Used Profile Forming for sale (11,398)

Condition: like new (used), Year of construction: 2023, operating hours: 400 h, functionality: fully functional, machine/vehicle number: 2022LW160, High-speed roll forming line, equipped with tooling for the production of GELAN and SCHUCO metal profiles used in PVC window frame manufacturing. Machine achieves speeds up to 55 m/min with 6 m profile length production. Maximum processable material thickness is 2.5 mm. Upper and lower shaft diameter is 60 mm, the width between the stands is 360 mm, and each station is driven by an individual gearbox with two cardan shafts. Both upper and lower shafts are driven at each station. The line features 15 forming stands plus two straightening stands (Turkish heads). All forming rollers have a surface hardness of 62 HRC. Additionally, all auxiliary rollers and shafts in contact with the material are induction-hardened to 58–62 HRC (including run-out table rollers and horizontal accumulator rollers). A flying cut servo positioning system (DELTA 7.5 kW servo motor, ball screw, and linear guides) facilitates precise length adjustments via HMI. Hydraulic cutting system included. The run-out table features an automatic profile kickout, conveying, and separation system for continuous production without stopping. The horizontal entry accumulator for strip material ensures uninterrupted production, equipped with pinch rollers and individual drives. Double-sided hydraulic decoiler included. The line is equipped with a continuous ink-jet marking system from KONING (Germany). The automatic stacking system is not installed (see photos). The machine features recirculating cooling and lubrication across all 15 stations. Electronics: SIEMENS (PLC, contactors), SCHNEIDER (contactors), DELTA (Taiwan drives and servo). Main electric motors by Siemens. Bearings by SKF. The mechanical frame is stress-relieved and milled for precision. The machine has only been used for test production, having processed just 250,000 m of material (machine is nearly new). It is installed and connected to power; test runs can be arranged on-site. The listed price refers to the machine disassembled and loaded onto a truck. Included is comprehensive documentation with detailed tooling setup instructions for each profile (including detailed assembly drawings of rollers). Kdjdpfx Ajyw Rzasbnsr Model: LW160 Supply voltage: 380 V Installed power: 73.5 kW (consumes only 40% of power when processing 2 mm strip) Frequency: 50 Hz Weight: 16,500 kg Current: 160 A Serial number: 2022LW160 Year of production: 2022 Year of on-site assembly: 2023

Year of construction: 1990, condition: used, functionality: fully functional, For sale is a robust and fully operational roll forming machine for the production of corrugated and tile-profile sheets made of aluminum. The system is suitable for the continuous production of various profile geometries. The machine was commissioned in October 1990 at Leichtmetallwerk Nachterstedt GmbH and impresses with its solid industrial design. Thanks to the integrated profiling line, the cutting and embossing tool, and the automatic stacking device, an efficient production process is possible, from the coil to the finished profile. The system is particularly designed for the production of roofing profiles, tile profiles, and aluminum corrugated profiles, thus offering a versatile range of applications in the field of sheet metal processing and profile manufacturing. System components: - Coil - Profiling line - Cutting and embossing tool - Automatic stacking device Ksdpfx Aoy Sxhwsbnedr Currently produced profiles: - Tile profile 33/175; material thickness: 0.6 mm - Asymmetrical corrugated profile 33/175; material thicknesses: 0.6 mm and 0.7 mm - Aluminum corrugated profile 28/125; material thicknesses: 0.7 mm, 0.8 mm and 1.0 mm Condition & Inspection: The system is ready for production, is in fully operational condition, and is currently still used for production. This allows the functionality to be verified on-site if desired. The roll forming machine can be inspected at any time by arrangement at our location in Krostitz, Hilchenbacher Straße 2A. The system is immediately available and ready for sale. We will gladly provide further technical information, images or details upon serious interest.

