Used Okuma Lb 15 2 Mit Osp 5020 L for sale (198)

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: 132542, turning diameter over cross slide: 470 mm, turning length: 300 mm, turning diameter: 580 mm, spindle bore: 62 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 260 mm, travel distance Z-axis: 380 mm, spindle motor power: 11,000 W, rapid traverse X-axis: 25 m/min, rapid traverse Z-axis: 30 m/min, total height: 1,839 mm, total length: 1,865 mm, total width: 1,734 mm, overall weight: 3,200 kg, Equipment: documentation/manual, OKUMA LB2000EX-MC x 300mm OSP P200L CNC-Controller Cpedpfx Afexrnr Nenot Number of axis - 3 Swing over bed - 580mm Swing over cross slide - 470mm Max dia. turning - 360 mm Max turning length - 300 mm X axis travel - 260 mm Z axis stroke - 390 mm Rapid X-axis 25,000 mm/min Z axis rapid 30,000 mm/min Spindle nose - Flat Main spindle speed - 6000 rpm Main spindle power - 11 kW Main spindle diameter - 100 mm Kitagawa 6 inch chuck Driven tools - 6000rpm Driven tools - 5,5kW Turret type VDI 12 Stations Square tool section - 20mm Boring bar section - 32mm Tailstock Quill diameter - 70mm NC tailstock stroke - 415mm Konus - MK 4 Chip conveyor type high Wight - 3200kg One Touch dialog with colour High presure coolent

Condition: good (used), Year of construction: 2015, machine/vehicle number: 190630, turning length: 150 mm, turning diameter: 200 mm, spindle bore: 42 mm, spindle speed (max.): 4,500 rpm, spindle speed (min.): 50 rpm, travel distance X-axis: 150 mm, travel distance Z-axis: 155 mm, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 24 m/min, turning diameter over bed slide: 220 mm, overall weight: 5,000 kg, spindle nose: 140 Flat, bar diameter (max.): 51 mm, power: 0.015 kW (0.02 HP), The innovative front-facing spindle of the 2SP-150H helps create an automation-friendly lathe for small parts production. By moving the spindle off the side and incorporating the Okuma Gantry Loader (OGL) into the production line, parts can be loaded and unloaded automatically. An extremely compact footprint improves floor space utilization, while the popular dual spindle option significantly reduces cycle time. Equipped with: Okuma OSP-P300L CNC Control 8" 3-Jaw Chuck Expanding Mandrel Cpjdpfxjrtrlzj Afnet Turret Tooling Gantry Loader Pendant Controller Chip Auger Stack Light

Condition: good (used), Year of construction: 1998, functionality: fully functional, Controller OSP700L Swing dia 300 mm Turning dia 170 mm Between centers 340 mm X travel 150 mm Z travel 350 mm C axis 360/0,001 degree Spindle hole D42 mm Chuck dia 200 mm Turret 12-fold Tool holder type VDI30 Spindle speed 50 - 6000 rpm Spindle power 5,5/7,5 kW Power required 400V, 15 kVA Weight 3500 kg Dimensions LxWxH = 2300 x 1635 x 1850 mm Accessories - C axis and live tool turret - Hydraulic tailstock - Coolant unit - Chip conveyor - Hydraulic 3 jaws, D160 mm chuck - Machine light Cpodpfx Asvmzc Uefnet Good condition, still under power.

