Used Bar Machining Center for sale (75,655)

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, travel distance X-axis: 730 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, workpiece weight (max.): 300 kg, spindle speed (max.): 12,000 rpm, The machine spindle was recently replaced. The corresponding report can be provided upon request. TECHNICAL DETAILS Travel X-axis: 730 mm Travel Y-axis: 510 mm Travel Z-axis: 510 mm Rapid traverse X-axis: 50 m/min Rapid traverse Y-axis: 50 m/min Rapid traverse Z-axis: 40 m/min Table width: 500 mm Table height: 870 mm Table length: 500 mm Table load capacity: 300 kg Rotary table diameter: 500 mm Rotational speed (max.): 1,200 rpm Spindle speed (max.): 12,000 rpm Spindle interface: HSK-A63 Workpiece height (max.): 450 mm Workpiece weight (max.): 300 kg Tool length: 300 mm Tool diameter: 125 mm Tool weight: 8,000 g Number of tool magazine slots: 180 MACHINE DETAILS Control unit: Siemens 840 D Total weight: 14,800 kg Incoming voltage: 400 V EQUIPMENT Mori Seiki tool application manual Godpjx Exvzofx Agboil KNOLL FKA/500 band filter system + 3 filter rolls Filtermist FX5000 emulsion extraction unit Renishaw OMP60 3D probe Chip conveyor Spindle chiller Documentation + circuit diagrams

Condition: ready for operation (used), Year of construction: 2012, operating hours: 45,656 h, functionality: fully functional, machine/vehicle number: AX4E -NAOS 12-160, travel distance X-axis: 730 mm, travel distance Y-axis: 730 mm, travel distance Z-axis: 880 mm, table load: 500 kg, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel X-axis: 730 mm Travel Y-axis: 730 mm Travel Z-axis: 880 mm Max. spindle speed: 12,000 rpm Spindle drive power: 15 / 11 kW Max. torque: 102 Nm Tool holder: SK 40 Distance spindle center to table: 80 - 800 mm Distance spindle nose to table center: 70 - 950 mm Number of pallets: 2 Gijdsx I Amijpfx Agbol Pallet size: 500 x 500 mm Max. workpiece weight: 500 kg Max. workpiece diameter: 800 mm Max. workpiece height: 1,100 mm Pallet change time: 9.5 s Indexing time: 1.49 s Number of tool stations: 60 Max. tool diameter: 70 mm Max. tool diameter with adjacent stations free: 170 mm Max. tool length: 550 mm Tool-to-tool change time: 0.9 s Rapid traverse: 60 m/min Max. feed rate: 60,000 mm/min Creep feed range: 0 - 5,000 mm/min MACHINE DETAILS Total power requirement: 34 kVA Dimensions & Weight Footprint: approx. 5500 x 3000 x 2800 mm Machine weight: approx. 11.1 t Operating hours: 45,656 h EQUIPMENT Chip conveyor Coolant system Internal coolant supply IF Knoll Tool changer B-axis Pallet changer Oil mist separator Magazine tool breakage control Thread milling Note: Proof of spindle replacement in 2019 is attached.

Condition: ready for operation (used), Year of construction: 2008, operating hours: 23,838 h, functionality: fully functional, travel distance X-axis: 1,270 mm, travel distance Y-axis: 508 mm, travel distance Z-axis: 635 mm, rotational speed (max.): 7,500 rpm, Submitting a bid obligates you to collect the item on time by 30.01.2026! TECHNICAL DETAILS Travel X-axis: 1,270 mm Travel Y-axis: 508 mm Travel Z-axis: 635 mm Spindle speed: 7,500 rpm Table size: 1,320 mm x 455 mm T-slots: 14 mm MACHINE DETAILS Operating hours: 23,838 h Tool changes: 300,000 EQUIPMENT SK 40 taper with 40-position automatic tool changer Note: The two vices are not included in the scope of sale and delivery. Gisdpox Nvv Hefx Agbol

