Used 4-Axis Cnc Wire Bending Machine for sale (102,581)

Condition: used, Year of construction: 2019, machine/vehicle number: 0191, For sale: Fenstek Emerald F260, a 4-axis CNC profile machining center from 2019, designed for the precise machining of long aluminum and plastic profiles. Thanks to its working range of up to 7,000 mm and the powerful 9 kW HSD spindle, this machine is particularly suitable for window, door, and facade production. The machine comes from a professional production environment, has been well maintained, is damage-free, and is fully operational. Inspection and a demonstration under power are possible. Key specifications: - Axes: X / Y / Z / A, 4-axis interpolation - Control: PA8000 - Spindle: HSD, 9 kW - Maximum speed: 24,000 rpm - A-axis rotation: +90° to -90° - Working range: up to 7,000 mm, depending on the clamping configuration - Tool magazine: ISO30, 9 positions - Operations: milling, drilling, tapping, grooving, and chamfering - Suitable materials: aluminum profiles, light alloys, and uPVC An interesting machine for companies that want to machine long profiles flexibly and in a single setup. Ledsx R U Eispfx Abzsag

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, operating hours: 200 h, power: 4.5 kW (6.12 HP), input voltage: 380 V, type of input current: three-phase, travel distance X-axis: 1,800 mm, travel distance Y-axis: 4,500 mm, travel distance Z-axis: 1,050 mm, number of axes: 4, controller manufacturer: Syntec, total height: 3,600 mm, total length: 5,800 mm, total width: 2,440 mm, overall weight: 2,600 kg, table length: 5,400 mm, table width: 2,030 mm, For sale is a large-format, 4-axis CNC portal milling machine from Yishun, privately owned. With its enormous working area and 1050 mm Z-axis, the machine is ideal for the precise machining of large components made of foam (Ureol/Styrodur), plastics, wood, and aluminum (e.g., for mold making, boat building, or prototype construction). The machine has only been in operation for approximately 200 hours (year of manufacture 2016) and will be handed over in perfect mechanical and electrical condition. High-quality industrial components have been used throughout. TECHNICAL DATA & COMPONENTS: • Working area (X/Y/Z): 1800 mm x 4500 mm x 1050 mm • External dimensions: approx. 5800 mm x 2440 mm x 3600 mm (L x W x H) • Weight: approx. 2600 kg • Spindle: High-quality HSD spindle • Drives: Reliable, powerful Yaskawa servo motors • Controller: Syntec controller (machine can be moved on-site) • Guides & Mechanics: HIWIN linear guides, WMH rack and pinion with precise Rouist gears on the servo motors, ball screw in the Z-axis feed • Equipment: Integrated zero-point sensor for the Z-axis. Post-processors for HSMtec are available to a limited extent. • Reference: The finely finished aluminum milling sample produced on the machine, shown in the video, is available (see photos). • Note on scope of delivery: The machine does not have an automatic tool changer, dust extraction system, or vacuum clamping table. CONDITION & HISTORY: The machine has been unused but stored dry in a hall for the past few years. To consistently prevent the onset of surface rust due to natural humidity in the winter, the steel structure was recently preventively re-primed and painted. The guides are completely free of rust and have been regularly preserved. The machine runs perfectly mechanically and electrically. IMPORTANT INFORMATION REGARDING TRANSPORT & PICK-UP: 1. Private sale: The sale is made by a private individual, excluding any liability for defects, warranty, or right of return. No VAT can be charged. Purchased as seen and tested. 2. Loading assistance on-site: A suitable forklift will be arranged and can be used free of charge for loading onto your low-bed trailer or truck. 3. Transport options: The machine is primarily intended for self-collection. Delivery within a close radius (up to 50 km) is possibly possible after prior arrangement and upon payment of costs. If transport over longer distances is an issue, we will Lodpfx Abezv U Tbszjag certainly find a joint solution after prior consultation or provide assistance in finding a freight forwarder. We are open to realistic price offers. An inspection and demonstration of the axes on-site in 91183 Abenberg are welcome after prior arrangement.