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 109566, turning length: 480 mm, turning diameter: 340 mm, spindle speed (max.): 4,500 rpm, spindle diameter: 100 mm, Machine with a large V12 turret for L- or M-sized tools and a hydraulic tailstock. TECHNICAL DETAILS Swivel diameter over bed: 530 mm Swivel diameter over longitudinal slide: 530 mm Swivel diameter over cross slide: 410 mm Number of controllable axes: 4 Turning length: 480 mm Turning diameter: 340 mm Speed: 4,500 rpm Spindle diameter: 100 mm Spindle Spindle diameter: 100 mm Spindle head type: JIS A2-6 Taper bore: Ø70 (2.75) x 1/10 mm Spindle bore: 62 mm Spindle speed: 38 - 4,500 rpm Longitudinal slide (Z-axis) Axis stroke: 500 mm Feed: 0.001 - 1,000 mm/rev Rapid traverse: 25,000 mm/min Cross slide (X-axis) Axis travel: 280 mm [70 + 210] Feed: 0.001 - 1,000 mm/rev Cjdpfx Asv I Tkaofnopt Rapid traverse: 20,000 mm/min Y-axis Axis travel: +70 to -50 mm Feed: 0.001 - 1,000 mm/rev Rapid traverse: 10,000 mm/min Turret Type: V12 Number of tools: 12 (L or M tools) Tool size (external turning tools): 25 x 25 mm Tool size (internal turning tools): 40 mm C-axis Control angle: 360° (increment: 0.001°) Rapid traverse: 200 °/min Tailstock & Motor Tailstock spindle diameter: 90 mm Tailstock spindle stroke: 120 mm Spindle drive motor: 15/11 kW (20 min/continuous operation) Longitudinal slide feed (Z-axis): 6 kW Cross slide feed (X-axis): 4 kW MACHINE DETAILS Machine height: 2,200 mm Floor area: 2,200 x 1,720 mm Weight: 5,200 kg EQUIPMENT - Hydraulic tailstock

Year of construction: 2008, condition: good (used), functionality: fully functional, Machine is provided free loaded. TECHNICAL DETAILS turning length over bed / saddle: 670 / 480 turning length: max. 750 mm turning diameter: max. 430 mm Bar diameter: max. 102 mm speed: 42 - 4200 rpm travel X / Z: 300 / 840 mm rapid traverse: 30 / 25 m/min spindle power cont. / 30 min: 30 / 22 kW spindle nose: ASA 11 tool holder: 12 places tool size: 25 x 25 mm / 40 mm tool speed: 45 / 6000 rpm MACHINE DETAILS weight: 6700 kg dimensions: 4500 x 1900 x 2320 mm EQUIPMENT Chip conveyor Cedpfxjpgrzcj Afnjpt tool presetting automatic door opening high pressure pump. 6 bar drive tools and various static tools (see picture)

Year of construction: 2018, operating hours: 1,256 h, condition: excellent (used), functionality: fully functional, machine/vehicle number: 2189, OKUMA LB3000EX-II - is particularly suitable for universal turned parts and complete machining of complex workpieces thanks to generous flatbed guides and the high-torque drives ensure high precision and continuous accuracy TECHNICAL DETAILS turning diameter over bed: 580 mm Machinable turning diameter: 340 mm workpiece length: 950 mm traverse X / Z / Y: 230 / 510 / 120 (+70/-50) mm C axis: 360 / 0.001 ° Control: OKUMA OSP-P300LA rapid traverse X / Z / Y: 25 / 30 / 12,5 m/min Cedpfxont T Aus Afnspt riveting stroke: 1015 mm spindle speed: 4200 rpm spindle end piece: JIS A2-8 spindle bore: 91 mm diameter spindle bearing: 140 mm tool holder: M-V12 with 12 places tool size: 25 x 25 mm tool diameter: 40 mm tool change time: 0,1 s Tool speed: 45 - 6000 rpm Operating hours: 1.256 h Control on: 1.660 h MACHINE DETAILS dimensions L x W x H: 3420 x 2041 x 2444 mm weight: 6600 kg Supply voltage: 400 V, 3 phases, 50 Hz Power drawn: 38,9 kVA Spindle power (30 min/continuous): 30 / 22 kW Spindle torque: (30 min/continuous): 700 / 512 Nm Tool power (25 min/continuous): 7.1 / 4.1 kW Tool torque (25 min/continuous): 40.4 / 23.4 Nm Note: The WTOH hobbing tool holder (see document in the appendix) is not part of the scope of delivery.

