Used Profiling for sale (5,215)

Condition: used, Number of spindles 3 St. Number of tools 8 St. Spindle diameter 50 mm Dimensions (L/W/H) 4250x1850x2300 mm ! MACHINE FUNCTIONALLY CHECKED AND READY FOR DEMONSTRATION ! !!! Technical description in RUSSIAN, more machine pictures as well as machinevideos - if available - at the end of this description as attached files !!! # 6988 Weinig Univar 6 CNC ..... ..... Technical details summary (please ask for possibly more included equpment) ..... ..... 1st profiling spindle: ..... ..... > spindle rotation direction: clockwise and reverse for rip-off free outside profiling of sashes > position: vertical right > number of tools: 1 pcs. > length of spindle: 120 mm > number of revolutions: 6000 rpm > spindle diameter: 50 mm > tool diameter max.: 232 mm > engine: 11 kW 2nd profiling spindle: ..... ..... > position: vertical right > number of tools: variabel, CNC > length of spindle: 320 mm > spindle stroke vertical: variabel, CNC > number of revolutions: 6000 rpm > spindle diameter: 50 mm > tool diameter max.: 232 mm > engine: 11 kW 3rd profiling spindle: ..... ..... > position: vertical right > length of spindle: 160 mm Kledpfx Ahoymf Ekovep > number of revolutions: 5850 rpm > spindle diameter: 40 mm > tool diameter max.: 210 mm > engine: 3 kW More features: ..... ..... > possible to work online: > monitor control: > Equipment for profiling small sashes: min. 500 mm > Control: PC-Nexus If the technical characteristics of this machines donnot fit with your requirements, please get in contact with us. Our longtime experienced team is looking forward to support you in technical adaptions or in finding a suitable machine for you! Technical details according to manufacturer - without guarantee!

Condition: like new (used), functionality: fully functional, Year of construction: 2010, The line is from 2010. Modernization is being done in 2020. ZEMAN CZS LINE SPECIFICATIONS ZEMAN's flagship product, the fully automated "PURLIN" line, is used to produce open, cold-formed sections such as C, Z, and SIGMA, in various widths and shapes, thanks to fully automatic adjustment of the profiling rollers. Coils up to 750 mm wide and 1.25 mm to 3 mm thick sheet metal in grade S-390 and lower can be used as raw material. The machine is designed to produce components up to 15 m long. The width of the specially hardened profiling rollers is infinitely adjustable, using only dedicated software. A fully integrated "flying punching" device creates all types of mounting holes, and the entire process is continuous, meaning the material does not stop for individual operations such as punching holes or cross-cutting. To maintain production efficiency, the line speed is dynamically optimized. The machine decelerates and accelerates automatically without operator intervention. A coil uncoiler with a maximum working load of 15 tons is mounted on a mobile trolley, enabling precise centering of the material strip before feeding it into the straightener. The straightener, along with a crescent straightening system, allows for straightening the material, ensuring the required sheet flatness and reducing the crescent on the feed belt. 2. Punching Section Ksdpfx Ajymampshvolp This section contains 5 double, "flying" punching portals, which can be equipped with 20 small (up to 40 mm) or 10 large (up to 100 mm) tools (punches and dies) for punching mounting holes. A combination of these tools can also be used. 3. Pre-cutting Shear A "flying" shear used to make preliminary holes for the cutting shear. This process is designed to maintain material continuity, resulting in a more precise profile shape, especially at its beginning and end. This is an adaptive guillotine that adjusts the width of the hole being cut to the width of the sheet metal strip. 4. Guide Carriage/SIGMA Modules The guide carriage is used to center the sheet metal strip before entering the profiler. It is interchangeable with the module for producing Sigma-shaped profiles. To produce S+ profiles, the guide table should be removed and two Sigma modules inserted. These modules position fully automatically and independently, left and right. 6. Rotary Cut-Off Guillotine. The rotary cut-off guillotine with hook knives is used to finally cut the profile from the material strip using the holes made by the pre-cutting guillotine. This is a "flying" guillotine, so the sheet metal does not stop during the cutting process. Depending on the profile being produced, a properly oriented cutting cassette should be attached. 7. Receiving Table The receiving table is used to automatically discharge the completed profiles from the roller conveyor. The elements are then manually arranged into a package. The design allows for easy bundling of the package. The table is designed to accept 15-meter profiles and allows for access by a forklift or overhead crane to collect the package of profiles.

