Used Model Milling Machine for sale (98,424)

Condition: refurbished (used), Year of construction: 2025, Dear customers, we are currently offering, upon request/order, a refurbished table router, type FZ0 by F. Zimmermann. Here are the machine's technical specifications: Worktable: 590 x 420 mm Rotary movement: 360° Tilting: 2x90° Spindle power: 0.25 kW Speed: 22,000 rpm Tool holder: collet chuck with clamping nut Ø 8 mm - CE marking - Vernier stop - Plexiglas milling guard - Original base cabinet (optional) Dimensions: 1,100 x 1,180 x 1,760 mm Weight: 120 kg The machine has been repainted in RAL 7035 light grey, drives have been cleaned, inspected, and equipped with a new belt. With the machine, you will also receive an angle table and a set of milling tools – in other words, a complete setup! VAT is itemized separately on the invoice. Shipping available at an additional charge. Dwsdpfxjxlzg Ho Adusc Current delivery time: 6 weeks If you have any questions, please feel free to contact us!

Condition: excellent (used), Year of construction: 2008, Universal Table Router FZ0 by Zimmermann Modelling milling machine with variable-speed Bosch motor GGS 27 LC Ideally suited for model making and tool & die applications. Drive motor: 230 Volt, 0.6 kW Adjustable spindle speed approx. 12,000 to 27,000 rpm Dwsdpfxjw Ip Dgo Adujc Machine table approx. 590 x 420 mm Unit swivels 90 degrees to both sides Longitudinal fence with fine adjustment Extraction hood and safety guard Collet chucks for 6 mm and 8 mm Includes the cutters and milling bits shown in the pictures Comes with lockable base cabinet, 2 drawers and 1 door; key included The base cabinet was modified by the previous owner with an aluminium sheet and angles to provide an integrated extraction option, see photos Waldmann surface-mounted lamp with magnifier attachment Original paint, partially touched up CE mark Very well-maintained machine from the prototype manufacturing section of a motorsport department at a Wolfsburg automotive manufacturer. Evidently, it has seen very little use so far. Machine dimensions approx. 680 x 600 x 780 mm (L x W x H) Cabinet dimensions approx. 600 x 620 x 880 mm (L x W x H) Weight approx. 190 kg The machine can be demonstrated on site by appointment. We only offer machines that are ready for demonstration in our warehouse – see “more offers from this seller.”

Condition: used, Year of construction: 1997, Control Heidenhain TNC 407 serial number 60/1997 x-travel 1.000 mm y-travel 600 mm z-travel 700 mm Dwedoumyhrjpfx Adujc TISCHMAß: 1300 X 600 mm Werkzeugwechsler: 24- fac

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, travel distance X-axis: 1,900 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 850 mm, table width: 825 mm, table length: 2,300 mm, overall weight: 12,500 kg, MILLING MACHINE GLOBA TRADE Dsdewxyh Sepfx Aduowc MOD. U 1900 CNC CNC SELCA MOD 3045 TABLE 2300 X 825 LONGITUDINAL TRAVEL X: 1900 mm CROSS TRAVEL Y: 800 mm VERTICAL TRAVEL Z: 850 mm ISO 50 SPINDLE MOTOR POWER: 15 kW WEIGHT: 12,500 kg USED MACHINE INTERNAL CODE: SVR 348

Condition: good (used), Year of construction: 1979, Model making milling machine, universal model milling machine, milling machine, universal milling machine, tool milling machine, drilling and milling machine, model making milling machine -Manufacturer: Zimmermann, universal milling machine type FZ 1 with extensive accessories -rotating cross table: 490 x 400 mm -Travel: X/Y/Z 320/385/430 mm -Spindle holder: SK30 -Drive: 1.1 kW -Speed: 560 to 14000 rpm, 8-stage -Accessories: incl. see photos -Dimensions: 1000/680/H1970 mm -Weight: 477 kg Dsdpfx Aenzpx Rsduswc