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, machine/vehicle number: 0014, turning length: 1,500 mm, turning diameter over cross slide: 610 mm, travel distance X-axis: 598 mm, travel distance Y-axis: 230 mm, travel distance Z-axis: 1,660 mm, TECHNICAL DETAILS Travel Distances X-axis travel: 598 mm Y-axis travel: 230 mm Z-axis travel: 1,660 mm C-axis: 0.001 Turning Length: 1,500 mm Swing diameter over cross slide: 610 mm Swing diameter: 580 mm Spindle Spindle motor power: 30,000 W Spindle speed (min.): 14 rpm Spindle speed (max.): 3,200 rpm Spindle bore: 90 mm Cpodpfxexqyiko Afnot Spindle bearing diameter: 130 mm Spindle nose: JIS A2-11 Rapid Traverse Rapid traverse (Z-axis): 20 m/min Rapid traverse (X/Y): 12,000 mm/min Rapid traverse (C): 100 min^-1 Cutting feed rate X/Z/Y: 0.001 - 1,000 mm/rev Tools Tool magazine positions: 32 pos. Tool holder: MAS BT 50 Max. tool diameter: 170 mm Max. tool length: 350 mm Max. tool weight: 20 kg Turret type: H2 ATC Tool stations: 2 (1x L-Tool / 1x M-Tool) Driven tool stations: stepless Spindle speed – driven tool stations: 40 - 3,000 rpm Tailstock Quill diameter: 120 mm Quill stroke: 170 mm Centre taper: MT 5 MACHINE DETAILS CNC Control: OSP 7000L Total power requirement: 53 kVA Dimensions & Weight Dimensions (L x W x H): 5.3 x 3.2 x 3.0 m Machine weight: 18,500 kg EQUIPMENT Chip conveyor

Condition: excellent (used), Year of construction: 2019, operating hours: 2,044 h, functionality: fully functional, machine/vehicle number: 223697, turning length: 950 mm, turning diameter: 340 mm, travel distance X-axis: 260 mm, travel distance Y-axis: 120 mm, travel distance Z-axis: 1,010 mm, rotational speed (max.): 5,000 rpm, Machine with Big-Bore Spindle TECHNICAL DETAILS Spindle speed: 45 to 4,200 rpm Spindle motor: 30/22 kW Spindle mount: JIS A2-8 Spindle bore: ø91 mm Axes and Travel Turning length: 950 mm Turning diameter: 340 mm C-axis control: 360° at 0.001° increments X-axis travel: 260 mm Y-axis travel: 120 mm; +70 mm / −50 mm Z-axis travel: 1,010 mm Tool Turret Turret type: V12, radial, for L and M tools Tool holder mount: VDI Speed: 45 to 6,000 rpm Rotary tool motor: VAC 7.1/4.1 kW Control CNC control: OSP-P300LA with 15" touch panel Pitch error compensation: X-/Y-/Z-axes Workpiece ejection detection: available Smart Interface: included API Library 2: activated Virus Protection System - OSP-VPS: available Software Functions One Touch IGF Advanced M-E Kit: standard Optional IGF Advanced M-D Kit: available Cpsdpfx Aswnqdiofnjt Multitasking coordinate conversion: available Profile generation: available Cycle time inspection and reduction: available Hi-Cut Pro: available Load monitoring, spindle & feed axes: available NC operation monitoring: available Spindle speed control: variable Y-axis turning: available Helical milling for MY machine: X/Y surface, Y/Z surface Cooling and Lubrication Coolant pump: 0.25 kW Coolant tank: L-type, replacing I-type High-pressure coolant pump: 0.8 kW Lubrication monitoring: A-1 incl. hydraulic pressure monitoring Dimensions and Construction CE marking and EMC: available IEC standard compliance: available Power supply CE-compliant: adapted to local standards Guideway extension for steady rests: available TAS-C: available Chip and Coolant Management Chip tray: side extraction Chip conveyor H-type: side, CE-compliant Fully enclosed with coolant protection: available MACHINE DETAILS Height: 2,444 mm Footprint: 3,420 x 2,041 mm Weight: 6,600 kg

