Used Dmg Machining Center for sale (405)

Condition: excellent (used), Year of construction: 2012, Technical specifications: 5-axis machine: X, Y, Z, C, B Travel distances (X/Y/Z): 500 / 450 / 400 mm Travel range B axis: +110/-5° Travel range C axis: 360° CNC control: SIEMENS 840D Table width: 500 mm Table diameter: 630 mm Table angle adjustable in degrees Max. workpiece weight: 200 kg Number of tool changer positions: 30 Spindle speed: 20 – 10,000 rpm Motor power: 13 kW Dimensions (L x W x H): approx. 3400 x 2550 x 2200 mm Machine weight: approx. 4.8 t Additional equipment: Workpiece measuring probe Chip conveyor Condition: Dsdpoyzzpvefx Ac Hoci Very good condition, little used, approximately 12,850 operating hours

Condition: excellent (used), Year of construction: 2022, DMG MORI CMX 50 U 3+2, year 2022. Siemens SlimLine control. Travels: X-500 mm, Y-450 mm, Z-400 mm, B -5 / +110°, C 360°. Spindle max 15,000 rpm. Tool magazine for 60 tools, BBT40. Through-spindle cooling 70 bar. Chip conveyor. Filter paper. High-pressure coolant pumps. Workpiece probe, tool probe. Quickset (rotary axis calibration). Machine in very good condition, available at our warehouse in France, 01360 Loyettes. Full specification below in PDF. Dsdpfoxyi Hwex Ac Hsci

Condition: excellent (used), Year of construction: 2010, DMG DMU 80 monoBLOCK, 5-axis Year of manufacture: 2010 Control: iTNC 530 Technical specifications x-travel 880 mm y-travel 630 mm z-travel 630 mm control iTNC 530 Heidenhain turning speed range - main spindle max. 12.000 min/-1 tool taper SK40 swivel milling head B-axis: +30° / -120 ° table surface area Ø 700 / 1.250 x 700 mm max. table load 650 kg NC rotary table, integrated, C-axis: 360 ° number of toolpositions 2x16 pos. tool taper SK40 max. tool diameter 80 mm max. tool-dia with free toolbox 130 mm max. tool weight 8,0 kg max. tool length 315 mm feed speeds max. 30.000 mm/min rapid traverse 30 m/min total power requirement 48 kVA weight of the machine ca. 12 t dimensions of the machine ca. 4,5 x 4,0 x 2,6 m Accessories/options: Dcedpfx Aeytfn Sec Hsi - swarf conveyor - replaced X/Y/Z ball screws and spindle in 2019 - full set of documentations - precision vice - tool holders

Condition: good (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 288-40003902, travel distance X-axis: 800 mm, travel distance Y-axis: 710 mm, travel distance Z-axis: 710 mm, table width: 500 mm, table length: 630 mm, For sale is a horizontal machining center DMC 80 H hi-Dyn with 4 axes. Dedpfxoytf N Ae Ac Hsci The machine has only been used for milling and drilling cast parts for surface finishing. The spindle is in very good condition. Technical specifications: Travel paths: X-axis: 800 mm Y-axis: 800 mm Z-axis: 800 mm B-axis: 360° Table data: Table size: approx. 630 × 500 mm Max. workpiece weight: ~1,200–1,400 kg Rotary table: 4th axis, 360° continuous Spindle: Direct drive, liquid cooled Replaced in 2023/2024 Measuring system: Glass scales Main drive: Max. speed: up to 10,000 rpm Spindle power: approx. 20 kW Torque: S1 – 100% duty cycle Transport dimensions: LxWxH in meters: 5.2 x 2.4 x 2.7 Machine transport weight: 12,500 kg Dismantling, loading, and transport throughout Europe can be organized upon request for an additional charge. All prices are plus VAT. Inspection possible by appointment. Contact us — our team will be happy to assist you. Trade-in or exchange possible! Machinery purchase & sales PURCHASE / SALE OF PRODUCTION AND METALWORKING MACHINES ETC. Are you looking for a high-quality but affordable metalworking machine for your production? Or would you like to sell yours? For further information or contact options, please visit our website.