Condition: good (used), Year of construction: 1984, CNC Optical Profile Grinding Machine Ksdpfx Ahsp R Rm Isvjlp Wasino GLS-130AS 1984

Condition: good (used), Year of construction: 1996, Hema Profile Grinding Machine Type PSM 300, year 96, with base frame HEMA PSM 300 Universal Profile Grinder - Automatic belt tensioning - Tool-free, fast belt change within seconds Kledpoyl Ilwefx Ahvop - Standard internal grinding with same belt length - Quick-change system for grinding bars - Cast iron table, 450x450 mm, tiltable up to 45°, zero stop and scale - Motor 1.1 kW, 2800 rpm - Very quiet operation - Maximum grinding height 300 mm, grinding bar height inside 200 mm, outside 250 mm - Switch with undervoltage release - Extraction port 60 mm - Connection for industrial vacuum cleaner

Condition: used, Tube bending machine, mandrel bending machine, bending machine for tubes and profiles Tube bending unit with SIEMENS servo motor and planetary gearbox Year of construction: 2003 Bending capacity: max. Ø 20 x 1 mm Bending radius: max. R 70 mm Bending angle: max. 200° - last used for round tube Ø 15.4 x 0.8 mm, R60 mm - Bending tools and bending jaws interchangeable Klsdpfx Asd E A I Ijhvep - Bending tool drive via AC servo motor and Alpha spur gear, planetary gearbox - 2-part bending tool opens and closes via hydraulic stroke movement - MERKLE hydraulic round block cylinder, item 014445 for hydraulic tool opening - Pneumatic height adjustment of the bending jaw via Festo compressed air cylinder - without electrical control - without hydraulic unit Dimensions L/W/H 760 x 400 x 150 mm weight: approx. 60 kg good condition Removed from a functional special machine, tested before removal. Drive: Brushless permanent magnet servo motor SIEMENS Typ:1FK6061-7AF71-1EG0 Nominal torque = MO: 6.4 Nm Rated current = Io: 6.1 A Speed = n. max.: 5500 rpm - Brushless permanent magnet servo motor SIEMENS ----- 5 pieces available in right-hand version. 5 pieces available in left-hand version. The price quoted refers to 1 bending unit with servo motor. If required, we also sell individual assemblies of the bending unit. We also offer the electrical components for controlling the servo motor. We also offer hydraulic units.

Condition: used, Mechanical pull-down NC machine vice FRIBOSA type size B Precision machine vice, grinding vice, clamp Jaw width 100 mm Jaw height 34 mm Clamping width 0 to 130 mm guideway height 40 mm guideway length 270 mm - mechanical machine vice - Clamping range via trapezoidal spindle - Stable base body ground on all sides Klsdpfx Aeilx Ufohvsp - Can be clamped horizontally, vertically or laterally Dimension L x W x H 310 x 100 x 77 mm weight: 10 kg good condition

Condition: used, 5-fold combined profile steel shears PEDDINGHAUS type 210 AD/13 Machine. No. 529A059 Year of manufacture approx. 1970 Punching machine: Punching force 60 ton. Punch stroke 25.5 mm Punching capacity Ø 25 mm in 16 mm sheet metal Ø 20 mm in 19 mm sheet metal throat depth 365 mm Bar steel shears: Cutting capacity Round 42 mm Square 38 x 38 mm Flat steel shears: Cutting capacity with shearing angle 5° 150 x 13 mm or 200 x 10 mm Blade length 245 mm Kjdsi Duh Ijpfx Ahvolp Profile steel shears: Shearing capacity angle steel at 90° 110 x 10 mm Shearing capacity angle steel at 45° 90 x 9 mm T-steel 110 x 10 mm Notching device: Rectangular notcher up to 12 mm sheet metal Punch dimensions 85 x 50 mm Motor power 3 kW Mains connection 380 Volt, 50 Hz. - Center punch detection device via hand lever and centering device - Mechanical stroke release via hand lever - Flat steel shears equipped with 2° blade - Mechanical hold-down device on the profile steel shears, bar steel shears and flat steel shears Space requirement L x W x H 1500 x 800 x 1900 mm Weight 2000 kg good condition

