Used Thread Machining for sale (63,762)

Condition: refurbished (used), Year of construction: 2018, functionality: fully functional, High-precision wire EDM machine GF CUT 1000 Year of manufacture: 2018 Travel (X/Y/Z): 220 x 160 x 100 mm Travel (U/V): +/- 40 mm Max. taper: 3° at 80 mm height Wire diameter: 0.07 mm to 0.20 mm Ljdexq Akwepfx Ab Uehn Best achievable surface finish: Ra=0.08 µm Max. workpiece dimensions: 300 x 200 x 80 mm Max. workpiece weight: 35 kg Includes AGIEJOGGER handbox for convenient machine setup 15" LCD color screen with lift-up keyboard and mouse AGIEVISION control Includes AGIESETUP 3D Includes AGIEDUO twin-wire system for automatic switching between two wire diameters Machine dimensions: 1400 x 1900 x 1970 mm Machine weight: 2700 kg The machine is cleaned, completely overhauled, and thoroughly tested by our specialists. We are happy to set up the machine at your location and provide thorough training on both operation and control.

Condition: as good as new (ex-display), Year of construction: 2022, operating hours: 690 h, functionality: fully functional, workpiece weight (max.): 400 kg, travel distance X-axis: 350 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 250 mm, total height: 222 mm, total length: 300 mm, total width: 185 mm, workpiece height (max.): 250 mm, workpiece width (max.): 680 mm, workpiece length (max.): 820 mm, type of input current: three-phase, overall weight: 2,850 kg, Equipment: cooling unit, GF CUT E 350, year 2022. Lhedpfx Ajvvld Isb Ujn Machine like new, only 685 hours of operation (upgradable). Available in our Semsales workshop at the end of February.

Condition: new, Year of construction: 2025, table width: 450 mm, table length: 900 mm, table load: 500 kg, spindle speed (min.): 8,000 rpm, number of spindles: 1, VMC 650 CNC machining center, milling machine with CNC system VMC 650 machining center is a multifunctional equipment that allows you to perform milling, drilling, thread cutting, and turning operations in automatic mode (if these options are available in the machine). The VMC 650 milling machine can have 16- or 24-position tool magazine. Depending on the customer's wishes, the milling machine can be equipped with a GSK, Siemens or Fanuc CNC system. It is possible to optionally add a Y-axis drive. As a very convenient additional option, we recommend installing a chip conveyor that will save you time when working with the equipment. Technical parameters: Worktable size 900x450mm Maximum workpiece weight 500 kg Movement along the axes X/Y/Z 800/450/500 mm Maximum distance from the spindle to the table surface 120-620 mm Motor power 5.5-7.5 kW Maximum spindle speed 8000 rpm Spindle type BT40 Positioning accuracy ±0.008/300 mm Repeatability ±0.005 mm Machine dimensions 300022752550 mm Machine weight 4000 kg It is also possible to supply CNC milling machines, machining centers with other table sizes: VMC 850 table 1000x500 mm VMC 855 table 1000x550 mm VMC 1060 table 1200x600 mm VMC 1160 table 1200x600 mm VMC 1275 table 1300x700 mm Lhjdjxc I Dgjpfx Ab Usn VMC 1370 table 1400x700 mm VMC 1580 table 1600x800 mm VMC 1680 table 1700x800 mm VMC 1890 table 2000x900 mm

Condition: good (used), Year of construction: 2015, operating hours: 3,000 h, functionality: fully functional, travel distance X-axis: 300 mm, travel distance Y-axis: 200 mm, travel distance Z-axis: 300 mm, workpiece weight (max.): 300 kg, table width: 400 mm, overall weight: 870 kg, table length: 300 mm, Electrode diameter 0.1 - 3 mm Electrodes available in brass, copper, or carbide Suitable for starter hole drilling in steel, aluminum, hard metal for wire EDM or for precise, deep, narrow boreholes Manual or CNC-controlled programming cycle Approach cycles Includes pump and collection tank on castors Lodew Dqdnepfx Ab Ujhn Includes drill chuck and seal for 1.5 mm electrodes Machine can be inspected or tested under power at any time.

