Used Annealing Furnace for sale (776)

Condition: excellent (used), High temperature debinding furnace, make GERO type: HBO 50/13-3 2G heating: electrical useable space: ø400 x 400 mm temperature: max. 1.300°C ventilation: exhaust fan during the cooling phase and activated cooling fan ultimate vacuum: 10 mbar Djdpfxehgiz Ij Agvjch exhaustion time: ca. 5 min nitrogen: inlet pressure min. 3 bar oxygen: inlet pressure min. 3 bar

Condition: used, Plasma-nitriding furnace, make Ipsen type: VVPH useable dimensions: ø800 x 1200 (H) mm charge weight: 600 kg gross heating power: 100 kW working temperature: 150 – 600°C PLC: Siemens S5 plasma generator: MAG-Puls QT 800/50/150-UP plasma generator: MAG-Puls was newly acquired in 2008 Dcsdpfxjxc D E Ho Agvjh

Year of construction: 2020, condition: like new (used), functionality: fully functional, Fully automatic sintering continuous furnace system Manufacturer: Sarnes Model: 600-G/CQI-9 Year of manufacture: 2020 (commissioned 2021) Programmable, with online diagnostic system. Fuel: natural gas Hydrogen + nitrogen (N2+H2) operation integrated The system has seen very little use and is in excellent condition. Offer / Quotation Date: 18.1.19 620 mm belt width, gas heated, N2/H2 operation, LED dewaxing zone, rapid cooling section (Pos 2), flameless discharge and ceramic muffle, Heating: low NOx RS Rekudrall burners, SiSiC burner tubes, installed heating capacity 320 kW in 8 zones, dual thermocouples, 100 mm usable height. LED 3 dewaxing zones ("low energy dewaxing" – utilization of chemically bound energy of the waxes and improved burnout conditions especially for heavy PM parts (>0.9 kg)). Dimensions: - Infeed table 2 m (target-actual belt speed compensation) - LED3 dewaxing zone: 1.5 m - Sintering zone length 7.5 m - Rapid cooling length 1 m - Convective cooling zone length 2 x 4 m - Flameless discharge with air shower 2 m - Outfeed table 2.7 m - Total system length 23.7 m - Width 2.3 m Dcodpjxfcdyjfx Agveh Connection ratings: Heating: installed power 320 kW Natural gas: 25 m³/h (80 mbar) N2: 45-65 m³/h (max. 80 mbar) H2: 0.5 - 15 m³/h (80 mbar) Cooling water: 3-5 m³/h (non-pressurized; temp.

Condition: new, Year of construction: 2024, Drying and Burn-in Furnace TRO, Model I For drying racks with max. 50rods, useable size 60x90cm, outer dimensions: approx. 2290mm wide x 1390mm deep x 2230mm high, useable space: approx. 1400x1070x1660cm. Suitable for vaporisation of low amounts of solvent, authorised for inks and solvents up to hazard class A II, according to safety requirements DIN EN 1539. Equipped with control of the minimum exhaust volume and a heating system in regard to the exceedance of the max. temperature. Fixing and drying temperature: up to max. 180°C. Power connection: 400V/50Hz, 21kW, weight: approx. 650kg, varnishing: corps RAL 7035 (light grey), doors RAL 7037 (dust grey). Special varnishing upon request. Chamber dryer, all-steel construction, with good thermal insulation. Simple insertion of drying racks by means of easy-to-open wing doors. The air is sucked out of the drying chamber by ventilators, is blown through thermostat-controlled heating registers and re-fed temperature-controlled to the drying chamber. The solvents released during the drying process are dissipated from the exhaust side of the ventilator while supply air gets into the drying chamber. The horizontal air guide in the drying chamber guarantees an even temperature control. The required temperature can easile adjusted via actual and nominal value thermostat. Overheating protection by safety thermostat. Particularly suitable for fixing and drying of textile inks, flock glues as well as for burning-in of plate and aluminium signs up to 180°C. - Various drying racks for different applications available. - We recommend the installation of a gas warning unit. Delivery time 10-12 weeks. ATTENTION: Not permitted for solvents! Not permitted for foods! Dodpfxod I T Exj Agvjch