Condition: used, functionality: fully functional, travel distance X-axis: 1,600 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 760 mm, table width: 2,000 mm, Sachman Model R Dsdpfxswtfvqe Adujwc Table size 2000 x 560 Travel: X 1600 Y 700 Z 760

Condition: used, Table size 900 x 460 mm X/Y/Z - 600/400/420 mm Spindle speeds 20-4000 rpm Spindle taper ISO 40 Hydraulic tool clamping Quill stroke in vertical head Dsdpfxel Dvx Ej Aduewc Vertical head swivels +/- 90 deg. Tool changer w/32 stations Control: Heidenhain TNC 407 Equipped with: Vice 19 tool holders Coolant

Condition: excellent (used), Year of construction: 1982, Used Noble & Lund Double Column Plano Milling machine model P/RLMA with vertical milling head and planing head. Serial #6344P Year of manufacture: October 1982. MACHINE FORMERLY INSTALLED AT ROLLS ROYCE PLC IN DERBY UK. IMMEDIATELY FOR SALE AND NOW LOCATED IN BELGUIM WHERE IT CAN BE INSPECTED. SPECIFICATION TABLE WORKING AREA 5’-0 x 16’ 0”( 1524mm x 4876mm) MAX COMPONENT HEIGHT 5’0 (1524 mm) DISTANCE BETWEEN COLUMNS 6’1” (1866mm) MAX. WEIGHT OF WORKPIECE 15000kgs RAM TRAVEL 4’0”(914mm) RAM SECTION 14” x 14”(355 x 355 mm) Dsdpfx Adoh U Nvkjuowc SPINDLE TAPER ISO 50 MILLING SPINDLE MOTOR 40HP (30Kw) MILLING FEED RATES / MIN 1”-48”/MIN( 25-1200MM/MIN) PLANING MOTOR 40HP(30 Kw) MILLING SPINDLE SPEEDS 7-835 RPM ELECTRICAL SUPPLY 415V 3Ph 50Hz LENGTH TBA MM WIDTH TBA MM HEIGHT TBA MM WEIGHT 42000 KGS NOTE: The information contained herein is provided in good faith, but however due to unforeseen errors or omissions cannot be binding as to accuracy.

Condition: used, Model milling machine, milling machine, universal milling machine, tool milling machine, drilling and milling machine -Milling machine head: pivoting/rotating -Feed: in X and Y no feed because no motors are installed (gears are available, see pictures) -Clamping table: 280 x 1300 mm Dwjdpfx Adjd Dt R Heuec -Travel: X/Y/Z 450/300/325 mm -Spindle mount: SK40 -quill stroke -quill feed: 0.04-0.16 mm/rev -Speeds from: 60 to 3000 rpm -Dimensions: 1700/1530/H2200 mm -Weight: 1362 kg

Condition: new, functionality: fully functional, machine/vehicle number: RM310119, feed length X-axis: 787 mm, feed length Y-axis: 508 mm, feed length Z-axis: 584 mm, quill diameter: 105 mm, table width: 355 mm, table length: 1,372 mm, type of input current: three-phase, rotational speed (max.): 5,000 rpm, rotational speed (min.): 40 rpm, table load: 600 kg, overall weight: 2,390 kg, input voltage: 400 V, workpiece weight (max.): 600 kg, warranty duration: 12 months, input current: 22 A, input frequency: 50 Hz, Built-in programming cycles: Position: Spindle positioning Drilling: Simple holes, holes on a circle Milled holes: Holes made by milling cutter – straight and circular Arcs: Arcs in XY, XZ, and YZ plane Pockets: Rectangular, circular, irregular Dedpfx Adswtnxneuowc Island: Milling rectangular, circular, and irregular islands Profile: Rectangular, circular, irregular Helix: Spiral ramping Milling: Straight lines along X, Y, or Z axis or any combination Engraving: Text engraving Thread cutting: Thread cutting with tap Thread milling: Thread milling with form cutters Copying: Copying a series of cycles Mirror: Mirror image Rotation: Rotation around an axis Repetition: Repetition of a series of cycles G-code editor Clipboard

