Used Cnc Multi Spindle for sale (21,355)

Condition: good (used), Year of construction: 2004, machine/vehicle number: 2420701, CNC multi-spindle automatic lathe, make Index, type MS52C2-1, year 2004, serial no. 160024, - robot cell, - 7 clamping devices, - 3 rigid tool holders simple, - 3 rigid tool holder multiple, - 4 powered tool holders, - Suction Büchel Handlings and assembly robot cell Stäubli Unimation incl. basket translator with basket stack for raw and finished parts, two shuttles on top of each other for supply/removal baskets, Integrated measuring station Commissioning 2021 Connected load 24 kW, control, make Index, type C200-4D (Siemens 840 D basis), - 2 steering positions, - 6 spindles, - travel X/Y 300 x 500 mm, - bar diameter max. 52 mm, - Gbsdpfxslmkuce Ah Eew - spindle speed max. 5000 rpm, -12 tool carriers, coolant system, - Industrial robot, make Stäubli, - programming panel, - extraction device, - settling device, - Accesories

Condition: good (used), Year of construction: 2018, machine/vehicle number: 18043108351805, functionality: fully functional, operating hours: 1,500 h, power: 3 kW (4.08 HP), input voltage: 380 V, input current: 35 A, input frequency: 50 Hz, type of input current: three-phase, travel distance X-axis: 2,000 mm, travel distance Y-axis: 2,300 mm, travel distance Z-axis: 700 mm, workpiece length (max.): 2,500 mm, workpiece width (max.): 1,300 mm, workpiece height (max.): 700 mm, number of axes: 3, number of slots in tool magazine: 1, total height: 2,250 mm, total length: 3,600 mm, total width: 2,650 mm, overall weight: 1,750 kg, table length: 2,500 mm, table width: 1,300 mm, year of last overhaul: 2018, Equipment: CE marking, documentation/manual, The machine was purchased in 2018 and has not been used for the past three years, since 2023. It has primarily been used for wood processing. The machine was intended to produce high-quality picture frames for some of the most renowned international art, including modern art, as well as historically accurate frames for Dutch Renaissance paintings, for public institutions such as the National Gallery of Denmark and the Nivågård Collection. Gbsdpfxo Aip Sne Ah Eew

Year of construction: 1977, condition: ready for operation (used), Two Schütte six-spindle turning machines including one Iemca bar feeder are available. 1) Schütte SF 42, year of manufacture: 1977, number of spindles: 6, max. bar capacity: 42mm, max. longitudinal slide stroke: 125mm, speed: 2240rpm, machine dimensions X/Y/Z: approx. 6500mm/1400mm/2200mm, weight: approx. 10000kg. Including pick-off spindle, cams, collets, chip conveyor, oil mist extraction system and Iemca PRA40/33/P bar feeder. 2) Schütte SF 51 DNT, year of manufacture: 1987, max. bar capacity: 51mm, number of spindles: 6, max. turning length: 102mm, max. drilling depth: 102mm, spindle circle diameter: 340mm. Including pick-off spindle, CNC cross slide in position 4, cams, collets, auxiliary coolant pump and chip conveyor. Documentation available. An on-site inspection is possible. Gjdszbuuwepfx Ah Eobw