Condition: ready for operation (used), Year of construction: 2021, operating hours: 11,537 h, functionality: fully functional, workpiece weight (max.): 1,000 kg, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 350 mm, workpiece length (max.): 1,030 mm, Wire EDM machine from 2021 with only 11,537 operating hours! TECHNICAL DETAILS Travel Path Travel path X-axis: 600 mm Lhodpow Ngd Hjfx Ab Uen Travel path Y-axis: 400 mm Travel path Z-axis: 350 mm Workpiece Data Workpiece weight: 1,000 kg Workpiece height: max. 350 mm Workpiece width: max. 800 mm Workpiece length: max. 1,030 mm Table Data Table width: 630 mm Table length: 950 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 3,400 x 2,160 x 2,320 mm Total weight: 5,440 kg EDM hours: 11,537 h Power-on hours: 29,381 h Type of input current: three-phase current EQUIPMENT 16 kg spools Note: Dismantling and loading can be carried out by the seller at an additional charge.

Condition: excellent (used), CNC INFOTEC Machining center Model: 3121 Lhjdpfx Abeun Rqyj Uon 3-axis Year of production: 2016 Machine working area dimensions for axes X and Y: X: 2200 mm Y: 3100 mm Head stroke in the Z axis: 250 mm Machine working speed X, Y, Z: X: 60m/min Y:60m/min Z:12m/min Vacuum table Price of a new machine: approx. 75.000 € Price: 27.900 €

Condition: refurbished (used), Year of construction: 2016, functionality: fully functional, travel distance X-axis: 350 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 300 mm, workpiece weight (max.): 500 kg, total height: 2,398 mm, total width: 1,690 mm, total length: 1,900 mm, quill stroke: 300 mm, workpiece length (max.): 790 mm, workpiece width (max.): 530 mm, workpiece height (max.): 275 mm, overall weight: 2,800 kg, tank capacity: 410 l, GF Machining Solutions FORM 200 Year of manufacture: 2016 Die-sinking EDM machine in C-frame design Stationary table with lowering tank Travel (X/Y/Z): 350 x 250 x 300 mm Maximum workpiece dimensions: 790 x 530 x 275 mm Maximum workpiece weight: 500 kg Programmable tank height: 100-325 mm Including pneumatic chuck Erowa ITS 50 or 3R Systems (at your choice) Ljdpfx Aexpw Axsb Ushn Maximum electrode weight: 50 kg Maximum moment of inertia: 2000 kgcm² 16-position electrode changer Operator interface: AC FORM HMI Operation via 15" LCD color touchscreen Keyboard and handset also available Machine dimensions: 1900 x 1690 x 2398 mm Total weight: 2800 kg The machine will be cleaned and serviced by us after receipt of order. Subsequently, an erosion test will be performed. We are happy to commission the machine at your location and provide an operator training. Optional: - Transport - Chiller unit - Dielectric fluid - Clamping devices

Condition: refurbished (used), Year of construction: 2012, operating hours: 24,760 h, functionality: fully functional, workpiece weight (max.): 750 kg, travel distance X-axis: 350 mm, travel distance Y-axis: 220 mm, travel distance Z-axis: 220 mm, total height: 200 mm, total length: 220 mm, total width: 200 mm, type of input current: three-phase, empty load weight: 2,450 kg, GF CUT 200 MS, year 2012. Excellent condition, the machine will be cleaned, revised and tested. Ledsvvlhyspfx Ab Uehn Option 0.1 mm. Available in our workshop in Semsales during March.

Condition: used, Year of construction: 2009, operating hours: 6,000 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, controller model: Heidenhain iTNC530, spindle speed (max.): 36,000 rpm, GF Mirkon XSM600U X: 800 Y: 600 Z: 500 A: +30/-100 degrees C: 360 degrees continuous HSK50 spindle: max. 36,000 rpm, 25 kW HR410 handwheel Lsdpswa R A Nefx Ab Uehn 60-station tool changer Rotary table including 3R clamping system Chip conveyor Coolant system with 20 bar internal coolant supply Blum laser tool measurement M&H 3D probe Pallet automation with 21 pallets - the pallets are not included in the scope of delivery This machine is offered on a customer order basis!