Condition: good (used), Year of construction: 2018, Table 1473 x 305mm, Traverses XYZ: 1000 x 410mm x 400mm (knee), quill travel 127mm, Spindle Taper ISO40, Power Drawbar, Spindle Motor 5HP, Dedpoxftqdsfx Aduewc Spindle Speeds 70 - 3600rpm, Prototrak SMX CNC Control,

Condition: used, Year of construction: 2020, functionality: fully functional, machine/vehicle number: 19090103008, Equipped with a milling spindle for 3 axes. Additionally fitted with an oscillating tangential knife, upgraded for a fourth axis (rotary axis). Furthermore, two additional tools are installed for performing 45° miter cuts along both X and X axes. Ideal for applications such as acoustic materials, foam materials, PU foam panels, cardboard, etc. Max. knife length: up to 120mm, shank diameter: 6mm. Dimensions: - 2200 x 3600 mm - Travel width (dome): 2440 x 3600 mm Working area for the oscillating knife: - Y direction: 3100 mm Dodpfx Adswx E Tgouowc - X direction: 2100 mm Working area for the spindle (4.5 kW): - Y direction: approx. 3000 mm - X direction: approx. 2000 mm - Clearance: 200 mm Vacuum table size: 2020 x 3100 mm The machine features a 6-zone vacuum table and a water-cooled pump with a power rating of 5.5 kW (pump dimensions: 1200 x 800 x 1000 mm – to be set up separately). Total machine weight is approx. 1.85 t. - Rack and pinion drive - Oil lubrication system - Stepper motors (step by step) - Spindle speed max. 24,000 rpm – high-frequency, water-cooled - Dust extraction connection Included in delivery is a complete workstation including CAD/CAM software in German, PC, monitor, and keyboard, all ready for immediate operation. Various tools and spare parts are also included. The machine has been in use since 01/2020 for acoustic material processing and has been regularly maintained. Price: €12,500.00 (excl. VAT), without delivery and installation. The machine is disassembled and ready for collection.

Condition: good (used), Erba Titan Model 3 die cutter Format: 830×1200 The machine is fully operational, ready for production. Titan is synonymous with power, it is the strongest machine in its class. Production Italy Format in frame 830×1200 mm Format of the press 855x1230mm Djdpfx Adow D E Rvjuowc Weight 6900kg Power supply 380V Number of cycles 900-1400/h Installed power 5.5 kW Equipment: – electromagnetic clutch and brake – control panel – 3 operating modes: single, continuous, with time delay on opening – central lubrication – additional safety guards and two pressure safety mats – service tools – hard sheet metal for the press

Condition: ready for operation (used), Fanuc 6-assige robotfreescentrum voor aluminium en staal X-beweging van de robot: 10 500 mm Uitgebreid armbereik van de robot (links en rechts): 3045 mm maximale werkstuklengte als het een profiel is: 15 meter max. werkstukgrootte zonder verlengde armbereik: 10 500 x 3045 mm max. werkstukhoogte: 3500 mm Gereedschapswisselaar met 13 posities: - 12 aangedreven gereedschappen Dwodpfxjv Sfk Ho Adujc - 1 meetsonde Freeskop: -SK40 - 12 kW op spindel / 16 000 tpm - automatische smering Er zijn veel configuraties mogelijk, afhankelijk van het type werkstuk. Momenteel zijn er twee aparte werkgebieden, maar u kunt dit aanpassen naar één werkgebied (voor een groot werkstuk) of opsplitsen in meerdere aparte werkgebieden voor kleinere werkstukken.