Condition: ready for operation (used), Year of construction: 2014, machine/vehicle number: AA2/002546, functionality: fully functional, travel distance X-axis: 7,033 mm, travel distance Y-axis: 1,940 mm, travel distance Z-axis: 475 mm, spindle speed (max.): 24,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Number of milling spindles: 1 Number of controlled axes: 5 Spindle speed: max. 8,000 rpm Main motor power: 11 kW C-axis: Available Tool holder: HSK-F63 Table design: Cantilever table Table length: 5,200 mm Table width: 1,300 mm Working area X-axis: 6,350 mm Working area Y-axis: 1,300 mm Working area Z-axis: 200 mm Travel range X-axis: max. 7,033 mm Travel range Y-axis: max. 1,940 mm Travel range Z-axis: max. 475 mm Drilling tool: Available Motor power: 3 kW Horizontal drilling spindles: 6 Vertical drilling spindles: 10 Gbodpfx As Aidx Hsh Eow Tool changer positions: 24 MACHINE DETAILS Vacuum pump: Becker VTLF 250 Year of manufacture: 2008 Main motor power: 5.5 kW Capacity: 300 m³/h Connection diameter: 70 mm Oil-free: Yes Voltage: 400 V Current consumption: 64 A Dimensions & Weight Dimensions (L x W x H): 10,300 x 2,450 x 2,800 mm Installed length: 11,000 mm Installed width: 3,900 mm Installed height: 3,000 mm Transport weight: 6,600 kg Transport packages: 1 EQUIPMENT Tools CE marking

Year of construction: 1992, condition: ready for operation (used), Number of spindles: 6, max. bar capacity: 42mm, max. machining diameter: 42mm, speed: 5000rpm, machining slides: 4, number of slides front/rear: 4/2. Machine dimensions X/Y/Z: approx. 7200mm/1700mm/2300mm, weight: approx. 10000kg. The machine has an electrical problem as a result of which the control does not start up. Documentation available. On site inspection is possible. Gbedpfex Tum Sjx Ah Eew

Condition: ready for operation (used), Year of construction: 1980, functionality: fully functional, No minimum price – guaranteed sale to the highest bidder! Loading: December 1st to December 10th. TECHNICAL DETAILS General Data Manufacturer: Haulick + Roos Type: RVD 63-800 HS/CNC Year of manufacture: 1980 Machine number: 1,202,097 Machine type: Punching press Press Data Press force: 630 kN Gbjdpe Adzicjfx Ah Eew Speed range: 30–800 rpm Drive power: 26 kW Stroke: 4–60 mm Stroke adjustment: 80 mm Die hole: 52 mm Table Table dimensions: approx. 800 × 600 mm Table slots: 4 MACHINE DETAILS Dimensions and Weight Length: 2,500 mm Width: 2,000 mm Height: 2,400 mm Weight: 6,000 kg EQUIPMENT Integrated guiding system by Haulick + Roos

Condition: used, Year of construction: 2009, Used Machine Year of manufacture: 2009 Condition: Overhauled by a Hirzt specialist Description: The machine’s design is very simple. The workpiece is loaded into the machine. A quickly adjustable stop with pneumatic locking centers the workpiece in the machine. After a foot switch is activated, the workpiece is pneumatically clamped and automatically fed to the drilling unit (30 m/min). The vertical spindles drill from below, so that the resulting chips do not remain on the workpiece, as they would in a machining center. The horizontal spindles operate on two sides of the workpiece. The workpiece can be of any length, as it is guided to the drilling unit (= X-axis). The drilling spindles can be freely programmed individually or in groups and move along the Y-axis. The drilling depth and the horizontal drills are controlled by the Z-axis. After all holes have been drilled, the workpiece is conveyed back to the infeed side or, if desired, to the outfeed side. While in conventional machining centers the workpiece is clamped using a vacuum and the vacuum clamps must be adjusted to the workpiece size, this step is completely eliminated with the 3-axis-controlled point-to-point drilling machine. Advantages: - High machining speed - Good value for money - Compact footprint All drilling operations can be performed in a very small space: - Row drilling - Structural holes - Hardware holes - Cabinet joint holes Features: - Welded machine frame - Drilling head with 7 vertical drilling spindles and 1 horizontal double drilling spindle - 3-axis control: - X: NC-controlled plate feed via “overlapping” pneumatic clamping jaws - Y: NC-controlled drill head movement - Z: NC-controlled drilling spindle depth adjustment - TRK precision guides - Pneumatic split pressure beam above the drilling unit - Pneumatic roller hold-down devices in the feed area - Pneumatic clamping jaws for transport - Pneumatically lockable side stop with rollers - Control via Windows XP-based PC (1 GB flash memory) - 8?? color screen - Alphanumeric multifunction keyboard including mouse - Network card Gbsdpfx Ahjzwg Tio Eow - USB interface Technical Specifications: - Number of controlled axes: 3 - Maximum panel width: 1,000 mm - Maximum drilling width: 800 mm - Maximum feed rate (X-axis): 30 m/min - Drill speed: 3,400 rpm - Maximum drill bit diameter: 35 mm - Maximum total drill bit length: 70 mm - Drill bit chuck: 10 mm shank with clamping surface - Power rating: 2.5 kW - Exhaust port diameter: 100 mm - Required pressure: 6 bar - Working height: 900 mm - Fold-out roller support on the feed side, 500 x 750 mm Dimensions: 1,650 x 1,920 mm Availability: available shortly Location: North Rhine-Westphalia

