Used Cnc Bar Lathe for sale (29,386)

Condition: used, Year of construction: 2007, machine/vehicle number: L151804, Nakamura-Tome NTM3 lathe together with a 6-meter IRCO SiMag Breuning bar feeder. The machine has been serviced throughout its life by Abplanalp service, who also disconnected it and prepared it for transport after production was finished. We took it in as a trade-in with plans to start some production, but it turned out to be too large for our needs – so we never even connected it since then. Technical details (from manufacturer): • Year of manufacture: 2007 • 11-axis Nakamura-Tome Super NTM3 • 2 spindles, 3 turrets • Every second tool driven • Control system: Fanuc 16i-TB • Main spindle: 15 kW, up to 4500 rpm • Sub spindle: 11 kW, up to 5000 rpm Itjdsxg Nb Iopfx Afisn • Max turning diameter: 190 mm • Bar capacity: 65 mm • Machine weight: 12,000 kg Full documentation included: all manuals and schematics originally supplied with the machine. Additional equipment: • Parts catcher • Parts conveyor • Bar loader: IRCO SiMag • Electrical transformer • IRCO SiMag Breuning bar feeder (6m)

Condition: good (used), Year of construction: 1991, max. bar diameter: 42mm Chuck diameter: 40mm Diameter over cross slide: 160mm Speed range: 10-5000 rpm Turret with 12 stations (not driven) 12 Itedpfovy Uy Hox Afien Chip conveyor Bar loader FMB turbo 3000 max. bar length: 3m

Condition: good (used), Year of construction: 1998, Baujahr 1998 Spindelstunden 52’000h Stangendurchlass 40mm Itsdpfetth Hgex Afijn Fanuc Series 18i-T Späneförderer Toolsetter integriert 12Stationen 1Spindel, X und Z Achse Kurzstangenlader Spannzangenfutter F48

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: L220M0165, turning length: 510 mm, turning diameter: 250 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 175 mm, travel distance Z-axis: 550 mm, Maintenance of the machine in 2024 for €10,000 TECHNICAL DETAILS Control: CNC Fanuc I Series Turning diameter over bed: 250 mm Max. machining diameter: 250 mm Max. turning length: 510 mm Spindle Spindle bore: 53 mm Spindle speed: up to 6,000 rpm Drive power: 12 kW Axes X-axis travel: 175 mm (160 mm + 15 mm) Z-axis travel: 550 mm Tool carrier Iodpfxjwcnubo Afijtn Turret: 12-way Driven tools: All 12 stations MACHINE DETAILS Machine weight: 4 t Rated power: 23.68 kVA Part counter: 1,313,733 Control switch-on time: approx. 53,000 h EQUIPMENT - Tailstock - Bar loader LNS Turbo

Condition: excellent (used), Year of construction: 2020, SIEMENS 840D SL control unit Itsdpfovi Nizox Afien MAIN SPINDLE Speed 5.000 1/min Spindle bore 65 mm COUNTER SPINDLE Speed 7,000 1/min Spindle bore 42 mm 2 REVOVER Travel X1, X2 180mm Travel Y1 ±45mm Travel Z1= 704mm, Z2= 620mm 12 stations per revover all driven Chip conveyor Bar loading magazine TOP X-FILES XFS/7.3