Condition: ready for operation (used), Year of construction: 1996, functionality: fully functional, table width: 520 mm, table length: 900 mm, overall weight: 4,500 kg, controller manufacturer: Heidenhain, TECHNICAL DETAILS Table size: 900 x 520 mm MACHINE DETAILS Control: Heidenhain Electrical Data Operating voltage: 400 V / 3~ Dwodpexl Sy Defx Aduoc Mains frequency: 50 Hz Control voltage: 24 V Total rated current: 23 A Total power: 16 kVA Weight: 4,500 kg

Condition: excellent (used), Year of construction: 1998, functionality: fully functional, travel distance X-axis: 5,000 mm, travel distance Y-axis: 2,800 mm, travel distance Z-axis: 1,500 mm, table length: 4,000 mm, table width: 2,000 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS X-axis travel: 5,000 mm Y-axis travel: 2,800 mm Z-axis travel: 1,500 mm Table length: 4,000 mm Table width: 2,000 mm Max. table load: 20,000 kg Spindle speed: 20 – 3,000 rpm Spindle power S1 = 100%: 30 kW Dwsdpfx Aexfiazjduec Spindle power S3 = 60%: 35 kW Max. spindle torque: 1,250 Nm at 226 rpm Tool holder: ISO SK50 Number of tool changer positions: 100 Milling Head Automatic milling head: Index 2.5° Straight milling head: Index 1.0° Feed Rate Working feed rate: 2 – 5,000 mm/min Rapid Traverse X-axis: 12,000 mm/min Y-Z-axis: 15,000 mm/min MACHINE DETAILS Control: HEIDENHAIN TNC426CB Dimensions (L x W x H): 9,800 x 6,200 x 7,100 mm Machine weight: approx. 31,600 kg

Condition: used, Year of construction: 1988, x-travel 870 mm y-travel 370 mm z-travel 400 mm table-size 310 x 1370 mm distance vertical spindle / table 50 - 450 mm Dwsdpjxlkw Uefx Adusc feed - longitudinal/cross 20 - 800 mm/min 9 - 355 mm/min rapid traverse longitudinal and cross 3000 / 1375 mm/min spindle taper SK 50 spindle turning speed range 40 - 1750 U/min spindle speed: 12 Stück total power requirement 5,5 kW weight of the machine ca. 2,4 t dimensions of the machine ca. 1,9 x 2,0 x 1,5 m - Powerful CNC universal milling machine - Includes Fanuc control system - Kneading milling head - Automatic feeds on X/Z/Y axes - Central lubrication system - Coolant system - Pivoting machine light - Splash guard tray - Separate transformer

Condition: good (used), Year of construction: 1998, Ref. -No.: 10583 Manufacturer: MTE Type: BF 4200 Year of construction: 1998 Type of control: CNC Control: Heidenhain TNC 426 Storage location: Halberstadt X-Travel: 4000 mm Y-Travel: 1200 mm Z-Travel: 1500 mm Turning Speeds: 2.500 RPM Rapid Traverse X/Y/Z: 400 m / min Table surface area (LxW): 4200 x 1000 mm Tool changer: 40 Table load max.: 13.000 kg Tool Taper: SK 50 Weight: 20 t Number Of T-Slots: 7 Pcs Width of the T-slots: 22 mm Distance between the grooves: 140 mm Dodpfxexmd U Ne Aduowc Further information: - Heidenhain Handrad HR410 - 3D-Scanner, Infrarot - Die Kugelspindel auf Achsen Z und Y laufen eingespannt und aufgelagert auf kombinierte radial/axial Rollager und radial Kugellager mit bzw. 250 N/qm, Steifigkeit. Maschine kann unter Strom besichtigt werden.

Condition: used, Year of construction: 2000, x-travel 6000 mm y-travel 1600 mm z-travel 1300 mm control FIDIA C20 /4H-SB tool taper SK50 spindle turning speed range 22 - 4000 U/min SHW – UFZ5 Year of manufacture: 2000 Specifications X-axis 6000 mm Y-axis 1600 mm (stroke with vertical head rotated 1900 mm) Z-axis 1300 mm Orthogonal head 2 axes, indexed 1° Automatically swivelling milling head holder (rear) 360x1 degree Automatically swivelling milling head holder (front) 180x1 degree Control: Fidia - C20 / 4H-SB SK 50 - DIN 69871 Infinitely variable feed range; X-axis: 2–12,000 mm/min. Y-axis: 2–18,000 mm/min. Z-axis: 2–18,000 mm/min. Rapid traverse; X-axis: 12,000 mm/min. Dwsdpfx Adoxmaqyeuoc Y-axis: 18,000 mm/min. Z-axis: 18,000 mm/min. Spindle/auto. Milling head: Speed 22 - 4,000 rpm Torque max. 1180 Nm Total current load: approx. 50 kVA/80 A. Without clamping plate Without chip conveyor

