Used Wmw Dlz 355 for sale (481)

Condition: used, Year of construction: 1959, machine/vehicle number: 1727, Offer 24177 Technical data: - Center height 180 mm - Center distance 1000 mm - Larger swing – Ø over bed 355 mm - Over cross slide approx. 200 mm - Spindle bore 36 mm - Taper of tailstock quill MK 5 - Travel of tailstock quill 260 mm - Spindle speeds 18 - 1800 rpm - Feeds Cjdpfx Aiev Hckgoisri - Travel of cross slide approx. 200 mm - Travel of top slide approx. 115 mm - Drive 400 V / 5.8 kW - With: - Tailstock, 3-jaw chuck, steady rest - Steel holder, live center, - Chip tray - Space requirement approx. W 2500 x H 1500 x D 1200 mm - Weight approx. 2100 kg

Condition: ready for operation (used), functionality: fully functional, turning diameter over cross slide: 530 mm, spindle bore: 90 mm, turning diameter: 920 mm, Lathe type WMW DLZ 800 III for sale. Equipped with Heidenhain digital readout. Crsdpfsy Ar Niex Aiiji The machine functions flawlessly and has seen very little use (mainly for maintenance). Includes faceplate, 2x steady rests, several tool holders, and operating manual. - Heidenhain digital readout - Turning length: 3150 mm - Weight: approx. 7300 kg - Power: 13/20 kW - 380 V - Swing over bed: 800 mm - Swing over gap: 920 mm - Swing over cross slide: 530 mm - Spindle bore: 90 mm - Tailstock MK-6 Loading by forklift. Shipping possible by arrangement. Please feel free to contact me with any questions.

Condition: ready for operation (used), machine/vehicle number: BS 50, For sale is a heavy-duty, industrial pillar drilling machine made in Germany, suitable for medium to heavy drilling operations. The machine is immediately available, can be demonstrated while powered on, and is in fully functional, ready-to-use condition. Technical data: Machine type: Pillar drilling machine Manufacturer: WMW SAALFELD Type: BK 50 A I Cedpj Ah Urhjfx Aiieri Control: conventional Country of origin: Germany Drilling capacity in steel: 50 mm Overhang: 355 mm Drilling stroke: 280 mm Spindle mount: MK 5 Spindle head adjustment: vertical 280 mm, motorized Feed rate: 0.11 – 1.73 mm/rev (9 steps) Speed range: 32 – 1,400 rpm (12 steps) Table size: 770 × 640 mm Clamping area: 630 × 500 mm Base plate: 490 × 530 mm Distance from base plate to spindle: max. 1,180 mm Total power requirement: 8.1 kW Machine weight: approx. 1,700 kg Dimensions (L × W × H): approx. 1.25 × 0.8 × 3.0 m Used, solid industrial machine Machine can be demonstrated while powered on Technically functional – immediately ready for use Delivery time: immediate Incoterms: EXW (ex works) Loading: can be organized via a freight forwarder If you are interested, please feel free to write or call: ☎️ Maschinenhandel Nord Gerstenstraße 2 17034 Neubrandenburg

Condition: good (used), Year of construction: 1954, machine/vehicle number: 1749, Offer 24178 Crodpfjtiym Rjx Aiiji Technical data: - Center height 250 mm - Center width 2000 mm - larger circulation - Ø over bed 490 mm - over cross slide approx. 300 mm - Spindle bore 72 mm - Taper of the tailstock quill MK 5 - Travel of the tailstock quill 260 mm - Spindle speeds 25 - 1160 rpm - Feed rates - Travel of the cross slide 200 mm - Travel of the top slide 115 mm - Drive 380 V / 5.5 kW - with: - tailstock, 3-jaw chuck, steady rest - Steel holder, rotating center point, - chip tray - Space requirement approx. W 3500 x H 1500 x D 1300 mm - Weight approx. 3000 kg

Condition: used, Parallel Lathe WMW NILES type DLZ 500 IV L 1000 Between points: 1000 mm Maxi Ø on bench: 500 mm Maxi Ø over saddle: 300 mm Spindle diameter: Ø 50 mm Spindle speed: from 28 to 1400 RPM 3-jaws chuck Ø 200 mm Csdjz Iz Hpopfx Aiiori Threadings: Metric + Whitworth Tailstock CM4 Auto Feeds transverse + longitudinal + rapid Lubricant pump Voltage: 380 V Dimensions (L x W x H): 3000 x 1400 x 1500 mm Weight: approx 2,5 T