Condition: used, Year of construction: 2012, total height: 4,500 mm, total length: 8,000 mm, total width: 6,000 mm, overall weight: 50,000 kg, Machine No.: 11720001123 Control Heidenhain iTNC 530 HSCI (3D path control) Travel Paths X: 1,850 mm Y: 2,100 mm Z: 1,250 mm B-axis: controlled universal swivel milling head C-axis: NC rotary table Ø 1,700 mm 5-axis simultaneous machining Spindle Motor spindle SK50 Speed: 20–12,000 min⁻¹ Power: 44 kW (40% duty cycle) / 32 kW (100% duty cycle) Torque: 288 / 187 Nm Tool holder: SK50 according to DIN 69871 Tool Changer 60-fold chain magazine Double gripper Equipment IKZ 40 bar Chip conveyor Tool measurement system Blum Laser NT Hybrid Heidenhain TS 640 infrared probe Electronic handwheel Minimum quantity lubrication (MQL) Oil/emulsion mist separator Coolant through spindle Coolant tank 980 l Rotating viewing window 3D quickSET Machine Protection Control (MPC) Adaptive Feed Control (AFC) ATC (Application Tuning Cycle) DMG MORI NetService DMG MORI SMARTkey Documentation and electrical schematic (German) Travel X-axis: 1850 - mm Dimensions (LxWxH) approx.: 8000 x 6000 x 4500 mm Travel Y-axis: 2100 - mm Weight approx.: 50,000 kg Travel Z-axis: 1250 - mm Year of construction: 2,012 Ledszv A Akopfx Abzoag Condition: in working order Terms of payment: 100% prepayment before pick-up Terms of delivery: EXW EX Works under power: Yes

Condition: new, functionality: fully functional, Year of construction: 2025, pipe diameter (max.): 38 mm, bending angle (max.): 190 °, bending radius (max.): 220 mm, total length: 4,250 mm, power: 19 kW (25.83 HP), input voltage: 400 V, input frequency: 50 Hz, type of input current: three-phase, warranty duration: 24 months, drive type: Servo - Hydraulic, operating speed: 147 mm/s, pressure: 150 bar, wall thickness: 2 mm, working length: 3,600 mm, Equipment: documentation/manual, 38x2mm Fully Automatic Cnc Tube Bending Machine Ledpfxsvurm He Abzeag The "Griffin" tube bending machines are hybrid structures. This type of tube benders includes hydraulic and pneumatic for clamping operations. Bending, feeding, rotation, stack changer and tube aligment operations working with servo engine. Flexible bending and working capacity with CNC control system. The capacity to adjust molds in 3 different radius scales Ability to automatically convert 3D technical drawings to bending program Multivariable roll bending system Ability to work with or without a mandrel Automatic oil cooling system With linear guideway systems minimize the system gaps in moving parts Program changing feature while in the bending process ETU bending simulation program, for bending process, helps to make 3d tube bending arising from the coordinates, with excellent results. With DcOnTool tool, you can convert X, Y, Z coordinates to bending program (Y,B,C) Can review the last error messages with Dlog Its user-friendly, easy, knowledgeable and quick-to-learn design allows you to start the project quickly. Easy to use with 17 inch computer. The vibration-free structure shall help your work. Unlimited program saving and changing Turkish – English and French language 10 years sending spare parts

Condition: new, functionality: fully functional, Year of construction: 2025, pipe diameter (max.): 76 mm, bending angle (max.): 190 °, bending radius (max.): 250 mm, power: 44 kW (59.82 HP), input voltage: 400 V, input frequency: 50 Hz, type of input current: three-phase, warranty duration: 24 months, drive type: Servo - Hydraulic, operating speed: 48 mm/s, pressure: 150 bar, wall thickness: 3 mm, working length: 3,600 mm, Equipment: documentation/manual, 76x3mm Fully Automatic Cnc Tube Bending Machine The "Griffin" tube bending machines are hybrid structures. This type of tube benders includes hydraulic and pneumatic for clamping operations. Bending, feeding, rotation, stack changer and tube aligment operations working with servo engine. Flexible bending and working capacity with CNC control system. The capacity to adjust molds in 3 different radius scales Ability to automatically convert 3D technical drawings to bending program Multivariable roll bending system Ability to work with or without a mandrel Automatic oil cooling system With linear guideway systems minimize the system gaps in moving parts Laodpfovwg H Hsx Abzjg Program changing feature while in the bending process ETU bending simulation program, for bending process, helps to make 3d tube bending arising from the coordinates, with excellent results. With DcOnTool tool, you can convert X, Y, Z coordinates to bending program (Y,B,C) Can review the last error messages with Dlog Its user-friendly, easy, knowledgeable and quick-to-learn design allows you to start the project quickly. Easy to use with 17 inch computer. The vibration-free structure shall help your work. Unlimited program saving and changing Turkish – English and French language 10 years sending spare parts