Condition: excellent (used), Year of construction: 2002, Control Siemens Sinumerik 840D Travel paths X/Y/Z: 560 x 560 x 510 mm Spindle speed 15,000 min-1 2-fold pallet changer 400 x 400 mm Dcedpsyrir Sjfx Ac Hsi Tool magazine for 40 tools, SK 40 Paper filter Chip conveyor

Condition: good (used), Year of construction: 2016, CNC Control Axes X-axis travel mm: 1050 Y-axis travel mm: 530 Z-axis travel mm: 510 4th axis: DDRT-260X Feed rate m/min: 5 Rapid traverse m/min: 30 Work Table Number of pallets: 1 Table dimensions mm: 1350x600 Maximum workpiece weight kg: 1200 Table surface configuration: 18mm T-slot, 6 units Spindle Spindle speed rpm: 8000 Spindle power kW: 30/22 (25%ED/cont) Spindle torque Nm: 304 Tool System Tool holder: MAS-BT 50 Tool magazine positions: 30 With adjacent positions free mm: 240 With adjacent positions occupied mm: 120 Maximum tool length mm: 350 Maximum tool weight kg: 20 Tool change time s: 2.34 Equipment Chip conveyor Internal coolant supply Rated power kVA: 52 Dcedpoyyc Dlofx Ac Hji Machine basic dimensions / weight Length mm: 3300 Width mm: 3000 Height mm: 2800 Weight kg: 7700

Condition: used, Year of construction: 2017, Technical details: x-travel: 560 mm y-travel: 560 mm Dcodeyqybbjpfx Ac Hoi z-travel: 660 mm control: Celos Siemens 840D SL Operate ERGOline Multitouch turning speeds: 20 - 20.000 1/min spindle drive: 25/ 35 kW max. torque on the spindle: 86 / 130 tool taper: HSK-A63 Number of tool station: 60 diameter of tools max.: 70 mm Tool diameter with no neighbouring tools: 170 mm tool length - max.: 450 mm weight of tools max.: 12 kg numbers of pallets: 2 Pallet dimension: 400 x 400 mm max. workpiece diameter: 630 mm workpiece height max.: 900 mm table load: 400 kg rapid travel x/y/z: 60 m/min Feed x/y/z: 60 m/min internal coolant system feed: 70 bar weight of the machine ca.: 8,5 t dimensions: 3200 x 4800 x 2900 mm Accerories Rotoclear window Signal lamp 4 colours Electronic handwheel Probe for tool breakage and length measuring Coolant shower Renishaw probe (spindle) Vorbereitung / preparation only HSK cone cleaning station with brushes Horizontal machining center with Siemens - Celos control, full b-axis, tool magazine with 123 pos. HSK-A 63, coolant through spindle 40 bar. The machine has just received a new milling spindle. *

Condition: good (used), Year of construction: 2015, Table size 950 x 800mm , table load 1,000 kgs, Traverses X Y Z 1,000 x 900 x 700mm, B axis -5/+110 degrees, C axis 360 degrees Rapid feedrates 80m/min, 60 station toolchanger, Dodpoyqxdujfx Ac Hoci spindle taper HSK 63, spindle speed 18,000rpm, Heidenhain TNC 530 control, swarf conveyor, Through Spindle Coolant

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: 1153 000006 3, travel distance X-axis: 1,250 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, controller model: Siemens 840 D Solutionline (PCU 50), spindle speed (max.): 8,000 rpm, TECHNICAL DETAILS Travel X-axis: 1,250 mm Travel Y-axis: 1,000 mm Travel Z-axis: 1,000 mm Feed rate X, Y, Z-axis: 20 - 60,000 mm/min Rapid traverse X, Y, Z-axis: 60 m/min B-axis travel: 360 x 0.001° B-axis feed rate: 10,800 /min Max. table rotation: 30 rpm Max. workpiece diameter: 1,250 mm Max. workpiece height: 1,580 mm Max. workpiece weight: 1,500 kg Clamping area: 800 x 800 mm Pallet weight: 570 kg Spindle speed: 20 - 8,000 rpm Max. permissible weight difference for pallet loading: 1,000 kg Tool holder: SK 50 according to DIN 69871 Maximum tool length: 650 mm Tool magazine: 120 positions MACHINE DETAILS Control: Siemens 840 D Solutionline (PCU 50) Dimensions & Weight Transport dimensions: 6,500 x 3,000 x 3,200 mm Transport weight of the machine (without magazine or other accessories): approx. 20,000 kg Required space: approx. 7,000 x 6,000 mm Total machine weight: 24,000 kg Operating hours "Counter external 2 (read off)": 60,197 h EQUIPMENT Dcjdpfxsyvzl Ho Ac Hsi Chip conveyor with coolant tank Coolant/lubrication system 4x machine pallets Tool magazine Oil mist extraction unit Length measuring system Y-axis (new spare part) Lubrication unit 230V 0.12 30bar (new spare part) Gear unit ZAHNRADP-AGG*MKF1-KW2-20036 (new spare part) Cyclo gearbox*F1C-A25 (new spare part) Retrofit kit for power module (new spare part) Lifting devices for the machine