Condition: excellent (used), functionality: fully functional, Year of construction: 2008, actuation type: hydraulic, Complete production line for drywall metal profiles (CD/UD/CW50/UW50) for sale, ideal for anyone looking to start or expand a profitable business in the construction materials industry. ✔ Strong and reliable machines ✔ Efficient and continuous production ✔ Easy to operate ✔ Perfect for producing your own products or supplying construction material distributors Ksdpfx Abeyv R N Usnsdr The production line is in very good working condition, well maintained, and can be tested on site. This is an excellent opportunity for entrepreneurs or companies who want to enter the drywall profile market without investing in expensive new equipment. Selling due to business reorganization. 📞 For more details, price, photos, or videos of the machines in operation, please contact me by phone or message.

Condition: used, Second-hand Leitz Variform profile cutter for woodworking applications. Technical data: - Blade: Z4 - Flight circle (ø): 165 mm - Bore: 40 mm Kdodpfxszr D Srj Abner - Marking: MEC - Length: 46 mm - Material: Steel

Condition: used, Pressure zone turret, softforming interchangeable profiles for softforming machines, double-end tenoners, edging machines, scoring motor, chipper motor, milling motor for edging machines Kdodpfx Abob Uhu Aensr -HOMAG softforming interchangeable profiles for softforming profiles can be quickly converted to straight edges -with heavy leadership -laterally movable -with counter -Dimensions: 1300/780/H620 mm -Weight: 260 kg

Condition: used, Pressure zone turret, softforming interchangeable profiles for softforming machines, double-end tenoners, edging machines, scoring motor, chipper motor, milling motor for edging machines Kdedpfjb Uhukjx Abnor -HOMAG softforming interchangeable profiles for softforming profiles can be quickly converted to straight edges -with heavy leadership -laterally movable -with counter -HOMAG milling unit for joint milling -with heavy dovetail guide -1x engines Perske -Motor type: -Power: 3.0/4.4 kW -Voltage: 220/380/380 volts -Frequency: 50/100 Hz -Speed: 2860/5860 rpm -Other engines with other services in stock for an additional charge -Dimensions: 1800/1400/H1300 mm -Weight: 712 kg

Condition: used, Pressure zone turret, softforming interchangeable profiles for softforming machines, double-end tenoners, edging machines, scoring motor, chipper motor, milling motor for edging machines -HOMAG softforming interchangeable profiles for softforming profiles can be quickly converted to straight edges -with heavy leadership -laterally movable -with counter -HOMAG milling unit for joint milling -with heavy dovetail guide -1x engines Perske -Motor type: -Power: 3.0/4.4 kW -Voltage: 220/380/380 volts -Frequency: 50/100 Hz -Speed: 2880/5880 rpm -Other engines with other services in stock for an additional charge -Dimensions: 1800/1400/H1300 mm -Weight: 712 kg Kjdpfx Abeb Uhrmsnedr

Condition: used, DALLAN Rollforming machine | Omega profiles 60mm & 80 mm With 11 forming stations, fully equipped and currently set up for Omega 60 mm, the line includes additional tooling for Omega 80 mm profiles. This machine is complete, in excellent condition. DALLAN rollforming line with 11 forming stations: · Maximum sheet width: 300 - 350 mm · Controls: Dual console · Shaft diameter: 60 mm · End unit: Integrated cutting station · Current setup: Configured for classic Omega 60 mm, includes tooling for Omega 80 mm Kdedpfx Ajxugf Hobner · Idle decoiler · Tooling box (approx. 1,000 kg) for producing other profile types · Dimensions: 10,000 x 1,400 x 1,600 mm (L x W x H) · Weight: 10 tons Maximum sheet width: 300 - 350 mm Controls: Dual console Shaft diameter: 60 mm End unit: Integrated cutting station Current setup: Configured for classic Omega 60 mm, includes tooling for Omega 80 mm

