Used Plastic Injection Molding Machine for sale (85,921)

Condition: good (used), Year of construction: 2006, operating hours: 58,401 h, machine/vehicle number: 61007671, Technical details Clamping force: 4200 kN Size of mould platens (H x V): 800 mm x 800 mm Mould opening stroke: 1020 mm Minimum mould height: 380 mm Maximum mould height: 1400 mm Max daylight: 1380 mm Hydraulic ejector – stroke: 250 mm Ejector force forward/backward: 95 kN Injection unit Screw diameter: 80 mm Injection pressure: 1829 bar Stroke volume: 1433 ccm Shot weight PS: 513 g Screw speed: 218 1/min Bdodpfexzdqajx Ab Tek Maximum plasticising rate: 108 g/sec

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 194573, clamping force: 1,000 kN, screw diameter: 30 mm, injection pressure: 2,500 bar, opening stroke: 500 mm, plate length: 570 mm, TECHNICAL DETAILS Clamping force: 1,000 kN First injection unit Screw diameter: 30 mm Shot weight: 65 g Shot volume: 78 cm³ Injection pressure: 2,210 bar Second injection unit Screw diameter: 25 mm Shot weight: 45 g Shot volume: 54 cm³ Injection pressure: 2,500 bar Tie bar spacing: 420 x 420 mm Platen size: 570 x 570 mm Opening stroke: 500 mm Maximum daylight between platens: 850 mm Mold height: 350 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 4.63 x 1.3 x 3.9 m Weight: 4,000 kg Connected load: 125 A EQUIPMENT Bedjxx T Dwspfx Ab Tjdk 2 x core pull (simultaneous movement, adjustable holding pressure) Intermediate stop for hydraulic rotary control CF card drive Host computer interface Input device interface Conveyor belt interface Machine prepared for Multilift Selector unit with connection Installation height expanded to 350 mm Highly wear-resistant screws Connection for air blow-off device 2-color / horizontal-vertical injection unit Includes disks/CF cards – complete documentation/manuals

Year of construction: 2005, condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 291257-100, MACHINE DETAILS Net weight: 23,500 kg / 8,500 kg Hydraulics – Operating pressure: 231 bar Electrical data Motor rated current: 109 A Bdodpfx Absxyizhs Tsk Control voltage: 230 V Frequency: 50 Hz

Condition: ready for operation (used), Year of construction: 2007, operating hours: 64,291 h, functionality: fully functional, clamping force: 1,200 kN, screw diameter: 35 mm, displacement volume: 154 cm³, injection pressure: 1,595 bar, installation height: 300 mm, TECHNICAL DETAILS Clamping force: 1,200 kN Screw diameter: 35 mm Shot volume: 154 cm³ Injection pressure: 1,595 bar Platen size: 740 mm x 470 mm Bsdpfx Abexzfl So Tedk Minimum mold height: 300 mm Maximum platen distance: 800 mm Opening stroke: 507 mm MACHINE DETAILS Control system: CC100 Dimensions & Weight Machine dimensions (L x W x H): 4.35 m x 2.2 m x 2.1 m Total weight: 7,300 kg Operating hours: 64,291 h EQUIPMENT Screen language German & English CEE socket 16 A Hydraulic core pull 2x Handling unit Conveyor belt Safety enclosure Levelling elements EUROMAP 12 interface Interface for ejector plate monitoring Schuko socket 10 A

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: 133404-100, clamping force: 3,000 kN, screw diameter: 55 mm, injection pressure: 2,040 bar, injection weight: 600 g, TECHNICAL DETAILS Clamping Unit Clamping force: 3,000 kN Platen size (H x W): 1,020 x 1,030 mm Tie bar spacing (H x W): 710 x 610 mm Minimum mould height: 375 mm Maximum mould height: 375 mm Maximum opening stroke: 1,150 mm Injection Unit Screw diameter: 55 mm Shot volume: 653 cm³ Shot weight: 600 g Bjdpfjx A Df Tjx Ab Todk Injection pressure: 2,040 bar MACHINE DETAILS Weight: 12,200 kg

Condition: ready for operation (used), functionality: fully functional, clamping force: 800 kN, clearance between the columns: 1,200 mm, ARBURG 1200 T 800-150 MACHINE DETAILS Operating Hours Bjdsx Af S Uspfx Ab Todk Machine Cycles: 2,426,431 Pump Operating Hours: 38,226 h Automatic Operation Hours: 30,517 h FTP ATR-25 Q MACHINE DETAILS Weight: 1,400 kg Note: Further information regarding the machine configuration can be found in the attached document.

