Used Hydraulic Bed Plates for sale (27,585)

Condition: ready for operation (used), Year of construction: 2000, sheet width 1030 mm plate thickness 12.0 mm thickness at "Niro-steel" 8.0 mm blade length 1050 mm cutting angle 3.0 Grad no. of strokes ca. 10 Hub/min back stop - adjustable 500 mm Control konv. table height 900 mm operating pressure max. 280 bar oil volume 150 l engine output 11.0 kW weight 1900 kg range L-W-H 1550 x 1150 x 1600 mm Machine from a maintenance workshop (!) Furnishing: - heavy / robust electro-hydraulic sheet metal plate shears - Machine body in a closed design as an all-steel welded construction - Knife upper cheek slides in a long downward direction over the knife edge . protruding plastic guides - Cutting is done hydraulically via two hydraulic cylinders Djdpfx Acexyafdo Nekh - The upper beam returns to its starting position in two ways . Spring batteries on the side stands - manual back gauge, adjustable from the rear * Adjustment by handwheel, with mm scale - manual cutting gap adjustment - 1x side stop, with mm scale and T-slot - Foot switch for lifting version - rear sheet metal slide - instruction manual * Machine link: ?machineno=1008-9325319

Condition: good (used), sheet width 2540 mm plate thickness 4.0 mm thickness at "Niro-steel" 3.0 mm 9.0 St. back stop - adjustable 100 mm/sek cutting angle 1° 20 table height 855 mm table depth 500 mm no. of strokes 33 - 55 Hub/min 0 max. 250 bar engine output 5.5 kW weight of the machine ca. 5000 kg. range L-W-H 3500 x 2000 x 1750 mm From a maintenance workshop Good / well-maintained condition (!!) Equipment: - Powerful electro-hydraulic guillotine shear - AMADA NC control unit * Pivoting control panel, front left - NC electro-motorized material backgauge * Backlash-free ball screw - Manual cutting gap adjustment with 2 levers - 1x long side stop - 1x support arm - Rigid welded machine body Dkedpfjxn Tx Hex Ac Njh - Sighting device with three mirrors (cutting according to marking) - Front safety guard (finger protection) - 1 freely movable foot switch - Operating instructions (PDF) * Special accessories included: - Sheet metal holding device for thin sheet metal blanks

Condition: used, Year of construction: 1993, Technical details: sheet width: 3150 mm plate thickness: 13 mm distance between columns: 3670 mm Knife length: 3150 mm down holder: 18 Stück back gauge: motorisch 1000 height over floor: 850 mm operating hours: 3256 Table dimensions: LxB: 3770 x 500 mm total power requirement: 30 kW weight of the machine ca.: 12,9 t dimensions of machine: 4,4 x 2,8 x 2,4 m Short stroke Continuous run Gap lighting Hydraulic sheet metal lifting device rear light curtain Positionable backgauge * Dkjdpfxju Icnfo Ac Nsh

Condition: used, Year of construction: 1993, Technical details: sheet width: 3050 mm plate thickness: 6,0 mm distance between columns: 3460 mm no. of strokes: min./max.: 9 / 17 Hub/min back gauge: 750 mm (motorisch) mm cutting angle: 0,5° - 3,0° ° cutting gap adjustment: manuell mm down holder: 18 Stück (hydraulisch) Stück Table dimensions: 380 x 3100 mm total connected load: 7,5 kW weight of the machine ca.: 4,56 t dimensions of machine: L: 3,64 x B: 2,55 x H: 1,58 m Equipment: Dkjdpju Rni Hjfx Ac Njh With side stop L: 1000 × W: 100 × H: 60 mm and stop bar 990 mm, with 8 supports Operation via control panel and foot switch Cutting zone lighting Stroke counter Machine feet *

Condition: ready for operation (used), Heavy hydraulic press Dkedpfxju R U Szo Ac Nsh