Condition: used, Year of construction: 1969, turning diameter over bed 500 mm turning diameter over slide rest 330 mm turning diameter in the gap 600 mm turning length 3000 mm bed width 505 mm spindle bore 72 mm spindle head DIN 55022 Gr. 8 taper in tailstock MK 5 turning speed range 22,4- 1120 U/min power requirement 18,5 kW dimensions 5,3 x 1,75 x 1,53 m weight of the machine ca. 5,2 t used lathe in nice condition with digital scale - 2 axis digital scale Crodpfjy Tyy Dsx Aiiji - 4 jaw chuck Ø 250 mm - 3 jaw chuck Ø 260 mm - Multifix "C" toolholder system - some toolholders - steady

Year of construction: 1983, condition: ready for operation (used), Turning diameter over bed/face slide: 630mm/340mm, turning length: 2000mm, center height: 290mm, clearance: 70mm, speed: 1180rpm, chuck: 400mm wedge bar chuck, tailstock: MK5, total power requirement: 15kW, machine dimensions X/Y/Z: approx. 5000mm/1350mm/1500mm, weight: approx. 4500kg. Including 2x 340mm steady rests, 2x medium steady rests, face plate with a diameter of 630mm, 2x face plates with cross slots, various tool holders, steady rest box, tool cabinet with additional tools, Heidenhain position indicator and 400mm key bar chuck. Documentation available. On-site inspection is possible. Cedpfsu Av E Hjx Aiisri

Condition: ready for operation (used), Center height: 450mm, distance between centers: 3000mm, fuse protection: 630A, rated current: 46A, control voltage: 220V, operating voltage: 380V, frequency: 50Hz, connected load: 22,5kW, weight: 6,1t, with four-jaw chuck (diameter: 800mm), tailstock, quill and three steady rests. An on-site inspection is possible. Codpfx Aozukufoiieri

Condition: ready for operation (used), Fuse protection: 100A, control voltage: 220V, operating voltage: 380V, connected load: 30,4kW, weight: 14,4t, with four-jaw chuck (diameter: 900mm), tailstock, quill, three steady rests and control system. An on-site inspection is possible. Csdpfxozukt Ie Aiijri

Condition: good (used), functionality: fully functional, turning diameter over cross slide: 630 mm, LATHE TECHNICAL SPECIFICATION – PERFORMANCE OVERVIEW Workpiece Capacity Turning diameter over bed (nominal / max): 630 mm / 660 mm Turning diameter over carriage: - Short slides: 400 mm - Long slides: 320 mm Max. swing in front of faceplate notch: 720 mm Notch length: 265 mm Over bed: 305 mm Over floor: 1125 mm Machine Construction & Spindle System Bed width: 550 mm Spindle bore: 72 mm Faceplate: - Diameter: 630 mm - Width: 120 mm Tooling & Setup Tool cross-section (cutter): 40 × 40 mm Tool holder side length: 200 mm Cedpfex Acpdox Aiisri Spindle & Drive Performance Main motor speed: 1400 rpm Spindle speed steps: 18 Max. permitted faceplate speed: 560 rpm Feed Ranges Longitudinal feeds: - Steps: 68 - Range: 0.035–10 mm/rev Cross feeds: - Steps: 68 - Range: 0.014–4 mm/rev Rapid Traverse Rates Longitudinal: 5000 mm/min Cross travel: 2000 mm/min Thread Cutting Capability Metric threads: - 84 types, 0.2–224 mm Inch threads: - 94 types, 140–1/8 TPI Module threads: - 72 types, 0.1–112 Pitch range: - 94 types, 280–1/4 Machine Dimensions Overall length: 2300 mm + distance between centers Width: 1850 mm Height: 1725 mm Ask for a testing video! Robust and precise heavy-duty lathe featuring wide turning capacity, extensive thread cutting options, and high feed/rapid traverse performance. Ideal for demanding workshops requiring versatility, power, and reliability.

