of the machine ca. 3800 kg dimensions of the machine ca. 3800 x 1750 x 1600 mm

Condition: excellent (used), Year of construction: 1986, Heavy-duty lathe, cycle-controlled lathe, lathe, center- and feed-screw lathe, center- and feed-screw lathe, CNC lathe -Control: Monforts Control System MTC K -Machine bed: hardened -Turning length: 1100 mm -Turning Ø over bed: 560 mm Kledpfxew E Nkij Ah Njl -Turning Ø over support: 300 mm -Spindle bore: Ø 60 mm -Spindle speeds: 2 - 2800 rpm -Key bar chuck: Schunk Ø 250 mm -Tailstock mount: MK5 -Drive: 16 kW -Accessories: Multifix tool holder, tools see photos -Dimensions: 1600/2860/H1830 mm -Weight: 3300 kg

Condition: used, Year of construction: 2004, Technical details: turning diameter over bed: 850 mm turning dia. over face-slide: 580 mm turning length: 4000 mm centre distance: 4000 mm faceplate diameter: 800 mm control: Siemens 810D revolution per minute: 1 - 1600 / 2 step U/min max. torque on the spindle: 6000 Nm feed motor: X= plan + Z= längs: 16000 / 20000 N rapid motion - x-axis: 4 m/min rapid motion - y-axis: 7 m/min spindle passage: 130 (Spindelkopf DIN 55027 Gr. 11) mm operating hours - idle run: werden noch ausgelesen h tailstock taper ISO: MK 6 tailstock quill stroke: 350 mm max. workpiece weight between centers: 5000 kg max. workpiece weight -without tailstock: 1800 kg interface: RS 232 / V24 voltage: 400 V / 50Hz V control voltage: 24 V Gleichstrom V total power requirement: ca. 52 kW Weight approx.: 14,0 t dimension machine xH: 2,6 x 9,1 x 2,5 m Cycle lathe with Siemens cycle control Motor: 37kW, rated speed 1500 rpm; max. speed 6500 rpm; torque 235 Nm Two gear shift stages Stage II: Spindle torque 258.9 to 1364.6 Nm Stage I: Spindle torque 1050.4 - 5536.1 Nm Feed drive Three-phase servo drive 2x chip conveyor Double E-cabinet Quick-change steel holder parat Coolant device incl. various accessories see photo, as well as steady rest and 3-jaw chuck Ø 500mm Rota-S plus Klsdju Ix Izepfx Ah Nel *