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 1,350 mm, travel distance Y-axis: 675 mm, travel distance Z-axis: 635 mm, rotational speed (max.): 7,500 rpm, number of slots in tool magazine: 24, TECHNICAL DETAILS X axis: 1,350 mm Y axis: 675 mm Z axis: 635 mm Distance spindle nose – table: 745 mm Control: Siemens Sinumerik Work Table Length: 1,450 mm Width: 685 mm T-slot size: 18 mm Number of T-slots: 5 T-slot spacing: 100 mm Table load capacity: max. 1,500 kg Spindle Spindle speed: 30 – 7,500 rpm Gearbox: 2-step Spindle taper: NT-40 Motors Spindle motor (30 min duty cycle): 12 / 16 kW X-axis drive motor: 4.7 kW Y-axis drive motor: 4.7 kW Z-axis drive motor: 4.7 kW Tool Changer Magazine capacity: 24 stations Taper: SK 40 Max. tool diameter: 90 mm Max. tool length: 300 mm Max. tool diameter (without adjacent tool): 110 mm Max. tool length (without adjacent tool): 350 mm Gjdpfxex Iuics Agbjil Max. tool weight: 6 kg Tool selection: shortest path Feed Rapid traverse (X/Y/Z): 18 m/min Feed range (X/Y/Z): 1–10,000 mm/min MACHINE DETAILS Machine dimensions: Length 3,324 mm / Width 2,746 mm / Height 2,840 mm Machine weight: 7.5 t Required floor space: 4,500 mm × 3,500 mm EQUIPMENT ICS / internal coolant supply Paper band filtration system with high-pressure pump

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, machine/vehicle number: 0-250-05-2654, travel distance X-axis: 3,950 mm, travel distance Y-axis: 1,943 mm, travel distance Z-axis: 400 mm, controller model: HOMATIC-2000 IPC, No reserve price – guaranteed sale to the highest bidder! The machine is equipped with a C-axis! TECHNICAL DETAILS Travel distances X-axis: 3,950 mm Y-axis: 1,943 mm Z-axis: 400 mm Vertical drilling unit X-direction Drill spindles: 16 Z-stroke: 60 mm Drilling depth: max. 38 mm Rotational direction: clockwise/counterclockwise Speed: 1,500 - 5,900 rpm Drive: 1.5 kW Drill chuck: d= 10 mm Total drill length: 70 mm Drill diameter: max. 20 mm (15 spindles), 1 spindle up to 25 mm, max. 35 mm (1 reinforced spindle) Spindle spacing: 32 mm (15 spindles) Spindle type: individually controllable Extraction: central Vertical drilling unit Y-direction Drill spindles: 15 Z-stroke: 60 mm Drive: 1.5 kW Rotational direction: clockwise/counterclockwise Speed: 1,500 - 5,900 rpm Drill chuck: d= 10 mm Drilling depth: max. 38 mm Total drill length: 70 mm Drill diameter: max. 20 mm, 1 spindle up to 25 mm Spindle spacing: 32 mm (15 spindles) Spindle type: individually controllable Arrangement: Y-direction Horizontal drilling unit X-direction Drill spindles: 4 Drilling depth: max. 38 mm Drilling height Z-direction: 38 mm Rotational direction: counterclockwise Speed: 4,800 rpm Drill chuck: d= 10 mm Total drill length: 70 mm Drill diameter: max. 20 mm Spindles: individually controllable Horizontal drilling unit Y-direction Drill spindles: 2 Drilling depth: max. 38 mm Drilling height Z-direction: 38 mm Rotational direction: clockwise Speed: 4,800 rpm Drill chuck: d= 10 mm Total drill length: 70 mm Drill diameter: max. 20 mm Spindle type: individually controllable Router motor Drive power: 7.5/10 kW (S1/S6 duty cycle) Speed range (stepless): 750 - 18,000 rpm Cooling: liquid recirculation cooling Bearings: hybrid bearings (ceramic) Extraction: central Tool changer magazine Magazine positions: 30 tool positions Tool weight: max. 5 kg Tool change time: approx. 8 - 10 seconds MACHINE DETAILS Control: HOMATIC-2000 IPC Giedpsx Sqm Ssfx Agbol Liquid recirculation cooling: 18,000 l/min Power: 7.5 / 10 kW S1/S6 operation EQUIPMENT Integrated CNC axis (360° rotational) Torque support Main spindle (motor power 7.5 / 10 kW, HSK F63) Workpiece support system 1,500 mm Workpiece console K-table 1,500 mm Gantry extension Y-direction 120 mm Compressed air connection strip with quick couplers Extraction hood for additional router motor Router 5 kW with Hydro quick-release clamping system Left-side safety guard with door Safety tread mat 3,250 mm Control cabinet left Note: For further details regarding the machine’s equipment, please refer to the attached documents.