Year of construction: 2010, operating hours: 900 h, condition: excellent (used), functionality: fully functional, AXIS TRAVEL X-AXIS (longitudinal) (mm) 4,300 Y-AXIS (transversal) (mm) 270 Rotary table -90°/90° continuous ELECTROSPINDLE Maximum power in S1 (kW) 5.5 Maximum speed (rpm) 20,000 Tool clamping cone HSK - 63F AUTOMATIC TOOL MAGAZINE Maximum number of tools in magazine 8 Ledpfxszq Rn Ds Abzjag Maximum diameter of blade that can be inserted into the magazine (mm) Ø = 180

Year of construction: 2018, condition: ready for operation (used), Rotation axis: 360°, max. rotational speed: 60.000/min, including accessories and documentation. Lajdpfxoihp Ipe Abzog

Year of construction: 2006, condition: ready for operation (used), Travels X/Y/Z: 885mm/600mm/600mm, travels B/C: -10° - 110°/360°, rapid traverse X/Y/Z: 9000mm/min, speed: 28000rpm. Table dimensions X/Y: 950mm/650mm, operating hours: 90711h, spindle hours: 19457h. Including workpiece measuring probe, tool changer with 100 places. Ledjta H S Sjpfx Abzeag

Condition: ready for operation (used), Year of construction: 2019, X-axis: 620mm, y-axis: 520mm, z-axis: 460mm, B-axis: -50° to +110°, C-axis smallest increment: 0.001°, distance from spindle nose to table surface B/C-axes: 140-600mm, B/C-axis rotary table diameter: 650mm, centering bore: Ø55H7x12, T-slots quantity/width/pitch: 5x18x100, max. workpiece dimensions: Ø520x330mm, max. table load (90°/horizontal): 200/300kg, max. spindle speed (standard) direct drive: 12,000/min, spindle bearing inner diameter: 70mm, rapid traverse X/Y/Z: 36m/min, working feed rate: 1-10m/min, rapid traverse B/C-axis: 25rpm, tool holder: MAS BT-40, number of tool positions: 40, max. tool length: 250mm, max. tool weight: 7kg, compressed air requirement: 0.6MPa / 500l/min, coolant tank capacity: 420l, connected load: 45kVA, control: Heidenhain iTNC 640 HSCI, length: 2325mm, width: 4210mm, height: 3108mm, weight: 9.5t, operating hours control on: 9,380h, machine on: 9,501h, program run: 3,141h, hydraulics: 8,371h, axes: 1,863h, spindle S1: 2,377h. Equipment: roller guideways in all 3 linear axes (Taiwan manufacture), spindle chiller, hydraulic unit, central lubrication system, oil separator, water gun, air gun, full enclosure, machine light and warning light, M30 machine shutdown, air conditioning unit for electrical cabinet, chip conveyor (scraper-type design), chip bin, work area flushing device, tailstock support for rotary table, roller guideways in all 3 linear axes, CE-compliant design, CTS (coolant through spindle), Heidenhain linear scales X/Y/Z, workpiece probing system, transformer, oil mist extraction unit, collision protection software, spindle thermal compensation, with documentation. An on-site inspection is possible. Laodszavyfjpfx Abzjg

Condition: ready for operation (used), Year of construction: 2018, Max. profile length for 3 side machining: 7600mm, Y axis: 845mm, Z axis: 620mm, max. travel speed X axis: 63m/min, max. travel speed Y axis: 60m/min, max. travel speed Z axis: 60m/min, swivel range A axis: −90°, 0°, +90°, max. spindle speed: 24,000/min, spindle power: 11kW S1, machining direction: top/front/rear/left/right, positioning accuracy: 0.1mm/m, tool holder: HSK-63F, disc milling cutter diameter: 120mm, saw blade diameter: 180mm, software: eluCam, connected load: 30kVA, compressed air connection: 7bar, compressed air consumption: approx. 180l/min, length: 10,775mm, width: 3430mm, height: 2950mm, weight: 4.9t, operating hours reading: 1550h, standby: 6300h. Accessories: length measurement for profile bar, HSK-63F tool holder set, five chucks, eight collets, 2 layer length machining with second light barrier, camera system, additional stationary tool magazine for eight tools, barcode scanner for reading orders/machining operations and documentation. Was serviced regularly, an on-site inspection is possible. Lajdpfx Abjzbb Rrszog

