Used Threading Machine for sale (65,001)

Condition: used, Year of construction: 1989, machine/vehicle number: 921, overall weight: 3,500 kg, type of input current: three-phase, ORT Italia RP20 hydraulic rolling machine for creating threads, knurls, and profiles through cold forming. Manufacturer: ORT Italia Model: RP20 Serial number: 921 Year: 1989 Number of rollers: 2 Maximum rolling force: 20 tons Maximum workpiece diameter: 60 mm Chedpfx Age Afaa Nerjd Spindle speeds: 25, 40, 55, 65, 85, 105, 135 and 220 rpm Power supply: 380 V three-phase, 50 Hz Control: hydraulic / electromechanical Machine complete as shown in the photographs. Inspection possible at our warehouse. Loading onto the transport vehicle is the seller’s responsibility. Transportation is the buyer’s responsibility.

Condition: ready for operation (used), Year of construction: 1989, operating hours: 2,100 h, functionality: fully functional, thread length: 880 mm, feed length X-axis: 1,000 mm, feed length Z-axis: 100 mm, feed rate X-axis: 1 m/min, feed rate Y-axis: 5 m/min, position of the milling head: Horizontal, swivelling, center height: 1,060 mm, type of input current: AC, power of feed motor: 4,000 W, milling spindle length: 200 mm, spindle bore: 90 mm, spindle speed (max.): 400 rpm, spindle speed (min.): 25 rpm, mandrel length: 200 mm, collet bore: 90 mm, clamping length: 880 mm, workpiece diameter (max.): 500 mm, Thread Milling and Gear Hobbing Machine MSZ 5A352ПФ2 The MSZ model 5A352ПФ2 is a universal thread milling and gear hobbing machine, designed for machining splines, worms, and cylindrical gears by milling and hobbing processes. Manufactured in 1984, the machine is intended for industrial applications requiring reliable performance, versatility, and repeatable accuracy. The machine is suitable for workpieces with a maximum length of 1000 mm and a maximum diameter of 500 mm. The maximum machining (spline/thread) length is 880 mm, and the machine supports gear cutting up to module 8, covering a wide range of thread and gear machining tasks. Helix and thread angles up to 30° can be machined, allowing flexible use in mechanical engineering and transmission manufacturing. The milling and hobbing spindle features a 90 mm spindle bore and supports cutting tools with a maximum hob diameter of 160 mm and a maximum hob length of 200 mm. The spindle operates in a speed range of 25 to 400 rpm, providing suitable cutting conditions for different materials and tool diameters. The main drive motor offers multiple power and speed stages (5 / 6.3 / 10 kW at 750 / 1000 / 1500 rpm). The machine is equipped with stepless longitudinal and radial feeds, with longitudinal feed rates from 2 to 100 mm/min and radial feed rates from 2 to 50 mm/min, enabling precise control during machining operations. The milling head is horizontal and swivelling, and the machine allows accurate synchronization for thread milling and gear hobbing operations. With overall dimensions of approximately 3100 × 2270 × 2100 mm (up to 3540 × 2515 × 2100 mm with auxiliary equipment) and a total weight of about 7890–8500 kg, the 5A352ПФ2 features a rigid, heavy-duty construction that ensures excellent stability and vibration damping. The machine operates on three-phase AC power (380 V, 50 Hz) and is equipped with a PU F5007 control system. Condition: *Used machine *Ready for operation *Fully functional *Operating hours: approx. 2,100 h Scope of delivery: *Complete set of change gears Cedpfx Aox Unpvsgrshd *Technical passport (Russian) *Operating manual (Russian) Typical applications: *Thread milling *Gear hobbing (spur gears, worms) *Machining of transmission components *General mechanical engineering *Repair and small- to medium-series production