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, workpiece weight (max.): 1,000 kg, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 350 mm, total height: 2,320 mm, total length: 3,400 mm, total width: 2,160 mm, workpiece height (max.): 350 mm, workpiece width (max.): 800 mm, workpiece length (max.): 1,030 mm, type of input current: three-phase, table width: 630 mm, overall weight: 5,440 kg, table length: 950 mm, empty load weight: 4,440 kg, feed rate X-axis: 3 m/min, feed rate Y-axis: 3 m/min, feed rate Z-axis: 3 m/min, table load: 1,000 kg, input voltage: 380 V, tank capacity: 1,000 l, Equipment: cooling unit, documentation/manual, fridge, Wire EDM Machine Manufacturer: GF Machining Solutions Model: CUT E 600 Year of Manufacture: 2016 EDM Hours: 14,680 h (as of May 20, 2025) Travels: X / Y / Z: 600 / 400 / 350 (mm) Extras: 25kg spools Condition: Very good and well-maintained condition Payment Terms: 100% before disassembly and loading We are a tool shop and are downsizing our production. We purchased the machine new in 2016 and it has been in use ever since. The machine is powered and continues to be in use. A viewing and test run are available. The machine can be handed over at short notice upon request. With a purchase, we can also offer the following: - Training your staff - Cleaning the machine - Installing transport restraints - Loading onto the truck - Transporting with our own truck - Unloading at your location - Moving the machine to your site Ljdpfx Abou Hp Ate Uehn - Aligning the machine - Connecting and commissioning

Condition: like new (used), Year of construction: 2018, operating hours: 11,300 h, functionality: fully functional, travel distance X-axis: 1,350 mm, travel distance Y-axis: 1,150 mm, travel distance Z-axis: 700 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, controller model: itnc 530, workpiece weight (max.): 1,600 kg, table load: 1,600 kg, rotary table diameter: 1,100 mm, spindle speed (max.): 15,000 rpm, operating hours of spindle: 11,000 h, coolant supply: 80 bar, number of slots in tool magazine: 30, MIKRON HPM 1350U, 2018, machine is under service contract, fully functional under power. IKZ 80 BAR, Renishaw probe, laser measuring, kinematic OPT, OSS cycles. Geometry report available Lhsdpfx Abev Ibtco Usn

Condition: like new (used), Year of construction: 2022, operating hours: 1,100 h, functionality: fully functional, workpiece weight (max.): 1,500 kg, travel distance X-axis: 550 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 400 mm, total height: 2,600 mm, total length: 2,600 mm, total width: 2,340 mm, GF Machining Solutions CUT P550 Pro Year of manufacture: 2022 Uniqua Control Travel distances (X / Y / Z): 550 x 350 x 400 mm Travel distances (U / V): 550 x 350 mm Max. taper angle: +/- 30° at 400 mm height Maximum workpiece dimensions: 1200 x 700 x 400 mm Maximum workpiece weight: 1,500 kg Integrated Collision Protection (ICP) on all 5 axes Ledpfx Aexl Suujb Ujhn Cutting speed of 400 mm²/min Best surface finish: Ra 0.08 µm Available wire diameters: 0.10 to 0.33 mm (with WIRE100 option) Including Taper Expert option for 0.25 mm wire Including AC-Setup 3D option Including wire chopper option Including horizontal manual annealing option Including automatic central lubrication option Including active thermal stabilization option Including SparkTrack option Including iWire option Including kit for 0.10 mm wire Overall system dimensions: 2,600 x 2,600 x 2,340 mm Total system weight: 3,300 kg The machine will be cleaned, serviced, and fully tested for all functions by us upon order placement. You will receive a 6-month warranty on the machine. We would be happy to offer you commissioning of the machine.