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, DESCRIPTION: Complete production process: hydraulic uncoiling, guided feeding, roll forming, hydraulic post-cutting, and automatic run-out/stacking. Profile-specific tooling for TR153 / 290 / 870 high-profile sheets. Full mesh safety guarding around the main forming section. Siemens PLC/HMI control and Schneider frequency-controlled main drives. Kdsdpfezvaibex Abnjr Profile: TR153 / 290 / 870 Standard sheet thickness: 0.70-1.50 mm Feed coil width: 1,500 mm Overall / effective width: 900 mm / 870 mm Profile height / pitch: 153 mm / 290 mm Maximum profile length: unlimited Working speed: 15 m/min Location of the line: Serbia

Condition: excellent (used), Year of construction: 2023, functionality: fully functional, Equipment: documentation/manual, Professional Spiral Duct Forming Machine – Ø80–1600 mm Kdedpfx Aozt Ni Eebner We are offering for sale a complete industrial machine for the production of round spiral ducts (SPIRO ducts) for HVAC, ventilation and dust extraction systems. We are the first owner. The machine was purchased directly from the manufacturer, professionally commissioned, configured and fine-tuned for production. It has only been used occasionally for our own production requirements and has never been operated in continuous or multi-shift mass production. The machine is fully operational, properly adjusted and ready for production. It is currently connected and can be demonstrated under actual production conditions, allowing the buyer to inspect the complete process and the quality of finished ducts before purchase. Key Features * working diameter range: Ø80–1600 mm * production speed: up to 60 m/min * installed power: 11.25 kW * galvanized steel: 0.4–1.2 mm * stainless steel: 0.4–0.7 mm * aluminium: 0.4–1.3 mm * pneumatic sheet metal strip decoiler * touchscreen control panel * automatic lubrication system * automatic forming angle adjustment * automatic rotary cutting * automatic fault detection * smooth ducts or single/double reinforcing beads * external spiral lock seam * machine weight: approx. 2,900 kg 39 Forming Heads Included The machine comes with an extensive set of 39 forming heads covering 22 diameters: Ø80 (1), Ø100 (2), Ø125 (3), Ø160 (3), Ø200 (3), Ø250 (3), Ø315 (3), Ø355 (2), Ø400 (2), Ø450 (2), Ø500 (2), Ø560 (2), Ø630 (2), Ø710 (1), Ø800 (1), Ø900 (1), Ø1000 (1), Ø1120 (1), Ø1250 (1), Ø1400 (1), Ø1500 (1), Ø1600 (1). The set therefore covers the full working range from Ø80 to Ø1600 mm, with additional heads for the most commonly produced diameters. Spare Parts Package A comprehensive package of spare and wear parts is included, such as forming and guiding components, lock-seaming rollers, pneumatic components, cutting knives/rotary cutting components and decoiler braking parts. This provides an important operational reserve and helps minimise downtime without having to immediately source essential parts internationally. Production-Ready + Training The buyer receives a fully configured and proven production machine, not an uncommissioned unit requiring extensive setup and adjustment. We provide on-site commissioning assistance and operator training at the buyer’s facility, including machine operation, forming head replacement, adjustment for different diameters and sheet thicknesses, maintenance and trial production. The machine can be inspected and demonstrated during actual spiral duct production before purchase. Approximately 100 steel stacking racks (Maurack type) for storing and transporting finished ducts are also available and can be purchased together with the machine. The machine is located in Poland. Transport can be arranged individually. Price: upon request / subject to negotiation. For further information, photos, videos or to arrange a live machine demonstration, please contact us directly.