Condition: good (used), Gebhardt Q2M-P2B6N-PAC RD centrifugal fan 20000 m³/h Gebhardt Q2M-P2B6N-PAC RD Centrifugal fan 20000 m³/h 7,50 kW n max: 1782 t max: 250 p: 1,200 Motor Siemens UD 0705/1082878-016-1 400/690 V 50 Hz 7,5 kW 8,6 kW 60 Hz 1160/min Dimensions. Height without motor = 64 cm Height with motor = 95 cm width = 102 cm Djdpfxsicav Do Agvjch Depth = 102 cm Weight approx. 280 kg

Year of construction: 2016, condition: new, Gas-fired recirculation chamber furnace Dedpfjcmr D Hex Agvsch max. temperature: 300°C external dimensions ( d x w x h): 2500 x 5300 x 8300 mm internal dimensions ( d x w x h): 1500 x 3800 x 3000 mm control zones: 2 burners power: 4 x 90 kW fans power: 2 x 4 kW

Year of construction: 2017, condition: ready for operation (used), Vötsch VAW 60/100 Heat Oven / Heating Cabinet / Furnace Internal dimensions: 600mm x 1000mm x 600mm (W x D x H) External dimensions: 1800mm x 1800mm x 2200mm (W x D x H) Rated temperature: 650 °C Year of manufacture: 2017 Nominal power: 20 kW You are welcome to arrange a viewing. We can organize cost-effective shipping for you upon request. You will receive a proper invoice. For international customers, a net invoice can be issued provided a valid VAT ID number is supplied. Dsdpfewykz Sox Agvoch Subject to prior sale. Visit our shop to see more of our offers. All listed company names and trademarks are the property of their respective owners and are used for identification and description purposes only. Deviations from technical data as well as errors in the description of the item may occur and are reserved.

Condition: used, Large Gas-Fired Furnaces for Sale: 7500 long x 2780 wide x 2000 height. These are Internal - bed sizes Gas fired Eurotherm Control 4102. Dcedpovitnhofx Agvjh Will heat up steel to 1000 degrees C plus. Both installed and working order. Spares available including a controller and thermocouples.

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, total width: 2,350 mm, total length: 6,000 mm, inner dimension length: 3,000 mm, inner dimension width: 1,600 mm, TECHNICAL DETAILS Oven dimensions: 3,000 x 1,600 mm MACHINE DETAILS External dimensions (L x W): 6,000 x 2,350 mm Firing: Gas Orientation: Vertical, for use with vacuum bags; connection to vacuum port inside oven EQUIPMENT 2 x trolleys included The following data is from a general offer; the seller accepts no liability for its accuracy. This also applies to the data sheet in the appendix. Electrical Voltage: 400 V Current: 16 A Frequency: 50 Hz Gas Type: Natural gas / Propane / LPG Connection: 1"1/4 Gas pressure: 20–60 mbar Propane/LPG consumption (4 burners): 8 kg Propane/LPG consumption (8 burners): 16 kg Natural gas consumption (4 burners): 9.6 m³ Natural gas consumption (8 burners): 19.2 m³ Temperature range (4 burners): 40–150 °C Dcodpoxur Ndofx Agvsh Temperature range (8 burners): 40–320 °C Power output (4 burners): 96 kW Power output (8 burners): 192 kW

Condition: defective spare-parts repository (used), Stainless steel housing for a vacuum furnace with a heating chamber made of molybdenum. Chamber size: 600 mm x 600 mm x 900 mm Internal diameter of the working chamber: 1,000 mm External diameter of the working chamber: 1,280 mm External diameter of the vessel (without flange): 1,450 mm Height without wooden pallet: 1,900 mm Height with wooden pallet: 2,100 mm Width: 1,900 mm Dodpfsvrh Iujx Agvoch Length: 1,900 mm Weight with wooden pallet: 1,750 kg Inspection by appointment is possible at any time.