Condition: ready for operation (used), Year of construction: 2005, Offered is a CNC horizontal machining center. Working area X/Y/Z: 750mm/750mm/850mm, pallet size: 550mm/550mm (2-position changer), spindle speed: 15000rpm, tool holder: SK50, tool magazine: 60 positions (chain type), B-axis: 0.001°, max. loading weight: 800kg, rapid traverse: 60m/min, power-on hours: 64148h, feed time: 21867h, control: Fanuc 31i. Equipped with 2-position pallet changer, coolant filtration system (central system designed for up to 3 machines), cooling unit, oil mist extraction system, tool package (15x drill chucks, 8x collet chucks, 13x face clamping holders), linear measuring system X/Y/Z, weight: approx. 12500kg, overall dimensions X/Y/Z: approx. 5500mm/3500mm/3200mm. Inspection possible by arrangement. Laodpfx Abjy T N Hyozjg

Condition: ready for operation (used), Year of construction: 2010, Workpiece diameter: 500mm, workpiece height: 730mm, travel X/Y/Z: 630mm/765mm/600mm, A-axis: -120°/+30°, C-axis: +/-360°, max. table load: 500kg, spindle interface: HSK-A63, speed: 18000rpm, rapid traverse: 52m/min, feed rate: 52m/min, rotary table diameter: 610mm, tool positions: 30, control: Mazak Mazatrol Matrix. Documentation available. An on-site inspection is possible. The machine is located in China. Ledpsx Aunxofx Abzeag

Year of construction: 1978, condition: ready for operation (used), A Haeusler CNC large-format 4-roll plate bending machine is available. Number of rolls: 4, Roll width: 3050mm, Max. prebending plate width: 3000mm, Max. prebending plate thickness: 60mm, Max. rolling capacity at max. plate width and 3500mm bending diameter: 70mm, Roll diameter top/bottom/side: 620mm/600mm/500mm, Max. top roll load: 12000kN, Operating speed: 4m/min, Connected load: 132kW, Weight: approx. 85t. Including cone bending device. Documentation available. An on-site inspection is possible. Ledpfx Abjzka H Ajzoag

Condition: ready for operation (used), Year of construction: 2009, Travel ranges working area 1: X: 6450mm, Y: 1535mm, Z: 250mm, working area 2: X: 6200mm, Y: 1535mm, Z: 250mm, working area 3: X: 6200mm, Y: 1520mm, Z: 275mm, axis travel configuration 1: X: 6820.5mm, Y: 1963mm, Z: 350mm, axis travel configuration 2: X: 6820.5mm, Y: 1963mm, Z: 350mm, axis travel configuration 3: X: 6820.5mm, Y: 1963mm, Z: 663mm (5-axis head), Z: 350mm (additional machining units), control: Biesse XP600. Maintenance: complete C-axis was replaced in 2015 including accessories, vacuum pump was fully replaced in 2016 including bellows, hoses and additional components, in 2021 the machine was equipped with a new high-performance control PC running a current Windows 10 operating system. With extensive documentation. An on-site inspection is possible. Ljdsylziispfx Abzjag

Condition: ready for operation (used), Year of construction: 1999, Tube diameter: 25mm, wall thickness: 2mm, bending angle: 190°, feed length: 2000mm, weight: 2t, left-bending. Accessories: CNC IsoBend 2.0. Without mandrel bending device, monitor glass has impact damage but is still functional. An on-site inspection is possible. Lodsxcx Atepfx Abzsag

Condition: ready for operation (used), Year of construction: 2008, Offered is a CNC horizontal milling machine. Working area X/Y/Z: 1000mm/800mm/850mm, pallet size: 630x630mm, table load: 1300kg, B-axis indexing: 0.001°, spindle speed: 6000rpm, spindle power: 30kW, spindle torque: 600Nm, tool holder: SK50, magazine positions: 120, spindle internal cooling pressure: 70bar, pump capacity LD: 150l/min at 3bar, pump capacity MD: 40l/min at 7bar, pump capacity HD: 32l/min at 70bar, cooling capacity cooling unit: 11.8kW, control: FANUC 31iMA. Equipped with additional pallets with threaded grid (24xM16 in 125mm grid), direct absolute scales, spindle internal cooling system, automatic scraper belt chip conveyor with 1000l dirty water fine filtration, recirculating chiller, washing shower, mist extraction system, touch probe. Weight: approx. 18500kg, overall dimensions X/Y/Z: approx. 6800mm/4200mm/3400mm. Inspection possible by arrangement. Ljdpfx Aoy T N H Hsbzeag