Condition: used, Line for forming cevapcici and cevapi (grinder with mixer, portioning device and belt transporter) Kdodeg Atrvepfx Abnor

Condition: new, functionality: fully functional, Year of construction: 2026, control type: CNC control, degree of automation: automatic, actuation type: electric, laser type: fiber laser, laser power: 12,000 W, sheet thickness (max.): 30 mm, Equipment: CE marking, centralized greasing system, cooling unit, documentation/manual, dust extraction, emergency stop, fume extraction, nozzle changer, safety light barrier, Supports 12m steel pipe cutting Equipped with fully automatic combined loading and unloading system One-stop intelligent loading, cutting and unloading, increasing production efficiency by 200% Supports multiple processes such as beveling, locking, cutting, punching, opening welding holes, cutting bolt holes, marking and marking Laser power 12,000 W – 20,000 W X-axis travel 1,600 mm Y-axis travel 1,900 mm Z-axis travel 900 mm A-axis rotation ±90° C-axis rotation ±90° U-axis travel 30 mm V-axis travel 13,000 mm Positioning accuracy ±0.1 mm Kdedjw A H T Aepfx Abnor Max. workpiece section 1,000 × 400 mm Max. supported weight 5 T Supported profiles H-beam, channel steel, I-beam

Condition: new, Year of construction: 2025, Roll forming metal siding “double façade panel” machine SPM-2 Roll forming metal siding “double façade panel” machine SPM-2 is new design product of our company for façade and wall metal panels forming with the necessary configuration. These double façade panels are very popular in construction business of cladding residential buildings and industrial structures, for the construction of fences of various configurations, gazebos, roofing elements, etc. The SPM-2 metal siding production line is fully automatic and consists of a rolling part of the machine, an automation system and guillotine cutting shears at the machine exit. The line can have as additional parts a manual or automatic uncoiler for metal rolls, depending on the customer's needs. As standard version, this metal siding double façade panels roll forming machine SPM-2 makes a flat panel profile, but with the additional equipment, it is possible to roll panels with a microwave or rib shape profile. To start rolling, it is necessary to install a roll of metal to the decoiler and to put the end of the strip to the first rolling rollers of the equipment and feed it into them. After step by step, to put the metal to the next rollers, adjusting it if necessary. When metal comes to the cutting device of machine you need to feed metal into cutting knives and to make “zero” cut. After such step, equipment can move to automatic operation mode. The control panel of machine has the ability to set the number of tasks and the length of products, single tasks or to work in multitasking mode. After setting up necessary parameters the machine will automatically roll the metal cladding wall panels and cut them into necessary sizes. Thus, the customer will receive final product as quickly as possible and with the highest possible result. The roll forming speed is adjustable and can be up to 10-15 meters per minute. The SPM-2 metal wall cladding panels production line has special tools for punching out fastening holes on the side of the panel. It makes possible for the customer to get more interesting solution options and to offer a wider range of products to the end user. The rolling part of the machine has 18 pairs of forming steps, ensuring high quality of final product. You can get machine with protective cover or without it as per your request preferences. Ksdpfxjxghngo Abnsdr Specifications Material width (mm) 416 The material thickness (mm) 0,4-0,5 Engine power (kW) 3 + 1,1 Rolling speed (m/min) 10-15

Condition: excellent (used), Year of construction: 1994, Weinig 925 Rondomat profile knife grinder Stock code: 15443 Price: request for quotation $ Subcategory: Knife grinders Producer: Weinig Model: 925 Condition: used Tag number: 15443 Machine type: Grinding machines UMCC: G6775 Producer: Weinig Model: 925 Rondomat Year: 1992 Serial number: 925-438 Description: Weinig 925 Rondomat profile knife grinder We offer turnkey services with this machine. Printable page Get a quote General technical data Kdodpfon Ut Sljx Abner Shaft length 9-1/2 inches Maximum tool diameter 9 inches Motor 1.5 HP, 220/440 V 8-7/8 Maximum wheel diameter Variable grinding wheel speeds: 1700, 2000, 2250, 2800 rpm Relief angle for back relief: 15 - 45 degrees Axial: 0 - 10 degrees Cooling liquid

Condition: new, Year of construction: 2025, functionality: fully functional, machine/vehicle number: HB10011N2025006, The machine has not been used yet! MACHINE DETAILS Control: Teach-in Motor power: 4.0 kW Dimensions & Weight Dimensions (L x W x H): 1,300 x 800 x 1,400 mm Unladen weight: 800 kg Transport packages: 1 piece EQUIPMENT Kdedpfszuw D Tox Abnsr Documentation CE marking CE certificate

