Radial drill

MAS VO 63

Condition: used, Technical details: x-travel: 6500/13150 mm y-travel: 4000 mm z-travel: 1250 mm w-axis: 2250 mm table surface area: 5500/12150 x 3000 mm max. workpiece weight: 70.000/105.000 kg ram head dimension: 480 x 510 mm milling spindle motor: 63 kW max. torque on the spindle: 3300 Nm tool taper: DIN 39871 AD ISO 50 milling head speed: 6,3 - 4000 U/min feed speeds: 1 - 24000 mm/min w-axis: 1 - 6000 mm/min. distance between columns: 3500 mm passage: 3000 mm total power requirement: 120 kW weight of the machine ca.: 245 t dimensions of the machine ca.: 29,0 x 7,7 x 8,1 m The machine is in mint condition and was generally overhauled in 2020! with CNC SIEMENS 840 D autom. tool magazine for 153 tool stations autom. milling head magazine for 6 heads milling heads - straight - straight extended length - milling head -angular head standard - 4000 rpm, 144 x 2,5°, ISO 50 milling head -angular small extended length -40 kW, 4000 rpm, 1800 Nm, 144 x 2,5°, ISO 50 Gedpfxewc A Sho Agbjtt milling head -universal index - 40 kW, 4000 rpm, 2100 Nm, C-axis 144 x 2,5° , B-axis +/- 44 x 2,5°, ISO 50 coolant attachment, chip conveyor *

Condition: used, Surface grinding machine BLOHM type HFS 6 make no.: 10493 year of construction 1973 Electro magnetic clamping plate 600 x 300 mm grinding length 600 mm grinding width 400 mm table longitudinal movement max. 650 mm transversal movement 350 mm distance spindle center - table surface max. 600 mm distance spindle center - magnetic plate max. 517 mm Clamping surface table 1020 x 300 mm Gjdpfx Aged Hbafsbett grinding wheel diameter 300 mm grinding wheel width 50 mm grinding wheel bore 76 mm table longitudinal feed 2-30 m/min infinitely variable table cross feed 2-65 mm stepless electric cross feed 3 m/min vertical feed 0,001 - 0,020 mm per infeed pulse vertical feed 0,250 m/min grinding wheel speed 1400 / 2800 rpm. Motor power hydraulic pump 2,2 kW Motor power grinding spindle 5 / 6 kW Mains connection 380 Volt, 50 Hz. Total power 11 kW - automatic depth adjustment - hydraulic longitudinal table movement - grinding wheel dresser on the headstock - electromagnetic plate height 83 mm - coolant system adjacent, with magnetic filter in filter housing - grinding spindle circulating lubrication - adjacent control cabinet (800 x 500 mm) - swiveling control panel - operating instructions and spare parts manual space requirement L x W x H 3000 x 2200 x 2100 mm weight surface grinding machine 3000 kg weight switch cabinet 200 kg good condition

Condition: used, Year of construction: 2001, functionality: fully functional, machine/vehicle number: 124, Price upon request Used CNC Vertical Lathe Manufacturer MORI SEIKI Model VL 55 Year of manufacture 2001 With MSC 518 CNC control, 12-tool turret, and chip conveyor Gtsdpfswl An Iex Agbet Turning length = 653 mm Turning diameter = 550 mm X-axis = 350 mm Z-axis = 660 mm Speed up to = 2000 rpm Spindle power = 30 kW Approx. weight = 12.5 t Price upon request Specifications: Used CNC Vertical Lathe Manufacturer MORI SEIKI Model VL 55 YOM 2001 With MSC 518 CNC control, 12-tool turret, and chip conveyor Turning dia. = 550mm Turning length = 653 mm X-Axis = 350mm Z – Axis = 660 mm Speed = 2000 rpm Spindle power = 30 kW Weight approx.. = 12.5 t

Condition: excellent (used), New 2008 Swing over bed - 600 (Ø 23.62) Gtodpfx Agjrfx Tnebet Diameter × length - Ø 300 × 600 (Ø 11.81 × 23.62) Max. diameter - Ø 380 (Ø 14.96) Max. travel range of Z/X axis - 600 / 240 (23.62 / 9.44); Z-axis: FANUC 2.8 kW (4 HP) /3000 rpm; X-axis: FANUC 2.8 kW (4 HP) /3000 rpm Diameter of spindle bore/Draw bar bore - STD: Ø 77 / Ø 52 (Ø 3.03 / Ø 2.04); OPT: Ø 86 / Ø 77 (Ø 3.38 / Ø 3.03) Spindle speed - STD: 8” chuck 3500 rpm; OPT: 8” chuck 4500 rpm, 10” chuck 3500 rpm Chuck diameter - STD: Ø 8” ; OPT: Ø 10” Hydraulic Tailstock – travel 465 (18.3) MT. No.4 VDI Tool stations - OPT: 8 STD: 10 Coolant Chip conveyor Power requirement - 208-220 volts / 100 Amps / 3 Phases / 60 Cycles Floor area (L × W × H) - 4080 ×1675 × 1842 (160.62 × 65.94 × 72.51) Gross weight (approx.) - 5200 kg (11440 Ibs)

Condition: ready for operation (used), Year of construction: 2001, CNC milling machine TOS TV-1000 A CONTUR Gjdpfehlp Iwsx Agbjtt Manufacturer: Trens Model: MC 100 VA Year of construction: 2001 Condition: used Control unit: Heidenhain TNC 426 X-axis travel: 1000mm Y-axis travel: 600mm Z-axis travel: 760mm Table length: 1080mm Table width: 580mm Tool changer with 40 positions Tool holder according to ISO 40 Spindle speed: 8000 rpm Overall dimensions: L 3200 x W 2100 x H 2900 mm Weight: 6200 kg Shipping possible throughout Germany and Austria. Surcharge 1000 € Sale excluding warranty.