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, operating hours: 3,000 h, number of axes: 5, number of slots in tool magazine: 24, We are offering this well-maintained, young COSMEC 5-axis CNC milling machine, model CONQUEST 515, from 2021. The machine is currently in production and operates on a single-shift basis. It can be inspected and tested while powered on. - Training/instruction for your employees can be provided at our facility before the machine is disassembled. Ljdpfx Abozukurjzsag - Year of manufacture: 2021, commissioning date: 05/2021 - Work table: 4000mm x 1500mm - OSAI control system - 24-position tool changer (2 disks with 12 tools each) - Portal clearance: 500mm - 5-axis swivel head: 18KW, 500 - 24,000 RPM - NC-controlled extraction hood - Bumper safety system - Control cabinet with air conditioning unit - Mobile control panel - Central lubrication system - Vacuum pump: 250 m³/h - Approximately 24 HSK63F tool holders - Automatic tool length measurement - Nesting table - Nesting CNC milling machine - Swivel machining is possible The price is "Ex Works". We will gladly assist with disassembly and loading. Similar to Reichenbacher Vision or Homag CNC. If you have any questions or would like to arrange a viewing, please feel free to contact me by phone or email.

Condition: used, Year of construction: 2009, machine/vehicle number: 30008138, Travel ranges X/Y/Z: approx. 3,500 x 1,000 x 770 mm, table size: approx. 1,000 x 4,150 mm, power: 40 kVA, machine weight: 25,000 kg, chip conveyor AME, control system HEIDENHAIN ITNC620, rigid tool clamping plate approx. 1,200 x 3,500 mm, tool changer HSK-A63, 1 mobile workbench, 5-axis, 1-door, contents: hand tools. Ledpfx Ajzqzdvsbzjag

Condition: used, Year of construction: 2007, operating hours: 70,859 h, machine/vehicle number: 15145361464, Travel ranges (X/Y/Z): 3,600/920/820 mm, with B-axis and integrated NC table, maximum spindle speed: 18,000 rpm, tool interface HSK-A63, 30-position tool changer, pendulum machining, control system SIEMENS Sinumerik 840 D Powerline, chip conveyor, emulsion separator, infrared measuring probe. The customer must ensure that drilling emulsion/lubricants are professionally extracted and disposed of. Laedpozqy Umsfx Abzjg

Condition: used, Year of construction: 2017, operating hours: 18,074 h, machine/vehicle number: 302-58, Travel ranges (X/Y/Z): 550/300/425 mm, spindle speed max.: 10,500 rpm, tool holder SK 40, machine weight: 6,500 kg, control system SIEMENS Sinumerik 840 D, chip conveyor KNOLL 600 K-1/320, belt filter system BÜRENER MASCHINENFABRIK KA M. TPF 150/510S, year of manufacture: 2017, rotary table. Drilling emulsion/lubricants must be extracted and disposed of by the customer in a professional manner. Lajdpfx Ajzqy Utsbzjg

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, machine/vehicle number: 193.006, travel distance X-axis: 350 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 256 mm, wire diameter (max.): 0.33 mm, controller model: AGIEVISION / AGIE HSS-Steuerung, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel in X-axis: 350 mm Travel in Y-axis: 250 mm Travel in Z-axis: 256 mm Travel in U/V axes: ±70 mm Positioning resolution: 0.0001 mm Positioning accuracy: approx. ±3 µm Machining data Max. taper: 30° at a workpiece height of 100 mm Surface finish: up to approx. Ra 0.2 µm with multiple finishing passes Workpiece data Workpiece size, maximum dimensions: 750 × 550 × 250 mm Workpiece weight, maximum: 450 kg Wire system Wire diameter: 0.10 – 0.33 mm Wire speed: up to approx. 3 m/min Lsdpszpypzjfx Abzeag Wire tension: CNC-controlled MACHINE DETAILS Control system: AGIEVISION / AGIE HSS Generator: AGIE HSS Mains connection: 3 × 400 V, 50 Hz Connected power: approx. 10.5 kVA Dimensions & Weight Dimensions (L × W × H): approx. 2,215 × 2,215 × 2,220 mm Machine weight: approx. 3,600 kg EQUIPMENT Fully automatic wire threading