Condition: used, TORNOS MULTIDECO 20/6b is a CNC Multi-spindle turning lathe engineered for high-precision machining with excellent accuracy and reliability. Key capacities: 17 axes total, 6 cross slides, 5 plain turning slides, longitudinal carriage way 160 mm, 6 spindles + 1 back spindle, round bar capacity Ø 5–20 mm, max workpiece length 100 mm, production rate 45 pcs/min. Technical specs: stepless spindle speeds up to 5000 rpm, spindle power 15 kW, total installed power 43 kVA, supply 3x 400 V 50 Hz, machine weight ≈8500 kg, dimensions L3500×W1600×H1950 mm. Equipment: ROBOBAR bar feeder type MSF 522/6, coolant system, chip conveyor, pick-up spindle, spindle stop device, lamp and status light. Delivers tight tolerances; suitable for automotive, watchmaking, toolmaking, aerospace and medical industries. Godpjyxny Ajfx Ah Eebw

Condition: good (used), Year of construction: 2004, functionality: fully functional, Manufacturer INDEX-Werke Model series MS52C with IEMCA bar loader Machine type CNC multi-spindle turning machine with bar loading system Capacity class 52 mm bar diameter Working spindles Gbodpfxe Aiimte Ah Ejw 6 independently driven spindles Control system Siemens SINUMERIK on INDEX C200 control panel; verify the exact software version on site NC system Two NCU units are documented in the provided report Year of manufacture 2004 according to the provided machine report Feature Specification Working spindles 6; six positions are documented in the machine's process display Maximum bar diameter 52 mm as a typical reference value for the model series Maximum spindle speed 5,000 min⁻¹ as a typical reference value for the model series Tool holder Up to 12, depending on the model series; the actual configuration must be verified on site Driven machining Two driven machining units according to the provided configuration information Rear machining Two back drilling stations documented, one of which is driven Axis concept Multiple NC-controlled X and Z axes; diagnostic and correction displays are documented Tool monitoring ARTIS tool and process monitoring system is available Machining system Feature Specification Working spindles 6; six positions are documented in the machine's process display Maximum bar diameter 52 mm as a typical reference value for the model series Maximum spindle speed 5,000 min⁻¹ as a typical reference value for the model series Tool holder Up to 12, depending on the model series; the actual configuration must be verified on site Driven machining Two driven machining units according to the provided configuration information Rear machining Two back drilling stations documented, one of which is driven Axis concept Multiple NC-controlled X and Z axes; diagnostic and correction displays are documented Tool monitoring ARTIS tool and process monitoring system is available The interior shots show a complete multi-spindle machining arrangement with several independent slides and tool stations. The actual scope of supply of tool holders, clamping devices and special tools must be definitively documented during the inspection. Feature Bar loading system Chip removal Part handling Process monitoring Fire extinguishing system Specification IEMCA bundle and bar loader; confirm type, length range and diameter range on site KNOLL chip conveyor High-pressure pump up to 80 bar according to the provided equipment list Visible part or discharge guide; verify the exact function during production ARTIS tool breakage and process monitoring system; integrated Kraft and Bauer CO₂ extinguishing system