Condition: excellent (used), Year of construction: 1983, TOYOSK 01CC-T 36-spindle Thread cutting machine with fixed spindle and Manufacturer: TOYOSK Chjdpfx Aswh Sh Nogrod Type: 01CC-T Year of manufacture: 1983 Number of spindles: 36 Three-speed gearbox: 520rpm, 850rpm, 1330rpm Application: Simultaneous drilling of multiple holes in precise, mass production tasks (e.g. automotive parts, sheet metal, castings)

Condition: used, Thread Rolling Machine, Cold Rolling Machine, Thread Rolling Machine, Profile Rolling Machine Manufacturer: PEE-WEE Model: UPW 24 Serial No.: P07 Year of manufacture: 2007 Maximum rolling force: 24 tons Maximum tool diameter: 270 mm Roll spindle diameter: 69.85 mm Tool bore diameter: 70 mm (nominal diameter) Maximum tool/reception length: 180 mm Maximum workpiece diameter: 50 mm Hydraulic motor power: 3 kW Roll drive motor power: approx. 5.5 kW Electrical connection: 400 Volt, 50 Hz, 10 kW - Pivotable roll spindle for through-feed thread rolling - Roll spindle speed adjustable in 4 steps via gearbox shift - Hydraulic unit integrated in the machine base - Operating manual with electrical schematic Space requirements (L x W x H): 2,000 x 1,450 x 1,900 mm Weight: approx. 3 tons Very good condition Plunge Rolling: The thread rolling tools, having the same pitch as the workpiece, form the thread by penetrating the workpiece up to the nominal diameter. The maximum thread length is limited to the width of the rolling dies. Through-feed Rolling: Used when the thread length is greater than the width of the rolling dies. Through-feed tools are divided into three sections – entry, calibration, and exit. Knurling rolls have no pitch and are swiveled at the lead angle corresponding to that of the profile to be rolled. Cjdpfx Aouz If Njgrohd Lead angle rolls differ from knurling rolls by having a pitch in the profile. The sum of the lead angle and swivel angle results in the effective lead angle in the workpiece.

Condition: good (used), functionality: fully functional, GWR 80 thread rolling machine. Chodpo Ahmvijfx Agred

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, machine/vehicle number: NT2012, ESCOFIER MACHINE, EXCELLENT CONDITION, VERY LITTLE USED. 12-TON MACHINE. POSSIBILITY TO SEE IT OPERATING IN OUR WORKSHOP. Csdpfjycq Ebox Agrohd

Year of construction: 2011, condition: used, 32 mm direkt 1:1,25 angle adjustable from - to -20/ +20 Grad weight 17,0 kg dimensions 180 x 120 x 260 mm mm Threaded swivel apparatus with two driven toolholders in well condition. For Maier swiss lathe - Price of a new one: 16.100,-- € - prepared for two driven toolholders straight 2-020-W10-1001 (not included) - Angle-adjustable threaded swivel head Chedpfxowa Uf Ue Agrjd