Condition: refurbished (used), Year of construction: 2012, functionality: fully functional, Year of manufacture: 2012 Control system: Siemens 840D SL Spindle: SC63, 16,000 rpm, 40 kW, 96 Nm Tool clamping system: HSK 63 Tool magazine / positions (options): Chain / 54 Rotary table: 360,000° x 0.001° Coolant system: KNOLL, VRF 250, IKZ 50 bar, (work area flushing) Working area XYZ (mm): 630 / 630 / 630 Pallet size (mm): 500 x 400 Workpiece clamping: Hydraulic, 60 bar Laodpszpyg Tefx Abzjg Additional options, special features: Infrared receiver for measuring probe (RENISHAW); SBBK; Pneumatic support control at the workpiece setup station; Status indicator light; Chip conveyor for wet machining;

Condition: excellent (used), Year of construction: 2008, travel distance X-axis: 3,000 mm, travel distance Y-axis: 825 mm, travel distance Z-axis: 1,100 mm, rapid traverse X-axis: 48,000 m/min, rapid traverse Y-axis: 80,000 m/min, rapid traverse Z-axis: 48,000 m/min, table width: 835 mm, table length: 3,500 mm, table load: 3,500 kg, 1 Axis CNC Swivel head, infinitely variable Axis drive with ball screw drive Roller linear guides in all axes Lajdpfjwyv Nzsx Abzog Direct path measuring systems Full work area encosure with roof Chip conveyor Coolant unit X - Travel: 3000mm Y - Travel: 825mm Z - Travel: 1100mm B - Axis: - 3 to + 105° Table Length: 3500mm Table Width: 835mm Table load: 3500 Feed rate X-Axis: 48000mm/min. Feed rate Y-Axis: 80000mm/min. Feed rate Z-Axis: 48000mm/min. Spindle Taper: HSK 100ISO/Bt/Mk Power on spindle: 37kW Speeds / ranges: 8000Rpm ATC / revolver: 40 Coolant through spindle / Bar:25 Number of controlled axis: 4 Chip conveyor: Yes Coolantsystem: Yes Length: 8000mm Width: 3800mm Height: 3800mm

Condition: excellent (used), Year of construction: 2015, operating hours: 12,500 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 550 mm, spindle speed (max.): 18,000 rpm, overall weight: 12,500 kg, We offer in perfect condition Hermle C42U Dynamic with Heidenhain 640 control. Machine has 12.000 spindle hours. X-Axis travel: 800 mm Y-Axis travel: 800 mm Z-Axis travel: 550 mm Dynamic package torque axis, table Ø440 with secondary claming plates 920 x 490 mm Lodpfx Abjzpfg Eozjag Spindle: HSK-A63 18.000 RPM Machine will be in stock in 2 weeks

Condition: used, CNC press brake FASTI, Type 904-125/30 Serial No. 95-904-5775 Year of manufacture 1995 Press force 125 tons Working length 3050 mm Stroke approx. 335 mm Stand distance 300 mm Distance between side stands 2550 mm Tool installation height max. 465 mm (opening width between tool holders) Table width 90 mm (the clamping system is mounted on the table) Table height above floor 875 mm (910 mm with clamping system) Back gauge X-axis 500 mm Back gauge R-axis 115 mm Back gauge Z-axis approx. 1950 mm Lajdpfx Abohmmfkezeg Lowering speed Y-axis rapid traverse 90 mm/s Lowering speed Y-axis working traverse 8.9 mm/s Return speed Y-axis retraction 75 mm/s Oil capacity approx. 160 liters Motor power 18.5 kW Mains connection 400 volts, 50 Hz, 20 amps - 7-axis CNC control DELEM, Type DA 58 with LCD screen - 1 axis for back gauge - gauge depth (X-axis) - 2 axes for back gauge - gauge height (finger R1 + finger R2) - 2 axes for back gauge - gauge fingers, laterally adjustable (finger Z1 + finger Z2) - 2 axes for press beam with servo valves and measuring system Y1 and Y2 - Operation via electric foot switch and 2-hand control panel or only 2-hand control panel - Hydraulic tool clamping for the upper tool system TRUMPF, with 20 mm clamping groove - Hydraulic tool clamping for the lower tool with 13 mm table groove, depth 21 mm (tool shank 13 x 20 mm) - Safety light curtain FIESSLER, Type AKAS - 2 pcs material support arms, manually adjustable laterally and in height - Electrical diagram, hydraulic diagram, user manual for control system available - Control cabinet on the machine - Without tools Space requirement L x W x H 5000 x 2500 x 3050 mm Transport dimensions L x W x H 5200 x 1900 x 2950 mm Weight 8.5 tons Good condition
