Materia CL is a range of versatile, compact,
5-axis processing center designed to meet a
Bm03e7vyjb
wide variety of high-speed machining needs in
relation to the milling of advanced and compound
materials and special or stratified resins
for mould models, the machining of thermoformed
elements, unusually shaped three-dimensional
elements, and components for the
aeronautical sector, boats and the car industry.
Materia CL is a range of versatile, compact,
5-axis processing center designed to meet a
Bmpu2gc8dn
wide variety of high-speed machining needs in
relation to the milling of advanced and compound
materials and special or stratified resins
for mould models, the machining of thermoformed
elements, unusually shaped three-dimensional
elements, and components for the
aeronautical sector, boats and the car industry.
BIESSE Materia CL 4020 is a range of versatile, compact,
5-axis processing center designed to meet a
wide variety of high-speed machining needs in
relation to the milling of advanced and compound
materials and special or stratified resins
for mould models, the machining of thermoformed
elements, unusually shaped three-dimensional
elements, and components for the
aeronautical sector, boats and the car industry.
Bmptux2ilm
Machine No. 17
Control Heidenhain 530i TNC
Table Load 30,000 kgs
Portal clearance width 4140mm
Portal clearance height 2400mm
Vartical swing milling head C-axis +/- 275 degrees
Horizontal swing milling head A-axis + 95 / - 125 degrees
Longitudianal travel, X Axis 6000mm
Cross Travel. Y Axis 3000mm
Vertical Travel. Z Axis 1500mm
Feed Rate 20,000mm/min
Tool holding HSK
ATC 29 Station
Maximum tool lenght 300mm
Maximum tool diameter 80mm
Maximum tool weight 5 kg
Input 400/3/50hz / 40kW
Speeds 18,...
x-travel 500 mm
y-travel 350 mm
z-travel 610 mm
Bng0lzvclr
weight of the machine ca. 3.2 t
Serial No. 29125
Control Heidenhain TNC 430 CA
Reciprocating Table Size 4000mm x 1000mm
Table Load 10,000 Kgs
Longitudinal Travel X = 3713 mm
Cross Travel Y = 1214 mm
F9y9pel
Vertical Travel Z = 1005 mm
Longitudinal Travel & Vertical Rapid Feeds 15000mm/min
Spindle Taper 40 INT
Head Swivels 180 Degrees on 'A' Axis, 360 Degrees on 'B' Axis
Input 415/3/50AC 50KVA. Main motor 8kW
Max, Height Spindle Nose to Table 1090mm
Spindle Speeds 3000 - 15000 rpm
Feed Rate 6 - 5000 mm/min
Fitted with 30 Tool...
Serial No. 56,047
Control Heidenhain TNC 415
Table Size 3000mm x 1000mm
Table Load 10,000 kgs
Longitudinal Travel 2703mm
Ram In/Out Travel 1015mm
Vertical Travel 1501mm
Longitudinal Rapid Feed 1500mm/min
Vertical Rapid Feed 1500mm/min
Bm7zctkai2
Cross Rapid Feed 1500mm/min
Working Feeds 6 - 5000mm/min
Spindle Taper in Vertical Head 50 BT
Head Auto Indexing A / B axis
Input 415/3/50Hz 34kW
Fitted with 40 Station Automatic Tool Change, Coolant.
Equipment Hand Wheel
Length 7800mm
Width 4380mm...
Equipment Tool Presetter, Daikin Chiller, Swarf Conveyor, Signal Tower & Wash Gun
Oc29l
Equipment Tool Presetter, Daikin Chiller, Swarf Conveyor, Signal Tower & Wash Gun
Blnpu7q9li
Equipment Tool Presetter, Daikin Chiller, Swarf Conveyor, Signal Tower & Wash Gun
Vto3bspf
Serial No. 12402
Control Heidenhain TNC 355
Table Size 1600mm x 1400mm
Jcfbfrgt
Table Load 6300 Kgs
Power of Main Drive 33kW
Longitudinal Traverse Z Axis - 2500mm
Cross Traverse X Axis - 1985mm
Vertical Traverse Y Axis - 1620mm
Boring Spindle Traverse W Axis - 530mm
Table Rotates B Axis - 360 degrees
Speeds 6.3-1250 rpm variable
Spindle Diameter 110mm
Spindle Taper IOS 50
Input 415/3/50hz with transformer
Fitted with Spindle brake
Equipment 2 x outriggers, coolant
Length 8000mm
Width 4800mm
Heig...