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, clamping force: 3,188 kN, injection weight: 6,935 g, screw conveyor diameter: 130 mm, production capacity: 17,000 unit/h, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Clamping force: 320 t Shot weight: 6,935 g Screw diameter: 130 mm Performance: 17,000 preforms/h Bsdpjx A Efhjfx Ab Todk MACHINE DETAILS Configuration: 72-cavity, 4-stage EQUIPMENT Take-out unit Conveyor belt LT/h 1825 TPS robot TRT-M4-72-E

Condition: excellent (used), Year of construction: 2006, operating hours: 45,200 h, 1,0 St. gebr. Spritzgießmaschine mit Roboter Hersteller: KRAUSS MAFFEI Typ: KM200-700C2 Baujahr: 2006 Schließkraft: 200 Tonnen Holmabstand 560 x 560 mm Schnecken DN: 45 mm Max. Hubvolumen: 305 cm³ Spritzteilgewicht: 278 g/PS Steuerung: MC5 Ausstattung: Roboter GHS Baujahr: 2004 Verschleißarme Plastifizierung Bjdpexpnpiofx Ab Tedk 1 St. Kernzug 1 St. Förderband Sicherheitszaun Ca. 45.300 Betriebsstunden

Condition: good (used), Year of construction: 2023, operating hours: 50 h, Brand: Dr.Boy Model: 60E Year of construction: 2023 Operating hours: 50 Screw diameter: 32 mm Max. injection pressure: 2,142 bar Max. shot volume: 100.5 cm³ Clamping force: 60 t Max. distance between tie-bars: 360 x 335 mm Min. mould height: 250 mm Max. distance between platens: 650 mm Dimensions: 3,450 x 1,150 x 1,950 mm Weight: 2,250 kg Bodpfxjx Aphts Ab Tjdk Options: • Procan ALPHA 4 display • Hydraulic core pull (2x) • Air valve (2x) • Interface package (incl. RS232/485, OPC-UA + licence fee) • 4 Freely programmable AIO's • Robot interface Euromap 67 • Interface between safety fence and machine Euromap 78 • Colouring contact interface • Quick change mould package – Cooling circuits (3x) on fixed and moving platen – 8-way water manifold – Ejector with quick coupling – Open nozzle with threaded tip • 6-way energy distribution box (supply via second cable) – 3x 400V – 3x 220V • Oil filling (Econfluid, ISO-32)

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, clamping force: 1,300 kN, screw diameter: 55 mm, displacement volume: 510 cm³, injection pressure: 1,650 bar, ejector force: 61,000 N, Injection moulding machine, function-tested and immediately ready for operation by an Engel specialist technician! Inspection with dry run possible at any time. TECHNICAL DETAILS Clamping force: 1,300 kN Screw diameter: 55 mm Shot volume: 510 cm³ Injection pressure: 1,650 bar Ejector force: 61,000 N Ejector stroke: 150 mm Platen length: 750 mm Platen width: 750 mm Opening stroke: 600 mm Screw length: 20 l/d Minimum mould installation height: 300 mm Maximum platen distance: 900 mm Bdjdpsxzfkbsfx Ab Tok Daylight: 900 mm MACHINE DETAILS Control system: CC200 Power supply type: Three-phase current Input frequency: 50 Hz Input voltage: 400 V Dimensions & Weight Machine dimensions (L x W x H): 5.8 m x 1.7 m x 2.3 m Total weight: 9,500 kg Operating hours: 24,896 h EQUIPMENT Documentation/manual Display language: German CEE socket 16A Hydraulic core pull 1x Water manifold Levelling elements EUROMAP 67 interface Interface for ejector plate monitoring Schuko socket 10A Mould heating 8x Note: The machine is sold without material hopper and safety guarding.