Condition: used, Year of construction: 1988, functionality: fully functional, machine/vehicle number: M08L/8356, Offer Number: M08L/8356 Machinetype: 4 die - 4 blow transfer header Cpedpfowi S A Aex Afnet Info: bushing cut-off , PKO Make: ASAHI OKUMA Type: AF1513-4 Constr. year: 1988 diameter range: 7-15 mm number of dies: 4 number of stations (incl. cut off): 5 cutting length: 10-160 mm shaft length under head: 15-130 mm output - pieces/min: 130 press power: 150 to Location: In our warehouse

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, Reference: LT-2501 Manufacturer: Okuma Model: LB4000EX-MC x 750 CNC Control: Okuma OSP-P200L Year of Manufacture: 2007 Keyboard/Software Language: International / Spanish Country of Origin: Japan Cpsdpfxsw Dvb Se Afnjt Technical Specifications: Capacity: Maximum swing over bed: Ø 670 mm Maximum swing over carriage: Ø 480 mm Distance between centers: 770 mm Maximum turning diameter: Ø 430 mm Maximum turning length: 750 mm Maximum bar capacity: Ø 90 mm (requires modification) Main Spindle: Spindle diameter: Ø 160 mm Spindle nose (type): JIS A2-11 Spindle bore: Ø 112 mm Speed ranges: 2, infinitely variable Spindle speed: 30 – 3,000 rpm Motor: 37 / 30 kW (30 min / continuous) Motor type: PREX Motor Tailstock: Rotating center: MT 5 Travel (W axis): 780 mm Rapid traverse: 12,000 mm/min Maximum thrust: 7,500 N Z Axis: Travel: 840 mm Cutting feedrate: 0.001 – 1,000.00 mm/rev Rapid traverse: 30,000 mm/min X Axis: Travel: 300 mm Cutting feedrate: 0.001 – 1,000.00 mm/rev Rapid traverse: 25,000 mm/min C Axis: Controlled angle: 360° (0.001° increment) Turret: Type: M-V12 NC Number of tool stations: 12 x BMT40 (L or M) Indexing speed: 0.2 sec/position Tool Dimensions: External turning: 25 x 25 mm Internal turning: Ø 40 mm Driven Tool: Speed: 45 – 6,000 rpm Number of speed ranges: 1, infinitely variable Motor: 7.5 / 4.3 kW (25 min / continuous) Motor type: PREX Motor Dimensions and Weight: Machine height: 1,955 mm Floor space required: 3,050 x 1,900 mm Machine weight: 6,300 kg Included Options: SCHUNK ROTA THW plus 315-104 quick-change chuck (3 jaws, Ø 315 mm) CROMAR chip conveyor Assisted programming (ONE Touch IGF Advanced) Rigid tapping DNC-T1

Condition: used, Year of construction: 1996, Switch-on time: 68743 h Codevfucfepfx Afnept Spindle hours: 17338 h

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 762 mm, travel distance Y-axis: 460 mm, travel distance Z-axis: 460 mm, controller model: OSP-P200M, rotational speed (max.): 15,000 rpm, TECHNICAL DETAILS Travel X-axis: 762 mm Travel Y-axis: 460 mm Travel Z-axis: 460 mm Spindle speed range: 50 - 15,000 rpm Rapid traverse X-axis: 40 m/min Rapid traverse Y-axis: 40 m/min Cpjdpfex I Ecyox Afnjt Rapid traverse Z-axis: 32 m/min Tool magazine: 32 positions MACHINE DETAILS Control: OSP-P200M Main drive motor: 22 kW Dimensions & Weight Required space (L x W x H): 2,850 x 2,810 x 2,750 mm Machine weight: 7,200 kg EQUIPMENT Chip conveyor Internal coolant supply Standard filtration unit