Condition: used, Adjustable cutters on a hydraulic sleeve for the production of log planks (tongue and groove). Current settings: Groove profile width: 58.45 mm Tongue profile width: 53.25 mm Technical data: - Cutter: HW - Cutting circle (ø): ~ 160 mm - Bore: 50 mm Kedpfx Abezvnbfenjdr - Material: Steel

Condition: used, The scope of delivery includes: 1x steel beam, used Material color: orange Box profile: 130 x 40 mm Agraffe: 4 HK (hooks) Overall length: approx. 2,780 mm Length of box profile: approx. 2,680 mm Note: This is a former pallet rack crossbar that can no longer be used in its current form. If you separate the agraffe here, you will obtain a box profile with a length of approx. 2,680 mm. General information about the item: This item is offered for collection only. Any additional transport or shipping of this item will incur extra costs, which can be requested separately depending on the delivery location and scope of delivery. Kdedjzvlrnopfx Abnor

Condition: excellent (used), Year of construction: 2026, functionality: fully functional, total length: 4,200 mm, spindle speed (min.): 100 rpm, spindle speed (max.): 1,000 rpm, total height: 2,800 mm, total width: 2,300 mm, overall weight: 13,000 kg, power: 28 kW (38.07 HP), New hydraulic hose New seals New covers Optional retrofitting possible New controller New PLC – SIEMENS Main power: 28 kW Steel telescopic covers CE safety fence with door Optional tooling for parabolic 1200 mm Previous owner machined 3 mm aluminum parts Commissioning, training, tool, and installation possible!! Max. blank/workpiece size over bed: 1500 Center height over bed: 750 mm Distance between centers: 1225 mm Maximum sheet thickness: 7 mm Kdodjzvf N Topfx Abnsr Stroke X-axis: 360 mm Stroke Y-axis: 800 mm Speed range: 100 - 1000 rpm Power: 28 kW Spindle taper headstock: 11 DIN / Camlock Stroke tailstock quill: 300 mm Length: 4200 mm Width: 2300 mm Height: 2800 mm Weight: 13000 kg

Condition: new, clear span: 2,700 mm, total length: 2,760 mm, The scope of delivery includes: 1x Push-through protection, new Type: universal Suitable for field width: 2,700 mm Customs tariff number: 73066192 Steel grade: S235 | S275 Consisting of EACH: 1 x Square tube, new Material color: hot-dip galvanized Dimensions: 50x50x2.0 mm Weight: 3.26 kg | per meter Tube length: approx. 2,760 mm 2x Angle bracket, new Material color: sendzimir galvanized Design: Holding device Profile dimensions: 155 x 120 mm Headplate: 120 x 40 mm Overhang: 75 mm Design: 90 degrees Opening for square tube: 51 x 51 mm Material thickness: 3.00 mm Weight / piece: 0.460 kg Incl. each: 4 x Screws, M8 x 20 mm 4 x Nuts, M8 4 x Washers, M8 2 x Drill screws, self-tapping 25 mm You can also request the following lengths: (For field width:) 1,350 mm = 19.00 € plus 19% VAT 1,800 mm = 26.00 € plus 19% VAT Kedpfxjzu Stcj Abnedr 1,900 mm = 27.00 € plus 19% VAT 2,000 mm = 29.00 € plus 19% VAT 2,100 mm = 30.00 € plus 19% VAT 2,200 mm = 31.00 € plus 19% VAT 2,300 mm = 33.00 € plus 19% VAT 2,400 mm = 34.00 € plus 19% VAT 2,500 mm = 36.00 € plus 19% VAT 2,600 mm = 37.00 € plus 19% VAT 2,800 mm = 40.00 € plus 19% VAT 2,900 mm = 41.00 € plus 19% VAT 3,000 mm = 42.00 € plus 19% VAT 3,100 mm = 44.00 € plus 19% VAT 3,300 mm = 47.00 € plus 19% VAT 3,600 mm = 51.00 € plus 19% VAT 3,900 mm = 55.00 € plus 19% VAT 4,300 mm = 61.00 € plus 19% VAT General information about the article: This article is only offered for collection. Any additional transport or shipment of this article will incur additional costs, which can be requested separately depending on the delivery location and scope of delivery.