Condition: excellent (used), REMS TORNADO 2010 THREADING MACHINE Product description: - Reliable, highly efficient machine for threading, cutting, deburring, thread rolling, and facing - For installation work, locksmith shops, and production facilities - Robust, compact, and adaptable design suitable for construction sites and workshops - Operating principle: rotating workpiece – stationary tool - Automatic features: clamping chuck, universal threading head, lubrication, and cooling - Large work area and chip collection container - Adjustable workpiece support - Extremely powerful and fast drive, e.g., threads a 2" pipe in just 15 seconds - Gearbox is completely maintenance-free and operates in an enclosed oil bath - Two base options: - Portable version on 3 legs, with a detachable, large oil bath and chip container - T-shaped base with an integrated, larger oil bath and chip container, for placement on a table. Fixed base or mobile trolley with a storage area for workpieces, for easy transport, at an optimal working height, stable design, available as optional extra - Three high-performance motors to choose from: - High-efficiency universal motor, 1700 W, overload protection, rotational speed 53 rpm. - Capacitor motor, 2100 W, overload protection. Two rotational speeds: 52 and 26 rpm, even under full load. Very quiet operation. - Three-phase motor, 2000 W, overload protection. Two rotational speeds: 52 and 26 rpm, even under Chedpfxoz Sk Imj Agrod full load. Very quiet operation. - Convenient-to-use, two-stage foot switch with an emergency stop button, allowing the operator to lean fully on the machine during operation - Two automatic clamping chucks with self-centering jaws. Quickly and easily clamps and releases the workpiece - Self-tightening chucks provide maximum clamping force - Powerful, reliable pump with high flow rate - Optimal, multi-directional guidance of the threading tool through the threading head ensures precise threading in the correct location, guaranteeing clean threads and long service life for the threading dies, gearbox, and motor - Only one automatic universal head for all threads, including long threads; automatically opening - with automatic thread length control for tapered threads - Fast, easy adjustment of thread size - Clear thread scale - Easy and quick replacement of threading dies thanks to their positioning in the clamping part - Reliable, durable, high-quality REMS threading dies with optimal geometry, guaranteeing very easy entry into the material, light threading, and clean threads. Made of high-strength, specially hardened steel, ensuring an exceptionally long service life. - Self-centering pipe cutter. Stable bow made of forged steel. Ergonomic, wide handle for firm pressure on the spindle - Specially hardened cutting wheel made of reliable, tough-hard tool steel ensures a long service life. - Internal deburring tool. Stable, easy-to-use deburring tool with adjustable deburring position. - Specially hardened and processed blade guarantees light deburring and exceptionally long service life - Two blades for optimal burr removal, especially for small pipe diameters.

Condition: used, Year of construction: 1979, workpiece diameter 320 mm Chedet Hwnpjpfx Agrsd threading length 300 mm thread pitch mm total power requirement 90 kW weight of the machine ca. 12000 kg dimensions of the machine ca. m Thread and worm grinder for steering worms

Condition: used, The REMS Magnum pipe threader is suitable for pipes from 1/4" to 2". The following threading dies are included: - 3x: R1/2 - 3/4 - 5x: R1 - 2 The unit has been function-tested and comes with an electrical inspection carried out by a professional electrical company. Chodpfx Agoz Nlfgjrod

Condition: used, Year of construction: 2013, pressure 20 - 600 kN adjustment of rolling slide 2 x 90 mm diameter of rolling spindle 120 mm roll spindle height over machine bed 200 mm Control SIN 840 D taper length of the roll spindle 200 mm rolling spindle turning speeds 0 - 34 1/min torque per rolling spindle 6.160 Nm power capacity 2 x 8,4 kW distance between rolling spindles min. 271 / max. 368 mm Cedpj Afar Esfx Agrohd rolling tool outer diameter max. 300 mm total power requirement 26 kW weight of the machine ca. 7,1 t dimensions of the machine ca. 9,70 x 4,50 x 3,80 m CNC machine for gear cold rolling / thread rolling Felsomat loader cell Complete housing

Condition: excellent (used), Year of construction: 2004, LEISTRITZ RT 400-CCA Thread Rolling Machine Manufacturer: Leistritz Thommen GmbH, Switzerland Model: RT 400-CCA Machine Type:Thread Rolling Machine Year of Manufacture: 2004 Serial Number:1028 Country of Manufacture: Switzerland Technical Specifications Rolling Capacity - Maximum rolling force: 40 tons - Minimum shaft length: 125 mm - Maximum shaft length: 275 mm Rolling Die Dimensions For Ø69.85 mm tooling: - Minimum rolling die diameter: 176–178 mm - Maximum rolling die diameter: 215 mm For Ø80 mm tooling: - Minimum rolling die diameter: 176 mm - Maximum rolling die diameter: 210 mm Electrical Specifications - Power supply: 3 × 400 V - Frequency: 50 Hz - Rated power: 65 kW Chsdpfx Agez Rzx Ssrod - Main fuse: 125 A - Control voltage: 24 V DC - Spindle power: 22 / 20.5 kW Hydraulic and Pneumatic System - Hydraulic operating pressure: 270 bar - Compressed air pressure: 6 bar - Hydraulic unit manufacturer: CYMAX AG, Switzerland - Hydraulic unit type: IHS240-DD10-IT75/55+18/270-9.2-A783.1 - Hydraulic oil tank capacity: 240 liters - Hydraulic reservoir capacity (auxiliary): 60 liters - Hydraulic pump flow rates: 75 / 18 / 40 l/min Machine Dimensions and Weight - Approximate dimensions (L × W × H): 3,400 × 2,900 × 2,200 mm - Machine weight: 4,900 kg Equipment - Two-spindle thread rolling arrangement - Hydraulic rolling system - CYMAX hydraulic power unit - Coolant and filtration system - Additional spindle pair for Ø69.85 mm and Ø80 mm tooling (subject to confirmation) Control - PLC control system - Control system retrofit reported in 2019 (subject to confirmation)