Year of construction: 2001, condition: used, machine/vehicle number: 12117, Continuous Furnace / Brazing Furnace Max. operating temperature: 1120°C Normal operating temperature: 1050°C Dcodpfx Agowku N Usvoh Conveyor Belt: Useful width of conveyor belt: 250mm Useful height of conveyor belt: 150mm Heating Chamber: Heating Chamber Length: 1530mm Heating Chamber Width: 500mm Height: 500mm Installed Power, Gas: 33kW Number of Heating Zones: 3 Number of Control Zones: 3 Voltage: 3 x 400/230V Frequency: 50Hz You are welcome to visit us by appointment.

Year of construction: 2006, condition: used, functionality: fully functional, Multi-purpose chamber furnace line consisting of the following components: • Aichelin chamber tempering and stress-relief furnaces VKHLE 4/2-70/85/130 (2 units) • Aichelin chamber preheating furnace VKHLG 4/2-70/85/130 (1 unit) • Aichelin single-chamber continuous furnace DGKS 4/2-70/85/130 (3 units) • Aichelin chamber washing machine EKFG 4/2-70/85/130 (1 unit) • Aichelin loading/unloading trolleys (2 units) • Aichelin table loader storage station (1 unit) • Aichelin transfer table storage station (1 unit) • Aichelin cooling unit storage station (2 units) • Storage stations (30 units) • Charging racks • Spare parts for the line Useful load: Grate length: 1300 mm Grate width: 700 mm Loading height above grate: 800 mm Max. batch weight: gross max. 1000 kg/grate Aichelin chamber tempering and stress-relief furnace VKHLE 4/2-70/85/130: External dimensions: Width: approx. 1820 mm Height: approx. 4050 mm Length (incl. control cabinet): approx. 3300 mm Working height above floor: 1600 mm General data: Maximum temperature: 350°C Operating temperature: 150-200°C Number of temperature control zones: 1 Chamber preheating furnace VKHLG 4/2-70/85/130: External dimensions: Width (incl. control cabinet): 3035 mm Height (overall): 4450 mm Length (overall): 3450 mm Loading height above floor: 1600 mm General data: Maximum temperature: 600°C Operating temperature: 400-500°C Number of temperature control zones: 1 Single-chamber continuous furnace DGKS 4/2-70/85/130: External dimensions: Width (incl. control cabinet): approx. 3400 mm Height (incl. maintenance platform): approx. 5300 mm Length (incl. exhaust hood): approx. 6850 mm Working height above floor: 1600 mm General data: Maximum temperature: 1050°C Operating temperature oven: 750-1000°C Temperature control range oil bath: 60-150°C Gross batch weight at 950°C (max.): 1000 kg Max. gross heating capacity from 25 to 850°C (max.): 800 kg/h Number of temperature control zones in oven and oil bath: 1 + 1 Oil bath volume: approx. 6.5 m³ Cooling capacity oil bath (at 90°C bath temperature): 80 kW Chamber washing machine: External dimensions: Dedpfx Agsxwn R Nevjch Width: 2900 mm Height (above hall level): 4000 mm Length: 3150 mm Loading height: 1600 mm General data: Washing fluid temperature: 50-80°C Spray fluid temperature: 50-80°C Bath volume, washing fluid: 4550 l Bath volume, spray fluid: 4700 l Gross weight incl. batch and washing fluid: 125 kN Loading table: Width: approx. 2200 mm Length: approx. 3200 mm Loading height: 1600 mm Weight (incl. batch): approx. 29 kN Batch cooling stations: Length: approx. 2100 mm Width: approx. 800 mm Height: approx. 4350 mm Loading height: 1600 mm Weight (incl. batch): approx. 20 kN Preparation table fixed: Length: approx. 2100 mm Width: approx. 800 mm Loading height: 1600 mm Weight (incl. batch): approx. 25 kN Preparation table, hydraulically height-adjustable: Length: approx. 2100 mm Width: approx. 800 mm Lift: 1000 mm Loading height: 1600 mm Lifting capacity: 2.0 T Weight (incl. batch): 25 kN The sale covers the entire multi-purpose chamber furnace line. Individual furnaces, systems, or components cannot be purchased separately. The complete chamber furnace line must be dismantled, loaded, and transported by the buyer at their own expense. Inspection appointments can be arranged on request.