Serial No. 168256
Control Mazatrol 640M 5X
Capacity 630mm diameter x 500mm height
Table size 600mm x 500mm
Table load 500kg
A Axis -120 / +30 degrees
B Axis 360 degrees / 0.0-01 indexing
X Axis Traverse 630mm
Y Axis Traverse 765mm
Z Axis Traverse 510mm
Speeds 12000 rpm Variable
Spindle taper ISO 40
Automatic tool changer Yes
Number of tools 80
Omt37
Tool length 360mm
Tool diameter 80mm or 125mm with adjoining pocket empty
Tool weight 8kg
Input 380/3/50hz
Fitted with Tool probe,
Equipment...
Vertical Machining Centre 5-axis
CNC Control Fanuc 31iMB Manual Guide
Max. workpiece 520 x 330 mm
X-axis stroke (saddle right/left movement) 620 mm
Y-axis stroke ( column back/forth movement) 520 mm
Z-axis stroke (spindle up/down movement) 460 mm
Ok3bd
A-axis (table tilt) travel amount/indexing 0,001° -40/110°
C-axis (table rotation) travel amount/indexing 0,001° 360°
Max. table load 300 kg
Spindle taper Mas BT 40 Big Plus
Max. spindle speed 12.000 r/min
Table diameter 650 mm
Tool storag...
with robot, control Siemens Sinumerik 840 D, dressing wheel, 2 grinding spindles.
Working range diameter 8-16,5 mm (limited)
Clamping length with robot / hand 80-140 / 250 mm
Ysxj8g
Twist direction right/left/straight
Angle of twist 0-42
grinding wheel diameter 200 mm
max. grinding length 650 mm
max. grinding width 325 mm
grinding diameter min./max. 100/250 mm
table clamping area 1000 x 287 mm
Spindle speeds from 2000-6000 rpm
power 35 kW
Weight approx. 2.5 t
Accessories: machine bed extended, m...
Serial No. AOK 2132
Control Fanuc 15 iM
Workpiece Weight 4990kg
Table size 3048mm x 1220mm
Fitted with Tilting Table for easy loading and swarf removal.
X, Axis travel 3048mm
Y, Axis travel 1320mm
Z, Axis travel 712mm
A , Axis +/- 90 degrees
C, Axis +/- 270,- 360 degrees
2ie0wvao
Table top to Spindle end 762mm
Speeds 15,000 rpm
Rapid Traverse X, Y, Z Axis 19990 mm/min
Feed rate, X, Y, Z, Axis 1486 mm/min
Spindle taper 50 INT
Automatic tool changer Yes
Number of tools 40
Equipment Swarf Co...
Serial No. 120L729/723739.
Control Heidenhain iTNC 530
Table size 280mm
Table load 200kg
A Axis +/- 110 degrees
B Axis 360 degrees
X Axis Traverse 700mm
Y Axis Traverse 590mm
Z Axis lTraverse 480mm
Speeds 15000 rpm
Feed rate Rapid 32m/min
Automatic tool changer Yes, Big plus spindle system
Number of tools 32
Tool length 280mm
Bjhii7z08k
Tool diameter 88mm or 125mm with adjoining pocket empy
Tool weight 7 kg
Input 400/3/50hz 33kW
Equipment Swarf conveyor, coolant, Hand wheel, Oil cooler
Featu...
Ref. -No.: 10075
Brand: FERMAT
Type of control: CNC
Control: Heidenhain iTNC 530
Storage location: Mülheim an der Ruhr
Country of origin: Deutschland
Installation: 2014
Bhze3en
X-Travel: 9800 mm
Y-Travel: 3500 mm
Z-Travel: 600 mm
W-Axis: 730 mm
Spindle Diameter: 130 mm
Spindle Taper: SK 50
Rotary Table (Lxw): 2000 x 2400 mm
Table Load: 20000 kg
Support bearing: 250 mm
Main Drive: 37 kW
Numbers Of Pallets: 2
Size Of Pallet: 4000 x 1885 mm
Servo drive: 2 Pcs
pinion: 2 Pcs
Internal cooling: 30 b...
Leasing offer:
The price quoted refers to the monthly instalment and purchase through a leasing company.
Leasing object: CNC 5-axis HSC machining centre EXERON
Acquisition value: 159.000,00 Euro
Duration: 48 months
Leasing rate per month: 3.350,00 Euro
Payment frequency: monthly
Bfetanfmqk
Processing fee: one-time 80,00 Euro
Imputed residual value: 18.000,00 Euro
The prerequisite is a positive credit report.