Condition: used, Year of construction: 2004, Tornos MultiDeco 20/8 Number of spindles: 8 Maximum bar diameter: 20 mm Spindle speed: 5000 rpm Main spindle power: 15 kW / 18.5 kW Maximum part length: 100 mm without backworking; 75 - 80 mm with backworking Number of backworking spindles: 1 Backworking spindle axial travel: 160 mm Backworking spindle motor power: 1.1 kW CNC control unit: Fanuc Programming system: TB-DECO software platform IEMCA integrated automatic bar feeder High-pressure coolant pump and fine filtration system Automatic chip conveyor The machine is in working condition and can be inspected upon request. Gbodpfx Ahszy Spuj Eow

Condition: used, functionality: unexamined, travel distance X-axis: 2,400 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 130 mm, total length: 3,070 mm, table length: 2,800 mm, table width: 1,340 mm, total width: 1,800 mm, spindle speed (max.): 30,000 rpm, total height: 1,420 mm, overall weight: 500 kg, spindle motor power: 2,200 W, controller manufacturer: CNC-STEP (KinetiC-NC), number of axes: 3, Equipment: documentation/manual, We are selling our CNC portal milling machine, CNC-STEP High-Z T-Rex S-1224, with extensive equipment. The machine was purchased new in 2019 (total investment approximately €39,900 net) and is suitable for milling and engraving aluminum, plastic, and wood. Condition: The machine is generally functional. However, after being transported to its current location, it has not been fully reassembled and connected, so its functionality cannot currently be tested. An inspection is possible, but a test run under power is not. Technical data: - Travel distances: X 2,400 mm / Y 1,200 mm / Z 130 mm - Clamping area: 2,800 x 1,340 mm - Drive: 3 brushless stepper motors, ball screw spindles on all axes - Linear guides HIWIN/THK on all axes - Rapid traverse max. approx. 12,000 mm/min, working speed max. approx. 8,000 mm/min - Repeatability approx. 0.01 mm - Overall dimensions approx. 3,070 x 1,800 x 1,420 mm, weight approx. 500 kg Equipment: - High-frequency spindle Mechatron ATC-8022-30: 2.2 kW, 30,000 rpm, HSK25/ER16, pneumatic, with control cabinet and frequency inverter Gedpfxj Af Ifzs Ah Ejbw - 5 tool holders HSK-E-25-ER16, collet set ER16 - Tool length sensor - Vacuum table covering the entire area (MDF), 2 side channel blowers each 4 kW (high voltage) - Minimum quantity lubrication - T-slot table - KinetiC-NC control system with wireless remote control, emergency stop - Control laptop (ASUS) included - CAM software VCarve Pro - Operating manuals and wiring diagrams Without automatic tool changer. Notes: - Inspection possible by arrangement (not under power) - Disassembly and transport by the buyer, we will assist with the forklift during loading - Sale excludes any warranty - Invoice with VAT shown

Condition: used, TECHNICAL DETAILS - Number of axes : 23 - Max. bar diameter : 20 [mm] - Spindle speeds : 3500 [rpm] - Spindle power : 15 / 18.5 [kW] COUNTER-SPINDLE - Counter-spindle position : 8 - Max. bar diameter : 20 [mm] - Travel : 160 [mm] - Max. part length : 75 [mm] - SLIDES - Number of transversal slides : 3 * Position : 1 / 8 / 9 * Stroke x, position 1 : 50 [mm] * Stroke X, position 8/9 : 65 [mm] Gsdpfxswuu R He Ah Ejbw - Number of crossed slides : 6 * Position : 2 / 3 / 4 / 5 / 6 / 7 * Stroke X x Z1 : 50 x 80 [mm] - Number of longitudinal slides : 1 * Position : 8 * Stroke Z2 : 160 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 80 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 9600 x 2500 [mm] - Machine height : 2200 [mm] EQUIPMENT - CNC : FANUC PNC DECO - Counter-spindle with brake - Retractable stop Spindle stop - Chips conveyor - Coolant tank * with high-pressure pump * with paper filtering unit - Cooling unit - Bar loader : IEMCA PRA 52F / 33