Condition: good (used), Year of construction: 2013, operating hours: 20,791 h, functionality: fully functional, workpiece weight (max.): 450 kg, travel distance X-axis: 350 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 256 mm, workpiece height (max.): 250 mm, workpiece width (max.): 550 mm, workpiece length (max.): 750 mm, TECHNICAL DETAILS Max. workpiece dimensions width x depth x height: 750 x 550 x 250 mm Max. workpiece weight: 200 kg (submerged), 450 kg (not submerged) Travel paths Travel paths X/Y/Z axes: 350 / 250 / 256 mm Travel paths U/V axes: ±70 mm Max. taper at height: 30° at 100 mm Positioning speeds Manual positioning speed X/Y/Z/U/V axes: 2 m/min Programmable positioning speed X/Y/Z/U/V axes: 3 m/min Remote control Functions: wire drive, work container, measuring cycles Display resolution: 0.0001 mm Jogger: electronic handwheel for X/Y/U/V/Z axes Control console Display: TFT 15" XGA (1024 x 768) Input elements: alphanumeric push buttons, keyboard/mouse Wire threading system Threading height: up to 250 mm Threading nozzle diameter: 2 mm Ledpfovuqtfox Ab Uohn Combined wire guide Wire diameter: standard 0.07 - 0.3 mm (option: 0.05 mm) V-Guide: cylindrical to 2° Toroid guide: 2° - 30° Wire drive Wire spool: up to 25 kg Wire tension: 0 - 25 N Wire speed: 0 - 300 m/s Wire guide: semi-automatic Wire disposal: Schopper Work container Access: automatic lowering container Clamping system: clamping support or universal Clamping frame Operating mode: water bath and/or coaxial flushing Height adjustment: 0 - 250 mm automatic Flushing Flushing pressure: 0.2 - 18 bar programmable Flushing combination: coaxial/flushing/extraction Dielectric unit Load volume: 700 l Pre-cleaning: 10 µS/cm Water quality: 4 canisters with 8 filter cartridges Deionization resin: 10 l Water conductivity: 2 µS/cm automatic Cooling system: water/heat exchanger Temperature control: ±1 °C automatic IPG generator Generator: integrated Average working current: 38 A Feed control: servo-controlled/fixed feed Cooling system: air/heat exchanger Max. cutting speed, cylindrical: 300 mm²/min Best roughness Ra: 0.1 µm Average contour deviation Tkm: ± 1 µm (Tf 6 µm) Vision 5 control Control/operator interface: Vision 5 Operating system: Windows XP Operating mode: Multiprocessor Units of measurement: mm/inch Instruction set: absolute/incremental Smallest programmable step: 0.0001 mm Max. instruction length: 15 digits with floating point Max. path correction: 6 mm MACHINE DETAILS Dimensions width x depth x height: 2,095 x 1,950 x 2,247 mm Distance floor - clamping surface: 1,100 mm Net weight: 2,800 kg

Condition: refurbished (used), Year of construction: 2017, functionality: fully functional, GF MachiningSolutions CUT E350 Year of manufacture: 2017 Control: AC CUT HMI Travel distances (X/Y/Z): 350 x 250 x 250 mm Travel distances (U/V): +/- 45 mm Taper: +/- 30° at 77 mm height Workpiece dimensions: 820 x 680 x 250 mm Max. workpiece weight: 400 kg Collision protection on X/Y/Z axes Best surface finish on carbide/steel: 0.12/0.18 µm Maximum cutting speed: 300 mm²/min Overall dimensions: 1750 x 2470 x 2200 mm Lhsdpfjxbzimox Ab Ujn Total weight: 2525 kg The machine is cleaned, overhauled, and tested by us after receiving your order. We are happy to perform a test cut tailored to your needs. Optional services: - Commissioning and training - Transport - Warranty - Cooling unit

