Used Cnc Lathe Control Cycle for sale (52,416)

Condition: like new (used), Year of construction: 2019, operating hours: 40 h, functionality: fully functional, machine/vehicle number: D6A 191101, turning diameter over cross slide: 220 mm, turning length: 900 mm, turning diameter: 400 mm, turning diameter over top slide: 220 mm, center height: 1,100 mm, rapid traverse X-axis: 5 m/min, rapid traverse Z-axis: 5 m/min, spindle speed (max.): 4,000 rpm, feed length X-axis: 220 mm, feed length Z-axis: 900 mm, total length: 2,495 mm, total width: 1,730 mm, total height: 1,700 mm, workpiece weight (max.): 80 kg, mount diameter: 20 mm, type of input current: three-phase, spindle motor power: 7,500 W, overall weight: 1,500 kg, rotational speed (min.): 50 rpm, rotational speed (max.): 4,000 rpm, chuck outer diameter: 200 mm, input voltage: 400 V, input frequency: 50 Hz, input current: 25 A, warranty duration: 24 months, Equipment: CE marking, documentation/manual, rotational speed infinitely variable, EMCOMAT E-200 MC for the manual or cycle-controlled machining of large workpieces The machine is intended for production-oriented users. High chip-cutting power, precision and universality are its characteristic features. The generous workspace allows large workpieces to be machined. The EMCOMAT E-200 MC´s circulating ball screws free of play allow precise axes positioning. The machine can be operated manually with hand wheels or feed keys or, with Sinumerik 828D as cycle-controlled lathe. Therefore, it‘s applicable for the production of single parts or small series. The ‘manual machine’ function on the user interface of the SINUMERIK 828D optimally implements the concept of a controlled conventional lathe. Whether during set-up, programming or machining – the skilled workers’ normal view of the work process is improved. EMCO‘s wide range of options covers everything you need to handle even the most complicated machining projects. - High cutting power - High quality casting with strong ribs for low-vibration machining operations - Fully automatic central lubrication of the X and Z slides and the recirculation ball spindles - Electronic handwheels are available for manual operation of X and Z axis - Made in the Heart of Europe Standard machine equipment:  Hardened linear guides in X and Z axis  Recirculating ball spindles for X and Z axis  Sinumerik 828D with „manual machine“ and and 10,4" LCD monitor  Coolant system  Central lubrication of guides and recirculating ball spindles  Electronic handwheels for X and Z control  Machine lighting  Partly covered workspace with sliding chip-stop doors  Loading drawers  Operator tools  User guide and spare parts list  Documentation of the electrical systems  M easure tool  Traverse axes  Set zero offset (ZO)  Turn straight line / circle  D rill, such as centered drilling, centering, deep-hole drilling  Turn, such as stock removal, grooving, thread cutting Itsdpfjxgi R Nsx Afion  Turn contour

Year of construction: 1980, condition: good (used), A used very well preserved cycle controlled lathe from Weisser Heilbronn with SIEMENS control. centre distance 2000 mm centre height 295 mm Swing over bed 600 mm Swing over cross slide 260 mm Swing diameter in the bend 800 mm Total length of the crank 375 mm Bed width 450 mm Plan travel X-axis 350 mm Longitudinal travel Z-axis 1850 mm Spindle nose DIN 55022 size 8 Spindle speed Number 18 14 - 1400 rpm spindle bore 71,5 mm Diameter of front bearing 110 mm Itjdpfx Afegyy I Aeien feed range 0,01 - 40,95 mm/rev rapid traverse 8 m/min Direct current drive 15 kW 400V 50Hz Max. permissible torque at the spindle 2500 Nm Tailstock quill 80 mm quill stroke 250 mm inner taper quill MK 5 Length x width x height Weight of the machine 5500 kg Accessories Tailstock Pneumatic three-jaw chuck with interchangeable jaws 315mm Quick change holder "MULTIFIX "in front of the center size "C Quadruple turret behind the center Tool holder Coolant device Pneumatic steady rest Technical data and dimensions: Errors excepted. Videoconference via whatsapp possible by appointment

