Used Swing Chisel for sale (2,883)

Condition: used, Year of construction: 1973, Storage location: Nattheim Nsdevvkt Ujpfx Ahvswd

Condition: used, Year of construction: 2007, Fully programmable 3 axis horizontal CNC swing chisel mortiser suitable for general joinery and furniture production. By a combination of automatic movement of the mortisting head in the x axis and an automatic gripper that positions the timber no manual movement or handling of the component is required other than loading and positioning the timber against the pneumatic reference stop and then unloading when the mortising cycle is finished. The complete movement, clamping and, mortising cycle is fully automatic. X, Y and, Z axis movements are all via re-circulating ball and screw drives and using linear slideways to give maximum positioning accuracy. Thanks to the programmable Z axis it is possible to produce off line mortises, double mortises or produce thicker mortise slots with the same chisel. Programming is very simple thanks to the 'user friendly' graphic touch screen controller were programs can be memorised and stored under a number or specific name up to 8 characters. The swing chisel cutter itself produces a very clean mortise slot and if required for deep mortises up to 3 depths of cut can be programmed to give a 'woodpecker' type cutting operation. Other programming options include working off either the face of the timber or the thickness and the possibility to produce mirror image components (left/right hand) in one program. Year - 2007 CE X axis stroke 1100mm. Y axis stroke 250mm. Max. depth of cut 120mm (depending on chisel size) Z axis stroke 100mm Max. workpiece height of 120mm. All movements on re-circulating ball and screw drive with brushless motor Njdpfxoymnbns Ahvswd Max. workpiece width 200mm Max. swing chisel thickness 20mm. Min . slot length 25mm approx (with swing chisel) Min. slot thickness 6mm. 3 vertical pneumatic clamps. 3 horizontal pneumatic clamps. 4 hp main motor. 'Power 1000' touch screen graphic controller with 99 programs each with 50 lines. USB key facility. Programmable speed for cutting depth. Anti splinter guards with air blowers and dust extraction points. Working table dimensions 1210mm x 215mm Air supply 6 bar / 470 l/min consumption. Fitted with separate dedicated programmable hollow chisel head for producing the small mortises for glazing bars

Condition: new, Automatic mortising machine with 3 heads Worktable dimensions 3000 x 300mm Cast iron construction to give maximum rigidity 3 x vertical hydraulic work piece clamps Nedpfx Asn Nv Txshvewd 3 x horizontal hydraulic work piece clamps Speed movement in adjustable through hydraulics Automatic operation Mortising heads x 3. Manually positioned in X axis with mechanical locks Mechanical siko readouts for height position - Z axis Double eccentric operation of the mortising heads (patented design) Motor HP3 RPM 2800mm Max distance between 2 x outside mortising heads 2800mm Min distance between 2 x outside heads 180mm - ctre to ctre of mortise. Dust extraction outlets 100mm Hydraulic pump motor 10hp

Condition: new, Centauro BETA 3 Axis CNC Swing Chisel Mortiser A new fully programmable 3 axis horizontal CNC swing chisel mortiser suitable for general joinery and furniture production. By a combination of automatic movement of the mortisting head in the x axis and an automatic gripper that positions the timber no manual movement or handling of the component is required other than loading and positioning the timber against the pneumatic reference stop and then unloading when the mortising cycle is finished.The complete movement, clamping and mortising cycle is fully automatic. X,Y and Z axis movements are all via re-circulating ball and screw drives and using linear slideways to give maximum positioning accuracy. Thanks to the programmable Z axis it is possible to produce off line mortises, double mortises or produce thicker mortise slots with the same chisel. Programming is very simple thanks to the 'user friendly' graphic touch screen controller were programs can be memorised and stored under a number or specific name up to 8 characters. The swing chisel cutter itself produces a very clean mortise slot and if required for deep mortises upto 3 depths of cut can be programmed to give a 'woodpecker' type cutting operation. Other programming options include working off either the face of the timber or the thickness and the possibility to produce mirror image components (left/right hand) in one program. On request the machine can be equipped with a separate dedicated programmable hollow chisel head for producing the small mortise holes for glazing bars. Alternatively a horizontal milling head can be specified that can be used for hinge recessing, slotting for louvre doors etc etc. Nwedob Tmpqepfx Ahved X axis stroke 1100mm. Y axis stroke 250mm. Max. depth of cut 120mm (depending on chisel size) Z axis stroke 100mm Max. workpiece height of 120mm. All movements on re-circulating ball and screw drive with brushless motor Max. workpiece width 200mm (wider on request). Max. swing chisel thickness 20mm. Min . slot length 25mm approx (with swing chisel) Min. slot thickness 6mm. 3 vertical pneumatic clamps. 3 horizontal pneumatic clamps. 4 hp main motor. 'Power 1000' touch screen graphic controller with 99 programs each with 50 lines. USB key facility. Programmable speed for cutting depth. Anti splinter guards with air blowers and dust extraction points.1 x 80mm 1 x 60mm dia. Working table dimensions 1210mm x 215mm Installed power 3.6kw. (std machine) Air supply 6 bar / 470 l/min consumption.