Condition: used, Year of construction: 2013, operating hours: 6,000 h, functionality: fully functional, the following is included: Dcjdpewlvhhsfx Agvsh - Hardening furnace (vacuum oil quenching furnace) - Control cabinet for hardening furnace - Internal water tank with pump units and control box - Control box for water cooling - Internal nitrogen pressure vessel - External platform for cooling unit + connection points for nitrogen batteries (nitrogen battery containers not included, must be rented) - 7 hardening baskets - Red transport and loading trolley - Parts washing tank for complete baskets with compressed air and drip tray -> System has approx. 6,000 operating hours -> The pictures are up-to-date, only the date on the images is not correct

Condition: excellent (used), Mesh belt continuous furnace CIEFFE Dcedsxpuahjpfx Agvjh type: FNC procedure: tempering, carbonitriding, case hardening lenght: appr. 52 m belt (H x w x d): 25 X 930 X 9300 mm production output: 80-1000Kg/ h connected load: 170kW (HTO) + 35kW (wash) + 135kW (tempering) Heating capacity of natural gas: 768kW (annealing furnace) + 643kW (tempering furnace) annealing furnace: Belt speed: 20 -172 mm/min max. temperature: 910°C temperature uniformity: ± 7°C (area 1-3), ± 5°C (area 4-6) washing machine: wide conveyor belt: 1000 mm washing sink: 1800 lt rising tank: 1200 lt quantity per hourly production: 700dm3/h tempering furnace: belt speed: 60 - 234 mm/min max. temperature: 650°C temperature uniformity: ± 5°C (150-600°C)

Year of construction: 2007, condition: repair required (used), functionality: not functional, Belt width: 650 mm, usable height: 220 mm, heated length: 3250 mm. The furnace has 3 heating zones and a heating capacity of 125 kW. The furnace has been stored in a hall for several years, and many components need to be sandblasted and repainted. In addition, the interior of the furnace needs to be relined, and some parts need to be newly manufactured. The furnace can also be completely overhauled by us to meet current technical standards. Dcsdpsxdantofx Agvjh

Year of construction: 2014, condition: excellent (used), functionality: fully functional, Foundry electric induction melting furnace for melting of: - Steel - iron - aluminum - copper - brass - Bronze Dcjdpfslxnlfjx Agveh TECHNICAL DETAILS Nominal power: 1 ton Temperature: 1700 °C Transformer capacity: KVA 800 Year of manufacture transformer: 2014 High voltage: 10 +- 2 x 2,5% kV current: 41,86 / 38,97 - 23,89 A Low voltage: 840 - 105 V Current: 464 - 275 A EQUIPMENT / SCOPE OF DELIVERY Hydraulic tilting Water cooling system

Condition: good (used), Cole Parmer vacuum furnace Cole Parmer vacuum furnaces are designed for drying under carefully controlled conditions - normal atmosphere, vacuum up to 30" Hg or inert gas atmosphere. The furnace enables drying, vacuum embedding, electroplating and processing of electronic components. Non-corrosive, non-flammable gases such as nitrogen and carbon dioxide can be used in the furnace. Dsdpowxxgaofx Agvsch All controls and connections (except the power supply) are located on the front in a vertical panel. Manufacturer: Cole Parmer Model: 5053-12 Power: 600 W Voltage: 240 V Dimensions: 510 x 420 x 1200 mm You can find more items - new and used - in our store! International shipping costs on request!