Year of construction: 1995, condition: excellent (used), Travel X/Y/Z: 350 x 240 x 340 mm Spindle speed 6300 rpm Tool holder SK 40 Manual swivel rotary table Dcodpfx Aelawavjc Hei tool holder vice Accesories

Condition: good (used), For sale is a CNC milling machine DMG DMU 50 V with Heidenhain 426/430 control, 5 axes. The item is in good condition. Technical specifications: Travel X-axis: 500 mm Travel Y-axis: 380 mm Travel Z-axis: 400 mm Table: NC rotary/swivel table Rotary/swivel axes: B-axis approx. -10° / +95° C-axis (rotation): 360° Max. workpiece weight: approx. 200 kg Table surface: Ø 500 x 380 mm Dcsdpfx Acoxvzy Us Hei Main spindle: SK 40 (ISO 40) Max. spindle speed: approx. 10,000 rpm Max. tool length: approx. 280 mm Max. tool weight: approx. 6 kg Transport dimensions: 2.45 x 1.76 x 2.38 m Machine weight: approx. 3,500 kg Total power requirement: approx. 17 kW Transport and loading can be arranged Europe-wide for an additional charge, if required. Prices exclude VAT. Inspection possible by appointment. Please contact us, our team will be happy to assist you. Trade-in or exchange possible! Machinery Purchase / Sales PURCHASE & SALE OF PRODUCTION & METALWORKING MACHINES AND MORE. Are you looking for a high-quality yet affordable metalworking machine for your production? Or would you like to sell yours? For more information or contact options, please visit our website.

Condition: used, Year of construction: 1998, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 550 mm, rotational speed (max.): 12,000 rpm, overall weight: 7,500 kg, For sale: CNC 5-Axis Machining Centre, manufacturer DMG, model DMU 60 P The machine is fully operational and ready for immediate use. In 2021, a new spindle was installed, and all required maintenance has been carried out. Dcsdpfx Ajwbhq Hec Hoi History: 2019: New ball screw (KGT) 2021: New spindle 2022: Single-shift operation 2023: Occasional job orders 2024: Taken out of operation but remained connected to power 12/2025: Dismantled, cleaned, and stored Technical Specifications: X travel: 600 mm y travel: 650 mm z travel: 550 mm Control unit: Heidenhain TNC 426 Spindle speed: max. 12,000 rpm Spindle drive power: 15 kW Max. torque: 130 Nm Tool holder: SK 40 Table diameter: 630 mm Max. table load: 500 kg Number of tool pockets: 60 positions Max. tool length: 350 mm Rapid traverse (X/Y/Z): 24 m/min Feed rate: 20 - 10,000 mm/min Total connected load: 44 kVA Space requirements: approx. 7.0 x 6.0 x 2.7 m Machine weight: approx. 7.5 t Please note: Vices or clamping fixtures are not included in this offer. Upon request, we can organise transport and loading, at an additional cost. Europe-wide service available. All prices are subject to VAT. Inspection is possible by appointment. Please contact us—our team is happy to assist you. Trade-in or exchange possible! Machinery Purchase / Sales PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MORE. Are you looking for a high-quality yet affordable metalworking machine for your manufacturing needs? Or are you looking to sell yours? For more information or contact options, please visit our website.