Year of construction: 1965, condition: ready for operation (used), A WMW lead and feed spindle lathe that was overhauled in 1993 and has not been used since then is available. Center width: 1600mm, turning length: 1600mm, turning diameter: 250mm, turning diameter over bed/cross slide: 450mm/250mm, steel holder surface X/Y: 140mm/140mm, steel cross-section: 25mm/25mm. Speed: 2240rpm, spindle bore: 45mm, faceplate diameter: 450mm, quill stroke: 160mm, max. workpiece weight: 800kg/1250kg, max. journal diameter: 60mm. Including taper turning device, coolant device and quadruple steel holder. Documentation available. On-site inspection is possible. The machine was not used after its overhaul in 1993. Codpfxevy E A Se Aiisri

Condition: used, Technical details: turning diameter over bed: 1200 mm turning diameter over support: 800 mm turning length: 3200 mm length of gap: 600 mm center height measured in bed: 600 mm turning dia. in gap: 600 mm spindle turning speed - continuous: 4,6-545 / 22 steps U/min spindle passage: 90 mm feed: 1,4-510 m/min taper: MK6 total power requirement: 15 kW weight of the machine ca.: 10,0 t dimensions L x W x H: 6,20x2,00x1,80 m dimensions electric cabinet LxWxH: 0,55x0,33x1,0 m equipped with: face chuck diameter 1000m (4 jaw chuck) fourfold chisel taper steady rest closed, inside diameter 250mm revolving tail center conical turning device Cedpfx Aijzuyfaeijri *

Condition: excellent (used), Year of construction: 2011, operating hours: 39,090 h, functionality: fully functional, machine/vehicle number: 14390, travel distance X-axis: 1,350 mm, travel distance Y-axis: 970 mm, travel distance Z-axis: 1,300 mm, total height: 4,150 mm, total length: 8,500 mm, total width: 5,500 mm, overall weight: 32,500 kg, spindle speed (min.): 20 rpm, spindle speed (max.): 6,000 rpm, operating hours of spindle: 8,407 h, coolant supply: 80 bar, spindle motor power: 30,000 W, spindle nose: HSK-A100, number of slots in tool magazine: 60, Equipment: chip conveyor, Travel distances Travel distance X: 1350 mm Travel distance Y: 970 mm Travel distance Z: 1300 mm with measuring system from Haidenhain Pallet size: 800 x 1000 mm Table load: 2000 kg Horizontal/vertical milling table Working spindle Diameter at the front bearing: 110 mm Drive power: (60% duty cycle) 30 kW Drive power: (100% duty cycle) 29 kW Crjdpfxez Nc Eio Aiiei Torque: (60% duty cycle) 1088 Nm Torque: (100% duty cycle) 985 Nm Spindle speed: 20…6000 rpm Spindle taper: HSK-A100 NC rotary table with 500 rpm Table speed for positioning operation up to 60 rpm Table speed for turning operation up to 500 rpm Operation at 100% duty cycle with speed >200 rpm max. 20 min Workpiece diameter incl. fixture 1400 mm Workpiece height: 1400 mm Workpiece weight incl. fixture up to 60 rpm 2000 kg Workpiece weight incl. fixture above 60 rpm 1200 kg Tangential moment 10000 Nm Tilting moment 20000 Nm Drive power (100% duty cycle) 57 kW Drive torque (100% duty cycle) 2520 Nm Machine is equipped with automatic imbalance detection Tool changer: 60 positions Max. tool diameter: 325 mm Max. tool length: 450 mm Max. tool weight: 35 kg Internal coolant supply through the spindle center up to max. 80 bar Additionally: - Coolant gravity band filter from Knoll - Chip conveyor Knoll - HYFRA industrial cooling system - 1x special pallet for turning with 4 jaw chucks 50-2 D1000mm - 1x exchange pallet with T-slots 800x1000mm - 3x exchange pallet with threaded holes DIN55201 800x1000mm - Pallets without workpiece clamping devices - Electronic handwheel - Optical measuring probe OMP60 from Renishaw Net machine weight with H/V table approx. 32500 kg Space requirement approx. (L x W x H) 8500x5500x4150mm Technical data without guarantee. Errors and prior sale reserved.

Condition: used, Year of construction: 1990, functionality: fully functional, Table dimensions: 1000 x 1200 mm Max. table load: 3000 kg Spindle diameter: 90 mm Tool changer: manual Taper: MT5 (Morse Taper 5) "X" travel: 1000 mm "Y" travel: 1000 mm "Z" travel: 1600 mm Table rotation: 0-360 degrees Electric power: 23 kW Maximum table load: 30,000 N Machine weight: 9700 kg Dimensions (L x W x H): 8000 x 4000 x 3000 mm Crodpfxe Ah Ti To Aiioi Accessories, Equipment - 3-axis DRO (Digital Readout) system - Complete documentation - Various tools The machine is fully functional but no longer in production. It has been professionally dismantled.