Condition: new, functionality: fully functional, control type: CNC control, actuation type: hydraulic, controller manufacturer: Cybelec, controller model: Cybtouch 8, working width: 3,120 mm, cutting angle (max.): 2 °, sheet thickness (max.): 10 mm, back gauge adjustment: CNC-controlled, back gauge: 1,000 mm, power: 22 kW (29.91 HP), control voltage: 480 V, total length: 3,850 mm, total width: 2,745 mm, total height: 2,000 mm, warranty duration: 12 months, Equipment: CE marking, angle stop, documentation/manual, emergency stop, finger protection, foot remote control, safety light barrier, type plate available, Comparable to Durma, Baykal, Ermaksan, etc. Swing Beam Shear with Fixed Cutting Angle / Swing Beam Type Maximum cutting length: 3120 mm Maximum sheet thickness (at 450 N/mm²): 10 mm Cutting angle: 2 degrees Number of hold-downs: 15 pcs Motor power: 22 kW Cutting speed: 12 strokes/min Oil tank capacity: 200 l Machine length: 3850 mm Machine width: 2175 / 3060 mm with supports Overall width: 2745 mm Machine height: 2000 mm Machine weight: 13,500 kg Throat depth: 150 mm Standard equipment: CE safety equipment / compliance Maper control with memory function Manual central blade gap adjustment / handwheel Adjustment of cutting length via control panel Support balls integrated in the table Motorised, programmable backgauge 1000 mm via ball screw Folding finger guard up to 1000 mm 1 x 1000 mm support arm with scale, T-slot, tilting stop, support balls 2 x 1000 mm support arms with integrated balls Cutting line illumination via shadow line and LED lighting High-quality upper blades with 2 cutting edges High-quality lower blades with 4 cutting edges Option: CNC control Cybelec CybTouch 8 G The powerful upgrade for all types of high-quality guillotine shears. Djdpfoxyw Icox Ac Nekh High-contrast touchscreen with vibrant colors Clear display with all necessary information for the operator Intuitive and user-friendly Complete part programming in seconds CNC blade gap adjustment Automatic blade gap setting after entering material data on the control panel

Condition: new, functionality: fully functional, control type: CNC control, actuation type: hydraulic, controller manufacturer: Cybelec, controller model: Cybtouch 8, working width: 3,120 mm, sheet thickness (max.): 6 mm, back gauge adjustment: CNC-controlled, back gauge: 1,000 mm, power: 11 kW (14.96 HP), control voltage: 480 V, total length: 3,840 mm, total width: 2,050 mm, total height: 1,700 mm, warranty duration: 12 months, Equipment: CE marking, angle stop, documentation/manual, emergency stop, finger protection, foot remote control, safety light barrier, type plate available, Comparable to Durma, Baykal, Ermaksan Swing beam guillotine shear with fixed cutting angle Max. cutting length: 3120 mm Max. sheet thickness (at 450 N/mm2): 6 mm Cutting angle: 1.39 degrees Number of hold-downs: 15 units Motor power: 11 kW Cutting speed: 18 strokes/min Oil tank capacity: approx. 200 l Machine length: 3840 mm Machine width: 2050 mm Overall width: 2745 mm Machine height: 1700 mm Machine weight: 8800 kg Throat depth: 150 mm Standard equipment: CE safety equipment / conformity Maper control unit with memory function Manual central blade gap adjustment via handwheel Cutting length adjustment via control panel Ball transfer tables Motorized, programmable backgauge 1000 mm with ball screw drive Folding finger guard up to 1000 mm 1 piece 1000 mm stop arm with scale, T-slot, flip stop, ball bearings 2 pieces 1000 mm support arms with integrated ball bearings Cutting line illumination via shadow outline, LED lighting High-quality upper blades with 2 cutting edges High-quality lower blades with 4 cutting edges Option: CNC control Cybelec CybTouch 8 G The powerful addition to all types of high-quality guillotine shears. Dksdpfjxyxuqjx Ac Njh High-contrast touchscreen with vivid colors. Clear display with all information needed by the operator. Intuitive and user-friendly. Complete part programming in seconds. CNC blade gap adjustment Automatic blade gap adjustment after material data input via control panel