Condition: like new (used), Year of construction: 2009, operating hours: 625 h, functionality: fully functional, travel distance X-axis: 350 mm, travel distance Y-axis: 240 mm, travel distance Z-axis: 340 mm, total height: 2,100 mm, total length: 2,000 mm, total width: 1,700 mm, overall weight: 1,600 kg, For sale is a 3+2 axis machining center from DMG, model DMU 35 M. This machine comes from a technical training institute and was used mainly for training purposes, including CNC control and setup. Special attention should be paid to its very low spindle hours. Technical data: Year of manufacture: 2009 Spindle hours: 625 Machine no.: 18065358844 X axis: 350 mm Y axis: 240 mm Z axis: 340 mm Max. spindle speed: 6,300 rpm Feed rate: infinitely variable up to 5,000 mm/min Rapid traverse: 5 m/min Servo motors in X, Y & Z axis Clamping surface: Ø 400 x 280 mm Dedpsx Aiiqefx Ac Hjci Swivel range: 360° (mechanical) Table clamping: +105 / -150 (mechanical) Max. table load: 100 kg Tool changer: manual change Tool holder: SK 40 Tool clamp: pneumatic/mechanical Space requirements: 3,800 x 3,600 x 2,100 mm Transport dimensions: approx. 2,000 x 1,700 x 2,100 mm Weight: 1,600 kg Upon request, transport and loading can be organized Europe-wide at additional cost. All prices are plus VAT. Viewing is possible by appointment. Please contact us—our team will be happy to assist you. Trade-in or exchange possible! Machinery purchase and sales BUYING / SELLING OF PRODUCTION & METALWORKING MACHINES, AND MORE. Are you looking for a high-quality yet affordable metalworking machine for your production? Or would you like to sell yours? For further information or to contact us, please visit our website.

Condition: used, Year of construction: 1996, x-travel 600 mm y-travel 560 mm z-travel 560 mm Control Siemens size of pallet 400x500 mm Table load 300 kg feed 40.000 m/min spindle speed: 20-8000 U/min spindle taper ISO 40 Spindle capacity 13/20 KW Torque 191 Nm 4-axis horizontal machining center. Dual pallet changer. B-axis table indexing 0.001°. B-axis rapid traverse 40 rpm. KNOLL coolant system with filter and chip conveyor. 40 bar coolant supply via collar. Good condition. The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More Djdpoyutu Ajfx Ac Hjci than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: ready for operation (used), Year of construction: 2006, CNC machining center DMC 635V Year of manufacture 2006 Heidenhain TNC 530i control Control approx. 58,400 hours Program run approx. 19,980 hours According to the sticker in the control cabinet, the spindle and motor were replaced in January 2019 at 10,660 hours. No documentation available. Machine runs smoothly Travel distances X 635 Y 510 Z 460 Tool holder SK 40 20-position tool changer Table 790×560 with chip conveyor Weight approx. 3700 kg This offer is directed exclusively at commercial enterprises within the meaning of §14 BGB (German Civil Code). Dcjdpfsw Tir Uox Ac Hei No sale to private individuals.

Condition: used, Year of construction: 2001, x-travel 600 mm y-travel 560 mm z-travel 560 mm table surface area 500x400 mm control Siemens type 840 D spindle taper ISO 40 spindle turning speed range 8000 U/min type of pallet-changer 2 Rotary table 360 ° Tool changer 40 weight of the machine ca. 11,5 t The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. Dedpfsyt Rw Ssx Ac Hoci We look forward to your visit. Your Markus Hirsch Team

Condition: like new (used), Year of construction: 2009, travel distance X-axis: 200 mm, travel distance Y-axis: 220 mm, travel distance Z-axis: 280 mm, controller manufacturer: HEIDENHAIN iTNC530, workpiece weight (max.): 15 kg, table width: 200 mm, table length: 200 mm, spindle speed (min.): 42,000 rpm, Control CNC: HEIDENHAIN iTNC530 Axes X-axis travel mm: 200 Y-axis travel mm: 220 Z-axis travel mm: 280 C-axis degrees: 360º A-axis degrees: -15º max.130º Work Table Table dimensions mm: ø200 Maximum workpiece weight kg: 15 Dcedpfx Ajxpg H Hsc Hei Spindle Spindle speed rpm: 42.000 Cooling Cooling through the spindle bar: 40 Tool System Tool holder: HSK-E32 Tool magazine slots: 60 Max. tool diameter mm: ø50 Max. tool length mm: 200 Chip-to-chip time s: 10 Equipment Automation LM100 (EROWA ITS72, 5 levels of 9 positions); 10 kg maximum manipulation Electronic handwheel Chip conveyor Infrared probe High-pressure pump NC rotary tilting table Rated power kVA: 40