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, machine/vehicle number: L705226, TECHNICAL DATA Manufacturer: Baron Max Model: KL-2680 Year: 2007 Serial Number: L705226 Control Unit: Fagor 8055TC WORKING CAPACITY Swing over bed: 670 mm. Center height to bed: 335 mm. Center height to top cross slide: 205 mm. Swing over cross slide: 400 mm. Dis. Between centers: 2100 mm. Width of bed: 450 mm. HEADSTOCK Spindle nose: A1-11 Spindle bore: 305 mm. Bar capacity: Ø 105 mm. Range of spindle speeds: 3 rang Gears Auto Shifting Spindle speeds range: H: 1500-331 rpm M: 330-93 rpm L: 92-24 rpm Taper in spindle: MT#6 SADDLE Longitudinal travel (Z-axis): 2000 mm. Cross-slider travel: 450 mm. Size of tool holder: Boring Tool: Ø 40 mm. O.D. Tool & Facing Tool: 25 mm. Ball screw (Dia x pitch): X-Axis: Ø25 mm. x P 5 mm. Z-Axis: Ø50 mm. x P 10 mm. TAIL STOCK Quill diameter: Ø105 mm. Quill travel: 220 mm. Quill taper: MT#5 ENGINE Spindle motor: 20HP Z-axis drive motor: 12 Nm. (FKM 44.3) X-axis drive motor: 6.3 Nm (FKM 42.3) Coolant pump motor: 1/4 HP X, Z-AXES FEED X axis rapid travel: 6 M/min. Z axis rapid travel: 8 M/min. Iedpfovai Swjx Afijtn GENERAL Power Required: 20 KVA. Floor space (L x M x H): 4090x1950x1820 mm. Approx, machine weight: 4700 Kgs. EQUIPMENT Coolant system Manual 4-way tool post 4 Jaws Self-centering scrolling chuck Ø 12". Steady rest

Year of construction: 2005, condition: good (used), All parts shown by hand not come. Itjdpod N I Ezsfx Afijn VAT not included in price.

Condition: good (used), Year of construction: 1993, - TRAUB control TX 8F - spindle passage 42 mm - Working spindle speed: 40 - 4.000 1/min - 4 grooving slides: stroke 60 mm Itedpfjldd Iqox Afisn - 8-fold turret - high pressure pump 25 bar - backworking (2 spindles) - bar feeder (3 m) - chip conveyor

Condition: used, Year of construction: 2008, operating hours: 36,051 h, functionality: fully functional, Controller FANUC 310i No. of cnc controlled axis 9 No. of turrets 3 x (2 x lower and 1 x upper) Spindles 2 x (main and sub) Isdpfjwymydox Afistn Turrets 12-fold Travels X/Z = 215 / 350 mm Spindle speed 7000 rpm Speed of live tool 5000 rpm Spindle power 16 kW Bar capacity D45 mm Chuck dia max D140 mm. Power required 100 kVA Barfeeder FMB Turbo 5-42 Chip conveyor Coolant unit Some tool holders and collets Manuals

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, Controller GE FANUC 21i-TB Swing dia 533 mm Turning dia 340 mm Turning lenght 355 mm X travel 209 mm Z travel 355 mm Spindle hole D50,8 mm Spindle speed 5000 rpm Chuck size max. D200 mm Turret 12-fold Rapid speed 30 m/min Spindle power 11 kW Spindle face A2-6 Tool holder type VDI30 C axis 0,001 degree (programmable) Dimensions LxWxH = 2300 x 1700 x 1700 mm Weight ca 3000 kg Features, accessories - Hydraulic chuck - Short barfeeder EMT Super 80 - Manual Guide in FANUC Software - Drive tool turret and C axis - Tailstock - Part catcher - Manuals Very good condition. The lathe works accurately and run quitely. Ready to buy immediately. Iedpfevw Uqajx Afistn

Condition: good (used), Year of construction: 2012, functionality: fully functional, Schiess CNC vertical lathe with C axis, year 1992, retrofitted in 2012 CNC: NUM 1060 FLEXIUM 2 tables, table diameter 2000mm – max turning diameter 2500mm – max table speed 201 rpm – table power 56 KW Load capacity (table included): 16,000kg Movable crossrail with 12 positions, 50mm pitch Available space under spindle nose: min. 795mm, max. 1345mm RAM Z stroke: 1000mm C axis with 360,000 positions – milling spindle max speed 1600 rpm – milling spindle power 22KW – 2 gear ranges Tool magazine: 20 turning tool positions, 35 milling tool positions 1 milling head WIDAFLEX UTS80 1 milling head ISO 50 Renishaw MP60 touch probe (for parts) Tool presetter – Transmit function: G20 / G21 – No rigid tapping Chip conveyor Front door: partial opening M0 / full opening Itsdpfx Afsxpqm Rjijn