Condition: refurbished (used), Year of construction: 2015, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 450 mm, workpiece weight (max.): 1,600 kg, total height: 2,780 mm, total width: 2,265 mm, total length: 2,110 mm, quill stroke: 450 mm, workpiece length (max.): 1,220 mm, workpiece width (max.): 870 mm, workpiece height (max.): 470 mm, The GF AgieCharmilles FORM 300, built in 2015, is a powerful and precise used die-sinking EDM machine, specially designed for demanding machining tasks in tool and mold making. Thanks to its modern control system, excellent surface quality, and high efficiency, it offers an excellent investment opportunity for companies that value precision and cost-effectiveness. Key Features & Benefits: Lhsdpow Ebtvofx Ab Usn ✅ Large work area & high load capacity: Travel paths (X/Y/Z): 600 x 400 x 450 mm Maximum workpiece size: 1220 x 870 x 470 mm Maximum workpiece weight: 1600 kg Maximum electrode weight: 50 kg ✅ High-precision machining with state-of-the-art technology: Positioning accuracy thanks to linear glass scales (no recalibration required) Innovative ISPG (Intelligent Speed Power Generator) for maximum efficiency Adaptive control (ACC & ACO) for optimized spark discharge and reduced electrode wear Surface quality up to Ra 0.08 µm ✅ Powerful control & automation: AC FORM HMI with intuitive user interface & touchscreen Automatic CAD/CAM linking for seamless data transfer Job management with prioritization and Real-time monitoring Remote monitoring via SMS notification ✅ Maximum productivity & flexibility: Automatic 48-station electrode changer for unattended machining Intelligent workpiece measurement & 3D correction Reduced electrode wear thanks to iQ technology ✅ Reliability & low operating costs: Robust C-construction with high stability Efficient dielectric management with 6 filter cartridges Energy-efficient operation with low maintenance requirements Ideal for: ✔ High-precision mold and tool machining ✔ Series production with the highest quality requirements ✔ Complex geometries and fine surface structures Experience maximum productivity with the GF AgieCharmilles FORM 300 – your solution for precise and economical die-sinking EDM! 📌 Our used machine, built in 2015, is cleaned, overhauled, and comprehensively tested before sale to ensure the highest quality and reliability.

Condition: refurbished (used), Year of construction: 2013, functionality: fully functional, workpiece weight (max.): 400 kg, travel distance X-axis: 350 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 250 mm, total height: 2,200 mm, total length: 2,500 mm, total width: 2,500 mm, workpiece height (max.): 250 mm, workpiece width (max.): 680 mm, workpiece length (max.): 900 mm, overall weight: 3,000 kg, The GF AgieCharmilles CUT 20P, manufactured in 2013, is a high-performance, precise used wire EDM machine specifically engineered for demanding applications in the metalworking industry. Thanks to advanced technology and intelligent control, the CUT 20P delivers outstanding cutting quality, minimal maintenance requirements, and excellent return on investment. Main Features & Advantages: ✅ Compact design: Workpiece dimensions: max. 900 x 680 x 250 mm Maximum workpiece weight: 400 kg Travel ranges X/Y/Z: 350 x 250 x 250 mm Ledjw Dn Rlspfx Ab Uohn U/V: ± 45 mm Taper cutting up to ± 25° / 80 mm ✅ High-precision machining: Positioning accuracy via glass scales Automatic wire tensioning for consistently precise cuts Surface finish quality up to Ra < 0.25 µm ✅ Efficient wire system: Wire diameter: 0.15–0.30 mm Automatic wire threading and re-threading 25 kg wire spool for extended operating periods ✅ Intelligent control & user-friendly operation: Windows-based control system with intuitive user interface 15” LCD display for easy programming DXF import & 3D graphic check for precise simulations ✅ Reliability & low operating costs: Energy-efficient generator with low power consumption (9 kVA) Low maintenance costs due to robust construction and durable wear parts Integrated collision protection for maximum safety Ideal for: ✔ Tool & mould making ✔ High-precision components ✔ Series production & prototyping Achieve maximum productivity with the GF AgieCharmilles CUT 20P – The optimal choice for precise and cost-effective wire EDM! 📌 Our used machine from 2013 is professionally cleaned, overhauled, and thoroughly tested prior to sale in order to ensure the highest quality and reliability. 📩 Contact us for a tailored quote or to arrange a demonstration! We are also happy to offer commissioning and on-site training on the machine.