Condition: used, Buchformpresse / Book Forming Press Kolbus FE Kjdpjzu Dnlofx Abnodr Online-Video-Inspection by WhatsApp - MS Zoom - Telegram On Stock Emskirchen/Nürnberg - Available Immediately - Can be test

Condition: used, angle steel/side length / mm double T-iron on the x-axis / mm U-iron on the x-axis / mm BPR Brescia – Model C-602-HE, hydraulic 3-roll profile and pipe bending machine Technical Data BPR C-602-HE Specifications Manufacturer BPR – Brescia, Italy Model C-602-HE Type Hydraulic 3-roll bending machine Kdjdpfx Abszu A U Djnjr Operation Horizontal and vertical Number of rolls 3 Roll diameter 100 mm Shaft diameter 60 mm Shaft length 150 mm Max. roll spacing (center-to-center) 400 mm Motor power 2.2 kW Mains voltage 380 V Dimensions approx. 850 × 1,120 × 1,700 mm Weight approx. 1,100 kg Hydraulic feed Yes Rotation direction Clockwise/counter-clockwise Information subject to change / without guarantee

Condition: new, clear span: 2,700 mm, total length: 2,780 mm, The scope of delivery includes: 1x Push-through safety device, new Type: universal Suitable for field width: 2,700 mm Customs tariff number: 73066192 Consisting of EACH: 1 x Rectangular tube, 2nd choice (new goods) Material color: RAL 5010 blue Dimensions: 50x40x2.0 mm Weight: 2.64 kg | per meter Borehole diameter: 9 mm Tube length: 2,780 mm Center-to-center distance: 2,740 mm 2x Corner angle bracket, new Material color: sendzimir galvanized Design: Mounting bracket Profile dimensions: 155 x 120 mm Head plate: 120 x 40 mm Overhang: 75 mm Design: 90 degrees Opening for square tube: 51 x 51 mm Material thickness: 3.00 mm Weight / piece: 0.460 kg Incl. each: 4 x Screws, M8 x 20 mm 4 x Nuts, M8 4 x Washers, M8 2 x Screws, M6 2 x Nuts 2 x Washers You can also request the following additional lengths: (For field width:) 1,350 mm = €18.00 plus 19% VAT 1,800 mm = €23.00 plus 19% VAT 1,900 mm = €25.00 plus 19% VAT 2,000 mm = €26.00 plus 19% VAT 2,100 mm = €27.00 plus 19% VAT 2,200 mm = €28.00 plus 19% VAT 2,300 mm = €29.00 plus 19% VAT 2,400 mm = €31.00 plus 19% VAT 2,500 mm = €32.00 plus 19% VAT 2,600 mm = €33.00 plus 19% VAT 2,800 mm = €36.00 plus 19% VAT 2,900 mm = €37.00 plus 19% VAT Kedpfx Aszu Andobnjdr 3,000 mm = €38.00 plus 19% VAT 3,100 mm = €39.00 plus 19% VAT General information about the item: This item is offered for pick-up only. Any additional transport or shipping of this item will incur extra costs, which can be requested separately depending on the delivery location and scope of delivery.