Condition: used, Thread rolling machine, cold rolling machine, thread rolling machine, profile rolling machine Manufacturer PEE-WEE Type P 24 Q serial no. LC2403099 year of construction 2004 Rolling force max. 24 ton. Tool diameter max. 200 mm Rolling spindle diameter 69,85 mm Tool bore diameter 70 mm (nominal diameter) Tool length, tool length max. 180 mm Workpiece diameter max. 50 mm Rolling spindle speed 22 - 44 - 95 - 190 rpm Motor power hydraulics approx. 3 kW Motor power roller drive 5.5 kW Mains connection 400 Volt, 50 Hz - Swivel roller spindle for threaded continuous rollers - Rolling spindle speed in 4 stages via gear changeover - Hydraulic system integrated in the machine bed Space requirement L x W x H 2000 x 1750 x 2550 mm Weight approx. 3 tons good condition Grooving rollers: The thread rolling tools with the same pitch as the workpiece form the thread by penetrating into the workpiece up to the nominal diameter. The thread length is maximum as long as the rolling tools are wide. Continuous rolling: When the thread length is greater than the rolling tool width. Ksdpfx Ahsh A S Htevelp Through-feed tools have 3 sections - the infeed, the calibration section and the outfeed. Grooved rollers have no pitch and are swiveled with the pitch angle of the profile to be rolled. Pitch rollers differ from grooved rollers in that they have a pitch in the profile. The sum of the pitch angle and the swivel angle gives the pitch angle in the workpiece.

Condition: used, Tool presetter GILDEMEISTER-DE VLIEG Type EGS 5045 / Microset DPS 100 Serial No. 83-10-102 Year of construction 2002 Travel distance X-axis approx. 400 mm Travel distance Z-axis approx. 400 mm Tool holder in mounted rotary table: Ø 50 mm Pitch circle diameter of the tool holders in the mounted rotary table Ø 340 mm Inner cone in the mounted rotary table Ø 245 mm Tool mounting plate as rotary table with 8 mounting holes Ø 50 mm Centering diameter of the mounted tool holder plate: Ø 102 mm Swivel-mounted flange holder with centering diameter: Ø 102 mm Swivel-mounted flange holder with outer diameter: Ø 155 mm Swivel-mounted flange holder with 3x M10 mounting holes, bolt circle: Ø 130 mm Mains connection 230 Volt, 50 Hz - Microset DPS 100 measuring electronics - Rotary table with 8 tool positions - Interfaces: 1x RS232, 2x measuring system (X/Z) - Profile projector with screen Ø 100 mm magnification 20x and two circular screens - Fixed focusing screen with crosshairs - Axis movement via manual quick adjustment with pneumatic clamping - Fine adjustment via hand wheels - Rotatable rotary table with pneumatic clamping - Metal substructure with 3 drawers Space requirement L x W x H 1100 x 1000 x 800 mm Weight 400 kg Kledpjhbal Djfx Ahvsp good condition

Condition: new, Ostas Profile Ring Bending Machine OPK 125 Technical Specifications: Klsdoxrd Rnopfx Ahvsp • Tool holder, shaft: 120 mm • Tool: 390 mm • Working speed: 2-7.5 m/min • Motor: 15 kW • Dimensions (L-W-H): 2000 x 1700 x 1950 mm • Weight: 4850 kg • 3 rollers are driven separately by a hydraulic motor and planetary gearbox • Hardened standard rolls • Hardened and ground tool holder, shaft • Mobile control panel • Horizontal and vertical working position • Hydraulic side supports • Digital displays (2 pcs.) • In accordance with CE standard

Condition: new, Ring-profile bending machine Akyapak APK 81 I-steel - upright 100 x 20 (d 2100) mm raw diameter max. 100 x 3 (d 3000) mm angle steel 80x80x8 (d 2000) mm square steel 50 x 25 x 2 (d 600) mm I - steel - flat 120 x 30 (d 600) max.140b mm solid material - diameter 60,0 (d 1000) mm tool holder 80,0 mm Speed 4,2 m/min. Weight 1.600 kg Dimension L-W-H 1240 x 1375 x 1540 mm Equipment: hydr. roller drive planetary gear feed of the 2 lower rollers for extra small bending radii hardened tool holder (42CrMo4) standard roll set, hardened mobile control panel 3 driven rolls Kloded R Iquepfx Ahvsp digital display machine can be used horizontally and vertically CE-sign / declaration of conformity Operating instructions in German