Condition: good (used), Year of construction: 2003, functionality: fully functional, input voltage: 400 V, travel distance X-axis: 780 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 560 mm, workpiece weight (max.): 4,000 kg, number of slots in tool magazine: 120, controller manufacturer: Heidenhain, total height: 2,800 mm, total length: 6,000 mm, total width: 6,000 mm, overall weight: 12,000 kg, table length: 630 mm, table width: 500 mm, controller model: iTNC530, nominal power (apparent): 61 kVA, rapid traverse Z-axis: 50 m/min, rapid traverse X-axis: 50 m/min, rapid traverse Y-axis: 50 m/min, spindle speed (max.): 18,000 rpm, spindle speed (min.): 20 rpm, table load: 4,000 kg, operating hours of spindle: 19,500 h, Equipment: chip conveyor, rotational speed infinitely variable, DMG DMC 60T RS3 with Heidenhain iTNC 530, no maintenance backlog, in good condition. Ideal machine for unmanned operation, geometrically within new-machine tolerance. The machine can be inspected and measured on site by arrangement. Machine Data: Machine description: Machining centre with pallet storage Manufacturer: DMG MORI Model: DMC 60T RS3 Year of manufacture: 2005 Condition: good Equipment: - Direct linear measurement in X/Y/Z (glass scales) - Chip conveyor - High-pressure coolant system 40 bar (IKZ) Dodpfx Acsrxrkls Hsci - Extraction unit - NC rotary table - Tool magazine, 120 positions - Heidenhain measuring probe - Rotating viewing window - High-pressure coolant 40 bar - Signal lamp - Chip flushing - Operating mode 4 Technical Data: Number of axes: 5-axis Control: Heidenhain iTNC 530 NC rotary table clamping surface: 500 mm x 630 mm Weight: approx. 9,000 kg Chip conveyor: Yes Coolant system: Yes Internal coolant supply: Yes Travels and axes: X-axis: 780 mm Y-axis: 560 mm Z-axis: 560 mm C-axis: 360° B-axis: -90°/+12° Feed rates and rapid traverse: X-axis: 50 m/min Y-axis: 50 m/min Z-axis: 50 m/min B-axis: - C-axis: 30 m/min Motor spindle: Max. speed: 18,000 rpm Spindle taper: HSK A63 Tool changer: Automatic tool changer: Yes Number of magazine positions: 120 Pallet changer: 5 pallets

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, operating hours: 69,000 h, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, number of slots in tool magazine: 40, controller manufacturer: Siemens, total height: 2,800 mm, total length: 7,000 mm, total width: 4,000 mm, overall weight: 10,000 kg, table length: 800 mm, table width: 630 mm, controller model: Sinumerik 840D powerline, coolant supply: 40 bar, nominal power (apparent): 69 kVA, rapid traverse Z-axis: 50 m/min, rapid traverse X-axis: 50 m/min, rapid traverse Y-axis: 50 m/min, spindle nose: HSK63, spindle speed (max.): 12,000 rpm, spindle speed (min.): 20 rpm, table load: 800 kg, operating hours of spindle: 27,000 h, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, DMG MORI DMC 80U Year of manufacture: 2002 Operating hours: 69,000h Spindle hours: 27,000h Dedpfx Acov Eurms Hjci Equipment: 5-axis Swivel head Direct path measurement in X/Y/Z (glass scales) Chip conveyor Extraction NC rotary table as an add-on table Pallet changer Tool magazine 60 places Heidenhain measuring probe Handwheel Rotating viewing window IKZ 40 bar Chip flushing Operating mode 4 + Machine technically serviced and in very good condition + Geometrically within new machine tolerance + Transport and commissioning can be offered separately