Condition: ready for operation (used), Year of construction: 2006, operating hours: 17,716 h, functionality: fully functional, machine/vehicle number: 0144, travel distance X-axis: 1,200 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 675 mm, controller model: Heidenhain iTNC 530, TECHNICAL DETAILS X-axis travel: 1,200 mm Y-axis travel: 600 mm Z-axis travel: 675 mm Work spindle speed: 30 - 8,000 rpm Tool holder: ISO B 40 Table size: 1,220 x 620 mm T-slots: 18 T-slots: 5 x 18 mm T-slot spacing: 100 mm Table load capacity: 1,700 kg Control system: Heidenhain iTNC 530 Feed rate X / Y / Z: 3,000 mm/min Rapid traverse X,Y / Z: 24 / 20 m/min MACHINE DETAILS Voltage: 3 x 400 V AC + PE, 50/60 Hz Godpfxjx Trpqe Agbeil Control voltage: 24 V DC Connected load: 16 kW Weight: 8,000 kg Operating hours Control on: 44,842 h Machine on: 36,513 h Program run: 15,882 h Drives on: 31,655 h Spindle on: 17,716 h

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 762 mm, travel distance Y-axis: 460 mm, travel distance Z-axis: 460 mm, controller model: OSP-P200M, rotational speed (max.): 15,000 rpm, TECHNICAL DETAILS Travel X-axis: 762 mm Travel Y-axis: 460 mm Travel Z-axis: 460 mm Spindle speed range: 50 - 15,000 rpm Rapid traverse X-axis: 40 m/min Rapid traverse Y-axis: 40 m/min Rapid traverse Z-axis: 32 m/min Tool magazine: 32 positions MACHINE DETAILS Control: OSP-P200M Main drive motor: 22 kW Dimensions & Weight Required space (L x W x H): 2,850 x 2,810 x 2,750 mm Machine weight: 7,200 kg EQUIPMENT Chip conveyor Internal coolant supply Gsdpjx I Ecyjfx Agbjil Standard filtration unit

Condition: ready for operation (used), Year of construction: 2021, operating hours: 2,200 h, functionality: fully functional, travel distance X-axis: 1,016 mm, travel distance Y-axis: 635 mm, travel distance Z-axis: 635 mm, spindle speed (max.): 8,000 rpm, table diameter: 635 mm, TECHNICAL DETAILS Travel X-axis: 1,016 mm Travel Y-axis: 635 mm Travel Z-axis: 635 mm B-axis: 120-35 ° C-axis: 360 ° Spindle: SK 40 Speed: 8,100 rpm Table diameter: 635 mm Tool changer: 30 stations Gijdpfsx I Ag Ajx Agbel MACHINE DETAILS Number of axes: 5 Operating hours Power-on time: 4,300 h Cycle time: 2,200 h EQUIPMENT Control panel with touchscreen Network interface Wi-Fi connection 1 GB part program memory Power failure detection module Control cabinet with air conditioning unit Wireless measuring system Coolant unit Programmable coolant nozzle Prepared for retrofitting internal coolant supply Hinged belt chip conveyor

Condition: ready for operation (used), Year of construction: 2006, operating hours: 19,857 h, functionality: fully functional, travel distance X-axis: 4,400 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 180 mm, number of slots in tool magazine: 72, TECHNICAL DETAILS Gisdpfxsx Sri Ij Agbol X-axis travel: 4,400 mm Y-axis travel: 1,300 mm Z-axis travel: 180 mm Milling unit power: 15 HP Tool change: automatic Number of tool positions: 3 x 24 slots EQUIPMENT Worktable with traverse Auxiliary unit for heavy parts Pneumatic clamps for door and window production Vacuum pump 250 m3/h Automatic lubrication Waste conveyor

Condition: ready for operation (used), Year of construction: 2004, operating hours: 55,476 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller model: HEIDENHAIN Mill Plus IT, spindle speed (max.): 12,000 rpm, New motor spindle in 2012 TECHNICAL DETAILS X-axis travel: 800 mm Y-axis travel: 700 mm Z-axis travel: 600 mm Motor spindle speed: 12,000 rpm Tool holder: HSK-A 63 Tool magazine positions: 120 MACHINE DETAILS Control: HEIDENHAIN Mill Plus IT Spindle hours: 55,476 h EQUIPMENT Universal milling head with controlled B-axis 2 pallets 800 mm x 630 mm Pallet changer Rotating viewing window Operating mode 4 Tool breakage control Gedpfsx Sqr Isx Agbeil