Condition: as good as new (ex-display), Year of construction: 2023, operating hours: 31 h, 3D Coordinate CNC measuring device Profitech Innometrik Advanced in gantry design (demo unit at a special price) Open Cable Special features of the gantry design: Gantry design with a low center of gravity, wide bearing separation and optimum stiffness to mass ratio. The granite guideways ensure a uniform thermal, dimensional, torsional and geometric stability of the machine. 24 air bearings for smooth movement of the three axes. High dynamics for better performance, the machine can achieve high accelerations like comparable medium and large CMMs. Thermally compatible materials and components minimize the influence of ambient temperature fluctuations on measurement results, Air filter and regulator. Z-axis pneumatic counterweight system. Granit table with thread inserts of size M10. Passive vibration isolation pads Technical specifications Measurement paths: X: 500mm Y: 600mm Z: 400mm Max workpiece weight: 250kg Weight of the machine: 850kg Dimensions over everything: 1290x1160x2350mm Accuracy according to DIN EN ISO 10360-2 or ISO 10360-4: Volumetric probing deviation: MPEP = 2.2μm Volumetric length measurement deviation: MPEE = 2.2+ L / 350 (μm) Environmental conditions: Room temperature standard: 18-22 ° C Operating temperature 10-35 ° C Air Supply: Gjdpfodyah Sox Agbjtt Minimum air pressure: 6bar Air consumption: 90NI / min Also configurable as a complete package with touch probe, software commissioning and training. (Annual maintenance & calibration can also be offered)

Condition: used, Year of construction: 2007, Technical details: faceplate diameter: 1600 mm power requirement: 80 kW weight of the machine ca.: 25 t Gtodpfsx Aq E Hex Agbet dimensions of the machine ca.: 4,4 x 4,62 m max. workpiece diameter: 2000 mm max. diameter of face turning: 1800 mm tool taper: ISO50 The machine has been regularly serviced and is in good technical condition. With C-Axis *

Condition: used, VTL SC 17 CC Vertical Turret Lathe Gedpfsxdcxuex Agbott Specification: Faceplate diameter: 1450 mm Swing diameter: 1700 mm Turning height: 1200 mm Weight of the machine ca.: 22 t

Condition: used, Year of construction: 2005, x-travel 1.000 mm y-travel 1.000 mm z-travel 1.000 mm Control 840 D Siemens turning speed range - main spindle 20 - 18.000 min/-1 power capacity - main spindel 28 / 19 kW max. Torque 121 Nm tool taper HSK-A63 swivellable B: -30 / +180 ° swivle time 1,2 s numbers of pallets 2 size of pallet 1.000 x 800 mm max. workpiece weight 1.500 kg rotatable C: 360 ° number of toolpositions 180 pos. tool taper HSK-A63 total power requirement 78 kVA weight of the machine ca. 27,0 t dimensions of the machine ca. 8,0 x 7,0 x 3,4 m 5 Axis - CNC Machining Center Universal DECKEL MAHO - DMC 100 U duoBLOCK - Swivel-Milling-Head (B-Achse) - NC-Rotary (C-Axis) Gedpfx Aswf Rgfjgbjtt - pallet changer - 180-pos. tool-changer - WITHOUT zero point clamping system - WITHOUT RINGLER exhaust - WITHOUT tools

Condition: used, Year of construction: 1999, Technical details: x-travel: 3 500 mm y-travel: 2 200 mm z-travel: 1 200 mm c-axis: +/- 200° control: Heidenhain TNC 426 spindle rpm - counter clockwise:: max. 10000 spindle rpm - clockwise:: max. 10000 distance between columns: 2 500 mm distance spindle /table: vertical: 1230 mm clamping surface area: Tisch: 3000 x 2000 mm table load: 10 t tool taper: HSK A 63 feed:: X/Y/Z: max. 20 m/min. compressed air: 8 bar total power requirement: ca. 100 kW Gedpfx Agju Nc Emjbjtt weight of the machine ca.: 40 000 kg dimensions of machine: 18,0 x 6,0 x 5,8 m 5 axis Portal Milling Machine 5-axis portal milling machine Milling spindle: make Hauser type HS 256A-01 Uni, speed max. 10.000 rpm. direct drive Milling head: make Hamül, fork type, A-axis integrated = angle of rotation +/- 110°. Tool changer: Hamül make, rotary indexing table type with rotary table, for 32 tool positions chip conveyor: 2 pieces hinged belt conveyor make DGS with water tank, insertion length 8.500mm make BKW type DL 55V-2KK, capacity 2,41 l/min.; (combined for oil- water mixture for oil and spindle cooling) Cooling lubricant system: belt filter make DGS type SBF 150 Operation: via control panel type Heidenhain LE 426 X-, Y- and Z-axis with Heidenhain measuring rods. manual control unit HR 410 hydraulic counterbalance (Z-axis) Equipment: Enclosure (protective walls with viewing windows and protective doors) hydraulic system working area lighting *