Condition: new, Bernardo TM 36 BLO/ R 1200 Electric threading machine Csdpfx Agopag R Rerohd Technical specifications Threaded holes* M5 - M36 Tool holder GT 24 Speed max. 30 - 150 rpm Adjustable angle 0° - 90 Max. Working radius R 1200 mm Quick-change chuck DIN 376: M5-6 / M8 / M10 / M12 / M14 M16 / M18 / M20 / M22-24 / M27 / M30 / M33 / M36 Motor power 1200 W Voltage 230 V Weight approx. 35 kg * Material strength 400 N / mm2 Scope of delivery Operation via touchscreen Digital drilling depth display Micro spray system Blow-out device Quick-change holder Quick-change chuck according to DIN Electric motor 90° angle adjustment Mounting flange features With micro-spray system as standard for constant cooling and minimum cooling lubricant consumption Includes blow-out device for removing chips, providing an optimum view of the drill hole Includes quick-change chuck for using taps for through holes and blind holes Swivel motor unit for tapping at any desired angle between 0° and 90 Higher accuracy compared to manual tapping, thread is guaranteed to be at right angles (90°) High productivity, significant time savings compared to manual tapping Quick-change chuck with integrated slip clutch prevents the tap from breaking Includes swivel arm with large radius for easy positioning of the tap on the workpiece For tapping in steel, stainless steel, aluminum and non-ferrous metals Price: Base frame 900 x 600 mm with 2 drawers for TM series 830.00 € plus 19% VAT

Condition: used, Year of construction: 2000, functionality: fully functional, machine/vehicle number: 308, Technical characteristics: ⚙️ Core Specifications Attribute Value Thread Diameter Range: 3 mm to 75 mm Rolling Pressure: 0.5 to 20 tons Max Thread Length (Plunge): 160 mm Max Thread Length (Through): 2000 mm Speed Range: 24 to 114 rpm (8-step gearbox) Cjdpfx Ajxx Nuxogrohd Tool Diameter: 145 mm to 200 mm Roll Spindle Diameter: 54 mm Shaft Distance: 130 mm to 200 mm Machine Dimensions (L×W×H): 1880 (INCLUDING HYDRAULIC UNIT) × 991 × 1270 mm Weight: ~1.6 tons 🧰 Features & Capabilities Variable Rolling Pressure: Adjustable to suit different materials and thread profiles. Heavy-Duty Construction: Built for long-term industrial use with high repeatability. Manual or Semi-Automatic Operation: Depending on configuration and accessories. Machine status: WORKING

Condition: used, REISHAUER US is a Thread grinding machine of high precision, engineered for superior accuracy and reliability. Capacities: grinding length 450 mm; clamping 1055 mm; max Ø 250 mm; thread Ø 2–250 mm; spindle bore 45 mm; weight on centres 200 kg; pitch ≤100 mm; angles ±40°; module ≤10; wheels Ø280–350 mm, width 4–40 mm. Specs: wheel speeds 6 steps 1700–2540 rpm; work spindle 27 steps up to 160 rpm; 3×380 V 50 Hz; grinding spindle 4 kW; total 15 kVA; machine ≈4700 kg; footprint 3300×1930×1800 mm. Accessories: coolant, wheel set, flanges, gear set, centers, oil-mist extractor. Achieves tight tolerances; suitable for automotive, aerospace, watchmaking, machine tools, medical. Chedpfez Dbh Esx Agrjd