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, machine/vehicle number: AH/121500, travel distance X-axis: 2,486 mm, travel distance Y-axis: 1,255 mm, travel distance Z-axis: 150 mm, table width: 1,290 mm, table length: 2,570 mm, TECHNICAL DETAILS Travel X-axis: 2,486 mm Travel Y-axis: 1,255 mm Travel Z-axis: 150 mm Maximum stroke X-axis: 3,120 mm Maximum stroke Y-axis: 1,685 mm Maximum stroke Z-axis: 250 mm Table length: 2,570 mm Table width: 1,290 mm Tool changer positions: 8 pieces MACHINE DETAILS Dimensions (L x W x H): 3,870 x 1,900 x 2,300 mm Net weight: 2,500 kg Transport packages: 1 unit Godpex Tppnsfx Agboil EQUIPMENT CE marking

Condition: used, Year of construction: 2006, Working area X-Y-Z: 5300 x 1700 x 180 mm Travel length X-Y-Z: 6040 x 1810 x 280 mm Drilling head with 30 + 8 spindles Speed: 6000 rpm Power: 2.2 kW Automatic central lubrication Worktable TV with 10 supports L=1500 4 working zones 2 cross lasers Vacuum pump 250 m³/h PC control Windows Vertical milling unit ISO 30 7.5 kW with tool changer RAPID 14 and vector axis Additional drilling unit (E-axis) Dongle for XILOG software Giodpfxjx Twd Ho Agbsl Location: Nattheim

Condition: good (used), Year of construction: 1996, Control: OSP 700M Travel X/Y/Z: 1050 x 560 x 450 mm Table size: 1300 x 560 mm Spindle speed: 6,000 rpm Tool magazine for 20 tools, BT 50 Godpfx Agsx Tvgasboil Chip conveyor Approx. 40 toolholders BT 50

Condition: used, Year of construction: 2012, x-travel 762 mm y-travel 508 mm z-travel 508 mm Control Haas CNC Max. rpm 12.000 min/-1 power capacity - main spindel 22,4 kW max. Torque 102 Nm tool taper ISO 40 table surface area 914 x 457 mm T-slots 16 mm max. table load 1362 kg number of toolpositions 24 pos. tool taper SK 40 max. tool diameter 76 (152) mm max. tool weight 5,4 kg change-time tool to tool 2,8 sec change-time chip to chip 3,6 sec rapid traverse ( X / Y / Z ) 18,0 m/min Gisdpfx Aexddrpogbsl Number of working hours 14375 h spindle drive 22,4 kW transport dimension 2,25 x 2,4 x H = 2,5 mm weight of the machine ca. 3,42 t dimensions of the machine ca. 3,2 x 2,5 x 2,8 m Well-maintained 5-axis machining center, 3-axis machine + 2-axis dividing head. Machine with low operating hours (14,375). Lehmann dividing head, model ix-Y3, weight 80 kg. Machine dealer with own stock of 1600 m².

Condition: good (used), Year of construction: 2016, In good technical condition and fully functional. Built in 2016. Machine includes 4-axis TSUDAKOMA, workpiece probe, and tool probe. Drives Axis drives (X/Y/Z) 1,000 / 550 / 500 mm Distance table surface - spindle surface 130 - 630 mm Axis guide - linear rolling LM Table work surface 1,100 x 502 mm Giedsx Tti Sjpfx Agbol Load capacity 700 kg Table surface configuration mm 5x T-slot (width 18, pitch 80) Maximum spindle speed 12,000 rpm Spindle power (10 min./continuous) kW 18.5 / 11 Rapid feeds (X/Y/Z) m/min 36 / 36 / 30 Working feed (X/Y/Z) mm/min 1 - 24,000 Sliding motor (X/Z) kW 1.8 / 1.8 / 3.0 Automatic tool change Tool taper - BT40 Clamping bolt - MAS P40T-1 (45°) Number of tool positions: 24 Max. tool diameter mm Ø 80 / Ø 150 (without secondary tool) Max. tool length / weight mm / kg 300 / 8 Tool-to-tool change time: Section 2.5 Chip-to-chip change time: Section 4.3 Magazine and change disk design with rotating arm Power consumption: 30 kVA Tank capacity for spindle lubrication/cooling: l 6 / 20 For cooling emulsions: l 380 Machine dimensions: Height mm 2,670 Floor area (length x width) mm 3,335 x 2,200 Weight: 6,500 kg Control system: Fanuc 0i-MD Air blowing of the spindle Machine adjustment elements Machine protective cover Screw conveyor in the work area Cooling system Safety door Ethernet interface