Condition: used, Year of construction: 2019, - 6 working spindles - max. working width 250 mm - feed rate 6 - 24 m/min used planing and profiling machine Manufacturer: HOMAG Kjdpfjzuzf Uex Abnedr Type: Optimat LPP306 Year of construction: 2019 OPTIMAT LPP306 Planing and profiling machine with 6 working spindles. Workpiece width after processing: - min. 10 mm - max. 250 mm Workpiece height after processing: - min. 10 mm - max. 160 mm Control system: - PowerControl with powerTouch LPP300 Infeed table 2,500 mm Feed rate min. 6 m/min max. 24 m/min FIRST LOWER SPINDLE: - Spindle motor power 7.5 kW - Siemens IE3 energy-saving motor Power speed range: - 7.5 kW - 6,000 rpm Spindle diameter 40 mm Spindle length 281 mm FIRST RIGHT SPINDLE: Spindle motor power 7.5 kW, adjustable - Siemens IE3 energy-saving motor - Spindle speed continuously adjustable Power speed range: - 7.5 kW - 4,000 rpm - up to 8,000 rpm Spindle diameter 40 mm Spindle length 176 mm FIRST LEFT SPINDLE: Spindle motor power 7.5 kW, adjustable - Siemens IE3 energy-saving motor - Spindle speed continuously adjustable Power speed range: - 7.5 kW - 4,000 rpm - up to 8,000 rpm Spindle diameter 40 mm Spindle length: 176 mm Total length: 176 mm FIRST UPPER SPINDLE: - Spindle motor power 7.5 kW, adjustable - Siemens IE3 energy-saving motor - Spindle speed continuously adjustable Power speed range: - 7.5 kW - 4,000 rpm - up to 8,000 rpm Spindle diameter 40 mm Spindle length 266 mm SECOND UPPER SPINDLE: Spindle motor power 7.5 kW, adjustable - Siemens IE3 energy-saving motor - Spindle speed continuously adjustable Power speed range: - 7.5 kW - 4,000 rpm - up to 8,000 rpm SECOND LOWER SPINDLE: Spindle motor power 7.5 kW, adjustable - Siemens IE3 energy-saving motor - Spindle speed continuously adjustable Power speed range: - 7.5 kW - 4,000 rpm - up to 8,000 rpm Spindle diameter 40 mm Spindle length 266 mm Note: The technical data and descriptions are a transcript of the original order confirmation. Data is for informational purposes only and is not binding.

Condition: used, Year of construction: 2008, Profiling machine Manufacturer: SCM Type: Superset NTE Year of construction: 2008 Technical data - Touchscreen control for the machine with 6 spindles + UNIWAVE - Spindle speed 8,300 rpm - Working width 240 mm, working height 125 mm, electronic - Touchscreen control MOBILE 10 - HSK 85S - SPINDLE QUICK-CHANGE SYSTEM T-SET - QUICK-CLAMPING DEVICE for tools - 7 shafts as a UNIWAVE, suitable for separating - 2 feed units after the upper spindles to reduce the center distance from 620 to 450 mm - Motor-driven feed roller in the working table, basic equipment for forced lubrication, electronic horizontal positioning, electronic adjustment of the tool diameter (setup) - Manual pump for lubricating the working table - WITH machining tool - Min. working width (finished size) mm 15 - Max. working width (finished size) mm 240 - Min. length of the individual workpiece mm 450 - Feed speed controlled via inverter 6 - 36 m/min, feed motor power kW 4 - Motor power surfacing spindle kW 7.5, quick-clamping device - Motor power vertical spindle right kW 7.5, Powerlock HSK 85 - Motor power vertical spindle left kW 7.5, Powerlock HSK 85 - Motor power upper horizontal spindle kW 7.5, quick-clamping device - Motor power 2nd upper horizontal spindle kW 7.5, Powerlock HSK 85 - Motor power lower horizontal spindle kW 7.5, Powerlock HSK 85 - Motor power universal spindle kW 7.5, quick-clamping device - Spindle speed rpm 6000/8300 - Spindle diameter mm 40 - Spindle receiving length vertical mm 220 - Spindle receiving length horizontal mm 250 - Axial adjustment range of the vertical spindles standard mm 75 - Axial adjustment range of the horizontal spindles standard mm 45 min. max. - Sweeping circle diameter of the surfacing cutter mm 120/140 mm min. max. - Sweeping circle diameter of the profiling spindles mm 100/200 - Profiling depth of the 2nd lower shaft with a tool diameter of mm 200 mm 15 - Diameter of the spindle cylinders mm 120 - Diameter of the feed rollers mm 140 Ksdpfxozuzfhj Abnsdr - Infeed table length mm 2500 - Adjustment range of the infeed table and infeed fence 10 mm - Motor-driven feed roller in the outfeed table - Manual central lubrication - On/off switch for the feed unit before the surfacing cutter - Horizontal pressure pads before the surfacing cutter with on/off switch - Pressure shoes at the front on the protective cover of the horizontal spindle(s), hardened insert in the working table in front of the surfacing cutter - Pneumatic pressure shoes in front of the upper horizontal spindles - Horizontal pressure device in front of the surfacing cutter, can be switched on from the control panel - 2 feed rollers 140 x 25 per feed shaft - Lighting inside the protective cover - Extraction capacity min. 10,443 m3/h - Including extraction hood! - Including Powerlock mounting bracket - All 240 mm heads, horizontally arranged, and fixed tools on HSK spindles are included. - Spare parts catalog: Complete, 8 PDF catalogs available Note: Not all tools shown are part of this offer. Note: The technical data and descriptions are copies of the original order confirmation. The information is provided for informational purposes only and is not binding.