Condition: refurbished (used), Year of construction: 2017, functionality: limited functionality, WMW UNION CNC table-type boring mill, completely overhauled and modernized in 2017. The machine has been rarely used since then. It is currently disassembled and kept in storage. Cannot be inspected under power!!! Codpfx Aj Af U Dvoiiori

Year of construction: 2020, condition: ready for operation (used), functionality: fully functional, WMW Niles, Czech Republic Made, CNC(Siemens Controls, Retrofitted in 2020) Floor Type Heavy Duty Lathe ,With heavy Duty Tail Stock, Steady Rest, Rollers, and with 6000 MM X 4000 MM Floor plates Crsdszww R Sjpfx Aiioi

Condition: good (used), Year of construction: 1969, number of straightening rollers: 7, straightening roller diameter: 290 mm, max. sheet width: 2500 mm Convexity length of rollers: 2700 mm max. sheet thickness (St 50): 32 mm max. sheet thickness (St 34): 39 mm min. sheet thickness (St 50): 8 mm number of straightening rollers: 7 rollers number of driven straightening rollers: 5 rollers diameter of straightening rollers: 290 mm diameter of input/output straightening rollers: 345 mm number of support rollers: 13 diameter of support rollers: 288 mm stroke of upper beam: 120 mm Crsdpfx Ais Ah Enfjiei Straightening speed: 16 m / min Rated power of main drive: 90 kW Total load: 138 kW

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 1,600 mm, feed length W-axis: 900 mm, workpiece weight (max.): 12,000 kg, overall weight: 30,000 kg, year of last overhaul: 2020, For Sale – Used CNC Horizontal Boring Machine UNION BFKR 150 CNC Control: HEIDENHAIN TNC 530 CNC Retrofit: The machine was retrofitted with CNC control in 2020. Technical Specifications: X-axis travel: 3,000 mm Y-axis travel: 1,600 mm Z-axis travel: 1,600 mm W-axis travel: 900 mm (spindle travel) Spindle diameter: Ø 150 mm B-axis: 360° – CNC-controlled rotary table Table dimensions: 1,600 × 2,000 mm Crodpfj Afm Uyjx Aiiei Machine Condition: The machine is currently still connected to the power supply and is available for inspection and a test run. The machine underwent a mechanical overhaul approximately three years ago, including the replacement of bearings and other components. The machine has been out of operation for approximately six months.

Condition: used, Year of construction: 1981, functionality: fully functional, overall weight: 4,800 kg, total height: 1,800 mm, total width: 3,500 mm, total length: 3,200 mm, Grinding machine NILES ZSTZ 315/630 C2 Max. wheel diameter: 315 mm Max. module: 10 Min. module: 1.5 Max. gear width: 160 mm Max. workpiece weight: 200 kg Cjdpsz Tc Akefx Aiieri Engine power: 8 kW Machine dimensions: 3.2 x 3.5 x 1.8 m Machine weight: 4.8 t

