Used Hydraulic Bed Plates for sale (29,246)

Condition: good (used), Year of construction: 1997, machine/vehicle number: 68868, Offer 25500 Technical Data: - Cutting length: 3050 mm - Cutting thickness at 400 N/mm² tensile strength: 13 mm - Cutting thickness at 400 N/mm² tensile strength (up to 1000 mm length): 15 mm - Cutting angle: 0.5 – 3° - Number of sheet hold-downs: 18 pcs - Strokes per minute: 10 – 23 min⁻¹ - Motorized backgauge up to: 1000 mm Isdpfxox A Tpne Ahbotn - Rear guard with light barrier - Front angular stop: 1000 mm - HSLX version: – CNC control HACO SC 5 Controller with input of sheet thickness in mm – Automatic cutting angle adjustment according to sheet thickness – Limit for cutting length – Automatic positioning of backgauge (8 programs – 80 sets) with digital display and automatic backgauge retraction – Motorized backgauge adjustment possible via 2 push buttons - Drive: 400 V / 22 kW - Electric foot switch - Space requirement without support arms: approx. W 4200 x H 2250 x D 2200 mm - Weight: approx. 8500 kg

Condition: used, Year of construction: 2018, sheet width 4050 mm plate thickness 20 mm distance between columns 4100 mm column daylight 4200 mm no. of strokes 10-20 Hub/min working pressure 250 bar total power requirement 85 kW weight of the machine ca. 43,6 t dimensions of the machine ca. 5,5x2,8x2,9 m No. 793 Please note: this machine has no electrical system. The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop Iodpfx Aheyqvchebotn If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1990, plate width 2503 mm plate thickness 4.0 mm ST plate thickness 2.5 mm VA plate thickness 6.0 mm ALU Itedpfx Aoxabd Uohben number of strokes - loaded 15 - 20 Hübe/min cutting angle 1.7 ° work height max. 900 mm Control ELGO TYP 85 total power requirement 8.5 kW weight of the machine ca. 3400 kg range L-W-H 2913 x 2250 x 1760 mm Features: - Robust NC electro-hydraulic guillotine shear - NC electro-motorized backgauge * with ELGO control unit - Manual cutting gap adjustment - Front support table including recessed grips - 1x sturdy side stop with scale and tilting cam - 2x sturdy front support arms - 1x freely movable foot switch - Front finger guard - Front emergency stop button - Operating instructions (PDF)

Condition: used, Year of construction: 1982, sheet width - max. 1255 mm plate thickness 4.0 mm ST Iodpjxaa I Sjfx Ahbotn plate thickness 2.0 mm VA plate thickness 6.0 mm ALU number of strokes - loaded ~ 66 Hübe/min. cutting angle 1.5 ° back stop - adjustable max. ~ 1.000 mm total power requirement 5.5 kW weight of the machine ca. 2600 kg. range L-W-H 1750 x 1800 x 1800 mm Machine from a technical college - prototype construction very well-maintained condition (!!) Furnishing: - electro-hydraulic guillotine shears - manual backgauge with analogue position display (scale + magnifying glass) - electrical cutting length limitation - manual cutting gap adjustment - 1x extra long side stop - 2x extra long support arms - 1x free moving footswitch - rear sheet metal slide - User manual (PDF) * Machine link : ?machineno=1008-9325278

Condition: excellent (used), Year of construction: 2007, Technical data: Working length: 2550 mm Max. bending capacity for small diameters: 12.0 mm Bending capacity from diameter 900 mm: 18 mm Bending allowance: 10 / 12.0 mm Itsdpfx Ahjztckisbon Roller diameter: 310 mm Hydraulic folding bearing Drive power: 11 kW Lateral bending support Sheet metal holding device Digital display Dimensions (length x width x height): approx. 4200 x 1500 x 1650 mm Weight: approx. 10 tons Condition: Overall in very good condition, used only sparingly. The seller is not liable for typographical or data transmission errors. The machine's appearance, technology, and wear are consistent with its age; used machines are sold without any warranty.