Condition: used, CNC cycle controlled lathe HARRISON type Alpha 400 Plus Machine No. P30180/150 Year of construction 1998 center distance 1250 mm turning diameter over bed 400 mm center height 200 mm Swing diameter over cross slide 245 mm Swing diameter in the bend 585 mm bed width 313 mm face travel (X-axis) 250 mm Tailstock spindle diameter 73 mm Tailstock quill stroke 140 mm Tailstock quill mount MK 5 spindle bore 54 mm spindle head size Camlock D1 size 6 Spindle speed 20-2500 rpm. Spindle speed range (stage 1) 15-275 rpm. Spindle speed range (stage 2) 35-795 rpm. Spindle speed range (level 3) 110-2500 rpm. Feed rate X and Z 0.03 - 0.6 mm/rev. Rapid traverse speed X axis max. 2000 mm/min. Rapid traverse speed Z-axis max. 4000 mm/min. Threading function Metric / Inch / Diametral / Module Spindle drive power 7.5 KW Mains connection 400 Volt, 50 Hz, 23,5 kVA - cycle control Harrison Alpha / GE FANUC - language in French (France) - automatic gear range shifting in 3 steps (15-275, 35-795, 110-2500 rpm.) - electronic handwheels with different transmission ratios (1/10/100) - 3-jaw face spiral lathe chuck FORKARDT Ø 250 mm type CSN, 1 set of soft top jaws - quick-change tool holder MULTIFIX size B with 2 inserts - 1 piece of centering point running with the tool - 1 piece quick-action drill chuck RÖHM, 3-16 mm - hinged lathe chuck guard - hinged working area protection doors - chip tray with coolant device under the machine bed - Switch cabinet fixed to the machine Ijdpfx Aeh Hvk Aofietn - Interface RS 232 Space requirement L x W x H 2600 x 1450 x 1550 mm weight 1950 kg good condition

Condition: as good as new (ex-display), Year of construction: 2025, Machine is in the exhibition and was only used for demonstration purposes. Optiturn L44 CNC Premium CNC lathe direct from the manufacturer. L44 CNC - The OPTIMUM Premium CNC milling machine with Siemens SINUMERIK 828D control is characterized by performance, speed, precision and long service life. Dimensions and weights Width/depth max. 2300 mm Length approx. 2530 mm Width/depth approx. 1595 mm Height approx. 1795 mm Weight approx. 2600 kg Working areas Lathe chuck diameter 150 mm Lathe chuck Hydraulic control of the clamping movement Center height 223 mm Center width 850 mm Swing diameter over machine bed 446 mm Swing diameter in the bed bridge 520 mm Swing diameter over cross slide 240 mm Bed width 300 mm Motor torque X-axis 6 Nm Z-axis 8.5 Nm Speed range Number of speed ranges 1 Speed range 10 - 3000 min¯¹ Electrical data Drive motor power 7 kW Supply voltage 400 V Mains frequency 50 Hz Electrical connection Total connected load 23 kVA Accuracy Repeat accuracy ± 0.005 mm Positioning accuracy ± 0.005 mm Hydraulic system Motor output 0.75 kW Tank capacity 50 l Coolant system Coolant pump output 270 W Tank capacity 90 l Machine data Chuck opening diameter 40 mm Motor(s) Torque drive motor 33 Nm Tailstock Mounting MK 4 Quill stroke 165 mm Quill diameter 52 mm Spindle Spindle holder DIN ISO 702-1 No. 5 Spindle bore/bar passage diameter 52 mm Control system Ijdpfxsw Ea Tuo Afiotn Type Sinumerik 828D PPU 240 System software SW 24 CNC memory 3 MB Look Ahead 50 Block change time 3 ms Number of tools 128 Travel distance X-axis 250 mm Z-axis 760 mm Vertical spindle Power drive motor continuous operation S1 7 kW Power drive motor S6-30 % operation 16 kW Drive motor torque 33 Nm Drive motor S6-30 % operation 80 Nm Feed rate Speed X-axis 15000 mm/min Z-axis 15000 mm/min Feed force Feed force X-axis 7.5 kN Feed force Z-axis 5.3 kN Tool changer Hydraulic type; VDI 30 Number of tool positions 8 pcs Mounting height, width square max. 20 x 20 mm Boring bar mounting diameter max. 25 mm SIEMENS SAFETY INTEGRATED Equipment Main spindle - Solid design Machine bed - Heavily ribbed - High rigidity and durability Guideways - Stable flat bed guide Recirculating ball screw - For high rapid traverse speeds in all axes - Less wear and tear - For high positioning and repeat accuracy Cast body - Hardened HRC48-52 and heat-treated Machine feet - Six pieces - Optimum alignment of the machine Heat exchanger - Closed switch cabinet with intelligent cooling management - Optimum temperature even at high outside temperatures Tool changing system - Eight tool stations - Hydraulic VDI30 tool changer - Pick-up height max. 20 mm Hydraulic unit - Motor power 750 W - Tank capacity 50 liters - Clamping pressure / operating pressure 2,500 - 2,942 kPa Three-jaw chuck - Hydraulic three-jaw lathe chuck Ø 150 mm - Hydraulic loosening and clamping via foot switch - Simple clamping of workpieces - Hard and soft block jaws Central lubrication system - Automatic supply at intervals - Reduces wear on bearings, ledges and ball screws - With float switch. An acoustic signal sounds if the oil level is too low