Condition: new, functionality: fully functional, control type: CNC control, actuation type: hydraulic, controller manufacturer: Cybelec, controller model: Cybtouch 8, working width: 4,160 mm, sheet thickness (max.): 13 mm, back gauge adjustment: CNC-controlled, back gauge: 1,000 mm, power: 30 kW (40.79 HP), control voltage: 480 V, overall weight: 16,850 kg, total length: 4,930 mm, total width: 3,160 mm, total height: 2,100 mm, warranty duration: 12 months, Equipment: CE marking, angle stop, documentation/manual, emergency stop, finger protection, foot remote control, safety light barrier, type plate available, Comparable to Durma, Baykal, Ermaksan, etc. Swing beam guillotine shearing machine with fixed cutting angle Maximum cutting length: 4160 mm Maximum sheet thickness: 13 mm (at 450 N/mm²) Cutting angle: 2 degrees Number of hold-downs: 19 Motor power: 30 kW Cutting speed: 8 strokes/min Oil tank: 400 l Machine length: 4930 mm Machine width (without support arms): 2345 mm Total width: 3160 mm Machine height: 2100 mm Machine weight: 16,850 kg Gap depth: 150 mm Standard equipment: CE safety equipment / conformity Manual central blade gap adjustment / handwheel Cutting length adjustment via control panel Support balls in the table Dkedpfxoxyxxco Ac Neh Motorized, programmable backgauge 1000 mm via ball screw drive Folding finger guard over 1000 mm 1 piece 1000 mm stop arm with scale, T-slot, flip stop, support balls 2 pieces 1000 mm support arms with integrated balls Cutting line illumination via shadow projection, LED lighting Adjustable shadow line High-quality top blade with 2 cutting edges High-quality bottom blade with 4 cutting edges Features: CNC control Cybelec Cybtouch 8 Pneumatic sheet support device Front finger guard with light barrier CNC-controlled blade gap adjustment Service and spare parts supply provided by Viering Werkzeuge Maschinen GmbH. Other Dener sheet metal working machines available upon request.

Year of construction: 1988, condition: used, sheet width 1500 mm plate thickness 3 mm weight of the machine ca. 4 t dimensions of the machine ca. BxTxH 2000x1500x1800 mm Dksdpfxolp U Txs Ac Neh

Condition: excellent (used), functionality: fully functional, Year of construction: 2017, Amada Hydraulic Guillotine Shear Type GX II 630 Working width: 3050 mm Max. sheet thickness: 6.35 mm Robust CNC electro-hydraulic guillotine shear AMADA CNC touch control, located front left ("GP 37W2") Machine control system including information display Main display with 4 operating panels Control/operation of all machine functions Up to 50 cutting programs, each with up to 15 sequences CNC electromechanical backgauge Travel speed: 100 mm/sec Dkedpfjxwmycex Ac Noh CNC electro-hydraulic cutting angle adjustment CNC electro-hydraulic blade gap adjustment Sight device & cutting line illumination for viewing the scribe line Shearing according to optical scribe mark Manually adjustable table support plates including ball rollers Grip recesses in the front support table 2x movable foot switches Operating manual and circuit diagrams included

Condition: good (used), Year of construction: 2004, machine/vehicle number: 69839, Offer 25493 Dkedjx D Uzzepfx Ac Nsh Technical data: - Cutting length: 3050 mm - Cutting thickness at 400 N/mm² tensile strength: 13 mm - Cutting thickness at 400 N/mm² tensile strength (up to 1000 mm length): 15 mm - Cutting angle: 0.5 – 3° - Number of sheet hold-downs: 18 pcs - Strokes per minute: 10 – 23 min⁻¹ - Powered backgauge up to: 1000 mm - Rear area secured with light barrier - Front squaring arm: 1000 mm - HSLX version features: - CNC control HACO SC 5 controller (sheet thickness input in mm) - Automatic cutting angle adjustment by sheet thickness - Cutting length limitation - Automatic positioning of the backgauge (8 programs – 80 sets) with digital display and automatic backgauge retraction - Option for powered backgauge adjustment via 2 push buttons - Drive: 400 V / 22 kW - Electric foot pedal - Space requirement without support arms: approx. W 4200 x H 2250 x D 2200 mm - Weight: approx. 9000 kg - The machine has been welded in various places by the previous owner and has only been repainted on the front side.