----
CNC 5-axis HSC vertical machining center EXERON type HSC-MP 7/5 P
Linear milling ce...
5-axis overhead gantry machine with 3.6 x 1.5 x 0.9 meter work envelope.
Fagor controller 8055M, spindle 8 kw HSD F63 2000-20,000 rpm
12 position Auto tool changer
Bnhr00id0j
Renishaw tool length setter
slip ring for continuous C axis
CE certification mark
Used CNC High speed pendulum vertical machining center with 2 seperate work zones. On the left work zone 5 axis and right side a fixed table.
Unisign unipro 5P from 2002 but installed in 2004.
Machining details:
CNC Control: Siemens Sinumerik 840D
Spindle taper: HSK 63-A
Spindle speed: 12.000 1/min
Number of tools in magazine: 63
Spindle motor (40/100%): 38/26 kW
Work area left (5Axis)
Table: NC controlled table with B and C axis
Xysvs
Table size: 680x680mm
Table load: 750 kg
Maximum workpiec...
5-axis machining center : SCHAUBLIN
Model: 34.CNC
Year: 1991
Table: 350 x 350
Bmfwtxropt
Races: 700 x 500 x 500
32 tool changer
Siemens Sinumerik 3
The FFZ 30/60 CNC is a portal milling machine with a table width of 3000mm and an X-axis travel of +/- 6000mm
Technical specifications:
DIMENSIONS OF THE MACHINE
Length [mm] 13 200
Width [mm] 6 000
Height [mm] 9 800
PORTAL PASSAGE
Height [mm] x width [mm] 3 200 x 3 370
Distance between clamping surface and lower edge of the milling head min./max. mm] 0000 / 2500
WORKING SECTOR
X-axis travel of machine table [mm] +/-6000
Y-axis travel milling unit [mm] 4 100
Z-axis plunger [mm] 1 500
Cross...
Ref. -No.: 10078
Brand: HÜLLER HILLE
Type of control: CNC
Storage location: Mülheim an der Ruhr
Country of origin: Deutschland
X-Travel: 700 mm
Y-Travel: 630 mm
Z-Travel: 700 mm
Machine length: 4000 mm
Machine width: 3000 mm
Machine Height: 3000 mm
Max. Tool Weight: 10 kg
Max. Tool Length: 350 mm
Bnolpt803t
Max. Tool Diameter: 150 mm
Max. Size Of Workpiece Lxwxh: 750 x 700 mm
Clamping Area: 500 x 500 mm
Tool Taper: SK 40
Numbers Of Tools In Magazin: 130
Turning Speeds: 10000 RPM
Rapid Traverse...
CNC 5-axis HSC vertical machining center EXERON type HSC-MP 7/5 P
Linear milling center with CNC control Heidenhain iTNC 530 HSCI FS
Make no. 6876 Year of construction 2015
Travel distances X: 670 mm, Y: 250 mm, Z: 400 mm
B axis +/? 105 °
C-axis 360° endless
Feed speed 1 to 40000 mm/min.
Rapid traverse in X, Y and Z 40 m/min
turning speeds B-axis 190 rpm.
turning speeds C-axis 250 rpm.
workpiece clamping table Ø 185 mm
distance table/spindle nose 20 - 420 mm
Table load max. 60 kg
Tool holder HSK...
CODE 872
CB FERRARI 5 AXES WORK CENTRE MOD A17 CNC LS500
STATE OF THE CAR: USED;
TECHNICAL CHARACTERISTICS:
Model: A17;
Serial number: AZF91030;
Numerical control: ELEXA MOD 520;
Table surface: 1250 x 400 mm;
Longitudinal X axis stroke: 1050 mm;
Transversal Y axis stroke: 520 mm;
Vertical Z axis travel: 420 mm;
Motor speed: RPM 5000 rpm;
Tool change: ISO 40;
Ysr0fg
Spindle power: 9 KW;
A-axis rotation: 360°;
B-axis rotation: -92°+15°;
Net Weight: 6000 Kg;
Year of construction: 1996;
CE machine;
...
Ref. -No.: 10108
Brand: UNISIGN
Type of control: CNC
Control: Siemens Sinumerik 840 D
Storage location: Mülheim an der Ruhr
Country of origin: Niederlande
X-Travel: 2000 mm
Y-Travel: 750 mm
Z-Travel: 400 mm
C-Axis: vorhanden °
Machine length: 9000 mm
Machine width: 2500 mm
Machine Height: 3350 mm
Spindle Taper: SK 50
Table Load: 1000 kg
Clamping Area: 8 Stück 600 x 600 mm
Tool Piece Magazine With: 51 Pcs./pcs.