Condition: ready for operation (used), Year of construction: 2010, operating hours: 47,512 h, functionality: fully functional, travel distance X-axis: 2,230 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 850 mm, table load: 6,000 kg, spindle speed (max.): 6,000 rpm, TECHNICAL DETAILS Travel X-axis: 2,230 mm Travel Y-axis: 1,400 mm Travel Z-axis: 850 mm Table size: 2,000 mm × 1,250 mm Table load capacity: 6,000 kg Spindle speed: 6,000 rpm Spindle drive / Power: 38 kW Tool holder: SK50 Rapid traverse: 12 m/min Number of tool stations: 40 MACHINE DETAILS Control: HEIDENHAIN iTNC 435 Dimensions & Weight Machine dimensions (L × W × H): 6,135 × 4,338 × 4,150 mm Weight: 22,000 kg Operating Hours Spindle hours: 47,512 h Program run time: 48,891 h Power-on hours: 72,846 h EQUIPMENT Coolant system Chip conveyor Internal cooling Gjdpfxsx Sqrhj Agbjil Electronic handwheel control Automatic tool measurement Workpiece measuring probe Chip flushing

Condition: good (used), Year of construction: 2004, operating hours: 156,897 h, functionality: fully functional, machine/vehicle number: 6006285, travel distance X-axis: 1,000 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 500 mm, controller manufacturer: Heidenhain TNC 426/430, workpiece weight (max.): 7 kg, table width: 800 mm, table length: 1,250 mm, table load: 1,200 kg, rotational speed (max.): 18,000 rpm, overall weight: 12,000 kg, For sale is a vertical CNC machining center, DMG DMC 100 V. The machining center is in good condition. Vertical CNC Machining Center DMG DMC 100 V Technical Data Travel & Work Area X-axis: 1,000 mm Y-axis: 800 mm Z-axis: 500 – 600 mm Table Table size: 1,250 x 800 mm Max. table load: 1,200 kg T-slots: e.g. 14 mm Spindle & Performance Max. spindle speed: 18,000 rpm Alternative speeds: 8,000 – 15,000 rpm Spindle taper: SK 40 or HSK-A 63 Spindle power: 15 kW Operating Hours: Control on: 156,896 hrs Gedex Tqr Repfx Agbjil Machine on: 103,327 hrs Program run: 48,388 hrs Spindle runtime: 46,398 hrs Tool changer: 1,431 hrs Tool Magazine & Change Number of tool stations: 30 pcs. Max. tool weight: 7 – 12 kg Coolant supply: Internal coolant Control & Weight CNC control: Heidenhain TNC 426/430 Machine weight: approx. 12,000 kg

Condition: used, Year of construction: 2007, Working area: 2780 x 1140 mm (vertical milling) 2500 x 950 mm (horizontal drilling) X-Y travel: 2980 x 1271 mm Z-axis travel: 200 mm Passage height: 180 mm The structure of the base body is a monolithic construction made of thick-walled steel. It is stiffened by welded triangular plates across the entire machine bed, making it extremely stable. The triangular shape used for load-bearing parts, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user optimal workflow despite minimal space requirements. The base body constructed in this way therefore offers the machining unit a balanced and secure base with particularly good load distribution. The mobile unit carrier is made of a solid monoblock. It is positioned in the X direction on prismatically ground guides via recirculating ball slides. On this mobile unit carrier, the working unit is mounted on prismatic, ground guides and the recirculating ball slide. Description of the units and accessories (basic) Drilling unit: Drilling head with 10 + 4 spindles · 6 individually accessible vertical spindles in X · 4 individually accessible vertical spindles in Y · 2 horizontal spindles in X (1 + 1) · 2 horizontal spindles in Y (1 + 1) · Speed: 4,000 rpm · Power: 2.2 kW · Grid: 32 mm · Drill chuck: M 10 with 11 mm fitting · Extraction nozzle: D = 160 mm Vertical milling unit (position 2) · Tool chuck HSK 63F · Speed 1,500 - 24,000 rpm continuously adjustable via inverter · Motor power 4.4 kW (6 HP) from 12,000 rpm (S1) · Right-hand / left-hand rotation · Ceramic bearings · Scope of delivery: 4 tool chucks (right) without collet chuck · Tool changer · Side-mounted tool magazine 7-way (TR7) with full encapsulation to prevent chipping · 7 tool positions for HSK 63F tool holder arranged in a row · maximum tool diameter D=120 mm · maximum weight per holder 4.5 kg · maximum tool weight of all tools 20 kg (TR7) · angular gears can be accommodated Horizontal milling unit (position 1) Horizontal unit with two opposite outputs for milling and grooving. · Speed 9,000 - 18,000 rpm continuously variable via inverter · 1 output for collet 3-20 mm (ER 32) · 1 output for saw/collet 3-12 mm (ER20) (For saw D = 120 mm / bore 50 mm) · Motor power 3 kW (4 HP) · Max. tool diameter front milling: 20 mm · Max. tool length front milling: 110 mm · Max. tool diameter rear milling: 12 mm · Max. tool length rear milling: 80 mm · Max. saw blade diameter: 100 mm · Bore saw blade (ER 32): 50 mm · Mandrel diameter saw blade (ER 20): 12 mm Work table The work table is designed to guarantee the operator maximum freedom of movement. The vacuum quick clamping system ensures maximum flexibility with precise positioning and optimal grip of the workpieces. · 4 supports 900 mm continuously adjustable in X · 8 vacuum suction cups round D = 110 mm continuously adjustable in Y (2 per support) · 2 stops in X (1 x left / 1 x right) · 1 stop in Y per support (total 6) · The retractable reference stops are controlled via CNC. · Scope of delivery: 4 plug-on adapters for suction cups · Pendulum machining standard (2 working areas) Axis movement The drive system in X, Y and Z is carried out via ground ball screws of the highest precision class. The ball drive screw of the X-axis is located exactly in the center Gijdpfx Aox Twdysgbel