Condition: not inspected (used), Year of construction: 2012, functionality: unexamined, machine/vehicle number: 12.0273 / 121V0308, spindle bore: 128 mm, turning diameter: 530 mm, center width: 3,000 mm, turning diameter over bed slide: 830 mm, spindle speed (min.): 1,800 rpm, No minimum price – guaranteed sale to the highest bidder! Placing a bid obliges you to collect the machine punctually between 28.07.2025 and 31.07.2025. TECHNICAL DETAILS Max. machining diameter: 530 mm Swing diameter over bed: 820 mm Swing diameter over cross slide: 530 mm Distance between centers: 3,000 mm WORK SPINDLE Front spindle nose (DIN 55027, 55029): B11 / C11 Spindle bore: 128 mm Taper in spindle (metric): 132 mm Control: HEIDENHAIN MP620 Spindle speed range: 0–400 / 20–1,800 rpm Torque level 1: 2,150 Nm Torque level 2: 430 Nm X-AXIS Travel: 370 mm Ballscrew diameter/pitch: 32/5 mm Rapid traverse: 10 m/min Max. feed force: 10 kN Repeatability of positioning: 0.01 mm Z-AXIS Ballscrew diameter/pitch: 50/10 mm Iedpfx Afewu E Icsietn Stroke: 3,000 mm Rapid traverse: 10 m/min Max. feed force: 20 kN Repeatability of positioning: 0.015 mm TOOL TURRET Type: Multifix D Tool profile: 40 x 40 mm TAILSTOCK Tailstock quill diameter: 115 mm Quill stroke: 225 mm Morse taper in quill: Morse 6 MACHINE DETAILS Connection voltage: TN-C 400/230 V Frequency: 50 Hz Installation dimensions: 5,000 x 2,200 x 1,900 mm Weight: 5,300 kg Connected load: 38 kVA EQUIPMENT With technical documentation Coolant tank capacity: 200 l Chip conveyor capacity: 160 l

Condition: used, Year of construction: 2003, functionality: fully functional, machine/vehicle number: 020564, turning length: 2,980 mm, turning diameter: 660 mm, spindle bore: 90 mm, spindle speed (max.): 2,500 rpm, spindle speed (min.): 2 rpm, total height: 2,000 mm, total length: 6,510 mm, total width: 2,370 mm, quill diameter: 100 mm, quill stroke: 200 mm, swing diameter over cross slide: 400 mm, turning diameter over bed slide: 433 mm, workpiece weight (max.): 2,000 kg, overall weight: 5,300 kg, We are offering our cycle lathe for sale here. This is a bad investment that we never put into operation. Iodjwycnqjpfx Afietn * CNC control Siemens 810 D * Automatic 8-position SAUTER turret, tool holder VDI 40 * 3-jaw power chuck, diameter 300 mm * Chip conveyor * 2 steadies * Central lubrication * Mahle changeover filter system

Condition: good (used), Year of construction: 1998, mas masturn 40 cnc teach-in Heidenhain control 1998 max. turning diameter 400 mm max. turning diameter over bed 250 mm max. turning length 800 mm spindle 1 - 2400 rpm Itsdpfxswbputj Afion spindle bore 61 mm 11 kW including accessories and documentation machine is powered up for inspection.