Year of construction: 1988, condition: as good as new (ex-display), machine/vehicle number: 1116/87, MANUFACTURER: ELTERMA/IPSEN MODEL: VDFC-413 DESCRIPTION: Vacuum tempering furnace YEAR OF PRODUCTION: 1988 Dsdpjm E Tvhefx Agvsch STATUS: New unused, need revamping of the obsolete parts ( Cabinets ) Max Load Dimensions: 610x900x500mm Max Load Weight: 500 kg Working temperature: 150-750⁰C Approximate warm-up time of the vacuum chamber at 550 ° C for 30 minutes

Year of construction: 1990, operating hours: 16,400 h, condition: good (used), AICHELIN ROTARY FURNACE WITH HESS PRESS AND WASHING MACHINE description: Rotary hearth furnace AichelinModel: RDLGs-R-SJ-1,5m. Year: 1990 External dimensions: 2460 x 2460 x 2335mm Operation: Gas fired with 4 Rekumat self-recovery radiant tube burners. Consumption electrical connection: Connection voltage 380V/50Hz Control voltage 220V/50Hz Total nominal consumption 15Kva Nominal consumption motors 11,7Kva Max. temperature: 950º Cycle time approx. 50 seconds. Hess PressModel : HP 1-48 Year : 1990 Outside dimensions : 1830 x 1650 x 2630mm Dsdponzhx Hofx Agvech Empty Weight: 3000kg Max Cooling Unit: 230kg of SteelMax Workpiece Size: Approximately 210mm Caber Washing MachineModel: 350 T Year: 1990 Outer dimensions: 7100 x 1470 x 2700mm Unladen weight: 4000kg Loading height: 1180mm

Condition: good (used), Year of construction: 1991, functionality: fully functional, load capacity: 650 kg, EROS SIZE 7 furnace for carburizing, carbonitriding and quenching. Refractory exchanged with Kanhtal resistors. Useful dimensions. 700x450x1150mm Chamber dimensions: 750x560x1540 mm Outer dimensions (layout) 2500x 3715x 4500 mm Furnace heating power: 85 kW Dodpfx Agou A Tf Devjch Oil heating power : 35KW Furnace working temperature : 20-950ºC Cesats dimensions: 700x1150x150 mm (capacity 3 superimposed baskets) Oil tank capacity: 4500 liters Maximum load approx : 600-650 kg Control equipment UDC-5000 (potential carbon control) Carbon sensor rod (with co2 cleaning) Few hours of use

Condition: ready for operation (used), Year of construction: 2022, operating hours: 500 h, functionality: fully functional, Complete aluminum ingot casting and stacking line manufactured in 2022 by GHI Smart Furnaces. Inclined casting machine for the production of 10 kg commercial aluminum ingots, with a nominal capacity of 5 t/h. The line includes an automatic pouring system, water spray cooling system, demolding system, cooling and ingot positioning conveyor belt, 3-axis stacking robot, and a walking beam hydraulic conveyor for package handling. • Application: casting and solidification of metal ingots • Status: available for immediate sale Dedozbty Sepfx Agvjch • Current condition: in operation The equipment has been operated under normal industrial conditions and has been maintained in accordance with the manufacturer's recommendations. The machine is suitable for the production of aluminum ingots and can be integrated into existing melting and casting operations. Its robust design ensures reliable operation and consistent casting quality.