Condition: new, Akyapak Akbend ring APK 35 profile bending machine Description •. base • horizontal and vertical working • Foot switch • Standard rolls (shared) • 2 driven rollers • CE mark / conformity declaration • User manual in German Technical details • I - steel - flat: 120 x 15 (d 750) mm • I steel upright: 60 x 10 (800 d) mm Kledped Er S Iofx Ahvjp • Angle steel: 50 x 5 (1200 d) mm • Round material: 35.0 (800 d) mm • Max size: 70 x 2 (1200 d) mm • Square material: 50 x 40 x 3 mm • Bending speed: 4.3 m / min • Diameter of the roller - top: 155 mm • Bore: 50.0 mm • Total power: 1,5 kW • Weight: 320 kg • Dimensions L W H: 730 x 830 x 1350 mm

Condition: new, Ostas Profile Ring Bending Machine OPK 105 Technical Specifications: • Tool holder, shaft: 100 mm • Tool: 315 mm • Working speed: 7 m/min • Motor: 7.5 kW • Dimensions L-W-H: 1980 x 1450 x 1650 mm • Weight: 3130 kg • 3 driven rolls • Hardened standard rolls • Hardened and ground tool holder, shaft • Mobile control panel • Horizontal and vertical working positions Klsdpsxrd H Nsfx Ahvep • Side angle guide rolls • Digital displays (2 pcs.) • Brake motor • Compliant with CE standard

Condition: new, Akyapak Akbend ring profile bending machine APK 50 Description - lower roll adjustment, hydraulic both lower rolls can be adjusted - horizontal and vertical working - Control panel ( the position of the lower rolls is shown in the display ) - Standard rollers included - 3 driven rollers - CE-sign / declaration of conformity - Instruction manual Technical details - Bending capacity see performance table - bending speed : 4,4 m/min - Roll diameter : 157 mm - Shafts : 50,0 mm - total power requirement : 1,1 kW - weight: 500 kg Kledpfx Aod Er S Aohvop - Dimension L-B-H: 950 x 700 x 1220 mm

Condition: new, Ostas Hydraulic Profile Ring Bending Machine OPK 45 - 3 Special equipment included in the price: 3 driven rollers Digital display Incl. standard roller set steel Description Hydraulic / motorized ring bending machine horizontal and vertical applicable with 3 driven rolls Klodpeg Tzbwefx Ahvjp 3 rollers motor driven Feeding of the upper roller hydraulic Rollers are hardened Left/right rotation by means of foot pedal Shaft 50mm roller-Ø top 158 mm roller-Ø bottom 158 mm Speed 4,5 m/min Motor power : 0,75 +1,5 kW Electrical connection 400 V According to CE standard Weight 420 kg

Condition: new, Ostas profile ring bending machine OPK 85 Technical specifications: - tool holder, shaft: 80mm Ksdpfx Ahjfig A Novolp - tool: 245mm - working speed: 6m/min - Engine: 4kw - Dimensions L-W-H: 1020x1460x1350mm - Weight: 1800kg - 3 rollers driven - Hardened standard rollers - Hardened and ground tool holder, shaft - Mobile control panel - Horizontal and vertical working position - Side angle guide rollers - Digital displays (2pcs.) - Brake motor - According to CE-Norm

Condition: new, Tubend hydraulic profile ring bending machine HPK 50 3 driven rollers Digital display Incl. standard roller set steel Hydraulic / motorized ring bending machine Can be used horizontally and vertically with 3 driven rollers 3 motor-driven rollers Hydraulic infeed of the top roller Hydraulic: 8 tons Rollers are hardened Klodpfx Asum R U Ashvep Left/right rotation via foot pedal Mounting: shaft 50 mm Roller Ø 162 mm Speed: 4.5 m/min Motor power: 1.1 kW Electrical connection 400 V According to CE standard Weight 510 kg L.W.H. 810 x 950 x 1500mm Power table see PDF file

Condition: new, Ostas hydraulic profile ring bending machine OPK 45 2 driven rollers Digital display Incl. standard steel roller set Description Hydraulic / motorized ring bending machine Ksdjvmzfijpfx Ahvelp Can be used horizontally and vertically with 2 driven rollers 2 rollers motor-driven Adjustment of the upper roller hydraulic Rollers are hardened Left/right rotation using foot pedal Mounting: shaft 50mm Roller diameter at top 158 mm Roller diameter at bottom 158 mm Speed 4.5 m/min Motor power: 0.75 +1.5 kW Electrical connection 400 V According to CE standard Weight 420 kg