Condition: used, Year of construction: 1984, plate width 3100 mm plate thickness 6 mm distance between columns 3150 mm no. of strokes 20 - 75 Hub/min cutting angle 0,5 - 1,25 ° down holder 16 Stück voltage 380 V frequency 50 Hz Iedpfx Ahetv Ihqebjtn power capacity 10 kW weight of the machine ca. 6 t dimensions of the machine ca. 4,0 x 2,1 x 1,7 m with electr. back stop, 950 mm

Condition: used, Year of construction: 1973, sheet width 3100 mm plate thickness 3 mm rear stop 1000 mm down holder 18 Stk cutting angle 0.5 - 1,0° 30° ° Ijdpfxetzv T Te Ahbotn oil volume 150 l total power requirement 5,5 kW weight 4300 kg dimensions of the machine ca. 3800 x 1950 x 1600 mm Features: - Manual rear stop (front via handwheel) - Manual cutting angle adjustment - 1x front support arm - 1x side stop - Front finger guard - Operating instructions (English)

Condition: used, Year of construction: 2008, sheet width 3200 mm plate thickness 6 mm distance between columns 3200 mm back stop - adjustable 20 - 600 mm dimensions ca. 4010 x 1610 x 1620 mm engine output 7,5 kW Control eView weight of the machine ca. 7,2 t CNC swing cut panel shears electrical components from Siemens, ABB and Mitsubishi, Pilz safety control Iodpsqva Rzjfx Ahbstn hydraulic components made in Italy 3 support arms and 1 angle stop Ball rollers in the table Operating instructions available

Year of construction: 1981, condition: good (used), machine/vehicle number: 3626, OFFER 21448 Iodpfx Ashhc Ixshbotn Technical data: - max. working width 2540 mm - max. cutting capacity St 40 4 mm - motorized cutting angle adjustment - cutting gap adjustment by means of graduated adjusting screws - number of hydraulic clamping bars 14 pcs - motorized rear stop with positioning 10 - 1000 mm - number of strokes depending on cutting angle and cutting length 23 per minute - hydraulic drive 400 V / 7.5 kW - table height 1030 mm - space requirement approx. W 2500 x H 1630 x D 2150 mm - weight approx. 3600 kg - including: - sheet metal lifting with pneumatic assistance - front angle stop + support arms - electronic cutting depth adjustment - cutting line illumination - electric foot switch

Condition: used, Year of construction: 1998, gebraucht 1998 090148 prompt, Zwischenverkauf v Belgien 22800 € 1 3100 mm 6 mm 0.5 - 3.5 ° 9.5 kW 950 mm 4070 mm 2330 mm 3400 mm 1850 mm 5500 kg Motorized backgauge 1000 mm, ball screws, digital display Cutting gap adjustment from the front with handwheel Cutting length adjusment Cutting angle adjustment Downholer safety guard Rear safety via light barrier Foot pedal Table supports with ball bearings 1 side arm 1500 mm 2 support arms Operating manual in German with CE declaration of conformity Iedpoyackwsfx Ahbetn BUYING USED MACHINERY IS A MATTER OF TRUST - OUR TRANSPARENCY PROMISE We offer you maximum security and complete transparency. • HONEST INSIGHTS: Detailed photos and functional videos of the current condition • LIVE ON-SITE CHECK: Live testing is possible at our facility • DIGITAL DEMONSTRATION: Individual live demonstration via video call • RISK-FREE PURCHASE: 14-day return policy Details:

Condition: used, Year of construction: 2001, - Year of manufacture: 2001 Specifications - Cutting length: 3100 mm - Capacity: 16 mm - Stroke: 170 mm - Strokes per minute: 10 - Oil tank: 410 l - Motor power: 37 kW Iedpfexa Aclex Ahbstn - Operating voltage: 400 V - Rated current: 72 A - Main fuse rated current: 100 A - Dimensions (W x H x D): 3750 x 2400 x 3425 mm - Weight: 13800 kg