Condition: used, Year of construction: 2012, functionality: fully functional, machine/vehicle number: 0049, overall weight: 12,000 kg, Manufacturer: Profiroll Type: UWRA 160S Chsdpfx Agoz Tznrjrjd Control system: Siemens Machine type: Ring rolling machine Pressing force: 63 t Max. outer diameter of round parts: 160 mm Dimensions: 80 mm Roller bore: 30/100

Condition: good (used), Thread diameter: 22 mm Thread length: 30 mm throat: 300 mm Max. working height: 1100 mm Hole table: 360 x 500 mm Drilling depth max.: approx. 500 mm Distance between drill bits: 130 mm Cjdpoi Nnutefx Agrehd Power requirement: approx. 1.0 kW Nominal current consumption: 6 A Machine weight approx.: 1.4 t Machine dimensions approx.: 1.3 x 0.68 x 2.85 m Control unit: conventional Unique table for double-headed drilling with 4 material clamps. Size: 375x250 mm The lateral movement of the table is 150 mm

Year of construction: 1995, condition: good (used), 2 Die Thread Rolling machine SENY, Type D-44 EH, Versatile for all types of work, manual and automatic cycles, easily adapted to automating loading,range of cycle times and roll speeds.operating pressure 100Kn, workpiwcw min 3mm max 40mm,lead 3,5 max, pitch of serrations 1,75mm max, roll length 80mm, diameter roll min 80mm max 120mm,roll spindle speeds 47-94, roll spindle diameter 40mm,distance between rolling spindles 80mm minim 165mm max, working stroke 7, feed 0,5mm/s minim 6mm/s maxim, rolling time,variable 0,1-100 seg, swivelling roll spindles +-5º,main motor 3Kw, connected electrical load 4,68kw, tank capacity 150L,aprox weigth 1100kg Codopwbvkjpfx Agrjhd

Condition: used, Year of construction: 1976, functionality: fully functional, machine/vehicle number: M14L/8736, Offer Number: M14L/8736 Chodpfx Aswi Tmvsgred Machinetype: thread rolling machine - flat die Info: vibratory feeder Make: HILGELAND / ZOM Type: TR4L Constr. year: 1976 diameter range: 6-12 mm shaft length under head: 170 mm max. thread length: 102 mm output pieces/min: 125 Location: In our warehouse

Condition: good (used), Thread cutting machine, pipe thread cutter -Manufacturer: Ridgid, thread cutting machine type 535 -Pipe size: 1/8 to 2 inches -Spindle bore: Ø 64 mm Cedpfxewub Eke Agrehd -Operating voltage: 230 volts -Dimensions: 1080/700/H1140 mm -Weight: 128 kg

Condition: good (used), Year of construction: 2019, machine/vehicle number: 6284, Offer 24033 Technical data: - Tapping capacity M 3 - M 24 - Working range (swivel radius) 1800 mm - Infinitely variable speed adjustment up to 475 rpm Chsdort Unwopfx Agred - Digital depth adjustment - Torque 140 Nm - Quick-change tool holder size 2 diam.31 - various inserts for quick-change tool holder - Table surface 1200 x 990 mm - Table height 830 mm - Space requirement approx. W 1250 x H 2000 x D 1000 mm - Weight approx. 300 kg