Condition: good (used), Year of construction: 2000, sheet width 3100 mm plate thickness 13.0 mm thickness at "Niro-steel" 8.0 mm down holder 14 Stück no. of strokes max. 11 Hub/min cutting angle 1°15 work height max. 770 mm column arm ? mm oil volume 300 ltr. control konv. total power requirement 15.0 kW weight 11800 kg range L-W-H 4255 x 2250 x 2400 mm Features: - Robust electro-hydraulic swing pruning shears - Operation, swivels to the front left - Electro-motorized backgauge * on recirculating ball screws * Movement by push-button (forwards backwards) * including ELGO digital position indicator - Manual quick cutting gap adjustment * by eccentric (right side stand) - Machine stand with overhang - 1x long side stop, with mm scale - 2x front support arms, with mm scale - Ball rollers in the front support table - Hinged front finger guard - 1x free-moving foot switch - Rear safety device (protective grille) - 2x front emergency stop button Djdpfxjx Ni D Rs Ac Nokh - Operating instructions (PDF)

Condition: good (used), functionality: fully functional, Sheet width: 4050 mm Sheet thickness: 8 mm Dodpjxu Nc Iefx Ac Nskh Cutting angle: 2 - 10° Cutting speed: 0.053 m/s Table length: 710 mm Machine weight approx.: 10,100 kg

Condition: new, neu ca. 12 - 14 Wochen ab Auf Türkei 62400 € 1179.36 € 4100 mm 6 mm 4 mm 50 mm 12 1/min 1.5 ° 20 17 to 1000 mm 200 mm/s 15 kW 200 l 3 Stk. 865 mm 580 mm 4510 mm 5230 mm 2300 mm 3600 mm 2150 mm 11460 kg Swing cut construction NC-preselection system D-touch 7 with touch screen for back gauge, cutting length, quantity, USB port Motorized back gauge 1000 mm on ball screws, folding upwards Clear control panel mounted on moveablearm Hydraulic hold down pistons are arrangedclose to the cutting edge Foot switch Central, manual blade gap adjustment Cutting line illumination Broad table with balls Piece counter Single and continous stoke Fold up finger guard 1.000 mm 1 squaring arm 1. 500 mm with scale,T-slot and tilting cam 2 supporting arms 1.000 mm with T-slot Djdjwiqw Sspfx Ac Nokh Simple replacement and grinding of theblades Variable adjustable cuttinglength for economic processing Lower blade fourfold turnable Upper blade double turnable Oilfilling Light barrier on the back of the machine Qualified customer support User manual in GERMAN and ENGLISH according to CE rules (sample photo) WE HAVE MORE THAN 850 REFERENCES!

Condition: new, neu ca. 10 Wochen ab Auftrags Türkei 59600 € 1126.44 € 3100 mm Dsdpfswiqxcox Ac Njkh 10 mm 6 mm 50 mm 13 1/min 1.5 ° 16 22 to 1000 mm 200 mm/s 22 kW 200 l 2 Stk. 865 mm 580 mm 3515 mm 4200 mm 2250 mm 3600 mm 2100 mm 9300 kg Swing cut construction NC-preselection system D-touch 7 with touch screen for back gauge, cutting length, quantity, USB port Motorized back gauge 1000 mm on ball screws, folding upwards Clear control panel mounted on moveablearm Hydraulic hold down pistons are arrangedclose to the cutting edge Foot switch Central, manual blade gap adjustment Cutting line illumination Broad table with balls Piece counter Single and continous stoke Fold up finger guard 1.000 mm 1 squaring arm 1. 500 mm with scale,T-slot and tilting cam 2 supporting arms 1.000 mm with T-slot Simple replacement and grinding of theblades Variable adjustable cuttinglength for economic processing Lower blade fourfold turnable Upper blade double turnable Oilfilling Light barrier on the back of the machine Qualified customer support User manual in GERMAN and ENGLISH according to CE rules WE HAVE MORE THAN 850 REFERENCES!

Condition: new, neu ca. 12 - 14 Wochen ab Auf Türkei 94900 € 1793.61 € 4100 mm 13 mm 8 mm 350 mm 8 1/min 1.75 ° 18 62 to 1000 mm 200 mm/s 30 kW 330 l 3 Stk. 818 mm 550 mm 4520 mm 5350 mm 2250 mm 3650 mm 2250 mm 16300 kg Swing cut construction NC-preselection system D-touch 7 with touch screen for back gauge, cutting length, quantity, USB port Motorized back gauge 1000 mm on ball screws, folding upwards Clear control panel mounted on moveablearm Hydraulic hold down pistons are arrangedclose to the cutting edge Foot switch Central, manual blade gap adjustment Cutting line illumination Broad table with balls Piece counter Single and continous stoke Fold up finger guard 1.000 mm 1 squaring arm 1. 500 mm with scale,T-slot and tilting cam 2 supporting arms 1.000 mm with T-slot Simple replacement and grinding of theblades Variable adjustable cuttinglength for economic processing Lower blade fourfold turnable Upper blade double turnable Oilfilling Light barrier on the back of the machine Qualified customer support User manual in GERMAN and ENGLISH according to CE rules Dkjdswirynspfx Ac Nsh (sample photo) WE HAVE MORE THAN 850 REFERENCES!