Condition: ready for operation (used), Year of construction: 2005, operating hours: 112,163 h, functionality: fully functional, clamping force: 2,700 kN, screw diameter: 55 mm, injection pressure: 2,040 bar, ejector stroke: 200 mm, TECHNICAL DETAILS Clamping unit Clamping force: 2,700 kN Platen size (H x W): 1,030 x 1,020 mm Tie bar spacing (H x W): 710 x 630 mm Min./max. mould height: 350 mm Max. opening stroke: 1,150 mm Locating ring diameter: 160 mm Ejector stroke: 200 mm Bsdpfjx A Dbbsx Ab Tsdk Injection unit Screw diameter: 55 mm Shot volume: 650 cm³ Shot weight: 565 g Injection pressure: 2,040 bar Max. injection speed: 144 mm/s MACHINE DETAILS Operating hours: 112,163 h EQUIPMENT Pneumatic valve Core pulls (3 pcs.)

Condition: excellent (used), Year of construction: 2007, operating hours: 20,357 h, functionality: fully functional, clamping force: 600 kN, screw diameter: 25 mm, displacement volume: 59 cm³, injection weight: 56 g, overall weight: 6,000 kg, Equipment: documentation/manual, Here we offer the following well-maintained used injection moulding machine as part of our injection moulding machine dealership. Of course, we are also actively purchasing well-maintained injection moulding machines from model year 2010 onwards. We have been a wholesale supplier of used injection moulding machines for over 25 years. Current note – Tax information and benefit for used machines: As of 01.07.2025, used machines may also be depreciated using the special 30% annual depreciation allowance. In addition to the lower purchase cost compared to a new machine, you can claim the same depreciation amounts as for a new machine. Reference: Growth Booster (§ 7 Section 2 EStG-E) Vertical injection moulding machine – thermoplastics, with rotary table, 2 or 4 stations Manufacturer: Battenfeld Model: Vertikal R 60 / 125 H Control: B4 Year: 2007 Bdodpsx Ak I Ijfx Ab Tok Machine number: 130953 – 100 Vertical machine with rotary table / 2-4 stations (750 mm) Operating hours: 20,357 h Injection unit (125) Screw diameter: 25 mm Screw length: 21.6 L/D Shot volume: 58.9 cm³ Shot weight: 53.6 g Heating capacity: 6.78 kW Heating zones: 4 Nozzle stroke: 200 mm Injection pressure: 2,149 bar Clamping unit Clamping force: 60 tons / 600 kN Opening stroke: 250 mm Min. mould installation height: 250 mm Ejector stroke: 150 mm Max. platen distance: 500 mm Rotary table diameter: 1,040 mm Weight: 6,000 kg Extras: - Light curtain - Automatic suction loader Simar FX 2504, year 2013 - Water manifold - Air valve

Condition: excellent (used), Year of construction: 2009, operating hours: 63,700 h, 1,0 St. gebr. Spritzgießmaschine Hersteller: ARBURG Typ: 270S400-70 Baujahr: 2009 Schließkraft: 40 Tonnen Holmabstand 270 x 270 mm Schnecken DN: 18 mm Dosiervolumen: 23 ccm³ Spritzteilgewicht 21 g/PS Steuerung: SELGOCIA Ausstattung: Bsdpfsxq R D Esx Ab Tjdk -Schnittstelle Roboter -Vertikale Einspritzung Betriebsstunden: ca. 63.700 Hours

Condition: ready for operation (used), Year of construction: 2005, operating hours: 64,218 h, functionality: fully functional, clamping force: 2,000 kN, screw diameter: 50 mm, clearance between the columns: 520 mm, displacement volume: 392 cm³, injection pressure: 2,000 bar, TECHNICAL DETAILS Clamping force: 2,000 kN Screw diameter: 50 mm Tie bar distance: 520 mm Shot volume: 392 cm³ Injection pressure: 2,000 bar Mould height (h x v): 520 x 520 mm Platen size (h x v): 728 x 728 mm Minimum installation height: 250 mm Maximum platen opening: 900 mm Opening stroke: 650 mm MACHINE DETAILS Control system: Selogica Dimensions & Weight Machine dimensions (L x W x H): 5.45 m x 1.95 m x 2.1 m Total weight: 7,300 kg Operating hours: 64,218 h Bdsdpfxsxzfh Te Ab Tek EQUIPMENT Screen language: German CEE socket 16A Hydraulic core pull 1x Pneumatic core pull 1x Air valve 1x Water battery Levelling elements EUROMAP 12 interface Interface for handling Schuko socket 10A Mould heating 12x Note: Machine is sold without material hopper.