Condition: new, Year of construction: 2025, turning diameter over cross slide: 250 mm, turning length: 730 mm, turning diameter: 500 mm, spindle speed (max.): 1,800 rpm, CNC lathe machine CK 6150 with flat bed We offer a new CNC lathe machine model CK6150. We use this machine in our production and you can see it in operation before ordering. The CK 6150 lathe has a flat bed and hardening guides, which ensures a long period of operation of the equipment. The machine is equipped with a CNC system, the GSK CNC system is installed as standard. Optionally, the machine can be equipped with a Fanuc or Siemens CNC system. The machine can have a tool holder for 4-6 or 8 tools, depending on the customer's wishes. It is possible to install a hydraulic chuck on the machine, which will greatly simplify the process of installing parts on it and a hydraulic tailstock. The CK 6150 lathe can be equipped with additional supporting frame for more accurate manufacturing of long parts. Technical specifications: Model CK 6150 x 1000 Maximum workpiece diameter over bed 500 mm Isdpfx Aoxdmgvefietn Maximum workpiece diameter over support 250 mm Maximum workpiece length 1000 mm Maximum turning length 730 mm Spindle bore diameter 82 mm Spindle speed 150-1800 rpm Engine power 7.5 kW Mechanical chuck (hydraulic optional) Chuck size 250 mm. 4-position tool holder (6 or 8 optional) Maximum tool size for tool holder 25x25 mm Machine weight 2700 kg Machine dimensions 2650×1700×1820 mm We can also supply lathes CK 6140, CK 6150 and CK 6160 with other dimensions of the working part: CK 6140 dimensions of the working part 550/750 mm CK 6150 dimensions of the working part 1000/1500/2000 mm CK 6160 dimensions of the working part 1000/1500/2000 mm CK 6152E dimensions of the working part 1000/1500/2000/3000 mm CK 6165E dimensions of the working part 1000/1500/2000/3000 mm CK 6165E dimensions of the working part 1000/1500/2000/3000 mm CK 6185E dimensions of the working part 1000/1500/2000/3000/4000 mm CK 61100E dimensions of the working part 1000/1500/2000/3000 mm CK 61125E dimensions of the working part 1000/1500/2000/3000 mm

Condition: excellent (used), Machine in very good condition. It has worked to the end, now it is on warehouse not connected to power. Machine in 100% completed Hu3Nhjg Parts conveyor, chips conveyor, bar feeder available. Spindels bore 42 mm IRCO feeder bar All manuals and documentation available Iodpfevllbrox Afijtn

Condition: ready for operation (used), Year of construction: 2005, operating hours: 9,400 h, functionality: fully functional, machine/vehicle number: 8662, turning length: 380 mm, turning diameter: 400 mm, spindle bore: 55 mm, spindle speed (max.): 5,000 rpm, spindle speed (min.): 100 rpm, travel distance X-axis: 160 mm, travel distance Y-axis: 440 mm, travel distance Z-axis: 380 mm, spindle motor power: 11 W, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 12 m/min, rapid traverse Z-axis: 20 m/min, total height: 1,900 mm, total length: 3,500 mm, total width: 1,650 mm, type of input current: three-phase, overall weight: 3,300 kg, bar passage: 45 mm, spindle nose: ASA 5", coolant pump power: 75 W, tailstock quill diameter: 85 mm, number of tool stations in tool turret 1: 12, Equipment: documentation/manual, Biglia B301 CNC Lathe – Used and Refurbished, in Excellent Condition Year 2005, used and overhauled, ideal for precision machining of small and medium components. A compact, reliable, and robust machine equipped with a bi-directional 12-position turret, hydraulic tailstock, and hinged chip conveyor. Perfect for machine shops and companies seeking a high-quality CNC lathe, fully operational and ready for use. Main technical specifications: - Model: Biglia B301 - Year: 2005 Capacity: - Max swing diameter: 400 mm - Max bar working diameter: 45 mm - Max chuck working diameter: 220 mm - Max machining length: 380 mm Spindle: - Spindle nose: ASA 5” - Spindle bore: 55 mm - Chuck: 3-jaw Autoblok 210 BH - Spindle speed: 100 – 5,000 rpm - Spindle motor power: 11 – 15 kW Travels: - X-axis travel: 160 mm - Z-axis travel: 380 mm - B-axis travel: 440 mm Rapid traverses: - X/Z axes rapid speed: 20 m/min - B axis rapid speed: 12 m/min Turret and tailstock: - Turret: bi-directional, 12 stations - Automatic tailstock: yes - Quill diameter: 85 mm - Taper: MT4 Weight and dimensions: - Machine weight: 3,300 kg - Dimensions: 3,500 × 1,650 × 1,900 mm (h) Included accessories: Itodpfx Aovw Agvsfijn - Hinged chip conveyor - 12 static tool holders - Finished parts catcher Condition and availability: - Refurbished, tested used machine in perfect operating condition - Ready for delivery - Inspection available by appointment at our premises Ideal for: Precision machining, serial production, and applications involving steel, brass, aluminum, and engineering plastics.