Condition: excellent (used), Year of construction: 2006, operating hours: 32,000 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 800 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 15 m/min, torque: 121 Nm, controller manufacturer: Siemens, table width: 700 mm, table length: 900 mm, table load: 1,400 kg, rotational speed (min.): 20 rpm, rotational speed (max.): 18,000 rpm, spindle speed (max.): 18,000 rpm, operating hours of spindle: 32,000 h, coolant supply: 40 bar, spindle nose: HSK63A, number of slots in tool magazine: 30, tool length: 350 mm, tool diameter: 100 mm, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, DMG MORI DMU 80P duoBlock Year of manufacture: 2006 Operating hours: 62,000 h Spindle hours: 31,000 h Function tested and cleaned Maintenance performed according to manufacturer's specifications Geometry within new machine tolerance Equipment: 5 axes Swivel head (controlled B-axis) Direct linear measurement in X/Y/Z (glass scales) Chip conveyor Extraction system NC rotary table Tool magazine with 30 positions Heidenhain touch probe BLUM laser Handwheel Rotating viewing window ICS 40 bar (internal coolant supply) Chip flushing Djdpfow Ht Ibjx Ac Hsci Operating mode 4

Condition: excellent (used), Year of construction: 2012, operating hours: 4,961 h, functionality: fully functional, travel distance X-axis: 120 mm, travel distance Y-axis: 120 mm, travel distance Z-axis: 200 mm, rapid traverse X-axis: 10 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 10 m/min, overall weight: 1,800 kg, spindle speed (max.): 40,000 rpm, operating hours of spindle: 4,961 h, spindle nose: HSK-E32, number of slots in tool magazine: 60, Equipment: chip conveyor, documentation/manual, Including plenty of tool holders and clamping fixtures for dental manufacturing Dcjdpfx Aoyr Difjc Hei

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 11160000593, travel distance X-axis: 600 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, spindle speed (max.): 18,000 rpm, table diameter: 630 mm, TECHNICAL DETAILS Travel X-axis: 600 mm Travel Y-axis: 700 mm Travel Z-axis: 600 mm Number of simultaneous axes: 5 Table diameter: 630 mm Number of T-slots: 9 Distance between T-slots: 63 mm T-slot width: 14H7 mm Centering bore diameter: 50H6 mm Dcjdpfx Aoyhnxvoc Hsi Max. spindle speed: 18,000 rpm Feed rate longitudinal: from 20 mm/min to 15,000 mm/min Feed rate transverse: from 20 mm/min to 15,000 mm/min Feed rate vertical: from 20 mm/min to 15,000 mm/min Rapid traverse: 40 m/min Max. workpiece height: 1,000 mm Max. workpiece diameter: 920 mm Max. workpiece weight on table: 500 kg Table indexing (B-axis): 360° Swivel angle (A-axis): +45/-30° Holding torque A-axis: 3,866 Nm Clamping torque C-axis: 6,008 Nm Max. torque: 2,650 Nm Number of tools: 180 Tool diameter: 80 mm Diameter with adjacent tool pockets empty: 160 mm Max. tool length: 350 mm Max. tool weight: 10 kg Tool holder: SK 40 DIN 69871 MACHINE DETAILS Measuring system resolution: µm Compressed air connection: 5 - 8 bar Power supply: 50 Hz 3x 400 Volt Total power requirement: 44 kVA Noise level: 80 dB(A) Dimensions & Weight Dimensions (L x W x H): 7,500 x 4,500 x 2,628 mm Machine weight approx.: 7,500 kg EQUIPMENT Set of tool holders SK 40 approx. 150 pcs High-pressure coolant system 40 bar Coolant through the spindle (CTS) Renishaw tool probe Lighting Rotating viewing window Electrical cabinet air conditioning unit