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, machine/vehicle number: 134022-100, clamping force: 3,000 kN, screw diameter: 60 mm, injection pressure: 2,040 bar, injection weight: 840 g, TECHNICAL DETAILS Clamping Unit Clamping force: 3,000 kN Platen size (H x W): 1,020 x 1,030 mm Tie bar distance (H x W): 710 x 630 mm Minimum/maximum mold height: 375 mm Maximum opening stroke: 1,175 mm Bsdpfox A A S Esx Ab Tsdk Injection Unit Screw diameter: 60 mm Shot volume: 913 cm³ Shot weight: 840 g Injection pressure: 2,040 bar MACHINE DETAILS Net weight with control cabinet: 12.2 t EQUIPMENT The machine can be inspected and tested under power. Additional photos and videos available upon request. Loading and transport can be arranged.

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, clamping force: 1,100 kN, screw diameter: 40 mm, clearance between the columns: 470 mm, displacement volume: 217 cm³, injection pressure: 2,377 bar, The machine has been partially refurbished and is ready for immediate use! The clamping side has been completely refitted with new seals and two almost new tie bars have been installed! TECHNICAL DETAILS Clamping force: 1,100 kN Screw diameter: 40 mm Distance between columns: 470 mm Shot volume: 217 cm³ Ejector force: 22,000 N Ejector stroke: 150 mm Clear opening: 900 mm Injection pressure: 2,377 bar Opening stroke: 600 mm Platen length: 770 mm Platen width: 745 mm Minimum mould height: 300 mm Maximum daylight: 900 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 4,400 x 1,500 x 2,120 mm Total weight: 6,000 kg Bodpfxjxzfg No Ab Tedk Power supply type: Three-phase current Input frequency: 50 Hz Input voltage: 400 V EQUIPMENT Documentation / manual Display language: German CEE socket 16 A CEE socket 32 A Hydraulic core pull 2x Air valve, movable WAP Levelling elements EUROMAP 12 interface Schuko socket 10 A Note: The machine is sold without a material hopper and water battery.

Condition: ready for operation (used), Year of construction: 2014, operating hours: 47,000 h, functionality: fully functional, machine/vehicle number: 135541-100, clamping force: 3,500 kN, screw diameter: 65 mm, injection pressure: 2,070 bar, ejector stroke: 200 mm, controller model: B6P, TECHNICAL DETAILS Clamping Unit Clamping force: 3,500 kN Platen size (H × W): 1,030 × 1,140 mm Tie bar spacing (H × W): 710 × 710 mm Min. / Max. mould height: 300 / 710 mm Max. opening stroke: 1,380 mm Centring ring diameter: 160 mm Ejector stroke: 200 mm Injection Unit Screw diameter: 65 mm Shot volume: 1,171 cm³ Shot weight (PS): 1,078 g Injection pressure: 2,070 bar Max. injection speed: 600 mm/s MACHINE DETAILS Bdsdpox A A E Eefx Ab Tjk Control: B6P Operating hours: 47,000 h EQUIPMENT 4 pneumatic valves 1 core puller

Condition: ready for operation (used), Year of construction: 2010, operating hours: 54,872 h, functionality: fully functional, clamping force: 2,500 kN, screw diameter: 55 mm, clearance between the columns: 630 mm, displacement volume: 570 cm³, injection pressure: 2,387 bar, TECHNICAL DETAILS Bedexzd R Tepfx Ab Tsdk Clamping force: 2,500 kN Injection pressure: 2,387 bar Screw diameter: 55 mm Tie bar spacing: 630 mm Shot volume: 570 cm³ Ejector force: 58,000 N Ejector stroke: 200 mm Opening stroke: 820 mm Mold size H x V: 630 x 630 mm Platen size H x V: 995 x 1,050 mm Minimum mold height: 330 mm Maximum daylight: 1,150 mm MACHINE DETAILS Control system: MC5 Dimensions & Weight Dimensions (L x W x H): 6,500 x 2,200 x 2,300 mm Total weight: 15,000 kg Input frequency: 50 Hz Input voltage: 400 V Operating hours: 54,872 h EQUIPMENT Documentation/manual 2x temperature control units for hot runner Screen text: German CEE socket 16A Accumulator for increased injection performance + ejector or core pull parallel operation Hydraulic core pull 1x Air valve 4x Material hopper Water manifold Leveling elements EUROMAP 12 interface EUROMAP 67 interface USB interface Schuko socket 10A Wear-resistant plasticizing unit Note: Machine is sold without handling unit.