Condition: excellent (used), Year of construction: 2000, Control unit: Heidenhain TNC 426 Clamping area: 345x295 mm X=240 mm Y=240 mm Z=240 mm Speed range: 300-48,000 rpm Gsdpex Tqgzjfx Agbeil

Condition: excellent (used), Year of construction: 2002, Used CNC machining center Manufacturer: Weeke Model: Optimat BHC 750 Swiss Profiline Year of manufacture: 2002 4-axis machine with console table, 8 manually adjustable supports in X direction, 3 vacuum cups per console, vacuum pump 100 m³/h vacuum connection for templates laser positioning aid for vacuum cups laser projection for cup positioning Working area X: 200 – 3250 mm Working area Y: 70 – 1220 mm Working area Z: 12 – 125 mm (clearance 150 mm) 22 vertical drilling spindles 6 horizontal drilling spindles, of which 4 are in X-direction and 2 in Y-direction. Milling spindle 12 kW up to 24,000 rpm with C-axis 360° interpolation, liquid circulation cooling – 18-fold tool changer at the rear Gisdpfjx Tpczex Agbol Control system Homatic 2000 IPC WoodWop 4.5 incl. MDE and production list software Operator terminal Delivery includes only the adapter units, tools, and HSK mounts shown in the pictures!

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, Double table machining center Working range X 2,590 mm Working range Y 2,260 mm Working range Z 400 mm Gsdpfouqw E Nox Agbjil Number of milling spindles 2 Liquid-cooled spindle Main motor 19.2 kW Max rotational speed 24,000 rpm Aggregate heads 4 C-axis Tool clamping system HSK-F63 Tool change positions central magazine 24 Tool change on each head from 12 positions Boring heads vert. 20 (for each head) Horizontal boring heads X 8 Horizontal boring heads Y 8 Blade for grooves in X, in Y 2 Platens Number 4 360 m³/h vacuum pumps T Jet system for chip blowing Nesting Manual labeling Bar code reader Tool length measurement Software BIESSE BIESSEWORKS ADVANCED, BIESSE B_NEST Weight 17,900 kg

Condition: used, Year of construction: 2009, x-travel 800 mm y-travel 800 mm z-travel 800 mm control SIN840D Gjdpfx Ajx Tiy Tjgbeil spindle turning speed - stepless 5 - 10.000 U/min power capacity at 40 % load 38,00 KW power capacity at 100 % load 25,00 kW max. torque at 40% / 100% load 288 / 187 kW spindle taper HSK 100 feed X/Y/Z/-axis 0 - 60.000 mm/min rapid traverse X/Y/Z 60,00 m/min feed capacity X/Y/Z 12,00 kN B - axis 180 x 0,001 ° rapid travel B-axis 10,00 U/min size of pallet 800 x 630 mm table load 0,80 t C-axis 360 x 0,001 ° rotary table speeds infinitely variable 1 - 800 U/min power capacity - table 13,85 kW max. torque on the faceplate 1.550 Nm toolpiece magazine: chain magazine 60 Stück tool diameter 110 mm wotkpiece diameter with 2 vacant positions 230 mm tool length - max. 450 mm weight of tools max. 30,00 kg total power requirement 80,00 kW weight of the machine ca. 18,00 t dimensions of the machine ca. 7,50 x 5,50 x H3,50 m 5-axis machining center with SIEMENS Sinumerik 840D control, belt filter system, coolant through the spindle, chip conveyor, exhauster.