Condition: new, neu ca. 10 Wochen ab Auftrags Türkei 68700 € 1298.43 € 3100 mm 13 mm 8 mm 50 mm 13 1/min 1.75 ° 16 37 to 1000 mm 200 mm/s 30 kW Dkedpfx Acowir D He Noh 330 l 2 Stk. 840 mm 600 mm 3550 mm 4280 mm 2300 mm 3600 mm 2350 mm 12500 kg Swing cut construction NC-preselection system D-touch 7 with touch screen for back gauge, cutting length, quantity, USB port Motorized back gauge 1000 mm on ball screws, folding upwards Clear control panel mounted on moveablearm Hydraulic hold down pistons are arrangedclose to the cutting edge Foot switch Central, manual blade gap adjustment Cutting line illumination Broad table with balls Piece counter Single and continous stoke Fold up finger guard 1.000 mm 1 squaring arm 1. 500 mm with scale,T-slot and tilting cam 2 supporting arms 1.000 mm with T-slot Simple replacement and grinding of theblades Variable adjustable cuttinglength for economic processing Lower blade fourfold turnable Upper blade double turnable Oilfilling Light barrier on the back of the machine Qualified customer support User manual in GERMAN and ENGLISH according to CE rules (sample photo) WE HAVE MORE THAN 850 REFERENCES!

Condition: new, neu ca. 12 - 14 Wochen ab Auf Türkei 145000 € 2740.5 € 6080 mm 6 mm 4 mm 350 mm 10 1/min 0,5 - 2 ° Dksdpfx Ajwiqygoc Neh 29 20 to 1000 mm 200 mm/s 22 kW 200 l 5 Stk. 900 mm 630 mm 6370 mm 7300 mm 2150 mm 3400 mm 2750 mm 25500 kg linear guided CNC touch screen D-touch 7back gauge,cutting angle,cutting gap,cutting length, quantity USB port CNC controlled cutting gap adjustment by the table (patented) oil cooler manual central lubrication cutting line illumination foldable ball screws for back gauge balls in table foldable finger protection, 1.000 mm side lay with T-slot, tilting cam and scale 5 support arms wit T-slots oilfilling light barrier on the back of the machine user manual in GERMAN and ENGLISH PRICE FCA TURKEY (sample photo)

Condition: new, neu ca. 10 Wochen ab Auftrags Türkei 51600 € 975.24 € 3080 mm 6 mm 4 mm 350 mm 20 1/min 0,5 - 2 ° 16 20 to 1000 mm 200 mm/s 11 kW 125 l 3 Stk. 820 mm 494 mm 3280 mm 4100 mm 2050 mm 3650 mm 1950 mm 7980 kg linear guided CNC touch screen D-touch 7back gauge,cutting angle,cutting gap,cutting length, quantity Dsdowirwtjpfx Ac Nokh USB port cutting line illumination foldable ball screws for back gauge balls in table foldable finger protection, 1.000 mm side lay with T-slot, tilting cam and scale 3 support arms wit T-slots oilfilling light barrier on the back of the machine user manual in GERMAN and ENGLISH