Condition: ready for operation (used), Year of construction: 2010, operating hours: 27,052 h, functionality: fully functional, machine/vehicle number: 11680001673, travel distance X-axis: 560 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, controller model: HEIDENHAIN iTNC 530, spindle speed (max.): 12,000 rpm, The machine spindle was replaced in 2017! Machine equipped with KUKA loading robot! TECHNICAL DETAILS X-axis travel: 560 mm Y-axis travel: 600 mm Z-axis travel: 600 mm Number of axes: 4 Maximum workpiece weight on table: 500 kg Maximum workpiece height: 850 mm Maximum workpiece diameter: 630 mm Table rotation speed: 40 rpm Table clamping torque: 1,580 / 2,300 Nm Maximum torque: 1,550 Nm Pallet changer dimensions (L x W): 400 x 400 mm Maximum pallet changer workpiece weight: 500 kg Number of tools in the tool changer: 120 Maximum tool diameter: 80 mm Tool diameter with free adjacent slots: 160 mm Maximum tool length: 400 mm Maximum tool weight: 12 kg Tool holder: HSK 63 DIN 69893 Form A Spindle diameter: 225 mm Spindle speed: 0 – 12,000 rpm Feed speed: 0 – 60,000 mm/min Rapid traverse: 60 m/min Maximum feed force: 10 N MACHINE DETAILS Control system: HEIDENHAIN iTNC 530 Spindle drive power: 20 kW Connection: 50 Hz 3x 400 V Total power requirement: 58 kVA Dimensions & Weight Dimensions (L x W x H): 5,000 x 2,700 x 2,700 mm Machine weight: approx. 9,700 kg Operating Hours Power-on time: 75,886 hours Operating time: 27,052 hours EQUIPMENT Loading robot KUKA High-pressure coolant system Coolant through spindle (IKZ) 40 bar Spindle taper air purge Probe Chip conveyor Pallet storage rack Setup stations (number): 60 (3x20) Lighting Rinse gun Rotating viewing window Electrical cabinet air conditioner Foot pedal Dsdpfeyhnpzjx Ac Hjci Status indicator lamp

Condition: ready for operation (used), Year of construction: 2000, operating hours: 19,467 h, functionality: fully functional, machine/vehicle number: 1100 0000323, travel distance X-axis: 600 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 550 mm, controller model: HEIDENHAIN 430, spindle speed (max.): 12,000 rpm, The spindle of the machine was replaced in 2016! TECHNICAL DETAILS Travel X-axis: 600 mm Travel Y-axis: 700 mm Travel Z-axis: 550 mm Number of axes: 5 Table length: 630 mm Table width: 500 mm Centering bore diameter: 50 mm Maximum workpiece weight on table: 600 kg Number of pallets: 2 Pallet dimensions: 500 x 500 mm Maximum load capacity: 600 kg Tool magazine - number of tool stations: 60 Maximum tool diameter: 100 mm Diameter with adjacent spaces free: 160 mm Maximum tool length: 350 mm Maximum tool weight: 10 kg Tool holder: SK 40 DIN 69871 Spindle speed (stepless): 20 – 12,000 rpm Feed rate: 1 – 10,000 mm/min MACHINE DETAILS Control: HEIDENHAIN 430 Connection: 50 Hz 3x 400 V DIMENSIONS & WEIGHT Dimensions (L x W x H): 3,902 x 2,687 x 2,484 mm Machine weight: approx. 9,500 kg Dcjdpfxeyhnm Tj Ac Hsi Operating hours: 19,467 h EQUIPMENT Cooling unit Coolant through spindle (IKZ) 17 bar Pallet changer Lighting Rotating viewing window

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 83156, travel distance X-axis: 800 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 550 mm, controller model: DECKEL GRUNDIG MILL PLUS, spindle speed (max.): 6,300 rpm, TECHNICAL DETAILS X-axis travel: 800 mm Y-axis travel: 650 mm Z-axis travel: 550 mm Table length: 1,100 mm Table width: 650 mm Milling head indexing (B): 90° Number of tools: 25 Tool diameter: 80 mm Diameter with adjacent free positions: 160 mm Maximum tool length: 315 mm Tool holder: ISO 40 Maximum spindle speed: 6,300 rpm Feed rate: 1–15,000 mm/min Rapid traverse: 15 m/min Spindle motor: 16.2 kW MACHINE DETAILS Control: DECKEL GRUNDIG MILL PLUS Total power requirement: 29 kW Dcedpfx Aeyhnkxsc Hsi Dimensions & Weight Dimensions (L x W x H): 3,100 x 2,300 x 2,500 mm Machine weight: approx. 5,500 kg EQUIPMENT Coolant system Lighting