Condition: ready for operation (used), Year of construction: 2008, Control Unit Brand OKUMA Main Drive Spindle speed range 8000 rpm Tool taper BT40 Number of axis 4 Movement X-Axis Movement 560 Cedpfx Aex R E S Hefnspt Y-Axis Movement 560 Z-Axis Movement 600 Additional Equipment Tool change gearbox has a defect This 4-axis Okuma MA-400HA horizontal machining center was manufactured in 2008. It offers robust construction and precision for demanding machining tasks. If you are looking to get high-quality milling capabilities, consider the Okuma MA-400HA machine we have for sale. Contact us for more information. Application Types Milling

Condition: used, Year of construction: 1988, operating hours: 23,103 h, functionality: fully functional, travel distance X-axis: 652 mm, travel distance Y-axis: 412 mm, travel distance Z-axis: 452 mm, feed length X-axis: 652 mm, feed length Y-axis: 412 mm, feed length Z-axis: 452 mm, controller manufacturer: Okuma, controller model: OSP 5000, table width: 500 mm, table length: 1,000 mm, rotational speed (max.): 6,000 rpm, spindle speed (min.): 6,000 rpm, spindle speed (max.): 6,000 rpm, spindle nose: BT40, number of slots in tool magazine: 20, We are offering this used Okuma MC-4VA machining centre, year of manufacture 1988. Manufacturer: Okuma Model: MC-4VA Machine type: Vertical machining centre 3-axis CNC milling machine Travels: Codpfx Asx Saybjfnopt X-axis: 652mm Y-axis: 412mm Z-axis: 452mm Spindle speed: 6000 rpm / 2 gear stages Tool changer: 20 tools Tool holder: BT40 Operating hours: 23,103 Control: OSP 5000 Programming: ISO code or IGF Data transfer: RS 232 The machine can be inspected under power. If you have any questions or need further information, please feel free to send us a message or give us a call.

Year of construction: 2005, condition: excellent (used), Okuma MB-46 VAE 2005 - max. machining dimensions 760x460 mm - max. loading weight 700 kg - table dimensions 1000x460 mm - travels X= 762, Y= 460, Z= 460 mm - distance table-spindle 150-610 mm - max. speed 15.000 rpm - tool capacity: 32 - tool holder SK 40 Cpodpfxsh If Spj Afnjt spindle makes noise ( videos available)

Condition: used, Year of construction: 2001, functionality: fully functional, OKUMA CNC lathe TL10-M in working condition ATTENTION, WITHOUT THE MIST DUST COLLECTOR! Specifications: - Year of manufacture: 2001 - Control: Okuma OSP-U100L - Chip conveyor - Including several tools Main spindle: - Bar capacity: 50mm - Spindle bore: 53mm - Max. swing over bed: 400mm - Max. turning diameter: 210mm - Turning length: 130mm - Spindle speed: 6000rpm Sub spindle: - Bar capacity: 50mm - Spindle speed: 6000rpm Turrets: - Number of turrets: 2 - Number of stations: 12 - Number of powered stations: 12 - X-stroke: 195mm - Z-stroke: 700mm Accessories: - Mist dust collector not included!!! Cjdpfx Afow Swp Eenjpt - CTS (coolant through spindle) in both turrets - Live tooling in both turrets - Chip conveyor - 2 x chuck 200mm - Several tool holders: 11 x single tool holder 20x20 2 x double tool holder 20x20 2 x top tool holder 20x20 2 x round tool holder 16 16 x round tool holder 25 4 x live tool holder radial 4 x live tool holder axial - Coolant installation - Machine manuals

Condition: good (used), Year of construction: 2013, Manufacturer: OKUMA Model/Series: LOC 650 Type: Oil Country CNC Lathe Control System: OSP-P300L CNC Control Year of Manufacture: 2013 (Nov) Serial No.: 172670 Featured Specification: Csdsx Rq Rhjpfx Afnspt - 14.76" spindle bore - Power on time: 20,538 hours - NC running time: 2,287 hours - Cutting time: 1,691 hours - SMW Autoblok BB-N850-375-3-ES Big Bore Air Chucks (front & rear) - 12-station upper turret - Swarf conveyor - Coolant system Technical Specification: - Swing over bed: 1,030 mm - Maximum turning diameter: 650 mm - Spindle motor: 60 hp / 45 kW - Spindle speeds: 5–500 rpm - Spindle nose: ASA A2-20 - Spindle bore: 14.76" dia (375 mm dia) - Machine size (without conveyor): Length 6.4 m, Width 2.8 m, Height 2,843 mm - Machine weight: 23,000 kg