Condition: refurbished (used), Year of construction: 2019, functionality: fully functional, GF Machining Solutions FORM X600 Year of manufacture 2019 - Factory revision 2022 C-shaped design, fixed table with lowerable container Travel paths (X/Y/Z): 600 x 400 x 500 mm Distance between table and quill: 200-700 mm Max. workpiece size: L x W x H = 1200 x 800 x 350 mm Max. workpiece weight: 2000 kg Integrated C-axis for rotation, indexing, and erosion (rpm = 0-100 rpm) Pneumatic chuck of your choice (Erowa/3R Systems) 80 amp ISPG generator Best achievable surface finish Ra 0.08 µm AC FORM HMI user interface 15" LCD color screen, mouse or touchscreen, keyboard, and hand control Incl. 3R-Systems Workpartner WPT1+ - 150 electrode positions - 10 pallet positions Ljdewh Sigjpfx Ab Ujhn Net weight of the system: 5504 kg Machine dimensions: 1790 x 2860 x 3100 mm We will clean, service, and test the machine upon receipt of the order. Optional: - Commissioning and instruction - Transport and installation - Cooling unit - Dielectric

Condition: refurbished (used), Year of construction: 2015, functionality: fully functional, travel distance X-axis: 350 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 300 mm, workpiece weight (max.): 500 kg, total height: 2,398 mm, total width: 1,690 mm, total length: 1,900 mm, quill stroke: 300 mm, workpiece length (max.): 790 mm, workpiece width (max.): 530 mm, workpiece height (max.): 275 mm, overall weight: 2,800 kg, tank capacity: 410 l, GF Machining Solutions FORM 200 Built in 2015 - Only 7,200 EDM hours! C-shaped die-sinking EDM machine Fixed table with lowerable tank Travel paths (X/Y/Z): 350 x 250 x 300 mm Maximum workpiece dimensions: 790 x 530 x 275 mm Ljdswi Iuuepfx Ab Ushn Maximum workpiece weight: 500 kg Programmable bath height: 100-325 mm Including pneumatic chuck Erowa ITS 50 / 3R Systems / Hirschmann (optional) Max. electrode weight: 50 kg Max. inertia: 2000 kgcm² 4-position electrode changer AC FORM HMI user interface Operation via 15" LCD color screen with touchscreen Keyboard and handheld control unit also available Machine dimensions: 1900 x 1690 x 2398 mm Total weight: 2800 kg kg We will clean and service the machine upon receipt of the order. This is followed by an erosion test. We would be happy to commission the machine at your location and provide operating instructions. Optional: - Transport - Cooling unit - Dielectric - Clamping device

Condition: refurbished (used), Year of construction: 2011, functionality: fully functional, The GF AgieCharmilles CUT 30P, built in 2011, is a powerful and precise used wire EDM machine specifically designed for demanding machining applications in the metalworking industry. Thanks to state-of-the-art technology and intelligent control, the CUT 30P offers the highest cutting quality, low maintenance requirements, and an excellent return on investment. Main Features & Benefits: ✅ Large work area: Workpiece size: max. 1050 x 800 x 350 mm Maximum workpiece weight: 1000 kg Travel paths: X/Y/Z: 600 x 400 x 350 mm U/V: ± 50 mm Conical machining up to ± 25° / 80 mm ✅ High-precision machining: Positioning accuracy thanks to glass scales Automatic wire tensioning for consistently precise cutting results Surface quality up to Ra < 0.25 µm Lhsdpfx Aov S Ua Dsb Uon ✅ Efficient wire system: Wire diameter: 0.15 – 0.30 mm Automatic wire feeding and rethreading 25 kg wire spool for long operating times ✅ Intelligent control & user-friendliness: Windows-based control with intuitive user interface 15" LCD display for easy programming DXF import & 3D graphic check for precise simulations ✅ Reliability & low operating costs: Energy-efficient generator with low power consumption (9 kVA) Low maintenance costs thanks to robust construction and durable wear parts Integrated collision protection for maximum safety Ideal for: ✔ Tool & mold making ✔ High-precision components ✔ Series production & prototyping Experience maximum productivity with the GF AgieCharmilles CUT 30P – The perfect choice for precise and economical wire EDM! 📌 Our used machine, built in 2011, is cleaned, overhauled, and comprehensively tested before sale to ensure the highest quality and reliability. 📩 Contact us for a customized quote or demonstration! We are also happy to offer commissioning and training on the machine.