Condition: like new (used), Year of construction: 2021, operating hours: 900 h, functionality: fully functional, spindle bore: 65 mm, spindle speed (max.): 4,000 rpm, spindle diameter: 200 mm, Equipment: documentation/manual, • Automatic opening/closing of the operator door (1000U) • Provision for fume extraction • Robot interface (Advance/Profibus) • 8" self-centering chuck with BB-08 through-hole (1st spindle) • Provision for Mazak Monitoring System-B RMP60 • Mazak API • Smooth synchronized tapping • On-machine writing function • Maximum program memory: 8 MB • 36-tool tool magazine - Main spindle motor: AC 15 kW (20 HP) - B-axis indexing: 1st (locking via joint) - Capto tooling - High-pressure coolant: 15 bar + simultaneous continuous flow coolant: 5 bar - Lateral chip conveyor Chodpfxszz Rt Uj Agrod • Counter-spindle with C-axis, including C1+C2 synchronization • Provision for Multi & Flash Tool system • Tailstock function for the counter-spindle

Condition: excellent (used), thread dia. 10 - 150 mm grinding length 900 mm thread pitch max. 3 mm workpiece diameter max. 260 / 340 mm threading length max. 50 mm Codpfxsyb S N Ss Agrjhd centre distance 1200 mm centre height 1100 mm grinding wheel diameter 275 - 400 mm grinding wheel width 14/20/30/40/50 grinding head-swivable, cross 4 re / 1 li ° max. stroke of grinding wheel 140 mm peripheral speed max. 35 m/sec total power requirement 14 kW weight of the machine ca. 5,8 t dimensions of the machine ca. 5,0 x 2,0 x 2,1 m

Condition: used, Thread rolling machine, cold rolling machine, thread forming machine, profile rolling machine Manufacturer PEE-WEE, Type P 24 Q Serial No. LC2403099, Year of manufacture 2004 Rolling force, max. 24 tons Tool diameter, max. 200 mm Rolling spindle diameter 69.85 mm Tool bore diameter 70 mm (nominal diameter) Receiving length, tool length, max. 180 mm Workpiece diameter, max. 50 mm Rolling spindle speed 22 - 44 - 95 - 190 RPM Hydraulic motor power approx. 3 kW Rolling drive motor power 5.5 kW Mains connection 400 Volt, 50 Hz - Swiveling rolling spindle for thread through-rolling - Rolling spindle speed in 4 stages via gear change Chedpsh A S Htjfx Agred - Hydraulic system integrated in the machine bed Space requirement L x W x H 2000 x 1750 x 2550 mm Weight approx. 3 tons Good condition Plunge rollers: The thread rolling tools with the same pitch as the workpiece form the thread by penetrating the workpiece up to the nominal diameter. The thread length is a maximum as long as the rolling tools are wide. Through-rolling tools: If the thread length is greater than the rolling tool width. Through-rolling tools have 3 sections - the inlet, the calibrating section, and the outlet. Grooved rollers have no pitch and are swiveled with the helix angle of the profile to be rolled. Helix rollers differ from grooved rollers by having a pitch in the profile. The sum of the helix angle and the swivel angle results in the helix angle in the workpiece.

Condition: used, Internal threading machine HAGEN & GOEBEL type HG 10 Tapping machine, Vertical tapping machine Machine. No. 4462 Year of construction approx. 1980 Cutting capacity in steel M3 to M10 Cutting capacity in cast iron M3 to M16 Cutting capacity in brass M3 to M18 mm throat depth 250 mm Pinol stroke 80 mm Table size 340 x 240 mm Spindle speed 200-1000 rpm 6 steps Motor power 0.55 and 0.75 kW Mains connection 380 Volt, 50 Hz - 6 speed levels through 2 motor speeds and 3 belt levels - Thread pitch via guide cartridge - 2 guide cartridges with 1.0 mm and 1.25 mm thread pitch Cjdpoupbf Dofx Agrohd - Spindle holder with cone Ø 14.8 to 16 mm and 4 mm keyway - Table height adjustment with toothed rack via hand crank on the round column - Quick-change tapping chuck size 1, Ø 19 mm Space requirement L x W x H 850 x 550 x 1800 mm Weight 255 kg Good condition