Condition: like new (used), Year of construction: 2022, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, pressing force: 100 t, stroke length: 500 mm, operating speed: 400 mm/s, reverse speed: 450 mm/s, table width: 1,250 mm, table length: 630 mm, table height: 860 mm, throat depth: 360 mm, ram plate width: 850 mm, ram plate length: 450 mm, distance table to ram: 800 mm, retraction force: 1.6 t, total length: 2,300 mm, total width: 1,865 mm, total height: 3,650 mm, overall weight: 7,000 kg, year of last overhaul: 2026, controller manufacturer: SIEMENS, Equipment: CE marking, documentation/manual, safety light barrier, Hydraulic C-frame press ZEULENRODA | 100t | Retrofit system from 2026 with CE conformity + manufacturer's warranty --3 units available | short delivery time-- HIGHLIGHTS - Press frame in steel welded construction for maximum stability and rigidity - Press force 1,000 kN | adjustable based on stroke and pressure - Clamping area, table 1250 x 630 mm - Ram stroke 500 mm - infinitely adjustable - Ram plate with anti-rotation protection and guided by columns - Rapid traverse and short stroke function - Active oil cooling - Hydraulic ball-type quick-release couplings for safe and fast tool changes - Protection on the operator side via light curtain, on the side and rear via safety guard Crodjz Hcz Sopfx Aiioi - SIEMENS control + touch panel - Interface for automation - Comfortable operation with BWS-1 cycle + BWS-2 cycle - Remote maintenance - CE conformity + manufacturer's warranty Ram column guidance: - Two diagonally arranged guide columns each. They also serve to prevent the ram plate from twisting. Hydraulic equipment: - Oil tank, hydraulic control / pump completely installed and ready for operation with all required pipelines, pumps and valves as well as the control units. - Electronic stroke measurement system - Stroke control: stroke-dependent - pressure-dependent - stroke-pressure-dependent - Option for setting a press time of 0 ... 10 minutes Safety: - BWS / light curtain on the operator side - Transparent protective elements on the sides, movable - Retraction lock (interlock) - Hydraulic and electrical safety devices in accordance with DIN EN 16092-3 Control / Operation: - SIEMENS - Touch panel control unit as a lift console (height adjustable) - Standing two-hand control unit - 100 storable tool data sets - Transfer of stroke parameters using the teach-in method - Various password levels - ... Operating modes of the press - Off - Setup / Two-hand - Single stroke / Two-hand - Single stroke BWS 1 cycle / 2 cycle - Master / Combined operation / Automation Tool control / protection - 6 x tool cams (24V / 2A outputs), freely programmable - Electronic tool protection with 8 inputs, freely configurable Remote maintenance (eWON Cosy) Service & Support ZEULENRODA PRESSTECHNIK

Condition: excellent (used), Year of construction: 1982, functionality: fully functional, power: 75 kW (101.97 HP), input voltage: 380 V, input frequency: 50 Hz, pressing force: 500 t, stroke length: 500 mm, table width: 2,100 mm, table length: 3,150 mm, distance table to ram: 1,200 mm, total length: 4,700 mm, total width: 4,400 mm, total height: 7,500 mm, overall weight: 140,000 kg, Equipment: documentation/manual, Erfurt mechanical press with an open frame, 500-ton capacity, 3150 mm table, in very good condition. The machine can be inspected at our workshop in Peschadoires, France. The technical documentation will be provided with the press. Csdpfx Aie Ahy Ttjiori Please find attached photos of the press and the technical data sheet. Price available upon request.

Condition: good (used), Year of construction: 1982, number of straightening rollers: 13, straightening roller diameter: 145 mm, bale length: 2,330 mm, Year of construction / YOM: 1982/2024 Sheet width: 2000 mm Sheet thickness - max.: 10 mm Sheet thickness - min.: 3 mm Number of straightening rollers: 13 rollers Straightening roller diameter: 145 mm Straightening speed: 16 m/min Bundle length: 2330 mm Center distance between straightening rollers: 150 mm Support roller diameter: 290 mm Main drive motor: 30 kW Weight: 32 t Additional information: - Number of support rollers: 21/24 - Number of supports (top/bottom): 3 /3 - Traverse lift speed: 0.71 mm/sec - Traverse lift stroke: -18 mm to +42 mm Cedpfo Ah Enqjx Aiisri - Max. tilting of lower traverse: 8 mm

Condition: excellent (used), Year of construction: 1980, Make: WMW Mikrosa Model: SASL 200x500 Minimum workpiece grinding diameter: 10mm Maximum workpiece grinding diameter: 200mm Maximum grinding wheel diameter: 500mm Minimum grinding wheel diameter: 370mm Maximum grinding wheel width: 500mm Grinding wheel bore diameter: 305mm Cedpfs Ahqhgex Aiijri

Condition: good (used), Year of construction: 1975, pressing force: 250 t, Pressure: 250 t Throat: 400 mm Stroke: 30...140 mm Table size: 1000 x 750 mm Passage opening in table: 360 x 400 mm Ram area: 630 x 500 mm Cjdpfx Ais Ahxlqoisri Ram adjustment: 110 mm Total power requirement: 18 kW Machine weight approx.: 16 t

Condition: used, faceplate diameter 800 mm Codpfx Aie Ah T Uzsijri hollow 130 mm height 120 mm weight of the machine ca. 0,25 t dimensions of the machine ca. 1,2 x 0,8 x 0,3 m Face plate with short-taper mount, size 8, diameter 800 mm