Condition: used, Swiveling aggregate, chain width 10 mm Storage location: Nattheim Njdpfx Ahsvvku Esvewd

Condition: good (used), functionality: fully functional, Year of construction: 1991, This high-performance swing beam shear RAS 83.30 with ELGO NC backgauge and pneumatic sheet support comes from first ownership. Cutting capacity: 3190 x 2.5 mm Drive power: 5.5 kW Machine weight: 2800 kg Nedpfx Ahsxmi Dpevjwd Includes pneumatic sheet support, ELGO NC backgauge, 1 left-hand side stop, and 3 additional support arms. Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany

Condition: new, functionality: fully functional, machine/vehicle number: 005119, Year of construction: 2016, Equipment: documentation/manual, Slewing arm – spare part – König Loader KA SL260 Nodex Tqhlopfx Ahvjwd Complete new 25x25 KA-SL V4 thread drive with mounting parts for a loader for the lifting movement of the slewing arm – automation of the production machine (Reishauer) Koenig Automation AG – Switzerland, Item 005119 new and unused – procured as a spare part Price / details on request. All technical information is subject to typing errors/mistakes. We sell exclusively to countries of the European Community.

Condition: new, Saw unit swivels 46 ° on both sides. Programmable, electric saw blade adjustment Control unit with electronic display for saw blade tilt and lift Torsional rigidity and vibration-free working Easier plate feeding due to large trimming frame with roller Telescopic ruler with 2 professional folding stops Excellent cutting precision scoring unit equipped with its own motor - easily adjustable from the outside Nodpjd Akygofx Ahvswd saw blade diameter of 400 mm scoring saw blade with a diameter of 160 mm 2-position saw blade pendulum protection manell adjustable 3-axis controlled Motorized rip fence with electronic positioning includes: Position display via an encoder Adjustment via ball screw Stepless adjustment via switch or automatic positioning system Cutting width 1270 mm Programmed movement of motorized adjustment and tilting for saw unit UP version with swivelling control panel for maximum flexibility X version with Compex miter fence for quick and accurate execution of miter cuts with automatic compensation of the stop position. (Length compensation) incl. options: - cutting lenght 3200 mm - on / off buttons for main motor and scoring unit integrated in saw carriage - CompeX frame - Version "READY 3 UP" - 2 saw speeds (3500/5000 U/min) Max. cutting width with rip fence 1270 mm Format cuts 3200 mm main motor 7,0 kW, 400 V, 50 Hz Saw blade angle -46 - 46 ° Max. cutting height 90° 136 mm Max. cutting height 45° 97 mm Max. cutting height -45° 60 mm saw blade diameter 400 mm Diameter scoring saw blade 160 mm (Main) saw blade speed 4000 min¯¹ Dust extraction ports 120 & 80 mm

Condition: excellent (used), functionality: fully functional, Year of construction: 2004, machine/vehicle number: LS137, Technical Data: 1x Demag KBK 2 pillar slewing crane, nominal load (NL) 500 kg with Demag DK chain hoist Load capacity at full outreach: 500 kg Height: approx. 4.05 m Underside of jib: approx. 3.55 m Outreach: 4 m Nwedpfsywfmwox Ahvsd Hook height: approx. 2.8 m Total weight: approx. 1,000 kg incl. anchor plate 115x115 cm With 500 kg Demag DK chain hoist incl. bolts, cable carrier, trolley, end cap, etc. Slewing range: 300°, connection at 400V 16A Crane is dismantled and immediately available Item location: 75053 Gondelsheim Additional cranes with load capacities from 80 kg to 5,000 kg available on request See pictures Shipping via forwarding agent or collection by appointment only

Condition: excellent (used), functionality: fully functional, Year of construction: 1986, machine/vehicle number: LS14 + RIO RES, Technical Data: 1x Demag KBK 2 pillar slewing crane NL 500KG with Demag PK chain hoist There are 4 cranes available!! Load capacity at full outreach: 500KG Height: approx. 3.55m Underside of jib: approx. 3m Outreach: 3m Hook height: approx. 2.6m Total weight: approx. 300KG With 500KG Demag PK chain hoist Incl. bolts, cable trolley, trolley, end cap, etc. Slewing range 300°, connection to 400V 16A Crane is dismantled and immediately available Item location: 75053 Gondelsheim, Germany Further cranes with capacities 80-5000Kg available – please inquire Nwedpfsywfl Tex Ahvjd See pictures Shipping via freight forwarding or collection only by appointment