Condition: used, Year of construction: 2011, · Working area: 2,550 x 1,067 mm · X-Y travel: 2,980 x 1,450 mm · Z-axis travel length: 150 mm · Clearance height: 120 mm Drilling Unit F14: · Drilling head with 8 + 6 spindles Giodpfx Agox Twc Njbjl · 5 individually selectable vertical spindles in X · 3 individually selectable vertical spindles in Y · 4 horizontal spindles in X (2+2) · 2 horizontal spindles in Y (1+1) · Speed: 4,000 rpm (6,000 rpm available as an option) · Power: 2.2 kW · Grid: 32 mm · Drill holder: M10 with 11 mm positive fit · Pneumatic feed stroke: 60 mm Grooving saw unit in "X": · Integrated in the drilling head · Grooving saw blade with a maximum diameter of 120 mm Main milling unit: · Tool interface HSK 63F · Speed: 1,500 – 24,000 rpm, infinitely variable via inverter · Motor power: 6.6 kW (9 HP) from 12,000 rpm (S1) · Motor power: 7.5 kW (10 HP) from 12,000 rpm (S6) · Right-/left-hand rotation · Ceramic bearings · Prepared for use with angle drives Tool changer TR10: Automatic lateral tool changer for 10 tools. · Number of tool positions: 10 · Maximum tool diameter: 120 mm · Maximum weight per tool: 4.5 kg · Maximum total tool weight: 28 kg A central extraction port collects all processing units into a single connection with D=200 mm. This reduces the required extraction capacity to approx. 3,200 m³/h. TVF worktable: The worktable is designed to provide the operator with maximum "freedom of movement." The vacuum quick-clamping system offers maximum flexibility for precise positioning and optimal holding of workpieces. · 4 TVF supports, L=1100 mm, infinitely adjustable in X · 12 TVF vacuum cups 120 x 120 mm, infinitely adjustable in Y · 2 stops in X (1 left / 1 right) · 1 stop in Y per support (total 4 pcs.) · Retractable reference stops controlled via CNC Automatic central lubrication: The correct amount of lubricating grease is distributed via an electronic CNC control unit (X, Y, Z axes) Vacuum system (base machine): · Vacuum pump: 90 m³/h · Power: 2.2 kW · Max. negative pressure (at pump): 0.9 bar PROGRAMMING SYSTEM XILOG PLUS Software features: - Import of DXF files - Import of ASCII files - User interface in operator’s native language Safety devices with bumpers Machine technical data: · Total connected load max.: 18 kW · Recommended fuse: 64 A · Power supply: 400 V 50-60 Hz · Compressed air: 6-7 bar · System pressure (recommended): 8 bar · Compressed air consumption: 200 Nl/min · Central extraction port Ø: 200 mm · Extraction speed: 30 m/sec · Air consumption (central extraction): 3,200 m³/h · Negative pressure: 3,000 Pascal · Weight: approx. 2,500 kg Remote control of machine functions 6 TVF supports L=1,100 mm and 18 vacuum cups 120x120 mm Cross lasers for vacuum cup positioning Two cross lasers mounted on the unit carrier allow for easy positioning of the vacuum cups. Location: Nattheim

Condition: used, Year of construction: 2023, Exhibition Machine Garbsen CNC-CONTROLLED MACHINING CENTER morbidelli m100 Drilling and Milling Made for You! This numerically controlled machining center is equipped with a comprehensive range of accessories and tools for milling and drilling, enabling it to meet every requirement in the field of wood processing. Highly efficient – with drilling spindles reaching up to 8,000 rpm – and featuring technology that includes the most robust spindle available on the market, offering more than 1,000 hours of maintenance-free operation. Fully equipped – the suction cups can be individually configured with the TV FLEX worktable to adapt the machine precisely to your requirements. Easy and intuitive programming thanks to the integrated Cad-Cam MAESTRO CNC software. User-friendly operation is ensured by the lowered machine frame, which provides unrestricted access to the worktable at all times. The control cabinet and vacuum pump are integrated into the machine base, and the PRO SPACE variant requires no additional structural safety measures. Robust Construction The supporting structure consists of an especially sturdy monolithic steel base, ribbed for stability and durability. The extra-wide bearing surface is purpose-designed to provide the machine with stability, ensuring constant precision in all working conditions. Anchoring to the floor is not required. The base forms a large, solid foundation for the moving gantry: the working unit is equipped with a balanced, stable, and resilient support, withstanding the highest stress, which ensures superior quality performance and greater accuracy. The moving gantry is a solid single piece anchored to the base, running on high-quality prismatic guides with ball bearing carriages. The working unit is mounted to this and moves along the Y and Z axes on prismatic guides with ball bearing carriages as well. Movement of the lower movable unit (X-axis) and the working unit along the gantry (Y-axis) is driven by a helical toothed rack and pinion system; this produces greater tooth-by-tooth thrust, achieving higher acceleration and increased speed on the X and Y axes. The specially designed helical gearing ensures reduced wear of mechanical components and quieter operation. The vertical Z-axis is driven by a recirculating ball screw, providing perfect balance under dynamic load and withstanding significant acceleration and deceleration. The main milling unit is directly coupled to the Z-axis carriage, enabling superior surface finish quality as vibrations are completely eliminated. Travel along the X-Y-Z axes is achieved with brushless motors powered by static inverters. These provide: - Reduced processing times due to improved acceleration Godpfx Agjx Twcioboil - Increased positioning accuracy due to high-resolution encoders - Elimination of setup tasks at machine startup thanks to absolute encoders - Elimination of general maintenance tasks, as the brushless system has no brushes Axis movement management and general operation of the working elements...