Condition: used, Year of construction: 1997, Profiling line, consisting of DEP Gabbiani + Weinig planing machine DEP Manufacturer: Gabbiani Type: T-Module 80/1600 Year of manufacture: 1997 Planing machine Manufacturer: Weinig Type: 22 BL Year of manufacture: 1995 Kdsdpfozuzfbex Abnjr Technical data of the DEP - 6 machining motors per side - 2 fixed scoring units, 3.2 HP / 3000 + 4500 RPM - 2 chip-removing units: 12.5 HP / 3000 + 4500 RPM - 2 chip-removing units: 12.5 HP / 3000 + 4500 RPM - 2 slotting units: 12.5 HP / 3000 + 4500 RPM - 2 free spaces - 1 feed motor: 4 HP / 1400 RPM Angle transfer between DEP and planing machine - Length: 290 - 1600 mm (1800 mm) - Width: 18 - 150 mm - Thickness: 5.5 - 50 mm - Density: 600 kg/m³ - Output max.: 150 workpieces/min - Belt conveyor after the double-end profiler - Toothed belt conveyor with brush attachment as counter holder - Cam conveyor for singulation - Toothed belt conveyor as buffer section - Longitudinal discharge - Roller conveyor before the planing machine - Control: Vipa, compatible with Siemens S7 300 - Safety technology Protective door switches: 3 Safety light barriers: 1 Technical data of the planing machine Working width and working height - Working width: 20 - 230 mm (with tool diameter 125 mm) - Working height: 9 - 140 mm (with tool diameter 125 mm) Infeed table - Length: 2000 mm - Adjustment range of the jointer table: 10 mm - Adjustment range of the fence: 10 mm Surfacing table - Length: 1200 mm - Adjustment range of the table: 10 mm - Adjustment range of the fence: 10 mm Jointer spindle - Motor power: 5.5 - 15 kW Thicknessing spindle - Motor power: 5.5 - 11 kW Left spindle - Motor power: 5.5 - 11 kW 2. Right spindle - Motor power: 5.5 - 11 kW Top spindle - Motor power: 5.5 - 22 kW Bottom spindle - Motor power: 5.5 - 22 kW Universal spindle - Motor power: 5.5 - 11 kW Feed - Cardan feed, continuously adjustable: approx. 6-36 m/min - Motor power: 4 - 8.6 kW Note: The technical data and descriptions are a transcript of the original order confirmation. The data is for informational purposes only and is not binding.