Condition: refurbished (used), Year of construction: 2013, functionality: fully functional, workpiece weight (max.): 800 kg, travel distance X-axis: 500 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 256 mm, GF AGIECHARMILLES CUT 3000 Year of manufacture: 2013 Travel paths: X = 500 mm, Y = 350 mm, Z = 256 mm U/V-axis travel: +/- 70 mm Maximum taper angle: 30° at 100 mm height Maximum workpiece dimensions: 1050 x 650 x 250 mm Maximum workpiece weight: 400/800 kg Achievable surface finish: Ra: 0.05 µm Available wire diameters: 0.05 – 0.33 mm (incl. KIT 50) Submerged wire EDM with automatic wire threading With automatic, two-sided lowering tank Incl. AGIEJOGGER handbox for convenient setup Incl. AGIESETUP 3D Incl. automatic wire changer AWC (for use with 2 wire spools) Incl. Conic-Plus option Incl. Fast-Threading option Incl. Smart-Threading option VISION 5 CNC control AGIE IPG-V generator Lhsdpfxowprq Tj Ab Usn Dimensions (L x W x H): 2800 x 2400 x 2220 mm Net weight: 4500 kg The machine will be thoroughly cleaned, reconditioned, and extensively tested after order placement. A laser measurement of the axes will be performed at our facility. We are also happy to carry out a customized test on the CUT 3000 for you. Operator training at Techma on your reconditioned machine included Optional extras available: - Transport - Commissioning - Chiller unit - Clamping devices - Consumables

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, travel distance X-axis: 900 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 500 mm, workpiece weight (max.): 3,000 kg, total height: 3,320 mm, total width: 3,100 mm, total length: 2,970 mm, workpiece length (max.): 1,814 mm, workpiece width (max.): 1,215 mm, workpiece height (max.): 600 mm, overall weight: 7,000 kg, GF FORM P900 Year of manufacture 2017 Die-sinking EDM machine in C-design with fixed table Travel paths (X/Y/Z): 900 x 700 x 500 mm Speed X/Y: 6 m/min Speed Z: 7.5 m/min Measuring resolution (X/Y/Z): 0.05 µm Max. workpiece dimensions: 1814 x 1215 x 600 mm Max. workpiece weight: 3000 kg Max. electrode weight: 50 kg ISPG generator with 80 ampere Best surface roughness: Ra 0.1 µm Including C-axis (U: 0-100 1/min) Including 20-position electrode changer Control AC FORM HMI 15" LCD color screen, mouse, touchscreen, and keyboard Machine dimensions: 2970 x 3100 x 3320 mm Total weight: 7000 kg Lhedpfx Abowprpie Ujn Dielectric volume: 2500 liters The FORM P900 belongs to the latest generation of die-sinking EDM machines from GF Machining Solutions and is in excellent condition in our stock. After order placement, it will be thoroughly serviced and extensively tested by us. We are also happy to offer you commissioning and training. This also includes a 6-month warranty.

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: AH00000267, overall weight: 3,000 kg, Equipment: CE marking, MACHINE DETAILS Electrical Data Rated voltage: 400 V Rated current: 37.5 A Frequency: 50 Hz Weight: 3,000 kg Lsdpjxmguxsfx Ab Ushn EQUIPMENT CE marking

Condition: ready for operation (used), Year of construction: 2005, operating hours: 12,976 h, functionality: fully functional, machine/vehicle number: NSO997, travel distance X-axis: 750 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 850 mm, controller model: FANUC Series 30i, spindle speed (max.): 15,000 rpm, TECHNICAL DETAILS Travel (X-axis): 750 mm Travel (Z-axis): 800 mm Travel (Y-axis): 850 mm Magazine Positions: 120 Spindle Speed Range: 50–15,000 rpm Spindle Diameter (Front Bearing I.D.): 80 mm Spindle Taper: ISO R297 / Taper No. 40 Tool Holder: MAS I Type P40T Lhedexqmbgopfx Ab Usn Table Pallet Size: 550 × 550 mm Max. Rotary Table Swivel Range: 360° Pallet Height: 750 mm Distances Distance Between Spindle Nose and Table Center: 150–1,000 mm Distance Between Spindle Nose and Table Surface: 50–850 mm Feed Rates Rapid Traverse X-, Y-, Z-Axis: 60,000 mm/min Cutting Feed Rate (X-, Y-, Z-Axis): 0.001–30 mm/min Tool Changer (ATC) Number of Tools: 40 Tool Size (Ø × Length): Ø75 × 470 mm Tool Weight: 8.0 kg Tool Change Time (Tool to Tool): 1.3 s Performance Data Positioning Accuracy (X-, Y-, Z-Axis): ±0.003 mm Repeatability (X-, Y-, Z-Axis): ±0.0015 mm Pallet Load Capacity: 800 kg Thrust Force: 9,800 N MACHINE DETAILS Control: FANUC Series 30i Space Requirements & Weight Footprint: 2,750 × 5,700 mm Machine Weight: 16,000 kg Motors Spindle Drive Motor (15 min rated power): 22 / 18.5 kW Hydraulic Pump Motor: 3.7 (4) kW Operating Hours Machine Running Hours: 12,976 h Control Powered Hours: 112,997 h