Condition: used, Year of construction: 1996, gebraucht 1996 090232 ca. 2 Wochen ab Auftragse Türkei 16900 € 1 3100 mm 6 mm 19 1/min 1.5 ° 14 1000 mm 15 kW 200 l 3700 mm 2250 mm 2700 mm 1830 mm 5600 kg Swing-beam cutting design Motorized backgauge (1000 mm) with digital display Footpedal Central manual blade gap adjustment Cutting line illumination Wide support table with transfer balls 1 side gauge with scale, T-slot, and flip-stop 2 sheet support arms with T-slots Oil fill Light curtains at the rear of the machine THE BLADES WERE GRINDED Operating manual in German with EC Declaration of Conformity BUYING USED MACHINERY IS A MATTER OF TRUST - OUR TRANSPARENCY PROMISE We offer you maximum security and complete transparency. • HONEST INSIGHTS: Detailed photos and functional videos of the current condition • LIVE ON-SITE CHECK: Live testing is possible at our facility • DIGITAL DEMONSTRATION: Individual live demonstration via video call Itedpfxjz Ikvms Ahben • RISK-FREE PURCHASE: 14-day return policy Details:

Condition: used, Year of construction: 1998, sheet width 3050 mm plate thickness 6,5 mm distance between columns 3100 mm 1000 mm Cutting length variabel mm cutting gap adjustment variabel mm connected load 12,0 kW weight of the machine ca. 5,5 t Itodpfx Ahez Dky Rjbon dimensions of the machine ca. 3,5 x 2,2 x 1,8 m Hydraulic guillotine shear with - cutting length adjustment - cutting angle adjustment - support arms - squaring arm - rear enclosure - mobile material bin

Condition: excellent (used), Year of construction: 1998, Technical data: Working width: 2000 mm Bending capacity: 25.0 mm Pre-bending: 20.0 mm CNC control Top roller diameter: 320 mm Middle roller diameter: 320 mm Iedsv Htnijpfx Ahbetn Side roller diameter: 240 mm Hardened rollers Conical bending device by tilting the two side rollers Mobile control panel with digital display Engine power: 11 kW CE mark Dimensions (length x width x height): approx. 4500 x 2000 x 1900 mm Weight: approx. 11 tons The seller is not liable for typing or data transmission errors. The machine's appearance, technology and wear are in keeping with its age; used machines are sold without any warranty.

Condition: used, Year of construction: 1993, Technical details: sheet width: 3150 mm Itsdpfju Icnfjx Ahbon plate thickness: 13 mm distance between columns: 3670 mm Knife length: 3150 mm down holder: 18 Stück back gauge: motorisch 1000 height over floor: 850 mm operating hours: 3256 Table dimensions: LxB: 3770 x 500 mm total power requirement: 30 kW weight of the machine ca.: 12,9 t dimensions of machine: 4,4 x 2,8 x 2,4 m Short stroke Continuous run Gap lighting Hydraulic sheet metal lifting device rear light curtain Positionable backgauge *

Condition: excellent (used), Technical Details: Working width: 3100 mm Maximum bending capacity: 16.0 mm Maximum pre-bending: 12.0 mm Top roll diameter: 300 mm Side roll diameter: 270 mm All three rolls powered Hardened rolls Conical bending device by tilting of both side rolls Itsdexyvx Topfx Ahbsn Swiveling control panel with digital display Hydraulic drop end bearing Motor power: 7.5 kW Dimensions (L x W x H): approx. 5800 x 1700 x 1500 mm Net weight: approx. 8.5 tons The seller is not liable for typing or data transmission errors. The machine's appearance, technical condition, and wear correspond to its age; used machines are sold without any warranty.