Condition: good (used), Year of construction: 2002, Universal CNC lathe BOEHRINGER NG 200 Manufacturer: BOEHRINGER Type: NG200 CNC double Control unit: Siemens 840D Year of construction: 10/2001 Turning diameter: 290 mm Turning length: 850 mm Control: SIEMENS 840 D Turning diameter over bed: 600 mm Turret 1 Turret 2 Counter spindle Counter spindle stock Tailstock C-axis Driven tools Automatic machine doors - newly retrofitted Z-axis resolution: 40nm (2nm interpolated) Travel path in Z: 740mm Rapid traverse speed in Z: 25 m/min Centering tip SK 30 X-axis resolution: 125nm (8nm interpolated) Travel path in Z: 220mm Rapid traverse speed in Z: 25 m/min Distance between main and counter spindle: 1034mm Drive power: 30-72 kW Torque: 662 Nm Max. speed range: 4500 rpm Spindle head: size 6/8 DIN 55026 Spindle diameter in front bearing: 120 mm Chuck diameter: 200-315mm Spindle bore: 103 mm Tailstock quill holder MK: MK 4 Machine weight approx. [weight]: 11 t Space required approx. [needed space]: 6.0x2.3x2.5 m Complete documentation is available. Inspection under power can be arranged at short notice. Iedpfx Afsvr Eqgoijtn We are happy to answer any further questions you may have. Price, ex warehouse here plus VAT. Condition: good - ready for demonstration Delivery: ex warehouse - as seen Payment: net - after receipt of invoice Subject to prior sale, errors excepted. We ask for your order. Other machines and systems available from stock - please enquire. We look forward to hearing from you.

Condition: good (used), Year of construction: 2013, operating hours: 59,861 h, functionality: fully functional, Control: Fanuc 32i A Automation: FMB Unirobot MH5LS-SP Grinding spindle: Jäger HF spindle Chuck: MicroCentric 4-410-3-QC Max. Ø80 Chip conveyor: Liqui gravity filter type UR1020 with clean container 180L Year of manufacture: 2013 Hours: 59861h Hardinge GT27SP CNC lathe: Control: Fanuc 32i Axes: 2 (X and Z) Travel paths: From the operating manual measured on the tool top plate Z: 286mm / X: 607mm Spindle speed max.: 6000rpm Dimensions of the machine L x W x H: 1850 x 1750 x 1750 Weight: approx. 2100Kg MARPOSS measuring system with automated dimension compensation Oil mist filter S400 on the machine Spindle cooling possible, currently out of service due to MircoCentric chuck FMB Unirobot MH5LS-SP Robot: Yaskawa Motoman MH005LS Control: DXM100 with handheld programming device Jaws: 3 jaws double gripper system with integrated presser Axes: 6 Serial number robot: RH9G49-3303-1 Serial number robot control: S21K60-2-4-O Year of manufacture: 08/2012 Dimensions of the robot cell L x W x H: 1900 x 950 x 2000 Weight of the robot cell: No exact details approx. 1000kg With blow-off unit Turning station in the robot cell 5x workpiece pallets 400x600mm, side 1: 77 parts / Page 2: 150 parts Liqui gravity filter type UR1020 with clean container Filter type: belt filter Serial number: 33145 Year of manufacture: 2013 Dimensions LxWxH: 1500 x 800 x 1100 Weight: approx. 250Kg Grinding spindle: Itodpevntk Tofx Afien Jäger SF spindle Type: Z80-M530.05 K1,2CK Max. speed: 30,000 rpm Supply voltage: 3-phase 200V-480V AC 50/60hz Frequency converter installed in the control cabinet, operated via external control interface External cooling unit KKG15 1.5kW Grinding spindle holder Grinding wheel holder RINECK Accessories / tools: 2x MAS-MEX20-GT27-1-S385H holder 2x MAS-MEX20 turn sleeve 2x MAS-turn ring 2x hydraulic expansion for internal extractor 1x holder for rotary holder + rotary holder 1x MARPOSS probe with holder