Condition: good (used), Year of construction: 2015, functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,000 mm, feed rate X-axis: 85 m/min, feed rate Y-axis: 85 m/min, feed rate Z-axis: 40 m/min, table length: 3,500 mm, table width: 2,000 mm, spindle speed (max.): 28,000 rpm, table height: 250 mm, rapid traverse X-axis: 85 m/min, rapid traverse Y-axis: 85 m/min, rapid traverse Z-axis: 40 m/min, table load: 5,000 kg, torque: 70 Nm, rotational speed (max.): 28,000 rpm, overall weight: 22,000 kg, Equipment: rotational speed infinitely variable, Year of manufacture: 2015 X-axis: approx. 2,500 mm Y-axis: approx. 3,000 mm Djdpfx Adjxl Tl Usuowc Z-axis: approx. 1,000 mm A-axis: +/- 115° C-axis: +/- 270° Control system: SIEMENS SINUMERIK 840D SL Clamping table, subfloor Length x Width x Height: approx. 3,500 x 2,000 x 250 mm (cast iron) Table load: max. 5,000 kg/m² T-slots: 22H12 T-slot spacing: 250 mm Milling spindle Spindle power S1 / S6: 40 / 54 kW Spindle speed: max. 28,000 rpm Tool holder: HSK 63A Torque S1 / S6: 51 / 70 Nm Linear axis drives Feed rate X and Y axes: up to 85 m/min Feed rate Z axis: up to 40 m/min Connection data Connected load: approx. 55 kW Line protection: 45 A Dimensions, weights Machine footprint: approx. 6,650 x 6,200 x 5,000 mm Total weight: 21,000 kg Description: Additional equipment - 2x chip conveyors - Protective bellows with compressed air sealing - 40 bar ICS coolant supply with belt filter system - Minimum quantity lubrication - 30-position tool changer Optional - Renishaw RMP60 Condition of the machine Fully functional condition, regularly serviced by the manufacturer. Immediately available and still connected to power. Special note The machine requires a special foundation so that the table and chip conveyors can be recessed into the floor.

Condition: good (used), Year of construction: 1992, functionality: fully functional, Technical details x-travel 300 mm y-travel 160 mm z-travel 290 mm table surface area 210 x 600 mm table load max. 200 kg tool taper SK 40 spindle turning speed range (16) 40 - 2000 U/min feeds -stepless- 5 - 500 mm/min rapid traverse 1,2 m/min spindle motor 1,5 / 1,9 kW total power requirement 9,5 kVA weight of the machine ca. 730 kg dimensions of the machine ca. 2000 x 2200 x 1655 mm Additional information The machine is in very good condition and comes from a research centre. Equipment: 3-axis active digital readout made by Heidenhain TNC 113 Fixed angle table Dwodexl Tcgjpfx Aduec Coolant equipment Kelch mounting block Machine vise Counterholding device for the horizontal spindle