Condition: used, Year of construction: 2008, sheet width 4100 mm plate thickness 6.0 mm thickness at "Niro-steel" 4.0 mm no. of strokes 12 - 24 Hub/min cutting angle 1 ° 30 work height max. 865 mm back stop - adjustable 1.0 - 1000 mm down holder 20 Stück Control ENC 100 M column arm 50.0 mm oil volume 200 ltr total power requirement 15.0 kW range L-W-H 5230 x 2250 x 2150 mm weight 11460 kg New price ~ 50,000 euros (!!) Special price on request ----- NC electro-hydraulic swing cut shears * with DURMA "ENC 100 M" control * manual cutting gap adjustment (eccentric) * including pneumatic sheet holding device for thin sheet metal cuts ----- Equipment: - robust electro-hydraulic swing cut shears - including DURMA "ENC 100M" NC control unit * Back stop pre-selection - X axis * Quantity * Cutting length limitation * Pivoting operation, left front - Monoblock welded steel construction made of high-quality steel - CNC electro-motorized back stop * with ball screw and linear guides * Automatic retraction of the back stop during the cutting process - Light barrier protection for access to the rear of the machine - manual cutting gap adjustment via eccentric - high-performance hydraulic cylinder made of SAM 1040 material - high-quality chrome-plated and finely ground hydraulic piston - split, fold-up finger guard 1,000 mm - easy handling of the sheets via ball rollers in the table - 1x long side stop including mm scale and tilting cam - 3x front support arms - 1x freely movable foot switch - operating instructions Special accessories included: - pneumatic sheet holding device for cutting thin sheet metal - up to max. material thickness - ST .. 3.0 mm Isdpfew U U T Tsx Ahbotn

Condition: used, Year of construction: 2008, sheet width 3100 mm plate thickness 13.0 mm thickness at "Niro-steel" 8.0 mm down holder 14 Stück no. of strokes 11 - 20 Hub/min oil volume 310 ltr. cutting angle 0.05 - 2.0 ° throat 350 mm table height 900 mm total power requirement 22.0 kW weight of the machine ca. 13400 kg range L-W-H 5.110 x 2.570 x 2.400 mm Current new price approx. 80.000 Euro Special price upon request - in checked conditions - machinevideo - ?v=K4ymYMIJ7_Y ----- Robust electro-hydraulic CNC sheet metal shear with slide guides * Includes CYBELEC "DNC 60 CUT" control system * Includes CNC electro-hydraulic cutting gap adjustment * Includes CNC electro-hydraulic cutting angle adjustment ----- Equipment: - CNC electro-hydraulic guillotine shear with slide guides - Includes CYBELEC CNC controller, model "DNC 60" - CNC electro-motorized backgauge, travel range = 5.0 - 1,000 mm (X axis) * On recirculating ball screws * Automatically folds up at maximum travel, for longer cuts * Includes selectable retraction function ("swing-away function") * Positioning accuracy 0.1 mm * Approx. travel speed 80.0 mm/sec. - Electro-hydraulic cutting angle adjustment - Electro-hydraulic cutting gap adjustment - 1x side stop with T-slot and mm scale - 2x front support arms with T-slot and mm scale - Ball transfer units in the front support table - Hinged finger guard with safety switch - BOSCH/HOERBIGER hydraulic system - SIEMENS electrical system - Light curtain behind the machine (safety device) Itedpfx Ahjxaadajbsn - Rear sheet chute (sheet inserts) - 1x freely movable foot switch - CE mark - Operating instructions

Condition: used, Year of construction: 1997, sheet width 3100 mm plate thickness 6.35 mm thickness at "Niro-steel" 4.00 mm cutting angle 0.5 - 2.5 ° cutting gap adjustment 0.05 - 0.8 mm no. of strokes 12 - 50 Hub/min back stop - adjustable 1000 mm Control DELEM DAC 360 oil volume 120 ltr. engine output 9.5 kW weight 7000 kg. range L-W-H 3950 x 1950 x 1680 mm well-maintained condition (!!) equipped with new DELEM control unit Equipment: - electro-hydraulic, guided plate shear - DELEM CNC control unit type DAC 360 * front control panel, swiveling front left - Electro-hydraulic cutting angle adjustment - Electro-hydraulic cutting gap adjustment - electro-motorized backgauge, with ball screws - 1x extra-long side fence with T-slot mm scale Iedpfxoy I Dbbs Ahbetn