Condition: ready for operation (used), Year of construction: 2014, operating hours: 49,462 h, functionality: fully functional, clamping force: 3,500 kN, screw diameter: 65 mm, injection pressure: 2,070 bar, ejector stroke: 200 mm, controller model: B6P, The toggle lever mechanism has been completely overhauled! TECHNICAL DETAILS Clamping Unit Clamping force: 3,500 kN Platen dimensions (H x W): 1,030 x 1,140 mm Tie bar spacing (H x W): 710 x 710 mm Minimum mould height: 300 mm Maximum mould height: 710 mm Maximum opening stroke: 1,380 mm Centerring diameter: 160 mm Ejector stroke: 200 mm Injection Unit Screw diameter: 65 mm Shot volume: 1,171 cm³ Bdedpfjx A A Akjx Ab Tsk Shot weight (PS): 1,078 g Injection pressure: 2,070 bar Maximum injection speed: 600 mm/s MACHINE DETAILS Control system: B6P Operating hours: 49,462 h EQUIPMENT Pneumatic valves: 4 units Cores: 2 units Toggle lever mechanism completely overhauled

Condition: ready for operation (used), Year of construction: 2018, operating hours: 9,585 h, functionality: fully functional, clamping force: 1,600 kN, screw diameter: 55 mm, clearance between the columns: 520 mm, displacement volume: 523 cm³, injection pressure: 1,904 bar, TECHNICAL DETAILS Clamping force: 1,600 kN Screw diameter: 55 mm Tie bar spacing: 520 mm Injection pressure: 1,904 bar Mold dimensions (h x v): 520 x 470 mm Platen size (h x v): 710 x 660 mm Shot volume: 523 cm³ Ejector force: 33,000 N Ejector stroke: 150 mm Minimum mold height: 200 mm Maximum mold height: 600 mm Opening stroke: 1,050 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 6,700 x 1,600 x 2,300 mm Total weight: 10,900 kg Power supply type: Three-phase current Operating hours: 9,585 h EQUIPMENT Display language German CEE socket 16 A CEE socket 32 A Accumulator for increased injection performance 3 freely programmable inputs and outputs each Core pull pneumatic 2x Water manifold Levelling elements Interface for dosing unit Interface for temperature control unit USB interface Schuko socket 10 A Low-wear plasticizing unit Bdjdpfx Aoxzd Nvjb Tek Tool heating 24x Note: Machine is sold without material hopper.

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: X66609, clamping force: 6,600 kN, screw diameter: 84 mm, injection pressure: 1,650 bar, ejector stroke: 300 mm, controller model: CDS700, TECHNICAL DETAILS Clamping unit Clamping force: 6,600 kN Platen size (H x W): 1,370 x 1,370 mm Tie bar spacing (H x W): 900 x 900 mm Minimum/maximum mold height: 300 - 900 mm Maximum opening stroke: 1,840 mm Centering ring diameter: 200 mm Ejector stroke: 300 mm Injection unit Bdjdsx A Awzopfx Ab Tsk Screw diameter: 84 mm Shot volume: 2,575 cm³ Shot weight (PS): 2,369 g Injection pressure: 1,650 bar Maximum injection speed: 500 mm/s MACHINE DETAILS Control system: CDS700 Clamping unit weight: 25,400 kg Injection unit weight: 7,000 kg EQUIPMENT Pneumatic valves (6 pcs.) Core pull (1 pcs.)