Condition: ready for operation (used), Year of construction: 2019, functionality: fully functional, machine/vehicle number: AA100001570, travel distance Z-axis: 180 mm, table width: 1,620 mm, table length: 5,510 mm, rapid traverse X-axis: 56 m/min, rapid traverse Y-axis: 56 m/min, TECHNICAL DETAILS Processing table dimensions (L x W): 5,510 x 1,620 mm Z-axis travel distance: 180 mm Maximum vectorial rapid traverse speed X/Y-axis: 56 m/min Spindle unit speed: 4,000 rpm Tool changer slots: 44 Connection diameter: 250 mm MACHINE DETAILS Dimensions & Weight Dimensions: 9,700 x 5,020 x 2,650 mm (LxWxH) Net weight: 5,000 kg Spindle unit motor power: 5.5 kW Air consumption: 4,430 m³/h Air velocity: 25 m/s Voltage: 400 V / 50 Hz EQUIPMENT PRO-Speed safety system TEPCAD control panel with touchscreen color display Linear tool changer TBR14 Linear tool changer FAST14 Air blower on the electrospindle XY-axis safety guard Vacuum pump 150/300 m³/h 5-axis unit ‘JQX’ version 13.5 kW Fixed pedestal: 145 x 145 H=75 mm Rotatable gondola: 145 x 55 H=75 mm Clamp for 8 rails TV FLEX / TV FLEXDRIVE / TV FLEXMATIC MULTIGRIP 90 round clamp (H83) for TV FLEX / TV FLEXMATIC Maestro connect 1 year (including Gateway Kit plug & play) SCM DIGITAL SOLUTIONS: MAESTRO CONNECT MAESTRO ACTIVE software for human-machine interface (HMI) Maestro software for CNC programming Hardware key for Maestro CNC Advanced Maestro 3D module Additional key for Maestro CNC (USB connection) Windows 10 embedded 64-bit operating system Lodpfexmgr Rox Ab Ushn Console with integrated PC eye-M PRO

Condition: ready for operation (used), Year of construction: 2005, operating hours: 15,756 h, functionality: fully functional, machine/vehicle number: 16252, travel distance X-axis: 500 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 500 mm, controller model: FANUC 30i, workpiece weight (max.): 250 kg, TECHNICAL DETAILS Travel X-axis travel: 500 mm Y-axis travel: 500 mm Z-axis travel: 500 mm Work Table Pallet size: 300 x 300 mm Ljdpfxexnwy Io Ab Uohn Max. workpiece weight: 250 kg Rotary table: 360° x 0.001° Minimum/maximum spindle to table center distance: 120/620 mm Minimum/maximum spindle to table surface distance: 80/580 mm Max. workpiece size: 500 x 500 mm Spindle speeds: 50 - 15,000 rpm Spindle taper: ISO 40 Spindle drive power: 15/7.5 kW Feed rates X/Y/Z: 1 - 50,000 mm/min Rapid traverse: 50 m/min Rapid traverse B-axis: 33.3 rpm MACHINE DETAILS Control: FANUC 30i Total connected load: 38 kVA Weight: 10,000 kg Operating Hours Running time: 15,756 h Control on-time: 116,776 h