Condition: used, Year of construction: 2006, · Working area: 2,650 x 1,240 mm · Travel distance X-Y: 2,995 x 1,385 mm · Z-axis travel length: 200 mm · Clearance height: 180 mm The basic frame structure is a monolithic construction made of thick-walled steel. It is reinforced across the entire machine bed with welded triangular plates, making it extremely stable. The use of the triangle shape with a broad base for load-bearing parts is the secret to permanent precision and stability. The layout of the machine allows the operator an optimal workflow while requiring minimal floor space. The resulting frame provides a balanced and secure base for the machining unit with outstanding load distribution. The mobile aggregate carrier is constructed as a solid monoblock. It is positioned along the X-axis on prismatically ground guides via recirculating ball carriages. The machining unit, in turn, is mounted to the mobile carrier using prismatic, ground rails and recirculating ball carriages. Description of aggregates and accessories (basic configuration) Drilling unit: Drill head with 12 + 6 spindles · 7 individually selectable vertical spindles in X · 5 individually selectable vertical spindles in Y · 4 horizontal spindles in X (2+2) · 2 horizontal spindles in Y (1+1) · Speed: 4,000 rpm · Power: 2.2 kW · Grid: 32 mm · Drill mount: M10 with 11 mm fitting Grooving saw unit in X: · Integrated into the drill head · Grooving saw blade up to max. 120 mm diameter Main milling unit (position 2): · Tool holder HSK 63F · Speed: 1,500 – 24,000 rpm, infinitely variable via inverter · Motor power: 4.4 kW (6 HP) from 12,000 rpm (S1) · Motor power: 6.6 kW (9 HP) from 12,000 rpm (S6) · Right/left rotation · Ceramic bearings · Includes: 4 tool holders (right), without collets R8L Tool changer Automatic tool changing system for 8 tools. Moves along with the rear aggregate carrier for quick tool access. · Number of tool slots: 8 Gijdpsx Twccofx Agbjl · Max. tool diameter: 120 mm · Max. weight per tool: 4.5 kg · Max. total tool weight: 22 kg · Adapter for 1 angle gearbox · Travels in X direction Horizontal milling unit (position 1) Horizontal unit with two opposing outputs for milling and grooving. · Speed: 9,000 – 18,000 rpm, infinitely variable via inverter · 1 output for collet 3–20 mm (ER 32) · 1 output for saw/collet 3–12 mm (ER20) (for saw D=120 mm / 50 mm bore) · Motor power: 3 kW (4 HP) · Max. tool diameter front milling: 20 mm · Max. tool length front milling: 110 mm · Max. tool diameter rear milling: 12 mm · Max. tool length rear milling: 80 mm · Max. saw blade diameter: 100 mm · Saw blade bore (ER 32): 50 mm · Saw blade arbor diameter (ER 20): 12 mm Worktable The worktable is designed to provide the operator with maximum freedom of movement. The quick-action vacuum clamping system ensures maximum flexibility with precise positioning and optimal holding of the workpieces. · 6 supports, 1000 mm, steplessly adjustable pneumatically in X · 12 vacuum cups, round, D = 110 mm, steplessly adjustable in Y (2 pcs. per support) · 2 stops in X (1 left / 1 right) · 1 stop in Y per support (6 in total) · The retractable reference stops are CNC-controlled · Pendulum operation standard (2 working fields) --- other clamping systems optional --- Axis movement The drive system for X, Y, and Z axes uses ground recirculating ball screws of the highest precision class. The recirculating ball drive...