Condition: excellent (used), Year of construction: 2013, operating hours: 1,719 h, functionality: fully functional, feed length X-axis: 470 mm, feed length Z-axis: 2,040 mm, feed rate X-axis: 5 m/min, feed rate Z-axis: 10 m/min, turning diameter over cross slide: 650 mm, turning diameter: 1,030 mm, spindle bore: 375 mm, spindle speed (max.): 500 rpm, spindle speed (min.): 5 rpm, overall weight: 23,000 kg, Okuma CNC Oil Country Hollow Spindle Lathe Model: LOC 650 Control: Okuma OSP P300L Year: 2013 Max Swing Over Bed: 1030mm Cjdjxzgkijpfx Afnjpt Max Turning Dia: 650mm Spindle Bore: 375mm Spindle Speeds: 5-500 RPM Double Air Chucks 850mm Dia 12 Station Upper Turret Swarf Conveyor Coolant System

Condition: used, Year of construction: 2014, Technical details: x-travel: 760 mm y-travel: 760 mm z-travel: 760 mm total power requirement: 43 kW Codpfx Aoxrwpdefnjpt weight of the machine ca.: 11,5 t dimensions of the machine ca.: 2,7 x 4,73 x 2,87 m max. table loading capacity: 500 kg

Condition: used, Year of construction: 2015, functionality: limited functionality, machine/vehicle number: MW130, Technical characteristics: Work Area - Maximum turning diameter: 300 mm - Maximum workpiece length: 276 mm - X-axis travel: 250 mm / Rapid traverse X: 24 m/min - Z-axis travel: 460 mm / Rapid traverse Z: 24 m/min - W-axis travel: 520 mm / Rapid traverse W: 24 m/min Main Spindle - Spindle nose: A2-8 - Maximum speed: Left 3,000 rpm - Continuous power (100% duty cycle): Left – 15 kW / Right – 7.5 kW - Maximum swing over bed: 520 mm - C-axis positioning accuracy: 0.001° - Bar capacity: Left spindle – 80 mm / Right spindle – 53 mm Counter-Spindle: - Spindle speed: 6,000 rpm - Maximum bar diameter: 53 mm - C-axis positioning accuracy: 0.001° - Travel: 520 mm Turret with Driven Tools - Tool interface: Okuma interface - Number of stations: 12-station lower turret, all positions driven - Maximum milling speed: 4,500 rpm - Milling motor power: 4.5 kW Electrical Equipment - Operating voltage: 400V, 3-phase, fuse: 151 A - Connected load: 22.5 kVA Dimensions - Machine dimensions (L×W×H): 3,200 × 2,200 × 1,900 mm - Weight: 5,500 kg Main Features and Capabilities: - Horizontal construction: Optimal chip evacuation, parts catcher + custom parts conveyor belt - CNC control: OSP-P300L-R - Chip conveyor - Fire protection system - Tool measuring system (Q SETTER) - Broken tool detection system: Load monitoring auto-learning analyzer controlled by OSP-P300L-R - Workpiece detection on counter-spindle: Low-pressure compressed air gauges - Spindle cooling system - Documentation: Available electronically and as a hard copy Machine status: Csdpfoxxrbbsx Afnopt Operative only with main spindle – sub spindle requires repair Optional Equipment - Bar feeder: TopAutomazione model FU352 - Bar feeder dimensions (L×W×H): 3,500 × 800 × 1,200 mm - Weight: 1,500 kg