Condition: new, Z-MaT CNC/Cycle Lathe FTL660-2000mm Control: Siemens 828D Shop Turn, 15" Touch Flat bed with linear roller guideways and telescopic cover Hydraulic 3-jaw chuck 380 mm Ø Max. swing over bed: Ø700 mm Max. workpiece length: 1800 mm (with chuck) Max. turning diameter over cross slide: Ø480 mm Spindle Spindle bore: Ø120 mm Max. bar capacity: Ø110 mm Spindle nose: A2-11 Max. spindle speed: 1000 rpm Spindle power: 22/30 kW Tooling 12-position servo turret Tailstock Hydraulic tailstock MK5 Quill stroke: 100 mm Tailstock travel: 1850 mm (manual) Itodpfx Ajwwt Trsfion Axes X-axis travel: 370 mm Z-axis travel: 2000 mm X/Z-axis rapid traverse: 15/15 m/min Bed type/guides: box bed/linear roller guides Bed width: 600 mm Accessories: Manual steady rest 110–260 Overall dimensions (L×W×H): 4.5 x 1.96 x 2.1 m Weight (approx.): 6.4 t The machine will be displayed at EMO, Hall 12/D10, and will be available immediately afterwards. Further sizes of this series can be found in the PDF.

Condition: excellent (used), Year of construction: 2016, Machining center Make KNUTH Type EcoMill 350 CNC Isdpjtiauhsfx Afijtn

Condition: new, Year of construction: 2025, CNC control Fagor or Siemens delivery time approx 4-5 month Including normal equipment: - electrical equipment 24/230/400V german fabrication (CE-Norm) - machine lamp 24Volt Itodpfx Ajdag Svefien - cooling unit - steel holder, 4-fold, incl. upper support - 4-chuck faceplate 1000mm - Savety housing - central lubrication SKF/Vogel -1 set technical documentation, including: -- Operating manual -- circuit diagramm -- programming manual -- decleration of conformity (CE) - machine painting combination RAL 7035 and RAL 5015 Technical specifications Workpiece diameter over bed: 1000mm Working diameter over bed:1000 mm Working diameter over support: 650mm length between centers: 5000mm Max. weight of workpiece, withoit steady rest: 8000 kg Spindle head DIN 55026: Gr.15 spindle bore: 128mm Spindle inside cone(metrisch): 140 Performance of main drive: 22/30* kW spindle speed: 5-500U/min Turning speed steps (manual / stepless within steps): 24 max. spindle torque:9500Nm Machine dimensions: Length: 8200mm Width: 2400mm Height: 2000mm Weight: 15750kg * option

Condition: used, Year of construction: 2002, Weiler E90 / 4.5M - CNC Lathe with Cycle Automation - Weiler D2 cycle control - Chip conveyor - Approx. 15 pcs. Multifix quick-change toolholders - 1 live centre Itjdexn Rr Repfx Afisn - Regular servicing by Weiler - Supplied without chuck, without steadies - Year of manufacture: 2002 Technical Data Working Area: - Distance between centres: 4500 mm - Centre height: 450 mm - Swing diameter over bed: 900 mm - Swing diameter over cross slide: 530 mm - Bed width: 600 mm - Travel of cross slide: 590 mm - Travel of top slide: 250 mm - Cross slide length: 1230 mm - Cross slide width: 345 mm - Saddle guideway length: 860 mm - Tool shank cross-section (height/width): 40 x 40 mm Spindle: - Spindle nose according to DIN 55027 / 55026 size: 11 - Spindle diameter in front bearing: 178 mm - Spindle bore: 128 mm - Main spindle internal taper, metric: 140 mm Main Drive: - Spindle nose according to DIN 55027 size: 11 - Total speed range: 1 - 1120 rpm - Speed range gear stage I: 1 - 350 rpm - Speed range gear stage II: 4 - 1120 rpm - Drive power at 60%/100% duty cycle: 45 / 37 kW - Max. torque at spindle: 6000 Nm Feed Drive: - Feed range Z/X: 0 - 20 mm/rev - Feed force Z/X: 20 kN - Rapid traverse speed Z/X: 7 / 3.5 m/min Tailstock: - Quill diameter: 140 mm - Quill stroke: 300 mm - Quill internal taper: MK 6 Thread Cutting Range: - Metric threads: 0.1 - 400 mm - Inch threads: 1/4 - 56 TPI - Module threads: 0.125 - 28 mm - DP threads: 1 - 224 DP Connection Data: - Operating voltage: 400 V - Control voltage: 24 / 230 V - Connected load: 55 kW - Rated current: 85 A Machine Dimensions: - Total length: 6900 mm - Total width: 2600 mm - Total height: 2120 mm - Machine weight: 10,500 kg