Condition: good (used), Year of construction: 2000, sheet width 3050 mm plate thickness 10.0 mm thickness at "Niro-steel" 6.0 - 8.0 mm down holder 13 Stück distance between columns 3070 mm cutting angle 1.0 - 4.0 ° no. of strokes ~ 22 Hub/min Control ELGO P8511 oil volume 240 l voltage 400 V total power requirement 15.0 kW weight 8000 kg range L-W-H 3550 x 2350 x 1900 mm good / well-maintained condition with special accessories (!!) Equipment: - NC electro-hydraulic guillotine shears - heavy / stable welded construction (machine body) - NC ELGO digital control unit "P8511" - NC electro-motorized backgauge on ball screws - electro-hydraulic cutting angle adjustment * Front analog cutting angle display - 1x stable side stop, with T-slot and mm scale - 3x stable support arms, with T-slot and mm scale - Ball castors in the work table incl. recessed grips - Front finger guard - can be folded up at the front - 1x freely movable foot switch - 2x front EMERGENCY OFF button - Operating instructions (PDF) Dkodpox Emqyefx Ac Neh

Condition: used, functionality: fully functional, Year of construction: 1978, Used 3-meter guillotine shear from Luther Werke Model: TS H 30 6 Djdpfex D Uwpox Ac Njkh Capacity: 3100 x 6 mm Electric guillotine shear Year of manufacture: 1978

Condition: good (used), functionality: fully functional, Year of construction: 2005, Used 4-meter guillotine shears from Haco Model: HSL 4010 Capacity: 4100 x 10 mm Dkodpfx Acox D Uvrs Noh Electric back gauge Year of manufacture: 2005

Condition: ready for operation (used), functionality: fully functional, Year of construction: 1997, working width: 4,050 mm, cutting angle (min.): 2 °, cutting angle (max.): 10 °, sheet thickness (max.): 8 mm, back gauge: 1,000 mm, TECHNICAL DETAILS Sheet width: 4,050 mm Sheet thickness: 8 mm Cutting angle: 2 - 10° Cutting speed: 0.053 m/s Table length: 710 mm Electric back gauge: 1,000 mm MACHINE DETAILS Djdpfxexxr H Rs Ac Nskh Machine weight: approx. 10,100 kg EQUIPMENT Support arms for material Sheet lifting device Scrap container Cutting gap and angle adjustment via the control system

Condition: used, functionality: fully functional, Year of construction: 1987, machine/vehicle number: 101536, Offered for sale is a hydraulic guillotine shear Manufacturer: Eisen und Hammerschmidt GmbH Model: TSS4-20 Year of manufacture: 1987 Serial No.: 101536 Capacity: 4 mm Working width: 2,000 mm Control: ELGO Type P8511 Light curtain system by SICK Used, fully functional condition. Collection by purchaser; assistance with dismantling/transport can be arranged if required. — If you are interested or have any questions, please feel free to send me a message. Viewing on site by appointment possible. Djdpfxox Da D Us Ac Njkh Further metalworking machinery such as bench drills, press brakes, column drilling machines, eccentric presses, heavy-duty racking, welding tables, MIG welders, compressors, etc. – please take a look at my other listings. Location for viewing and collection: 12277 Berlin Domestic price net plus VAT or Net export price Collection only – dismantling and transport by buyer or by arrangement. If you are interested or have any questions, please feel free to send me a message. Further photos and technical details available on request. All information is subject to change without notice. Errors and prior sale reserved. For further questions, please call Nous parlons Français / Мы говорим по-русски We speak English / Noi vorbim românește Viber / WhatsApp / Skype We handle all customs and registration matters for an additional charge. For an extra fee, we can transfer the vehicles to the port.

Condition: good (used), Year of construction: 1997, machine/vehicle number: 68868, Offer 25500 Technical Data: - Cutting length: 3050 mm - Cutting thickness at 400 N/mm² tensile strength: 13 mm - Cutting thickness at 400 N/mm² tensile strength (up to 1000 mm length): 15 mm - Cutting angle: 0.5 – 3° - Number of sheet hold-downs: 18 pcs - Strokes per minute: 10 – 23 min⁻¹ - Motorized backgauge up to: 1000 mm Dedpfx Acex A Tpne Nokh - Rear guard with light barrier - Front angular stop: 1000 mm - HSLX version: – CNC control HACO SC 5 Controller with input of sheet thickness in mm – Automatic cutting angle adjustment according to sheet thickness – Limit for cutting length – Automatic positioning of backgauge (8 programs – 80 sets) with digital display and automatic backgauge retraction – Motorized backgauge adjustment possible via 2 push buttons - Drive: 400 V / 22 kW - Electric foot switch - Space requirement without support arms: approx. W 4200 x H 2250 x D 2200 mm - Weight: approx. 8500 kg