Condition: used, Year of construction: 2005, SPACESACER SS2101 rod feeder Itodowcgdnjpfx Afijn year 2005 used - efficient

Condition: new, functionality: fully functional, turning diameter over cross slide: 654 mm, turning length: 1,514 mm, turning diameter: 418 mm, travel distance X-axis: 290 mm, travel distance Z-axis: 1,600 mm, spindle motor power: 18,500 W, rapid traverse X-axis: 18 m/min, rapid traverse Z-axis: 18 m/min, rotational speed (max.): 2,500 rpm, total height: 2,072 mm, total length: 5,575 mm, total width: 2,072 mm, overall weight: 9,000 kg, bar passage: 77 mm, spindle nose: ASA A2-8, LATHE FOCUS MOD. FBL 300 LMC WITH INCLINED BED TECHNICAL SPECIFICATIONS: CNC: FANUC 0i-TF Plus + Manual Guide I, 10.4'' color graphic display, remote handwheel Maximum turning length: 1,514 mm Distance between centers: 1,708 mm Maximum swing over bed: 654 mm Maximum turning diameter: 418 mm Bar capacity: 77 mm Spindle mount: ASA A2-8 Maximum spindle speed: 2,500 rpm Spindle motor: 15 – 18.5 kW X-axis travel: 290 mm Z-axis travel: 1,600 mm Rapid traverse X-Z: 18 m/min Tailstock travel: 1,510 mm Quill travel: 130 mm Quill diameter: 90 mm Quill taper: MT 5 Overall dimensions: 5,575 x 1,980 x 2,072 mm Weight: 9,000 kg COMPLETE WITH THE FOLLOWING STANDARD ACCESSORIES: - Hydraulic chuck Ø10'' Kitagawa, set of soft and hard jaws - Hydraulic chuck foot pedal - Serial, Ethernet, and USB ports - Belt-type chip conveyor with chip collection trolley - Rotating tailstock - Three-color alarm and cycle end warning lamp - Integrated work light - Levelling feet - Tool box with service keys - Programmable tailstock - Mobile coolant tank - Centralized lubrication system - Oil skimmer - Hydraulic spindle pedal - Set of tools and service keys - SAUTER turret, 12 positions - Tool holder BMT 65 - Driven tool motor 3.7/5.5 kW - Max driven tool speed: 4,000 rpm - No. 9 tool holders (4+4+1) - Power transformer - Operating and maintenance manuals, electrical diagrams, CNC manuals - CE Declaration INCLUDED ACCESSORIES: - Cooling system with Grundfos pump, 9.5 bar - Automatic tool presetting (Renishaw) - Hydraulic steady rest base with carriage-mounted positioning Itsdpfx Afew A Rnkeisn - Tailstock with carriage coupling via M function - Air blast through the spindle - No. 1 straight driven tool holder for BMT 65 - No. 1 angled driven tool holder for BMT 65 BRAND NEW MACHINE, CE COMPLIANT

Condition: excellent (used), Year of construction: 2008, DMG CTX 510 Iodpfx Aor Ak S Njfietn Sinumerik 840D Machine in perfect condition, equipped with bar feeder and C axis Spindle operating hours: 6720 Spindle bore: 95 mm Collet chuck Forkardt D=100 mm max; I also have a brand new Hainbuch SK100 collet chuck for this machine Tool holder VDI 40