Condition: ready for operation (used), Industrial CNC router for sale – AXYZ Automation Group Automation Series 6010, fitted with a high-speed Perske GmbH spindle. This is a large-format production machine suitable for woodworking, plastics, signage, and light aluminium work. Solid gantry construction with vacuum bed – ideal for sheet materials. Gedpjy A R Dxefx Ah Ejbw ⚙️ Key Specs Model: AXYZ 6010 (6000 Series) Bed Size: approx. 10ft x 6ft (3048 x 2150mm) Spindle: Perske high-speed spindle Power: approx. 4kW / 5.5HP Speed: up to 18,000 – 21,000 RPM Bed: Vacuum table (grid type) Axes: 3-axis gantry CNC Power: 3-phase Build: Heavy-duty industrial frame

Condition: used, TECHNICAL DETAILS - Number of axes : 19 - Number of spindles : 6 - Number of counter-spindles : 1 SPINDLES - Max. bar diameter : 32 [mm] - Spindle speeds : 6000 [rpm] - Spindle power : 13.6 [kW] COUNTER-SPINDLE - Spindle speeds : 8000 [rpm] POWER SUPPLY - Supply voltage : 380 [V] WEIGHT & DIMENSIONS - Machine floor space : 10100x1800 [mm] - Machine height : 2600 [mm] - Machine weight : 12000 [kg] MACHINE HOURS - Number of hours under power : 81250 [h] - Number of working hours : 31982 [h] EQUIPMENT - CNC : Fanuc 30I Godpfxowuu Rtj Ah Ejbw - Parts catcher - Parts conveying strip - Chips conveyor - Coolant tank * with high-pressure pump * with paper filtering unit - Cooling unit - Bar loader : Tornos MSF-832/6

Condition: used, TECHNICAL DETAILS - Number of axes : 18 - Number of spindles : 6 - Max. bar diameter : 32 [mm] - Spindle speeds : 400-5000 [rpm] COUNTER-SPINDLE WEIGHT & DIMENSIONS - Machine floor space : 8300 x 2300 [mm] - Machine height : 2240 [mm] Gsdjwuu Rmspfx Ah Ejbw - Machine weight : 11500 [kg] EQUIPMENT - CNC : Fanuc PNC Deco - Chips conveyor : Mayfran - Coolant tank * with high-pressure pump - Bar loader : TORNOS MSF 832/6

Condition: used, TECHNICAL DETAILS - Number of axes : 23 - Max. bar diameter : 20 [mm] - Spindle speeds : 3500 [rpm] - Spindle power : 15 / 18.5 [kW] COUNTER-SPINDLE - Counter-spindle position : 8 - Max. bar diameter : 20 [mm] - Travel : 160 [mm] - Max. part length : 75 [mm] - SLIDES - Number of transversal slides : 3 * Position : 1 / 8 / 9 * Stroke x, position 1 : 50 [mm] * Stroke X, position 8/9 : 65 [mm] - Number of crossed slides : 6 * Position : 2 / 3 / 4 / 5 / 6 / 7 * Stroke X x Z1 : 50 x 80 [mm] - Number of longitudinal slides : 1 * Position : 8 * Stroke Z2 : 160 [mm] Gedpfowuu Rysx Ah Eebw POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 80 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 9600 x 2500 [mm] - Machine height : 2200 [mm] EQUIPMENT - CNC : FANUC PNC DECO - Counter-spindle with brake - Retractable stop Spindle stop - Chips conveyor - Coolant tank * with high-pressure pump * with paper filtering unit - Bar loader : IEMCA PRA 52F / 33