Spindle Speed: 6000 RPM
Turning Speed Range - Stepless: 5 - 28.000 mm / min
Rapid Tra...
Parts shown by hand not come.
Bwwcxc9
5-AXIS CNC MACHINING
COVER MAHO DMU 60eVo
Control CNC: HEIDENHAIN iTNC530
Axles
X-axis travel mm: 650
Y-axis travel mm: 500
Z-axis travel mm: 500
Degree of the B axis: -5 + 110 x 0.001
Degree of the C axis: 360 x 0.001
Feed speed longitudinal / transverse / vertical mm / min: 50.000 / 50.000 / 50.000
Rapid traverse longitudinal / transverse / vertical m / min: 50/50/50
Work table
Dimensions mm: 600 x 500
max. workpiece weight kg: 400
Spindle
Spindle speed: 18.000
Spindle drive p...
Stock number : Z100000259
Brand : DMG MORI
Model : DMC 80 U DUOBLOCK
Year of Production : 2005
Control : SIEMENS
Axis Movement : X 800 MM / Y 800 MM / Z 800 MM / B -30 /+180 ° / C 360 °
Spindle Speed :
Tool Holders : HSK-A 63
X / Y / Z / B / C AXIS STROKE : X 800 MM / Y 800 MM / Z 800 MM / B -30 /+180 ° / C 360 °
CONTROL : SIEMENS
TOOL TAPER : HSK-A 63
TABLE SURFACE AREA : 800 X 630 MM
MAX. TABLE LOAD : 1.200 KG
TOTAL POWER REQUIREMENT : 60 KVA
Gwih7s
DIMENSIONS OF THE MACHINE : 3.12 X 4.56 X ...
Ref. -No.: 10079
Brand: SCHIESS
Type of control: CNC
Mvj3iw
Control: Siemens Sinumerik 840 D
Storage location: Mülheim an der Ruhr
Country of origin: Deutschland
Machine-No.: 70140009
X-Travel: 4000 mm
Y-Travel: 3800 mm
Z-Travel: 1250 mm
B-Axis: 0-360 °
C-Axis: +/- 190 °
Clamping Area: 3000 mm
Numbers Of Tools In Magazin: 80
Turning Speeds: 0-20000 RPM
Max. Torque On The Boring Spindle: 2400 Nm
Feed Speeds X/Y/Z Axis: 0-25000 mm / min
Max pallet load: 30000 kg
Drive Capacity - Spindle Motor: 5...
Technical specifications:
Control Unit: OSAI
X-Axis travel: 4800 mm
Y-Axis travel: 1600 mm
Z-Axis travel: 1200 mm
Table length: 4840 mm
Table width: 1360 mm
Max. Spindle speed: 24000 Rpm
Milling motor: 15 Kw
More info:
Olugr
The machine has 4 HSK 63-F tool changers, 2 shuttle tables that exit completely from the machine.
Complete dust and sound booth around the machine.
Aluminum worktop 4,840 x 1,360 mm. With threaded holes, material up to 8 mm.
Notes:
Availability immediately
395.000 €
Offer not including VAT
Another 18 days
Another 18 days
with CNC screen control, make: HEIDENHAIN, type: TNC 640, traverse paths, X axis 1,600 mm, Y axis 1,600 mm, Z axis 1.100 mm, C-axis 360 mm, B-axis 200 mm, 6-fold pallet station, oil mist extraction, cooling system, type: WK 803, chip conveyor, coolant preparation, clamping load 3.500 Kg, 3x tool changer, 1x 82 tools, 2x 81 tools, with operating panel, max. 15.000 rpm, dead weight 42 to.., with approx. 150 additional tool holders HSK 100 (partly equipped with tools), 9 pcs. clamping pallets, addi...
MAX ROTATING DIAMETER: 700 mm
MAX TURNING LENGTH: 630 mm
MAX TURNING DIAMETER: 330 mm
BAR CAPACITY: 75 mm
SPINDLE: 3500 rpm; 15-22 kW; ASA A2-8 ; 254 mm
COUNTER SPINDLE: 7000 rpm; 10-15 kW; 130 mm; ASA A2-5
X-AXIS TRAVEL: 165+35 mm
Y-AXIS TRAVEL: ± 45 mm
Z-AXIS TRAVEL: 600 mm
B-AXIS TRAVEL: 550 mm
RAPID FEEDS X-Y-Z: 24 - 10 - 24 m/min
DRIVEN TURRET HEAD: 12 POS; 4000 rpm; 4,5 kW
H8lriq7
CONTROL UNIT: FANUC 0i-TD
WEIGHT: 6500 Kg
OVERALL DIMENSIONS: 4250 x 1800 x 2260 mm
ACCESSORIES: PARTS C...