Condition: as good as new (ex-display), Year of construction: 2018, operating hours: 200 h, functionality: fully functional, machine/vehicle number: 1421160-BV40058101, turning length: 300 mm, turning diameter: 240 mm, spindle bore: 61 mm, spindle speed (max.): 3,500 rpm, travel distance X-axis: 190 mm, travel distance Z-axis: 400 mm, spindle motor power: 11 W, rapid traverse X-axis: 18 m/min, rapid traverse Z-axis: 24 m/min, total height: 1,880 mm, total length: 2,860 mm, total width: 1,700 mm, overall weight: 3,400 kg, bar passage: 42 mm, CNC Lathe Takamaz XL-150M – showroom demonstration machine, with almost zero operating hours, has never machined any material. The machine is in excellent condition, year 2018, essentially as new. Equipped with Fanuc CNC, live tooling, and numerous accessories. Main data: Year of manufacture: 2018 Serial number: 1421160-BV40058101 CNC: FANUC Series Oi – TD Max swing diameter: 280 mm Max turning diameter: 240 mm Max turning length: 300 mm Bar capacity: 42 mm Spindle bore: 61 mm Spindle: 3-jaw chuck SMW AUTOBLOK Ø 210 mm ASA A2-8 spindle nose Spindle nose height: 1050 mm Bearing internal diameter: 100 mm Spindle speed: up to 3500 rpm Axes: X-axis travel: 190 mm Z-axis travel: 400 mm Rapid traverse rates: X 18 m/min – Z 24 m/min Turret and tools: 12-position turret Internal/external tool holder 25x25 mm Boring bar holder Ø 32 mm Indexing: 0.1 sec Live tools up to 4000 rpm Motors and power: Spindle motor: AC 11/7.5 kW X-axis servomotor: 1.2 kW Z-axis servomotor: 1.8 kW Max absorbed power: 24 kW Isdpevw Ahysfx Afijtn Dimensions and weight: Footprint including chip conveyor: 2860 x 1700 x 1880 mm Net weight: 3400 kg Standard accessories: Right-side belt-type chip conveyor No. 1 axial driven tool holder No. 1 radial driven tool holder No. 6 static tool holders (2 boring bar holders + 4 tool holders) Included documentation: Lathe instruction manual Programming manual EC Declaration of Conformity Condition like new – machine available immediately.

Condition: new, Discover the ultimate power and precision of our vertical lathe series. With its robust construction and proven technology, it delivers groundbreaking results for your machining projects. Experience the limitless possibilities of our CNC variant and take your production to the next level. TECHNICAL MAIN DATA (CNC MODEL): - Max. swing diameter: 1500/1800/2750/4000/5000 mm - Max. turning diameter: 1250/1600/2500/4000/5000 mm - Max. workpiece height: 1000/1600/2000/2000/2000 mm - Spindle motor power: 30/37/55/75 kW - Table diameter: 1000/1250/2250/3600/3600/4500 mm - Max. table speed: 500/400/120/63/63/50 rpm Itedpfxod I I Ilo Afien ACCESSORIES: Fanuc or Siemens control, ZF gearbox, chip conveyor, lubrication system, hydraulic system, machine guard, air gun, tricolor lamp, work light, chip cart, foot pedal, standard tool holder. SPECIAL ACCESSORIES: C-axis, tool magazine, linear scale, tool presetter, workpiece probe, electrical cabinet air conditioner, special tool holder, and more. For further details, please refer to the attached PDF file. TECHNICAL MAIN DATA (CONVENTIONAL MACHINE): - Faceplate diameter: 1000|1400|1800|2000|2300 mm - Swing diameter: 1200|1600|2000|2300|2600 mm - Turning height: 1000|1250|1400|1600|1500 mm - Table speed: 6.3-200|5-160|3.2-100|5-160|2.5-80 m/min - Gear stages: 16 - Max. workpiece weight: 3.2|5|8|8|8 t - Main motor power: 22|30|37|37 kW - Approx. machine weight: 9|14|18|23|21 t ACCESSORIES: Tool holder: 5-fold; Faceplate: with 4 jaw clamps; Servo motors: for axis adjustment, and more. For further details, please refer to the attached PDF file. Conventional vertical lathe with solid and proven technology, power, and precision for the machining of heavy workpieces. - Optimal loading - easily accessible with crane and forklift - Vertical support with 5-fold tool holder and side support (optional) with separate feed for internal and external machining - Heavy-duty column construction with wide, hardened guides - Hydraulic clamping of the crossbeam - Stable guide construction provides excellent stability and accuracy to the vertical arm - The spindle runs in a highly precise double-row roller bearing and is adjustable - The drive is through a reduction gear for high torque and a speed range of 2.5 - 80 min- Warranty: 12 months on the machine Now get a 15% energy subsidy from BAFA when replacing an old machine! Also benefit from the favorable leasing and hire purchase conditions of our leasing partners. Ask us about it. Of course, you also receive free delivery, assembly/commissioning, and ready-to-use handover as well as control training from us. The special net price displayed refers to the smallest model of the conventional series. The images show the CNC variants as well as a conventional version.