Condition: used, Year of construction: 2007, Mazak Integrex E500H-II Multi-tasking CNC Lathe (2007), Maximum Cutting Diameter 820mm, Maximum Cutting Length 1500mm, C axis 0.0001 degrees, B Axis -30/+210 degrees, 40 ATC, Spindle Speed 1,600rpm, Milling Speed 10,000rpm, Main Spindle 37Kw, Spindle Taper din50, Y axis -/+ 250mm, Mazatrol Matrix Control, Swarf Conveyor. S/No. 186364. Country of Origin: Japan Gbjdps Ah E Dbsfx Ah Ejw Location: This lot is located in Leicester, UK. A charge of £375 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser.

Condition: used, TECHNICAL DETAILS - Number of axes : 17 - Max. bar diameter : 25.4 [mm] - Spindle speeds : 5000 [rpm] - Spindle power : 18 [kW] WEIGHT & DIMENSIONS - Machine floor space : 3500 X 1600 [mm] - Machine height : 1950 [mm] - Machine weight : 8500 [kg] MACHINE HOURS - Number of hours under power : 33026 [h] Gedpfowuu Rgox Ah Ejbw EQUIPMENT - CNC : TORNOS TB DECO - Chips conveyor - Coolant tank : KNOLL * with high-pressure pump * with paper filtering unit - Cooling unit - Bar loader : TORNOS Robobar MSF 522

Condition: used, TECHNICAL DETAILS - number of spindles : 6 independent Gbodpfouhaxljx Ah Eow - bar clearance : 32 [mm] - maxi spindle speed : 6 300 [rpm] - machine equipped with 32 numerical axes - slide unity 1.1 : X and Z axes controlled by CNC - slide unity 1.2 : fixed X axis, Z axis controlled by CNC - slide unity 2.1 : fixed X axis, Z axis controlled by CNC - slide unity 2.2 : X and Z axes controlled by CNC - slide unity 3.1 : X and Z axes controlled by CNC - slide unity 3.2 : fixed X axis, Z axis controlled by CNC - slide unity 4.1 : X and Z axes controlled by CNC - slide unity 4.2 : fixed X axis, Z axis controlled by CNC - slide unity 5.1 : fixed X axis, Z axis controlled by CNC - slide unity 5.2 : X and Z axes controlled by CNC - slide unity 6.1 : X and Z axes controlled by CNC - slide unity 6.2 : X and Z axes controlled by CNC - counter-spindle position 6.1 EQUIPMENT - INDEX C200-4 control (Siemens SINUMERIK 840D) - Simple NCU - IEMCA SIR MS32/33/P bar loader - Coolant tank with HP pump - KNOLL chips conveyor - Parts catcher with conveyor in position 6 - Cross drilling device in position 3.1 et 4.1

Condition: good (used), Year of construction: 2006, Number of working spindles: 6 pieces Bar spindle diameter capacity: 32 mm Working spindle maximum speed: 6000 rpm Spindle chuck diameter: 40 mm Maximum number of tool carriers: 12 pieces Tool carrier travel distances: X = 72 mm, Z = 100 mm Godsrqzzpopfx Ah Ejbw Part catcher receiver available in 6.1 position KNOLL chip conveyor In-machine air intake filtration system available (ventilation) Weight: 7,200 kg Magazine: IEMCA 3300 mm capacity bar feeder

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, AC motors for spindle speed and feed Chip conveyor No. 2 polygon milling/thread milling devices No. 1 broaching unit No. 1 threading unit No. 1 pick-up with retraction slide No. 1 deburring unit No. 1 rack milling device No. 2 wedge recesses Gsdoxyghfepfx Ah Eebw No. 2 marking devices No. 1 carriage on 6th radial CNC axis (Siemens), with X and Z No. 2 sensors for length control of short, non-threaded or first of bar piece, with automatic discharge into bin at 4th and 8th station Giovanni Cucchi integrated bar feeder No. 1 bar elevator Tool holders