Condition: excellent (used), Year of construction: 2002, OKUMA Euro Center V50 Year of construction 2002 Control system OSP-U100L Travel distances X-1020 Y-510 Cpsdperfw Nhjfx Afnjt Z-525 Table load 680kg Clamping surface 1200x510 Tool changer 20 magazine places chip conveyor

Condition: excellent (used), Year of construction: 2013, operating hours: 1,800 h, functionality: fully functional, turning diameter over cross slide: 650 mm, turning length: 1,750 mm, turning diameter: 650 mm, spindle bore: 375 mm, spindle speed (max.): 500 rpm, spindle speed (min.): 5 rpm, travel distance X-axis: 470 mm, travel distance Z-axis: 2,040 mm, rapid traverse X-axis: 5 m/min, rapid traverse Z-axis: 10 m/min, Okuma CNC Oil Country Hollow Spindle Lathe Codsxzi D Sepfx Afnjpt Model: LOC 650 Control: Okuma OSP P300L Year: 2013 Max Swing Over Bed: 1030mm Max Turning Dia: 650mm Spindle Bore: 375mm Spindle Speeds: 5-500 RPM Double Air Chucks 850mm Dia 12 Station Upper Turret Swarf Conveyor Coolant System

Condition: used, Year of construction: 2016, functionality: fully functional, machine/vehicle number: MW141, Technical characteristics: Work area # Maximum turning diameter: 300 mm # Maximum workpiece length: 276 mm # X-axis travel: 250 mm / Rapid traverse X: 24 m/min # Z-axis travel: 460 mm / Rapid traverse Z: 24 m/min # W-axis travel: 520 mm / Rapid traverse W: 24 m/min Main Spindle Cedpjxxifksfx Afnept # Spindle mount: A2-8 # Maximum spindle speed: Left 3000 rpm # Continuous power (100% duty cycle): Left - 15 kW / Right - 7.5 kW # Max workpiece diameter over bed: 520 mm # C-axis indexing accuracy: 0.001° # Bar capacity: Left spindle - 80 mm / Right spindle - 53 mm Counter-Spindle: # Spindle speed: 6000 rpm # Max bar diameter: 53 mm # C-axis indexing accuracy: 0.001° # Travel: 520 mm Motorized Tool Turret # Tool interface: Okuma interface # Number of stations: 12-position lower turret, all stations powered # Maximum speed: 4500 rpm, Milling motor power: 4.5 kW Electrical equipment # Supply voltage: 400V 3-phase # Connected load: 22.5 kVA Dimensions # Machine dimensions (L×W×H): 3200 × 2200 × 1900 mm; Weight: 5500 kg Main features and capabilities: # Horizontal design: optimal chip evacuation, parts catcher + custom parts conveyor belt # Additional coolant tank with 10 bar pressure for cutting tool cooling # CNC control: OSP-P300L-R # Chip conveyor # Fire protection system # Tool measuring system (Q SETTER) # Broken tool detection: Load force auto-learning analyzer managed by OSP-P300L-R # Workpiece detection on counter-spindle: Low-pressure compressed air sensors # Spindle cooling system # Documentation: Available electronically and as hardcopy Optional: Bar feeder: FMB model Turbo 10-72XT/3200/A # Bar feeder dimensions (L×W×H): 3500 × 800 × 1200 mm; Weight: 1500 kg Machine status: In operation