Condition: used, functionality: fully functional, Year of construction: 1986, machine/vehicle number: LS29, Technical data: 1 ABUS LS column slewing crane, rated load 125KG Load capacity at full outreach: 125KG / 0.125t Height: approx. 2.95m Outreach: approx. 4m Underside of jib: approx. 2.4m Hook height: approx. 1.95m Total weight: approx. 400 kg Incl. 125KG Abus chain hoist Nwsdpfx Ahsywfltevod Slewing range 270°, connection to 400V 16A Crane is dismantled and available immediately Item location is 75053 Gondelsheim Additional cranes available, load capacity 80–5000kg, please enquire See pictures Shipping by freight forwarder or collection by appointment only

Condition: used, functionality: fully functional, Year of construction: 1978, machine/vehicle number: LS32, Technical data: 1 ABUS LS column jib crane NL 125KG Capacity at full outreach: 125KG / 0.125t Height: approx. 2.95m Outreach: approx. 3m Underside of jib: approx. 2.4m Hook height: approx. 2.05m Total weight approx. 400 kg Incl. 125KG Liftket chain hoist, year of manufacture 1995 Slewing range 270°, connection to 400V 16A Crane is dismantled and immediately available Item location is 75053 Gondelsheim Nwodpfx Ahjywfk Njvod Additional cranes available, capacities from 80-5000kg, please inquire See pictures Shipping by freight forwarder or collection by appointment only

Condition: used, functionality: fully functional, Year of construction: 1978, machine/vehicle number: LS31, Technical data: 1 ABUS LS column slewing crane, rated capacity 125 kg Rated load at full outreach: 125 kg / 0.125 t Height: approx. 2.95 m Outreach: approx. 3 m Underside of jib: approx. 2.4 m Hook height: approx. 2.05 m Total weight: approx. 400 kg incl. 125 kg Abus GM chain hoist, year 2004 Slewing range 270°, connection 400V 16A Crane is dismantled and immediately available Nwsdeywfh Uopfx Ahvod Item location: 75053 Gondelsheim Several other cranes available, load capacity 80–5000 kg, please inquire See pictures Shipping by forwarding agent or collection by appointment only

Condition: like new (used), Chain Mortiser LS 103 EO - 8.7 kg - Year of manufacture: 2016 - 230 Volt - with stand Nodpfeyty I Hox Ahvewd - 2600 Watt

Condition: good (used), You are bidding here on a branded guillotine shear and a folding machine from the well-known German manufacturer Schechtl. Device features: - Guillotine Shear MSB 200: - Cuts 3 mm steel – significantly more for aluminum - Cutting length: slightly over 2 m - Front support table - 500 mm back gauge - Optional sheet metal tray - Free loading available - Folding Machine Schechtl MAX 200: - Rail bends cleanly – test possible - Degree indicator - Bending length: slightly over 2 m - Sheet thickness: 2.5 mm (steel, sheet metal, aluminum, zinc, etc., higher for softer materials) - Standard rail – special radius rails for aluminum and zinc available upon request (add-on and special rails) - Foot pedal operation - Optional back gauge We also have available: Schechtl MSB 200, Schechtl MA 200, Schechtl HA 200 (2 mm), segmented RAS 2 m / 2 mm, and many others from 1 to 6 m. You will receive an invoice with VAT shown separately. Shipping can be arranged upon request. Free loading as shown in the pictures. Inspection and testing possible by prior phone appointment. Payment in cash upon collection – if you need anything else, please give me a call. Thank you! Collection should take place within 8 days after the end of the auction. Nsdoyviwqepfx Ahvewd Location: 97249 Eisingen (3 minutes from the motorway) Item numbers: 251007 and 251008

Condition: excellent (used), functionality: fully functional, Year of construction: 1986, machine/vehicle number: MIKA-CN, Technical specifications: 1x Demag KBK 1 pillar jib crane, rated load 125 kg with Demag DC chain hoist (125 kg - year 2007) Load capacity at full outreach: 125 kg Height: approx. 3.05 m Underside of jib: approx. 2.55 m Outreach: 3 m Hook height: approx. 2.15 m Total weight: approx. 300 kg Nsdpfoyu E I Iex Ahvewd Equipped with 125 kg Demag DC chain hoist Including pin, cable drag chain, trolley, end cap, etc. Slewing range 300°, connection to 400V 16A Crane is dismantled and available immediately Item location: 75053 Gondelsheim Additional cranes with load capacities from 80–5000 kg available, please enquire See photos Shipping via freight forwarder or collection by appointment only