Condition: like new (used), Year of construction: 2020, operating hours: 5,600 h, functionality: fully functional, machine/vehicle number: 0-250-77-3262, 1. BASIC MACHINE - rigid steel frame construction - 2 workpiece clamping devices with integrated stop system - Separate adjustment of the clamping devices via rack and pinion gear in X-direction - Digital AC servomotors - The position of the clamping devices at the workpiece is program-controlled - Adjustment of the clamping devices between the separate processing steps in the processing area is possible. - Automatic measuring of the workpiece thickness and lengths by the clamps and the stop system - Blowing nozzle for safe removal of residual parts off the clamps 1.1 LOWER PROCESSING SUPPORT - Rigid aluminium cast construction - Integrated threefold divided table with selectable air cushion - Lateral stop system - Adjustment of the axes in Y- and Z-direction - Ball bearing spindle (Z-direction) and rack and pinion gear (Y-direction) - Digital AC servomotors - Suitable for fitting of various Gedpfoz Df Txex Ah Eebw configurations 1.2 UPPER PROCESSING SUPPORT - Rigid aluminium cast construction - Integrated threefold divided pressure beam with selectable air cushion - Adjustment of the axes in Y- and Z-direction - Ball bearing spindle (Z-direction) and rack and pinion gear (Y-direction) - Digital AC servomotors - Suitable for fitting of various configurations 1.3 WORKPIECE DIMENSIONS workpiece length: min. 200 mm workpiece length: max. 2500 mm workpiece width: min. 70 mm workpiece width: max. 1000 mm - with restrictions in processing: 1300 mm workpiece thickness: min. 8 mm (2 x 4 mm) workpiece thickness: max. 80 mm (2 x 40mm) workpiece stacking: max. 2 pieces - same workpiece dimensions Note: - Workpieces must have a straight edge at the reference edge - Max. curve tolerance: +/- 0.5 mm for a work- piece length = 2000 mm - The workpiece length/width ratio should be >=1. The longer edge of the workpiece should be placed on the machine. - Warped workpieces (>= 0.3 mm) lead to a higher rate of processing tolerances and wear at the workpiece tables - Due to the chips no stackable workpieces can be guaranteed for router processings. - An external cleaning or extraction in the outfeed area is recommended. - For through holes of double parts the drilling quality depends on the workpiece material and the tool as well as on the feeding speed profile and the rotation speed of the drilling spindle. Thus, however, efficiency could possibly be reduced. 1.4 WORKPIECE FEEDING AREA - Air cushion table in rigid frame construction - Surface from Hornit board - integrated fan 1.5 WORKPIECE REMOVAL AREA - Cross belt conveyor in rigid frame construction - 8 transport belts, frequency-controlled drive - 8 electro-pneumatic controlled disengaging device 2. CE SAFETY AND PROTECTION DEVICES - Safety fences in the lateral and rear area - Safety mats in the feeding area 3. ENVIRONMENTAL CONDITIONS - prescribed environmental temperature: + 5 degrees up to + 40° C (in case of environmental temperature >35°C or air humidity >65% a cooling unit for switch cabinet is recommended) 4. ENERGY SAVING MODE - ecoPlus button for starting stand-by operation. The button can be activated during processing. This will have the following impacts after the end of the program: - Primary power of drives will be switched