5-AXIS CNC MACHINING
Control: FANUC Professional 5
Axles
X-axis travel mm: 550
Y-axis travel mm: 1000
Z-axis travel mm: 500
A-axis travel degree: 150 (+30 - 120º) Rotary encoder
C-axis traverse path degrees: 360 (continuous rotation) / rotary encoder
Rapid traverse m/min: X: 48, Y, Z: 50, A, C: 48
Feed rate mm/min: X: 1 - 32.000, Y, Z: 1 - 40.000, A, C: 1 - 18.000
Work table
diameter rotary table mm: 500
Maximum workpiece size (D x H) mm: 650 x 500 (with restriction)
max. workpiece...
CNC 5-axis vertical machining center MUBEA type Multiflex MF5-750S-16
CNC control SIEMENS 840 D
No. 71103 Year of manufacture 2003
5-axis machining portal with controlled 2-axis fork milling head
Travel distances X: 8500 mm, Y: 1500 mm, Z: 900 mm
Fork milling head (B axis) +/- 115°
Fork milling head (C axis) +/- 210°
Rapid traverse speed (X axis) 80 m/min.
Rapid traverse speed (Y-axis) 60 m/min.
Rapid traverse speed (Z-axis) 60 m/min.
Spindle mount HSK-F63
Tool diameter max. 500 mm (e.g. saw bla...
Ref. -No.: 10012
Brand: SCHIESS
Type of control: CNC
Control: Siemens Sinumerik 840D Simodrive
Storage location: Mülheim an der Ruhr
Country of origin: Deutschland
X-Travel: 4000 mm
Y-Travel: 3800 mm
Z-Travel: 1250 mm
Bnokl2rxy2
B-Axis: 0 - 360 °
C-Axis: +/- 190 °
Clamping Area: 3000 mm
T - groove width: 10 x 28 H12 mm
T - slot spacing: 250 mm
Numbers Of Tools In Magazin: 80 Stk
Turning Speeds: 0 - 2000 RPM
Max. Torque: 2400 Nm
Feed Capacities X/Y/Z: 4000 N
Max pallet load: 3000 kg
Drive Capaci...
Working size: 6.000 x 1.250 mm.
1 Electrospindle 5 axis
1 Tool changer 12 positions
Bod0tpnb0g
1 Drilling head: 12 vertical + 6 horizontal + 1 saw for grooves
1 Vacuum pump 250 m3/h
Samag MFZ 2-3 five-axis three-spindle horizontal machining centre with Siemens Siematic CNC (to include all product specific work piece holders and tooling, etc.), Serial No. 53153, YoM 2009
Xunl8
x-path: 780 mm
y-path: 560 mm
z-path: 560 mm
controlled NC swivel milling head (B axis)
Control: Heidenhain iTNC 530
NC rotary table with pallet carrier
Rotary pallet changer
2 pallets 630 mm x 500 mm
tool holder: SK 40
max. speed: 12 000 rpm
Chain magazine horizontal: 120 places
Total power requirement: 32 kW
Machine weight approx.: 6.7 t
Transport dimensions LxWxH: 3,5x2,7x2,21 m
Space requirement approx. LxWxH: 4,4x5,4x2,9 m
Equipment:
Chip conveyor
Coolant unit IKZ 40 bar
Rotoclear
iTNC 530 ...
5-AXIS CNC MACHINING
MAKINO D500
Hdrmsid
Control: FANUC Professional 5
Axles
X-axis travel mm: 550
Y-axis travel mm: 1000
Z-axis travel mm: 500
A-axis stroke rate: 150 (+30 - 120º) Encoder
C-axis stroke rate: 360 (continuous rotation) / encoder
Rapid traverse m / min: X: 48
Rapid traverse m / min: Y, Z: 50
Rapid traverse m / min: A, C: 48
Feed mm / min: X: 1 - 32.000Feed mm / min: Y, Z: 1 - 40.000
Feed mm / min: A, C: 1 - 18,000
Work table
diameter turntable mm: 500
Maximum work...