Condition: ready for operation (used), Year of construction: 2008, operating hours: 49,673 h, functionality: fully functional, clamping force: 800 kN, screw diameter: 35 mm, clearance between the columns: 520 mm, ejector force: 22,000 N, ejector stroke: 100 mm, Function-tested and immediately ready for operation by service for Krauss Maffei injection moulding machines! Inspection with dry run possible at any time. TECHNICAL DETAILS Bdodpfx Asxzd Ixeb Tek Clamping force: 800 kN Screw diameter: 35 mm Tie bar spacing: 520 mm Shot volume: 154 cm³ Injection pressure: 2,429 bar Ejector force: 22,000 N Ejector stroke: 100 mm Platen length: 740 mm Platen width: 640 mm Mould mounting height: 300 mm Max. platen distance: 790 mm Tie bar dimensions (h x v): 520 x 420 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 5,350 x 1,700 x 2,000 mm Total weight: 6,500 kg Supply power type: three-phase current Input frequency: 50 Hz Operating hours: 49,673 h EQUIPMENT Documentation/Manual On-screen text in German CEE socket 16A 1x air valve Material hopper Water manifold Levelling elements EUROMAP 67 interface USB interface Schuko socket 10A Tool heating 24x

Condition: ready for operation (used), Year of construction: 2015, functionality: fully functional, machine/vehicle number: X88628, clamping force: 6,600 kN, screw diameter: 84 mm, injection pressure: 1,650 bar, ejector stroke: 300 mm, controller model: CDS700, The cylinder, screw, and screw tip of the injection system were replaced a year ago! TECHNICAL DETAILS Clamping Unit Clamping force: 6,600 kN Platen size (H x W): 1,370 x 1,370 mm Tie bar spacing (H x W): 900 x 900 mm Minimum mold height: 400 mm Maximum mold height: 1,125 mm Maximum opening stroke: 2,065 mm Bsdsx A Avqopfx Ab Todk Centering ring diameter: 200 mm Ejector stroke: 300 mm Injection Unit Screw diameter: 84 mm Injection volume: 2,575 cm³ Shot weight (PS): 2,369 g Injection pressure: 1,650 bar Maximum injection speed: 500 mm/s MACHINE DETAILS Control system: CDS700 Weight of clamping unit: 29,300 kg Weight of injection unit: 7,700 kg EQUIPMENT Pneumatic valves (4 pcs) Cores: (1 pc)

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, machine/vehicle number: X81559, clamping force: 9,000 kN, screw diameter: 115 mm, injection pressure: 1,740 bar, ejector stroke: 300 mm, controller model: CDS700, TECHNICAL DETAILS Clamping Unit Clamping force: 9,000 kN Platen size (H x W): 1,570 x 1,560 mm Tie bar spacing (H x W): 1,010 x 1,010 mm Min. mold height: 300 mm Max. mold height: 1,190 mm Max. opening stroke: 2,290 mm Centerring diameter: 250 mm Ejector stroke: 300 mm Injection Unit Screw diameter: 115 mm Shot volume: 6,232 cm³ Shot weight (PS): 5,733 g Injection pressure: 1,740 bar Max. injection speed: 300 mm/s MACHINE DETAILS Control system: CDS700 Weight of clamping unit: 44,500 kg Weight of injection unit: 20,000 kg Bodpox A At Njfx Ab Tjdk EQUIPMENT Pneumatic valves (6 pcs.) Core pulls (1 pc.)

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, machine/vehicle number: X81456, clamping force: 9,000 kN, screw diameter: 98 mm, injection pressure: 1,650 bar, ejector stroke: 300 mm, controller model: CDS700, Injection molding machine including Sytrama robot! TECHNICAL DETAILS Clamping Unit Clamping force: 9,000 kN Platen size (H × W): 1,570 × 1,560 mm Tie bar spacing (H × W): 1,010 × 1,010 mm Min. mold height: 300 mm Max. mold height: 1,190 mm Max. daylight: 2,290 mm Locating ring diameter: 250 mm Ejector stroke: 300 mm Injection Unit Screw diameter: 98 mm Shot volume: 4,010 cm³ Shot weight (PS): 3,690 g Injection pressure: 1,650 bar Bdedpfex A Ar Eex Ab Tjk Max. injection speed: 400 mm/s MACHINE DETAILS Control system: CDS700 Clamping unit weight: 44,500 kg Injection unit weight: 12,500 kg EQUIPMENT Pneumatic valves: 4 units Core pulls: 1 fixed / 1 movable Sytrama 101 GL robot