Condition: good (used), Year of construction: 2000, sheet width 3100 mm plate thickness 13.0 mm Iodpfx Aox Ni D Rohbjtn thickness at "Niro-steel" 8.0 mm down holder 14 Stück no. of strokes max. 11 Hub/min cutting angle 1°15 work height max. 770 mm column arm ? mm oil volume 300 ltr. control konv. total power requirement 15.0 kW weight 11800 kg range L-W-H 4255 x 2250 x 2400 mm Features: - Robust electro-hydraulic swing pruning shears - Operation, swivels to the front left - Electro-motorized backgauge * on recirculating ball screws * Movement by push-button (forwards backwards) * including ELGO digital position indicator - Manual quick cutting gap adjustment * by eccentric (right side stand) - Machine stand with overhang - 1x long side stop, with mm scale - 2x front support arms, with mm scale - Ball rollers in the front support table - Hinged front finger guard - 1x free-moving foot switch - Rear safety device (protective grille) - 2x front emergency stop button - Operating instructions (PDF)

Condition: used, Year of construction: 2019, sheet width 6080 mm plate thickness 6.0 mm rear stop 1000 mm cutting angle 0.5 - 2.0 ° down holder 29 Stk no. of strokes ca. 10 Hub/min total power requirement 22.0 kW dimensions of the machine ca. 7300 x 2150 x 2750 mm weight 25500 kg Current list price: approx. 150.000 euros Features: - Electro-hydraulic, slide-guided sheet metal shear - Electro-hydraulic cutting angle adjustment - Electro-hydraulic cutting gap adjustment - Electrically driven backgauge with ball screws - Manual central lubrication Itedezvq Etopfx Ahbjn - Cut line illumination - Ball bearings in the table - Fold-up finger guard, 1.000 mm - Side stop with T-slots, tilting stop, and scale - 5 support arms with T-slots - Photoelectric sensors on the rear of the machine - 1 freely movable foot switch Includes optional equipment: - Pneumatic sheet metal holding device

Condition: excellent (used), Year of construction: 2001, sheet width 4000 mm plate thickness 16 mm total power requirement 37 kW weight of the machine ca. 20 t dimensions of the machine ca. 4700 x 2100 x 2000 mm Isdpfey Diahsx Ahbetn

Condition: good (used), Year of construction: 1990, overall weight: 3,900 kg, total height: 300 mm, total length: 3,520 mm, total width: 2,000 mm, plate height: 300 mm, Floorplate Length: 3520mm Floorplate Width: 2000mm Iedpozw Ezrjfx Ahbotn Height: 300mm No. Of T-slots: 8 Distance from T to T-slot / Jump:250mm T -slot size: 28mm Weight a plate approx.: 3900kg Number of matching pieces: 1 Length: 3520mm Width: 2000mm Height: 300mm Weight: 3900kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Year of construction: 1993, Technical details: sheet width: 3050 mm plate thickness: 6,0 mm distance between columns: 3460 mm no. of strokes: min./max.: 9 / 17 Hub/min Itjdpfxsu Rni He Ahbon back gauge: 750 mm (motorisch) mm cutting angle: 0,5° - 3,0° ° cutting gap adjustment: manuell mm down holder: 18 Stück (hydraulisch) Stück Table dimensions: 380 x 3100 mm total connected load: 7,5 kW weight of the machine ca.: 4,56 t dimensions of machine: L: 3,64 x B: 2,55 x H: 1,58 m Equipment: With side stop L: 1000 × W: 100 × H: 60 mm and stop bar 990 mm, with 8 supports Operation via control panel and foot switch Cutting zone lighting Stroke counter Machine feet *

Condition: used, Year of construction: 2006, sheet thickness (max.): 6 mm, Brand: DURMA Type: VS 3006 Iedpewrx Taofx Ahbstn Year of manufacture: 2006 Maximum sheet width: 3080 mm Maximum sheet thickness: 6 mm