Condition: good (used), Year of construction: 1960, functionality: fully functional, type of input current: AC, Melting furnace, 1960 - KF Arc Furnace_AC EAF 8 ton, 4 MW - Nominal capacity 8,0 t, output during production has been 6,0 - 10,0 t - Power transformer 4 MW Karhula Foundry has two molding lines and hand molding for large castings. Our melting capacity consists of 8 ton arc furnace and 8 ton, 1,5 ton and 0,5 ton induction furnaces. We have an 8 ton AOD (Argon Oxygen Decarburization) converter for metal treatment. Dodpfx Agevampgsvoch

Year of construction: 2020, condition: new, Kreuzmayr fruit drying cabinet OTS 4 Dcodpfx Ajygm Isgveh drying surface 4m³ stainless-steel construction

Condition: used, functionality: fully functional, type of input current: three-phase, input voltage: 380 V, INDUSTRIAL ELECTRIC HEAT TREATMENT FURNACE - EMISON Dsdpfx Aozbg Rqjgvoch Electric heat treatment chamber furnace manufactured by EMISON (Forns Elèctrics Emison SA, Badalona, Spain), a Spanish specialist in industrial furnaces. From an industrial company liquidation (insolvency proceedings). ═════ SPECIFICATIONS ═════ - Manufacturer: EMISON (Forns Elèctrics Emison) - Country of origin: Spain (Badalona) - Type: Electric heat treatment chamber furnace - Power supply: 380V three-phase - Heating: electric resistance elements - Temperature control: analog - Large heating chamber - Robust metal frame construction - Model: [TO BE CONFIRMED FROM NAMEPLATE] - Max temperature: [TO BE CONFIRMED] - Total power: [TO BE CONFIRMED] - Chamber dimensions: [TO BE CONFIRMED] ═════ CONDITION ═════ - Used, from an industrial closure (not due to malfunction) - Frame in good condition - Sold as-is, a full inspection is welcome before pickup - Original manual NOT included - No warranty implied ═════ ABOUT THE MANUFACTURER ═════ EMISON (Forns Elèctrics Emison SA) is a Spanish industrial furnace manufacturer based in Badalona, Barcelona, and is still active today. The manufacturer provides technical support and spare parts directly for existing units. This makes EMISON furnaces a safer choice than those from defunct brands. ═════ APPLICATIONS ═════ Suitable for: - Heat treatment of metal parts (annealing, tempering, hardening preheat) - Industrial drying processes - Ceramic firing (low-medium temperature) - Curing of coatings and paints - Laboratory and R&D thermal processes - General industrial heating ═════ LOGISTICS & PURCHASE ═════ - Pickup location: Madrid, Spain (or Barcelona) - Weight: [TO BE CONFIRMED - approx. 600-1,000 kg] - Loading: forklift required - Inspection welcome by appointment - Payment: bank transfer - Documents: invoice provided - International shipping possible — buyer arranges transport Keywords: EMISON furnace, heat treatment furnace, electric industrial oven, chamber furnace, Spanish furnace, annealing oven, drying oven, tempering furnace, industrial heating equipment. For technical questions, additional photos, or to schedule an inspection, please send a message.

Condition: excellent (used), Year of construction: 2020, machine/vehicle number: SN376848, functionality: fully functional, 12 months warranty, available for immediate delivery Electrically heated recirculating air chamber furnace Nabertherm NA 500/45 - T max 450 °C - Internal dimensions W x D x H 750 x 1000 x 750 mm - External dimensions W x D x H 1400 x 1910 x 1810 mm - Volume 500 liters - Nabertherm controller P470 (50 programs, each with 40 segments) - Feedthrough, e.g., for thermocouples - Alarm and control indicator light Djdpfeya D Auox Agvsch - Pneumatic lift-up door - Additional insert shelf - Loading weight 500 kg - 125 kg max. per level - Power 18 kW - Weight 800 kg - Documentation, CE declaration - Electrically tested and supplied with a current DGUV test report This series can be operated with a fumigation box (not included). Internal dimensions 630 x 780 x 610 mm. A slot must be cut into the furnace door for this. Inspection in our warehouse is possible at any time! All devices are electrically tested and supplied with a warranty. Furnace, Industrial furnace, Burn-in oven, Heat treatment oven, Laboratory furnace, Drying oven, Tempering furnace, Chamber furnace, Annealing furnace.