Condition: used, TECHNICAL DETAILS - Number of axes : 23 - Number of spindles : 8 - Number of counter-spindles : 1 - Max. part length : 100 [mm] SPINDLES - Max. bar diameter : 22 [mm] - Spindle speeds : 8000 [rpm] - Spindle power : 11.2 [kW] COUNTER-SPINDLE - Y stroke : 280 [mm] - Z stroke : 450 [mm] NUMERICAL AXES - 1 cross slide, position 1: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 2: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 3: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 4: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 5: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 6: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 7: x=50 [mm], Z1=80 [mm] - 1 cutting carriage 8: x=65 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 80 [kVA] Gsdpfx Aszhph Djh Ejbw WEIGHT & DIMENSIONS - Machine floor space : 5.300 x 2.200 [mm] - Machine height : 2.600 [mm] - Machine weight : 12.000 [kg] MACHINE HOURS - Number of hours under power : 75000 [h] EQUIPMENT - CNC : Fanuc 30i-TB - Hirth teeth - 1 counter-spindle in position 7 - Counter-spindle with counter-operation device - 2 x 4 counter-operation tools - 8 spindles with independent spindle speeds - C-axis on all 8 spindles and the counter-spindle : 0.001 [°] - Chips conveyor : MAYFRAN - Coolant tank * with high-pressure pump : 35 + 80 [bars] - Bar loader : ROBOBAR MSF-522/8 - Oil mist extractor

Condition: used, TECHNICAL DETAILS - Number of axes : 23 - Number of spindles : 8 - Number of counter-spindles : 1 - Max. part length : 100 [mm] SPINDLES - Max. bar diameter : 22 [mm] - Spindle speeds : 8000 [rpm] - Spindle power : 11.2 [kW] COUNTER-SPINDLE - Y stroke : 280 [mm] - Z stroke : 450 [mm] NUMERICAL AXES - 1 cross slide, position 1: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 2: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 3: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 4: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 5: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 6: x=50 [mm], Z1=80 [mm] - 1 cross slide, position 7: x=50 [mm], Z1=80 [mm] - 1 cutting carriage 8: x=65 [mm] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 80 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 5.300 x 2.200 [mm] - Machine height : 2.600 [mm] - Machine weight : 12.000 [kg] MACHINE HOURS - Number of hours under power : 73500 [h] EQUIPMENT - CNC : Fanuc 30i-TB Gbsdpozhphwjfx Ah Ejw - Hirth teeth - 1 counter-spindle in position 7 - Counter-spindle with counter-operation device - 2 x 4 counter-operation tools - 8 spindles with independent spindle speeds - C-axis on all 8 spindles and the counter-spindle : 0.001 [°] - Chips conveyor : MAYFRAN - Coolant tank * with high-pressure pump : 35 + 80 [bars] - Bar loader : ROBOBAR MSF-522/8 - Oil mist extractor

Condition: used, TECHNICAL DETAILS - Number of spindles : 6 - Number of counter-spindles : 1 SPINDLES - Max. bar diameter : 22 [mm] - Spindle speeds : 10000 [rpm] - Spindle power : 8.5/15 [kW] NUMERICAL AXES - Slide unit 1.1 : X and Z axes controlled by NC - Slide unit 1.2 : Z controlled by NC - Slide unit 2.1 : Z controlled by NC - Slide unit 2.2 : X and Z axes controlled by NC - Slide unit 3.1 : X and Z axes controlled by NC - Slide unit 3.2 : X and Z axes controlled by NC - Slide unit 4.1 : X and Z axes controlled by NC - Slide unit 4.2 : X and Z axes controlled by NC - Slide unit 5.1 : X and Z axes controlled by NC - Slide unit 5.2 : X and Z axes controlled by NC - Slide unit 6.1 : Z axis controlled by NC - Slide unit 6.2 : X and Z axes controlled by NC POWER SUPPLY - Supply voltage : 380 [V] - Total installed power : 77 [kW] WEIGHT & DIMENSIONS - Machine floor space : 3329 x 2032 [mm] - Machine height : 2654 [mm] - Machine weight : 7100 [kg] MACHINE HOURS - Number of hours under power : 36508 [h] - Number of working hours : 26721 [h] - Number of spindle hours : 20860 [h] EQUIPMENT - CNC : Siemens 840D SL - Cutting force monitoring: ARTIS Gjdsyzi Umopfx Ah Eebw - Chips conveyor - Coolant tank * with high-pressure pump : 80 [bars] - Bar loader : IEMCA SIR mS22P/33 - Fire extinguisher * * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. - Electric transformer