Condition: new, Ostas profile ring bending machine OPK 65 Technical specifications: - tool holder, shaft: 60mm - tool: 175mm - working speed: 5m/min - Engine: 3kw - Dimensions L-W-H: 900x1250x1200mm - weight: 1080kg - 3 rollers driven - Hardened standard rollers - Hardened and ground tool holder, shaft - Mobile control panel - Horizontal and vertical working position - Side angle guide rollers Kljdpfefig Aiox Ahvjp - Digital displays (2pcs.) - Brake motor - According to CE-Norm

Condition: new, Balkaya Profile Ring Bending Machine HBM 80 Technical specifications: Tool holder, shaft: 80mm tool: 245mm working speed: 4,5m/min Motor: 4kw Hydraulics: 30 to Ksdpfx Ahjh T Ulnevelp dimension L-W-H: 1450x1050x18000mm weight: 1400kg 3 rollers driven Hardened standard rollers Hardened and ground tool holder, shaft Mobile control panel Horizontal and vertical working position Digital display According to CE standard

Condition: new, Ring profile bending machine Ostas OPK 42 Incl. standard roller set steel Motorized ring bending machine horizontal and vertical applicable with 2 driven rolls lower rolls motor driven rollers are hardened manual feed via upper roller left/right rotation by means of foot pedal shaft-Ø 50 mm roller-Ø top 158 mm roller-Ø bottom 158 mm speed 4,4 m/min Motor power 0,75 kW Kledpfx Ahjgw Hmqovep Electrical connection 400 V According to CE standard Weight 380 kg According to CE standard

Condition: excellent (used), functionality: fully functional, control type: manual, number of rollers: 3, shaft diameter: 105 mm, bending force (max.): 20 t, Equipment: documentation/manual, ALLENSPACH UNIVERSAL is a comparable machine to the PBT WALBA 20 Very large quantity of tools 2-in-1 machine: front section profile bending rear bending/pressing with setup change Shaft diameter 105 mm Number of rolls 3 X-axis stroke 265 mm Flat capacity Kljdpfxjynwhyj Ahvjp 100 x 15 x R =2500 mm Tube capacity 89 x R=2000 Ø x mm Bar capacity 50 x 50 x R=1500 mm Working speed 20000 mm/min.

Condition: excellent (used), Profile projector ORAMA 500 with digital display Kjdpfx Aeylc Utehvjlp

Condition: new, angle steel/side length / mm double T-iron on the x-axis / mm U-iron on the x-axis / mm total power requirement 4/380 kW weight of the machine ca. 1645 kg required space 1500 x 1000 x 1400 mm The Gerd Wolff HPK-80 is a hydraulic profile and tube bending machine with 3 rollers. The machine is ideal for bending profiles, tubes and similar material. Model: HPK 80 Upper shaft diameter: Ø 80 mm Bottom shaft diameter: Ø 70 mm Roll diameter: Ø 245 mm Working speed: 7 m/min Motor power: 4.75 kW / 380 V Dimensions (L x W x H): 1500 x 1000 x 1400 mm Weight: 1645 kg Standard accessories Steel construction welded frame 3 Rolls are powered Hardened and ground shafts made of high tensile special steel Rolls are hardened and ground Klodpoyk Im Eefx Ahvjp Horizontal and vertical working position Hardened standard rolls Mobile control panel 3 Axis mechanical lateral angle guide rolls Brake motor equipped for the precision bending Digital Read-Outs (2pcs) Optional Equipments Pipe, tube and profile bending rolls Hydraulic lateral guide rolls (2 axis) Automation with NC control

Condition: new, 35 (600) mm 35 (900) mm L-beam 50 x 50 x 5 (800) mm T - beam - web outwards 60 x 7 (600) mm Ksdpsfv H Etjfx Ahvjlp Axis diameter 50 mm work speed 4,5 m/min total power requirement 1,5 kW weight of the machine ca. 0,4 t dimensions of the machine ca. 1,1 x 0,8 x 1,5 m Profile bending machine with: - Foot pedal right / left - Recording: wave 50mm - with digital display - hardened special steel shafts - 1 set of standard rollers - Lower rollers are driven - Upper roll up and down hydraulically deliverable - Horizontal and vertical operation - Engine with braking device