Condition: good (used), Year of construction: 1985, Technical Data – Bridgeport Series I Table Size / Work Area 9″ × 49″ (approx. 299 mm × 1245 mm) T-Slots 3 slots, spacing 2.5″ (approx. 64 mm), slot width 0.625″ (approx. 16 mm) Travel Paths X (Longitudinal) without power feed: 36″ (approx. 914 mm) Dsdpsxl R N Defx Aduswc with power feed: 33″ (approx. 838 mm) Traverse Y (Cross Travel) 12″ (approx. 306 mm) Quill Stroke (Quill Travel) 5″ (approx. 127 mm) Knee Travel (Z-Axis/Table Elevation) 16″ (approx. 406 mm) Ram Travel (Headstock Fore/Aft on Ram) 12″ (approx. 306 mm) Min./Max. Distance Spindle Axis to Table Top (Spindle to Table Surface) min: 2.5″ (approx. 64 mm) max: 18.25″ (approx. 463 mm) Min./Max. Distance Spindle to Column Front (Min./Max. Throat) min: 6.75″ (approx. 171 mm) max: 18.75″ (approx. 476 mm) Spindle / Quill Spindle diameter: 1.875″ (approx. 48 mm) Quill diameter: 3.375″ (approx. 86 mm) Spindle taper (standard): R-8 Spindle Motor / Power 30 min. rating: 3 HP (approx. 2.2 kW) Continuous duty: 2 HP (approx. 1.5 kW) Spindle Speed Range (variable, two speed ranges) Low: 60 – 500 rpm High: 500 – 4200 rpm Drilling Capacity (Power Quill Feed, mild steel) approx. 3/8″ (approx. 9.5 mm) Milling Capacity (mild steel, cutting) approx. 2 CI/min (Cutting Inches per Minute) Drilling Radius (mild steel) up to Ø 6″ (approx. 152 mm) Traverse Speeds (X/Y) manual / automatic up to 100 ipm (approx. 2540 mm/min) in CNC models Machine Footprint & Height Floor space: 84″ × 120″ (approx. 2140 mm × 3048 mm) Overall height: 87″ (approx. 2210 mm) Net Weight / Shipping Weight Net weight: approx. 1930 lbs (approx. 875 kg) Maximum Workpiece Weight (on table) approx. 750 lbs (approx. 340 kg)

Condition: new, Year of construction: 2025, Ref. -No.: 10463 Manufacturer: IGREK Type: FR 3500 XL Year of construction: 2025 Type of control: CNC Control: Siemens 840 D / Heidenhain iTNC 640 Storage location: Istanbul Country of origin: Türkiye X-Travel: 6500 mm Y-Travel: 3500 mm Z-Travel: 1400 mm A-Axis: +/- 115 ° C-Axis: 360 ° Turning Speeds: 12500 RPM Max. Torque: 235 Nm Rapid Traverse X/Y/Z: 30 m / min Table-Size (Lxw): 2290 - 6490 x 3580mm mm Drive power spindle: 54 kW Table load max.: 4000 kg Tool Taper: HSK-A100 Machine length: 11500 mm Machine width: 7400 mm Machine Height: 6600 mm Weight: 120 t Further information: IGREK FR 3500 XL – Precision and performance at the highest level The IGREK FR 3500 XL is a CNC-controlled 5-axis portal milling machine of the latest generation (year of manufacture 2024). It was specially developed for the demanding machining of large workpieces and impresses with its versatility and precision. With a modern control system from Siemens 840D or Heidenhain iTNC 640 and a robust construction, the machine offers optimal conditions for manufacturing in a wide range of industries. Key features: Dsdjxmd Szopfx Aduswc Large machining areas: With travel distances of 6,500 mm (X), 3,500 mm (Y) and 1,400 mm (Z), the machine is ideal for machining large components. 5-axis simultaneous machining: The A-axis with a swivel range of +/- 115° and the C-axis with a rotation of 360° enable highly precise machining of complex geometries. Powerful spindle: The spindle reaches speeds of up to 12,500 rpm and a maximum torque of 235 Nm – perfect for demanding milling work. High stability: The machine weight of 120 tons and the table load of up to 4,000 kg ensure low-vibration machining even with heavy workpieces. Flexible tool holding fixture: The HSK-A100 tool holding fixture enables quick tool changes and optimal process times. Rapid feed rate: High productivity is achieved with 30 m/min in the X, Y and Z directions. Technical data at a glance: Table size: 2,290 – 6,490 x 3,580 mm Spindle power: 54 kW Max. torque: 235 Nm Tool holder: HSK-A100 Machine dimensions (LxWxH): 11,500 x 7,400 x 6,600 mm Max. table load: 4,000 kg The IGREK FR 3500 XL sets new standards in the machining of large parts. It is available immediately and offers comprehensive warranties and services directly from the manufacturer, internationally and across the board. Use the latest technology for your production – contact us for further details!