Condition: repair required (used), Year of construction: 2016, functionality: not functional, machine/vehicle number: MW144, Technical characteristics: Work Area - Maximum turning diameter: 300 mm - Maximum workpiece length: 276 mm - X-axis travel: 250 mm / Rapid traverse in X: 24 m/min - Z-axis travel: 460 mm / Rapid traverse in Z: 24 m/min - W-axis travel: 520 mm / Rapid traverse in Z: 24 m/min Main Spindle - Spindle nose: A2-8 - Maximum speed: Left 3000 rpm - Power at 100% duty cycle: Left – 15 kW / Right – 7.5 kW - Maximum swing over bed: 520 mm - C-axis indexing accuracy: 0.001° - Bar capacity: Left spindle – 80 mm / Right spindle – 53 mm Sub-Spindle: - Spindle speed: 6000 rpm - Maximum bar diameter: 53 mm - C-axis indexing accuracy: 0.001° - Travel: 520 mm Tool Turret with Driven Tools - Tool interface: Okuma interface - Number of stations: 12-position lower servo turret, all stations driven - Maximum speed: 4500 rpm - Milling motor power: 4.5 kW Electrical Equipment - Mains voltage: 400V 3-phase - Connected load: 22.5 kVA Dimensions - Machine dimensions (L×W×H): 3200 × 2200 × 1900 mm - Weight: 5500 kg Main Features and Capabilities: - Horizontal design: optimized chip evacuation, parts catcher + custom parts conveyor belt - CNC control: OSP-P300L-R - Chip conveyor - Fire protection system - Tool measurement system (Q SETTER) - Broken tool detection: Load monitoring and automatic force analysis via OSP-P300L-R - Workpiece detection at sub-spindle: Low-pressure compressed air monitoring - Spindle cooling system - Documentation: Electronic / Hard copy available OPTIONAL Bar feeder: TOP Automazione, model FU 352 - Bar feeder (L×W×H): 3500 × 800 × 1200 mm; Weight: 1500 kg Machine Condition: NOT WORKING - Turret disassembled for repair - X-axis ballscrew to be replaced - Heat exchanger / lubrication unit to be replaced - Hydraulic unit to be replaced - Sub-spindle to be repaired Csdjxxidaepfx Afnjpt - Spindle position encoder to be replaced - Chip conveyor to be repaired - Set of bar clamping guide and accessory kit - Set of bearings for pusher head

Condition: repair required (used), Year of construction: 2015, functionality: not functional, machine/vehicle number: MW137, Technical characteristics: Work Area - Maximum turning diameter: 300 mm - Maximum workpiece length: 276 mm - X-axis travel: 250 mm / Rapid traverse in X: 24 m/min - Z-axis travel: 460 mm / Rapid traverse in Z: 24 m/min - W-axis travel: 520 mm / Rapid traverse in Z: 24 m/min Main Spindle - Spindle nose: A2-8 - Maximum speed: Left 3,000 rpm - Continuous power (100% duty cycle): Left - 15 kW / Right - 7.5 kW - Maximum swing over bed: 520 mm - C-axis indexing accuracy: 0.001° - Bar capacity: Left spindle - 80 mm / Right spindle - 53 mm Counter-Spindle - Spindle speed: 6,000 rpm - Maximum bar diameter: 53 mm - C-axis indexing accuracy: 0.001° - Travel: 520 mm Tool Turret with Driven Tools - Tool interface: Okuma interface - Number of positions: 12 lower turret stations, all driven - Maximum speed: 4,500 rpm; Milling spindle power: 4.5 kW Electrical Equipment - Operating voltage: 400V (3-phase), fuse protection: 151A - Connected load: 22.5 kVA Dimensions - Machine dimensions (L×W×H): 3,200 × 2,200 × 1,900 mm; Weight: 5,500 kg Main Features and Capabilities: - Horizontal design: Optimal chip evacuation, parts catcher + custom-made conveyor belt - Additional emulsion tank with 10 bar pressure for cutting tool cooling - CNC control: OSP-P300L-R - Swarf (chip) extraction conveyor - Fire suppression system - Tool measuring system (Q SETTER) - Broken tool detection: Load monitoring with auto-learning analyzer via OSP-P300L-R - Workpiece detection on counter-spindle: Low-pressure compressed air gauges Cjdpoxxh Udefx Afnspt - Spindle cooling system - Documentation: Electronic and print manual available Optional: - Bar feeder: FMB Model: Turbo 10-72XT/3200/A - Bar feeder dimensions (L×W×H): 3,500 × 800 × 1,200 mm; Weight: 1,500 kg Machine status: NOT OPERATIONAL - X-axis encoder: faulty