Condition: not inspected (used), Year of construction: 2001, The machine is located in storage in 64850 Schaafheim. Condition is unchecked. There is the option to connect the machine to power. If someone is familiar with the machine, they are welcome to inspect it. Loading costs are covered by the buyer. The machine is sold as seen. Video available from before dismantling. Technical data: - 2x 10-position turret with driven tools - 2x C-axis on main and sub-spindle - 1x Y-axis 35 mm on turret 1 - 2x 3-jaw chucks Iedpfexlfyksx Afistn - Chip conveyor, bar feeder, tool eye - 17,500 spindle hours - Turning diameter 102 mm - Turning length 450 mm - Spindle bore 65 mm - Tools VDI 30 - Year of manufacture: 2001 Video before dismantling: Approx. 8 tons and 7 loading meters due to chip conveyor and loading magazine Invoice available

Condition: used, CNC control, numeric control, from GILDEMEISTER GDM 65/2A GILDEMEISTER type Eltropilot EP20 GD-2A year of manufacture 1989 Ijdpjh Ecnasfx Afiotn Order: 150 299 Ser. No.: 0.854.183 Mains connection: 220 VAC 50 Hz Rack with 20 module places - 11 Built-in modules Dimension W x H x D 480x 260 x 220 mm Weight approx. 7 kg The control comes from a lathe Gildemeister GDM 42/2A. Further components from the Gildemeister can be found under stock no: 60343, 60346, 60347

Year of construction: 2006, condition: ready for operation (used), Turning length: 3000mm, center height: 392mm, swing over bed/ slide: 800/ 490mm, rotational speed: 1500-6000/min, tailstock diameter: 100mm, controls: FAGOR 800 T, with documentation, three-jaw chuck 400mm, with change jaws, four-jaw plate face 500mm, Multifix change holder, fixed bezel. Itsdpfsiwuh Tex Afijn

Condition: like new (used), Year of construction: 2022, turning diameter over cross slide: 230 mm, turning length: 1,000 mm, Chevalier FCL-1840H with Siemens 828D Control incl. ShopTurn Used machine, year of manufacture 2022 Machine equipment: • 3-step automatic gearbox • Movable control arm / Swiveling operator panel with 10.4'' screen • Automatic central lubrication • Coolant system with reinforced coolant pump • Thread repair cycle (thread re-cutting function) • Tool system: 4-position tool holder, upgrade to Parat or Multifix available at extra cost! • Workholding: 3-jaw wedge-bar chuck SMW, diameter 210mm Features: • Siemens 828D control incl. dialogue programming system 'ShopTurn' and 3D simulation • Fixed steady rest 20 - 160mm / follow rest 10 - 90mm • Movable control arm (over the full centre distance length) • Manual tailstock with MK5 quill • Stable, double prism guideway • Max. torque 2,750 Nm Isdpfsw Adb Rex Afiotn

Year of construction: 2008, condition: ready for operation (used), Turning diameter over bed: 300mm, max. workpiece length: 500mm/600mm, travel X: 319mm, feed X/Z: 3000mm/min/4000mm/min, rapid traverse X/Z: 4000mm/min/5000mm/min, speed: 4000rpm. Collet chuck: 5C 173E, spindle bore: 40mm, tool positions: 4, spindle travel of tailstock: 110mm. Machine dimensions X/Y/Z: approx. 2000mm/1450mm/1500mm, weight: approx. 1200kg, control: Fanuc Series 0i-TC. Including 380V transformer, Fluidtec spraying system, collet set and multifix holder set. Documentation available. On-site inspection is possible. Itedpfju T Rifsx Afijn

Year of construction: 1986, condition: ready for operation (used), Turning diameter over bed/face slide: 360mm/160mm, center distance: 800mm, travel X/Z: 205mm/810mm, speed: 3150rpm, spindle bore: 60mm, tool positions: 8, rapid traverse X/Z: 10m/min. Machine dimensions X/Y/Z: approx. 3300mm/1800mm/1800mm, weight: approx. 3300kg, control: Traub System TX-8. An on-site inspection is possible. Itodpewmqx Defx Afijn