Condition: excellent (used), Year of construction: 2008, operating hours: 82,500 h, functionality: fully functional, travel distance X-axis: 5,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,750 mm, feed rate X-axis: 65 m/min, feed rate Y-axis: 65 m/min, feed rate Z-axis: 65 m/min, spindle speed (max.): 20,000 rpm, rapid traverse X-axis: 65 m/min, rapid traverse Y-axis: 65 m/min, rapid traverse Z-axis: 65 m/min, torque: 63 Nm, overall weight: 90,000 kg, Equipment: rotational speed infinitely variable, First commissioning: 2008 Control system: Heidenhain iTNC 530 incl. HR420 handwheel X-axis: approx. 5,000 mm Y-axis: approx. 3,000 mm Z-axis: approx. 1,750 mm A-axis: -120 / +95° C-axis: ±360° Maximum workpiece dimensions 3,800 mm (X-direction) 1,800 mm (Y-direction) 1,150 mm (Z-direction) 5-axis machining is possible in a single setup with a 300 mm long tool (A-axis at 90° swivel). Machine operating hours: approx. 82,500 h Total spindle hours: approx. 36,500 h Clamping table No machine table is included in the delivery. However, we are happy to offer a customer-specific solution at extra cost. Dwjdpfx Aoxl R Hvsdujc 2-axis fork-type milling head 5 Spindle power: 20 kW Spindle speed: max. 20,000 rpm Torque: max. 63 Nm Tool holder: HSK 63A Tool release: hydraulic Holding torque (clamped) A & C axis: 2,000 Nm Drives, linear axes Feed rate X, Y, and Z axis: up to 65 m/min Axis acceleration X, Y, and Z: up to 5 m/s² Connection data Voltage: 400 V Frequency: 50 Hz Power requirement: 130 kW Dimensions, weight Space required machine without peripherals: approx. 7,500 x 8,500 x 6,600 mm Total weight: approx. 90,000 kg Colour Enclosure, portal, control cabinet: RAL 7035 light grey Milling head and applications: RAL 5002 aquamarine blue Additional equipment - Minimum quantity lubrication - 50-fold tool changer - Work area enclosure Optionally available at extra cost: - Renishaw RMP60 probe - BLUM LaserControl NT mini Condition of the machine Fully functional, in very good condition. Can be inspected under power until April 2026.

Condition: good (used), Year of construction: 2002, Ref. -No.: 10442 Manufacturer: LIEBHERR Type: LC 122 Year of construction: 2002 Type of control: CNC Control: LIEBHERR PC NC Storage location: Halberstadt Country of origin: Germany Hob diameter max.: 90 mm Dwjdsxmd Shepfx Adusc Table Diameter: 145 mm Max. Module: 3 mm Smallest number of millable teeth: 4 Milling head swivel angle: +/- 45 ° Resolution accuracy: 0,1 Degree Workpiece table load: 17 kN Milling speed: 450 - 4.500 1 / min Operating voltage: 400 V control voltage: 24 V frequency: 50 Hz Max. rated current: 55 A Fuse in the supply line: 63 A Max. milling diameter spur gears/helical gears: 125 mm Max. milling width spur gears/helical gears: 250 (axial) mm Spindle stroke: 180 mm Max. cutter width: 200 mm Further information: Ambient temperature: +12°.....+40° Operating noise: 78 dB (A) Milling head designation: motor milling head Workpiece axis: vertical Stand: movable Table: fixed Milling method: axial hobbing in the same or opposite direction The machine can be inspected under power by arrangement.