Condition: used, Year of construction: 2019, Base frame, carousel and swing arm of a Kuka KR 360 R2830 industrial robot with: Nwedpfex A D Rcex Ahvjd - Axis 2 motor: Siemens 1FK7105-5AY81-1YY3-Z - Counterbalance GA16

Year of construction: 2026, condition: new, 1200mm diameter vibrating screen Two screening decks Made of SS304 stainless steel Nodpfeym Rinox Ahvewd 0.5mm and 0.25mm mesh Mesh cleaning ball system 2.2kW 380V 50Hz three-phase motor

Condition: used, Swing cut guillotine shears KÖLLSCHEN type BSK 2000/2 No. 69 1307 Year of manufacture 1969 Cutting length 2000 mm Cutting thickness 2 mm Stand projection 90 mm Working height 920 mm Mains connection 380 Volt, 50 Hz Motor power 4 kW - Drive via geared motor with brake and crankshaft - Mechanical sheet holder - Manual back gauge 500 mm - fence adjustment via 2 handwheels, at the rear on the back gauge guide with scale - front side stop left 720 mm Njdpfx Ahjifu Anjvewd - electric foot switch - manual central lubrication - Control cabinet on the machine - Machine stands on 4 swinging elements, approx. 100 mm height Space requirement L x W x H 2800 x 1700 x 1450 mm weight 2300 kg good condition

Condition: used, Model:- AY 1000 x 1000, Serial No: Nc-A3-045 Nedpfx Ahsyn R Hcsvowd 1 metre swing over bed, 1 meter between centres 390mm Swing Over Saddle 180mm Spindle Bore 4 Jaw Chuck 800mm Diameter Quick Change Tool Post Fagor 8055 controls Made In Taiwan

Year of construction: 1991, condition: as good as new (ex-display), machine/vehicle number: Mü0136, Technical data: 1 Demag KBK column slewing crane NL 2x 250KG with 2 booms Payload at full radius 2x 250KG / 0.25ton payload Height: approx. 4.23m, UK boom: approx. 3.75 + 3.2m Projection: approx. 2+3m, hook height: approx. 3.3m + 2.75m Weight completely approx. 700 KG with 2x 250Kg Demag PK chain hoist with floor control Connection to 400V 16A, swivel range 2x 270° Crane is dismantled and packed on a pallet Good condition, see pictures Location is 75053 Gondelsheim Only the crane system shown in the pictures is sold Njdsqmilljpfx Ahvewd Shipping by courier or collection by appointment

Condition: like new (used), Stainless vacuum packer, chamber dimensions 500mm x 430mm x 100mm, seal bars 400mm, timer / temp controls, mobile, 3Ph Nsdpfx Ahjfhdt Hevowd

Year of construction: 2007, condition: excellent (used), machine/vehicle number: WD700/10, Technical data: Nsdpfev Hv Edjx Ahvowd 1 Vetter / Demag pillar jib crane NL 500KG with Demag chain hoist Type AS5-4.0 Payload at full reach 500 KG / 0.5 tonne payload Height: approx. 3.75m UK boom: approx. 3.42m Reach: approx. 3.5m Hook height: approx. 2.85m Total weight approx. 800Kg including dowel plate 1050mm with Demag chain hoist 500Kg (older) Swivel range 270°, connection to 400V 16A Crane is dismantled and available immediately Item location is 75053 Gondelsheim Other cranes are available, load capacity 80-5000Kg, please enquire See pictures Shipping by freight forwarder or collection only by appointment

Condition: used, Used machine Nwedpoyklfxofx Ahvjd

Condition: excellent (used), functionality: fully functional, Year of construction: 2007, machine/vehicle number: OTH222, Technical data: 1 ABUS LSX column slewing crane NL 500KG Load capacity at full outreach: 500KG / 0.5t Height: approx. 3.25m (incl. 0.5m base) Outreach: approx. 3.5m Underside of jib: approx. 2.93m Hook height: approx. 2.5m Nwsdpsyl Sqqefx Ahved Total weight: approx. 800kg Incl. 500KG Abus chain hoist and anchor plate 100x100cm Slewing range 270°, connection 400V 16A Crane is dismantled and immediately available Item location: 75053 Gondelsheim Further cranes available, capacities 80-5000kg, please enquire See pictures Shipping by freight forwarder or collection by appointment only