Condition: ready for operation (used), Rotation diameter over bed/face slide: 710mm/410mm, turning length: 2000mm, center height: 350mm, spindle bore: 92mm, speed: 1800rpm, quill diameter: 210mm, rapid traverse X/Z: 8m/min/10m/min, feed: 5m/min, feed force: 2000daN. Machine dimensions X/Y/Z: approx. 5000mm/2000mm/2200mm, weight: approx. 5600kg. Documentation available. On-site inspection is possible. Ijdpfx Aevnd Trsfistn

Year of construction: 1997, condition: ready for operation (used), Center height: 195mm, center width: 1250mm, turning diameter over bed/faceplate/in bed gap area: 400mm/245mm/585mm, spindle bore: 54mm, speed: 2500rpm, power: 7.5kW, rapid traverse face pull/longitudinal pull: 1.5m/3m/min, quill: MK5. Machine dimensions X/Y/Z: approx. 2600mm/1500mm/1600mm, weight: approx. 1800kg, control: GE Fanuc. Documentation available. On-site inspection is possible. Itsdpfsua E Txsx Afion

Year of construction: 1995, condition: ready for operation (used), A Boehringer cycle-controlled CNC lathe is available. Turning diameter over bed/face slide: 820mm/520mm, turning length: 1000mm, spindle bore: 128mm, quill diameter: 125mm, quill stroke: 280mm, max. workpiece weight: 5000kg. Machine dimensions X/Y/Z: approx. 3700mm/2400mm/2500mm, weight: approx. 6500kg, operating hours: 39814h. On-site inspection is possible. Iodpfx Ajwu E Ddefietn

Condition: ready for operation (used), Turning diameter over bed/cross slide: 530mm/280mm, center height: 264mm, center width: 2000mm, bed width: 370mm, speed: 2000rpm, spindle bore: 80mm, tool shank dimensions X/Y: 25mm/25mm, cross slide travel: 300mm, quill diameter: 65mm, quill stroke: 180mm, repeat accuracy: mm. The machine has an electrical problem on the tool head. Documentation available. On-site inspection is possible. Iedpfx Afjv Amrtsistn

Condition: ready for operation (used), A Romi CNC cycle lathe is available. Center height: 215mm, center width: 1000mm, turning diameter over bed/face slide: 430mm/204mm, spindle bore: 53mm, rapid traverse X/Z: 7.5m/min / 10m/min, spindle speed: 4000rpm, main spindle motor power: 7.5kW, tool positions: 8, machine dimensions X/Y/Z: approx. 2800mm/1300mm/2000mm, weight: approx. 3000kg, control: GE Fanuc series 21i-TB. Documentation available. On-site inspection is possible. Isdpfxou H H Hve Afijtn

Year of construction: 1992, condition: ready for operation (used), Center height: 280mm, center width: 2000mm, turning length: 2000mm, turning diameter over bed/face slide: 570mm/340mm, spindle bore: 63mm, speed: 2500rpm, quill stroke: 160mm, quill diameter: 70mm, power requirement: 15kW. Machine dimensions X/Y/Z: approx. 3850mm/1850mm/1750mm, weight: approx. 3500kg. On-site inspection is possible. Isdewxfaaspfx Afijtn

Condition: ready for operation (used), Turning diameter over bed/face slide: 500mm/290mm, face travel: 260mm, turning length: 1000mm, spindle bore: 70mm, spindle diameter: 120mm, speed: 3050rpm, drive power: 12kW, torque: 920Nm, rapid traverse X/Z: 8m/min/10m/min, feed X/Z: 5m/min, quill stroke: 180mm, quill diameter: 80mm. Machine dimensions X/Y/Z: approx. 3400mm/2000mm/1850mm, weight: approx. 3100kg. Documentation available. On-site inspection is possible. Isdpsvnd Tfsfx Afiotn

Year of construction: 2006, condition: ready for operation (used), Turning diameter over bed/face slide: 500mm/290mm, face travel: 260mm, turning length: 1000mm, spindle bore: 70mm, speed: 3050rpm, torque: 920Nm, rapid traverse X/Z: 8m/min/10m/min, feed X/Z: 5m/min, quill stroke: 180mm, quill diameter: 80mm. Machine dimensions X/Y/Z: approx. 3400mm/2000mm/1850mm, weight: approx. 3100kg. Documentation available. On-site inspection is possible. Itjdpfx Afovnd Tljijn