Condition: excellent (used), Year of construction: 2017, operating hours: 34,536 h, functionality: fully functional, Control: Fanuc 32i A Automation: FMB FANUC UNIROBOT Grinding spindle: Jäger HF spindle Chuck: MicroCentric 4-410-3-QC Max. Ø80 Chip conveyor: Knoll filter system KF110/500 Year of manufacture: 2013 / Commissioning 2017 (exhibition machine) Hours: 34536h Hardinge GT27SP CNC lathe: Control: Fanuc 32i A Axes: 2 (X and Z) Travel paths: From the operating manual measured on the tool top plate Z: 286mm / X: 607mm Spindle speed max.: 6000rpm Dimensions of the machine with robot cell LxWxH: 4600 x 1600 x 2700 without status light Weight: approx. 2100Kg MARPOSS measuring system with automated dimension compensation Oil mist filter S400 on extendable stand 1525 - 2740mm Spindle cooling possible, currently out of service due to MircoCentric chuck FMB Unirobot LR Mate Robot: FANUC LR MATE 200iD7L-P2TB Control: FANUC R30iB Max. part diameter feed: Ø70mm Jaws: 3 jaws Double gripper system for gripping in the bore with blow-off unit Axes: 6 Serial number robot: E-83200 Serial number robot control: E15X36204 Year of manufacture: 10/2015 Dimensions of the robot cell: Robot cell sits on the machine (see photos) Weight of the robot cell: No exact details approx. 1000kg Turning station in the robot cell Conveyor belt raw/finished part converted to 2900mm length each Knoll filter system KF110/500 with Knoll hinged belt conveyor type 320 S-1/50 Filter type: belt filter Serial number: 581402 Year of manufacture: 2014 Tank volume: 500L Pressure: 5-30Bar Dimensions LxWxH: 1750 x 750 x 1550 Weight: No information, estimated at approx. 500-700Kg. Grinding spindle: Jäger SF spindle Type: Z80-M530.08 Max. speed: 30,000 rpm Control panel installed in the machine Frequency converter installed in the control cabinet Grinding spindle holder RINECK grinding wheel holder Accessories / tools: 2x MAS-MEX20-GT27-1-S385H holder 2x MAS-MEX20 turn sleeve 2x MAS-turn ring 2x hydraulic expansion for internal extractor Ijdpfx Afevntxkjijtn 1x holder for rotary holder + rotary holder 1x MARPOSS probe with holder

Condition: as good as new (ex-display), Year of construction: 2024, operating hours: 10 h, functionality: fully functional, machine/vehicle number: 8046723D038, spindle motor power: 11,000 W, turning diameter over cross slide: 380 mm, spindle speed (max.): 3,000 rpm, overall weight: 2,000 kg, type of input current: three-phase, total width: 1,800 mm, total length: 2,500 mm, total height: 1,800 mm, torque: 373 Nm, Equipment: documentation/manual, CNC LATHE STYLE 350 [850 dbc] - main spindle motor power 11kW - main spindle bore Ø54 mm, 3,000 rpm - manual universal with 3 jaws D200mm - VDI30 turret with 8 positions - Coolant gun, including high-pressure pump - Work area lighting (LED) - Cooling system - Automatic lubrication - Ball screw protection - Full fairing with sliding doors - Speed potentiometer - Coolant control button - Handwheel Itjdpfevvwblox Afien - Remote support on machine – allows remote diagnostics

Condition: new, Year of construction: 2023, functionality: fully functional, type of input current: three-phase, overall weight: 1,030 kg, rotational speed (max.): 2,500 rpm, turning diameter over cross slide: 320 mm, bar passage: 56 mm, spindle motor power: 3,700 W, mount diameter: 16 mm, spindle bore: 56 mm, spindle speed (max.): 2,500 rpm, spindle speed (min.): 150 rpm, turning length: 750 mm, Equipment: rotational speed infinitely variable, Technical Specifications Center Distance 750 mm Center Height 160 mm Swing Diameter Over Bed 320 mm Swing Diameter Over Cross Slide 150 mm Bed Width 215 mm Spindle Bore 56 mm Spindle Mount A2-5 Speed Range, Continuously Variable 150 - 2500 rpm Travel X-Axis / Z-Axis 160 mm / 750 mm Rapid Traverse X-Axis / Z-Axis 4 / 7 m/min Number of Tool Positions 6 pcs. Iodpfx Aewh Aiwsfietn Tool Shank Dimensions 16 x 16 mm Positioning Accuracy ± 0.01 mm Quill Diameter 45 mm Quill Travel 100 mm Quill Mount MT 4 Motor Power 3.7 kW Machine dimensions (W x D x H) 1910 x 1150 x 1840 mm Weight approx. 1030 kg

Condition: excellent (used), Year of construction: 2021, operating hours: 14,841 h, functionality: fully functional, Control: Fanuc 32i Automation: FMB UNIROBOT GP7-5Pkhs Grinding spindle: Jäger HF spindle Chuck: MicroCentric 4-410-3-QC Max. Ø80 Itjdjvnt Dtspfx Afion Chip conveyor: Knoll compact filter with hinged belt conveyor Year of manufacture: 2021 Hours: 14841h Hardinge GT27SP CNC lathe: Control: Fanuc 32i Axes: 2 (X and Z) Travel paths: From operating manual measured on tool top plate Z: 286mm / X: 607mm Spindle speed max.: 6000rpm Dimensions of the machine LxWxH: 1850 x 1750 x 1750 Weight: approx. 2100Kg MARPOSS measuring system with automated Dimension compensation Oil mist filter S400 on extendable stand 1525 - 2740mm Spindle cooling possible, currently out of service due to MircoCentric chuck FMB UNIROBOT GP7 Robot: YASKAWA GP7 Control: YASKAWA YRC1000 Jaws: 3 jaws double gripper system with integrated presser and blow-off unit Axes: 6 Machine No.: 11-210314 R 1889290 Year of manufacture: 2021 Dimensions of the robot cell LxWxH: 1850 x 900 x 2000 Weight of the robot cell: No exact details approx. 1000kg Turning station in the robot cell 5x workpiece pallets 400x600mm, side 1: 77 parts / side 2: 150 parts Knoll filter system KF110/570 with Knoll hinged belt conveyor type 320 S-1/50 Filter type: belt filter Serial number: 1513866 Year of manufacture: 2021 Tank volume: 570L Pressure: 5-30Bar Dimensions of the filter system LxWxH: 1800 x 900 x 1900 Weight: No information, estimated at approx. 500-700Kg. Grinding spindle: Jäger SF spindle Type: Z100-M536.03 K1,2S5GS Max. speed: 36,000 rpm Supply voltage: 3-phase 200V-480V AC 50/60hz Frequency converter installed in the control cabinet, operation via external control interface Grinding spindle holder RINECK grinding wheel holder Accessories / tools: 3x MAS-MEX20-GT27-1-S385H holder 3x MAS-MEX20 turn sleeve 3x MAS-turn ring 2x hydraulic expansion for internal extractor 1x hydraulic expansion for rotary holder + rotary holder 1x MARPOSS probe with holder
